Page 1

TV-2010

SERVICE MANUAL

COLOR TEREVISION

MODEL CODE : 86HR8-0117(B)

86HR8-1111(W) 86HR8-4444(L) 86HR8-8888(ST)

このサービスマニュアルはシンプル版です。改定版発行時に差し替えて使用してください。

• Replace this Service Manual with ”Revision Publishing” when it is issued.

S/M Code No. 09-003-340-3T1

SIMPLE

DATA

Page 2

ELECTRICAL MAIN PARTS LIST -1

PART NO. KANRI

NO.

87-A20-364-010 IC,KIA7809PI 87-027-666-010 IC,TC4052BP 87-A20-312-010 IC,M62420SP 87-070-237-010 IC,LA7832 87-A30-041-110 TR,SE115N

87-A20-611-080 IC,M51943BSL-700A 8Z-JAD-621-010 IC,M37272M8-165SP 87-A91-538-010 RCR UNIT,SBX1981-72P 87-A21-433-010 IC,KS24C041I 87-A21-299-010 IC,LA6458SLL

8Z-JBJ-605-010 IC,TA1268N 87-002-421-010 IC,NJM2233BL 87-A21-283-010 IC,AN5277 87-A21-259-010 IC,MM1454XD 87-A21-169-010 IC,MM1124B

87-A21-345-010 IC,NJM2150 87-A21-344-010 IC,STR-F6656

TRANSISTOR

89-337-794-580 TR,2SC3779 D/E 87-A30-091-080 FET,2SJ460 87-A30-114-080 TR,2SD1207T 89-208-922-380 TR,2SB892 ST 87-026-269-080 TR,DTA114ES

89-327-854-080 TR,2SC2785F 89-111-755-080 TR,2SA1175F 87-A30-121-080 TR,DTC 323 TS 87-A30-090-080 FET,2SK2541 87-A30-176-010 TR,2SC1573A P/Q/R

89-320-012-080 TR,2SC2001L 87-A30-095-010 TR,2SD2333LS/C202

DIODE

87-017-654-060 DIODE,GBU6JL6131 87-070-111-060 DIODE,RU30A 87-017-352-090 DIODE,RU3YX 87-070-112-060 DIODE,RU4YX 87-017-931-080 ZENER,MTZJ5.6B

87-002-743-080 ZENER,MTZJ 33B 87-070-136-080 ZENER,MTZJ5.1B 87-A40-523-080 ZENER,MTZJ9.1B 87-A40-348-080 ZENER,MTZJ3.3A 87-020-465-080 DIODE,1SS133 (110MA)

87-A40-286-080 DIODE,RGP10JE-5025 87-070-274-080 DIODE,1N4003 SEM 87-017-932-080 ZENER,MTZJ6.2B 87-A40-450-090 DIODE,RU 1P 87-A40-611-080 ZENER,MTZJ3.9B

87-A40-249-080 ZENER,MTZJ 15A

MAIN C.B

BT301 87-JBC-625-010 CONN ASSY,5P V WHT TV-NK BT401 8Z-JAE-615-110 CONN ASSY,4P V GRAY JK BT601 87-JBC-626-010 CONN ASSY,4P V WHT TV-NK C1 87-016-624-080 CAP,E 10-16 SSL C2 87-018-134-080 CAPACITOR,TC-U 0.0116

C3 87-018-134-080 CAPACITOR,TC-U 0.0116 C5 87-016-633-080 CAP,E 1-50 SSL C6 87-018-134-080 CAPACITOR,TC-U 0.0116 C7 87-016-621-080 CAP,E 220-10 SSL C10 87-018-119-080 CAP, CER 100P-50V

C15 87-018-123-080 CAP, CER 220P-50V

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

C16 87-016-633-080 CAP,E 1-50 SSL C17 87-018-131-080 CAP, CER 1000P-50V C18 87-018-128-080 CAP, CERA-SOL SS 560P C19 87-016-629-080 CAP,E 0.1-50 SSL C21 87-018-115-080 CAP, CER 47P-50V C22 87-018-115-080 CAP, CER 47P-50V C23 87-018-125-080 CAP, CER 330P-50V C24 87-018-131-080 CAP, CER 1000P-50V

C25 87-016-629-080 CAP,E 0.1-50 SSL C28 87-018-117-080 CAP,TC-U 68P-50 SL C29 87-018-117-080 CAP,TC-U 68P-50 SL C101 87-016-636-080 CAP,E 4.7-50 SSL C104 87-016-621-080 CAP,E 220-10 SSL

C106 87-A10-576-010 CAP,CER 0.01-50 Z YF C110 87-018-134-080 CAPACITOR,TC-U 0.0116 C111 87-018-134-080 CAPACITOR,TC-U 0.0116 C201 87-018-134-080 CAPACITOR,TC-U 0.0116 C202 87-018-134-080 CAPACITOR,TC-U 0.0116

C203 87-016-632-080 CAP,E 0.47-50 SSL C204 87-018-134-080 CAPACITOR,TC-U 0.0116 C205 87-016-577-080 CAP,E 470-16 SSL C207 87-016-632-080 CAP,E 0.47-50 SSL C208 87-018-134-080 CAPACITOR,TC-U 0.0116

C209 87-016-576-080 CAP,E 330-16 SSL C210 87-018-115-080 CAP, CER 47P-50V C211 87-A11-080-080 CAP,TC U 47P-50 J CH C214 87-016-627-080 CAP,E 47-16 SSL C251 87-018-134-080 CAPACITOR,TC-U 0.0116

C252 87-016-574-080 CAP,E 100-16 SSL C253 87-A10-112-080 CAP,E 100-10 SSL C254 87-015-464-080 CAP,E 4.7-16 BP C255 87-015-464-080 CAP,E 4.7-16 BP C301 87-016-624-080 CAP,E 10-16 SSL

C302 87-016-624-080 CAP,E 10-16 SSL C303 87-016-624-080 CAP,E 10-16 SSL C304 87-016-637-080 CAP,E 10-50 SSL C305 87-018-134-080 CAPACITOR,TC-U 0.0116 C306 87-016-574-080 CAP,E 100-16 SSL

C308 87-016-632-080 CAP,E 0.47-50 SSL C310 87-018-119-080 CAP, CER 100P-50V C311 87-A11-148-080 CAP,TC U 0.1-50 Z F C312 87-A11-148-080 CAP,TC U 0.1-50 Z F C313 87-A11-148-080 CAP,TC U 0.1-50 Z F

C314 87-018-134-080 CAPACITOR,TC-U 0.0116 C315 87-018-131-080 CAP, CER 1000P-50V C316 87-016-634-080 CAP,E 2.2-50 SSL C317 87-016-634-080 CAP,E 2.2-50 SSL C318 87-018-134-080 CAPACITOR,TC-U 0.0116

C319 87-016-575-080 CAP,E 220-16 SSL C320 87-016-587-090 CAP,E 1000-25 M SSL C321 87-016-636-080 CAP,E 4.7-50 SSL C323 87-016-625-080 CAP,E 22-16 SSL C324 87-016-632-080 CAP,E 0.47-50 SSL

C328 87-016-624-080 CAP,E 10-16 SSL C330 87-016-633-080 CAP,E 1-50 SSL C332 87-018-134-080 CAPACITOR,TC-U 0.0116 C333 87-018-125-080 CAP, CER 330P-50V C334 87-018-134-080 CAPACITOR,TC-U 0.0116

C335 87-016-574-080 CAP,E 100-16 SSL C336 87-A11-148-080 CAP,TC U 0.1-50 Z F C338 87-016-632-080 CAP,E 0.47-50 SSL C342 87-010-529-080 CAP,E 1-50 BP C343 87-018-131-080 CAP, CER 1000P-50V

Page 3

ELECTRICAL MAIN PARTS LIST -2

PART NO. KANRI

NO.

C344 87-A11-080-080 CAP,TC U 47P-50 J CH C346 87-016-622-080 CAP,E 470-10 SSL C348 87-018-126-080 CAP,TC-U 390P-50 B C401 87-018-134-080 CAPACITOR,TC-U

0.01-16 C402 87-016-627-080 CAP,E 47-16 SSL

!C403 87-010-399-090 CAP,E 3300-35 SME C404 87-018-134-080 CAPACITOR,TC-U

0.01-16 C405 87-018-134-080 CAPACITOR,TC-U

0.01-16 C406 87-018-134-080 CAPACITOR,TC-U

0.01-16 C407 87-016-627-080 CAP,E 47-16 SSL C408 87-016-574-080 CAP,E 100-16 SSL C409 87-016-625-080 CAP,E 22-16 SSL C410 87-016-624-080 CAP,E 10-16 SSL C411 87-016-624-080 CAP,E 10-16 SSL C412 87-016-624-080 CAP,E 10-16 SSL

C413 87-016-624-080 CAP,E 10-16 SSL C414 87-016-624-080 CAP,E 10-16 SSL C415 87-016-633-080 CAP,E 1-50 SSL C416 87-016-633-080 CAP,E 1-50 SSL C417 87-018-134-080 CAPACITOR,TC-U

0.01-16

C418 87-016-624-080 CAP,E 10-16 SSL C419 87-A10-112-080 CAP,E 100-10 SSL C428 87-016-627-080 CAP,E 47-16 SSL C429 87-016-627-080 CAP,E 47-16 SSL C430 87-018-134-080 CAPACITOR,TC-U

0.01-16

C435 87-016-627-080 CAP,E 47-16 SSL C436 87-018-134-080 CAPACITOR,TC-U

0.01-16 C437 87-016-624-080 CAP,E 10-16 SSL C440 87-016-627-080 CAP,E 47-16 SSL C444 87-016-633-080 CAP,E 1-50 SSL

C445 87-016-591-080 CAP,E 100-35 SSL C447 87-016-633-080 CAP,E 1-50 SSL C449 87-016-588-090 CAP,E 2200-25 SSL C450 87-016-588-090 CAP,E 2200-25 SSL C453 87-016-574-080 CAP,E 100-16 SSL

C454 87-016-624-080 CAP,E 10-16 SSL C455 87-016-624-080 CAP,E 10-16 SSL C459 87-015-464-080 CAP,E 4.7-16 BP C460 87-015-464-080 CAP,E 4.7-16 BP C465 87-018-134-080 CAPACITOR,TC-U

0.01-16

C466 87-016-624-080 CAP,E 10-16 SSL C473 87-018-118-080 CAP,TC-U 82P-50 B C474 87-018-118-080 CAP,TC-U 82P-50 B C475 87-018-117-080 CAP,TC-U 68P-50 SL C476 87-018-117-080 CAP,TC-U 68P-50 SL

C477 87-015-464-080 CAP,E 4.7-16 BP C478 87-015-464-080 CAP,E 4.7-16 BP C487 87-016-633-080 CAP,E 1-50 SSL C488 87-016-633-080 CAP,E 1-50 SSL C495 87-018-115-080 CAP, CER 47P-50V

C496 87-018-115-080 CAP, CER 47P-50V C502 87-A10-831-080 CAP,E 1000-25 M SMG C503 87-016-633-080 CAP,E 1-50 SSL C504 87-016-633-080 CAP,E 1-50 SSL C508 87-A10-469-080 CAP,CER 2200P-500 K B DD10

C510 87-018-131-080 CAP, CER 1000P-50V C511 87-016-591-080 CAP,E 100-35 SSL C601 87-016-644-080 CAP,E 10-100 SSL C604 87-016-593-080 CAP,E 470-35 M SSL C606 87-A10-675-090 CAP,M/P 0.56-250 J

C608 87-A10-833-010 CAP,CER 1000P-2K K R LONG C609 87-A11-047-090 CAP,M/P 8200P-1.25 H PHS !C610 87-010-974-080 CAP,CER 220P-500 B

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

!C611 87-010-974-080 CAP,CER 220P-500 B C612 87-016-624-080 CAP,E 10-16 SSL

C615 87-016-215-080 CAP,E 1-160 M TWSS C616 87-A10-833-010 CAP,CER 1000P-2K K R LONG !C801 87-A10-688-090 CAP,M/P 0.22-275 K (B81133) !C803 87-A10-517-010 CAP,CER 3300P-4K M E KX !C804 87-A10-517-010 CAP,CER 3300P-4K M E KX

C805 87-016-633-080 CAP,E 1-50 SSL C806 87-A11-825-010 CAP,CER 120P-2K J SL C807 87-018-127-080 CAP, CER 470P-50V !C808 87-A11-992-090 CAP,E 330-400 105 KMH C810 87-016-628-080 CAP,E 10-25 SSL

C811 87-016-582-080 CAP,E 47-25 SSL C812 87-A11-302-090 CAP,M/P 0.01-630 J ECQF6(ZH) C814 87-018-130-080 CAP,TC-U 820P-50 B C815 - - - CAP,CER 470P-2K K R C816 87-A10-731-090 CAP,E 220-160 M KMF !C817 87-A10-688-090 CAP,M/P 0.22-275 K (B81133) C819 87-016-587-090 CAP,E 1000-25 M SSL C821 87-010-446-010 CAP,E 2200-35 KME C822 - - - CAP,CER 1000P-1K KB C827 87-016-587-090 CAP,E 1000-25 M SSL

C830 87-A11-824-010 CAP,CER 100P-2K J SL C831 - - - CAP,CER 330P-2K KR CF201 84-LB3-626-010 FLTR,TPS4.5MB2 CF202 87-008-574-080 FLTR,SFSH4.5MCB CN1 87-009-195-010 CONN,5P B5BEH

CN401 87-049-469-010 CONN,4P V CN601 87-A60-933-010 CONN,4P V B04(5-3)B DVS-L CN604 87-A60-485-010 CONN,2P V LV GRA !CN801 87-099-674-010 CONN,2P VA V !CN802 82-481-649-010 PLUG,2P MINI(*)

CNA401 87-JB8-601-010 CONN ASSY,4P SP-20 D1 87-070-110-010 LED,SLP-181B-51 D810 87-A90-965-010 VRIS,TNR15G471K !F801 87-035-192-010 FUSE, 4AT FB801 87-003-320-080 F-BEAD,FBR07HA121NB

FB803 87-003-320-080 F-BEAD,FBR07HA121NB FB804 87-003-320-080 F-BEAD,FBR07HA121NB FB805 87-003-320-080 F-BEAD,FBR07HA121NB FB806 87-003-320-080 F-BEAD,FBR07HA121NB FB807 87-003-320-080 F-BEAD,FBR07HA121NB

!FC801 87-033-213-080 CLAMP, FUSE !FC802 87-033-213-080 CLAMP, FUSE FR601 87-A00-063-060 RES,FUSE 2.2-1/2W J R-TYPE FR602 87-A00-055-060 RES,FUSE 2.2-2WJ R-TYPE FR604 87-A00-106-060 RES,FUSE 3.3-1W J R-TYPE

FR801 87-029-070-090 RESISTOR, FUSE 1/4W

2.2 HL1 84-LB3-216-010 HLDR,LED J401 87-A60-856-010 JACK,PIN 3P J402 87-A60-324-110 JACK,PIN 6P Y-W-R W/SW J403 87-A60-858-010 JACK,3.5 BLK ST 2 SW

L2 87-005-614-080 COIL 100UH LAV35 J L104 87-003-139-080 COIL,0.56UH L201 8Z-JBR-612-010 COIL,SIF 4.5MHZ 504BN L203 87-003-148-080 COIL BIAS 33UH L204 87-003-282-080 COIL,12UH

L205 8Z-JBH-610-010 COIL,PIF-SQ57EL349A

45.75MHZ L206 87-005-612-080 COIL,68UH J LAV35 L207 87-003-147-080 COIL, 22UH L208 87-003-150-080 COIL, 68UH J LAL02 L251 87-005-610-080 COIL,47UH LAV35 J

Page 4

ELECTRICAL MAIN PARTS LIST -3

PART NO. KANRI

NO.

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

L401 87-005-507-080 COIL,22UH FL0606 J L402 87-005-507-080 COIL,22UH FL0606 J L403 87-005-610-080 COIL,47UH LAV35 J L404 87-005-507-080 COIL,22UH FL0606 J L602 87-A50-040-010 COIL,2.2MH

L801 87-A50-176-080 COIL,33UH-PJ87 !LF801 87-JB8-651-010 FLTR,LINE SS24 H-K15070 !LF802 8Z-JAD-610-010 FLTR,LINE FLF 15N022AV !PR801 87-A90-090-080 PROTECTOR,1.5A 491SERIES 60V !PR802 87-A90-195-080 PROTECTOR 7A 60V 491SERIES

!PR804 87-A90-195-080 PROTECTOR 7A 60V 491SERIES !PS801 87-A91-407-010 P-COUPLER,ON3171-R !PS802 87-A91-407-010 P-COUPLER,ON3171-R !PT801 8Z-JAD-801-010 PT,SW ZJA-D R107 87-A00-154-090 RES,M/F 18K-1W J RSF(S)

R110 87-A00-160-090 RES,M/F 33-2W J RSF(S) R312 87-025-602-090 RES,M/O 39-2W J R429 87-025-381-080 RES,M/F 18K-1/6W F R430 87-025-424-080 RES,M/F 10K 1/6W F R431 87-025-380-080 RES,M/F 15K-1/6W F

R432 87-025-381-080 RES,M/F 18K-1/6W F R450 87-A00-624-090 RES,M/F 3.3-7W J RSV7 R505 87-A00-563-090 RES,M/F 1.5-1/2W J ERXS R606 87-A00-196-090 RES,M/F 0.47-1/2W J RSF(S) R610 87-A00-123-090 RES,M/F 3.9K-2W J RSI-2S B R611 87-A00-561-090 RES,M/F 4.7K-2W J ERGS R624 87-A00-544-090 RES,M/F 220-3W J ERGS R804 87-A00-543-080 RES,SD 8.2M-1W J RCR60 R806 87-A00-204-090 RES,CEM 0.18-5W K R809 87-A00-552-010 RES,CEM 1.0-10W J MPC722

R810 87-A00-552-010 RES,CEM 1.0-10W J MPC722 R812 87-A00-576-090 RES,M/F 27K-5W J RSV5 R813 87-A00-577-090 RES,M/F 22K-2W J RSF(S) R816 87-A00-411-090 RES,M/F 33K-1W J R824 87-A00-577-090 RES,M/F 22K-2W J RSF(S)

SF201 8Z-JBH-633-010 FLTR,SAW M1969-US SW2 87-A90-712-080 SW,TACT EVQ11L07K SW3 87-A90-712-080 SW,TACT EVQ11L07K SW4 87-A90-712-080 SW,TACT EVQ11L07K SW5 87-A90-712-080 SW,TACT EVQ11L07K

SW6 87-A90-712-080 SW,TACT EVQ11L07K SW7 87-A90-712-080 SW,TACT EVQ11L07K !SW801 87-A90-364-010 SW,PUSH SDDLB1-C-D-2 !T601 8Z-JBS-605-010 FBT, HFT3608(SAN)20-C !T602 8Z-JBH-615-010 TRANS,US ETH09K10AZ

!TH801 87-A91-405-010 POS-THMS,T209-B80-A10 TU101 8Z-JBE-610-010 TU UNIT,USA ENV56D74G3 X1 87-A70-124-080 VIB,CER 8.0MHZ X301 87-A70-007-080 VIB,XTAL 3.58MHZ AQC-1001 X302 87-030-327-010 VIB,CER CSB503F30

C907 87-016-577-080 CAP,E 470-16 SSL C908 87-016-627-080 CAP,E 47-16 SSL CN901 87-049-469-010 CONN,4P V CN902 87-A60-622-010 CONN,5P V 2MM JMT CN903 87-A60-485-010 CONN,2P V LV GRA

L901 87-005-615-080 COIL,120UH J LAV35 R904 87-A00-165-090 RES,M/F 15K-2W J RSF(S) R905 87-A00-165-090 RES,M/F 15K-2W J RSF(S) R906 87-A00-165-090 RES,M/F 15K-2W J RSF(S) S901 86-LBU-670-010 SOCKET,CRT 9P CVT3326 1603

NK C.B

C901 87-012-372-010 CAP,CER 1000P-2K C902 87-018-125-080 CAP, CER 330P-50V C903 87-018-125-080 CAP, CER 330P-50V C904 87-018-125-080 CAP, CER 330P-50V !C905 87-010-976-080 CAP,CER 1000P-500 B

Page 5

MECHANICAL PARTS LIST - 1

PART NO. KANRI

NO.

1 87-054-086-010 BADGE,AIWA 52.5 2 8Z-JAK-003-010 PANEL,MAIN AN2010 NH 3 8Z-JBR-005-010 LENS,RC 4 8Z-JBR-006-010 LENS,LED 5 8Z-JBR-004-010 KEY,MAIN

6 8Z-JBS-001-010 CABI,FR 7 8Z-JB4-620-010 SPKR,6*12 8OHM 10W 8 8Z-JAD-620-010 AC CORD SET,NH BLK 9 8Z-JBR-201-010 HLDR,PCB 1 10 87-JBD-606-010 CRT,A48LRH94X02(W)

11 87-A50-557-010 DGC,20' 15 OHM-TYPE8 12 84-LB3-205-010 SPR-E,EARTH 13 84-LB2-633-110 CONN ASSY,1P CRT GND 14 8Z-JBR-002-010 CABI,REAR 15 8Z-JB5-010-010 PANEL,REAR SH

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

16 87-A90-332-010 HLDR,SF-2001 HV CABLE 18 8Z-JB5-007-010 BTN,POWER SH 19 84-LB3-216-010 HLDR,LED A 87-067-680-010 BVI T3+3-10 C 87-078-070-010 BVIT3B+4-12

D 86-LBB-206-010 S-SCREW,ASSY TV5-40 W20 E 87-067-761-010 TAPPING SCREW, BVT2+3-10 F 87-067-579-010 TAPPING SCREW, BVT2+3-8 G 87-067-844-010 BVT2+4-16 BLK H 87-067-690-010 TAPPING SCREW, BVIT3+3-12

Page 6

ACCESSORIES LIST-1

PART NO. KANRI

NO.

1 8Z-JAK-901-010 IB,NH (E) -AN2110/ 2010/1410 2 8Z-JAE-951-010 RC UNIT,RC-ZVT18 3 87-A90-702-010 ANT ASSY,TV 5 SEC (NTSC) 4 87-A91-015-010 PLUG,CONVERSION JT-0475A

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

Page 7

737004

2-1 1, IKENOHAT A 1-CHOME, T AIT O-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111

Printed in Singapore
