AIWA NSX SZ310 Service Manual

NSX-SZ310

V

SERVICE MANUAL

COMPACT DISC

STEREO SYSTEM

• Replace this Service manual with “Revision Publishing” when it is issued.

BASIC TAPE MECHANISM : ZZM-3 PR1NF
BASIC CD MECHANISM : BZG-5 YKZD3NF

S/M Code No. 09-012-442-0T2

SIMPLE

DATA

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O AC C 0085 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
S AC D 0082 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S AC D 0083 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
X AC F 0081 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
! O AC PT 0081 8B-MA6-675-010 1B PT,SUB BMA E (VRK) VSFD CX-NSZ310
! O AC RY 0081 87-A91-418-010 1B RELAY,AC12V G5PA-1-M VSFD CX-NSZ310
O AC T 0081 87-A60-317-010 0E TERMINAL, 1P MSC VSFD CX-NSZ310
O AC T 0082 87-A60-317-010 0E TERMINAL, 1P MSC VSFD CX-NSZ310
! O AC WH 0081 87-A90-510-010 0E HLDR,WIRE 2.5-9P VSFD CX-NSZ310
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM VSFD CX-NSZ310

O ACCESSORY 87-A92-150-010 1A ANT,LOOP AM NO-CONT VSFD CX-NSZ310
O ACCESSORY 8Z-NF9-702-010 1H RC UNIT,ZAS02 VSFD CX-NSZ310
! O APPEARANCE 87-CE3-023-010 0E BADGE,AIWA 30N SILV VSFD CX-NSZ310
O APPEARANCE 8B-NF9-025-010 1B PANEL,RIGHT VSFD CX-NSZ310
O APPEARANCE 8B-NF9-026-010 1B PANEL,LEFT VSFD CX-NSZ310
O APPEARANCE 8B-NF9-027-010 1C PANEL,TOP VSFD CX-NSZ310
O APPEARANCE 8B-NFY-002-010  PANEL,TRAY VSFD CX-NSZ310
O APPEARANCE 8B-NFY-003-010  BOX,CASS 1 VSFD CX-NSZ310
O APPEARANCE 8B-NFY-004-010  BOX,CASS 2 VSFD CX-NSZ310
O APPEARANCE 8B-NFY-005-010  WINDOW,DISP U VSFD CX-NSZ310

O APPEARANCE 8B-NFY-007-010  WINDOW,CASS 1 VSFD CX-NSZ310
O APPEARANCE 8B-NFY-008-010  WINDOW,CASS 2 VSFD CX-NSZ310
O APPEARANCE 8B-NFY-017-010  PANEL,CD VSFD CX-NSZ310
O APPEARANCE 8B-NFY-019-010  CABI,FR LH VSFD CX-NSZ310
O APPEARANCE 8B-NFY-023-010  PANEL,FR HR VSFD CX-NSZ310
O APPEARANCE 8B-NFY-062-010  CABI,REAR VSFD VSFD CX-NSZ310
X CD M8-BZG-593-040  BZG-5 YKZD3NF VSFD CX-NSZ310
! X ELECTRICAL 87-069-033-010 0E CABLE,TIE VSFD CX-NSZ310
! O ELECTRICAL 87-085-185-010 0E BUSHING,AC CORD(E) CM-22B VSFD CX-NSZ310
O ELECTRICAL 88-906-251-110 1A FF-CABLE,6P 1.25 VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O ELECTRICAL 88-908-301-110 1A FF-CABLE,8P 1.25 VSFD CX-NSZ310
O ELECTRICAL 88-911-101-110 0E FF-CABLE,11P 1.25 VSFD CX-NSZ310
! O ELECTRICAL PT 0001 8B-NFY-694-010  PT,BNF-Y EZ VSFD CX-NSZ310
! O ELECTRICAL W 0001 87-A80-157-010 1B AC CORD ASSY,E BLK CC VSFD CX-NSZ310
O FRCB MECHA 8B-NFY-201-010  GUIDE,FL 100-40 BNFY VSFD CX-NSZ310
O FUNC/E.VR C 0605 87-012-280-080 0E C-CAP,U 3300P-50 K B VSFD CX-NSZ310
O FUNC/E.VR C 0606 87-012-280-080 0E C-CAP,U 3300P-50 K B VSFD CX-NSZ310
O FUNC/E.VR C 0609 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM VSFD CX-NSZ310
O FUNC/E.VR C 0610 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM VSFD CX-NSZ310
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310

O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH VSFD CX-NSZ310
O FUNC/E.VR C 0616 87-016-459-080 0E CAP,E 470-10 M SMG VSFD CX-NSZ310
O FUNC/E.VR C 0617 87-016-459-080 0E CAP,E 470-10 M SMG VSFD CX-NSZ310
O FUNC/E.VR C 0618 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O FUNC/E.VR C 0620 87-010-263-080 0E CAP,E 100-10 M 11L SME VSFD CX-NSZ310
O FUNC/E.VR C 0623 87-A12-372-080 0E CAP,M 0.047-100 J CP VSFD CX-NSZ310
O FUNC/E.VR C 0624 87-A12-372-080 0E CAP,M 0.047-100 J CP VSFD CX-NSZ310

O FUNC/E.VR C 0630 87-016-669-080 0E C-CAP,S 0.1-25 K B VSFD CX-NSZ310
O FUNC/E.VR C 0631 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM VSFD CX-NSZ310
O FUNC/E.VR C 0632 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM VSFD CX-NSZ310
O FUNC/E.VR C 0633 87-A11-070-080 0E C-CAP,U 0.033-16 K B VSFD CX-NSZ310
O FUNC/E.VR C 0634 87-A11-070-080 0E C-CAP,U 0.033-16 K B VSFD CX-NSZ310
O FUNC/E.VR C 0661 87-012-336-080 0E C-CAP,U 330P-50 J SL VSFD CX-NSZ310
O FUNC/E.VR C 0662 87-012-336-080 0E C-CAP,U 330P-50 J SL VSFD CX-NSZ310
O FUNC/E.VR C 0669 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O FUNC/E.VR C 0670 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
! O FUNC/E.VR CN 0601 87-099-719-010 1B CONN,30P H BLK TYK-B(X) VSFD CX-NSZ310
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE VSFD CX-NSZ310
S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7BSA VSFD CX-NSZ310
S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7BSA VSFD CX-NSZ310
X FUNC/E.VR FB 0602 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
S FUNC/E.VR IC 0601 87-A21-401-040 1C C-IC,M61503FP VSFD CX-NSZ310
O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 PBSN VSFD CX-NSZ310
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

 2 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X FUNC/E.VR JR 0605 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X FUNC/E.VR JR 0606 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 VSFD CX-NSZ310
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 VSFD CX-NSZ310
S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 VSFD CX-NSZ310
S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 VSFD CX-NSZ310
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
X FUNC/E.VR R 0077 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310

X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0605 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0606 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0607 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0608 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0609 88-108-562-080 0E C-RES,U 5.6K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0610 88-121-562-080 0E RES,5.6K-1/8W J VSFD CX-NSZ310

X FUNC/E.VR R 0611 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0612 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0613 88-121-681-080 0E RES,680-1/8W J VSFD CX-NSZ310
X FUNC/E.VR R 0614 88-121-681-080 0E RES,680-1/8W J VSFD CX-NSZ310
X FUNC/E.VR R 0615 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0616 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0619 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0620 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0621 88-108-824-080 0E C-RES,U 820K-1/16W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X FUNC/E.VR R 0622 88-108-824-080 0E C-RES,U 820K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8W J VSFD CX-NSZ310
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8W J VSFD CX-NSZ310
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8W J VSFD CX-NSZ310
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0632 88-108-123-080 0E C-RES,U 12K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0633 88-108-184-080 0E C-RES,U 180K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0634 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0635 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

X FUNC/E.VR R 0637 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0638 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0639 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X FUNC/E.VR R 0661 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
X FUNC/E.VR R 0662 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
O KNOB 8B-NFY-010-010  KEY,OPE 1W VSFD CX-NSZ310
O KNOB 8B-NFY-012-010  KEY,FUN VSFD CX-NSZ310

O KNOB 8B-NFY-013-010  KEY,GEQ VSFD CX-NSZ310
O KNOB 8B-NFY-014-010  KNOB,RTRY JOG VSFD CX-NSZ310
O KNOB 8B-NFY-015-010  KNOB,RTRY VOL VSFD CX-NSZ310
O KNOB 8B-NFY-036-010  REFLECTOR,ECO VSFD CX-NSZ310
X LBL,POP 8B-NFY-975-010  LBL,POP EZR VSFD CX-NSZ310
X LBL,POP 8B-NFY-982-010  LBL,POP VL VSFD CX-NSZ310
O MECHANICAL 8B-NF9-241-010  CHAS,MAIN BFD 66-40 VSFD CX-NSZ310
X MICON * 8B-NFY-622-010  PWB,FRONT BNF-31 (ADK) VSFD CX-NSZ310
O MICON C 0108 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM VSFD CX-NSZ310
O MICON C 0153 87-010-787-080 0E C-CAP,U 0.022-25 K B VSFD CX-NSZ310

O MICON C 0154 87-010-246-040 0E CAP,E 47-35 M 11L SME VSFD CX-NSZ310
O MICON C 0155 87-010-404-040 0E CAP,E 4.7-50 M 11L SME VSFD CX-NSZ310
O MICON C 0156 87-010-404-040 0E CAP,E 4.7-50 M 11L SME VSFD CX-NSZ310
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O MICON C 0351 87-A10-353-080 0E C-CAP,U 0.22-10 K B VSFD CX-NSZ310
O MICON C 0361 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0362 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0371 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0372 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0601 87-010-382-040 0E CAP,E 22-25 M 11L SME VSFD CX-NSZ310

 3 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O MICON C 0702 87-010-787-080 0E C-CAP,U 0.022-25 K B VSFD CX-NSZ310
O MICON C 0801 87-A10-804-080 0E C-CAP,S 0.1-25 J B VSFD CX-NSZ310
O MICON C 0802 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM VSFD CX-NSZ310
O MICON C 0803 87-012-280-080 0E C-CAP,U 3300P-50 K B VSFD CX-NSZ310
O MICON C 0804 87-A10-592-080 0E C-CAP,S 0.015-50 J B VSFD CX-NSZ310
O MICON C 0805 87-012-184-080 0E C-CAP,U 33P-50 J CH VSFD CX-NSZ310
O MICON C 0806 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0807 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0808 87-010-544-040 0E CAP,E 0.1-50 M 11L SME VSFD CX-NSZ310
O MICON C 0809 87-010-404-040 0E CAP,E 4.7-50 M 11L SME VSFD CX-NSZ310

O MICON C 0810 87-016-114-080 0E C-CAP,U 0.01-25 J B GRM VSFD CX-NSZ310
O MICON C 0811 87-A12-052-080 0E C-CAP,S 0.033-25 J B VSFD CX-NSZ310
O MICON C 0901 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0902 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0903 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0904 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0905 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0906 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0907 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0908 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310

O MICON C 0909 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0910 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O MICON C 0911 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O MICON C 0912 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O MICON C 0913 87-A10-189-040 0E CAP,E 220-10 M 5L VSFD CX-NSZ310
O MICON C 0914 87-A10-189-040 0E CAP,E 220-10 M 5L VSFD CX-NSZ310
O MICON C 0915 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O MICON C 0916 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O MICON C 0917 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O MICON C 0919 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O MICON C 0920 87-010-829-080 0E C-CAP,U 0.047-16 Z F VSFD CX-NSZ310
O MICON C 0921 87-012-282-080 0E C-CAP,U 4700P-50 K B VSFD CX-NSZ310
O MICON C 0951 87-012-172-080 0E C-CAP,U 10P-50 D CH VSFD CX-NSZ310
O MICON C 0952 87-010-854-080 0E C-CAP,S 560P-50 J CH VSFD CX-NSZ310
O MICON C 0953 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM VSFD CX-NSZ310
O MICON C 0961 87-010-378-040 0E CAP,E 10-16 M 11L SME VSFD CX-NSZ310
O MICON C 0962 87-012-336-080 0E C-CAP,U 330P-50 J SL VSFD CX-NSZ310
O MICON C 0963 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
! O MICON CN 0104 87-A60-057-010 0E CONN,11P V 9604S-11C VSFD CX-NSZ310
! O MICON CN 0701 87-099-720-010 1B CONN,30P BLK TYK-B(P) VSFD CX-NSZ310

! O MICON CN 0731 87-099-196-010 0E CONN,8P V BLK 6216 VSFD CX-NSZ310
S MICON D 0104 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S MICON D 0301 87-A40-748-080 0E ZENER,UZ5.6BSA VSFD CX-NSZ310
S MICON D 0302 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S MICON D 0601 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S MICON D 0651 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S MICON D 0652 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S MICON D 0653 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S MICON D 0654 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S MICON D 0655 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310

S MICON D 0656 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
X MICON D 0702 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X MICON D 0703 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
S MICON D 0801 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S MICON D 0985 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
O MICON FL 0901 8B-NFY-605-010 2M FL,HNA-08LS02 VSFD CX-NSZ310
S MICON IC 0901 8B-NF9-601-030 2A C-IC,UPD780226GF-021-3BA VSFD CX-NSZ310
S MICON IC 0961 87-A21-218-110 1B IC,NJL64H380A VSFD CX-NSZ310
X MICON JR 0101 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0150 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X MICON JR 0151 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0152 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0153 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0154 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0155 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0156 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0157 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0158 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0159 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0160 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

 4 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON JR 0161 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0162 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0163 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0164 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0165 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0166 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0167 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0168 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0169 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0170 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X MICON JR 0171 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0172 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0173 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0174 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0175 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0176 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0177 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0178 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0179 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0180 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X MICON JR 0181 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0201 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0301 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0361 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0601 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0603 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0605 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0607 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0609 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0612 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON JR 0616 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0617 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0618 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0619 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0651 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0652 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0703 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0704 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0705 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0706 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X MICON JR 0901 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0902 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0903 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0904 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0905 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON JR 0964 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O MICON L 0951 87-A50-655-010 0E COIL,CLK 4.19MHZ (TOKO)7KLY VSFD CX-NSZ310
O MICON LED0209 87-A41-062-040 0E LED,LTL-1CHEE-012A RED VSFD CX-NSZ310
S MICON Q 0102 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S MICON Q 0103 87-A30-484-080 0E C-TR,KRA102S VSFD CX-NSZ310

S MICON Q 0104 87-A30-484-080 0E C-TR,KRA102S VSFD CX-NSZ310
S MICON Q 0105 87-A30-468-080 0E C-TR,KRC102S-RTK VSFD CX-NSZ310
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G VSFD CX-NSZ310
S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S MICON Q 0601 87-A30-495-080 0E TR,2SA1981Y VSFD CX-NSZ310
S MICON Q 0602 87-A30-495-080 0E TR,2SA1981Y VSFD CX-NSZ310
S MICON Q 0603 87-A30-582-080 0E TR,CDA1585BC VSFD CX-NSZ310
S MICON Q 0801 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S MICON Q 0802 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310

S MICON Q 0803 87-A30-490-080 0E C-TR,KRC107S VSFD CX-NSZ310
S MICON Q 0804 87-A30-490-080 0E C-TR,KRC107S VSFD CX-NSZ310
S MICON Q 0805 87-A30-490-080 0E C-TR,KRC107S VSFD CX-NSZ310
S MICON Q 0901 87-A30-484-080 0E C-TR,KRA102S VSFD CX-NSZ310
X MICON R 0109 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X MICON R 0110 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
X MICON R 0111 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310
X MICON R 0112 88-121-224-080 0E RES,220K-1/8W J VSFD CX-NSZ310
X MICON R 0114 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

 5 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0116 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0151 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X MICON R 0152 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X MICON R 0153 88-121-821-080 0E RES,820-1/8W J VSFD CX-NSZ310
X MICON R 0154 88-121-821-080 0E RES,820-1/8W J VSFD CX-NSZ310
X MICON R 0155 88-121-332-080 0E RES,3.3K-1/8W J VSFD CX-NSZ310
X MICON R 0156 88-121-332-080 0E RES,3.3K-1/8W J VSFD CX-NSZ310
X MICON R 0208 88-121-332-080 0E RES,3.3K-1/8W J VSFD CX-NSZ310
X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310

X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0306 88-108-471-080 0E C-RES,U 470-1/16W J VSFD CX-NSZ310
X MICON R 0321 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0322 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0323 88-121-821-080 0E RES,820-1/8W J VSFD CX-NSZ310
X MICON R 0324 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X MICON R 0325 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X MICON R 0326 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X MICON R 0327 88-108-182-080 0E C-RES,U 1.8K-1/16W J VSFD CX-NSZ310

X MICON R 0328 88-108-182-080 0E C-RES,U 1.8K-1/16W J VSFD CX-NSZ310
X MICON R 0329 88-108-272-080 0E C-RES,U 2.7K-1/16W J VSFD CX-NSZ310
X MICON R 0330 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310
X MICON R 0331 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X MICON R 0332 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X MICON R 0333 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0334 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X MICON R 0341 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0342 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0343 88-108-821-080 0E C-RES,U 820-1/16W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON R 0344 88-121-102-080 0E RES,1K-1/8W J VSFD CX-NSZ310
X MICON R 0345 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X MICON R 0346 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X MICON R 0347 88-121-182-080 0E RES,1.8K-1/8W J VSFD CX-NSZ310
X MICON R 0348 88-108-182-080 0E C-RES,U 1.8K-1/16W J VSFD CX-NSZ310
X MICON R 0349 88-108-272-080 0E C-RES,U 2.7K-1/16W J VSFD CX-NSZ310
X MICON R 0361 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0362 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0363 88-108-100-080 0E C-RES,U 10-1/16W J VSFD CX-NSZ310
X MICON R 0364 88-108-100-080 0E C-RES,U 10-1/16W J VSFD CX-NSZ310

X MICON R 0371 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0372 88-121-103-080 0E RES,10K-1/8W J VSFD CX-NSZ310
X MICON R 0373 88-108-100-080 0E C-RES,U 10-1/16W J VSFD CX-NSZ310
X MICON R 0374 88-108-100-080 0E C-RES,U 10-1/16W J VSFD CX-NSZ310
X MICON R 0601 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0602 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X MICON R 0603 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0604 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X MICON R 0605 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0606 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310

X MICON R 0607 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON R 0611 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X MICON R 0613 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X MICON R 0614 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X MICON R 0615 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X MICON R 0616 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X MICON R 0651 88-128-152-080 0E C-RES, 1.5K-1/8W J VSFD CX-NSZ310
X MICON R 0652 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X MICON R 0653 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X MICON R 0654 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310

X MICON R 0655 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X MICON R 0656 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X MICON R 0704 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0705 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0707 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0708 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0709 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0710 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X MICON R 0711 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310

 6 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0712 88-121-330-080 0E RES,33-1/8W J VSFD CX-NSZ310
X MICON R 0715 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0716 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X MICON R 0719 88-121-100-080 0E RES,10-1/8W J VSFD CX-NSZ310
X MICON R 0721 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0730 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0732 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0733 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0734 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0735 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310

X MICON R 0740 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0741 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X MICON R 0742 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0743 88-108-474-080 0E C-RES,U 470K-1/16W J VSFD CX-NSZ310
X MICON R 0744 88-108-823-080 0E C-RES,U 82K-1/16W J VSFD CX-NSZ310
X MICON R 0745 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0749 88-108-474-080 0E C-RES,U 470K-1/16W J VSFD CX-NSZ310
X MICON R 0803 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0804 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X MICON R 0805 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310

X MICON R 0806 88-108-562-080 0E C-RES,U 5.6K-1/16W J VSFD CX-NSZ310
X MICON R 0807 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON R 0808 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X MICON R 0809 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0810 88-108-272-080 0E C-RES,U 2.7K-1/16W J VSFD CX-NSZ310
X MICON R 0811 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0813 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X MICON R 0815 88-108-272-080 0E C-RES,U 2.7K-1/16W J VSFD CX-NSZ310
X MICON R 0816 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0818 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON R 0819 88-108-272-080 0E C-RES,U 2.7K-1/16W J VSFD CX-NSZ310
X MICON R 0821 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0822 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X MICON R 0823 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X MICON R 0824 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X MICON R 0825 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X MICON R 0826 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON R 0827 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0901 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0902 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310

X MICON R 0903 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0904 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0905 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0906 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0907 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0908 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0909 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0910 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0911 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0912 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310

X MICON R 0913 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0914 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0915 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0916 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0917 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0918 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0919 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0920 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0921 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0922 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310

X MICON R 0923 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0924 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0925 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0926 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0927 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0928 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0929 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0930 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0931 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0932 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310

 7 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X MICON R 0933 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0934 88-108-683-080 0E C-RES,U 68K-1/16W J VSFD CX-NSZ310
X MICON R 0935 88-108-683-080 0E C-RES,U 68K-1/16W J VSFD CX-NSZ310
X MICON R 0936 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0937 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X MICON R 0938 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X MICON R 0939 88-128-472-080 0E C-RES, 4.7K-1/8W J VSFD CX-NSZ310
X MICON R 0940 88-121-104-080 0E RES,100K-1/8W J VSFD CX-NSZ310
X MICON R 0941 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0942 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

X MICON R 0943 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X MICON R 0946 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X MICON R 0947 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0948 88-128-104-080 0E C-RES, 100K-1/8W J VSFD CX-NSZ310
X MICON R 0951 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X MICON R 0955 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0956 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0957 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0958 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X MICON R 0961 88-128-181-080 0E C-RES, 180-1/8W J VSFD CX-NSZ310

X MICON R 0962 88-108-563-080 0E C-RES,U 56K-1/16W J VSFD CX-NSZ310
O MICON S 0321 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0322 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0323 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0324 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0325 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0326 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0327 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0328 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0329 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O MICON S 0330 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0331 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0332 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0333 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0334 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0341 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0342 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0343 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0344 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0345 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310

O MICON S 0346 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0347 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0348 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0349 87-A90-164-080 0E SW,TACT SKQNAB(N) VSFD CX-NSZ310
O MICON S 0361 87-A91-633-010 1A SW,RTRY XRE012103PVB25FINA 1-2 VSFD CX-NSZ310
O MICON S 0371 87-A91-632-010 1A SW,RTRY XRE012103PVB25FINB 1-2 VSFD CX-NSZ310
! O OTHERS 82-NF5-229-010 0E PLATE,LOCK(*) VSFD CX-NSZ310
O OTHERS 86-NF9-224-010 0E SPR-C,LOCK VSFD CX-NSZ310
X OTHERS 87-064-080-010 0E BINDER,WIRE VSFD CX-NSZ310
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 VSFD CX-NSZ310

! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 VSFD CX-NSZ310
! O OTHERS 87-NF4-221-010 0E HLDR,CABLE VSFD CX-NSZ310
! O OTHERS 8A-NF8-206-010 0E HLDR,PWB M VSFD CX-NSZ310
O OTHERS 8A-NF8-281-010 0E SPR-T,EJECT 1 VSFD CX-NSZ310
O OTHERS 8A-NF8-282-010 0E SPR-T,EJECT 2 VSFD CX-NSZ310
! O OTHERS 8A-NF9-211-010 0E HLDR,PWB PT HI VSFD CX-NSZ310
X OTHERS 8B-NF9-204-010 0E CUSH, 11-8.5-2 VSFD CX-NSZ310
O OTHERS 8B-NF9-211-010 1B HLDR,TR S VSFD CX-NSZ310
X OTHERS 8B-NF9-214-010 1C HT-SINK,MAIN60 S VSFD CX-NSZ310
X OTHERS 8B-NFK-210-010 0E SH,TR VM VSFD CX-NSZ310

X OTHERS 8B-NFY-205-010  PLATE,EARTH MECH VSFD CX-NSZ310
! O OTHERS 8Z-NF6-210-010 0E DMPR,150 N VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN * 8B-NF9-650-110  PWB,COMB MAIN -IND VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN * 8B-NF9-651-110  PWB,MAIN-IND VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN * 8B-NF9-652-110  PWB,PT-IND VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0003 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0004 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0005 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0006 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0009 87-010-759-080 0E C-CAP,U 0.1-25 Z F VSFD CX-NSZ310

 8 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O P-SUPPLY/PWB/FAN C 0010 87-010-759-080 0E C-CAP,U 0.1-25 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0011 87-010-759-080 0E C-CAP,U 0.1-25 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0012 87-010-759-080 0E C-CAP,U 0.1-25 Z F VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0019 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0020 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0021 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0022 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0025 87-A12-072-080 0E CAP,E 100-25 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0026 87-A12-072-080 0E CAP,E 100-25 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0027 87-A12-072-080 0E CAP,E 100-25 SMG VSFD CX-NSZ310

O P-SUPPLY/PWB/FAN C 0028 87-A12-072-080 0E CAP,E 100-25 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0030 87-A12-095-080 0E CAP,E 100-50 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0031 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0032 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0034 87-A12-072-080 0E CAP,E 100-25 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0035 87-A12-071-080 0E CAP,E 47-25 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0036 87-A12-067-080 0E CAP,E 330-16 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0038 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0060 87-A12-089-080 0E CAP,E 3.3-50 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0061 87-A12-071-080 0E CAP,E 47-25 SMG VSFD CX-NSZ310

O P-SUPPLY/PWB/FAN C 0083 87-A12-068-080 0E CAP,E 470-16 SMG VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN C 0097 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0013 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0014 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0015 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0016 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0017 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0018 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0019 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0020 87-A40-454-090 0E DIODE,1N5393 GW 12.5 VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S P-SUPPLY/PWB/FAN D 0025 87-A40-553-080 0E DIODE,1N4003 LES VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0026 87-A40-553-080 0E DIODE,1N4003 LES VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0027 87-A40-553-080 0E DIODE,1N4003 LES VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0028 87-A40-553-080 0E DIODE,1N4003 LES VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0029 87-A40-776-080 0E ZENER,UZ27BSD VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0030 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0031 87-A40-764-080 0E ZENER,UZ10BSC VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0033 87-A40-553-080 0E DIODE,1N4003 LES VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0034 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0035 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310

S P-SUPPLY/PWB/FAN D 0041 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0042 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0060 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0062 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0063 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0064 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0065 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0071 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0072 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN D 0076 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310

S P-SUPPLY/PWB/FAN D 0077 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0001 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0003 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0004 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0005 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0006 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0023 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN JR 0024 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0001 87-A30-494-080 0E TR,2SA1980G VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0002 87-A30-494-080 0E TR,2SA1980G VSFD CX-NSZ310

S P-SUPPLY/PWB/FAN Q 0003 87-A30-559-010 1A TR,CSB1370EF VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0005 87-026-610-080 0E TR,KTC3198GR VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0006 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0008 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0009 87-A30-494-080 0E TR,2SA1980G VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0010 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0059 87-A30-107-070 0E C-TR,CMBT5401 VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0060 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0061 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0062 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310

 9 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

S P-SUPPLY/PWB/FAN Q 0063 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0064 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S P-SUPPLY/PWB/FAN Q 0065 87-A30-484-080 0E C-TR,KRA102S VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0002 88-121-109-080 0E RES,1-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0005 88-121-109-080 0E RES,1-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0009 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0010 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0011 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0012 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0013 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310

X P-SUPPLY/PWB/FAN R 0014 88-118-100-080 0E C-RES,S 10-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0015 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0016 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0017 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0018 88-118-221-080 0E C-RES,S 220-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0019 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0020 88-121-680-080 0E RES,68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0021 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0022 88-108-221-080 0E C-RES,U 220-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0023 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

X P-SUPPLY/PWB/FAN R 0027 88-118-471-080 0E C-RES,S 470-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0028 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0029 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0030 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0031 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0032 88-121-102-080 0E RES,1K-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0033 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0034 88-108-394-080 0E C-RES,U 390K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0037 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0038 88-130-151-080 0E RES,150-1/4W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X P-SUPPLY/PWB/FAN R 0039 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0042 88-130-151-080 0E RES,150-1/4W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0043 88-130-151-080 0E RES,150-1/4W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0044 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0045 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0046 88-130-151-080 0E RES,150-1/4W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0047 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0050 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0051 88-128-680-080 0E C-RES, 68-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0052 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310

X P-SUPPLY/PWB/FAN R 0054 88-118-473-080 0E C-RES,S 47K-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0055 88-118-473-080 0E C-RES,S 47K-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0056 88-108-822-080 0E C-RES,U 8.2K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0057 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0058 88-108-562-080 0E C-RES,U 5.6K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0059 88-118-103-080 0E C-RES,S 10K-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0060 88-118-473-080 0E C-RES,S 47K-1/10W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0061 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0062 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0063 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310

X P-SUPPLY/PWB/FAN R 0064 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0065 88-108-123-080 0E C-RES,U 12K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0066 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0067 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0068 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0069 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0070 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0071 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0072 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0073 88-128-470-080 0E C-RES, 47-1/8W J VSFD CX-NSZ310

X P-SUPPLY/PWB/FAN R 0074 88-128-470-080 0E C-RES, 47-1/8W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0076 88-108-562-080 0E C-RES,U 5.6K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0078 88-108-393-080 0E C-RES,U 39K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0079 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0081 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0085 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0086 88-108-334-080 0E C-RES,U 330K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0093 88-108-683-080 0E C-RES,U 68K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0094 88-108-393-080 0E C-RES,U 39K-1/16W J VSFD CX-NSZ310
X P-SUPPLY/PWB/FAN R 0095 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310

 10 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X P-SUPPLY/PWB/FAN R 0096 88-108-683-080 0E C-RES,U 68K-1/16W J VSFD CX-NSZ310
O P-SUPPLY/PWB/FAN W 0099 8A-NF9-609-010 1A F-CABLE,9P 2.5 480MM VSFD CX-NSZ310
! O P-SUPPLY/PWB/FAN WH 0001 87-A90-510-010 0E HLDR,WIRE 2.5-9P VSFD CX-NSZ310
X PACKING 87-B40-098-010 0E BAG,PV 0.025-650-750 PL VSFD CX-NSZ310
X PACKING 8B-NFY-869-010  CUSHION,FRONT FD VSFD CX-NSZ310
X PACKING 8B-NFY-870-010  CUSHION,REAR FD VSFD CX-NSZ310
X PACKING 8B-NFY-876-010  CTN,PRINTED VSFD VSFD CX-NSZ310
X PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 VSFD CX-NSZ310
! X PLATE 87-057-961-010 0E LBL,CAUTION TRIANGLE VSFD CX-NSZ310
! X PLATE 87-057-995-010 0E LBL,CAUTION EFSD VSFD CX-NSZ310

X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 VSFD CX-NSZ310
O POWER AMP C 0101 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O POWER AMP C 0102 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O POWER AMP C 0103 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310
O POWER AMP C 0104 87-A12-084-080 0E CAP,E 0.22-50 SMG VSFD CX-NSZ310
O POWER AMP C 0105 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM VSFD CX-NSZ310
O POWER AMP C 0106 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM VSFD CX-NSZ310
O POWER AMP C 0107 87-A12-089-080 0E CAP,E 3.3-50 SMG VSFD CX-NSZ310
O POWER AMP C 0108 87-A12-089-080 0E CAP,E 3.3-50 SMG VSFD CX-NSZ310
O POWER AMP C 0109 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310

O POWER AMP C 0110 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O POWER AMP C 0111 87-A12-077-080 0E CAP,E 33-35 SMG VSFD CX-NSZ310
O POWER AMP C 0112 87-A12-077-080 0E CAP,E 33-35 SMG VSFD CX-NSZ310
O POWER AMP C 0113 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O POWER AMP C 0114 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O POWER AMP C 0117 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O POWER AMP C 0118 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O POWER AMP C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O POWER AMP C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O POWER AMP C 0123 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O POWER AMP C 0124 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 VSFD CX-NSZ310
O POWER AMP C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K B VSFD CX-NSZ310
O POWER AMP C 0140 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O POWER AMP C 0186 87-010-759-080 0E C-CAP,U 0.1-25 Z F VSFD CX-NSZ310
O POWER AMP C 0187 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O POWER AMP C 0188 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O POWER AMP C 0223 87-010-176-080 0E C-CAP,S 680P-50 J SL VSFD CX-NSZ310
O POWER AMP C 0224 87-010-176-080 0E C-CAP,S 680P-50 J SL VSFD CX-NSZ310
O POWER AMP C 0225 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O POWER AMP C 0226 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310

O POWER AMP C 0227 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O POWER AMP C 0228 87-012-368-080 0E C-CAP,S 0.1-50 Z F VSFD CX-NSZ310
O POWER AMP C 0229 87-010-191-080 0E C-CAP,S 0.015-50 Z F GRM VSFD CX-NSZ310
O POWER AMP C 0230 87-010-191-080 0E C-CAP,S 0.015-50 Z F GRM VSFD CX-NSZ310
O POWER AMP C 0231 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O POWER AMP C 0232 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O POWER AMP C 0241 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
S POWER AMP D 0101 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S POWER AMP D 0103 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0104 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310

S POWER AMP D 0105 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0106 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0107 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0108 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0115 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S POWER AMP D 0117 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0118 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0150 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S POWER AMP D 0160 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S POWER AMP D 0185 87-A40-393-090 0E DIODE,1N5402GW(F20) VSFD CX-NSZ310

S POWER AMP D 0186 87-A40-393-090 0E DIODE,1N5402GW(F20) VSFD CX-NSZ310
S POWER AMP D 0187 87-A40-747-080 0E ZENER,UZ5.1BSB VSFD CX-NSZ310
S POWER AMP D 0188 87-A40-749-080 0E ZENER,UZ5.6BSB VSFD CX-NSZ310
S POWER AMP D 0189 87-A40-270-080 0E C-DIODE,MC2838 VSFD CX-NSZ310
S POWER AMP D 0190 87-A40-269-080 0E C-DIODE,MC2836 VSFD CX-NSZ310
S POWER AMP D 0191 87-A40-764-080 0E ZENER,UZ10BSC VSFD CX-NSZ310
S POWER AMP D 0192 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S POWER AMP D 0193 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
O POWER AMP J 0202 87-A60-488-010 1B JACK,DIA6.3 BLK ST W/SW KM16AT VSFD CX-NSZ310
! O POWER AMP J 0203 87-A60-238-010 1A TERMINAL,SP 4P (MSC) VSFD CX-NSZ310

 11 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP JR 0101 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0102 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0103 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0104 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0105 88-128-273-080 0E C-RES, 27K-1/8W J VSFD CX-NSZ310
X POWER AMP JR 0107 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0109 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0110 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X POWER AMP JR 0111 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X POWER AMP JR 0113 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X POWER AMP JR 0114 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O POWER AMP JR 0123 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O POWER AMP JR 0124 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O POWER AMP L 0201 87-A50-610-010 0E COIL,1UH K(MDEC) VSFD CX-NSZ310
O POWER AMP L 0202 87-A50-610-010 0E COIL,1UH K(MDEC) VSFD CX-NSZ310
S POWER AMP Q 0103 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S POWER AMP Q 0104 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S POWER AMP Q 0105 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S POWER AMP Q 0106 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S POWER AMP Q 0107 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310

S POWER AMP Q 0108 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0109 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0110 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0111 87-A30-190-080 0E TR,CC5551 VSFD CX-NSZ310
S POWER AMP Q 0112 87-A30-190-080 0E TR,CC5551 VSFD CX-NSZ310
S POWER AMP Q 0113 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0114 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0115 87-A30-106-040 0E C-TR,CMBT5551 VSFD CX-NSZ310
S POWER AMP Q 0116 87-A30-106-040 0E C-TR,CMBT5551 VSFD CX-NSZ310
S POWER AMP Q 0117 87-A30-528-010 1B TR,2SB1686 VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S POWER AMP Q 0118 87-A30-528-010 1B TR,2SB1686 VSFD CX-NSZ310
S POWER AMP Q 0119 87-A30-529-010 1B TR,2SD2642 VSFD CX-NSZ310
S POWER AMP Q 0120 87-A30-529-010 1B TR,2SD2642 VSFD CX-NSZ310
S POWER AMP Q 0121 87-A30-190-080 0E TR,CC5551 VSFD CX-NSZ310
S POWER AMP Q 0122 87-A30-190-080 0E TR,CC5551 VSFD CX-NSZ310
S POWER AMP Q 0123 87-A30-107-070 0E C-TR,CMBT5401 VSFD CX-NSZ310
S POWER AMP Q 0124 87-A30-107-070 0E C-TR,CMBT5401 VSFD CX-NSZ310
S POWER AMP Q 0126 87-A30-107-070 0E C-TR,CMBT5401 VSFD CX-NSZ310
S POWER AMP Q 0127 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0128 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310

S POWER AMP Q 0130 87-A30-106-040 0E C-TR,CMBT5551 VSFD CX-NSZ310
S POWER AMP Q 0183 87-A30-162-010 1B FET,2SK2937 VSFD CX-NSZ310
S POWER AMP Q 0184 87-A30-162-010 1B FET,2SK2937 VSFD CX-NSZ310
S POWER AMP Q 0185 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
S POWER AMP Q 0186 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S POWER AMP Q 0187 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
X POWER AMP R 0101 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0102 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0103 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0104 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

X POWER AMP R 0105 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0106 88-108-273-080 0E C-RES,U 27K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0107 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X POWER AMP R 0108 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X POWER AMP R 0109 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0110 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0111 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0112 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0113 88-118-273-080 0E C-RES,S 27K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0114 88-118-273-080 0E C-RES,S 27K-1/10W J VSFD CX-NSZ310

X POWER AMP R 0115 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0116 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0117 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0118 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0119 88-118-101-080 0E C-RES,S 100-1/10W J VSFD CX-NSZ310
X POWER AMP R 0120 88-118-101-080 0E C-RES,S 100-1/10W J VSFD CX-NSZ310
X POWER AMP R 0121 88-118-101-080 0E C-RES,S 100-1/10W J VSFD CX-NSZ310
X POWER AMP R 0122 88-118-101-080 0E C-RES,S 100-1/10W J VSFD CX-NSZ310
X POWER AMP R 0123 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0124 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310

 12 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP R 0125 88-128-102-080 0E C-RES, 1K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0126 88-128-102-080 0E C-RES, 1K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0127 88-118-390-080 0E C-RES,S 39-1/10W J VSFD CX-NSZ310
X POWER AMP R 0128 88-118-390-080 0E C-RES,S 39-1/10W J VSFD CX-NSZ310
O POWER AMP R 0129 87-A00-258-080 0E RES,M/F 0.22-1W J VSFD CX-NSZ310
O POWER AMP R 0130 87-A00-258-080 0E RES,M/F 0.22-1W J VSFD CX-NSZ310
O POWER AMP R 0131 87-A00-258-080 0E RES,M/F 0.22-1W J VSFD CX-NSZ310
O POWER AMP R 0132 87-A00-258-080 0E RES,M/F 0.22-1W J VSFD CX-NSZ310
X POWER AMP R 0133 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0134 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310

X POWER AMP R 0135 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0136 88-108-152-080 0E C-RES,U 1.5K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0137 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X POWER AMP R 0138 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X POWER AMP R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0142 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0151 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0152 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0153 88-118-390-080 0E C-RES,S 39-1/10W J VSFD CX-NSZ310
X POWER AMP R 0154 88-118-390-080 0E C-RES,S 39-1/10W J VSFD CX-NSZ310

X POWER AMP R 0155 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0156 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0157 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0158 88-128-272-080 0E C-RES, 2.7K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0159 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0160 88-121-103-080 0E RES,10K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0161 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0162 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0163 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0164 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X POWER AMP R 0165 88-118-152-080 0E C-RES,S 1.5K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0166 88-118-152-080 0E C-RES,S 1.5K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0167 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0168 88-118-473-080 0E C-RES,S 47K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0169 88-118-271-080 0E C-RES,S 270-1/10W J VSFD CX-NSZ310
X POWER AMP R 0170 88-118-271-080 0E C-RES,S 270-1/10W J VSFD CX-NSZ310
X POWER AMP R 0171 88-118-222-080 0E C-RES,S 2.2K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0172 88-118-222-080 0E C-RES,S 2.2K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0173 88-118-152-080 0E C-RES,S 1.5K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0174 88-118-152-080 0E C-RES,S 1.5K-1/10W J VSFD CX-NSZ310

X POWER AMP R 0175 88-118-331-080 0E C-RES,S 330-1/10W J VSFD CX-NSZ310
X POWER AMP R 0176 88-118-331-080 0E C-RES,S 330-1/10W J VSFD CX-NSZ310
X POWER AMP R 0177 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0178 88-118-103-080 0E C-RES,S 10K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0179 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0180 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0184 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0185 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0186 88-118-102-080 0E C-RES,S 1K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0187 88-118-103-080 0E C-RES,S 10K-1/10W J VSFD CX-NSZ310

X POWER AMP R 0188 88-118-222-080 0E C-RES,S 2.2K-1/10W J VSFD CX-NSZ310
X POWER AMP R 0189 88-128-272-080 0E C-RES, 2.7K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0190 88-128-272-080 0E C-RES, 2.7K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0192 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
X POWER AMP R 0193 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0194 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0195 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0196 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0197 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310
X POWER AMP R 0198 88-108-473-080 0E C-RES,U 47K-1/16W J VSFD CX-NSZ310

X POWER AMP R 0199 88-108-225-080 0E C-RES,U 2.2M-1/16W J VSFD CX-NSZ310
O POWER AMP R 0243 87-A00-999-050  RES,180-1/2W J BLT2J VSFD CX-NSZ310
O POWER AMP R 0244 87-A00-999-050  RES,180-1/2W J BLT2J VSFD CX-NSZ310
O POWER AMP R 0245 87-A00-999-050  RES,180-1/2W J BLT2J VSFD CX-NSZ310
O POWER AMP R 0246 87-A00-999-050  RES,180-1/2W J BLT2J VSFD CX-NSZ310
X POWER AMP R 0247 88-130-100-080 0E RES,10-1/4W J VSFD CX-NSZ310
X POWER AMP R 0248 88-130-100-080 0E RES,10-1/4W J VSFD CX-NSZ310
X POWER AMP R 0249 88-128-100-080 0E C-RES, 10-1/8W J VSFD CX-NSZ310
X POWER AMP R 0250 88-121-100-080 0E RES,10-1/8W J VSFD CX-NSZ310
X POWER AMP R 0265 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310

 13 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X POWER AMP R 0266 88-128-222-080 0E C-RES, 2.2K-1/8W J VSFD CX-NSZ310
O POWER AMP TH 0101 87-A91-042-080 0E C-THMS,100K 55001 VSFD CX-NSZ310
O POWER AMP TH 0102 87-A91-042-080 0E C-THMS,100K 55001 VSFD CX-NSZ310
X PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL VSFD CX-NSZ310
X PRINTED DU 87-B50-079-010 0E LIST,FACILITY(B)-0007 VSFD CX-NSZ310
O PRINTED DU 8B-NFY-907-010  IB,V(ER)IN VSFD CX-NSZ310
O SCREW 87-067-584-010 0E BVT2+3-6 W/0 SL0T VSFD CX-NSZ310
O SCREW 87-067-641-010 0E UTT2+3-8 W/O SLOT BLK VSFD CX-NSZ310
O SCREW 87-067-689-010 0E BVTT+3-8 VSFD CX-NSZ310
O SCREW 87-067-703-010 0E BVT2+3-10 W/0 SL0T VSFD CX-NSZ310

O SCREW 87-078-200-010 0E S-SCREW,ITC+4-8 R VSFD CX-NSZ310
O SCREW 87-721-096-410 0E QT2+3-10 W/O SLOT VSFD CX-NSZ310
O SCREW 87-721-097-410 0E QT2+3-12 W/O SLOT VSFD CX-NSZ310
O SCREW 87-723-096-410 0E QT2+3-10 W/O SLOT BLK VSFD CX-NSZ310
O SCREW 87-NF4-224-010 0E S-SCREW,IT3B+3-8 CU VSFD CX-NSZ310
X TAPE M8-ZZM-390-040  ZZM-3 PR1NF VSFD CX-NSZ310
O TAPE DECK C 0301 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0302 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0303 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0304 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM VSFD CX-NSZ310

O TAPE DECK C 0307 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O TAPE DECK C 0308 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O TAPE DECK C 0309 87-012-188-080 0E C-CAP,U 47P-50 J CH VSFD CX-NSZ310
O TAPE DECK C 0310 87-012-188-080 0E C-CAP,U 47P-50 J CH VSFD CX-NSZ310
O TAPE DECK C 0313 87-012-284-080 0E C-CAP,U 6800P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0314 87-012-284-080 0E C-CAP,U 6800P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0315 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O TAPE DECK C 0317 87-A12-085-080 0E CAP,E 0.33-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0318 87-A12-085-080 0E CAP,E 0.33-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0326 87-010-787-080 0E C-CAP,U 0.022-25 K B VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TAPE DECK C 0327 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TAPE DECK C 0350 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TAPE DECK C 0360 87-A12-087-080 0E CAP,E 1-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0399 87-A10-039-080 0E C-CAP,U 470P-50 J CH VSFD CX-NSZ310
O TAPE DECK C 0401 87-A12-083-080 0E CAP,E 0.1-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0402 87-A12-083-080 0E CAP,E 0.1-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0403 87-012-193-080 0E C-CAP,U 82P-50 J CH VSFD CX-NSZ310
O TAPE DECK C 0404 87-012-193-080 0E C-CAP,U 82P-50 J CH VSFD CX-NSZ310
O TAPE DECK C 0405 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TAPE DECK C 0406 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

O TAPE DECK C 0407 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TAPE DECK C 0408 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TAPE DECK C 0409 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O TAPE DECK C 0410 87-012-278-080 0E C-CAP,U 2200P-50 K B VSFD CX-NSZ310
O TAPE DECK C 0411 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0412 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O TAPE DECK C 0452 87-A12-069-080 0E CAP,E 22-25 SMG VSFD CX-NSZ310
O TAPE DECK C 0453 87-012-279-080 0E C-CAP,U 2700P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0454 87-012-279-080 0E C-CAP,U 2700P-50 K B GRM VSFD CX-NSZ310
O TAPE DECK C 0455 87-012-279-080 0E C-CAP,U 2700P-50 K B GRM VSFD CX-NSZ310

O TAPE DECK C 0456 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TAPE DECK C 0457 87-A12-361-080 0E CAP,M 5600P-100 J CP VSFD CX-NSZ310
O TAPE DECK C 0458 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O TAPE DECK C 0459 87-012-271-080 0E C-CAP,U 560P-50 K B VSFD CX-NSZ310
O TAPE DECK C 0460 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TAPE DECK C 0461 87-012-158-080 0E C-CAP,S 390P-50 J CH GRM VSFD CX-NSZ310
O TAPE DECK C 0462 87-012-158-080 0E C-CAP,S 390P-50 J CH GRM VSFD CX-NSZ310
O TAPE DECK C 0470 87-018-127-080 0E CAP,TC U 470P-50 K B UP050 VSFD CX-NSZ310
X TAPE DECK CLP0302 87-A60-884-010 0E PIN,DIA1 COATING-SHS VSFD CX-NSZ310
O TAPE DECK CN 0301 87-A60-620-010 0E CONN,3P V 2MM JMT VSFD CX-NSZ310

O TAPE DECK CN 0351 87-A60-625-010 0E CONN,8P V 2MM JMT VSFD CX-NSZ310
S TAPE DECK D 0401 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
X TAPE DECK FB 0301 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X TAPE DECK FB 0302 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
S TAPE DECK IC 0301 87-A21-419-040 0E C-IC,NJM14558MD-TE2 VSFD CX-NSZ310
S TAPE DECK IC 0401 87-A21-893-040 1A C-IC,NJM14558V-TE2 VSFD CX-NSZ310
X TAPE DECK JR 0302 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TAPE DECK JR 0305 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TAPE DECK JR 0306 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TAPE DECK JR 0307 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

 14 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TAPE DECK JR 0401 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TAPE DECK JR 0402 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TAPE DECK JR 0403 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TAPE DECK JR 0404 88-128-150-080 0E C-RES, 15-1/8W J VSFD CX-NSZ310
O TAPE DECK L 0451 87-007-342-010 0E COIL,OSC 85KHZ BIAS VSFD CX-NSZ310
S TAPE DECK Q 0301 87-A30-091-080 1E FET,2SJ460 VSFD CX-NSZ310
S TAPE DECK Q 0302 87-A30-091-080 1E FET,2SJ460 VSFD CX-NSZ310
S TAPE DECK Q 0303 87-A30-090-080 0E FET,2SK2541 VSFD CX-NSZ310
S TAPE DECK Q 0304 87-A30-090-080 0E FET,2SK2541 VSFD CX-NSZ310
S TAPE DECK Q 0305 87-A30-091-080 1E FET,2SJ460 VSFD CX-NSZ310

S TAPE DECK Q 0306 87-A30-062-080 0E C-TR,KRC104S VSFD CX-NSZ310
S TAPE DECK Q 0307 87-A30-091-080 1E FET,2SJ460 VSFD CX-NSZ310
S TAPE DECK Q 0308 87-A30-091-080 1E FET,2SJ460 VSFD CX-NSZ310
S TAPE DECK Q 0309 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S TAPE DECK Q 0310 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S TAPE DECK Q 0443 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S TAPE DECK Q 0444 87-A30-075-080 0E C-TR,2SA1235F VSFD CX-NSZ310
S TAPE DECK Q 0451 87-A30-495-080 0E TR,2SA1981Y VSFD CX-NSZ310
S TAPE DECK Q 0453 87-A30-615-080 0E TR,STC250 VSFD CX-NSZ310
S TAPE DECK Q 0454 87-A30-615-080 0E TR,STC250 VSFD CX-NSZ310

S TAPE DECK Q 0455 87-A30-076-080 0E C-TR,2SC3052F VSFD CX-NSZ310
X TAPE DECK R 0301 88-108-393-080 0E C-RES,U 39K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0302 88-108-393-080 0E C-RES,U 39K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0303 88-108-823-080 0E C-RES,U 82K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0304 88-108-823-080 0E C-RES,U 82K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0305 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0306 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0307 88-108-471-080 0E C-RES,U 470-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0308 88-108-471-080 0E C-RES,U 470-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0309 88-108-680-080 0E C-RES,U 68-1/16W J VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TAPE DECK R 0310 88-108-680-080 0E C-RES,U 68-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0313 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0314 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0315 88-108-394-080 0E C-RES,U 390K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0316 88-108-394-080 0E C-RES,U 390K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0317 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0318 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0319 88-108-472-080 0E C-RES,U 4.7K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0321 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TAPE DECK R 0322 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

X TAPE DECK R 0375 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0376 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0377 88-121-101-080 0E RES,100-1/8W J VSFD CX-NSZ310
X TAPE DECK R 0399 88-108-105-080 0E C-RES,U 1M-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0401 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0402 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0403 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0404 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0405 88-108-823-080 0E C-RES,U 82K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0406 88-108-823-080 0E C-RES,U 82K-1/16W J VSFD CX-NSZ310

X TAPE DECK R 0407 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0408 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0409 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0410 88-108-122-080 0E C-RES,U 1.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0411 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0412 88-108-153-080 0E C-RES,U 15K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0413 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0414 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0415 88-108-681-080 0E C-RES,U 680-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0416 88-108-681-080 0E C-RES,U 680-1/16W J VSFD CX-NSZ310

X TAPE DECK R 0417 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0418 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0419 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0420 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0421 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0422 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0423 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0424 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0453 88-118-152-080 0E C-RES,S 1.5K-1/10W J VSFD CX-NSZ310
X TAPE DECK R 0454 88-128-829-080 0E C-RES, 8.2-1/8W J VSFD CX-NSZ310

 15 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TAPE DECK R 0455 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0456 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0457 88-130-100-080 0E RES,10-1/4W J VSFD CX-NSZ310
X TAPE DECK R 0458 88-121-104-080 0E RES,100K-1/8W J VSFD CX-NSZ310
X TAPE DECK R 0459 88-128-150-080 0E C-RES, 15-1/8W J VSFD CX-NSZ310
X TAPE DECK R 0460 88-140-100-080 0E RES,10-1/2W J VSFD CX-NSZ310
X TAPE DECK R 0461 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TAPE DECK R 0462 88-108-471-080 0E C-RES,U 470-1/16W J VSFD CX-NSZ310
O TAPE DECK SFR0451 87-024-435-080 0E SFR,33K H RH063MC VSFD CX-NSZ310
O TAPE DECK SFR0452 87-024-435-080 0E SFR,33K H RH063MC VSFD CX-NSZ310

O TUNER(IF) C 0771 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O TUNER(IF) C 0772 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
X TUNER(IF) C 0781 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(IF) C 0782 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0783 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0784 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0785 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0786 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0788 87-012-167-080 0E C-CAP,U 5P-50 C CH VSFD CX-NSZ310
O TUNER(IF) C 0789 87-016-118-080 0E C-CAP,U 0.022-25 J B GRM VSFD CX-NSZ310

O TUNER(IF) C 0790 87-016-118-080 0E C-CAP,U 0.022-25 J B GRM VSFD CX-NSZ310
O TUNER(IF) C 0791 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(IF) C 0792 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0793 87-A12-090-080 0E CAP,E 4.7-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0795 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0796 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0797 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0798 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0799 87-010-265-080 0E CAP,E 33-16 M 11L SME VSFD CX-NSZ310
O TUNER(IF) C 0800 87-010-829-080 0E C-CAP,U 0.047-16 Z F VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O TUNER(IF) C 0801 87-A12-089-080 0E CAP,E 3.3-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0802 87-010-829-080 0E C-CAP,U 0.047-16 Z F VSFD CX-NSZ310
O TUNER(IF) C 0803 87-010-787-080 0E C-CAP,U 0.022-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0804 87-A12-062-080 0E CAP,E 100-10 SMG VSFD CX-NSZ310
O TUNER(IF) C 0807 87-A12-086-080 0E CAP,E 0.47-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0808 87-A12-087-080 0E CAP,E 1-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0809 87-A12-087-080 0E CAP,E 1-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0810 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(IF) C 0814 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(IF) C 0815 87-A12-086-080 0E CAP,E 0.47-50 SMG VSFD CX-NSZ310

O TUNER(IF) C 0816 87-A12-086-080 0E CAP,E 0.47-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0821 87-A12-091-080 0E CAP,E 10-50 SMG VSFD CX-NSZ310
X TUNER(IF) C 0822 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(IF) C 0823 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 VSFD CX-NSZ310
O TUNER(IF) C 0824 87-A12-090-080 0E CAP,E 4.7-50 SMG VSFD CX-NSZ310
O TUNER(IF) C 0825 87-010-596-080 0E C-CAP,S 0.047-16 K R C2012 VSFD CX-NSZ310
X TUNER(IF) D 0801 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
S TUNER(IF) D 0803 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S TUNER(IF) IC 0801 87-A21-695-010 1C IC,LA1845L VSFD CX-NSZ310
X TUNER(IF) JR 0781 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310

X TUNER(IF) JR 0785 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) JR 0786 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) JR 0792 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) JR 0795 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TUNER(IF) JR 0797 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) JR 0801 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(IF) L 0801 87-A50-608-010 0E COIL,FM DET-N(TOK) VSFD CX-NSZ310
O TUNER(IF) L 0802 87-A91-551-010 1A FLTR,PCFJZH-450 L(TOK) VSFD CX-NSZ310
O TUNER(IF) L 0811 87-005-847-080 0E COIL,2.2UH K CECS VSFD CX-NSZ310
O TUNER(IF) R 0790 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

X TUNER(IF) R 0791 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0793 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0795 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0801 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0802 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0803 88-128-183-080 0E C-RES, 18K-1/8W J VSFD CX-NSZ310
X TUNER(IF) R 0804 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0805 88-108-332-080 0E C-RES,U 3.3K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0806 88-108-682-080 0E C-RES,U 6.8K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0809 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310

 16 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

X TUNER(IF) R 0810 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0811 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0812 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0813 88-108-224-080 0E C-RES,U 220K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0814 88-108-105-080 0E C-RES,U 1M-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0815 88-121-682-080 0E RES,6.8K-1/8W J VSFD CX-NSZ310
X TUNER(IF) R 0818 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0821 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(IF) R 0823 88-108-333-080 0E C-RES,U 33K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0824 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310

X TUNER(IF) R 0825 88-108-123-080 0E C-RES,U 12K-1/16W J VSFD CX-NSZ310
X TUNER(IF) R 0826 88-108-223-080 0E C-RES,U 22K-1/16W J VSFD CX-NSZ310
O TUNER(PLL) C 0971 87-A12-067-080 0E CAP,E 330-16 SMG VSFD CX-NSZ310
O TUNER(PLL) C 0972 87-A12-090-080 0E CAP,E 4.7-50 SMG VSFD CX-NSZ310
O TUNER(PLL) C 0973 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(PLL) C 0974 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(PLL) C 0979 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
O TUNER(PLL) C 0981 87-A12-071-080 0E CAP,E 47-25 SMG VSFD CX-NSZ310
O TUNER(PLL) C 0982 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(PLL) C 0983 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

O TUNER(PLL) C 0984 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(PLL) C 0987 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(PLL) C 0991 87-012-176-080 0E C-CAP,U 15P-50 J CH VSFD CX-NSZ310
O TUNER(PLL) C 0992 87-012-176-080 0E C-CAP,U 15P-50 J CH VSFD CX-NSZ310
O TUNER(PLL) C 0993 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O TUNER(PLL) C 0995 87-012-274-080 0E C-CAP,U 1000P-50 K B VSFD CX-NSZ310
O TUNER(PLL) C 0997 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(PLL) C 0998 87-A12-071-080 0E CAP,E 47-25 SMG VSFD CX-NSZ310
O TUNER(PLL) C 0999 87-A11-155-080 0E CAP,TC U 0.01-16 Z F VSFD CX-NSZ310
S TUNER(PLL) D 0991 87-017-149-080 0E ZENER,HZS6A2L VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S TUNER(PLL) D 0994 87-A40-291-080 0E DIODE,1N4148M (CPT) VSFD CX-NSZ310
S TUNER(PLL) IC 0991 87-A21-928-010 1C IC,LC72131D-N VSFD CX-NSZ310
X TUNER(PLL) JR 0971 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TUNER(PLL) JR 0972 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(PLL) JR 0973 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TUNER(PLL) JR 0974 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(PLL) JR 0976 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(PLL) JR 0977 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(PLL) JR 0988 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(PLL) JR 0991 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

S TUNER(PLL) Q 0981 87-A30-234-080 0E TR,CSC4115BC VSFD CX-NSZ310
X TUNER(PLL) R 0975 88-108-562-080 0E C-RES,U 5.6K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0976 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0977 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0978 88-108-681-080 0E C-RES,U 680-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0980 88-108-684-080 0E C-RES,U 680K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0981 88-121-471-080 0E RES,470-1/8W J VSFD CX-NSZ310
X TUNER(PLL) R 0982 88-108-822-080 0E C-RES,U 8.2K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0983 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0984 88-121-181-080 0E RES,180-1/8W J VSFD CX-NSZ310

X TUNER(PLL) R 0985 88-121-471-080 0E RES,470-1/8W J VSFD CX-NSZ310
X TUNER(PLL) R 0986 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0987 88-121-472-080 0E RES,4.7K-1/8W J VSFD CX-NSZ310
X TUNER(PLL) R 0988 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0989 88-121-102-080 0E RES,1K-1/8W J VSFD CX-NSZ310
X TUNER(PLL) R 0990 88-108-563-080 0E C-RES,U 56K-1/16W J VSFD CX-NSZ310
O TUNER(PLL) R 0991 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
X TUNER(PLL) R 0992 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
O TUNER(PLL) R 0993 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
X TUNER(PLL) R 0994 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310

O TUNER(PLL) R 0995 87-012-195-080 0E C-CAP,U 100P-50 J CH VSFD CX-NSZ310
X TUNER(PLL) R 0996 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0997 88-108-154-080 0E C-RES,U 150K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0998 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(PLL) R 0999 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
O TUNER(PLL) X 0992 87-A70-306-010 1A VIB,XTAL 4.500MHZ CSA-309ST VSFD CX-NSZ310
X TUNER(RDS) JR 0871 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RDS) JR 0873 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(RF) C 0842 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
X TUNER(RF) C 0843 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

 17 

PARTS LIST

! = ! SAFTY PARTS
C = Components marked

K NO. = Only use japanese.

O TUNER(RF) C 0844 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
X TUNER(RF) C 0845 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) C 0846 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) C 0847 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) C 0848 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) C 0849 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(RF) C 0850 87-A12-071-080 0E CAP,E 47-25 SMG VSFD CX-NSZ310
O TUNER(RF) C 0851 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(RF) C 0852 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
O TUNER(RF) C 0853 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310

O TUNER(RF) C 0858 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(RF) C 0859 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(RF) C 0860 87-012-286-080 0E C-CAP,U 0.01-25 K B VSFD CX-NSZ310
X TUNER(RF) C 0940 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
O TUNER(RF) C 0959 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(RF) C 0960 87-010-831-080 0E C-CAP,U 0.1-16 Z F VSFD CX-NSZ310
O TUNER(RF) C 0961 87-012-167-080 0E C-CAP,U 5P-50 C CH VSFD CX-NSZ310
O TUNER(RF) C 0963 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 VSFD CX-NSZ310
O TUNER(RF) CF 0831 87-008-261-010 1A FLTR,CF SFE10.7MA5 VSFD CX-NSZ310
O TUNER(RF) CF 0832 87-008-261-010 1A FLTR,CF SFE10.7MA5 VSFD CX-NSZ310

X TUNER(RF) D 0944 88-100-000-010 0E PLATING-JW, 0.58 SN95 VSFD CX-NSZ310
X TUNER(RF) FFE0831 A8-6ZA-19P-030  6ZA-1 YFEMVNM VSFD CX-NSZ310
! O TUNER(RF) J 0831 87-A60-202-010 1A TERMINAL,ANT 4P MSP-154V-02 VSFD CX-NSZ310
X TUNER(RF) JR 0834 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0835 88-108-561-080 0E C-RES,U 560-1/16W J VSFD CX-NSZ310
X TUNER(RF) JR 0851 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
X TUNER(RF) JR 0943 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0946 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0951 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0952 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X TUNER(RF) JR 0954 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0955 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) JR 0964 88-129-000-080 0E C-JUMPER,3216 VSFD CX-NSZ310
O TUNER(RF) L 0832 87-005-847-080 0E COIL,2.2UH K CECS VSFD CX-NSZ310
O TUNER(RF) L 0951 8A-NF8-667-010 1C COIL,AM PACK 4(TOK) VSFD CX-NSZ310
S TUNER(RF) Q 0835 89-327-143-080 0E C-TR,2SC2714O VSFD CX-NSZ310
S TUNER(RF) Q 0836 87-A30-489-080 0E C-TR,KRA107S VSFD CX-NSZ310
X TUNER(RF) R 0832 88-108-391-080 0E C-RES,U 390-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0836 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0839 88-108-151-080 0E C-RES,U 150-1/16W J VSFD CX-NSZ310

X TUNER(RF) R 0840 88-108-221-080 0E C-RES,U 220-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0850 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0851 88-108-470-080 0E C-RES,U 47-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0853 88-108-102-080 0E C-RES,U 1K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0854 88-108-331-080 0E C-RES,U 330-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0855 88-108-183-080 0E C-RES,U 18K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0856 88-108-103-080 0E C-RES,U 10K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0857 88-108-181-080 0E C-RES,U 180-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0858 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0860 88-108-101-080 0E C-RES,U 100-1/16W J VSFD CX-NSZ310

X TUNER(RF) R 0921 88-108-000-080 0E C-JUMPER,U VSFD CX-NSZ310
X TUNER(RF) R 0945 88-108-104-080 0E C-RES,U 100K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0954 88-108-222-080 0E C-RES,U 2.2K-1/16W J VSFD CX-NSZ310
X TUNER(RF) R 0962 88-121-221-080 0E RES,220-1/8W J VSFD CX-NSZ310
X TUNER(RF) R 0963 88-108-330-080 0E C-RES,U 33-1/16W J VSFD CX-NSZ310

 18 

SCHEMATIC DIAGRAM – 1 (MAIN) <1/2>

SCHEMATIC DIAGRAM – 2 (MAIN) <2/2>

SCHEMATIC DIAGRAM – 3 (FRONT)

SCHEMATIC DIAGRAM – 4 (PT)

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]

Printed in Singapore9301978
