S E R V I C E M A N U A L
COMPACT DISC STEREO
CASSETTE RECEIVER
NSX-MT520
• BASIC TAPE MECHANISM: 6ZM-3 PR2NM
• BASIC CD MECHANISM: 4ZG-1 Z3DSHNM
SIMPLE MANUAL
CD
CASSEIVER
NSX-MT520
CX-NMT520
SPEAKERSYSTEM
SX–NA502
SX-C605
SX-R275
• TYPE : U
REMOTE
CONTROLLER
RC - 7AS09
• Replace this Service Manual with "Revision Publishing" when it is issued.
• If requiring information about the CD mechanism, see Service Manual of
4ZG-1, S/M Code No. 09-983-249-3OT.
S/M Code No. 09–985–276–5FE
ELECTRICAL MAIN PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
USTM ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
88-NF7-201-010 GUIDE,OPE A...................
C 105 87-010-178-080 CHIP CAP 1000P A...................
C 108 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 103 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 102 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 107 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 104 87-010-494-040 CAP,E 1-50 GAS A...................
C 101 87-010-550-040 CAP,E 100-6.3 GAS A...................
C 109 87-018-208-080 CAP 0.047-50F A...................
C 106 87-A10-189-040 CAP,E 220-10 A...................
C 114 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 115 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 118 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 112 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 113 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 111 87-010-320-080 CHIP CAP 68P A...................
C 116 87-010-498-040 CAP,E 10-16 GAS A...................
C 110 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 117 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 121 87-010-194-080 CAP, CHIP 0.047 A...................
C 122 87-010-194-080 CAP, CHIP 0.047 A...................
C 125 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 120 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 124 87-010-263-040 CAP,E 100-10 A...................
C 201 87-010-178-080 CHIP CAP 1000P A...................
C 202 87-010-194-080 CAP, CHIP 0.047 A...................
C 205 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 204 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 206 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 209 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 207 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 208 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 203 87-A10-797-040 CAP,E 47-35 M 5L SRM A...................
C 215 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 216 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 211 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 217 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 213 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 218 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 210 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 214 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 212 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 376 87-010-173-080 C-CAP,S 390P-50 SL A...................
C 377 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 371 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 373 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 372 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 375 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 408 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 402 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 406 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 404 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
D 107 87-A40-470-080 DIODE,1SS254 A...................
D 106 87-A40-470-080 DIODE,1SS254 A...................
D 105 87-A40-504-040 C-DIODE,KDS184 A...................
D 104 87-A40-504-040 C-DIODE,KDS184 A...................
D 102 87-A40-505-040 C-DIODE,KDS181 A...................
D 103 87-A40-509-080 ZENER,MTZJ6.8C A...................
D 319 87-A40-470-080 DIODE,1SS254 A...................
D 318 87-A40-470-080 DIODE,1SS254 A...................
D 315 87-A40-505-040 C-DIODE,KDS181 A...................
D 310 87-A40-505-040 C-DIODE,KDS181 A...................
D 311 87-A40-505-040 C-DIODE,KDS181 A...................
D 314 87-A40-505-040 C-DIODE,KDS181 A...................
D 317 87-A40-505-040 C-DIODE,KDS181 A...................
D 312 87-A40-505-040 C-DIODE,KDS181 A...................
D 313 87-A40-505-040 C-DIODE,KDS181 A...................
D 320 87-A40-470-080 DIODE,1SS254 A...................
D 322 87-A40-470-080 DIODE,1SS254 A...................
D 324 87-A40-470-080 DIODE,1SS254 A...................
D 330 87-A40-470-080 DIODE,1SS254 A...................
D 373 87-A40-470-080 DIODE,1SS254 A...................
D 372 87-A40-470-080 DIODE,1SS254 A...................
D 371 87-A40-470-080 DIODE,1SS254 A...................
D 374 87-A40-470-080 DIODE,1SS254 A...................
D 403 87-A40-470-080 DIODE,1SS254 A...................
D 405 87-A40-470-080 DIODE,1SS254 A...................
D 402 87-A40-470-080 DIODE,1SS254 A...................
D 404 87-A40-470-080 DIODE,1SS254 A...................
D 401 87-A40-470-080 DIODE,1SS254 A...................
D 409 87-A40-470-080 DIODE,1SS254 A...................
D 410 87-A40-470-080 DIODE,1SS254 A...................
D 701 87-A40-505-040 C-DIODE,KDS181 A...................
FL 201 88-NF7-651-010 FL,BJ602GK A...................
ELECTRICAL MAIN PARTS LIST - 2
IC 102 87-070-083-010 IC,GP1U281X A...................
IC 101 88-NF7-750-010 C-IC,LC866560W-5H26 A...................
IC 371 87-A20-083-010 IC,BA3835S A...................
IC 401 87-017-915-080 IC,BU4094BCF A...................
IC 402 87-017-915-080 IC,BU4094BCF A...................
IC 403 87-017-915-080 IC,BU4094BCF A...................
IC 404 87-070-289-040 IC,BU 2092F A...................
LED 405 87-070-197-080 LED,SLP7118C-51-S-T1 A...................
LED 407 87-070-197-080 LED,SLP7118C-51-S-T1 A...................
LED 401 87-070-197-080 LED,SLP7118C-51-S-T1 A...................
LED 403 87-070-197-080 LED,SLP7118C-51-S-T1 A...................
LED 409 87-070-197-080 LED,SLP7118C-51-S-T1 A...................
LED 414 87-070-201-080 LED,SLP9118C-51-S-T1 A...................
LED 411 87-070-201-080 LED,SLP9118C-51-S-T1 A...................
LED 413 87-070-201-080 LED,SLP9118C-51-S-T1 A...................
LED 412 87-070-201-080 LED,SLP9118C-51-S-T1 A...................
LED 415 87-070-201-080 LED,SLP9118C-51-S-T1 A...................
LED 419 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 417 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 425 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 423 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 421 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 427 87-070-281-080 LED,SLZ736A-25-S-T1 A...................
LED 428 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 429 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 437 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 435 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 431 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 436 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 433 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 432 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 434 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 430 87-A40-380-080 LED,SEL6510C-TP5 GRN A...................
LED 444 87-070-278-010 LED,SLZ-738A-24-S A...................
LED 449 87-070-278-010 LED,SLZ-738A-24-S A...................
LED 446 87-070-278-010 LED,SLZ-738A-24-S A...................
LED 447 87-070-278-010 LED,SLZ-738A-24-S A...................
LED 448 87-070-290-010 LED,SLZ 936-30-S A...................
LED 445 87-070-290-010 LED,SLZ 936-30-S A...................
LED 457 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 459 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 451 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 453 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 458 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 455 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 456 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 454 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
LED 450 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED A...................
Q 102 87-026-263-080 C-TR,RN1410 A...................
Q 104 87-026-610-080 TR,KTC3198GR A...................
Q 103 87-A30-071-080 C-TR,RT1N 144C A...................
Q 101 87-A30-087-080 C-FET,2SK2158 A...................
Q 301 87-A30-076-080 C-TR,2SC3052F A...................
Q 407 87-026-580-080 C-TR,DTA123JK A...................
Q 406 87-026-580-080 C-TR,DTA123JK A...................
Q 403 87-026-580-080 C-TR,DTA123JK A...................
Q 404 87-026-580-080 C-TR,DTA123JK A...................
Q 405 87-026-580-080 C-TR,DTA123JK A...................
Q 401 87-A30-073-080 C-TR,RT1N 141C A...................
Q 402 87-A30-073-080 C-TR,RT1N 141C A...................
Q 409 87-A30-074-080 C-TR,RT1P 141C A...................
Q 408 87-A30-075-080 C-TR,2SA1235F A...................
Q 414 87-A30-074-080 C-TR,RT1P 141C A...................
Q 419 87-A30-074-080 C-TR,RT1P 141C A...................
Q 411 87-A30-074-080 C-TR,RT1P 141C A...................
Q 417 87-A30-074-080 C-TR,RT1P 141C A...................
Q 413 87-A30-074-080 C-TR,RT1P 141C A...................
Q 418 87-A30-074-080 C-TR,RT1P 141C A...................
Q 415 87-A30-074-080 C-TR,RT1P 141C A...................
Q 410 87-A30-074-080 C-TR,RT1P 141C A...................
Q 416 87-A30-074-080 C-TR,RT1P 141C A...................
Q 412 87-A30-074-080 C-TR,RT1P 141C A...................
Q 420 87-A30-074-080 C-TR,RT1P 141C A...................
Q 424 87-A30-074-080 C-TR,RT1P 141C A...................
Q 421 87-A30-074-080 C-TR,RT1P 141C A...................
Q 423 87-A30-074-080 C-TR,RT1P 141C A...................
Q 422 87-A30-074-080 C-TR,RT1P 141C A...................
Q 704 87-A30-073-080 C-TR,RT1N 141C A...................
Q 703 87-A30-085-070 C-TR,CSA1362GR A...................
Q 702 87-A30-085-070 C-TR,CSA1362GR A...................
Q 701 89-112-965-080 TR,2SA1296 (0.75W) A...................
S 102 87-A90-535-010 SW,RTRY EC16B24304 A...................
S 101 87-A90-791-010 SW,RTRY EC16B12204 ENCODER A...................
S 307 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 306 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 301 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 303 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 308 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 305 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 304 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 302 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 309 87-A90-095-080 SW,TACT EVQ11G04M A...................
ELECTRICAL MAIN PARTS LIST - 3
S 312 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 311 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 310 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 325 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 326 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 327 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 323 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 321 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 322 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 324 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 334 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 335 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 341 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 346 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 347 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 343 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 348 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 345 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 344 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 342 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 349 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 352 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 354 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 351 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 353 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 350 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 355 87-A90-095-080 SW,TACT EVQ11G04M A...................
X 101 87-A70-070-080 VIB,CER 5.76MHZ CRHF A...................
C 602 87-010-186-080 CAP,CHIP 4700P A...................
C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 605 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 607 87-010-321-080 CHIP CAPACITOR,82P(J) A...................
C 606 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 604 87-010-382-040 CAP,E 22-25 SME A...................
C 601 87-010-391-040 CAP,E 10-35 SME A...................
C 603 87-010-498-040 CAP,E 10-16 GAS A...................
C 609 87-010-545-040 CAP,E 0.22-50 SME A...................
C 611 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 614 87-A10-189-040 CAP,E 220-10 A...................
C 652 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 653 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 651 87-010-401-040 CAP,E 1-50 SME A...................
D 601 87-A40-470-080 DIODE,1SS254 A...................
D 651 87-A40-470-080 DIODE,1SS254 A...................
FB 601 87-008-372-080 FILTER, EMI BL OIRNI A...................
IC 601 87-017-888-080 IC,NJM4558MD A...................
J 601 87-A60-284-010 JACK,3.5MO (MSC) A...................
J 602 87-A60-284-010 JACK,3.5MO (MSC) A...................
Q 601 87-A30-087-080 C-FET,2SK2158 A...................
Q 651 87-A30-076-080 C-TR,2SC3052F A...................
FC 101 87-A90-505-080 FUSE CLAMP,TP00351-51 A...................
FC 102 87-A90-505-080 FUSE CLAMP,TP00351-51 A...................
PR 102 87-026-691-080 FUSE,10A 125V 251 A...................
PR 101 87-026-691-080 FUSE,10A 125V 251 A...................
PR 103 87-026-691-080 FUSE,10A 125V 251 A...................
PR 104 87-026-691-080 FUSE,10A 125V 251 A...................
PR 106 87-A90-210-080 FUSE,7A 125V 251 A...................
PR 105 87-A90-210-080 FUSE,7A 125V 251 A...................
T 101 87-A60-317-010 TERMINAL, 1P MSC A...................
T 102 87-A60-317-010 TERMINAL, 1P MSC A...................
W 104 85-NF5-628-010 F-CABLE 7P-2.5 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
C 109 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 107 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 106 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 108 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 105 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 112 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 116 87-010-247-080 CAP, ELECT 100-50V A...................
C 113 87-010-247-080 CAP, ELECT 100-50V A...................
C 119 87-010-260-080 CAP, ELECT 47-25V A...................
C 118 87-010-263-080 CAP, ELECT 100-10V A...................
C 117 87-010-430-080 CAP, ELECT 100-63 A...................
C 124 87-010-112-080 CAP, ELECT 100-16V A...................
C 125 87-010-235-080 CAP,E 470-16 SME A...................
C 123 87-010-247-080 CAP, ELECT 100-50V A...................
C 122 87-010-263-080 CAP, ELECT 100-10V A...................
C 128 87-010-394-080 CAP ELECT220-35V A...................
C 120 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 121 87-012-140-080 CAP 470P A...................
C 151 87-010-917-090 CAP,E 3300-50 M SMG A...................
C 152 87-010-917-090 CAP,E 3300-50 M SMG A...................
C 153 87-010-928-090 CAP,E 4700-25 SMG A...................
D 101 87-002-225-010 DIODE,DBF40C-K10 A...................
D 102 87-002-225-010 DIODE,DBF40C-K10 A...................
D 108 87-070-274-080 DIODE,1N4003 SEM A...................
D 109 87-070-274-080 DIODE,1N4003 SEM A...................
D 107 87-070-274-080 DIODE,1N4003 SEM A...................
D 106 87-070-274-080 DIODE,1N4003 SEM A...................
D 103 87-A40-470-080 DIODE,1SS254 A...................
ELECTRICAL MAIN PARTS LIST - 4
D 105 87-A40-504-040 C-DIODE,KDS184 A...................
D 104 87-A40-505-040 C-DIODE,KDS181 A...................
D 112 87-A40-308-080 ZENER,DZ10M A...................
D 110 87-A40-341-080 ZENER,MTZJ 36 A A...................
D 116 87-A40-505-040 C-DIODE,KDS181 A...................
D 120 87-A40-004-080 ZENER,MTZJ16A A...................
Q 103 87-026-610-080 TR,KTC3198GR A...................
Q 109 87-A30-075-080 C-TR,2SA1235F A...................
Q 107 87-A30-075-080 C-TR,2SA1235F A...................
Q 106 87-A30-076-080 C-TR,2SC3052F A...................
Q 104 87-A30-076-080 C-TR,2SC3052F A...................
Q 108 87-A30-076-080 C-TR,2SC3052F A...................
Q 105 87-A30-196-080 TR,2SC4115SRS A...................
Q 102 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 101 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 111 87-026-609-080 TR,KTA1266GR A...................
Q 112 87-026-609-080 TR,KTA1266GR A...................
Q 115 87-A30-075-080 C-TR,2SA1235F A...................
Q 114 87-A30-075-080 C-TR,2SA1235F A...................
Q 110 87-A30-076-080 C-TR,2SC3052F A...................
R 123 87-022-200-080 RESISTOR, METAL 0.56 1W A...................
RY 101 87-A90-464-010 RELAY, DG12D2-O(M) A...................
C 209 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 212 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 211 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 214 87-010-186-080 CAP,CHIP 4700P A...................
C 213 87-010-186-080 CAP,CHIP 4700P A...................
C 215 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 216 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 210 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 217 87-A10-899-080 CAP,E 47-25 M BP SME A...................
C 218 87-A10-899-080 CAP,E 47-25 M BP SME A...................
C 229 87-A10-812-080 C-CAP,S 220P-200 J CH A...................
C 234 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 233 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 238 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 237 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 239 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 230 87-A10-812-080 C-CAP,S 220P-200 J CH A...................
C 248 87-010-178-080 CHIP CAP 1000P A...................
C 247 87-010-178-080 CHIP CAP 1000P A...................
C 240 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 280 87-010-188-080 CAP,CHIP 6800P A...................
D 206 87-A40-470-080 DIODE,1SS254 A...................
D 207 87-A40-470-080 DIODE,1SS254 A...................
D 202 87-A40-470-080 DIODE,1SS254 A...................
D 208 87-A40-470-080 DIODE,1SS254 A...................
D 204 87-A40-470-080 DIODE,1SS254 A...................
D 201 87-A40-470-080 DIODE,1SS254 A...................
D 203 87-A40-470-080 DIODE,1SS254 A...................
D 205 87-A40-470-080 DIODE,1SS254 A...................
D 226 87-A40-488-080 DIODE,1SS244 A...................
D 225 87-A40-488-080 DIODE,1SS244 A...................
D 221 87-A40-504-040 C-DIODE,KDS184 A...................
D 233 87-A40-470-080 DIODE,1SS254 A...................
D 234 87-A40-470-080 DIODE,1SS254 A...................
D 280 87-A40-470-080 DIODE,1SS254 A...................
D 295 87-A40-470-080 DIODE,1SS254 A...................
J 203 87-033-240-010 TERMINAL,SP 4P32SV1-05 A...................
J 211 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A...................
L 201 87-003-383-010 COIL,1UH-S A...................
L 202 87-003-383-010 COIL,1UH-S A...................
Q 208 87-A30-107-070 C-TR,CMBT5401 A...................
Q 207 87-A30-107-070 C-TR,CMBT5401 A...................
Q 209 87-A30-107-070 C-TR,CMBT5401 A...................
Q 213 87-A30-076-080 C-TR,2SC3052F A...................
Q 214 87-A30-076-080 C-TR,2SC3052F A...................
Q 212 87-A30-076-080 C-TR,2SC3052F A...................
Q 211 87-A30-076-080 C-TR,2SC3052F A...................
Q 210 87-A30-107-070 C-TR,CMBT5401 A...................
Q 218 87-A30-137-010 TR,2SD2494 A...................
Q 217 87-A30-137-010 TR,2SD2494 A...................
Q 219 87-A30-138-010 TR,2SB1625 A...................
Q 216 87-A30-190-080 TR,CC5551 A...................
Q 215 87-A30-190-080 TR,CC5551 A...................
Q 221 87-A30-106-070 C-TR,CMBT5551 A...................
Q 222 87-A30-106-070 C-TR,CMBT5551 A...................
Q 220 87-A30-138-010 TR,2SB1625 A...................
Q 280 87-A30-107-070 C-TR,CMBT5401 A...................
Q 295 87-A30-221-040 C-TR,DTA114WK A...................
R 237 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 238 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 239 87-A00-257-080 RES,M/F 0.15-1W J A...................
R 240 87-A00-257-080 RES,M/F 0.15-1W J A...................
C 309 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 301 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 302 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 306 87-012-145-080 CAP, CHIP S 270P CH A...................
C 305 87-012-145-080 CAP, CHIP S 270P CH A...................
C 304 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 303 87-012-157-080 C-CAP,S 330P-50 CH A...................
ELECTRICAL MAIN PARTS LIST - 5
C 314 87-010-180-080 C-CER 1500P A...................
C 313 87-010-180-080 C-CER 1500P A...................
C 315 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 316 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 310 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 311 87-010-198-080 CAP, CHIP 0.022 A...................
C 312 87-010-198-080 CAP, CHIP 0.022 A...................
C 324 87-010-260-080 CAP, ELECT 47-25V A...................
C 325 87-010-370-080 CAP,E 330-6.3 SME A...................
C 327 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 328 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 321 87-016-492-080 C-CAP,S 0.33-16 FZ A...................
C 322 87-016-492-080 C-CAP,S 0.33-16 FZ A...................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 336 87-010-401-080 CAP, ELECT 1-50V A...................
C 335 87-010-401-080 CAP, ELECT 1-50V A...................
C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 354 87-010-175-080 CAP 560P A...................
C 358 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 359 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 357 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 356 87-010-260-080 CAP, ELECT 47-25V A...................
C 352 87-012-140-080 CAP 470P A...................
C 351 87-012-140-080 CAP 470P A...................
C 355 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 360 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 379 87-010-382-080 CAP, ELECT 22-25V A...................
C 374 87-016-083-080 C-CAP,S 0.15-16 RK A...................
C 373 87-016-083-080 C-CAP,S 0.15-16 RK A...................
C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 381 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 383 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 382 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 380 87-010-382-080 CAP, ELECT 22-25V A...................
C 384 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 387 87-012-145-080 CAP, CHIP S 270P CH A...................
C 392 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 394 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 393 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 391 87-010-319-080 C-CAP,S 56P-50 CH A...................
D 351 87-A40-470-080 DIODE,1SS254 A...................
D 352 87-A40-505-040 C-DIODE,KDS181 A...................
IC 301 87-070-121-010 IC,HA12185NT A...................
L 301 87-A50-049-010 COIL,TRAP 85K(COI) A...................
L 302 87-A50-049-010 COIL,TRAP 85K(COI) A...................
L 351 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 358 87-026-610-080 TR,KTC3198GR A...................
Q 357 87-026-610-080 TR,KTC3198GR A...................
Q 359 87-026-610-080 TR,KTC3198GR A...................
Q 353 87-A30-087-080 C-FET,2SK2158 A...................
Q 354 87-A30-087-080 C-FET,2SK2158 A...................
Q 351 87-A30-087-080 C-FET,2SK2158 A...................
Q 355 87-A30-105-080 C-TR,RT1P 441C A...................
Q 360 87-026-238-080 TR,DTC144WK A...................
Q 383 87-A30-075-080 C-TR,2SA1235F A...................
Q 381 87-A30-076-080 C-TR,2SC3052F A...................
Q 382 87-A30-076-080 C-TR,2SC3052F A...................
SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA A...................
SFR 352 87-A90-433-080 SFR,50K H NVZ6TLTA A...................
C 403 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 404 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 406 87-010-193-080 CHIP CAPACITOR,0.033 A...................
C 405 87-010-193-080 CHIP CAPACITOR,0.033 A...................
C 409 87-010-380-080 CAP, ELECT 47-16V A...................
C 402 87-010-401-080 CAP, ELECT 1-50V A...................
C 401 87-010-401-080 CAP, ELECT 1-50V A...................
C 407 87-010-405-080 CAP, ELECT 10-50V A...................
C 408 87-010-405-080 CAP, ELECT 10-50V A...................
C 412 87-010-112-080 CAP, ELECT 100-16V A...................
C 416 87-010-187-080 CAP CHIP S5600P A...................
C 415 87-010-187-080 CAP CHIP S5600P A...................
C 410 87-010-380-080 CAP, ELECT 47-16V A...................
C 411 87-010-405-080 CAP, ELECT 10-50V A...................
IC 401 87-A20-804-040 C-IC,NJM2152M A...................
C 516 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 704 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 703 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 709 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 701 87-010-381-080 CAP, ELECT 330-16V A...................
C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 714 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 713 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 711 87-010-263-080 CAP, ELECT 100-10V A...................
C 723 87-010-178-080 CHIP CAP 1000P A...................
C 725 87-010-178-080 CHIP CAP 1000P A...................
C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 728 87-010-248-080 CAP, ELECT 220-10V A...................
ELECTRICAL MAIN PARTS LIST - 6
C 721 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 722 87-010-312-080 C-CAP,S 15P-50 CH A...................
D 721 87-A40-234-080 ZENER,MTZJ5.6A A...................
IC 721 86-NFZ-655-010 IC,LC72131D(Z) A...................
Q 711 87-A30-196-080 TR,2SC4115SRS A...................
X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
C 758 87-010-149-080 C-CAP,S 5P-50 CH A...................
C 756 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 755 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 757 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 759 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 763 87-010-194-080 CAP, CHIP 0.047 A...................
C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 768 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 766 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 762 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 765 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 764 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 767 87-010-405-080 CAP, ELECT 10-50V A...................
C 769 87-010-408-080 CAP, ELECT 47-50V A...................
C 760 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 772 87-010-194-080 CAP, CHIP 0.047 A...................
C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 776 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 774 87-010-263-080 CAP, ELECT 100-10V A...................
C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 778 87-010-401-080 CAP, ELECT 1-50V A...................
C 779 87-010-401-080 CAP, ELECT 1-50V A...................
C 775 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 771 87-010-407-080 CAP, ELECT 33-50V A...................
C 770 87-015-821-080 C-CAP 0.047 A...................
C 789 87-010-179-080 CAP,CHIP S B1200P A...................
C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 784 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 786 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 785 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 782 87-010-405-080 CAP, ELECT 10-50V A...................
C 781 87-010-405-080 CAP, ELECT 10-50V A...................
C 783 87-015-819-080 CAPACITOR,0.01 A...................
C 793 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 790 87-010-179-080 CAP,CHIP S B1200P A...................
C 798 87-010-181-080 CAP,CHIP S 1800P A...................
C 797 87-010-181-080 CAP,CHIP S 1800P A...................
C 799 87-010-194-080 CAP, CHIP 0.047 A...................
C 796 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 791 87-010-405-080 CAP, ELECT 10-50V A...................
C 794 87-010-406-080 CAP, ELECT 22-50 A...................
C 795 87-010-596-080 CAP, S 0.047-16 A...................
D 773 87-A40-470-080 DIODE,1SS254 A...................
IC 771 87-A20-438-010 IC,LA1837 A...................
L 771 87-A50-266-010 COIL,FM DET-2N(TOK) A...................
L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) A...................
L 781 87-005-847-080 COIL,2.2UH(CECS) A...................
C 812 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 814 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 822 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 823 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 821 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 820 87-010-408-080 CAP, ELECT 47-50V A...................
C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 961 87-010-152-080 C-CAP,S 8P-50 CH A...................
C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CF 801 87-008-261-010 FILTER, SFE10.7MA5-A A...................
CF 802 87-008-261-010 FILTER, SFE10.7MA5-A A...................
FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM A...................
FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC ....................
J 801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 A...................
L 832 86-NFZ-694-080 COIL,2.2UH K CECS A...................
L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) A...................
Q 806 87-A30-072-080 C-TR,RT1P 144C A...................
Q 805 89-327-143-080 TR,2SC2714 (0.1W) A...................
C 601 87-010-180-080 C-CER 1500P A...................
C 602 87-010-180-080 C-CER 1500P A...................
C 619 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 613 87-016-081-080 C-CAP,S 0.1-16 RK A...................
C 614 87-016-081-080 C-CAP,S 0.1-16 RK A...................
C 618 88-710-989-810 CAP,M 0.056-50 J TFL A...................
C 617 88-710-989-810 CAP,M 0.056-50 J TFL A...................
C 620 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 621 87-010-401-080 CAP, ELECT 1-50V A...................
C 622 87-010-401-080 CAP, ELECT 1-50V A...................
C 625 87-010-405-080 CAP, ELECT 10-50V A...................
C 626 87-010-405-080 CAP, ELECT 10-50V A...................
C 629 87-010-405-080 CAP, ELECT 10-50V A...................
C 637 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 636 87-010-194-080 CAP, CHIP 0.047 A...................
C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 635 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 630 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 632 87-010-263-080 CAP, ELECT 100-10V A...................
ELECTRICAL MAIN PARTS LIST - 7
C 633 87-010-263-080 CAP, ELECT 100-10V A...................
C 631 87-010-992-080 C-CAP,S 0.047-25 B A...................
C 641 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 667 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
D 601 87-A40-002-080 ZENER,MTZJ5.1C A...................
D 602 87-A40-438-080 ZENER,MTZJ4.7A A...................
IC 601 87-A20-954-040 C-IC,M62445FP-601 A...................
J 601 87-A60-426-010 JACK,PIN 6P YKC21-3835 A...................
Q 601 87-026-609-080 TR,KTA1266GR A...................
ELECTRICAL MAIN PARTS LIST - 1 (PRO : 8ZA-4)
PART NO. KANRI
NO.
IC
87-A20-715-010 IC,M62439SP
87-A20-853-010 C-IC,M62463FP
87-017-726-080 C-IC,BU4052BCF
87-017-917-080 C-IC,BU4066BCF
TRANSISTOR
87-A30-190-080 TR,CC5551
87-026-609-080 TR,KTA1266GR
87-026-610-080 TR,KTC3198GR
87-A30-108-010 TR,2SB1626
87-A30-109-010 TR,2SD2495
87-A30-214-010 TR,2SB1344
87-A30-215-010 TR,2SD2025
87-A30-075-080 C-TR,2SA1235F
87-A30-076-080 C-TR,2SC3052F
87-A30-107-070 C-TR,CMBT5401
87-A30-106-070 C-TR,CMBT5551
87-A30-086-070 C-TR,CSD1306E
87-A30-087-080 C-FET,2SK2158
87-A30-074-080 C-TR,RT1P 141C
87-A30-104-080 C-TR,RT1N441C
87-026-223-080 C-TR,DTC143TK
DIODE
87-A40-470-080 DIODE,1SS254
87-A40-488-080 DIODE,1SS244
87-070-136-080 ZENER,MTZJ5.1B
87-A40-348-080 ZENER,MTZJ3.3A
87-A40-442-080 ZENER,MTZJ9.1A
87-A40-116-060 DIODE,RS403L-B-D-51
PRO C.B
C101 87-012-368-080 C-CAP,S 0.1-50 Z F
C102 87-012-368-080 C-CAP,S 0.1-50 Z F
C103 87-010-917-090 CAP,E 3300-50 M SMG
C104 87-010-917-090 CAP,E 3300-50 M SMG
C105 87-010-196-080 C-CAP,S 0.1-25 Z F
C106 87-010-196-080 C-CAP,S 0.1-25 Z F
C111 87-010-178-080 C-CAP,S 1000P-50 K B
C207 87-010-402-080 CAP,E 2.2-50 M SME
C208 87-010-402-080 CAP,E 2.2-50 M SME
C209 87-010-183-080 C-CAP,S 2700P-50 K B
C210 87-010-183-080 C-CAP,S 2700P-50 K B
C211 87-010-404-080 CAP,E 4.7-50 M SME
C212 87-010-404-080 CAP,E 4.7-50 M SME
C217 87-010-408-080 CAP,E 47-50 M SME
C218 87-010-408-080 CAP,E 47-50 M SME
C219 87-A10-596-080 C-CAP,S 100P-100 J CH
C220 87-A10-596-080 C-CAP,S 100P-100 J CH
C221 87-A10-899-080 CAP,E 47-25 M BP
C222 87-A10-899-080 CAP,E 47-25 M BP
C223 87-010-544-080 CAP,E 0.1-50 M SME
C224 87-010-544-080 CAP,E 0.1-50 M SME
C225 87-010-993-080 C-CAP,S 0.056-25 K B
C226 87-010-993-080 C-CAP,S 0.056-25 K B
C227 87-010-196-080 C-CAP,S 0.1-25 Z F
C228 87-010-196-080 C-CAP,S 0.1-25 Z F
C233 87-010-263-080 CAP,E 100-10 SME
C234 87-010-263-080 CAP,E 100-10 SME
C307 87-010-402-080 CAP,E 2.2-50 M SME
C309 87-010-183-080 C-CAP, 2700P-50 K B
C311 87-010-404-080 CAP,E 4.7-50 M SME
C317 87-010-406-080 CAP,E 22-50 M SME
C319 87-A10-596-080 C-CAP,S 100P-100 J CH
C321 87-A10-899-080 CAP,E 47-25 M BP
C323 87-010-544-080 CAP,E 0.1-50 M SME
C325 87-010-993-080 C-CAP,S 0.056-25 K B
DESCRIPTIONREF. NO. KANRI
REF. NO. DESCRIPTIONPART NO.
C327 87-010-196-080 C-CAP,S 0.1-25 Z F
C333 87-010-263-080 CAP,E 100-10 SME
C400 87-010-378-080 CAP,E 10-16 M SME
C401 87-010-374-080 CAP,E 47-10 M SME
C402 87-010-196-080 C-CAP,S 0.1-25 Z F
C403 87-010-154-080 C-CAP,S 10P-50 D CH
C404 87-010-374-080 CAP,E 47-10 M SME
C405 87-010-196-080 C-CAP,S 0.1-25 Z F
C407 87-010-154-080 C-CAP,S 10P-50 D CH
C408 87-010-545-080 CAP,E 0.22-50 M SME
C410 87-010-546-080 CAP,E 0.33-50 SME
C413 87-010-196-080 C-CAP,S 0.1-25 Z F
C415 87-010-400-080 CAP,E 0.47-50 M SME
C416 87-010-400-080 CAP,E 0.47-50 M SME
C418 87-010-401-080 CAP,E 1-50 M SME
C419 87-010-260-080 CAP,E 47-25 SME
C421 87-010-378-080 CAP,E 10-16 M SME
C422 87-010-378-080 CAP,E 10-16 M SME
C501 87-010-176-080 C-CAP,S 680P-50 J SL
C502 87-010-176-080 C-CAP,S 680P-50 J SL
C503 87-A10-804-080 C-CAP,S 0.1-25 J B
C504 87-A10-804-080 C-CAP,S 0.1-25 J B
C505 87-A10-804-080 C-CAP,S 0.1-25 J B
C506 87-A10-804-080 C-CAP,S 0.1-25 J B
C509 87-010-112-080 CAP,E 100-16 M SME
C510 87-010-221-080 CAP,E 470-10 M SME
C511 87-A10-891-080 CAP,E 4.7-25 SME(K)
C512 87-A10-800-080 C-CAP,S 6800P-16 J B
C513 87-010-374-080 CAP,E 47-10 M SME
C514 87-010-196-080 C-CAP,S 0.1-25 Z F
C515 87-010-401-080 CAP,E 1-50 M SME
C516 87-010-401-080 CAP,E 1-50 M SME
C518 87-010-546-080 CAP,E 0.33-50 SME
C519 87-010-400-080 CAP,E 0.47-50 M SME
C520 87-010-546-080 CAP,E 0.33-50 SME
C521 87-010-546-080 CAP,E 0.33-50 SME
C522 87-018-209-080 CAP,TC U 0.1-50 Z F
C524 87-010-374-080 CAP,E 47-10 M SME
C526 87-010-196-080 C-CAP,S 0.1-25 Z F
C530 87-010-544-080 CAP,E 0.1-50 M SME
C531 87-010-546-080 CAP,E 0.33-50 SME
C532 87-010-971-080 C-CAP,S 4700P-50 J B
C533 87-012-349-080 C-CAP,S 1000P-50 J CH
C538 87-010-971-080 C-CAP,S 4700P-50 J B
C539 87-012-349-080 C-CAP,S 1000P-50 J CH
C540 87-010-401-080 CAP,E 1-50 M SME
C541 87-010-401-080 CAP,E 1-50 M SME
C542 87-A10-799-080 C-CAP,S 5600P-16 J B
C543 87-A10-802-080 C-CAP,S 0.047-16 J B
C544 87-A10-229-080 C-CAP,S 0.68-10 K
C545 87-012-393-080 C-CAP,S 0.22-16 K
C546 87-012-393-080 C-CAP,S 0.22-16 K
C547 87-010-404-080 CAP,E 4.7-50 M SME
C548 87-010-404-080 CAP,E 4.7-50 M SME
C549 87-012-393-080 C-CAP,S 0.22-16 K
C550 87-012-393-080 C-CAP,S 0.22-16 K
C551 87-016-081-080 C-CAP,S 0.1-16 K R
C552 87-A10-802-080 C-CAP,S 0.047-16 J B
C553 87-A10-802-080 C-CAP,S 0.047-16 J B
C554 87-016-081-080 C-CAP,S 0.1-16 K R
C555 87-016-081-080 C-CAP,S 0.1-16 K R
C556 87-A10-801-080 C-CAP,S 0.022-16 J B
C557 87-A10-801-080 C-CAP,S 0.022-16 J B
C558 87-016-081-080 C-CAP,S 0.1-16 K R
C579 87-010-402-080 CAP,E 2.2-50 M SME
C580 87-010-402-080 CAP,E 2.2-50 M SME
C601 87-010-196-080 C-CAP,S 0.1-25 Z F
C602 87-010-196-080 C-CAP,S 0.1-25 Z F
C603 87-010-196-080 C-CAP,S 0.1-25 Z F
C604 87-010-196-080 C-CAP,S 0.1-25 Z F
J201 87-A60-561-010 JACK,PIN 4P W/R,B/O
J601 87-A60-562-010 JACK,PIN 6P W/R
NO.
ELECTRICAL MAIN PARTS LIST - 2 (PRO : 8ZA-4)
PART NO. KANRI
NO.
L201 87-003-383-010 COIL,1UH K
L202 87-003-383-010 COIL,1UH K
L301 87-003-383-010 COIL,1UH K
R243 87-A00-258-080 RES,M/F 0.22-1W J
R244 87-A00-258-080 RES,M/F 0.22-1W J
DESCRIPTIONREF. NO. KANRI
REF. NO. DESCRIPTIONPART NO.
R245 87-A00-258-080 RES,M/F 0.22-1W J
R246 87-A00-258-080 RES,M/F 0.22-1W J
R343 87-A00-258-080 RES,M/F 0.22-1W J
R345 87-A00-258-080 RES,M/F 0.22-1W J
R509 87-022-214-080 C-RES,S 100K-1/10W F
NO.
MECHANICAL PARTS LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
USTM ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
82-NE6-067-010 BADGE,AIWA 30N A...................
86-NF6-101-010 WINDOW TOP UL A...................
87-NB8-051-010 PANEL,LEFT U A...................
87-NBG-006-010 PANEL,CD A...................
87-NBG-008-010 WINDOW,CD A...................
87-NBG-009-010 WINDOW,CASS 1 A...................
87-NBG-010-010 WINDOW,CASS 2 A...................
87-NF6-021-010 PANEL,TOP A...................
88-NF7-003-010 BOX,CASS 1 U A...................
88-NF7-004-010 BOX,CASS 2 U A...................
88-NF7-005-010 PANEL,TRAY A...................
88-NF7-007-010 PANEL,JOG A...................
88-NF7-051-010 PANEL,CONT PRO1 A...................
88-NF8-048-010 PANEL,RIGHT 2 U A...................
88-NFU-002-010 WINDOW,DISP PRO A...................
88-NFU-008-010 CABI,FR U A...................
88-NFU-010-010 CABI,REAR USTNM A...................
88-NFU-014-010 CABI,REAR UST ....................
87-NBG-011-010 KNOB,RTRY VOL A...................
87-NBG-015-010 KEY,POWER A...................
87-NBG-019-010 KEY,ECHO A...................
87-NBG-023-010 REFLECTOR,FUN A...................
88-NF7-006-310 KNOB,RTRY JOG A...................
88-NF7-008-010 KEY,BBE A...................
88-NF7-009-110 KEY,ASSY OPE A...................
88-NF7-012-010 REFLECTOR,OPE A...................
88-NF7-014-010 KEY,DSP A...................
88-NF7-015-010 REFLECTOR,JOG A...................
88-NF7-019-010 REFLECTOR,DEMO A...................
88-NF7-023-110 KEY,OPE U A...................
88-NF7-025-010 KEY,EDIT U A...................
88-NF7-027-010 KEY,TIMER U A...................
88-NF7-040-110 KEY,DEMO S A...................
88-NF7-052-110 KEY,ASSY DEMO U1 A...................
88-NF7-053-110 KEY,DEMO U1 A...................
88-NF7-062-010 KEY,CD A...................
88-NFU-012-010 KEY,FUN 5.1CH A...................
81-532-080-010 LABEL, CASS. COMPT A...................
86-NF6-061-010 REFLECTOR,CASS A...................
84-ZG1-245-210 CAP,OPTICAL A...................
82-NF5-218-010 SPR-T,EJECT 1 (SIN) A...................
82-NF5-219-010 SPR-T,EJECT 2 (SIN) A...................
82-NF5-229-010 PLATE,LOCK A...................
86-NF9-224-010 SPR-C,LOCK A...................
87-NF4-216-010 HLDR,LOCK 1 A...................
87-NF4-217-010 HLDR,LOCK 2 A...................
87-NF8-220-010 DMPR,150 A...................
87-NFR-203-010 HT-SINK,PRO A...................
87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................
87-067-688-010 BVTT+3-6 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-078-019-010 S-SCREW,IT+4-6 A...................
87-591-094-410 TAPPING SCREW, QIT+3-6 A...................
87-721-096-410 QT2+3-10 GLD A...................
87-721-097-410 QT2+3-12 GLD A...................
87-723-096-410 QT2+3-10W/O SLOT BL A...................
87-B10-091-010 UTT2+3-10 W/O BLK A...................
87-NF4-224-010 S-SCREW,IT3B+3-8 CU A...................
85-NF5-618-010 CABLE,FFC 13P-1.25 A...................
87-085-189-010 BUSHING, CORD (U) A...................
88-906-241-110 FF-CABLE,6P 1.25 A...................
88-911-201-110 FF-CABLE,11P 1.25 A...................
88-918-251-110 FF-CABLE, 18P 1.25 250MM A...................
C 206 87-010-402-010 CAP,ELECT 2.2-50SME A...................
C 205 87-010-402-010 CAP,ELECT 2.2-50SME A...................
F 101 87-035-490-010 FUSE,5A125V D UL A...................
PT 101 88-NFU-661-010 PT,8NF-U U A...................
W 101 87-050-053-010 AC CORD ASSY,U-2 A...................
W 101 87-050-079-010 AC-CORD ASSY,E A...................
88-NF7-201-010 GUIDE,OPE A...................
W 104 85-NF5-628-010 F-CABLE 7P-2.5 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
TAPE MECHANISM PART LIST - 1
PART NO. KANRI
NO.
1 86-ZM3-215-010 CHAS ASSY,RS
2 86-ZM3-202-010 BASE,HEAD S
3 86-ZM3-205-010 SPR-C,RPH S
4 82-ZM1-333-210 PLATE,LINK 2
5 86-ZM3-206-010 SPR-C,EH S
6 87-A90-403-019 HEAD,RPH MS15R
7 86-ZM3-201-010 CHAS,HEAD S(DECK L)
7 82-ZM3-206-910 CHAS,HEAD(DECK R)
8 87-045-347-019 MOT,SHU2L 70(M1)
9 82-ZM1-269-219 SPR-T,BRG
10 82-ZM1-219-110 SPR-T,LINK
11 86-ZM3-209-010 S-SCREW,ASIMUTHS
12 86-ZM3-207-010 S-SCREW,RPH
13 87-A90-404-019 HEAD,EH LE15B
14 86-ZM3-208-010 S-SCREW,EH
15 86-ZM3-203-010 HLDR,MOTS
16 82-ZM1-245-210 HLDR,IC
17 82-ZM1-218-019 SPR-E,HB
18 86-ZM3-214-010 BELT,SUB RR
19 82-ZM1-222-219 LVR,PLAY
20 82-ZM1-217-419 REEL TABLE
21 82-ZM1-244-519 SPR-C,BT
22 82-ZM1-285-410 SPR-C,BT L
23 82-ZM1-257-019 SPR-T,CAS
24 82-ZM3-221-010 PULLEY,MOT 2M
25 82-ZM1-242-019 LVR,CAS
26 82-ZM1-243-019 LVR,STOP
27 82-ZM1-344-119 LVR ASSY,PINCH
28 86-ZM3-204-010 SPR-T,PINCHDS
29 82-ZM1-240-119 LVR,REC (DECK 2)
30 86-ZM3-210-010 BELT,RS
32 82-ZM3-305-119 GEAR,CAM M2
33 82-ZM1-227-319 LVR,TRIG
34 82-ZM3-306-110 LVR,FR M2
35 82-ZM1-265-119 SPR-E,TRIG
36 87-761-073-419 VFT2+2.6-6 W/O SLOT
37 82-ZM1-239-019 CAPSTAN N 2.2-41.7
38 82-ZM1-322-019 SPR-T,FR60
39 82-ZM1-220-219 GEAR,IDLER
40 82-ZM3-616-019 RING MAGNET 4
DESCRIPTIONREF. NO. KANRI
REF. NO. DESCRIPTIONPART NO.
NO.
41 82-ZM1-216-319 GEAR,REEL
42 86-ZM3-213-010 S-SCREW,HLDR,MOT 3
43 82-ZM1-225-219 GEAR,FR
44 82-ZM1-226-019 GEAR,REW
45 82-ZM3-333-310 SLIP DISK ASSY 2
46 82-ZM1-338-010 BELT FR4
47 82-ZM1-349-019 FLY-WHL RW (DECK L)
47 82-ZM3-338-010 FLY-WHL R3W (DECK R)
48 82-ZM1-259-210 SPR-T,PINCH R
49 82-ZM1-341-110 LVR ASSY,PINCH L2
50 82-ZM1-258-210 SPR-T,PINCH L
51 82-ZM1-314-110 PLATE,HEAD
52 82-ZM1-208-310 HLDR,HEAD
53 87-A90-366-010 HEAD,PH YK50P-BF414
54 82-ZM1-207-810 GUIDE TAPE
55 82-ZM1-213-010 SPR-T,HEAD
56 82-ZM1-210-110 GEAR,HT
57 86-ZM4-206-010 S-SCREW AZIMUTH L
58 82-ZM1-348-010 FLY-WHL,LW
59 82-ZM1-236-019 CAPSTAN N 2-41.5
60 82-ZM3-335-210 PULLEY,COUPLER M3
61 86-ZM1-206-010 BELT,MAIN L
62 82-ZM1-266-110 LVR,DIR
63 82-ZM1-214-010 SPR-T,DIR
64 82-ZM1-255-310 SPR-E,LVR DIR
65 82-ZM3-339-010 SHAFT,COUPLER N3
A 87-251-071-417 U+2.6-4
B 80-ZM6-243-019 SH,1.75-3.6-0.5 SLT
C 82-ZM3-334-010 PW,2.16-6-0.4
D 80-ZM6-207-010 V+1.6-7
E 85-ZM3-202-010 S-SCREW TG
F 82-ZM1-288-010 SH,1.63-3.2-0.5 SLT
G 87-B10-043-010 W-P,0.99-4-0.25 SLT
H 87-571-032-410 VIT+2-3
ACCESSORIES / PACKAGE LIST - 1
NOTE: The characters in the suffix column indicate the part usage.
USTM ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
88-NFU-903-010 IB,U(ESF)M A...................
88-NFU-913-010 IB,U(ESF)I ....................
87-006-225-010 AM LOOP ANT NC2 A...................
87-043-115-010 ANT,FEEDER FM A...................
87-NFR-610-010 RC UNIT,RC-7AS09 A...................
SCHEMATIC DIAGRAM _ 1 (MAIN)
SCHEMATIC DIAGRAM _ 2 (TUNER)
SCHEMATIC DIAGRAM _ 3 (FRONT)
SCHEMATIC DIAGRAM _ 4 (PRO)
SCHEMATIC DIAGRAM _ 5 (PT)
4
9301978,750038
Tokyo Japan
Printed in Singapore
Loading...
