Important Safety Instructions
1. Please do not place device near any form of heat sources.
2. Please use the accessories specified by the manufacturer.
3. Please refer all servicing/repairs to a qualified personnel should there by
any form of damage to the device.
4. Keep this user manual for future referencing/ troubleshooting.
5. Please heed ALL safety cautions.
Unboxing
- MI-X 175 Retro Heritage Lite
- Type-C Charging Cable
- 3.5mm AUX Cable
- Handle
- User Manual
Please refrain from using any damaged components. Contact your local
authorized AIWA distributor/customer service should you need any assistance.
Product Overview
Connecting the Product
ON/OFF ON/OFF
Paired device
Pairable devices
AIWA Retro Heritage
Lite
Paired device
Pairable devices
AIWA Retro Heritage
Lite
TWS Function
Synced audio playback from two (2) speakers for true wireless stereo
experience. (Only compatible with the same speaker model: MI-X175 Retro
Heritage Lite)
1. Turn on both speakers.
2. Press and hold on BOTH speakers until a notification prompt beep is
heard.
3. TWS (True Wireless Stereo) playback is now available.
4. Connect to ONE (1) of the speakers via BT Connection.
5. Long press to exit TWS mode.
MI-X175 Retro Heritage Lite
User Manual
Aiwa Electronics Int'l Co., Ltd.
Explore more at www.int-aiwa.com
Safety Cautions
1. Always keep device AWAY from fire and heat sources.
2. Do NOT attempt to disassemble or alter the device.
3. Do NOT expose device to excessive heat (Direct sunlight etc.).
4. Do NOT immerse device into any form of liquids.
Product Specifications
Model Number: MI-X 175 Retro Heritage Lite
BT Version: V5.0
Power Output: 20W X 2
Driver: 3inch *2+2inch *2
Frequency Response: 120Hz~20kHz
S/N Ratio: 60dB
Supported Profiles: WMA, MP3, FLAC, MAV
Transmission Distance (Estimated): 10 Meters (No Obstacles)
DC Input Voltage/Current: DC 5V/ 2A (Type-C)
Battery: 7.4V/4000mAh (Li-on)
Playback Time: 9-11 Hours (50% Volume) ; 3-4 Hours (100% Volume)
Charging Time: 9-10Hours
Dimensions: 252*160*142mm
Weight: 3.1KG
The above playback & charging times are estimated values tested in a practical environment
and may vary upon individual usage habits.
1.
Power ON/OFF
2.
Function LED Indicator Light
3.
Charging LED Indicator Light
4.
Previous Track
5.
Play/Pause (Click once) / Switch Modes (Press and hold) /
Call Control (Click once to Answer & End Call, Press and
hold to Reject Call).
6.
Next Track / Disconnect BT (Press and hold)
7.
Treble Tuning Knob
8.
Bass Tuning Knob
9.
Volume Tuning Knob
10.
USB Port
11.
Charging Port (DC 5V)
12.
AUX-In
13.
Battery display
14.
Phone call
1. Turn on Bluetooth (BT) on your mobile device.
2. Turn on the speaker.
3. Search and connect to “AIWA Retro Heritage Lite” from your mobile
device.
4. Press and hold the “PAIR” button to disconnect BT.
MI-X175 Retro Heritage Lite automatically reconnects to the last paired mobile device it was
connected to.
Listening to music from external audio source
USB Playback
Insert USB Disk into the designated port.
AUX-IN
Connect speaker and Audio source via a 3.5mm AUX Cable.
Press and hold M/ button to switch between different audio sources
Battery & Charging
Connect charging cable to the speaker and a suitable power source.
Approximate Charging Time: 9-10 Hours
Please charge up the speaker fully prior to first-time usage.
MI-X175 Retro Heritage Lite will enter power-saving mode after 15 minutes of inactivity.
Long press "MODE" button for 3 seconds to exit power-saving mode.
Aiwa Electronics Int’l Co., Ltd.
Explore more at www.int-aiwa.com
