CS-P505
AEZ(S),AHS(S),
(W),(P)
SERVICE MANUAL
STEREO RADIO CASSETTE RECODER
Replace this Service Manual with “Revision Publishing” when it is issued.
BASIC TAPE MECHANISM : TN-9ZR-215
S/M Code No. 09-027-458-5T2
SIMPLE
DATA
![](/html/a2/a2e4/a2e4ef91f8b8bf4c1f2a90c0732485fdbb429781d75748b84e947b47ad7006e8/bg2.png)
ACCESSORIES PARTS LIST -1/1
! = ! SAFTY PARTS
C = Components marked
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
O AS1001 8C-CS8-906-01 IB,EZ a . . .
O AS1001 8C-CS8-931-01 IB,AHS . b c d
! O AS1002 S0-206-020-040 PT,230V 6VDC a . . .
! O AS1002 S0-206-020-070 PT,220V 6VDC . b c d
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
-2-
![](/html/a2/a2e4/a2e4ef91f8b8bf4c1f2a90c0732485fdbb429781d75748b84e947b47ad7006e8/bg3.png)
ELECTRICAL PARTS LIST -1/3
! = ! SAFTY PARTS
C = Components marked
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX C 0101 S6-220-520-500 C-CAP,22PF-50V a b c d
MAX C 0102 S6-300-520-500 C-CAP,30PF-50V a b c d
MAX C 0103 S4-220-500-500 CAP,CER 22PF-50V a b c d
MAX C 0104 S0-473-800-500 CAP,CER 0.047UF-50V a b c d
MAO C 0105 S0-001-005-0C0 CAP,E 0.1-50V a b c d
MAO C 0107 S0-040-005-0C0 CAP,E 4.7-50V a b c d
MAX C 0108 S0-103-800-500 (F003-010380-025) CERAMIC CAP a b c d
MAX C 0109 S0-331-100-500 CAP,CER 330PF-50V a b c d
MAX C 0110 S0-473-800-500 CAP,CER 0.047UF-50V a b c d
MAX C 0112 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAX C 0113 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAO C 0114 S0-221-001-0C0 ELECT CAP 220-10V a b c d
MAX C 0115 S5-224-120-100 C-CAP,0.22-10V a b c d
MAX C 0116 S5-224-120-100 C-CAP,0.22-10V a b c d
MAX C 0117 S5-224-120-100 C-CAP,0.22-10V a b c d
MAX C 0118 S6-308-320-500 C-CAP,3PF-50V a b c d
MAX C 0119 S5-105-820-100 C-CAP,1UF-10V a b c d
MAX C 0120 S5-104-820-250 C-CAP,0.1UF-25V a b c d
MAX C 0121 S5-104-820-250 C-CAP,0.1UF-25V a b c d
MAX C 0123 S4-220-500-500 CAP,CER 22PF-50V a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX C 0124 S6-180-520-500 C-CAP,18PF-50V a b c d
MAX C 0127 S6-608-420-500 C-CAP,6PF-50V a . . .
MAX C 0127 S6-408-320-500 C-CAP,4PF-50V . b c d
MAX C 0128 S6-308-320-500 C-CAP,3PF-50V a b c d
MAX C 0130 S0-103-800-500 (F003-010380-025) CERAMIC CAP a b c d
MAX C 0131 S0-103-800-500 (F003-010380-025) CERAMIC CAP a b c d
MAX C 0145 S0-103-800-500 (F003-010380-025) CERAMIC CAP a b c d
MAX C 0201 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
MAX C 0202 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
MAO C 0203 S0-040-005-0C0 CAP,E 4.7-50V a b c d
MAO C 0204 S0-040-005-0C0 CAP,E 4.7-50V a b c d
MAO C 0205 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAX C 0206 S0-223-501-000 CAP,M 0.022UF-100V a b c d
MAO C 0207 S0-040-005-0C0 CAP,E 4.7-50V a b c d
MAO C 0208 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAO C 0209 S0-040-005-0C0 CAP,E 4.7-50V a b c d
MAX C 0210 S0-223-501-000 CAP,M 0.022UF-100V a b c d
MAO C 0211 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAX C 0212 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
MAX C 0213 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX C 0214 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
MAX C 0215 S0-222-101-000 CAP,M 0.0022UF-100V a b c d
MAX C 0216 S5-221-120-500 C-CAP,220PF-50V a b c d
MAX C 0217 S5-221-120-500 C-CAP,220PF-50V a b c d
MAO C 0223 S0-221-001-0C0 ELECT CAP 220-10V a b c d
MAX C 0226 S5-103-120-500 C-CAP,0.01-50V a b c d
MAX C 0227 S5-103-120-500 C-CAP,0.01-50V a b c d
MAO C 0228 S0-004-005-0C0 CAP,E 0.47-50V a b c d
MAO C 0229 S0-004-005-0C0 CAP,E 0.47-50V a b c d
MAO C 0230 S0-471-001-0C0 ELECT CAP 470-10V a b c d
MAO C 0231 S0-100-005-0C0 ELECT CAP 10-50V a b c d
MAX C 0233 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAX C 0234 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAO C 0235 S0-001-005-0C0 CAP,E 0.1-50V a b c d
MAX C 0253 S5-221-120-500 C-CAP,220PF-50V a b c d
MAX C 0254 S5-221-120-500 C-CAP,220PF-50V a b c d
MAO C 0306 S0-004-005-0C0 CAP,E 0.47-50V a b c d
MAO C 0307 S0-004-005-0C0 CAP,E 0.47-50V a b c d
MAX C 0313 S5-562-120-500 C-CAP,0.0056UF-50V a b c d
MAX C 0314 S5-562-120-500 C-CAP,0.0056UF-50V a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX C 0315 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAX C 0316 S5-473-820-250 C-CAP,0.047UF-2 a b c d
MAO C 0317 S0-010-005-0C0 CAP,E 1-50V a b c d
MAO C 0318 S0-010-005-0C0 CAP,E 1-50V a b c d
MAX C 0319 S5-102-120-500 C-CAP,0.001UF-50V a b c d
MAX C 0320 S5-102-120-500 C-CAP,0.001UF-50V a b c d
MAO C 0321 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAO C 0322 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAX C 0323 S5-104-820-250 C-CAP,0.1UF-25V a b c d
MAO C 0324 S0-331-001-0C0 CAP,E 330-10V a b c d
MAX C 0325 88-WA2-697-08 CAP,0.1UF-50V a b c d
MAX C 0326 88-WA2-697-08 CAP,0.1UF-50V a b c d
MAO C 0327 S0-221-001-0C0 ELECT CAP 220-10V a b c d
MAO C 0328 S0-221-001-0C0 ELECT CAP 220-10V a b c d
MAO C 0332 S0-101-001-0C0 ELECT CAP 100-10V a b c d
MAO C 0334 S0-221-001-0C0 ELECT CAP 220-10V a b c d
MAO C 0335 S0-222-001-0C0 CAP,E 2200-10V a b c d
MAX C 0336 88-WA2-697-08 CAP,0.1UF-50V a b c d
MAO C 0349 S0-470-001-6C0 CAP,E 47-16V a b c d
MAO C 0350 S0-221-001-0C0 ELECT CAP 220-10V a b c d
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
-3-
![](/html/a2/a2e4/a2e4ef91f8b8bf4c1f2a90c0732485fdbb429781d75748b84e947b47ad7006e8/bg4.png)
ELECTRICAL PARTS LIST -2/3
! = ! SAFTY PARTS
C = Components marked
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAO CF 0101 S0-004-550-110 CERAMIC FILTER,CFSFU455B a b c d
MAO CF 0102 87-A90-988-01 C.FILTER KMFC5153T6-Z a b c d
MAO CF 0103 87-A90-988-01 C.FILTER KMFC5153T6-Z a b c d
MAO D 0101 S0-041-480-000 DIODE,IN4148 a b c d
MAO D 0102 S0-041-480-000 DIODE,IN4148 a b c d
MAO D 0201 87-020-465-08 DIODE,1SS133 a b c d
MAO D 0202 87-020-465-08 DIODE,1SS133 a b c d
MAO D 0203 S0-041-480-000 DIODE,IN4148 a b c d
MAO D 0204 S0-041-480-000 DIODE,IN4148 a b c d
MAO D 0301 S0-300-100-030 LED,SE3001 RED a b c d
MAO D 0303 S0-240-010-000 DI,1N4001B a b c d
MAO DZ 0104 S0-100-300-000 ZENER,MTZJ3.0A a b c d
MAO IC 0101 S8-321-110-010 IC TA2111N (TOSHIBA) a b c d
MAO IC 0201 S5-073-100-000 IC,AN7310 a b c d
MAO IC 0301 S3-022-090-010 IC,KA2209B a b c d
MAO IC 0302 S3-024-020-000 IC,KA2402 a b c d
MAO JK 0001 87-A60-420-01 JACK,HP ST 3.5MM a b c d
MAO JK 0002 S1-065-010-000 JACK,DC a b c d
MAX L 0101 S0-900-300-040 COIL,FM 9T 3-0.4 a b c d
MAO L 0102 S0-400-500-080 FM COIL 4T,5mm,DIA:0.8mm (CS5 a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX L 0103 87-HRL-605-019 COIL,FM 6-2.9-0.4 a b c d
MAO L 0104 8Z-HJ9-608-01 COIL,FM 6T a b c d
MAO LD 0101 S0-011-310-050 LED,L113SGDT 2-5 GREEN a b c d
MAO Q 0201 S3-045-800-030 TR,2SC458C a b c d
MAS Q 0301 S8-080-500-030 TR,SS8050C a b c d
MAX R 0101 S3-102-520-160 C-RES,1K-1/16 a b c d
MAX R 0102 S0-470-510-160 RES,47-1/16W a b c d
MAX R 0103 S0-100-510-160 RES,10-1/16W (1/ a b c d
MAX R 0104 S3-150-520-160 C-RES,15-1/16W a b c d
MAX R 0105 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0106 S3-562-520-160 C-RES,5.6K-1/16W a b c d
MAX R 0107 S3-562-520-160 C-RES,5.6K-1/16W a b c d
MAX R 0108 S3-822-520-160 C-RES,8.2K-1/16W a b c d
MAX R 0109 S3-822-520-160 C-RES,8.2K-1/16W a b c d
MAX R 0113 S3-182-520-160 C-RES,1.8K-1/16W . b c d
MAX R 0113 S3-331-520-160 C-RES,330-1/16W a . . .
MAX R 0118 S3-331-520-160 C-RES,330-1/16W a b c d
MAX R 0120 S3-331-520-160 C-RES,330-1/16W a b c d
MAX R 0200 S3-560-520-160 C-RES,56-1/16W a b c d
MAX R 0201 S3-273-520-160 C-RES,27K-1/16W a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX R 0202 S3-563-520-160 C-RES,56K-1/16W a b c d
MAX R 0203 S3-472-520-160 C-RES,4.7K-1/16W a b c d
MAX R 0204 S3-102-520-160 C-RES,1K-1/16 a b c d
MAX R 0205 S3-563-520-160 C-RES,56K-1/16W a b c d
MAX R 0206 S3-472-520-160 C-RES,4.7K-1/16W a b c d
MAX R 0207 S3-560-520-160 C-RES,56-1/16W a b c d
MAX R 0208 S3-273-520-160 C-RES,27K-1/16W a b c d
MAX R 0209 S3-102-520-160 C-RES,1K-1/16 a b c d
MAX R 0210 S3-682-520-160 C-RES,6.8K-1/16W a b c d
MAX R 0212 S3-682-520-160 C-RES,6.8K-1/16W a b c d
MAX R 0213 S3-102-520-160 C-RES,1K-1/16 a b c d
MAX R 0214 S3-222-520-160 C-RES,2.2K-1/16W a b c d
MAX R 0215 S3-222-520-160 C-RES,2.2K-1/16W a b c d
MAX R 0221 S3-103-520-160 C-RES,10K-1/1 a b c d
MAX R 0222 S3-472-520-160 C-RES,4.7K-1/16W a b c d
MAX R 0223 S3-472-520-160 C-RES,4.7K-1/16W a b c d
MAX R 0224 S3-563-520-160 C-RES,56K-1/16W a b c d
MAX R 0225 S3-563-520-160 C-RES,56K-1/16W a b c d
MAX R 0226 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0227 S3-332-520-160 C-RES,3.3K-1/16W a b c d
CS-P505 CS-P505 CS-P505 CS-P505
AEZSC AHSSC AHSWC AHSPC
MAX R 0228 S3-564-520-160 C-RES,560K-1/16W a b c d
MAX R 0229 S3-564-520-160 C-RES,560K-1/16W a b c d
MAX R 0230 S3-272-520-160 C-RES,2.7K-1/16W a b c d
MAX R 0231 S3-272-520-160 C-RES,2.7K-1/16W a b c d
MAX R 0235 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0236 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0237 S3-471-520-160 C-RES,470-1/16W a b c d
MAX R 0238 S3-392-520-160 C-RES,3.9K-1/16W a b c d
MAX R 0239 S3-224-520-160 C-RES,220K-1/16W a b c d
MAX R 0251 S3-273-520-160 C-RES,27K-1/16W a b c d
MAX R 0252 S3-273-520-160 C-RES,27K-1/16W a b c d
MAX R 0301 S3-680-520-160 C-RES,68-1/16 a b c d
MAX R 0302 S3-221-520-160 C-RES,220-1/16W a b c d
MAX R 0307 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0308 S3-332-520-160 C-RES,3.3K-1/16W a b c d
MAX R 0311 S3-682-520-160 C-RES,6.8K-1/16W a b c d
MAX R 0312 S3-682-520-160 C-RES,6.8K-1/16W a b c d
MAX R 0315 S3-103-520-160 C-RES,10K-1/1 a b c d
MAX R 0316 S3-103-520-160 C-RES,10K-1/1 a b c d
MAX R 0317 S3-478-520-160 C-RES,4.7-1/16W a b c d
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
