User’s Manual
Land Mobile Radio (LMR)
Model: AT-100 A/B
AT-200
AT -400 A/B
Airtech Information & Communication Co., Ltd.
GENERAL FEATURES .................................................2
UNPACKING..................................................................3
OPTIONAL ACCESSORIES .........................................3
GETTING READY..........................................................3
DESCRIPTION...............................................................4
LCD P ANEL...................................................................5
OPERATION..................................................................6
ADDITIONAL FUNCTION.............................................7
CHARGER AND BATTERY..........................................8
SPECIFICATIONS .........................................................8
General Features
1. Ultra compact desig n & size
(102 x 50 x 36mm, 310g with high capable batt er y )
2. Heavy durable constr uction
3. 90 channels
4. Alphanumeric LCD disp lay up to 6 characters
5. 38 CT CSS/ 8 3 CDCSS
6. PC Programmable, t r ansferable by cloni ng
7. Time-out timer (TOT)
8. Busy channel lock-out (BCLO)
9. Battery saving mode
10. Low battery alert
11. 2/5 tones programmable
12. 12.5K Hz/25KHz channel spaci ng program mab le
13. DTMF PTT-ID
14. Button lockable
15. Talking range to 5 miles
16. Transmit o utput power High/Low
17. DC7.5V Ni-MH battery
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LTD.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6B
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6C
Unpacking
Unpack and check that all items have been enclosed.
Packing contents: radioantennabattery pack (1,350
mAH) belt c lip hand st r ap charger user’s manual
Optiona l Accessor ies
1. External earphone & MIC. ( APE–10)
2. Additional batt er y pack ( 720 mAH, HM–720)
Getting Ready
1. I nst a lla tion, Removal Belt Clip
Installation
the plastic slots of t he batter y pac k.
Slide the belt clip onto the battery
pack, pushing firmly until a click
heard.
Removal
release tab w ith a fingernail or a
coin (or like instrument). While
holding up the release tab, slide the belt clip out and
away from the battery pack.
2. Installation, Removal Battery Pack
Installation
with the back of the unit facing up.
Place the battery pack against the
back of t he transceiver so that the
tabs on the transceiver engage t he
four openi ngs in the battery pack.
Slide the battery pack toward the
top of the transceiver until a click
heard.
Removal
Hold the radio with the back of the unit facing up. With
the thumbnail of your other hand slide the latch lever
down. While holding the latch lever down, slide t he
battery pack down toward the bottom of the transceiver.
Separate t he batter y pac k from the transceiver.
: align the belt clip with
: hold up the belt c lip
: turn off the transceiver. Hold the transceiver
: turn off the transceiver.
3. Installation Antenna
Rotate the antenna clockwise until
it is s e a ted f ir mly.
*. Before y our starting operation, make
sure the battery is fully charged.
Description
volume control switch clockwise and control the volume.
Channel Select Butto n
Select the desired channel with pressing Up and Down
button, pressing and holding down more than 1 second
makes t he channel moving fast. And you ca n c hoose On
or Off in func t io n mode.
PTT(Push To Talk) Button
Hold down to transmit, release to receive.
Function Button
Refer to “OPERATION” page 7.
Monitor Button
Press to monitor. Holding down over 2 seconds keeps
monitoring function on, and press shortly again or PTT
Button to stop.
LCD Display Panel
Refer to next page.
Tx / Rx Indicate LED (3 colors)
Red
Green
Orange On
Microphone
Talk 5~7Cm in distance d uring trans mitting.
Speaker
Ext ernal Earp hone/MIC and Programmi ng Jack Socket
Battery Pack
Helical Ante nna
On Transmitting
Blinking Low battery
On Receiving, mo nitoring
Blinking Different sub-tone when receiving
Initializing, programming and
cloning
Power on / off and Volume Control Swit ch
Turn the transceiver on by rotating power on / off and
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6D
LCD Panel
DISPLA Y FUNCTION
T
Sub-tone
Abnormal
Abnormal
Program
SCN
H L
!
Scanning
Transmitt output pow er
Beep sound
Button lock
Cha nnel
On
Off
PTT-ID
Clone
Cl oni ng f inished
Cloning processing (moves
rightward)
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6E
Operati on
1. Power Turn on / off and Volume Control
Rotate the Power on/off and Volume Control Switch
clockwise to t urn power on, then the LED lights orange
and power–up tone is generated aft er about on second,
indicating the transceiv er has passed the self–diagnostic.
When you turn on the transceiver, it comes same
channel and function with your last using. Rotate this
switch clockwise to increase the volume or
counterclockwise to reduce the volume. Rotate it
counterclockwise fully to tur n power off.
2. Transmit
Choose the channel by pressi ng Channel Select Button
as you desire. Hold down the PTT Button and talk to
MIC in 5~7Cm distance. The LED lights red on
transmitting. Release the PTT button to stop
transmitting.
3. Receive
Choose the channel by pressi ng Channel Select Button
as you desire. The LED lights green on receiving. In
case the signal doesn’t match in using sub–tone, green
light b links.
4. Monitor
Press the Monitor Button to monitor. Holding down
Monitor Button over 2 seconds keeps monitoring
function o n, and press Monitor Button shortly or press
PTT Button to stop.
5. Scan
Press Channel Select Button ▲ while holding down
Function Button to start sc anning forw ar d increasing
channels.
In case Priority Scan not settled down
1) me m 1 ch > me m 2 ch > me m 3c h > … ..
In case 1 cannel of Priority Scan is settled down
2) mem 1ch > pri ch > mem 2ch > pri ch > …..
In case 2 cannels of Priority Scan are sett led dow n
3) mem 1ch > pri 1ch > pri 2ch > mem 2ch > …. .
The transceiver stops scanning after det ec t ing a signal
and returns a receiving mode in the channel if the signal
keeps for 2 seconds. Or re-start scanning automatically.
And if detecting a signal while scanni ng, but in case of no
matching sub-tone, r e- starting s canning with a delayed
Pres s Channel Select B utton▲ to skip the cha nnel. And
if yo u pr e s s Ch annel Se le c t Button▼ when the
transceiver is recei ving a signal in a channel while
scanning, the transce i ver doesn’t sc an the same channel
in the next. And if you wa nt to return the normal mode,
press Channel Select Button ▲ w hile holding dow n
Function Button to finish scanning.
When you press PTT Button while scanning, the
transceiver transmits in the channe l which received a
signal last w hile scanning or LCD s how s when it’s
turned on.
6. Dual Watch
The t ranscei ver detects the channel LCD shows as well
as another channel set as a dual watch channel upon
“DW” mode.
7. Preference of Scan, Priority Scan & Dual Watch
Turn on holding down Channel Select Button▼. Then,
the LCD shows “SL-001”. And you can settle dow n which
channel can be scanned or not by pressing Function
Button in each channel while moving the channels
upward or downward with the Channel Select
Button▲▼. And press the PTT button to finish. T hen
the LCD shows “P1-000”. Then, you choose a channel
with the Channel Select Button▲▼. Then press the
PTT button to finish. As well, “P2-000” by the above
same way. If you choose “000”, it doesn’t work.
The LCD will show “DW000” once registered “Priority
Scan”. Then, also yo u can register a Dual Watch c hannel
in same way as one of “Priority Scan”.
8. Beep Sound on / off
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6F
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6G
When you press Func tion Button once sign on LCD
blinks. ( in case of being selected button lock f unct ion on
blinks) Press Channel Select Button to select t he beep
sound on or off. Press PTT Button to finish selection.
9. Button Lock on / off
When you press Functio n Button twice, s ign on LC D
blinks. Press Channel Select Button to select the button
lock on or off. Press PTT Button to finish selection. T his
function prevents from changing the channel by
unintended pressing of Channel Select Button. Press
Function Button once, sign on LCD blinks. Select off
with Channel Select Button, then press PTT Button to
set off.
10. DTMF PTT–ID on / off
When yo u press Function Button three times, “dt” sign
on LCD blinks. Press Channel Select B utt on to select
DTMF PTT–ID on or off. Press PTT Button to finish.
11. Transmit Output Power H / L
While holdi ng down PTT B ut ton, pre ss Channe l Select
Button▲ to set high power (it shows ‘H’ on LCD) or
press Channel Select Button▼ to set low power (it
shows ‘L ’ on LCD.
12. 2/5 Tone Decode (Selcal l)
During initial radio program mi ng by the technicia n this
radio can be configured for several diff er ent types of
decode operation. If a channel is selected that has
Selcall act ivated the radio will be m ute d until the prop e r
signal is received. W hen this occurs the radio can sound
a ringing type alert s ignal or a voice message maybe
heard. Dependi ng upon the initial progr amming, pressing
the PTT may cause a n automatic identifier to be sent.
When programmed for Selcal l press i ng the monitor and
function b uttons at the same time can cause t he Selcall
mode to be cancelled and generate an automatic
identificatio n. Please have yo ur radio tec hnicia n or
dispatcher f ully explain t his operatio n.
Additional Function
1. Ti m e–Out Ti m er (T OT )
I t li mits t he am o u nt o f t im e y ou c a n c o nt i n uo usl y t r a ns m it o n
a channel from 0~100 seconds by a progr ammer. There will
be a short pre–alert war ning tone 4 seconds pr ior t o the end
of the transmission. Then the trans mission is terminated and
there will be a c onsta nt alert tone unti l you re lease the PTT
Button.
2. Busy C hannel Lock–Out (BCLO)
It prevents from transmitti ng if any activity is detected on the
channel. Program mer can do this feat ure.
3. Power Saving Mode
If there is no transmitting and receiving for several time, the
transceiver takes the power saving mode automatically for
saving power.
4. Low Batt er y Alert
The LED will blink red whenever pressed the PTT B utton if
the transceiver falls below a low voltage level. As well,
whenever you release the PTT Button on low voltage level,
there will be alert tone twice. Finally there will be alert tone
three times and “OFF” sign on LCD then the operation is
terminated.
5. Cloning
You can clone from the transceiver to another. Connect the
transceivers with the cloning cable. While pressing both of
two Channel Select Button▲▼, turn the power on the
transceiver which wa nt to be cloned (LCD shows ‘prog’ and
indicate LED lights orange). While pressing the Monitor
Button, turn the power on the original transceiver (LCD
shows ‘clon’ and indicate LED lights orange). Press the
Monitor Button of the original transceiver again to start
cloning (LCD shows ‘–‘moving right side). After 15 seconds
approximately, the cloning finishes (the origi nal transcei ver ’s
LCD show ‘good’). Turn both transceivers power off and
disconnect the cloni ng cable.
AIRTECH INF OR MATION & COMM UN ICATI ON CO. , LT D.
FCC ID: ONKAT-100B
JOB #: 606BK0
EXHIBIT #: 6H
Charger and Batt ery
1. Battery (Ni-MH)
Voltage DC 7.5V
HM-1350 Over 8 hrsDuty time
(5-5-90)
2. Charger
Input power Free voltage (AC90~250V)
Charging time HM-1350 Appr. 100min
Operat ing temperature 0ºC~55ºC
Connect the charger to electric power supply (free voltage
AC 90~250 V). Turn the transceiver power off and put into
front socket of the charger. The red light turns on during
charging and the green light turns on when finished. When
you put two batteries together, the front one charges first
then the rear one starts charging.
* When you put the battery on rear cup of the charger for
charging, the charger
checks voltage. If voltage
is under 7.4V, the charger
starts discharging for 4
minutes then checks
again. If voltage is still less
than 7V, it discharges unti l
voltage is 6V then starts
charging.
Specifications
HM-720 Over 4 hrs
HM-720 Appr. 60min
Green On Fully
Orange
On ChargingRed
Blinking Abnormal
battery
charged
On Stand-by
for
charging
(rear cup)
Blinking Dischargi
ng
Operating Voltage DC 7.5V
Operating Temp.
Battery Life (H/L)
720mAH Battery
1,350mAH Battery
Channels 90
Privacy Codes 38 CTCSS, 83 CDCSS
Band Width 12.5KHz/25KHz programmable
Frequency Range Tx 136~150
FM Hum & Noise Tx -40 dB
Rx Sensitivity -119 dBm (0.25uV)
Rx Spurious
Response
Rx Selectivity -70 dB -70 dB -70 dB
Rx Intermodulation -65 dB -65 dB -65 dB
Tx Power (H/L) 5W/2W 3W/2W 4.0W/2W
Tx Spurious Rejection
Audio Power (8Ω)
Frequency stability
Standard units consist of
Desk Rapid/Trickle Charger ACR5-130/1.5 hrs
1,350 mAH Ni-MH Battery HM-1350
Helical antenna
-30 ~ 60
(based on 5% Tx: 5% Rx: 90% STBY)
6hrs/8hrs
10hrs/15hrs
(A)
150~174
(B)
Rx Same as the above
Rx -40 dB
-70 dB -70 dB -70 dB
-65 dBc
500mW (Max.)
±
2.5ppm
216 223MHz
±
5ppm
400~430
(A)
440~470
(B)
±
2.5ppm
Dimension
(HxWxD)
Weight (With
Battery)
AT-100 AT-200 AT-400
102x50x32mm (720mAH Battery),
102x50x36mm (1,350mAH Battery)
150g (243g/310g)
Loading...
