Air King CVS-11T User Manual

USER’S GUIDE

CVS-11T Complete Home Turbine Package

IMPORTANT SAFETY INSTRUCTIONS

* READ ALL INSTRUCTIONS before using the turbine nozzle.

When using this appliance, basic precautions should always be followed, including
the following:

WARNING:

1. Unplug and disconnect power before servicing.

2. Always turn off this appliance before connecting or disconnecting either

hose or turbine nozzle.

3. Do not vacuum up anything that is burning or smoking, such as cigarettes, matches,

or hot ashes.

4. Do not pick up flammable or combustible liquids such as gasoline or use it in areas

where they may be present.

5. Use only as described in this manual. Use only manufactures

recommended attachments.

6. Do not handle system or appliances with wet hands.

7. Turn off all controls before unplugging hose from wall inlet.

8. Do not allow to be used as a toy. Pay close attention when used by or

near small children.

9. The hose contains electrical wires. Do not use if damaged, cut, or punctured. Avoid

picking up sharp objects.

10. Do not put any object into openings.

11. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that

may reduce air flow.

12. Keep hair, loose clothing, fingers, and all parts of the body away from openings and

moving parts.

13. Unplug from wall outlet when not in use and before servicing.

14. If appliance is not working as it should, has been dropped, damaged, left outdoors, or

dropped in water, return it to your distributor

15. Use extra care when cleaning on stairs.

Electric shock could occur if used outdoors or on wet surfaces.

SAVE THESE INSTRUCTIONS — INTENDED FOR HOUSEHOLD USE ONLY

2

SAVE THESE INSTRUCTIONS

CVS-11T Complete Home Package

Individual tools may vary and
are subject to change at any time.

1.

3.

5.

PACKAGE INCLUDES:

1. 99473 — 30 f t . Low Vo lt Soft Grip 3 200 Series H o s e w/Friction Stub Tube

2. 34498 — Ch r o me Ratchet Wand

3. 35202 — Pl a s tic Hose Han g e r

4. 34905 — 12 ” Natural Bris t l e Hard Floor B rush.

5. 34828 — Du s t ing Brush

6. 34806 — Cr e v ice Tool

7. 35290 — Up h o lstery Tool / 3 5 312 — Slide- O n

8. 35257 — Si n g le Speed Bab y Turbo

9. 34751 — Wand C l i p-On Tool Cadd y

9.

6.

4.

2.

8.

7.

3

35257 TURBINE

This turbine, with chevron agitator, is ideal for homes with high quality area rugs laid
directly over hard floors where electric brushes can be too aggressive. This turbine must
be used with the ratchet wand.

FEATURES INCLUDE:

Soft non-marring wheels on the
cleaning shoe allow the tool to
traverse a carpet’s transition
area, between the carpet and a
hard surface, comfortably.

1.25” (32mm) double swivel

neck for maximum maneuver­ability while vacuuming.

The only air-turbine with a clean­ing shoe that keeps the brush
parallel to the floor throughout
the sweeping motion means bet­ter results.

Chevron brush pattern imporves cleaning ability by drawing the dirt
to the center of the brush where it is drawn away. A positive timing
belt drive provides reliable performance.

A built-in air relief valve
allows the tool to be adjusted
to better match the vacuum
and floor conditions.

4
