Page 1
Page 2
Set yourself apart with the superior
benefits built into every Air King Central
Vacuum System.
EXTRA VALVE
All Air King central vacuums come with an extra valve instead of a stationary
utility valve found on many competing brands. This allows the freedom to
place the valve where you need it the most.
HEALTH
Though most conventional vacuums are equipped with air filters, these
vacuums exhaust vacuumed air directly in the room being cleaned. This allows fine particles to
pass through the filtering system, which are then blown directly back into the room. With a central vacuum system, all of
the particles that are vacuumed up are expelled out of the room and trapped by the filter or exhausted out of the home.
POWER AND VALUE
An Air King Central Vacuum is up to five times more powerful than conventional uprights or canister vacuums and
will increase the value and salability of your home. Dollar for dollar it is the better choice.
LIFE EXPECTANCY
Air King Central Vacuums have an average life expectancy twice that of uprights or canister vacuums.
QUIET OPERATION
It only makes sense. The power unit is stored in either the basement or a garage away from where you are vacuuming;
therefore, the noise is not in the same room.
VALUE, QUALITY, AND SERVICE
Air King has been manufacturing quality products for over 45 years. We strive every day to exceed our customers’ expectations
for Value, Service and Quality. Our product design team is constantly working to develop new products to meet the changing
needs of today’s consumer while also keeping our existing products the leader’s in the industry. In this way Air King ensures
that our customers are always offered the right product at the right price.
PRODUCTS THAT EXCEED YOUR EXPECTATIONS
Air King engineers each product to meet and exceed the needs of our customers. Throughout our entire line of Central
Vacuums, the same rigorous quality standards are demanded and exceeded every day. From our Power Units to Tool Kits
and more, Air King has the product that meets your installation needs.
THE AIR KING DIFFERENCE
Customer service is a title that everyone in our company shares. From our corporate staff to our nationwide network of manufacturer’s
representatives, we are dedicated to making sure your questions are addressed and answered quickly and accurately.
...more comfortable living for the HOME
www.airkinglimited.com
2
2
Page 3
Model: CVCK8000
Ideal for Installers, Builders, and
Do-It-Yourself Homeowners
The Air King All-In-One Combination Kits include everything needed
for a total system installation. Power unit, attachment set, and
installation kit including the pipe and all the fittings needed for a
typical home!
Model CVCK8000
with Quiet Motor Technology
For homes up to 8,000 sq. ft., the model CVCK8000 has everything
that’s needed including a power unit with Quiet Motor Technology,
HEPA filtration and constructed of plastic that does not rust, dent,
chip or corrode. The kit also includes a deluxe electric power nozzle
attachment kit and a 7 standard inlet installation kit that has
everything needed to complete the installation.
Model CVCK2800
The full sized model CVCK2800 is ideal for homes up to 2,800 sq. ft.
and is complete with everything you need including an attachment
set with an electric power nozzle!
Model: CVCK2800
Model CVCK1535
with Quiet Motor Technology
The model CVCK1535 has a compact power unit with Quiet Motor
Technology ideal for Condo’s, Boats, and RV’s. Powerful enough
for homes up to 1,500 sq. ft. this kit includes a Turbine powered
attachment kit and a 4 standard inlet installation kit!
What’s Included?
Power Unit
Attachment Set
# of Standard Inlets
Capacity
Collection
Filtration
Quiet Motor Technology
Home Size
(Square Feet)
CVCK1535 CVCK2800 CVCK8000
AKCVQZ15 AKCV30 AKCVQP80
Turbine Electric Electric
447
1.5 gallon 5 gallons 9 gallons
Bag Only Bag Only Bag or Bagless
Paper Paper HEPA
Yes No Yes
1,500 2,800 8,000
Model: CVCK1535
www.airkinglimited.com
3
3
Page 4
Keep the cleaning experience quiet with an
Air King Quiet Zone® Central Vacuum Power Unit.
The Air King Central Vacuum Quiet Motor Power Units add life to the system, creating
a powerful cleaning experience with the added advantage of quiet operation. Life
no longer needs to go on hold while vacuuming.
• Durable, smooth platinum finish.
• Quiet Motor Technology
• Included exhaust muffler for extra sound protection
•
Includes an extra utility inlet.
• Four models to choose from:
AKCVQZ99
AKCVQZ80
AKCVQZ35
AKCVQZ15
- for homes up to 10,000 sq. ft.
- for homes up to 8,000 sq. ft.
- for homes up to 3,500 sq. ft.
- for homes up to 1,500 sq. ft
Enjoy the large capacity and worry-free maintenance
of the Plastic Central Vacuum Power Units.
The Air King Central Vacuum Plastic Power Units add life to the system, creating a
powerful cleaning experience with the added advantage of a plastic shell, perfect for
areas with high humidity or near salt water.
• Plastic construction does not rust, dent, chip, or corrode.
• Convertible bag or bagless dirt collection.
•
Includes an extra utility inlet.
• Includes intake receptacle for either right hand or left hand connection.
• Two models to choose from:
Models: AKCVQZ99
AKCVQZ80
AKCVQZ35
AKCVQZ15
AKCVQP80
- for homes up to 8,000 sq. ft.
Models: AKCVQP80
AKCVP35
MODEL SQ. FT. CAPACITY TYPE FILTRATION FINISH CFM LIFT WATTS AMPS
AKCVQZ99 Up to 10,000 7 Gallon Bag/Bagless HEPA Platinum 102 146" 530 14.4
AKCVQZ80 Up to 8,000 5 Gallon Bag/Bagless HEPA Platinum 96 136" 465 13.13
AKCVQZ35 Up to 3,500 5 Gallon Bag/Bagless HEPA Platinum 112 107 404 11.7
AKCVQZ15 Up to 1,500 1.5 Gallon Bag Bag Platinum 112 107" 404 11.7
AKCVQP80 Up to 8,000 9 Gallon Bag/Bagless HEPA Black 96 136" 465 13.13
AKCVP35 Up to 3,500 9 Gallon Bag/Bagless Micro-Tex Blue/Black 112 107 404 11.7
EFFECTIVE DIRT COLLECTION WATER AIR
AKCVP35
- for homes up to 3,500 sq. ft.
Specifications subject to change. without notice
www.airkinglimited.com
4
4
Page 5
Models: AKCV85
AKCV35
Maximize the cleaning experience with an Air King
Central Vacuum Power Unit.
The Air King Central Vacuum Power Units add life to the system creating a powerful
cleaning experience.
• Durable, textured gray finish.
• Open shroud for maximum airflow around the motor, extending the life.
• Micro-Tex
efficiency and is maintenance free.
•
Includes an extra utility inlet.
• Two models to choose from:
®
permanent filter removes allergens down to .1 Micron at 95%
AKCV85
- for homes up to 8,000 sq. ft.
AKCV35
Enjoy the economical and installation advantages of
the Builder’s Central Vacuum Power Unit.
The Air King Central Vacuum Builder’s Power Unit adds life to the system, creating a
powerful cleaning experience. A perfect solution for builders looking for a quality power
unit for use on larger projects.
• Durable, textured gray finish.
• Open shroud for maximum airflow around the motor, extending the life.
•
Includes an extra utility inlet.
• Internal venting - does not vent to the outside.
• 2 year warranty
• Model
AKCV30
- Powerful enough for homes up to 2,800 sq. ft.
- for homes up to 3,000 sq. ft.
Model: AKCV30
MODEL SQ. FT. CAPACITY TYPE FILTRATION FINISH CFM LIFT WATTS AMPS
AKCV85 Up to 8,000 5 Gallon Bag/Bagless Micro-Tex Gray 96 136" 465 13.13
AKCV35 Up to 3,000 5 Gallon Bag/Bagless Micro-Tex Gray 112 107" 404 11.7
AKCV30 Up to 2,800 5 Gallon Bag Bag Gray 106 112" 409 9.7
www.airkinglimited.com
5
5
EFFECTIVE DIRT COLLECTION WATER AIR
Specifications subject to change. without notice
Page 6
Air King’s Electric Tool Kits include a combination
of tools to maximize your cleaning experience.
Models: CVEK3000
CVEK3500
All of the Air King Electric Power Attachment Sets include a 30 foot
crushproof hose, electric power nozzle with aluminum extension
wand, 5 piece attachment set, hose hanger, tool caddy and mesh
carrying bag.
Models CVEK3000, CVEK3500
For homes or offices with extensive areas of wall-to-wall carpeting, the Air King Quiet
®
Electric Tool Kit provides the tools for fast and effective cleaning results. The
Zone
Quiet Zone
®
Electric Tool Kit includes a Quiet Drive Electric Brush with V-Belt technology
that features a headlight for vacuuming under furniture, height adjustments to match
the brush to the floor surface for more effective cleaning, a reset button to prevent motor
burnout in case an object has stopped the brush roll, and a step-on wand release system.
Corded Hose Connection
Models CVEK1000, CVEK1500
For homes with wall-to-wall carpet or carpets laid directly on hard surfaces the Air King Electric Tool
Kit provides the tools for fast and effective cleaning results. The Electric Tool Kit includes a powerful
Electric Brush for more effective cleaning and a step-on wand release system.
Direct Hose Connection
Model CVEK500
For homes with large areas of carpets the Air King Electric Tool Kit
provides the tools for fast and effective cleaning results. The Electric
Tool Kit includes a powerful Electric Brush that features a headlight
for vacuuming under furniture, height adjustments to match the
brush to the floor surface for more effective cleaning and a stepon wand release system.
What’s Included?
30' Electric Hose
Power Nozzle
Telescopic Wands
Friction Fit Wands
Hardwood Brush
Dust Brush
Crevice Tool
Upholstery Tool
Hose Hanger
Clip-On Tool Caddy
Caddy Bag
CVEK3000 CVEK3500 CVEK1000 CVEK1500 CVEK500
Corded Direct Corded Direct Corded
Quiet Drive Quiet Drive Electric Electric Electric
22221
----1
12" 12" 12" 12" 12"
Deluxe Deluxe Standard Standard Standard
Deluxe Deluxe Standard Standard Standard
Deluxe Deluxe Standard Standard Standard
Plastic Plastic Plastic Plastic Plastic
Yes Yes Yes Ye s Ye s
Mesh Mesh Mesh Mesh Mesh
Specifications subject to change. without notice
Models: CVEK1000
CVEK1500
Model: CVEK500
www.airkinglimited.com
6
6
Page 7
Movable carpet shoe keeps the brush at the
ideal position relative to the carpet at all times
during the sweeping motion. The shoe pivots
as the tool moves forward and back for better
cleaning and great carpet grooming.
Air King’s Air Powered Attachments Sets include
a combination of the tools needed to effectively
clean your home.
All of the Air King Air Power Attachment Sets include a 30 foot crushproof hose
along with a combination of the most commonly used tools.
Model CVK300
For homes that feature hardwood floors with area rugs, the Air King Turbine
Tool Kit provides the tools for fast and effective cleaning results. The Turbine
Tool Kit includes a turbine brush that features a unique design to maximize
power from the available air stream, a built-in air relief valve that allows the
head to be adjusted to better match the vacuum and the floor conditions, and
a brush pattern that improves cleaning ability by drawing the dirt to the center
of the brush where it is drawn away. The crush proof hose included in the
Turbine Tool Kit features an ergonomically designed handle, 360° swivel to
eliminate kinks in the hose and to reduce effort when cleaning, and a belowthe-surface slide switch along with dual contact points on the contact ring
provide a high level of reliability.
Model CVK100
For homes that feature mostly hard floors, the Air King Standard Tool Kit provides
the tools for effective cleaning results. The Standard Tool Kit includes a multipurpose
brush that effectively cleans hard flooring. The Standard Tool Kit also makes an
excellent kit for use in garages to clean out car interiors.
What’s Included?
30' Crushproof Hose
Floor Brush
Telescopic Wands
Friction Fit Wands
Hardwood Brush
Dust Brush
Crevice Tool
Upholstery Tool
Hose Hanger
Clip-On Tool Caddy
Specifications subject to change. without notice
CVK300 CVK100
Low voltage with Button Reinforced
Turbine Multipurpose
Aluminum -
- Plastic
12" Standard Standard
Standard Standard
Standard Standard
Plastic Plastic
Yes -
GREAT FOR USE AS A
SECONDARY TOOL KIT
FOR SMALLER JOBS
www.airkinglimited.com
7
7
Page 8
Model: AKDQZVH
Model: AKVH1000
When only select tools are needed, Air King offers
the flexibility to choose exactly what you need.
Model: AKVH300
Model: AKFB12
Model: AKMANTA
Models: CVH1000
CVH1500
Model: CVH100
Model: CVH300
Central Vacuum Brush Heads
POWER WAND TO BE
Model: AKVH100
MODEL DESCRIPTION TYPE USE WITH COLOR
AKDQZVH Quiet Drive Electric Brush 120 volt AKTW3000 Black
AKVH1000 Electric Brush 120 volt AKTW1000 Black
AKVH300 Turbine Floor Brush Air Turbine AKATW, AKPTW, AKSPW Gray
AKVH100 Floor Brush Air AKATW, AKPTW, AKSPW Gray
AKFB12 12" Deluxe Floor Brush Air AKATW, AKPTW, AKSPW Black
AKMANTA Dust Mop Air AKATW, AKPTW, AKSPW Gray
AKMANRF Refill mop head for AKMANTA - - Blue
Central Vacuum Hoses
MODEL DESCRIPTION TYPE USE WITH USED WITH COLOR
CVH1500 30' Direct Connect Electric Hose 120 volt CVIV65W, CVIV65A AKTW3000, AKTW1000 Gray
CVH1000 30' Cord Connected Electric Hose 120 volt CVIV60W, CVIV60A AKATW, AKPTW, AKSPW Gray
CVH300 30' Low Voltage Electric Hose Low Voltage CVIV60W, CVIV60A AKATW, AKPTW, AKSPW Gray
CVH100 30' Standard Hose Air CVIV60W, CVIV60A AKATW, AKPTW, AKSPW Orange
POWER INLET TO BE WAND TO BE
Model: AKTW3000
Model: AKPTW
Model: AKTHH
Model: AKMCB
AKTW1000
Model: AKATW
Model: AKSPW
Model: AKDUT
Model: AKDCT
Central Vacuum Wands
MODEL DESCRIPTION PIECES BE USE WITH COLOR
AKTW3000 Aluminum Telescoping Wand 1 AKDQZVH Silver
AKTW1000 Aluminum Telescoping Wand 1 AKVH1000 Silver
AKATW Aluminum Telescoping Wand 1 All non-electric Silver
AKPTW Plastic Telescoping Wand 1 All non-electric Black
AKSPW Plastic Wand Set 2 All non-electric Black
Model: AKDDB
Model: AKPCTC
Central Vacuum Tools and Storage
MODEL DESCRIPTION COLOR
AKTHH Plastic Hose Hanger Black
AKMCB Mesh Caddy Bag Black
AKPCTC Clip-On Tool Caddy Black
AKDDB Deluxe Dust Brush Black
AKDUT Deluxe Upholstery Tool Black
AKDCT Deluxe Crevice Tool Black
# OF BRUSH HEAD TO
www.airkinglimited.com
8
8
Page 9
The Air King VacPan provides the ultimate
in ease and convenience.
Perfect for installations into kitchens, mud rooms, and workshops.
The VacPan allows dirt and debris to be swept directly into the floor
level inlet. The toeswitch easily activates the power unit
automatically. The included trim finish plate gives the VacPan a
completed look.
VACPAN
• Toeswitch activates power unit
• Includes trim finish plate
• Available in: White
The Air King Sound Muffler effectively
reduces the sound level of your power unit.
Model AKCVM1
• Reduces the noise level of air exiting the power unit
• Easily installs to exhaust outlet on all Air King Central Vacuums
(AKVP3), Almond (AKVP5), and Black (AKVP6)
www.airkinglimited.com
9
9
Protect your floors and baseboards with the
Air King Hose Sock
Model AKHS30
• Protects floors, baseboards, and corners from the abrasiveness
sometimes caused by the hose rubbing against surfaces
• Easily installs on all Air King Central Vacuum Hoses
Page 10
Air King’s Fitting Kits combine the fittings
required for a typical installation and are
available with or without the pipe.
Model CVFK1
Single inlet fitter kit, includes all of the fittings needed for a typical single inlet
installation. Does not include pipe. Perfect for use with all Air King Attachment
Kits except for Direct Connect Kits (CVEK1500 and CVEK3500).
Model CVFK3
Triple inlet fitter kit, includes all of the fittings needed for a typical 3 inlet
installation. Does not include pipe. Perfect for use with all Air King Attachment
Kits except for Direct Connect Kits (CVEK1500 and CVEK3500).
Model AKVK5000
Complete standard installation kit that included all of the fittings for a typical
3 inlet installation. Includes 54' of pipe (4' 11" sections). Entire kit is UPSable.
Perfect for use with all Air King Attachment Kits except for Direct Connect
Kits (CVEK1500 and CVEK3500).
Models: CVK1
CVK3
Model AKVK5500
Complete Direct Connect installation kit that included all of the fittings for a
typical 3 D/C inlet installation. Includes 54' of pipe (4' 11" sections). Entire kit
is UPSable. Perfect for use with all Air King Direct Connect Attachment Kits
(CVEK1500 and CVEK3500).
Model AKVK8000
Complete standard installation kit that included all of the fittings for a typical
7 inlet installation. Includes 83' of pipe (4' 11" sections). Entire kit is UPSable.
Perfect for use with all Air King Attachment Kits except for Direct Connect
Kits (CVEK1500 and CVEK3500).
Model AKVK8500
Complete Direct Connect installation kit that included all of the fittings for a
typical 7 D/C inlet installation. Includes 83' of pipe (4' 11" sections). Entire kit
is UPSable. Perfect for use with all Air King Direct Connect Attachment Kits
(CVEK1500 and CVEK3500).
Models: AKVK5000
AKVK5500
AKVK8000
AKVK8500
www.airkinglimited.com
10
10
Page 11
Air King has all of the fittings needed to complete your installation.
Tee and Wye Fittings
MODEL DESCRIPTION
CVFT90 90° Sweep Tee
White, PVC Plastic
CVFT95 Short Tee
White, PVC Plastic
CVFT45 45° Single Wye
White, PVC Plastic
Coupler Fittings
MODEL DESCRIPTION
CVFC10 Stop Coupler
White, PVC Plastic
CVFC15 Slip Coupler
White, PVC Plastic
CVFC20 Pipe Cap
White, PVC Plastic
CVFC25 Valve Extension
White, PVC Plastic
Elbow Fittings
MODEL DESCRIPTION
CVFE90 90° Sweep Elbow
White, PVC Plastic
CVFE90S Short 90° Elbow
White, PVC Plastic
CVFE45 45° Sweep Elbow
White, PVC Plastic
CVFE95 90° Sweep Spigot
White, PVC Plastic
CVFE50 45° Sweep Spigot
White, PVC Plastic
Inlet Valves
MODEL DESCRIPTION
CVIV60W Inlet Valve
CVIV60A Inlet Valve
CVIV70 Valve Mounting Plate
CVIV80 Plaster Guard
CVIV90W Blank Cover Plate
CVIV90A Blank Cover Plate
For use with Direct Connect Hoses and Tool Kits only
CVIV65W Electric Inlet Valve
CVIV65A Electric Inlet Valve
White, Plastic
Almond, Plastic
White, Plastic
Use with: CVIV60W or CVIV60A
White, Plastic
White, Plastic
Almond, Plastic
White, Plastic
Almond, Plastic
Accessories
MODEL DESCRIPTION
CVFA40 Exhaust Vent Cap
CVFA30 Pipe Strap
AKCVF36 Plastic Flex Ducting
AKCVP510 Pipe, 2" OD x 4', 11" Length
(UPSable)
AKCVP8 Pipe, 2" OD x 8' Length
AKCVP10 Pipe, 2" OD x 10' Length
CVFA35 PVC Cement
White, Plastic
White, Plastic
2” OD, 36" Length
White, PVC Plastic
White, PVC Plastic
White, PVC Plastic
www.airkinglimited.com
11
11
Page 12
For additional information regarding our Central Vacuums or any of our other full lines of Range Hoods,
Ventilation Products, Building Products, or Air Circulators, please contact the dealer nearest you or:
United States:
820 Lincoln Avenue
West Chester, PA 19380
(877) 304-3785 • Fax (610) 696-8048
email: [email protected]
Canada:
110 Glidden Road
Brampton, Ontario L6T 2J3
(800) 250-8767 • Fax (905) 456-1015
email: [email protected]
AKCVC 7-07
Loading...
