This Guide contains several sections allowing you to install an AS-1200-BG-EXT, OAW-1250BGE, AS-1200-ABG-EXT, OAW-1250ABGE Airespace Access Point or an AS-1200-ABG-EXT-RE or OAW-1250ABGR Remote Edge Access Point (REAP). These models contain internal 802.11a and

802.11b/g antennas and connectors for optional external 802.11a and 802.11b/g antennas. When you are installing an AS-1200-BG-INT, OAW-1250BG, AS-1200-ABG-INT, or OAW-1250ABG

Airespace Access Point with internal 802.11a and 802.11b/g antennas and no connectors for optional external antennas, please refer to the Internal-Antenna Airespace Access Point Quick Installation Guide.

• Overview

• Step 1: Collecting Required Tools and Supplies

• Step 2: Configuring the Airespace AP or REAP Before Installation

• Step 3: Preparing Mounting Locations

• Step 4: Mounting the Airespace APs

• Step 5: Returning MAC Information

• Planning Notes

Installation GuideExternal-Antenna Airespace Access Point Quick Installation Guide

System Release 2.1

• FCC Statements for Airespace APs

• Industry Canada Required User Information for Airespace APs

ATTENTION!Special Considerations

While Airespace Access Points have been engineered for easy installation, there are some guidelines that are very important to the end users:

• PLACE Airespace APs NO MORE THAN 140 FEET APART FROM EACH OTHER. Placing Airespace

APs further apart almost always results in poor coverage.

• MAKE SURE THAT Airespace APs ARE INSTALLED VERTICALLY.

When Airespace APs are installed vertically, either standing up in a plenum or hanging from a ceiling, this creates the largest coverage area per Airespace AP. Hanging Airespace APs from the ceiling provides the best RF coverage.

• DO NOT MOUNT Airespace AP ANTENNAS WITHIN ONE METER

(3 FT.) OF ANY METAL OBSTRUCTIONS. THE RF WAVES FROM Airespace APs ARE BLOCKED AND/OR REFLECTED BY METAL OBJECTS, such as metal HVAC ducts, conduit, pipes, bookcases, elevator shafts, stairwells, and metal walls. REFER TO THE Airespace Access Point Deployment Guide MOUNTING Airespace APs NEAR METAL OBSTRUCTIONS.

BEFORE

• WHEN MOUNTING AN Airespace AP IN THE CORNER OF A

RIGHT-ANGLE HALLWAY INTERSECTION, MOUNT THE Airespace AP AT A 45-DEGREE ANGLE TO THE TWO HALLWAYS. The Airespace AP internal antennas are not omnidirectional, and cover a larger area when mounted this way.

• External antennas are NOT to be used when installing Airespace

APs and REAPs in a plenum.

• MAKE SURE that plenum-mounted Airespace APs and REAPs are powered using Power Over

Ethernet (POE) and use only the metal brackets (not the Ceiling-Mount Base or the Hanging-Ceiling Clips) to comply with safety regulations.

• DO NOT MOUNT Airespace APs OUTSIDE BUILDINGS.

• DO NOT MOUNT Airespace APs ON BUILDING PERIMETER WALLS UNLESS THE OPERATOR

WANTS TO PROVIDE COVERAGE OUTSIDE THE BUILDING.

11/16/04 External-Antenna Airespace Access Point Quick Installation Guide 90-100906-000 Rev 1 2

OverviewOverview

This guide is designed to provide you with the information needed to mount AS-1200-BG-EXT OAW-1250BGE, AS-1200-ABG-EXT, and OAW-1250ABGE Airespace Access Points, and AS-1200-ABG-EXT-RE and OAW-1250ABGR Remote Edge Access Points (REAPs). Airespace APs and REAPs are part of the innovative Airespace Wireless Enterprise Platform (Airespace System), and require no manual configuration after they are mounted.

This document assumes that a site survey has been performed as described in the Airespace Access Point Deployment Guide document, that Airespace AP and REAP locations and mounting options have been selected, and that you have one Airespace AP or REAP per indicated location.

After the site survey is done, you should have a map indicating the following:

• Airespace AP and REAP locations.

• Airespace AP and REAP mounting options: hanging from a ceiling, in the ceiling plenum,

projecting away from the wall, flat against the wall, or using the Ceiling-Mount Bezel Kit.

• Airespace AP and REAP power options: power supplied by the AC-to-DC power supply orderable

from the factory, or Power over Ethernet (PoE) from the Airespace WLAN Switch, another network device, or a PoE injector/hub (usually located in a wiring closet).

DANGER: Plenum-mounted Airespace APs and REAPs MUST BE powered using

Power Over Ethernet (POE) to comply with safety regulations.

If you do not have a map, make one so you can record the MAC addresses from each location and return them to the to the person who is planning or managing this wireless network.

Refer to the following sections to install the Airespace APs.

Note: When mounting Airespace APs and REAPs, make sure to maintain a 20 cm

(8 in.) separation between the Airespace APs or REAPs and bystanders to comply with FCC RF exposure regulations. Refer to the FCC Statements for Airespace APs section for more information.

For more details about Airespace AP and REAP installations, refer to the Planning Notes end of this document.

section at the

11/16/04 Overview 90-100906-000 Rev 1 3

Step 1: Collecting Required Tools and SuppliesStep 1: Collecting Required Tools and Supplies

• One Airespace AP or REAP per location.

• Airespace AP and REAP Mounting Kits, factory-supplied with each Airespace AP.

• Optional Airespace AP and REAP Mounting Kits, factory-orderable.

• Optional AC-to-DC external power supplies, factory-orderable. Note that this option requires

the power cable to be run through the plenum in a metal conduit to meet safety requirements.

• Optional external 802.11b/g antennas.

• Map showing Airespace AP and REAP locations, and mounting and power options.

• Screwdrivers, drills, and ladder.

• An assortment of sheet metal and drywall screws and toggle bolts.

• CAT-5 (or higher) cables to connect the Airespace AP and REAP locations and the Airespace

WLAN Switch or other network device.

• Optional Kensington MicroSaver Security Cable to secure each Airespace AP and REAP.

Continue with Step 2: Configuring the Airespace AP or REAP Before Installation

11/16/04 Step 1: Collecting Required Tools and Supplies 90-100906-000 Rev 1 4

Step 2: Configuring the Airespace AP or REAP Before InstallationStep 2: Configuring the

Airespace AP or REAP Before Installation

The following procedures are designed to make sure that your Airespace AP physical installation goes smoothly and that initial operation is as expected. If you are unable to prepare your Airespace AP for deployment, this Step also describes RMA (Return Material Authorization) procedures.

Note: Perform either of the following two procedures on each Airespace AP or REAP

BEFORE deploying the Airespace AP or REAP in its final location.

• Preparing a Version 1.2 Airespace AP for installation in a Version 2.0 Airespace System

• Preparing a Version 2.0 Airespace AP or REAP or Alternate Preparing a Version 2.0 Airespace AP

or REAP for installation in a Version 2.0 Airespace System

If you are unable to perform either of previous procedures, refer to the RMA Procedures section in the Airespace Product Guide.

Preparing a Version 1.2 Airespace APPreparing a Version 1.2 Airespace AP

If your Airespace AP has Airespace Operating System 1.2 or an earlier version loaded on it, or if you do not know what version the Airespace AP has loaded on it, use this procedure. If your Airespace AP is a REAP or has Airespace Operating System 2.0 or later loaded on it, use the Preparing a Version 2.0

Airespace AP or REAP procedure below.

Note: This procedure assumes that you are preparing a version 1.2 Airespace AP to

interoperate with a version 2.0 Airespace Switch or Appliance. When you are preparing a version 1.2 Airespace AP to interoperate with a version 1.2 Airespace Switch or Appliance, use the procedure found in the version 1.2 Airespace Access Point Quick Installation Guide.

Configuration SetupConfiguration Setup

Does My Configuration Qualify for this Procedure?Does My Configuration Qualify for this Procedure?

• You must have a version 2.0 Airespace Switch or Appliance on its own subnet that can be

reconfigured back and forth between Layer 2 and Layer 3 LWAPP operation. If you do not have a spare or depot Airespace Switch or Appliance that can be reconfigured back and forth between Layer 2 and Layer 3 operation, refer to RMA Procedures later in this document to RMA your version 1.2 Airespace APs.

• Alternatively, you may have a version 2.0 Airespace Switch or Appliance that is part of a

mobility group that can be reconfigured back and forth between Layer 2 and Layer 3 operation. If you do not have a mobility group of Airespace Switches and Appliances that can be recon-

11/16/04 Step 2: Configuring the Airespace AP or REAP Before Installation 90-100906-000 Rev 1 5

figured back and forth between Layer 2 and Layer 3 operation, refer to RMA Procedures later in this document to RMA your version 1.2 Airespace APs.

• If your version 1.2 Airespace AP(s) cannot be configured for any other reason using the

following procedure, refer to RMA Procedures

in the Airespace Product Guide.

Configuration Steps for an Airespace APConfiguration Steps for an Airespace AP

1. Configure the Airespace Switch or Appliance in LWAPP Layer 2 Mode (use the CLI command

show switchconfig to determine the mode; if it is set to layer 3, use the CLI command config switchconfig mode L2 to change it to Layer 2). Make sure the Airespace Switch or Appliance DS

Port is connected to the network. Use CLI, Web Browser and/or ACS procedures as described in the Airespace Switch or Appliance Quick Install Guide

and the Airespace Product Guide.

- Make sure Airespace AP ports are available (either Direct-Connect Mode or Appliance

Mode).

- Set the Airespace Switch or Appliance as the Master, so new Airespace APs always

associate with it. Use the CLI command show network config to determine if the Airespace Switch or Appliance DS Port is the Master. If it is not, make it the Master with the CLI command properly, make sure to use the CLI command config network master-base disable.

- Refer to the Airespace Product Guide for other settings.

(Note that Layer 3 and Layer 2 LWAPP operation can be switched back and forth as described in the Solutions section of the Airespace Product Guide.)

2. Take the Airespace AP out of the box and plug it into a front-panel 10Base-T connector on the

Master Switch (Direct-Connect mode), or through the same subnet that Airespace Switch or Appliance is on (Appliance Mode).

3. Apply power to the Airespace AP:

- Use 802.3af-compliant Power Over Ethernet (PoE) from the Airespace WLAN Switch or

from an orderable inline power injector. If you do not have PoE available, use an orderable external AC-to-48 VDC Power Supply plugged into the side of the Airespace AP.

- After powering up the Airespace AP, the RED Alarm LED comes on for a short period

(about 15-20 seconds) and then all the LEDs blink sequentially back and forth, indicating that the Airespace AP is trying to find an Airespace Switch or Appliance to connect to. This can continue for up to five minutes. If the Airespace AP remains in this mode for more than five minutes, the Airespace AP is unable to find the Master Airespace Switch or Appliance. Check the connection between the Airespace AP and the Airespace Switch or Appliance and make sure the Airespace AP and the Airespace Switch or Appliance are on the same subnet.

- If the power light does not come on, check the power (it can be powered either with

Power over Ethernet or a from an orderable Airespace AP External Power Supply.

- Make sure that a DHCP server is configured in the Airespace Switch or Appliance for the

Management Interface using the CLI, Web Browser, or ACS interface, and that the DHCP server is operating correctly.

- Once the Airespace AP finds the Airespace Switch or Appliance, it attempts to download

the new Airespace Operating System code if the Airespace AP code version differs from the Airespace Switch or Appliance code version. While this is happening, the LEDs on the top of the Airespace AP blink on and off together.

4. Once the Airespace Operating System code download is successful, the Airespace AP reboots.

The GREEN LED turns on and the two YELLOW LEDs indicate the states of the 802.11a and

11/16/04 Step 2: Configuring the Airespace AP or REAP Before Installation 90-100906-000 Rev 1 6

802.11b/g networks. If any part of the network is disabled in the Airespace Switch or Appliance, the corresponding YELLOW LED remains off.

- Note that the Red LED can light for a short period (10-20 seconds) when the Airespace

AP reboots. If the RED LED comes on AND STAYS ON for more than a minute, disconnect the Airespace AP and call Airespace Global Services & Support.

- Use the CLI command show ap summary. If the new Airespace AP appears on the list, it

has been configured successfully.

- From the CLI, Web Browser or ACS interface, configure the Airespace AP with its

Primary, Secondary and Tertiary Airespace Switch or Appliance names as described in the Airespace Product Guide.

- If you will be using the Airespace AP in a mobility group, set the mobility group name

using the CLI, Web Browser or ACS interface.

- If required, use the CLI, Web Browser or ACS interface to customize the Airespace

AP-specific 802.11a, 802.11b and 802.11g network settings. Once again, the two YELLOW LEDs indicate the states of the 802.11a and 802.11b/g networks. If any part of the network is disabled, the corresponding YELLOW LED remains off.

5. If everything works (the GREEN LED is on and the RED LED is off), disconnect the Airespace AP

and take it to its final destination and install it as described in this document. If your Airespace AP fails this visual test, refer to RMA Procedures Airespace APs.

in the Airespace Product Guide to return your

6. When you have installed and powered up the Airespace AP in its final destination, verify that

the LEDs are in the same state they were in at the end of Step 4.

- If no LEDs are on, the Airespace AP is most likely not receiving power.

- If the LEDs blink sequentially back and forth for more than five minutes, the Airespace

AP is unable to find its Primary, Secondary or Tertiary Airespace Switch or Appliance. Check the connection between the Airespace AP and the Airespace Switch or Appliance, and make sure the Airespace AP and the Airespace Switch or Appliance are either on the same subnet or that the Airespace AP has a route back to its Primary, Secondary and Tertiary Airespace Switches and Appliances.

- If the Airespace AP is not on the same subnet as the Airespace Switch or Appliance,

make sure there is a DHCP server on the same subnet as the Airespace AP. Also, make sure that the route between the Airespace AP and the Airespace Switch or Appliance can process IP fragmented packets.

After you have prepared all Airespace APs, reconfigure the Airespace Switch or Appliance so it is not the Master. A Master Airespace Switch or Appliance should only be used for configuring Airespace APs and not in a working network. Note that the Master Airespace Switch or Appliance is normally not used in a deployed network, so the Master Airespace Switch or Appliance setting is automatically disabled upon reboot or AireOS code upgrade.

After completing Step 2: Configuring the Airespace AP or REAP Before Installation and REAPs, continue with Step 3: Preparing Mounting Locations

for all Airespace APs

Preparing a Version 2.0 Airespace AP or REAPPreparing a Version 2.0 Airespace AP or REAP

If your Airespace AP has Airespace Operating System 2.0 or a later version (which includes all REAPs) loaded on it, continue with this procedure. If your Airespace AP has Airespace Operating System 1.2 or earlier loaded on it, or if you do not know what version the Airespace AP has loaded, use the Preparing

a Version 1.2 Airespace AP procedure above.

11/16/04 Preparing a Version 2.0 Airespace AP or REAP 90-100906-000 Rev 1 7

Note: This procedure assumes that you are preparing a version 2.0 Airespace AP or

REAP to interoperate with a version 2.0 Airespace Switch or Appliance. When you are preparing a version 1.2 Airespace AP to interoperate with a version 1.2 Airespace Switch or Appliance, use the procedure found in the version 1.2 Airespace Access Point Quick Installation Guide.

Configuration SetupConfiguration Setup

Does My Airespace AP Qualify for this Procedure?Does My Airespace AP Qualify for this Procedure?

• If your 2.0 or later version later Airespace AP(s) or REAP(s) cannot be configured for any

reason using the following procedure, refer to RMA Procedures

in the Airespace Product Guide.

Configuration Steps for an Airespace AP or REAPConfiguration Steps for an Airespace AP or REAP

1. Configure the Airespace Switch or Appliance in LWAPP Layer 3 Mode (use the CLI command

show switchconfig to determine the mode; if it is set to layer 3, use the CLI command config switchconfig mode L2 to change it to Layer 2). Make sure the Airespace Switch or Appliance DS

Port is connected to the network. Use CLI, Web Browser and/or ACS procedures as described in the Airespace Switch or Appliance Quick Install Guide

and the Airespace Product Guide.

Note: When you are installing a REAP or an Airespace AP, a DHCP server must be

accessible by the REAP or an Airespace AP.

- Make sure Airespace AP ports are available (either Direct-Connect Mode through the

Switch physical ports, or in Appliance Mode Management/AP-Manager Interface).

through the Airespace Switch or Appliance

- Set the Airespace Switch or Appliance as the Master, so new Airespace APs always

- Refer to the Airespace Product Guide for other settings.

2. Take the Airespace AP or REAP out of the box and plug it into the front panel of the Master

Switch (Direct-Connect Mode is on (Appliance Mode

), or through the same subnet that Airespace Switch or Appliance

3. Apply power to the Airespace AP:

- Use 802.3af-compatible Power Over Ethernet (PoE) from the Airespace Switch or

Appliance or from an orderable inline power injector. If you do not have PoE available,

11/16/04 Preparing a Version 2.0 Airespace AP or REAP 90-100906-000 Rev 1 8

use an orderable external AC-to-48 VDC Power Supply plugged into the side of the Airespace AP.
