# 540-539-P INSTALLATION INSTRUCTIONS

94-01 Mitsubishi 2.0L DOHC Non-Turbo

Thank you for purchasing the PowerAid Throttle Body Spacer. Please read the
instruction manual carefully bef ore proceeding with the installation. Cont ac t AIRAID @
[phone] 8:00 AM - 5:00 PM MST Weekdays for questions regarding fit or in­structions that are not clear to you. Your PowerAid Throttle Body Spacer was carefully
inspected and packaged. Check that no parts are missing, or were damaged during
shipping. If any parts are missing, please contact AIRAID.

Thank you for selecting AIRAID.

Nitrous Fitting
Not Included

Please refer to a nitrous oxide system manufacturer for proper application for your vehicle.

Be sure to follow the manufacture’s instructions & warnings when using nitrous oxide.

Vacuum Gauge
Fitting Shown

Parts List

(1) Power Plate

(2) Gaskets

(2) Bolts 8mm x 80mm

(2) 8mm Flat Washers

(2) 3/4 Extension Plates

(2) 6mm x 16mm Flat Head Screws

(1) 3/8 I.D. Vacuum Hose x 4 1/4 O.A.L.

(1) 3/16” Vacuum Fitting

1

Tools List

10mm Socket

8mm Socket

Flat head Screwdriver

Installation Instructions. Read Me!

1. DISCONNECT NEGATIVE(-) BATTERY CABLE.

2. Remove air intake hose assembly.

3. Remove throttle cable bracket and save bolts. (Ref. “B”)

4. Remove (2) bolts from the throttle body. (Ref. “A”)

5. Install (2) extension plates for throttle cable bracket using (2) 6mm flat head screws. (Ref. “B”)

6. Install power plate using (2) furnished gaskets, (2) 8mm x 80mm bolts, and (2) 8mm washers. (Ref. “A”)

7. Reinstall throttle cable bracket using saved bolts. (Step 3)

8. Inspect & Test throttle linkage for full Open & Closed travel before driving. Cables may require adjustmen t. Please refer to
service manual for proper adjustment.

9. Reinstall air intake hose assembly. (Step 2)

10. Replace 3/8 vacuum hose with furnished 3/8 I.D. x 4 1/4 O.A.L. vacuum hose (Ref. “C”)

11. Reconnect battery cable. Enjoy!

The sound of power...The “whistle” means its working!

Ref. “B”- (2) 3/4 Extension Plates
(2) 6mm x 16mm
Flat Head Screws

Ref. “A”- (1) Power Plate
(2) Gaskets
(2) 8mm x 80mm Bolts
(2) 8mm Flat Washers

Ref. “C”-

(1) Vacuum Hose

3/8 I.D. x 4 1/4 O.A.L.

Rev. 02/21/07

AIRAID Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 [phone] [e-mail] www.airaid.com
