Airaid 310-170 Installation Instructions

Installation Instructions

For Part Numbers:

310-170 700-458 Airaid Oiled Media Filter
311-170 701-458 SynthaMax Dry Media Filter - Red
312-170 702-458 SynthaMax Dry Media Filter - Black
313-170 703-458 SynthaMax Dry Media Filter - Blue

2005-10 Jeep Grand Cherokee

5.7L V8, 6.1L V8 Hemi

Component Identification

1. Airaid Premium Filter 1

2. MAF Panel 1

3. Front Panel 1

4. Weather Strip 17 1/2” 1

5. 6-32 x 5/16” Screw 4

6. #6 Flat Washer 4

7. 6-32 Keps Nut 4

8. Speed Clamp 1

9. 1/2” x 90° Elbow 1

Full color instructions can be viewed on our web site at Airaid.com. Use the Product Search function to find your part number, and click View Details.

1. Disconnect the negative battery cable.

Using a 5/16” socket, loosen the hose clamp
on the factory airbox lid. Twist and remove
the breather hose from the factory airbox lid.

2. Unlatch the two clips on the front of the
factory airbox lid.

3. Remove the factory airbox lid by sliding it
forward, and then up and out of the factory
intake tube.

4. Remove the factory air filter from the air­box base.

7. Re-install the breather hose and speed
clamp (#8) onto the nipple on the Quick Fit
Panel. If you are working on a 6.1L, install

the 1/2”x 90° elbow (#9) from the breather
hose to the nipple on the Quick Fit Panel.

5. Assemble the Quick Fit Panels (#2, #3)
using four 6-32 x 5/16” screws (#5), #6 flat
washers (#6), and 6-32 keps nuts (#7).

8. Install the Airaid Premium Filter (#1) onto
the tube on the Quick Fit Panels, and tighten
the clamp.

6. Install the Quick Fit Panels by sliding the
four tabs on the back of the panels into the
factory airbox base, and then into the factory
intake tube. Relatch the two factory clips into
the slots on the front of the Quick Fit Panels .
Tighten the hose clamp on the factory intake
tube.

9. Install the weather strip (#4) onto the top
of the Quick Fit Panels. (Hint: For ease of

installation, start at one end and work your
way to the other).

10. Double check your work!

Make sure there is no foreign material in the intake path. Make sure all clamps, hoses, bolts, and screws are tight.

11. Reconnect the negative battery cable!

Thank you for purchasing the Airaid Intake System. Contact Airaid @ [phone] 8:00 AM - 5:00 PM MST week­days for questions regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air
filter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water. WA­TER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter is reusable and should be cleaned periodically.

FILTER IDENTIFICATION

700-458 Airaid Oiled Media 701-458 Airaid SynthaMax Dry Media - Red

702-458 Airaid SynthaMax Dry Media - Black 703-458 Airaid SynthaMax Dry Media - Blue

For your Oiled media filter

we suggest using the

AIRAID Filter Tune-Up Kit!

P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray

Synthamax Air Filters do not re­quire oil. Service air filter as need­ed by cleaning with common non­petroleum all-purpose household
cleaner and water. Simple Green®,
Formula 409® or equivalent works
great. Apply cleaner to outside of
air filter and allow to soak. Then
flush filter clean from the inside out
with a garden hose and repeat steps
if necessary. Do not apply high
pressure water or air to clean filter.
Allow filter to air dry and reinstall.

Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 [phone] [e-mail] www.airaid.com

REV.12.3.13
