EX1810R

Bench Power Supply

INSTRUCTION MANUAL

Introduction

The EX1810R is an exceptionally compact and lightweight single output laboratory dc power supply providing 0 to 18V at 0 to 10A.

The EX1810R uses mixed−mode regulation technolog y which combines switch−mode pre−regulation with linear post−regulation. Special techniques are used to maintain very high efficiency whilst achieving noise levels that are close to that of a pure linear regulat or.

Excellent line and load regulation are matched by low noise and good transient response. High power efficiency ensures that the unit remains cool without any fan noise. High r esolut ion controls allow accurate setting of voltage and curr ent levels. Remot e sense terminals are provided so that good regulation can be maintained across remote loads at high currents.

The output operates in constant voltage or constant current mode with automatic cross-over and mode indication. There is a DC output on−off switch.

The EX series incorporates separate digital voltage and current m eters on each output. The meters use bright 14mm ( 0· 56” ) LED displays and have an update rate of 4 per second providing near instantaneous response. Simultaneous metering of voltage and curr ent provides accurate information “at a glance” and avoids any possibility of misinter pr etat ion. When the output switch is set to “off”, the cur r ent limit s et t ing is displayed enabling conditions to be set before the load is connected.

The EX series has been designed to meet t he s t r ingent requirements of the latest relevant IEC standards for safety and EMC, including harmonics emissions. All outputs are intrinsically short circuit proof, and are protec t ed against external voltages and reverse currents.

Introduction 1 Specification 2 Safety 3 Installation 4 Connections 4 Operation 5 Maintenance 6

Instructions en Francais 7 Bedienungsanleitung auf Deutsch 11 Istruzioni in Italiano 16 Instrucciones en Español 20

Voltage Range:

0V to 18V minimum

Current Range:

0A to 10A minimum

Output Voltage Setting:

By coarse and fine controls.

Output Current Setting:

By single logarithmic control.

Operating Mode:

Constant voltage or constant current with automatic cross-over.

Output Switch:

Electronic. Preset voltage and current displayed when off.

Output T erminals:

Universal 4mm safety binding posts on 19mm (0.75”) pitc h.

terminals for remote connec t ion.

Reverse protection by diode clamp for reverse currents up to 3A.

sense.

Line Regulation:

<0.01% of maximum output for a 10% line change.

(20MHz bandwidth):

Transient Response:

<200µs to within 50mV of set level for a 5% to 95% load change.

Temperature Coeff icient :

Typically < 100ppm /°C

Status Indicat ion:

Output on lamp. Constant current mode lam p.

Meter Types:

Dual 4 digit meters with 14mm (0.56") LEDs. Reading r ate 4 Hz.

Meter Resolutions:

10mV, 10mA

Current 0.6% of reading ± 3 digits

factory option. Installation Category II .

Power Consumption:

400VA max.

Operating Range:

+5ºC to +40ºC, 20% to 80% RH.

Storage Range:

40ºC to + 70ºC.

Environmental:

Indoor use at altitudes up to 2000m, Pollution Degr ee 2.

instrument via http://www.aimtti.com/support (serial no. needed) .

Size:

140 x 160 x 320mm (WxHxD).

Weight:

2.8kg

OUTPUT

Sensing: Switchable between local and remote. Spring-loaded push

Output Protection: Output will withstand up to 22V forward voltage.

Load Regulation: <0.01% of maximum output for a 90% load change, using remote

Specification

Ripple & Noise

METER SPECIFICATIONS

Meter Accuracies: Voltage 0.3% of reading ± 3 digits

GENERAL

AC Input: 220-240VAC ±10%, 50/60Hz; 110-120VAC ± 10%, 50/60Hz by

Typically < 2m Vrms, <20mV pk-pk, constant voltage mode.

−

Safety & EMC: Complies with EN61010-1 & EN3126-1.

For details, request the EU Declaration of Conformity for this

alternating current (ac)

Safety

This power supply is a Safety Class I instrument according to I EC classification and has been designed to meet the requirem ents of EN61010-1 (Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use). I t is an Installation Category II instrument intended for operation from a normal single phase supply.

This instrument has been tested in accordanc e with EN61010-1 and has been supplied in a safe condition. This instruction manual contains some information and warnings which have to be followed by the user to ensure safe operation and to r etain the inst r um ent in a safe condition.

This instrument has been designed f or indoor use in a Pollut ion Deg r ee 2 environment in the temperature range 5°C to 40°C, 20% - 80% RH (non-condensing). It may occasionally be subjected to temperatures between +5° and -10°C without degradation of its safety. Do not operate while condensation is present.

Use of this instrument in a manner not s pecified by these instructions may impair the safety protection provided. Do not operate the instrum ent outside its rat ed supply voltages or environmental range.

WARNING! THIS INSTRUMENT MUST BE EARTHED

Any interruption of the mains earth conduct or inside or outside t he inst r um ent will make the instrument dangerous. Int entional interruption is prohibited. The protective action must not be negated by the use of an extension cord without a protective conductor.

When the inst r um ent is c onnect ed to its supply, term inals may be live and opening the covers or removal of parts (except those to which access can be gained by hand) is likely to expose live parts. The apparatus shall be disconnected from all voltage sources before it is opened for any adjustment, replacement, m aint enance or repair. Capacitors inside the power supply may still be charged even if the power supply has been disconnected from all voltage sources but will be safely discharged about 10 minutes after s witching off power.

Any adjustment, maintenance and repair of the opened instrument under voltage shall be avoided as far as possible and, if inevitable, shall be carried out only by a skilled person who is aware of the hazard involved.

If the instrument is clear ly def ect ive, has been subject to mechanical damage, excessive moisture or chemical corrosion the safety protection may be impaired and the apparatus should be withdrawn from use and returned for checking and repair.

Make sure that only fuses with the required rated c ur r ent and of the specified type are used for replacement. The use of makeshift fuses and the short-circuiting of fuse holders is prohibited.

Do not wet the instrument when cleaning it. The following symbols are used on the instrument and in this m anual:-

Earth (ground) terminal.

mains supply OFF.

mains supply ON.

direct current (dc)

Mains Operating Voltage

Check that the instrument oper ating voltage marked on the rear panel is suitable for t he local supply.

Mains Lead

When a three c or e m ains lead with bare ends is provided this should be connect ed as follows:

BROWN - MAINS LIVE

Installation

BLUE - MAINS NEUTRAL GREEN/YELLOW - EARTH Safety Earth Symbol

When f it t ing a fused plug a 5 amp fuse should be fitted inside the plug. As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:

The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol shown above or coloured green or greenand-yellow.

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

WARNING! THIS INSTRUMENT MUST BE EARTHED.

Any interruption of the mains earth conduct or inside or outside t he inst r um ent will make the instrument dangerous. Int entional interruption is prohibited.

Connections

All connections are made from the front panel. The load should be connected to the positive (red) and negat ive (black ) terminals marked

OUTPUT. Remote sense connections to the load, if r equired, are made from the posit ive (+) and

negative (−) SENSE terminals. Switch the LOCAL/REMOTE switch to REMOTE when remote sensing is required. Switch back to LOCAL when remote sensing is not in use.

The terminal marked

is connected to the chassis and safety eart h ground.

Setting Up the Output

With the PO WER switch on (l) and the output off the output voltage and current limit can be accurately preset using the VOLTAGE and CURRENT controls; the left-hand met er shows the set voltage and the right-hand meter shows the set maximum c ur r ent.

Operation

When the the actual voltage and the right-hand meter t he ac t ual load current.

output switch is switched on, the ON lamp lights; the left-hand meter now shows

Constant Voltage

The output voltage is adjusted using the coar se and fine VOLTAG E cont r ols; the CURRENT control sets the maximum current that c an be supplied.

Constant Current

If the load resistance is low enough such that, at the output voltage set, a current gr eat er than the current limit setting would flow, the power supply will automatically move into constant current operation. The current output is adjusted by the CURRENT control and the VOLTAGE controls set the maximum voltage that can be generated.

The CC lamp lights to show constant current mode.

Instantaneous Current Output

The current limit control can be set to limit the continuous output current to levels down to 10mA. However, in com m on with all precision bench power supplies, a capacitor is connected acr os s the output to maintain stability and good transient response. This capacitor charges to the output voltage and short-circuiting of the output will produce a current pulse as the capacitor discharges which is independent of the current limit setting .

Protection

The output has intrinsic short-cir cuit pr ot ec t ion and is pr ot ected from reverse voltages by a diode; the continuous reverse current must not exceed 3 Amps, although transients can be much higher.

Connection to the Load

The load should be connected to the positive (red) and negat ive (black ) OUTPUT terminals. Both are fully floating and either can be connected to ground.

Remote Sensing

The unit has a very low output impedance, but this is inevitably increased by the resistance of the connecting leads. At high currents this can result in significant differenc es bet ween the indicated source voltage and the actual load voltage (two 20mΩ connecting leads will drop 0.2V at 5 Amps, for instance). This problem can be minimised by using short, thick, connecting leads, but where necessary it can be completely overcome by using the remote sense f acility.

This requires the sense term inals to be c onnected to the output at the load instead of at t he source; insert wires into the spring-loaded SENSE terminals and connect directly to the load. Switch the LOCAL/REMOTE switch to REMOTE. To avoid instability and transient response problems, care must be taken to ensur e good coupling between each output and sense lead. This can be done either by twisting the leads together or by using coaxially screened cable (sense through the inner). An electrolytic capacitor directly across the load connection point may also be beneficial.

The voltage drop in each output lead must not exceed 0.5 Volts. Switch the LOCAL/REMOTE switch back to LOCAL when remote sensing is not in use.

Series or Parallel Connection with Other Outputs

The outputs of the power supply are fully floating and m ay be used in series with other power supply units to generate high DC voltages up to 300V DC.

The maximum permissible voltage between any terminal and earth ground ( WARNING! Such voltages are exceedingly hazardous and great care should be taken to shield

the output terminals for s uch use. On no account should the output terminals be touc hed when the unit is switched on under such use. All connections to the terminals must be made with the power switched off on all units.

It should be noted that the unit can only source current and cannot sink it, thus units cannot be series connected in anti-phase.

The unit can be connected in parallel with others to produce higher currents. Where several units are connected in parallel, the output voltage will be equal to that of the unit with the hig hest output voltage setting until the current dr awn exceeds its current limit setting, upon which the output will fall to that of the next highest set ting, and so on. In constant current m ode, units can be connected in parallel to provide a current equal to the sum of t he c ur r ent limit settings.

Note that the output terminals are rated at 15A maximum; if several outputs are operated in parallel to source higher currents than this the junction should be made at a separate point, not one of the terminals.

Ventilation

The power supply is very efficient but nevertheless can generate signif icant heat at full power. The supply relies on convection cooling only and it is therefore important that ventilation is never restricted if perf or mance and safety are to be maintained.

) is 300VDC.

The Manufacturers or their ag ents overseas will provide repair for any unit developing a fault. Where owner wish to undertake their own maintenance work , t his s hould only be done by skilled personnel in conjunction with the service manual which may be purchased directly from the Manufacturers or their agents overseas.

Fuse

The correct fuse type is:

Note that the main function of the fuse is to make the inst rument safe and limit damage in the event of failure of one of the switching devices. If a fuse fails it is therefore very likely that the replacement will also blow, because the supply has developed a fault; in such circumstances the instrument will need to be returned to the manuf ac t ur er for service.

Make sure that only fuses of the required rated current and specified t ype are used for replacement. The use of makeshift fuses and the short-circuiting of fuse-holders is prohibited.

To replace a fuse, first disconnect the instrument from the AC supply. Remove the 6 cover securing screws and lift off the cover. Replace the fuse with one of the correct t ype and refit the cover.

Cleaning

Maintenance

10 Amp 250V HBC time-lag(T), 5 x 20mm.

If the PSU requires cleaning use a clot h t hat is only lightly dampened with water or a mild detergent. Polish the display window with a soft dry cloth.

WARNING! TO AVOID ELECTRIC SHOCK, OR DAMAGE TO THE PSU, NEVER ALLOW WATER TO GET INSIDE THE CASE. TO AVOID DAMAGE TO THE CASE OR DISPLAY WINDOW NEVER CLEAN WITH SOLVENTS.

courant alternatif (c.a.)

Sécurité

Cet instrument est de Classe de sécurité 1 suivant la classification IEC et il a été construit pour satisfaire aux impératifs EN61010-1 ( impér atifs de sécurité pour le matériel électrique en vue de mesure, commande et utilisation en laboratoire) . Il s'agit d'un instrument d'installation Catégorie II devant être exploité depuis une alimentation monophasée habituelle.

Cet instrument a été soumis à des essais conformément à EN61010-1 et il a été f our ni en t out état de sécurité. Ce manuel d'instructions contient des informations et avertissements qui doivent être suivis par l'utilisateur afin d'assurer un fonctionnement de toute sécurité et de conser ver l'instrument dans un état de bonne sécurité.

Cet instrument a été conçu pour être utilisé en interne dans un environnement de pollution Degré 2, plage de températur es 5°C à 40°C, 20% - 80% HR (sans condensation). Il peut être soumis de temps à autre à des températures c om pr ises entre +5°C et -10°C sans dégradation de sa sécurité. Ne pas l'utiliser lorsqu'il y a de la condensation.

Toute utilisation de cet instr um ent de m anièr e non spéc ifiée par ces instructions risque d'affecter la protection de sécurité conférée. Ne pas utiliser l'instrument à l'extérieur des tensions d'alimentation nominales ou de la gamme des conditions ambiantes spécifiées.

AVERTISSEMENT! CET INSTRUMENT DOIT ETRE RELIE A LA TERRE

Toute interruption du conducteur de terre secteur à l'intérieur ou à l' extér ieur de l' inst rument rendra l'instrument dangereux. I l est abs olument interdit d'effectuer une interr upt ion à dessein. Ne pas utiliser de cordon de prolongation sans conducteur de protect ion, car c eci annulerait sa capacité de protection.

Lorsque l'instrument est r elié au sect eur, il est possible que les bornes soient sous tension et par suite, l'ouverture des couvercles ou la dépose de pièces (à l'exception de celles auxquelles on peut accéder manuellement) risque de m et tre à découvert des pièces sous tension. Il faut débrancher ke cordon secteur de l'appareil avant de l'ouvrir pour effectuer des réglages, remplacements, travaux d'entretien ou de réparations. Les condensateurs qui se trouvent dans le bloc d'alimentation risquent de rester chargés, même si le bloc d'alimentation a été déconnecté de toutes les sources de tension, mais ils se décharg er ont en toute sécurité environ 10 minutes après extinction de l'alimentation.

Eviter dans la mesure du possible d'effectuer des rég lages, travaux de réparations ou d'entretien lorsque l'instrument ouvert est br anché au s ecteur, mais si c'est absolument nécessaire, seul un technicien compétent au courant des risques encour us doit effectuer ce genre de travaux.

S'il est évident que l'instrument est défectueux, qu'il a été soumis à des dég âts m écaniques, à une humidité excessive ou à une corrosion chimique, la protection de sécurité ser a am oindr ie et il faut retirer l'appareil, afin q u'il ne soit pas utilisé, et le renvoyer en vue de vérifications et de réparations.

Remplacer les fusibles uniquement par des fusibles d' int ensit é nom inale requise et de type spécifié. Il est interdit d'ut iliser des fusibles bricolés et de court-circuiter des por t e-fusibles. Eviter de mouiller l'instrument lors de son nettoyage. Les symboles suivants se trouvent sur l'instrument, ainsi que dans ce m anuel.

Borne de terre (masse)

alimentation secteur ON (allumée) alimentation secteur OFF (éteinte)

courant continu (c.c.)

Tens ion d’utilisation secteur

Vérifier que la tension opérationnelle de l'instrum ent indiq uée sur le panneau arrière est appropriée pour l'alimentation locale.

Câble secteur

Relier de la manière suivante tout câble secteur à trois conduct eur s à fils nus:

MARRON - SECTEUR SOUS TENSION

Installation

BLEU - SECTEUR NEUTRE VERT/JAUNE - TERRE Symbole Terre de protection

Lors du montage d'une fiche à f usible, m ettre un fusible de 5 A à l'intérieur de la fiche. Il est possible que les couleurs des fils du câble secteur de cet appareil ne corr espondent pas aux marques de couleur d'identificat ion des bor nes de la fiche, et par suite, il est recommandé de procéder de la manière suivante:

Relier le fil vert et jaune à la borne de la fiche désignée par la lettre E ou par le symbole Terr e de protection indiqué ci-dessus, ou qui est en vert, ou en vert et jaune.

Relier le fil bleu à la borne désignée par la lettre N, ou qui est en noir. Relier le fil marron à la borne désignée par la lettre L, ou q ui est en r ouge.

AVERTISSEMENT! CET INSTRUMENT DOIT ETRE RELIE A LA TERRE

Connexions

Toutes les connexions sont effectuées au panneau avant.

Relier la charge aux bornes positive (rouge) et négative (noire) m ar quées OUTPUT (Sortie). Effectuer des connexions de télédétection à la charge, le cas éc héant , des bornes de détection

(SENSE) positive (+) et négative (−). Placer le comm utat eur LO CAL/ REMOTE en position REMOTE lorsque la détection distante est requise. Placer le com m utat eur en posit ion LO CAL lorsque cette détection distante n’est pas utilisée.

La borne désignée

est reliée au châssis et à la terre de protect ion.

Réglage de la sortie

L’interrupteur POWER (alimentation) sur (l) et la sor tie éteinte, il est possible de régler avec précision la limite de tension et de courant de sortie au m oyen des comm andes VO LTAGE (Tension) et CURRENT (Courant); l’appareil de mesure gauche indiq ue la t ension r églée et l’appareil droit le courant maximum réglé.

Fonctionnement

Lorsque le commutateur de sortie l’appareil de mesure gauche indique alors la tension véritable et l’appareil droit le courant de charge véritable.

Tens ion constante

Les commandes VOLTAGE de réglage grossier et de précision permettent d’ajuster la tens ion de sortie; la commande CURRENT règle le courant maximum qui peut êtr e fourni.

Courant constant

Si la résistance de charge est suffisamment bass e qu’un courant supérieur au réglage de limite de courant puisse passer pour la tension de sortie réglée, l’alimentation passera automatiquement en mode de f onc t ionnem ent de courant constant. La commande CURRENT ajuste le courant de sortie et les commandes VO LTAGE règ lent la tens ion maximale q ui peut êt r e engendrée. Le témoin CC s’allume pour indiquer le mode de courant constant .

Sortie de courant instantanée

Il est possible de régler la commande de limite de courant pour limit er le cour ant de s or t ie continu à des niveaux aussi bas que 10 mA. Toutefois, ainsi que c’est le cas de toutes les alimentations de précision sur banc, un condensateur est relié aux bornes de la sortie, afin de maintenir la stabilité, ainsi qu’une bonne réponse transitoire. Ce condensat eur se c har ge jusqu’à la tension de sortie, et le court-circuitage de la sor t ie pr oduir a une impulsion de cour ant , lors du déchargement du condensateur indépendam m ent du r églage de limite de courant.
