AGPtek TP10V, TP15H, TP15 User Manual

TABLET USER MANUAL

Attention:
This handbook contains important security measures and the information for correct

usage of the product in order to avoid accidents. Please make sure to read the
manual carefully before using the device.

• Avoid exposure to moisture and dust

• Avoid exposure to high temperature do not keep the device on the

dashboard of the car specially when the windows are closed.

• Avoid fall or violent shaking of the device This could cause damage to TFT
display screen

• Please choose appropriate volume, if using headphones volume should not
be too high

• Please charge the device in the following conditions,

A. The battery power ICON indicates low or no power
B. The system automatically shuts off, as soon as device is started
C. Operat ion buttons do not respond
D. The icon at the top right corner turns red

• .When the device is being formatted or during uploading and downloading of
files, please do not suddenly disconnect as this can cause application error

• Do not use the device in places where use of electronic devices is prohibited
e.g. during flights

• Don’t disassemble the product, don’t use alcohol Thinner or
benzene to scrubb in g
products

• Please do not use the Tablet PC when you in driving or walking

• USB must be used only for data transmission

• The company reserves right to improve product, products specification and

design and make any changes w i thout pr i or noti ce.

• This tablet is not waterproof

[Remark.] : All images in this manual is only for your reference. products
specification and design may differ. The information is subject to changes without
prior notice.

1. Appearance and button:

1.1 Touch panel
Capacitive touch panel: In The Operation, for clicking ,dragging on the touch

panel

1.2 POWER
Startup: Long Press and hold the power button, the system will enter the main

interface
Shutdown: In the main menu interface, Press the power button for about 5

seconds to shutdown, The system will display "power off" option, Clik ”ok”. To
safely shut down.

Lock screen: Short press Power button to lock or unlock screen.
Remark 1.When power is empty, system will shut down automatically.

2.In case of improper turn off of the device, restart may take
longer time as it will scan and restore the disk

1.3 ESC
Short Press of ESC button will return to the last interface, long Press ESC button

will return to the main interface
1,4 Menu
Under normal operating conditions, short press of M button will bring you back to

the home screen

1.5 Volume +, Volumethe
Use buttons on top “ Volume +”, “Volume- “ to achieve changes in the volume.

1.6 Earphone jack

3.5 mm standard earphone jack

1.7 Video output interface

1.8 TF card
TF-CARD solt: external T-FLASH card

1.9 Mini USB
Mini USB jack: you can use it to connect the computer for data transmission,

charging and external conn ec ti on USB flas h dr i v e

1.10 Reset
When the Tablet seems to have hung up or has stopped taking commands , use

a small object to short press RESET button, Tablet will be forced to shut down.
.[Remark.]: unless actually unable to shutdown do not use the reset, methods as

this can easily cause to damage the machine system.

2. First use

2.1 Battery management and charge
Before first use, please fully charge the device's battery
For charging you only need to connect the adaptor or USB interface to power

source, On the first two instances charge battery for about 6 hours, subsequently4
hour charging will suffice.

.[Remark].: This tablet uses its Built-in type polymer battery, Charging device
must be a standard adaptor (Input: AC110~240V 50/60Hz Max:180MA.. Output:
DC5.0~5.5V/1.5-2.0A), This device can be charged without DC supply , using USB
interface , for this , Choose USB interface to charger During the charging, the battery
icon will scroll,When finished charging, battery icon will become green and stop
scrolling. In order to prolong the service life of the machine, suggest use out battery
power before again charging it

.[Remark]: 1. If tablet is not in use for long time, ,in order to avoid power
consumption caused damage please charge/play the battery once a month,.

2 .When battery is low ,shut down device ,connect DC adaptor , wait for some time

until the battery is enough power to enter into main menu.

3. While charging please keep devise in standby mode for faster charging.

2.2 Connection with PC

Use USB cable to connect device to PC, device will pop up the USB connection

window, click “Turn on USB storage” to connect to PC

Into the load mode, you can copy, delete the file on the device and the file on the
memory card
