AGPtek G05 User Manual

Unit overview

G05 USER MANUAL

1.Previous song/Fast backward/ Return

2.Return / Move down

3.Submenu button / Lock /Unlock / Move up

4.Play / Pause / Enter / Power On-off

5.Next song/Fast forward

6.Micro-USB port

7.MIC hole

8.Power on-off

9.Earphone jack

10. Micro SD card slot

11.Vol+/Vol-

12.Clip

13.1.5”TFT screen

Basic Operation

Screen

1.5 inch 128*128 TFT display

Flash memory

8GB

Audio format

MP3/WMA/OGG/APE/FLAC/WAV/A
AC-LC/ACELP

Recording format

FM/MIC record and WAV

Battery

Li-polymer rechargeable 300mAh

FM frequency

87.0-108MHZ

Micro-SD card

Extend to 64GB

Photo format

JPG,BMP and GIF

Charging time

3 hours

Powering on the player

 Push on-off button to the “on” side or long press button

for about 3 seconds to turn it on.



Push on-off button to the“off”side or long press button

for about 3 seconds to turn it off.

Return operation

 At any interface, long press to enter Main menu.



At main menu, press back to the interface you just

use(music or FM).

Lock the Screen

Long press to lock the screen. Repeat to unlock. When

the screen is locked, all of the buttons on the key pad are

not available.

MUSIC

Battery Charging

When there is a battery indicator on the screen, you must

charge the device.

The device has two charge options:

a)You can charge the device via the USB connector.

b)You can also charge the device via a 5V 500mA USB wall

adapter(not included)

Note:The charging time should not exceed 4 hours. It is

recommended to turn off the device before charging.

Press buttons definition

Action

Basic operation

Short press

Press time is less than 1-2 seconds

Long press

Press time is more than 1-2 seconds

Hold

Keep pressing one button

Note:Without special instruction, all pressing mean short

pressing in this user manual.

At any interface, long press to enter main menu

interface and find music UI.

Play your music

On music menu, press to enter music function ,and by

pressing / view sub-menu from up to down:“All songs”,

“Now playing”, “Resume”, “Artists”, “Albums”, “Genres”,

“Playlists” and “Create playlists”. Press to confirm your

option and start to play your music.

When the device is playing songs, press button to enter

below sub-menus, and press to enter the option you

want.

 Repeat
