FULL D1 DVR

User Manual

 Intelligent Video Surveillance

 GUI Display with USB Mouse Control

Please read instructions thoroughly before operation and retain it for future reference.

For the actual display & operation, please refer to your DVR in hand.

700_708h_m769_769-b_769h_Manual_V1.4

IMPORTANT SAFEGUARD

CAUTION

CAUTION:

To reduce the risk of electric shock, do not expose this apparatus to rain or moisture. Only operate this apparatus from the type of power source indicated on the label. The company shall not be liable for any damages arising out of any improper use, even if we have been advised of the possibility of such damages.

RISK OF ELECTRIC SHOCK

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive.

The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do not dispose of these products as unsorted municipal waste. Contact your local dealer for procedures for recycling this equipment.

This apparatus is manufactured to comply with the radio interference requirements.

Federal Communications Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Trademark Acknowledgements

and (EagleEyes) - The trademark application is filed and under process in the U.S. and other countries.

iPhone® is the registered trademark of Apple Inc.

BlackBerry® and related trademarks, names and logos are the property of Research In Motion Limited and are registered and/or used in the U.S. and countries around the world. Used under license from Research In Motion Limited.

Android™ is a trademark of Google Inc. Use of this trademark is subject to Google Permissions.

Microsoft®, Windows®, Internet Explorer®, Mozilla® Firefox®, Google Chrome™, Safari®, QuickTime®, Windows® Mobile & Symbian® mentioned in this document are the registered trademarks of their respective holders.

Disclaimer

The information in this manual was current when released. We reserve the right to revise or remove any content in this manual at any time. We do not warrant or assume any legal liability or responsibility for the accuracy, completeness, or usefulness of this manual. For the actual display & operation, please refer to your DVR in hand. The content of this manual is subject to change without notice.

Grounding

This is a Safety Class 1 Product (provided with a protective earthing ground incorporated in the power cord). The mains plug shall only be inserted in a socket outlet provided with a protective earth contact. Any interruption of the protective conductor inside or outside of the instrument is likely to make the instrument dangerous. Intentional interruption is prohibited.

Water & Moisture

Do not expose this product to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the product.

MPEG4 Licensing

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, LLC. SEE HTTP://WWW.MPEGLA.COM.

GPL Licensing

This product contains codes which are developed by Third-Party-Companies and which are subject to the GNU General

Public License (“GPL”) or the GNU Lesser Public License (“LGPL”).

The GPL Code used in this product is released without warranty and is subject to the copyright of the corresponding

author.

Further source codes which are subject to the GPL-licenses are available upon request.

We are pleased to provide our modifications to the Linux Kernel, as well as a few new commands, and some tools to get

you into the code. The codes are provided on the FTP site, and please download them from the following site or you can refer to your distributor:

http://download.dvrtw.com.tw/GPL/076D_Series/arm-linux-2.6.tar.gz

TABLE OF CONTENTS

1. HARDWARE OVERVIEW................................................................................................................ 1

1.1 Package Content ...................................................................................................................................................1

1.2 Front Panel ............................................................................................................................................................1

1.3 Rear Panel .............................................................................................................................................................2

2. CONNECTION AND SETUP........................................................................................................... 4

2.1 SATA Hard Disk Installation....................................................................................................................................4

2.2 Camera Connection ...............................................................................................................................................5

2.2.1 Normal / DCCS Camera ................................................................................................................................5

2.2.2 PTZ Camera

2.3 External Device Connection...................................................................................................................................6

2.4 DVR Power On ......................................................................................................................................................7

2.5 Date and Time Setting............................................................................................................................................7

2.6 Clear Hard Disk......................................................................................................................................................8

2.7 Password Setting ...................................................................................................................................................8

2.8 Examining DCCS Signal Transmission ..................................................................................................................9

..................................................................................................................................................5

3. USER INTERFACE........................................................................................................................ 10

3.1 DVR Access.........................................................................................................................................................10

3.2 Live Page .............................................................................................................................................................10

3.1.1 DVR Status ..................................................................................................................................................10

3.1.2 Channel Status. ...........................................................................................................................................11

3.1.3 Record-related Icons ...................................................................................................................................11

3.3 Quick Menu Bar ...................................................................................................................................................11

3.4 Main Menu ...........................................................................................................................................................12

4. FREQUENTLY-USED FUNCTIONS.............................................................................................. 13

4.1 Key Lock / Unlock ................................................................................................................................................13

4.2 User Level Creation .............................................................................................................................................13

4.3 PTZ Control..........................................................................................................................................................14

4.4 Playback ..............................................................................................................................................................15

4.4.1 Playback Control..........................................................................................................................................15

4.4.2 Event Search ...............................................................................................................................................16

4.4.3 Audio Playback ............................................................................................................................................16

4.5 Video Backup.......................................................................................................................................................16

4.6 Video Playback on PC (.dv5) ...............................................................................................................................17

4.6.1 Convert the file format to AVI .......................................................................................................................17

4.7 Digital Zoom.........................................................................................................................................................17

5. MAIN MENU .................................................................................................................................. 19

5.1 QUICK START .....................................................................................................................................................19

5.1.1 GENERAL ...................................................................................................................................................19

5.1.2 TIME SETUP ...............................................................................................................................................20

5.1.3 DAYLIGHT ...................................................................................................................................................21

5.2 SYSTEM ..............................................................................................................................................................21

5.2.1 ACCOUNT ...................................................................................................................................................21

5.2.2 TOOLS.........................................................................................................................................................22

5.2.3 SYSTEM INFO ............................................................................................................................................23

5.2.4 BACKUP DATA............................................................................................................................................24

5.2.5 BACKUP LOG .............................................................................................................................................26

5.3 EVENT INFORMATION .......................................................................................................................................27

5.3.1 QUICK SEARCH .........................................................................................................................................27

5.3.2 EVENT SEARCH.........................................................................................................................................27

5.3.3 HDD INFO ...................................................................................................................................................28

5.3.4 EVENT LOG ................................................................................................................................................28

5.4 ADVANCED CONFIG...........................................................................................................................................29

5.4.1 CAMERA .....................................................................................................................................................29

5.4.2 DETECTION................................................................................................................................................29

5.4.3 ALERT .........................................................................................................................................................30

5.4.4 NETWORK ..................................................................................................................................................31

5.4.5 DISPLAY......................................................................................................................................................34

5.4.6 RECORD .....................................................................................................................................................35

5.4.7 DEVICES.....................................................................................................................................................36

5.4.8 DCCS ..........................................................................................................................................................37

5.4.9 IVS...............................................................................................................................................................38

5.4.10 NOTIFY .....................................................................................................................................................42

5.5 SCHEDULE SETTING .........................................................................................................................................45

5.5.1 RECORD .....................................................................................................................................................45

5.5.2 DETECTION................................................................................................................................................46

5.5.3 ALARM ........................................................................................................................................................46

6. REMOTE OPERATION.................................................................................................................. 47

6.1 Supplied Licensed Software.................................................................................................................................47

6.1.1 Installation & Network Connection ...............................................................................................................47

6.1.2 Control Panel Overview ...............................................................................................................................48

6.1.3. General Operation ......................................................................................................................................50

6.1.4. E-Map .........................................................................................................................................................52

6.2 Web Browser .......................................................................................................................................................58

6.2.1 Event Playback & Download........................................................................................................................60

6.2.2 IVS Statistics................................................................................................................................................61

APPENDIX 1 SPECIFICATIONS....................................................................................................... 62

APPENDIX 2 PIN CONFIGURATION................................................................................................64

APPENDIX 3 PUSH VIDEO CONFIGURATION ............................................................................... 65

A3.1 PIN Connection .................................................................................................................................................65

A3.2 Configuration .....................................................................................................................................................67

APPENDIX 4 MOBILE SURVEILLANCE VIA EAGLEEYES............................................................ 68

A4.1 Prerequisites......................................................................................................................................................68

A4.2 Where to download............................................................................................................................................68

APPENDIX 5 SET PUSH VIDEO....................................................................................................... 70

A5.1 Prerequisite .......................................................................................................................................................70

A5.2 Enable Push Video ............................................................................................................................................70

A5.2.1 From iPhone / iPad....................................................................................................................................70

A5.2.2 From Android Mobile Device .....................................................................................................................71

APPENDIX 6 COMPATIBLE USB FLASH DRIVE LIST................................................................... 72

APPENDIX 7 COMPATIBLE SATA HDD LIST.................................................................................. 73

APPENDIX 8 MAIN MENU STRUCTURE.........................................................................................74

APPENDIX 9 DVR BATTERY REPLACEMENT............................................................................... 76

APPENDIX 10 DVD WRITER INSTALLATION................................................................................. 77

HARDWARE OVERVIEW

1. HARDWARE OVERVIEW

Note: The functions on the front panel and rear panel may vary, depending on the model you hav e .

1.1 Package Content

 Standard Package

 DVR  HDD screws

 Adapter & power cord  USB Mouse

 IR remote controller  Manual for IR remote controller

 Optional Accessories

 IR Receiver extension cable  CD manual

1.2 Front Panel

1) LED Indicators

DVR is powered on.

The hard disk is reading or recording.

An alarm is triggered.

Timer recording is on.

Under playback status.

2) CH1 ~ 16

Press the channel number buttons to select the channel to display.

Press to show the 4 channel display mode.

4) SEQ

Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it

will repeat from CH1 again. To exit this mode, press “SEQ” again.

5) SLOW

In the playback mode, press to show slow playback.

6) ZOOM

Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode.

7) PLAY

Press to playback the latest recorded data.

8) LIST (Event List Search)

Press to quickly search the recorded files by event types, or select FULL to show all the event logs.

To quickly search the time you want, select “QUICK SEARCH”. For details, please refer to “5.4.1 QUICK

SEARCH” in the user manual.

9) MENU

Press “MENU” to enter the main menu.

10) ENTER

Press “ENTER” to confirm the setting.

11)  (▲) /  (▼) /  (◄) /  (►)

Press ▲ / ▼ / ◄ / ► to move up / down / left / right.

In the playback mode:

Press “” to pause playback.

Press “” to stop playback.

Press ““ to fast forward.

Press ““ to fast rewind.

12) AUDIO (SLOW + ZOOM)

Press “SLOW” + “ZOOM” to select live or playback audio from audio channel 1~4.

Live audio from audio channel 1~4 (indicated in white).

Audio channel unselected

Playback audio from audio channel 1~4 (indicated in yellow).

13) P.T.Z. ( + SEQ)

Press “ ” + “SEQ” at the same time to enter / exit the PTZ control mode.

HARDWARE OVERVIEW

14) USB port

There are two USB ports on the front panel, one for connecting your USB mouse for mouse control, and the other

one for connecting your USB flash drive for video backup.

Note: It’s not allowed to have two USB mice or two USB flash drives connected on the front panel.

Note: For the compatible USB flash drive list, please refer to “APPENDIX 6 COMPATIBLE USB FLASH

DRIVE LIST” at page 72.

15) (For selected models only)

Press “ ” to eject the disk tray of the DVD writer.

1.3 Rear Panel

1) 75Ω / HI-IMPEDANCE (For selected models only)

When using VIDEO LOOP, switch to HI-IMPEDANCE. If not, switch to 75Ω.

2) VIDEO IN: Connect to the video connector of a camera.

VIDEO LOOP (For selected models only): Video output connector.

Note: The DVR will automatically detect the video system of the camera, please make sure that the

cameras are properly connected to the DVR and power-supplied before the DVR is turned on.

3) AUDIO IN (1~4)

Connect to the audio connector of a camera if the camera supports audio recording.

Note: To make a video backup with audio, make sure the camera which supports the audio function is

connected to the video-in channel and audio-in channel. For example, the audio data from audio CH1 will be recorded with the video data from video CH1. For 16CH models, the audio CH1 ~ CH4 are corresponding to video CH1 ~ CH4 respectively.

4) AUDIO OUT (1~2)

Connect to a speaker with 1 mono audio output.

5) CALL (For selected models only)

Connect to a monitor specific for sequence display.

6) HDMI

Connect to the HDMI port of the monitor which supports HDMI video output.

Note: Dual video outputs via both VGA and HDMI ports are supported.

7) VGA

Connect to the VGA port of the monitor which supports VGA video output.

Note: Dual video outputs via both VGA and HDMI ports are supported.

8) IR

Connect the IR receiver extension line for remote control.

HARDWARE OVERVIEW

9) eSATA

This port is used to connect a storage device supporting eSATA interface; for instance, an external hard disk or a

disk array.

Note: Please purchase a disk array supporting Linux system to ensure your DVR to work properly.

10) Push Video Alarm In (For selected models only)

Connect up to four external alarm devices for active event notifications to your smart phone (Push Video). The

four alarm inputs, 1 ~ 4, are corresponding to the four video inputs, CH1 ~ 4.

11) EXTERNAL I/O

This port is used to connect external devices (such as speed dome cameras or external alarm, etc).

12) LAN

Connect to Internet by LAN cable.

13) DC 19V IN

Connect to the supplied adapter.

14) Power Switch

Switch to “—” to turn on the power, and “” to turn off the power.

CONNECTION AND SETUP

2. CONNECTION AND SETUP

Before the DVR is powered on, make sure you have installed a hard disk, connected at least one camera and a

HDMI monitor. For details, please refer to the following sections.

Note: The DVR is designed to automatically detect the video system of the connected cameras (NTSC or

PAL). To make sure the system detection is correct, please check if the camera s are connected to the DVR and power-supplied before the DVR is powered on.

2.1 SATA Hard Disk Installation

A SATA hard disk must be installed before the DVR is powered on.

Note: It’s not recommended to use a green hard disk in this device. Please check our hard disk

compatible list at page 73.

Note: It’s recommended to clear all data in the hard disk when the DVR is powered on and the date &

time are set correctly to ensure the recorded data are not mixed with other data previously saved in the same hard disk. For details, please refer to “2.6 Clear Hard Disk” at page 8.

Step1: Loose the screws on the upper cover and open the upper cover of the DVR.

Note: The DVR cover is made of metal. Please be careful with its edge when you remove the cover.

Step2: There are two hard disk brackets for this DVR as

indicated in the right picture.

2-1 To install on the first bracket

Remove the bracket, and align the screw holes of the

bracket with the hard disk’s screw holes. Make sure the

PCB side of the hard disk is facing up.

Fasten the hard disk to the bracket, and connect the

power connector and data bus connector to the hard

disk. Then, replace the bracket to DVR.

2-2 To install on the second bracket

Connect the power connector and data bus connector

to the hard disk.

Align the screw holes of the bracket with the hard disk’s

screw holes. Make sure the PCB side of the hard disk is

facing up. Then, fasten the hard disk to the bracket.

Step3: Close the upper cover of the DVR, and fasten all the screws you loosened in Step1.

CONNECTION AND SETUP



2.2 Camera Connection

Install the camera on the wall or ceiling based on your installation environment and camera type. For installation

details, please refer to the user manual of your camera.

2.2.1 Normal / DCCS Camera

1) Connecting to DVR video input

Connect the camera video output to the DVR video input port with a coaxial cable or RCA line with a BNC

connector.

Note: For connecting a DCCS-type camera, make sure your DVR model supports DCCS, the camera is

connected to the 1st video channel (CH1), and the distance between the camera and DVR needs to be within 200 meters by using a 3C2V coaxial cable (112 braids) for DCCS control to take effects. For more details, please refer to “2.8 Examining DCCS Signal Transmission” at page 9.

2) Connecting to DVR audio input (Optional)

Connect the camera audio output to the DVR audio input port with a coaxial cable or RCA cable with BNC

connectors.

3) Connecting to power

Connect the camera with indicated power supply and make sure it’s power-supplied.

2.2.2 PTZ Camera

The following description is taking our brand’s PTZ camera as an example.

Note: The RS485 wiring is not needed when your DVR and PTZ camera both support DCCS, and the

video channel your PTZ camera connects is CH1. If yes, please go to STEP 5 directly for PTZ camera setting.

For detailed PIN / port connection, please refer to “APPENDIX 2 PIN CONFIGURATION” at page 64. For detailed

PTZ camera control and operation, please refer to its own user manual.

RJ11 cable 25 PIN D-Sub Connector

RS485-A: Red wire RS485-A: PIN 12

RS485-B: Green wire RS485-B: PIN 24

25-pin D-Sub connector

RS485 -A: PIN12 / RS485-B: PIN2 4

The RJ11 cable is not supplied in the sales package. The D-Sub connector is not supplied with the DVR package.

STEP 1: Get a RJ11 cable with the proper length to your connection.

Different RJ11 connector may have different wire layout, so the connection might be different. If you

cannot control the DVR after connection, please reverse the RJ11 cable connection with the DVR.

Solder Side o

1516171819202122232425 14

2345678910111213

STEP 2: Remove one end of the insulating coating of the RJ11 cable.

Remove one end of the insulating coating of the RJ11 cable to find the RS485-A and the RS485-B wires,

and remove the insulating coating to reveal the naked wires for further connection.

CONNECTION AND SETUP



STEP 3: Twist the RS485-A and RS485-B wires of the RJ11 cable and the speed dome camera together.

Twist the RS485-A (red) and RS485-B (green) wires of the RJ11 cable to the RS485-A (brown) and

RS485-B (orange) wires of the speed dome camera. To protect the naked wires, use the insulation tape

to cover on the twisted wires.

STEP 4: Connect the other end of the RJ11 cable to DVR.

Solder the RS485-A (red) and RS485-B (green) wires of the RJ11 cable to the corresponding pins on the

solder side of the 9 or 25 PIN D-Sub connector (as shown above).

STEP 5: Set the camera at the DVR side.

Right click to show the main menu in the live view, and go to “ ” (ADVANCED CONFIG)  “DEVICES” to set the camera.

a) Select the device to “PTZ”.

b) Set the ID to the value the same as the one set in the camera. The default ID of the camera is 000.

c) Select the protocol to “NORMAL”.

d) Set the baud rate to the value the same as the one set in the camera. The default baud rate of the

camera is 2400.

ADVANCED CONFIG

CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11  DETECTION

ALERT NETWORK DISPLAY RECORD

DEVICES

DCCS IVS NOTIFY

EXIT

DEVICE PTZ ID 000 PROTOCOL NORMAL RATE 2400

2.3 External Device Connection



 

This device supports external device connection with RS485 and alarm I/O ports, allowing users to connect

control devices such as a PTZ camera or keyboard controller, or connect alarm devices such as a magnetic

contact or buzzer.

Check the user manual of your external device to know which pin(s) should be used, and connect it to the

corresponding pins on the DVR rear panel.

Note: For more details about alarm I/O pin configurations, please refer to “APPENDIX 2 PIN

CONFIGURATION” at page 64.

Certain alarm-in pins also support sending instant event notifications to your mobile devices, such as iPhone, iPad

and Android mobile devices, for an alarm event (Push Video). For details, please refer to “APPENDIX 3 PUSH

VIDEO CONFIGURATION” at page 65.

CONNECTION AND SETUP

2.4 DVR Power On

This device should be operated only with the type of power source indicated on the manufacturer’s label. Connect

the indicated AC power cord to the power adapter, and plug into an electrical outlet. Then turn the power switch on

the rear panel to “—“. The power LED will be on.

Note: Before the DVR is powered on, make sure (1) the cameras are connected and power-supplied for

the detection of the camera video system to be correct, and (2) a HDMI monitor is connected to the DVR for correct video output detection.

Note: To ensure that your DVR works constantly and properly, it's recommended to use an UPS,

Uninterruptible Power Supply (Optional), for continuously operation.

2.5 Date and Time Setting

Before operating your DVR, please set the date and time on your DVR FIRST.

Note: Please DO NOT change the date or time of your DVR after the recording function is activated.

Otherwise, the recorded data will be disordered and you will not be able to find the recorded file to backup by time search. If users change the date or time accidentally when the recording function is activated, it’s recommended to clear all HDD data, and start recording again.

Note: For the first time to use the DVR, please power it on for at least 48 hours continuously after the

date & time is set correctly . It helps to prevent DVR time from resetting after the disconnecting of DVR power. If the DVR time resets after the disconnecting of DVR power, for example, caused by a power outage, the battery might run out and please replace the battery as described in “APPENDIX 9 DVR BATTERY REPLACEMENT” at page 76.

Right-click to enter the DVR password with the password keypad. The default administrator password is 0000.

The status will be changed from (key lock) to (unlock). Then, right-click to show the main menu, and

select (QUICK START)  “TIME SETUP” to set the date & time.

QUICK START

GENERAL DATE 2009 / NOV / 17

TIME SETUP TIME 15 : 35 : 53

DAYLIGHT

EXIT

CONNECTION AND SETUP

2.6 Clear Hard Disk

It’s recommended to clear all data in the hard disk for the first time to user this DVR to ensure the recorded data

are not mixed with other data previously saved in the same hard disk.

Right-click to show the main menu, and select (SYSTEM)  “SYSTEM INFO”  “CLEAR HDD”. The DVR

will reboot when hard disk data are cleared.

SYSTEM

ACCOUNT TOOLS

SYSTEM INFO

BACKUP DATA BACKUP LOG

EXIT

BAUD RATE 2400 HOST ID 000 R.E.T.R 5 AUTO KEY LOCK(S) NEVER CLEAR HDD HDD-0 RESET DEFAULT SUBMIT REMOTE CONTROL ID 000

SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1019-1008-1010-1010



  

2.7 Password Setting

Right-click to show the main menu, and select (SYSTEM)  “ACCOUNT” to change the default password of

SUPERVISOR.

There are four user levels for different access privileges: SUPERVISOR, POWER USER, NORMAL & GUEST.

For details, please refer to “4.2 User Level Creation” at page 13.

SYSTEM

ACCOUNT

TOOLS SYSTEM INFO BACKUP DATA BACKUP LOG

EXIT

USER LIST

USER NAME LEVEL admin SUPERVISOR power POWER USER normal NORMAL guest GUEST

ADD EDIT DEL

2.8 Examining DCCS Signal Transmission

Note: Needed only when the camera connected to CH1 supports DCCS.

Check the channel status bar of CH1, and see if the status icon of DCCS connection is “ ”.

 If yes, the connection is ok.

CONNECTION AND SETUP

 If you see “

- The distance between this DVR and the DCCS camera should not exceed 200 meters with a 3C2V coaxial cable (112 braids).

”, make sure:

Note: However, different materials used in 3C2V coaxial cables with different connection distance may

cause some effects for the availability and fluency of signal transmission.

- It’s not allowed to use a signal booster or modem to amplify signals and extend the connection distance.

USER INTERFACE

3. USER INTERFACE

3.1 DVR Access

Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( ) on the screen, indicating the USB mouse is detected properly.

Move your mouse to enter the DVR password with the password keypad. The default user name and password

are both “admin”. The status will be changed from (key lock) to (unlock).

Note: You may configure four different user levels to have different access privileges in “SYSTEM” 

“ACC OUNT”. For details, please refer to “4.2 User Level Creation” at page 13.

Password Input

3.2 Live Page

3.1.1 DVR Status

Note: Certain icons are for selected models only.

Key lock

Overwrite on

Internet disconnected

Local connection

USB flash drive / device connected

IVS on

Timer record on

PTZ mode on

Sequence mode on

Key unlock

Overwrite off

Internet connected

USB mouse connected

No USB device connected

Timer record off

PTZ mode off

Sequence mode off

3.1.2 Channel Status.

Note: Certain icons are for selected models only.

USER INTERFACE

Original size

Live audio on

Recording

Record mode: Frame

Virtual fence event

Fit to screen DCCS connection OK DCCS connection failed

Audio off

Human detection event Motion event Alarm event

Record mode: Field

One way pass event

Audio playback on

Record mode: CIF

Scene Change event

Audio playback off

3.1.3 Record-related Icons

1) Manual Recording

By defaults, manual recording is on ( ) when the DVR is powered on and a hard disk is installed.

2) Event Recording

The event icons, / / / / / , show on the channel status bar when their respective

events occur and the related record function is on.

3) Timer Recording

When timer recording is on, you will see “ ” on the screen.

4) HDD Overwritten

Be defaults, the HDD overwritten function is set to ON, and “

” will be shown on the screen.

Note: To disable this function, right click to display the main menu in the live view, and go to “

(ADVANCED CONFIG.)  “RECORD”  “OVERWRITE”.

3.3 Quick Menu Bar

Move to the arrow mark to extend the quick menu bar and show the five functions as follows:

Quick Menu: Open

Click to show the channel switch panel and select the channel you

want. For details, please refer to “3.2.1 Channel Switch” below.

Click to display the playback control panel, and click to play the

latest recorded video clip, or click

to enter the search list.

”

Switch to the channel you want first, and click to enter the zoom-in mode. In this mode, click and drag the red frame on the bottom left of the screen to move to the place you want to see. To exit this mode, click .

Click to show the power off panel to either halt or reboot the system.

3.4 Main Menu

Right-click anywhere on the screen to show the main menu as follows, and right-click again to exit.

Main Menu

USER INTERFACE

QUICK START

SYSTEM Click to set the system configurations.

Click to set the status display, image settings, and date & time.

EVENT INFORMATION Click to enter the event search menu.

Click to set CAMERA, DETECTION, ALERT,

ADVANCED CONFIG

SCHEDULE SETTING

* For selected models only

NETWORK, DISPLAY, RECORD, DEVICES, DCCS*, IVS* & NOTIFY*.

Click to set record timer, detection timer & alarm timer.

FREQUENTLY-USED FUNCTIONS

4. FREQUENTLY-USED FUNCTIONS

4.1 Key Lock / Unlock

To lock or unlock NVR local operation, click (unlock) or (lock) on the DVR status bar to change the

status to (lock) or (unlock).

To unlock NVR local operation, you’ll be prompted to enter the user name and password to access.

Note: The default user name and password are both “admin”, which is the highest user level.

Note: Different user level has different access privilege for certain DVR functions. Please refer to “4.2

User Level Creation” at page 13.

4.2 User Level Creation

Note: This function is available only for “SUPERVISOR ”.

To create different user account for different access privilege, click (SYSTEM)), and select “ACCOUNT” to enter “USER LIST”.

SYSTEM

ACCOUNT

TOOLS SYSTEM INFO BACKUP DATA BACKUP LOG

EXIT

Different user level has different access privilege for certain functions as described below:

USER LIST

USER NAME LEVEL admin SUPERVISOR power POWER USER normal NORMAL guest GUEST

ADD EDIT DEL

 DVR status

 Channel status

 Quick menu bar

Function User Level

Key lock / unlock

Live audio on / off

Playback audio on / off

Original size / Fit to screen

PTZ Control

Channel Selection

Playback

SUPERVISOR POWER NORMAL GUEST

   



 

   

  

Digital Zoom

Power

   



FREQUENTLY-USED FUNCTIONS

 Main menu

 Playback control

Function User Level

Quick Start

System

Event Information

Advanced Config.

Schedule Setting

Fast Forward

Fast Rewind

SUPERVISOR POWER NORMAL GUEST



  

Play / Pause

Stop

Slow Playback

Previous / Next Hour

Quick Search

  

4.3 PTZ Control

Note: This function is available only for “SUPERVISOR” and “POWER USER”. To know more details,

please refer to “4.2 User Level Creation” at page 13.

Click on the channel status bar to display the panel as follows:

/ / /

Up / Down / Left / Right

Digital zoom in / out

Click to move your selection up / down / left / right, or

change settings.

Click to zoom in / out the camera image digitally.

How to set a preset point:

Step1:

Focus near / far

Preset point

Click to adjust the focus of the image.

Click to display the preset point panel for preset point

viewing or setting. For details, please refer to the section below.

Step2: Click or to the proper ratio you need, and

click / / / to move to the point you

want to configure as a preset point.

Step3: Click the numbering you want to configure for this

point, and wait till you see (command sending)

appearing and disappearing on the DVR status bar.

Step4: Repeat from Step1 again to set other points if

needed, or click to return to the preset point

selection panel.

How to go to a preset point:

FREQUENTLY-USED FUNCTIONS

Step1:

Step2: Select the numbering within which saves the camera view you want to

see, and wait till you see (command sending) appearing and

disappearing on the DVR status bar.

4.4 Playback

Note: This function is NOT available for “GUEST”. please refer to “4.2 User Lev el Creation” at page 13.

Click “ ” on the quick menu bar to display the playback control panel, and click to play the latest recorded

video clip, or click to enter the search list.

Note: There must be at least 8192 images of recorded data for playback to work properly. If not, the

device will stop playback. For example, if the IPS is set to 30, the recording time should be at least 273 seconds (8192 images / 30 IPS) for the playback to work properly.

Note: During playback, the image size of the recording (FRAME , FIELD or CIF ) will be shown

on the screen.

4.4.1 Playback Control

Increase the speed for fast forward. Click once to get 4X speed forward and click

twice to get 8X speed, etc., and the maximum speed is 32X.

Increase the speed for fast rewind. Click once to get 4X speed rewind and click

twice to get 8X speed, etc., and the maximum speed is 32X.

Click to play the latest recorded video clip immediately, and click again to pause.

In the pause mode, click once to get one frame forward, and click to get one frame rewind. Click to stop the video playback.

Click once to get 1/4X speed playback, and click twice to get 1/8X speed

playback.

Fast Forward

Fast Rewind

Play / Pause

Stop

Slow Playback

Previous /

Click to jump to the next / previous time interval in an hour, for example, 11:00 ~

12:00 or 14:00 ~ 15:00, and start playing the earliest event video clip recorded

Next Hour

during this whole hour.

Click to set point A and point B in a video clip, and the system will play only the

Repeat

specified range in that clip.

Backup Click to open the backup menu for video backup.

FREQUENTLY-USED FUNCTIONS

4.4.2 Event Search

Click to quickly search the recorded files by event types, or select FULL to show all the event logs.

To quickly search the time you want, select “QUICK SEARCH”.

4.4.3 Audio Playback

In the playback mode, click or on the channel status bar to play or mute audio recording.

Note: To make a video backup with audio, or play a recording with audio, make sure the camera which

supports the audio function is connected to the video-in channel and audio-in channel. For example, the audio data from audio CH1 will be recorded with the video data from video CH1. For 16CH models, the audio CH1 ~ CH4 are corresponding to video CH1 ~ CH4 respectively.

4.5 Video Backup

Note: This function is available for “SUPERVISOR”. For details, please refer to “4.2 User Level Creation”

at page 13.

Note: Before using the USB flash drive, please use your PC to format the USB flash drive to F AT32 format

first. For the list of compatible USB flash drives, please refer to “APPENDIX 6 COMPATIBLE USB FLASH DRIVE LIST at page 72.

Note: Video backup could be made via the built-in DVD writer (optional), a USB flash drive, or the

Internet. It’s NOT allowed to connect the hard disk to your PC directly for it may impair the recorded data saved in the hard disk.

To copy recorded data for video backup, click (SYSTEM), and select “BACKUP DATA (USB)” or “BACKUP DATA (DVD)”.

SYSTEM

ACCOUNT TOOLS SYSTEM INFO

BACKUP DATA

BACKUP LOG

EXIT

START DATE 2009/NOV/19

START TIME 08:30:21

END DATE 2009/NOV/19

END TIME 17:59:29

CHANNEL 3 SELECTED

 ALL

 CH1

 CH2

 CH3

 CH4

 CH5

HARD DISK ALL HDD

OUTPUT FILE FORMAT AVI

TARGET D E VICE USB DEVICE

BACKUP SUBMIT

REQUIRE SIZE: 554MB SUBMIT

AVAILABLE SIZE: 3788.0MB







Step1: Select the time within which includes the video data you want to backup.

Step2: Select the channel(s) within which includes the video data you want to backup.

Step3: In “OUTPUT FILE FORMAT”, select the output video format: DEFAULT / AVI.

 When “DEFAULT” is selected, the copied video is saved to ".dv5”, and you can only open it with our own video

player on PC. For details, please check "4.6 Video Playback on PC”.

FREQUENTLY-USED FUNCTIONS

Note: It’s recommended to save the file to the default format for security reasons. Only specific video

player supports the default format and not everyone can see the video footage.

 When "AVI" is selected, the copied video will be converted to “avi”, and you can open it with any media player

which supports the “avi” format on PC.

Step4: In “TRAGET DEVICE”, select “USB DEVICE” or “DVD DEVICE” based on the device you want to use for

video backup.

Note: “DVD DEVICE” is available for selected models only.

Step5: In “REQUIRE SIZE”, select “SUBMIT” to know the file size of the selected data.

Step6: In “BACKUP”, select “SUBMIT” to start backup to your USB flash drive, and wait till the backup successful

message appears.

4.6 Video Playback on PC (.dv5)

For video backup with the format “.dv5”, you can only use our own player to play.

Note: It’s NOT allowed to remove the hard disk installed in the DVR and connect it directly to your PC to

check recorded video clips. It might impair the files saved in the hark disk, causing the loss of those files even when the disk is replaced back to the DVR.

To play “.dv5” video on your PC:

Step1: Insert the USB flash drive or CD / DVD with recorded data into your PC.

Note: The supported PC operating systems are Windows 7, Vista & XP.

Step2: Find the program “PLAYER.EXE” in the USB flash drive, and double-click it to install.

Note: “PLAYER.EXE” can also be downloaded from www.surveillance-download.com/user/c700.swf.

Step3: Run the program, VideoPlayer, and browse to where you save the recorded data.

Step4: Select the file you want to start video playback

4.6.1 Convert the file format to AVI

To convert the video file format to AVI, click “AVI” from the playback panel to start file conversion.

Note: The recorded audio (if any) will be removed when the file format is converted to AVI.

Note: If the backup video includes data for multiple channels, click to a specific channel for this function

to work properly.

4.7 Digital Zoom

Switch to the channel you want to zoom in, and move to the left side of the screen to show the quick start bar.

Click to enter the zoom-in mode. In this mode, click and drag the red frame on the bottom left of the screen to

move to the place you want to see.

To exit this mode, right-click anywhere on the screen.

Note: Y o u need to exit the zoom mode first to use other DVR functions.

FREQUENTLY-USED FUNCTIONS

5. MAIN MENU

5.1 QUICK START

5.1.1 GENERAL

QUICK START

GENERAL CHANNEL TITLE ON

TIME SETUP EVENT STATUS ON DAYLIGHT DATE DISPLAY ON BUTTON CONTROL DISPLAY ON MOUSE SENSITIVITY - ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀ +

RECORD CONFIG SETUP

EXIT

MAIN MENU

1) CHANNEL TITLE

Select to display the channel title or not (ON / OFF).

2) EVENT STATUS

Select to display the event icons or not (ON / OFF).

Note: For details about each event icon, please refer to “3.2 Live Page” at page 10.

3) DATE DISPLAY

Select to display the date or not (ON / OFF).

4) BUTTON CONTROL DISPLAY

Select to display the control icons on each single channel or not (ON / OFF).

5) MOUSE SENSITIVITY

Select the mouse sensitivity by 9 levels.

6) RECORD CONFIG

Click “SETUP” to enter the setting page individually for manual record, event record and timer record.

a) Select the record type you want to set.

b) In “CHANNEL”, select “ALL” to apply the changes here to all channels.

Note: The I.P.S. section is based on NTSC system.

QUICK START

MANUAL EVENT TIMER

CHANNEL IMAGE SIZE I.P.S. QUALITY ALL FRAME 480 SUPER BEST

EXIT

Or, select “BY CHANNEL” to set the image size, image per second & image quality individually for each

channel.

Note: The I.P.S. section is based on NTSC system.

QUICK START

MANUAL EVENT TIMER

CHANNEL IMAGE SIZE I.P.S. QUALITY CH1 960H 40 SUPER BEST CH2 CIF 30 SUPER BEST CH3 CIF 30 HIGH CH4 FIELD 15 SUPER BEST CH5 FRAME 15 SUPER BEST CH6 CIF 30 SUPER BEST CH7 CIF 30 HIGH CH8 FIELD 7.5 SUPER BEST NEXT

AVAILABLE IPS: CIF 705 / FIELD 352.5 / FRAME 176.25

APPLY EXIT

Note: The image size of 960H is available for selected models only.

5.1.2 TIME SETUP

MAIN MENU

QUICK START

GENERAL DATE 2009 / NOV / 17

TIME SETUP TIME 15 : 35 : 53

DAYLIGHT NTP SERVER tock.stdtime.gov.tw FORMAT Y/M/D SYNC PERIOD DAILY GMT (GMT+08:00)TAIPEI

EXIT

7) DATE

Set the current date. The default display format is YEAR – MONTH – DATE (Y-M-D).

8) TIME

Set the current time in HOUR : MIN : SEC.

9) NTP SERVER

Click to change the default NTP server to another server they’re familiar with, or keep the default NTP

server.

10) FORMAT

Select one date format from the following three options: Y/M/D, M/D/Y or D/M/Y.

11) SYNC PERIOD

Select to synchronize the NVR time everyday (DAILY), or turn this function off (OFF).

12) GMT

Select your time zone.

5.1.3 DAYLIGHT

QUICK START

GENERAL DAYLIGHT SAVING ON TIME SETUP

DAYLIGHT START TIME

1ST MON AUG 06:00 END TIME

LAST MON OCT 10:00 ADJUST 01:00

EXIT

Depending on the time zone you’re in:

1) DAYLIGHT SAVING

MAIN MENU

Select to enable (ON) or disable (OFF) this function.

2) START TIME / END TIME

Set the start time and end time.

3) ADJUST

Set the time in HOUR : MIN.

5.2 SYSTEM

5.2.1 ACCOUNT

This function is used to create a new user account, or modify or delete an existing account for different access

privilege.

Note: For details about available local operations of each user level, please refer to “4.2 User Level

Creation” at page 13.

ADVANCED CONFIG

ACCOUNT USER LIST

TOOLS USER NAME LEVEL SYSTEM INFO admin SUPERVISOR BACKUP DATA (USB) power POWER USER BACKUP LOG (USB) normal NORMAL guest GUEST

EXIT ADD EDIT DEL

5.2.2 TOOLS

SYSTEM

ACCOUNT LANGUAGE ENGLISH 

TOOLS UPGRADE SUBMIT

SYSTEM INFO NETWORK UPGRADE SUBMIT BACKUP DATA BACKUP CONFIG SUBMIT BACKUP LOG RESTORE CONFIG SUBMIT

EXIT

1) LANGUAGE

Select the language of the OSD.

2) UPGRADE

Save the upgrade files obtained from your installer or distributor in a compatible USB flash drive, and insert it

MAIN MENU

into the USB port at the front panel. Then, click “SUBMIT” to start upgrading.

Note: Before using the USB flash drive, please use your PC to format the USB flash drive to F AT32 format

first. For the list of compatible USB flash drives, please refer to “APPENDIX 6 COMPATIBLE USB FLASH DRIVE LIST” at page 72.

Note: After upgrading firmware, it’s recommended to clear all HDD data for the system to work more

stably. Before clearing all HDD data, please remember to make video backup.

3) NETWORK UPGRADE

Click “SUBMIT” for perform system upgrade via Internet.

Note: This function requires Internet access. Please make sure your DVR is connected to Internet before

using this function.

4) BACKUP CONFIG / RESTORE CONFIG

To keep the current configurations after DVR upgrade, insert a compatible USB flash drive into the USB port,

and select “SUBMIT” in “BACKUP CONFIG” to copy the current DVR configurations to a file “System.bin”

and save to your USB flash drive.

To restore the DVR configurations, insert the USB flash drive including “System.bin” to the USB port, and

select “SUBMIT” in “RESTORE CONFIG”.

5.2.3 SYSTEM INFO

SYSTEM

ACCOUNT BAUD RATE 2400  TOOLS HOST ID 000

SYSTEM INFO R.E.T.R 5 

BACKUP DATA AUTO KEY LOCK(S) NEVER  BACKUP LOG CLEAR HDD HDD-0  RESET DEFAULT SUBMIT REMOTE CONTROL ID 000

SERIAL TYPE RS485 VIDEO FORMAT NTSC VERSION 1010-1005-1006-1007

EXIT

1) BAUD RATE

Set the baud rate of the DVR (2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200).

MAIN MENU

2) HOST ID

Set the ID of the DVR (000 ~ 254).

3) R.E.T.R

Select the timeout in minute after which the R.E.T.R. function will be activated (3 / 5 / 10 / 30).

4) AUTO KEY LOCK(S)

Set the time-out in second after which the key lock function is activated (NEVER / 30 / 60 / 120).

5) CLEAR HDD

Select the HDD you want to clear, and click “YES” to confirm or “NO” to cancel.

It’s recommended to clear all data in the hard disk when:

 It’s the first time to use this DVR to ensure the recorded data are not mixed with other data previously saved in the

same hard disk.

 The DVR firmware is upgraded for the system to work more stably. Before clearing all HDD data, please remember

to make video backup.

 DVR date and time are changed accidentally when the recording function is activated. Otherwise, the recorded

data will be disordered and you will not be able to find the recorded file to backup by time search.

6) RESET DEFAULT

Click “SUBMIT” to reset all settings as default, and select “YES” to confirm or “NO” to cancel. The DVR will

reboot after reset.

7) REMOTE CONTROL ID

This function is available when users need to control two or more DVRs with one IR remote controller. The

ID set here is used to identify the DVR the remote controller is going to control. Please also read the user

manual of the IR remote controller for details.

8) SERIAL TYPE

Here shows the serial type of the DVR (RS-485).

9) VIDEO FORMAT

Here shows the information of the DVR video format (NTSC / PAL).

10) VERSION

Here shows the firmware version information.

MAIN MENU

5.2.4 BACKUP DATA

Note: It’s NOT allowed to remove the hard disk installed in the DVR and connect it directly to your PC to

check recorded video clips. It might impair the files saved in the hard disk, causing the loss of those files even when the disk is replaced back to the DVR.

Insert a compatible USB flash drive to the USB port at the front panel, or press to eject the DVD writer and

place a DVD-R or CD-R to it.

Note: Copying video footage to CD / DVD is available only for selected models.

Note: Before using the USB flash drive, please use your PC to format the USB flash drive to F AT32 format

first. For the list of compatible USB flash drives, please refer to “APPENDIX 6 COMPATIBLE USB FLASH DRIVE LIST” at page 72.

SYSTEM

ACCOUNT START DATE 2009/NOV/19 TOOLS START TIME 08:30:21 SYSTEM INFO END DATE 2009/NOV/19

BACKUP DATA END TIME 17:59:29

BACKUP LOG CHANNEL ALL  HARD DISK ALL HDD  OUTPUT FILE FORMAT DEFAULT TARGET DEVICE USB DEVICE BACKUP SUBMIT REQUIRE SIZE: 554MB SUBMIT

EXIT AVAILABLE SIZE: 3788.0MB

1) START DATE / START TIME

Select the start date & time.

2) END DATE / TIME

Select the end date & time.

3) CHANNEL

Click to select the channel(s).

4) HARD DISK

Select the hard disk containing the video data you need or “ALL HDD”.

5) OUTPUT FILE FORMAT

Select the file format for backup video: “DEFAULT” or “AVI”.

 When “DEFAULT” is selected, the copied video is saved to ".dv5”, and you can only open it with our own video

player on PC. For details, please check the next section, "Video Playback on PC”.

Note: It’s recommended to save the file to the default format for security reasons. Only specific video

player supports the default format and not everyone can see the video footage.

 When "AVI" is selected, the copied video will be converted to “avi”, and you can open it with any media player

which supports the “avi” format on PC.

6) TARGET DEVICE

Select the device you want to use for video backup: “USB DEVICE” or “DVD DEVICE”.

Note: “DVD DEVICE” is available for selected models only.

MAIN MENU

7) BACKUP

Click “SUBMIT” to start backup.

8) REQUIRE SIZE

To know the size of the expected backup video before backup, click “SUBMIT” to start calculating.

Video Playback on PC (.dv5)

For video backup with the format “.dv5”, you can only use our own player to play.

Note: It’s NOT allowed to remove the hard disk installed in the DVR and connect it directly to your PC to

check recorded video clips. It might impair the files saved in the hark disk, causing the loss of those files even when the disk is replaced back to the DVR.

To play “.dv5” video on your PC:

Step1: Insert the USB flash drive or CD / DVD with recorded data into your PC.

Note: The supported PC operating systems are Windows 7, Vista & XP.

Step2: Find the program “PLAYER.EXE” in the USB flash drive, and double-click it to install.

Note: “PLAYER.EXE” can also be downloaded from www.surveillance-download.com/user/c700.swf.

Step3: Run the program, VideoPlayer, and browse to where you save the recorded data.

Step4: Select the file you want to start video playback.

Convert the file format to AVI:

To convert the video file format to AVI, click “AVI” from the playback panel to start file conversion.

Note: The recorded audio (if any) will be removed when the file format is converted to AVI.

Note: If the backup video includes data for multiple channels, click to a specific channel for this function

to work properly.

MAIN MENU

5.2.5 BACKUP LOG

This function is used to backup the event log.

Insert a compatible USB flash drive to the USB port at the front panel.

Note: Before using the USB flash drive, please use your PC to format the USB flash drive to F AT32 format

first. For the list of compatible USB flash drives, please refer to “APPENDIX 6 COMPATIBLE USB FLASH DRIVE LIST” at page 72.

SYSTEM

ACCOUNT START DATE 2009/NOV/19 TOOLS START TIME 08:30:21 SYSTEM INFO END DATE 2009/NOV/19 BACKUP DATA (USB) END TIME 17:59:29

BACKUP LOG (USB) CHANNEL ALL 

DATA TYPE

BACKUP SUBMIT

EXIT

3 SELECTED

ALL



MANUAL 



MOTION



ALARM



SYSTEM



TIMER 





1) START DATE / START TIME

Select the start date & time.

2) END DATE / TIME

Select the end date & time.

3) CHANNEL

Click to select the channel(s).

4) DATA TYPE

Click “SETUP” to select the event type you want: MANUAL / MOTION / ALARM / SYSTEM / TIMER /

HUMAN DETECTION / INFLOW / OUTFLOW / VIRTUAL FENCE / ONEWAY / SENCE CHANGE, or select

“ALL” to choose all event types.

Note: Some events are available only for selected models.

5) BACKUP

Click “SUBMIT” to start backup. You’ll see a log file (.csv) in the flash drive. You may open it with any txt

editor, such as NotePad.

MAIN MENU

5.3 EVENT INFORMATION

5.3.1 QUICK SEARCH

EVENT INFORMATION

QUICK SEARCH HARD DISK ALL HDD 

EVENT SEARCH HDD INFO

EVENT LOG 2009 NOV SUN MON TUE WED THU FRI SAT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

22 23 24 25 26 27 28 29 30

EXIT

CHANNEL 2 SELECTED

00 06 12 18 24

15 : 20 SUBMIT



Step1: Select the hard disk and channel including the video data you want to search.

Step2: Select the year and month including the video data you want to search from the calendar, and the date with

recorded data will be highlighted.

Note: To select the year and month, move your mouse to the display bar. Then, click and hold to drag up

or down.

Step3: Select the date you want from the calendar, and the time with recorded data will be highlighted from the

time scale bar.

Step4: To immediately play the video clip, click “SUBMIT”.

To choose the start time for video playback, move your mouse cursor to the highlighted time, and click to

confirm the time when the time display below is the time you want. The video playback is activated right

away when you confirm the time.

Note: For video playback operations, please refer to “4.4 Playback” at page 15.

5.3.2 EVENT SEARCH

EVENT INFORMATION

QUICK SEARCH DATE 2009/NOV/19

EVENT SEARCH TIME 16:13:16

HDD INFO CHANNEL 1  EVENT LOG

EVENT TYPE MOTION  SEARCH START

EXIT

HARD DISK ALL HDD



1) DATE / TIME

Select the specific time period that you want to search.

2) CHANNEL

Select the video channel you want to search.

3) HARD DISK

Select the hard disk including the video data you want to search, or select “ALL HDD”.

MAIN MENU

4) EVENT TYPE

Select the event type you want to search, or select “ALL” to choose all events.

Note: Some events are available only for selected models.

5) SEARCH

Click “START” to start search and play the video data immediately.

5.3.3 HDD INFO

You can check the remaining capacity of the connected HDD in this device.

EVENT INFORMATION

QUICK SEARCH NUMBER MODEL TEMP. EVENT SEARCH HDD-0 ST31000526SV

HDD INFO

EVENT LOG

EXIT

46 890.562GB 864.832GB 2011/DEC/13 18:18:53 9V0DN5WS ST31000526SV

SIZE FREE FORMAT TIME SERIAL NUMBER

F.W.

5.3.4 EVENT LOG

You can check all system events (SYSTEM) and backup logs (BACKUP), or clear all log records.

EVENT INFORMATION

QUICK SEARCH SYSTEM BACKUP EVENT SEARCH EVENT TIME COMMENT HDD INFO KEY UNLOCK 2009/NOV/19 15:49:07

EVENT LOG VIDEO LOSS 2009/NOV/19 15:32:05 04

POWER ON 2009/NOV/19 15:32:02

PREV NEXT CLEAN

EXIT

5.4 ADV ANCED CONFIG

5.4.1 CAMERA

ADVANCED CONFIG

CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11  

DETECTION BRIGHTNESS 128 ALERT CONTRAST 128 NETWORK SATURATION 128 DISPLAY HUE 128 RECORD COV. OFF DEVICES REC ON DCCS CHANNEL TITLE CH1 IVS NOTIFY

EXIT

1) BRIGHTNESS / CONTRAST / SATURATION / HUE

MAIN MENU

Click the current value to manually adjust the brightness/contrast/saturation/hue of each channel here. .

2) COV.

Select if you want to mask the selected channel under recording (ON / OFF). When this function is activated,

the wording “COV.” will be shown on the channel screen.

Note: T o hide the wording “C OV.” When this function is on, go to “DISPLA Y”, and set “DISPLAY COVER T”

to “OFF”. For details, please refer to “5.4.5 DISPLAY” at page 34.

3) REC

Select if you want to enable recording for the selected channel (ON / OFF).

Note: When this function is disabled, no manual, event or timer recording will be activated even if any

of these three record functions is set to “ON”.

4) CHANNEL TITLE

Click the channel title column to change the channel title (up to 12 characters). The default title is the

channel number.

5.4.2 DETECTION

ADVANCED CONFIG

CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11  

DETECTION LS 07

ALERT SS 03 NETWORK TS 02 DISPLAY MOTION OFF RECORD ALARM OFF DEVICES AREA EDIT DCCS IVS NOTIFY

EXIT

1) LS (Level of Sensitivity)

“LS” is to set the sensitivity of comparing two different images. The smaller the value is, the higher sensitivity

for motion detection. The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default

value is 07.

MAIN MENU

2) SS (Spatial Sensitivity)

“SS” is to set the sensitivity for detecting the size of one object (the number of the grids) on the screen. The

smaller the value is, the higher sensitivity for motion detection.

The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default setting is 03.

Note: The default setting of SS is 03, which means once an object is detected more than 3 grids, the

system will get triggered. So the value of SS must be less than the number of grids that you set up for the motion detection area.

3) TS (Time of Sensitivity)

“TS” is to set the sensitivity regarding how long one object stays in the detection area and triggers the

recording. The smaller the value is, the higher sensitivity for motion detection.

The highest sensitivity setting is 00, and the lowest sensitivity setting is 15. The default setting is 02.

4) MOTION

Select if you want to activate the motion detection function for the selected channel (ON/OFF).

5) ALARM

Select N.C./ N.O depending on your installation need. The default alarm value is OFF.

6) AREA

Click “EDIT” to set the motion detection area.

There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being

detected while the transparent blocks are the area under detection.

5.4.3 ALERT

ADVANCED CONFIG

CAMERA EXT. ALERT ON DETECTION INT. BUZZER OFF

ALERT KEY BUZZER ON

NETWORK VLOSS BUZZER ON DISPLAY MOTION BUZZER ON RECORD ALARM BUZZER ON DEVICES HDD BUZZER ON DCCS ALARM DURATION (SEC) 5  IVS HDD NEARLY FULL (GB) 5  NOTIFY HDD OVERHEAT ALERT (°C) 60 

EXIT

1) EXT. ALERT

Select to enable or disable the sound when any external alarm is triggered (ON / OFF).

2) INT. BUZZER

Select to enable or disable the sound (ON / OFF) for all internal buzzers: KEY BUZZER, VLOSS BUZZER,

MOTION BUZZER, ALARM BUZZER, and HDD BUZZER.

Note: When this item is set to “OFF” , item 3) to item 7) will be dis abled even though they are set to ON.

3) KEY BUZZER

Select to enable or disable the sound when pressing the buttons on the front panel (ON / OFF).

4) VLOSS BUZZERD

Select to enable or disable the sound when video loss happened (ON / OFF).

5) MOTION BUZZER

Select to enable or disable the sound when any motion alarm is triggered (ON / OFF).

6) ALARM BUZZER

Select to enable or disable the sound when any internal alarm is triggered (ON / OFF).

7) HDD BUZZER

Select to enable or disable the sound (ON / OFF) when the HDD remaining capacity reaches to the value set

in “HDD NEARLY FULL (GB)”.

MAIN MENU

8) ALARM DURATION (SEC)

Select the duration time for alarm buzzer in second (5 / 10 / 20 / 40).

9) HDD NEARLY FULL (GB)

If HDD BUZZER is enabled, select the duration time for buzzer notifications when the hard disk available

capacity is 5/10/15/20 GB left.

10) HDD OVERHEAT ALERT (°C)

Select the temperature alert for your hard disk to be aware of the possible overheat of your hard disk.

5.4.4 NETWORK

NETWORK



SSTTAATTIICC

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION NETWORK TYPE STATIC  ALERT IP 192.168.001.010

NETWORK GATEWAY 192.168.001.254

DISPLAY NETMASK 255.255.255.000 RECORD PRIMARY DNS 168.095.001.001 DEVICES SECONDARY DNS 139.175.055.244 DCCS PORT 0080 IVS APPLY NOTIFY

EXIT MAC: 00:0E:53:EC:A7:B4

1) NETWORK TYPE

Select the network type as STATIC and set all the information needed in the DVR.

2) NETWORK INFORMATION (IP / GATEWAY / NETMASK)

Key in all the network information obtained from your ISP (Internet Service Provider).

3) DNS (PRIMARY DNS / SECONDARY DNS)

Key in the IP address of the domain name server obtained from your ISP (Internet Service

Provider).

4) PORT

The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by

HTTP is 80. However in some cases, it is better to change this port number for added flexibility or

security.

MAIN MENU



PPPPPPOOEE

Note: When PPPOE configuration is completed, please move to “DDNS” to configure the DDNS service.

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION NETWORK TYPE PPPOE  ALERT IP 192.168.001.010

NETWORK GATEWAY 192.168.001.254

DISPLAY NETMASK 255.255.255.000 RECORD PRIMARY DNS 168.095.001.001 DEVICES SECONDARY DNS 139.175.055.244 DCCS PORT 0080 IVS USER NAME OFFICE NOTIFY PASSWORD ●●●●●●

EXIT MAC: 00:0E:53:EC:A7:B4

1) NETWORK TYPE

Select the network type as PPPOE and set all the information needed in the DVR.

2) DNS (PRIMARY DNS / SECONDARY DNS)

Key in the IP address of the domain name server obtained from your ISP (Internet Service

Provider).

3) PORT

The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by

HTTP is 80. However in some cases, it is better to change this port number for added flexibility or

security.

4) USER NAME / PASSWORD

Set “username” and “password” subscribed from your ISP supplier



DDHHCCPP

Note: When DHCP configuration is completed, please move to “DDNS” to configure the DDNS service.

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION NETWORK TYPE DHCP  ALERT IP 192.168.001.010

NETWORK GATEWAY 192.168.001.254

DISPLAY NETMASK 255.255.255.000 RECORD PRIMARY DNS 168.095.001.001 DEVICES SECONDARY DNS 139.175.055.244 DCCS PORT 0080 IVS NOTIFY

EXIT MAC: 00:0E:53:EC:A7:B4

1) NETWORK TYPE

Select the network type as DHCP.

2) DNS (PRIMARY DNS / SECONDARY DNS)

Key in the IP address of the domain name server obtained from your ISP (Internet Service

Provider).

3) PORT

The valid number ranges from 1 to 9999. The default value is 80. Typically, the TCP port used by

HTTP is 80. However in some cases, it is better to change this port number for added flexibility or

security.

MAIN MENU

FTP

When this function is enabled and an event occurs, a html file including a link will be sent to the specified FTP site.

Click the link to access to this DVR and check the event recording.

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION FTP ALERT ON ALERT USER NAME MANAGER

NETWORK PASSWORD ●●●●●●

DISPLAY SERVER 192.168.2.32 RECORD PORT 0021 DEVICES DIRECTORY UPLOAD DCCS IVS NOTIFY

EXIT

E-MAIL

When this function is enabled and an event occurs, a html file including a link will be sent to the specified E-mail

address. Click the link to access to this DVR and check the event recording.

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION E-MAIL ALERT ON ALERT SMTP SERVER SMTP.GMAIL.COM

NETWORK PORT 465

DISPLAY MAIL FROM MANAGER RECORD SSL ENCRYPTION ON DEVICES VERIFY PASSWORD ON DCCS USER NAME MANAGER IVS PASSWORD ●●●●●● NOTIFY RECEIVER SETUP

EXIT

1) E-MAIL ALERT

Select “ON” to enable this function, or “OFF” to disable this function.

2) SMTP SERVER

Enter the SMTP server address provided from your e-mail system supplier.

3) PORT

Enter the port number provided from your e-mail system supplier. If this column is left blank, the e-mail

server will use port 25 to send e-mails.

4) MAIL FROM

Enter the sender’s name.

5) SSL ENCRYPTION

Select “ON” if your e-mail server is using SSL encryption to protect your e-mail content from unauthorized

access.

6) VERIFY PASSWORD

Some mail servers are required to verify the password. Please enter the “user name” and “password”.

7) USER NAME / PASSWORD

Enter the “user name” and “password” when “VERIFY PASSWORD” is set to “ON”.

8) RECEIVER

Select “SETUP” to add up to 15 e-mail addresses of the assigned recipients.

MAIN MENU

DDNS

You need to additionally set DDNS when your network type is PPPOE or DHCP.

We have our own DDNS server for quick DDNS service configuration. You don’t need to additionally apply a

DDNS service.

 To use our own DDNS server, select “eagleeyes” in “SYSTEM NAME”.  The default host name is the MAC address of the DVR.

Then, note down the whole address under “CURRENT HOST ADDRESS”, such as

MAC000E53ECA7B4.ddns.eagleeyes.tw. This is the default IP address used to access your DVR remotely.

Note: Please at least use the default address to access your DVR remotely once. This is to ensure our

DDNS server has your DVR registered. Then, you may change the host name to a more meaningful name to memorize later here.

 (Optional) Enter your email address to receive our DDNS server notification if any.

Note: If you want to additionally apply a DDNS service instead of using ours, please refer to

www.surveillance-download.com/user/CMS.pdf and check “Appendix 2” for details.

ADVANCED CONFIG

CAMERA WAN FTP E-MAIL DDNS DETECTION DDNS ON ALERT SYSTEM NAME eagleeyes 

NETWORK HOST NAME MAC000E53ECA7B4

DISPLAY EMAIL EMPTY RECORD DEVICES DCCS IVS NOTIFY

CURRENT HOST ADDRESS

EXIT MAC000E53ECA7B4.ddns.eagleeyes.tw

5.4.5 DISPLAY

ADVANCED CONFIG

CAMERA FULL SCREEN DURATION 03  DETECTION QUAD SCREEN DURATION 03  ALERT CALL SCREEN DURATION (For selected models only) 03  NETWORK DISPLAY COVERT ON

DISPLAY HDD DISPLAY MODE REMAINING SIZE 

RECORD DISPLAY OUTPUT AUTO  DEVICES DCCS IVS NOTIFY

EXIT

1) FULL SCREEN DURATION

Select the full screen dwell duration time in second (03 / 05 / 10 / 15).

2) QUAD SCREEN DURATION

Select the quad screen dwell duration time in second (03 / 05 / 10 / 15).

3) CALL SCREEN DURATION (For selected models only)

Select the duration time in second for the CALL monitor function (03 / 05 / 10 / 15).

4) DISPLAY COVERT

Select “ON” or “OFF” to display or hide the wording “COV.” When covert recording is activated in

“CAMERA”.

MAIN MENU

5) HDD DISPLAY MODE

Select “REMAINING SIZE” to show the remaining HDD capacity for recording in GB, “REMAINING TIME” to

show the remaining recording time, or “DAYS KEPT” to show how many recording data are saved in day.

6) DISPLAY OUTPUT

Select the display resolution you want. There are four options as follows:

 AUTO (default)  1920 x 1080  1024 x 768  1366 x 768

Note: T o have the best image qualit y on your monitor, make sure (1) the selected DVR output resolution

is supported by your monitor, and (2) the output settings on both the L CD monitor and DVR are consistent. If the image is not positioned or scaled properly , please go to your monitor’s menu for adjustment. For details, please refer to the user manual of your monitor.

5.4.6 RECORD

Note: Please DO NOT change the date or time of your DVR after the recording function is activated.

ADVANCED CONFIG

CAMERA MANUAL RECORD ON DETECTION EVENT RECORD ON ALERT TIMER RECORD ON NETWORK PRE-ALARM RECORD ON DISPLAY OVERWRITE ON

RECORD KEEP DATA LIMIT (DAYS) OFF 

DEVICES RECORD CONFIG SETUP DCCS IVS NOTIFY

EXIT

1) MANUAL RECORD

Set the manual recording function on / off.

2) EVENT RECORD

Set the event recording function on / off.

3) TIMER RECORD

Set the timer recording function on / off.

4) PRE-ALARM RECORD

Select to enable or disable the pre-alarm function (ON / OFF).

When pre-alarm and event recording functions are both activated, the DVR will record 8MB data before an

alarm / motion event is triggered.

5) OVERWRITE

Select “ON” to overwrite previous recorded data in your hard disk when the hard disk is full. When this

function is on and the hard disk is full, the DVR will clear 8GB data from the oldest for continuous recording

without notice.

6) KEEP DATA LIMITS (DAYS)

Assign the maximum recording days from 01 to 31 after which all the recorded data will be removed, or

select “OFF” to disable this function.

7) RECORD CONFIG

Click “SETUP” to enter the setting page individually for manual record, event record and timer record.

For details, please refer to “5.1.1 GENERAL” at page 19.

5.4.7 DEVICES

ADVANCED CONFIG

CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11   DETECTION DEVICE PTZ  ALERT ID 00 NETWORK PROTOCOL NORMAL  DISPLAY RATE 2400  RECORD

DEVICES

DCCS IVS NOTIFY

EXIT

MAIN MENU

1) DEVICE

For the PTZ camera, select “PTZ”.

For a zoom lens control camera:

The DVR will detect it automatically and display its model number here. To configure the parameters for a zoom lens control camera, please refer to “5.4.8 DCCS” at page 37. Different zoom lens control

came

ras might have different parameter settings. For details, please refer to their own user manuals.

2) ID

Click the current value to set the ID number (0 ~ 255) for the connected PTZ camera if necessary.

Make sure the ID setting of the camera is the same as the setting here, or the DVR will not be able to control

the device.

Note: To know the default ID of the PTZ camera, please refer to its user manual.

3) PROTOCOL

Select NORMAL (our protocol), P-D (PELCO-D) or P-P (PELCO-P) protocol.

4) RATE

Select the baud rate for the connected PTZ camera (2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200).

Make sure the baud rate setting of the camera is the same as the setting here, or the DVR will not be able to

control the device.

Note: To know the default baud rate of the PTZ camera, please refer to its user manual.

MAIN MENU

5.4.8 DCCS

Note: This function is for selected models only.

Note: DCCS is supported only for CH1. Make sure you’ve connected a DCCS-enabled camera to the

video channel of CH1, and you see “ ” in the channel status bar.

ADVANCED CONFIG

CAMERA CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11   DETECTION DIAGNOSTIC START ALERT MENU SETUP NETWORK DISPLAY RECORD DEVICES DEVICE AVK523

DCCS CONNECTION OK

IVS NOTIFY

EXIT

1) DIAGNOSTIC

Click “START” to start examining the DCCS signal transmission between the DVR and the camera. The

result will display in “CONNECTION”.

2) MENU

Click “SETUP” to configure the connected zoom lens control camera.

Different zoom lens control cameras might have different parameter settings. For details, please refer to their

own user manuals.

Note: While configuring the camera parameters, the DVR will switch to the corresponding cha nnel, and

you can simultaneously preview the effects for the settings.

3) DEVICE

Here shows the model number of the camera.

4) CONNECTION

Here shows the examining result for DCCS signal transmission between the DVR and camera. The

message is as follows:

MESSAGE SHOWN MEANING

CHECKING The DVR is checking the DCCS signal transmission between the DVR and camera.

OK The signal transmission is fine and the DCCS function works properly.

FAIL The signal transmission is too weak or not available for the DCCS function to work properly.

MAIN MENU

5.4.9 IVS

Note: This function is for selected models only.

Note: Before using the IVS function, make sure the event record function is enabled on your DVR.

IVS, Intelligent Video Surveillance, is the advanced application for motion detection, but more precise and smarter.

It can be applied to different situations with one of the following three modes: FLOW COUNTING, VIRTUAL

FENCE, and ONE WAY.

When anyone crosses the detection line (virtual fence), the recording will be on.

Note: Four camera channels are supported for this function.

ADVANCED CONFIG

CAMERA IVS1 IVS2 IVS3 IVS4 DETECTION CAMERA CH3  ALERT IVS MODE FLOW COUNTING  NETWORK DISPLAY LINE OFF  DISPLAY SENSITIVITY 07 RECORD RESET COUNT SUBMIT DEVICES VIRTUAL FENCE AREA SETUP DCCS SCENE CHANGE OFF 

IVS SCENE CHANGE LEVEL MIDDLE 

NOTIFY

EXIT

1) CAMERA

Select the camera channel that you want to use the IVS function.

2) IVS MODE

Select one of the following three modes depending on your environment:

MODE DESCRIPTION

FLOW COUNTING A virtual detection line is set to detect the moving direction of pedestrians for flow counting.

VIRTUAL FENCE A virtual detection line is set to detect intruders crossing the detection line, and an alarm will be

triggered.

ONE WAY A virtual detection line is set to detect intruders from the specified direction, and an alarm will be

triggered.

3) DISPLAY LINE

Select to display the detection line for IVS on the screen or not.

4) SENSITIVITY

Set the sensitivity for IVS from 00 ~ 15. The larger the value, the more sensitive the IVS will be.

5) RESET COUNT

Click “SUBMIT” to reset the flow counting number to 0 when the IVS mode is set to “FLOW COUNTING” and

activated.

6) VIRTUAL FENCE AREA

Click “SETUP” to draw the detection line for IVS, and set the detection direction from left to right, or right to

left. This area setting is the detection base for IVS MODE.

Note: There are some tips to draw the detection line. For details, please check

www.surveillance-download.com/user/IVS_setup.pdf.

7) SCENE CHANGE

Select “ON” to trigger a motion event when the camera is sensed to be moved and the camera scene is

changed. At the same time, the icon “ ” will be also shown on the screen in addition to the motion icon

“ ”.

8) SCENE CHANGE LEVEL

Set the detection sensitivity for “SCENE CHANGE” to “HIGH”, “MIDDLE” or “LOW”.

IVS APPLICATION

MAIN MENU



FFLLOOWW CCOOUUNNTTIINNGG

Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the

detection direction by selecting “REVERSE”.

Step2: Finish the IVS setting and return to the live view. The IVS icon “ ” will be shown on the status bar.

Click it to show the flow counting panel as follows.

When anyone walks across the detection line, the system will determine his movement is in or out, and add one count to the corresponding channel on the flow counting panel.

IN OUT

People coming from the opposite direction to the arrow mark.

People coming from the same direction as the arrow mark.

MAIN MENU



VVIIRRTTUUAALL FFEENNCCEE aanndd OONNEE WWAAYY

Step1: Go to “VIRTUAL FENCE AREA” to draw a detection line with your mouse, and decide the

detection direction by selecting “REVERSE”.

Step2: Finish the IVS setting and return to the live view.

When anyone walks across the detection line, the system will determine his movement is in or out,

and:

VIRTUAL FENCE

ONE WAY An event happens for anyone walking from the opposite direction to the

An event happens for anyone walking across the detection line, and “ ”

will be shown on the screen.

arrow mark, and “ ” will be shown on the screen.

IVS STATISTICS

Press “LIST” on the DVR front panel, or click “ ”  “ ” to enter the event search menu. Then, select

“STATISTIC”

LIST

QUICK SEARCH RECORD MOTION ALARM TIME HUMAN DETECTION IVS FULL

STATISTIC

EXIT

CHANNEL 3 SELECTED      

EVENT TYPE 3 SELECTED      

TIME 2010/MAY/17 STATISTIC SUBMIT

ALL

CH1  CH2 CH3 CH4 CH5 

ALL

INFLOW  OUTFLOW VIRTUAL FENCE ONEWAY MOTION 



MAIN MENU

Set all the criteria you want to search, and click “SUBMIT” in “STATISTIC” to show the event statistics by

DAY in LIST (default) or CHART.

 To check the statistics in the bar chart, click “CHART”.

 To switch to the MONTH or HOUR view, click “DAY” at the bottom.

List View

IVS STATISTIC

LIST CHART  HOUR COUNT 00:00 – 00:59 0 01:00 – 01:59 0 02:00 – 02:59 0 03:00 – 03:59 0 04:00 – 04:59 0 05:00 – 05:59 10 06:00 – 06:59 0 07:00 – 07:59 0 08:00 – 08:59 5 09:00 – 09:59 0  2010/MAY/17 DAY EXIT

MAIN MENU

Chart View

IVS STATISTIC

LIST CHART 

COUNT

2010/MAY/17 DAY EXIT

0 1 2 3 4 5 6 7 8

HOUR 

5.4.10 NOTIFY

You can configure this DVR to send notifications for certain events to mobile devices with our mobile app,

EagleEyes, installed, or to the specified E-mail address(es).

PUSH VIDEO

Note: This function is for selected models only.

Before using this function, make sure:

 An external alarm is connected to PUSH VIDEO Alarm in terminal on the rear panel.  You have a iPhone, iPad, or Android mobile phone or tablet.  You have subscribed the mobile network service from your mobile service provider.  The mobile app, EagleEyes, is installed in your mobile device. For details, please refer to “APPENDIX 4 MOBILE SURVEILLANCE

VIA

EAGLEEYES” at page 68.



You have configured EagleEyes to access this DVR, and Push Video is enabled. For details, please refer to “APPENDIX 5 SET

PUSH VIDE

You’ll get an active event notification with video telling you the occurrence of alarm event(s).

O” at page 70.

ADVANCED CONFIG

CANERA DETECTION ALERT NETWORK DISPLAY RECORD DEVICES DCCS IVS

NOTIFY

EXIT

PUSH VIDEO PUSH MESSAGE MESSAGE MAIL VIDEO MAIL

GUARD ON CH01 ALARM OFF / INTERNAL ALARM  CH1 CH02 ALARM OFF  CH2 CH03 ALARM N.O.  office CH04 ALARM OFF  CH4

1) GUARD

Select to enable or disable Push Video function (ON / OFF).

Select to activate the Push Video function (ON / OFF). Or it could also be activated later from your iPhone,

iPad or Android mobile device.

Note: For details about DVR operations from your mobile device, please visit

http://www.eagleeyescctv.com.

2) ALARM TYPE

Select the external alarm type to “ALARM NO.” or “ALARM N.C.”

For CH01, there’s one more option of “INTERNAL ALARM”. This option should be selected only when the

camera connected to CH1 is a human detection camera.

MAIN MENU

3) CH1 ~ 4

Enter the text you want to see when your iPhone, iPad or Android mobile device receives Push Video. The

default text is the channel number.

PUSH MESSAGE

Note: This function is for selected models only.

Before using this function, make sure:

 You have iPhone, iPad, or Android mobile phone or tablet.  You have subscribed the mobile network service from your mobile service provider.

 The mobile app, EagleEyes, is installed in your mobile device. For details, please refer to “APPENDIX 4 MOBILE SURVEILLANCE

EAGLEEYES” at page 68.

VIA



You have configured EagleEyes to access this DVR, and Push Video is enabled. For details, please refer to “APPENDIX 5 SET

PUSH VIDE

You’ll get a text message telling you the occurrence of selected system event(s).

CANERA DETECTION ALERT NETWORK DISPLAY RECORD DEVICES DCCS IVS

NOTIFY

EXIT

O” at page 70.

ADVANCED CONFIG

PUSH VIDEO PUSH MESSAGE MESSAGE MAIL VIDEO MAIL ACTION ON EVENT  ALL  VIDEO LOSS  HDD FULL  POWER ON  CLEAR HDD  NET LOGIN  KEY UNLOCK  NETWORK  UPS  SYSTEM ABNORMAL

Step1: Switch “ACTION” to “ON”.

Step2: Select the system event(s) you want to get notified via your mobile device.

Step3: Enable “Push Message” in EagleEyes on your mobile device, and try to trigger an alarm event to see if

you’ll get Push Message.

AGI Security SYS-16A901 User Manual [en, fr, es, de]

Specifications and Main Features

Frequently Asked Questions

User Manual

1. HARDWARE OVERVIEW

1.1 Package Content

1.2 Front Panel

1.3 Rear Panel

2. CONNECTION AND SETUP

2.1 SATA Hard Disk Installation

2.2 Camera Connection

2.2.1 Normal / DCCS Camera

2.2.2 PTZ Camera

2.3 External Device Connection

2.4 DVR Power On

2.5 Date and Time Setting

2.6 Clear Hard Disk

2.7 Password Setting

2.8 Examining DCCS Signal Transmission

3. USER INTERFACE

3.1 DVR Access

3.2 Live Page

3.1.1 DVR Status

3.1.2 Channel Status.

3.1.3 Record-related Icons

3.3 Quick Menu Bar

3.4 Main Menu

4. FREQUENTLY-USED FUNCTIONS

4.1 Key Lock / Unlock

4.2 User Level Creation

4.3 PTZ Control

4.4 Playback

4.4.1 Playback Control

4.4.2 Event Search

4.4.3 Audio Playback

4.5 Video Backup

4.6 Video Playback on PC (.dv5)

4.6.1 Convert the file format to AVI

4.7 Digital Zoom

5. MAIN MENU

5.1 QUICK START

5.1.1 GENERAL

5.1.2 TIME SETUP

5.1.3 DAYLIGHT

5.2 SYSTEM

5.2.1 ACCOUNT

5.2.2 TOOLS

5.2.3 SYSTEM INFO

5.2.4 BACKUP DATA

Video Playback on PC (.dv5)

5.2.5 BACKUP LOG

5.3 EVENT INFORMATION

5.3.1 QUICK SEARCH

5.3.2 EVENT SEARCH

5.3.3 HDD INFO

5.3.4 EVENT LOG

5.4 ADV ANCED CONFIG

5.4.1 CAMERA

5.4.2 DETECTION

5.4.3 ALERT

5.4.4 NETWORK

NETWORK

E-MAIL

DDNS

5.4.5 DISPLAY

5.4.6 RECORD

5.4.7 DEVICES

5.4.8 DCCS

5.4.9 IVS

IVS APPLICATION

IVS STATISTICS

5.4.10 NOTIFY

PUSH VIDEO

PUSH MESSAGE
