Agilent Technologies B2200A User Manual

Agilent B2200A

Femto Leakage Switch Mainframe

Agilent B2201A

14ch Low Leakage Switch Mainframe

User’s Guide

Agilent Technologies

Notices

No part of this manual may be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from Agilent Technologies, Inc. as governed by United States and international copyright laws.

Manual Part Number

B2200-90001

Edition

Edition 1, October 2004 Edition 2, July 2005

Agilent Technologies, Inc. 395 Page Mill Road Palo Alto, CA 94303 USA

Warranty

The material contained in this document is provided “as is,” and is subject to being changed, without notice, in future editions. Further, to the maximum extent permitted by applicable law, Agilent disclaims all warranties, either express or implied, with regard to this manual and any information contained herein, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. Agilent shall not be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or performance of this document or of any information contained herein. Should Agilent and the user have a separate written agreement with warranty terms covering the material in this document that conflict with these terms, the warranty terms in the separate agreement shall control.

Tec hn ol og y L i ce ns es

The hardware and/or software described in this document are furnished under a license and may be used or copied only in accordance with the terms of such license.

defined in FAR 52.227-19(c)(1-2) (June

1987). U.S. Government users will receive no greater than Limited Rights as defined in FAR 52.227-14 (June 1987) or DFAR

252.227-7015 (b)(2) (November 1995), as applicable in any technical data.

Restricted Rights Legend

If software is for use in the performance of a U.S. Government prime contract or subcontract, Software is delivered and licensed as “Commercial computer software” as defined in DFAR 252.227-7014 (June 1995), or as a “commercial item” as defined in FAR

2.101(a) or as “Restricted computer software” as defined in FAR 52.227-19 (June

1987) or any equivalent agency regulation or contract clause. Use, duplication or disclosure of Software is subject to Agilent Technologies’ standard commercial license terms, and non-DOD Departments and Agencies of the U.S. Government will receive no greater than Restricted Rights as

DECLARATION OF CONFO RMITY

According to ISO/IEC Guide 22 and CEN/CENELEC EN 4501 4

Manuf ac tu rer ’s Name : Agilen t Technologies Interna tional sarl Manu fact urer’s Add ress : Supplier’s Address :

Rue de la G are 29 CH - 1110 Morge s Switzerland

Declares under sole responsibility that the product as originally delivere d

Product Name : Femto Leakag e Switch Mainframe

Femt o Lea kage Switc h Modul e

14ch Low Leakag e Switc h Mainfram e

14ch Low Leakag e Switch Modul e

Model Number : Agilen t B2200 A

Agilent B22 10A

Agilen t B2201 A

Agile nt B22 11A

Product Options : This declaration covers all options of the above product(s )

complies with the esse ntial requireme nts o f the following applicable Eu rop ea n D irect ives, and carr ies the CE mark ing acc ordingl y:

Low Voltage Directive (73/23/EEC, amended by 93/68/EEC ) EMC Direc tive (89 /336/EEC , amended by 93/68 /EEC )

and conforms with the following product standard s EMC Standar d

IEC 61326:2002/ EN 61326:02

CISPR 11:1999+A2 / EN 55011:1998+A 1

IEC 61000-4-2:2001 / EN 61000-4- 2:1995+A1+A2 IEC 61000-4-3:2002 / EN 61000-4- 3:1996+A1+A2 IEC 61000-4-4:1995+A1 +A2 / EN 61000- 4-4:1995+A1 IEC 61000-4-5:2001 / EN 61000-4-5:1995+A1 IEC 61000-4-6:2001 / EN 61000-4-6:1996+A1 IEC 61000-4-11:2001 / EN 61000- 4-11 :1994+A1

Canada: ICES -001:1998 Australia/New Ze aland: AS/NZS 2064. 1

The produ ct was tested in a typical configuration with A gilent Techn ologies te st systems.

Safet y

IEC 61010-1:2001 / EN 61010-1:2001 Canada: CSA C22.2 No. 1010 .1:1992, NRTL/C

Limit

Group 1 Class A 4 kV CD, 8 kV AD 3 V/m, 80-1000 MHz

0.5 kV signal lines , 1 k V power lines

0.5 kV line -line, 1 kV line-ground 3V,0.15-80MHz 1 cycle, 100%

Supplementary Information: This DoC applies to abov e-listed products placed on the EU market after:

Sep 24, 2004

Date

Toshiyuki Kawaj i

QA Manager Agilent Technologie s

• Herstellerbescheinigung

GEÄUSCHEMISSION

Lpa < 70 dB

am Arbeitsplatz

normaler Betrieb

nach DIN 45635 T. 19

• Manufacturer’s Declaration

ACOUSTIC NOISE EMISSION

Lpa < 70 dB

operator position

normal operation

per ISO 7779

NOTE This ISM device complies with Canadian ICES-001.

Cet appareil ISM est conforme ?Hla norme NMB-001 du Canada.

This product complies with the WEEE Directive (2002/96/EC) marking requirements. The affixed label indicates that you must not discard this electrical/ electronic product in domestic household waste.

Product Category: With reference to the equipment types in the WEEE Directive Annex I, this product is classed as a “Monitoring and Control instrumentation” product.

Do not dispose in domestic household waste.

To return unwanted products, contact your local Agilent office, or see www.agilent.com/environment/product/ for more information.

Microsoft, Windows, Windows NT, Visual C++, and Visual Basic are registered trademarks of Microsoft Corporation.

Borland C++ Builder is registered trademark of International, Inc. LabWindows and LabVIEW are registered

trademarks of National Instruments Corporation. All other trademarks are the property of their respective owners.

Safety Summary

The following general safety precautions must be observed during all phases of operation, service, and repair of this instrument. Failure to comply with these precautions or with specific warnings elsewhere in this manual may impair the protections provided by the equipment. In addition, it violates safety standards of design, manufacture, and intended use of the instrument. Agilent Technologies, Inc. assumes no liability for customer’s failure to comply with these requirements.

NOTE Agilent B2200 complies with INSTALLATION CATEGORY II for mains input and

INSTALLATION CATEGORY I for measurement input terminals, and POLLUTION DEGREE 2 defined in IEC 1010-1.

Agilent B2200 is INDOOR USE products.

• GROUND THE INSTRUMENT

This is Safety Class I instrument. To minimize shock hazard, the instrument chassis and cabinet must be connected to an electrical ground. The power terminal and the power cable must meet International Electrotechnical Commission (IEC) safety standards.

• DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE

Do not operate the instrument in the presence of flammable gases or fumes. Operation of any electrical instrument in such an environment constitutes a definite safety hazard.

• KEEP AWAY FROM LIVE CIRCUITS

Operation personnel must not remove instrument covers. Component replacement and internal adjustments must be made by qualified maintenance personnel. Do not replace components with power cable connected. Under certain conditions, dangerous voltages may exist even with the power cable removed. To avoid injuries, always disconnect power and discharge circuits before touching them.

• DO NOT SERVICE OR ADJUST ALONE

Do not attempt internal service or adjustment unless another person, capable of rendering first aid and resuscitation, is present.

• DO NOT SUBSTITUTE PARTS OR MODIFY INSTRUMENT

Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized modification to the instrument. Return the instrument to a Agilent Technologies Sales and Service Office for services and repair to ensure that safety features are maintained.

• DANGEROUS PROCEDURE WARNINGS

Warnings, such as example below, precede potentially dangerous procedures throughout this manual. Instructions contained in the warnings must be followed.

WARNING Dangerous Voltage, capable of causing death, are present in this instrument.

Use extreme caution when handling, testing, and adjusting.

Safety Symbols

The general definitions of safety symbols used on equipment or in manuals are listed below.

Instruction manual symbol: the product will be marked with this symbol when it is necessary for the user to refer to the instruction manual in order to protect against damage to the instrument.

Indicates dangerous voltage and potential for electrical shock. Do not touch terminals that have this symbol when insrument is on.

Affixed to product containing static sensitive devices--use anti-static handling procedures to prevent electrostatic discharge damage to component.

Protective conductor terminal. For protection against electrical shock in case of a fault. Used with field wiring terminals to indicate the terminal which must be connected to ground before operating equipment.

Frame or chassis terminal. A connection to the frame (chassis) of the equipment which normally includes all exposed metal structures.

Indicates earth (ground) terminal.

Alternating current.

Direct current.

ON (Supply).

OFF (Supply).

STANDBY (Supply).

CAT 1

WARNING The warning sign denotes a hazard. It calls attention to a procedure, practice,

CAUTION The caution sign denotes a hazard. It calls attention to an operating procedure,

Means INSTALLATION CATEGORY I. Measurement terminals on the rear panel comply with INSTALLATION CATEGORY I.

condition or the like, which, if not correctly performed or adhered to, could result in injury or death to personal.

practice, condition or the like, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of the product.

In This Manual

This manual is a user’s guide for Agilent B2200A/B2201A Switch Mainframe, and consists of the following chapters:

• Introduction

Describes an overview and specifications of the Agilent B2200 series.

• Installation

Describes how to install the Agilent B2200 and how to setup the input/output.

• Front Panel Operation

Explains the front panel operation and the switch control functions of the Agilent B2200, also provides the reference information of the front panel keys and display.

•Programming

Explains the programming examples that control the Agilent B2200.

• SCPI Command Reference

Describes the all commands of the Agilent B2200 SCPI commands.

• VXIplug&play Driver

Describes the all functions of the Agilent B2200 VXIplug&play driver.

• Error Messages

Lists and describes the error messages for the Agilent B2200.

Text Conventions

The following text conventions are used in this manual:

Screen Text Represents text that appears on screen of the controller.

Italic Refers to a related document, or is used for emphasis.
