Agilent N5230A Data Sheet

Agilent
4-Port PNA-L Microwave
Network Analyzer

N5230A Options 240 and 245
300 kHz to 20 GHz

Data Sheet

Note:
Specification information in this
document is also available with­in the PNA-L network analyzer’s
internal Help system.

2

Table of Contents

Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Corrected System Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Table 1. System dynamic range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Table 2. Extended dynamic range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

N5230A Option 245

Corrected system performance with 3.5mm connectors . . . . . . . . . . 6

Table 3. 85052B Calibration kit N5230A –

Configurable test set and extended power range (Option 245) . . . . . 6

Table 4. N4691A Electronic calibration module N5230A –

Configurable test set and extended power range (Option 245) . . . . . 8

Table 5. Uncorrected system performance . . . . . . . . . . . . . . . . . . . . . . 10

Table 6. Test port output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Table 7: Test port input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 8. Dynamic accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Table 9. Test port input (group delay) . . . . . . . . . . . . . . . . . . . . . . . . . . 21

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 10. Miscellaneous information . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 11. Front panel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 12. Rear panel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 13. Analyzer environment and dimensions . . . . . . . . . . . . . . . . . 24

Measurement Throughput Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Table 14. Typical cycle time (ms) for measurement completion . . . . . .25

Table 15. Cycle time vs IF bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Table 16. Cycle time vs number of points . . . . . . . . . . . . . . . . . . . . . . .27

Table 17. Data transfer time (ms) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Specifications: Front-Panel Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 18: Measurement receiver inputs, 0.1 dB typical compression . 29
Table 19: Reference receiver input at max. specified output power . . 29

Table 20: Reference output at max. specified output power . . . . . . . . 29

Table 21: Source outputs at max. specified output power . . . . . . . . . . 30

Table 22: Coupler inputs, insertion loss of coupler thru . . . . . . . . . . . 30

Table 23: Coupler outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Test Set Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

N5230A Option 240

(standard test set and standard power range) network analyzer . . . 31
N5230A Option 245

(configurable test set and extended power range) network analyzer . 31

Web Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3

This is a subset of technical specifications for the N5230A Option 240 and 245
network analyzer.

To view or print the N5230A technical specifications, visit our web site at

www.agilent.com/find/pnal

This N5230A document provides technical specifications for the following calibration
kit and ECal module only: 85052B and N4691A. Please download our free Uncertainty
Calculator from www.agilent.com/find/na_calculator to generate the curves for
your calibration kit and PNA setup.

Definitions

All specifications and characteristics apply over a 25 °C ±5 °C range
(unless otherwise stated) and 90 minutes after the instrument has been
turned on.

Specification (spec.): Warranted performance. Specifications include
guardbands to account for the expected statistical performance distribution,
measurement uncertainties, and changes in performance due to
environmental conditions.

Characteristic (char.): A performance parameter that the product is expected
to meet before it leaves the factory, but that is not verified in the field and is
not covered by the product warranty. A characteristic includes the same
guardbands as a specification.

Typical (typ.): Expected performance of an average unit which does not include
guardbands. It is not covered by the product warranty.

Nominal (nom.): A general, descriptive term that does not imply a level of
performance. It is not covered by the product warranty.

Calibration: The process of measuring known standards to characterize a
network analyzer's systematic (repeatable) errors.

Corrected (residual): Indicates performance after error correction (calibration).
It is determined by the quality of calibration standards and how well "known"
they are, plus system repeatability, stability, and noise.

Uncorrected (raw): Indicates instrument performance without error correction.
The uncorrected performance affects the stability of a calibration.

Standard: When referring to the analyzer, this includes no options unless
noted otherwise.

4

Corrected System Performance

The specifications in this section apply for measurements made with the
N5230A Options 240 and 245 analyzer with the following conditions:

• 10 Hz IF bandwidth

• No averaging applied to data

• Isolation calibration with an averaging factor of 8

Table 1. System dynamic range at test port

1

Standard configuration and standard power range (Option 240)

Description

Specification (dB) Typical (dB)

at test port at test port

300 kHz to 10 MHz 111
10 MHz to 4 GHz

2

120 128
4 GHz to 6 GHz 118 129
6 GHz to 10.5 GHz 115 127

10.5 GHz to 15 GHz 107 119
15 GHz to 20 GHz 103 116

Configurable test set and extended power range (Option 245)

Description

Specification (dB) Typical (dB)

at test port at test port

300 kHz to 10 MHz 111
10 MHz to 4 GHz

2

120 128
4 GHz to 6 GHz 118 128
6 GHz to 10.5 GHz 113 125

10.5 GHz to 15 GHz 105 117
15 GHz to 20 GHz 98 115

1. The system dynamic range is calculated as the difference between the noise floor and the specified

source maximum output power. The effective dynamic range must take measurement uncertainties
and interfering signals into account.

2. May be degraded by 10 dB at particular frequencies (multiples of 5 MHz) below 500 MHz due to

spurious receiver residuals. Methods are available to regain the full dynamic range.

5

Table 2. Extended dynamic range

1

Configurable test set and extended power range (Option 245)

Specification (dB) at Typical (dB) at

Description direct receiver direct receiver

access input access input

300 kHz to 10 MHz 127
10 MHz to 4 GHz

2

136
4 GHz to 6 GHz 134
6 GHz to 10.5 GHz 129

10.5 GHz to 15 GHz 121
15 GHz to 20 GHz 114

1. The direct receiver access input extended dynamic range is calculated as the difference between

the direct receiver access input noise floor and the source maximum output power. The effective
dynamic range must take measurement uncertainties and interfering signals into account. This
set-up should only be used when the receiver input will never exceed its compression or damage
level. When the analyzer is in segment sweep mode, it can have predefined frequency segments
which will output a higher power level when the extended dynamic range is required (i.e. devices
with high insertion loss), and reduced power when receiver compression or damage may
occur (i.e. devices with low insertion loss). The extended range is only available in one-path
transmission measurements.

2. May be degraded by 10 dB at particular frequencies (multiples of 5 MHz) below 500 MHz due to

spurious receiver residuals. Methods are available to regain the full dynamic range.

6

N5230A Option 245
Corrected system performance with 3.5 mm connectors

1

Note: For any Siireflection measurement:

S

jj

= 0

For any S

ij

transmission measurement:

S

ji = Sij

when S

ij

≤ 1

S

ji =

1/S

ij

when S

ij

≥ 1

S

kk

= 0 for all k

Table 3. 85052B Calibration kit

N5230A – configurable test set and extended power range (Option 245)

Applies to the N5230A Option 245 analyzers, 85052B (3.5mm) calibration kit,
85131F flexible test port cable set, and a full 2-port calibration. Also applies
to the following condition: Environmental temperature 23° ±3 °C, with < 1 °C
deviation from calibration temperature.

Specification (dB)

Description

10 MHz to 500 MHz to 2 to 8 to

500 MHz 2 GHz 8 GHz 20 GHz

Directivity 48 48 44 44
Source match 40 40 33 31
Load match 48 48 44 44

Reflection tracking

±0.003 ±0.003 ±0.003 ±0.006

(+0.01/°C) (+0.01/°C) (+0.02/°C) (+0.03/°C)

Transmission tracking

±0.017 ±0.017 ±0.062 ±0.125

(+0.01/°C) (+0.01/°C) (+0.02/°C) (+0.03/°C)

Transmission uncertainty (specifications)

1. From 300 kHz to 10 MHz, performance is characterized as “typical”. To generate these typical values,

please download our free Uncertainty Calculator from www.agilent.com/find/na_calculator

.

Magnitude

0.01

0.1

1

10

-90-80-70-60-50-40-30-20-10010

Uncertainty (dB)

N5230A 245 with 85052B

■

10 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Source power = -5 dBm

Transmission coefficient (dB)

7

85052B Calibration kit (continued)
N5230A – configurable test set and extended power range (Option 245)

Reflection uncertainty (specifications)

Phase

0.1

1

10

100

-90-80-70-60-50-40-30-20-10010

Uncertainty (degrees)

■

10 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Magnitude

0

0.01

0.02

0.03

0.04

0.05

0 0.2 0.4 0.6 0.8 1

Uncertainty (linear)

N5230A 245 with 85052B

■

10 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Phase

0

2

4

6

8

10

0 0.2 0.4 0.6 0.8 1

Uncertainty (deg)

N5230A 245 with 85052B

■

10 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

N5230A 245 with 85052B

Source power = -5 dBm

Transmission coefficient (dB)

Source power = -5 dBm

Reflection coefficient (linear)

Source power = -5 dBm

Reflection coefficient (linear)

8

N5230A Option 245

Corrected system performance with 3.5 mm connectors

1

(continued)

Table 4. N4691A Electronic calibration module

N5230A – configurable test set and extended power range (Option 245)

Applies to the N5230A Option 245 analyzers, N4691A electronic calibration module,
85131F flexible test port cable set, and a full 2-port calibration. Also applies to the
following condition: Environmental temperature 23° ±3 °C,
with < 1 °C deviation from calibration temperature.

Specification (dB)

Description

45 MHz to 500 MHz to 2 to 8 to

500 MHz 2 GHz 8 GHz 20 GHz

Directivity 56 56 54 49
Source match 47 47 45 44
Load match 46 46 45 43

Reflection tracking

±0.050 ±0.050 ±0.070 ±0.090

(+0.01/°C) (+0.01/°C) (+0.02/°C) (+0.03/°C)

Transmission tracking

±0.055 ±0.056 ±0.057 ±0.071

(+0.01/°C) (+0.01/°C) (+0.02/°C) (+0.03/°C)

Transmission uncertainty (specifications)

1. From 300 kHz to 10 MHz, performance is characterized as “typical”. To generate these typical values,

please download our free Uncertainty Calculator from www.agilent.com/find/na_calculator

.

Magnitude

0.01

0.1

1

10

-90-80-70-60-50-40-30-20-10010

Uncertainty (dB)

N5230A 245 with N4691A

■

45 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Phase

0.1

1

10

100

-90-80-70-60-50-40-30-20-10010

Uncertainty (degrees)

N5230A 245 with N4691A

■

45 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Source power = -5 dBm

Transmission coefficient (dB)

Source power = -5 dBm

Transmission coefficient (dB)

9

N4691A Electronic calibration module (continued)
N5230A – configurable test set and extended power range (Option 245)

Reflection uncertainty (specifications)

Magnitude

0

0.01

0.02

0.03

0.04

0.05

0 0.2 0.4 0.6 0.8 1

Uncertainty (linear)

N5230A 245 with N4691A

■

45 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Phase

0

2

4

6

8

10

0 0.2 0.4 0.6 0.8 1

Uncertainty (deg)

N5230A 245 with N4691A

■

45 MHz to 500 MHz

◆ 500 MHz to 2 GHz

▲ 2 GHz to 8 GHz

● 8 GHz to 20 GHz

Source power = -5 dBm

Reflection coefficient (linear)

Source power = -5 dBm

Reflection coefficient (linear)

10

Table 5. Uncorrected system performance

1

Directivity

Specifications Typicals

Options 240, 245 Options 240, 245

300 kHz to 10 MHz –23 dB
10 MHz to 1 GHz –28 dB
1 GHz to 3 GHz –25 dB
3 GHz to 5 GHz –20 dB
5 GHz to 11.5 GHz –17 dB

11.5 GHz to 20 GHz –15 dB

Source match

300 kHz to 10 MHz –8 dB
10 MHz to 1 GHz –12 dB
1 GHz to 3 GHz –12 dB
3 GHz to 5 GHz –12 dB
5 GHz to 10.5 GHz –12 dB

10.5 GHz to 11.5 GHz –10 dB

11.5 GHz to 20 GHz –8 dB

Load match

300 kHz to 10 MHz –9 dB
10 MHz to 1 GHz –20 dB
1 GHz to 3 GHz –20 dB
3 GHz to 5 GHz –18 dB
5 GHz to 11.5 GHz –12 dB

11.5 GHz to 16 GHz –7 dB
16 GHz to 20 GHz –7.5 dB

Crosstalk

2

300 kHz to 5 MHz –70 dB
5 MHz to 10 MHz –100 dB
10 MHz to 45 MHz –110 dB
45 MHz to 4 GHz –122 dB
4 GHz to 6 GHz –123 dB
6 GHz to 10.5 GHz –120 dB

10.5 GHz to 15 GHz –115 dB
15 GHz to 20 GHz –110 dB

1. Specifications apply over environmental temperature of 25 °C ±5 °C with less than 1 °C variation

from calibration temperature.

2. Measurement conditions: normalized to a thru, measured with two shorts, 10 Hz IF bandwidth,

averaging factor of 8, alternate mode source power set to the lesser of the maximum power out
or the maximum receiver power.

11

Table 6. Test port output

1

Description

Specifications Typicals

Option 240 Option 245 Option 240 Option245

Frequency range

300 KHz to 20 GHz

Nominal power

–5 dB –8 dB Preset power; attenuator switch

point 10 dB below nominal power

Frequency resolution

1 Hz

CW accuracy

±1 ppm

Frequency stability

±0.05 ppm. –10° to 70° C
±0.1 ppm/yr maximum

Description

Specifications Typicals

Option 240 Option 245 Option 240 Option245

Power level accuracy

Variation from nominal power in range 0
300 kHz to 10 MHz ±1.0 dB ±1.0dB
10 MHz to 2 GHz ±1.0 dB ±1.0 dB
2 GHz to 10.5 GHz ±1.5 dB ±1.5 dB

10.5 GHz to 20 GHz ±2.5 dB ±2.5 dB

Max leveled power

300 kHz to 10 MHz +8 dBm +8 dBm
10 MHz to 4 GHz +8 dBm +8 dBm +12 dBm +11 dBm
4 GHz to 6 GHz +6 dBm +6 dBm +10 dBm +9 dBm
6 GHz to 10.5 GHz +3 dBm +1 dBm +8 dBm +6 dBm

10.5 GHz to 15 GHz 0 dBm –2 dBm +5 dBm +3 dBm
15 GHz to 20 GHz –3 dBm –8 dBm +2 dBm –1 dBm

Power level linearity

Specified on Port 1 only. Ports 2, 3, 4 performance is Typical. Test is at the nominal power level.
300 kHz to 10 MHz ±2.0 dB ±2.0 dB
10 MHz to 1 GHz ±2.0 dB ±2.0 dB
1 GHz to 20 GHz ±1.5 dB ±1.5 dB

Power sweep range (ALC)

ALC range starts at maximum-leveled power and decreases by the dB amount specified here.
300 kHz to 10 MHz 35 dB 35 dB
10 MHz to 4 GHz 33 dB 33 dB
4 GHz to 6 GHz 31 dB 31 dB
6 GHz to 10.5 GHz 28 dB 26 dB

10.5 GHz to 15 GHz 25 dB 23 dB
15 GHz to 20 GHz 22 dB 17 dB

Power resolution

0.01 dB 0.01 dB

12

Table 6. Test port output1(Continued)

Description

Specifications Typicals

Option 240 Option 245 Option 240 Option245

Power range

300 kHz to 10 MHz –27 to +8 dBm –87 to +8 dBm
10 MHz to 45 MHz –27 to +12 dBm –87 to +11 dBm
45 MHz to 4 GHz –27 to +12 dBm –87 to +11 dBm
4 GHz to 6 GHz –27 to +10 dBm –87 to +9 dBm
6 GHz to 10.5 GHz –27 to +8 dBm –87 to +6 dBm

10.5 GHz to 15 GHz –27 to +5 dBm –87 to +3 dBm
15 GHz to 20 GHz –27 to +2 dBm –87 to –1 dBm

Power settings

Minimum power setting –30 dBm –90 dBm
Maximum power setting +20 dBm +20 dBm

Harmonics (2nd or 3rd) at maximum output power

In-band source harmonics
300 kHz to 10 MHz –17 dBc
10 MHz to 1 GHz –17 dBc
1 GHz to 20 GHz –20 dBc

Non-harmonic spurious (at nominal output power)

300 kHz to 20 GHz –50 dBc for offset frequency > 1kHz

Typical performance

Phase noise (Nominal power at test port)

10 kHz Offset 100 kHz Offset 1 MHz Offset

300 kHz to 10 MHz –86 dBc/Hz –86 dBc/Hz –95 dBc/Hz
10 MHz to 1.5 GHz –86 dBc/Hz –91 dBc/Hz –95 dBc/Hz

1.5 GHz to 3.125 GHz –83 dBc/Hz –91 dBc/Hz –95 dBc/Hz

3.125 GHz to 6.25 GHz –77 dBc/Hz –85 dBc/Hz –89 dBc/Hz

6.25 GHz to 12.5 GHz –71 dBc/Hz –79 dBc/Hz –83 dBc/Hz

12.5 GHz to 20 GHz –65 dBc/Hz –73 dBc/Hz –77 dBc/Hz

1. Performance specified on Port 1 only. Ports 2 , 3, and 4 performance is a typical.

Test reference is at the nominal power level.

13

Table 7: Test port input

Description

Specification Typicals

Options 240, 245 Option 240, 245

Test port noise floor

Total average (rms) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.

10 Hz IF bandwidth

300 kHz to 10 MHz < –103 dBm
10 MHz to 500 MHz < –112 dBm < –116 dBm
500 MHz to 4 GHz < –112 dBm < –120 dBm
4 GHz to 10.5 GHz < –112 dBm < –119 dBm

10.5 GHz to 15 GHz < –107 dBm < –114 dBm
15 GHz to 20 GHz < –106 dBm < –114 dBm

1 KHz IF bandwidth

300 kHz to 10 MHz < –83 dBm
10 MHz to 500 MHz < –92 dBm < –96 dBm
500 MHz to 4 GHz < –92 dBm < –100 dBm
4 GHz to 10.5 GHz < –92 dBm < –99 dBm

10.5 GHz to 15 GHz < –87 dBm < –94 dBm
15 GHz to 20 GHz < –86 dBm < –94 dBm

Direct receiver access input noise floor (Option 245 only)

Total average (rms) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.

10 Hz IF bandwidth

300 kHz to 10 MHz < –119 dBm
10 MHz to 500 MHz < –128 dBm < –132 dBm
500 MHz to 4 GHz < –128 dBm < –136 dBm
4 GHz to 10.5 GHz < –128 dBm < –135 dBm

10.5 GHz to 15 GHz < –123 dBm < –130 dBm
15 GHz to 20 GHz < –122 dBm < –130 dBm

1 KHz IF bandwidth

300 kHz to 10 MHz < –99 dBm
10 MHz to 500 MHz < –108 dBm < –112 dBm
500 MHz to 4 GHz < –108 dBm < –116 dBm
4 GHz to 10.5 GHz < –108 dBm < –115 dBm

10.5 GHz to 15 GHz < –103 dBm < –110 dBm
15 GHz to 20 GHz < –102 dBm < –110 dBm

Description

Specification Typicals

Options 240, 245 Option 240, 245

Compression level (at +8 dBm except as noted)

Power Compression Power Compression

300 kHz to 10 MHz +5 dBm 0.10 dB
10 MHz to 50 MHz +8 dBm 0.35 dB
50 MHz to 1 GHz +8 dBm 0.35 dB
1 GHz to 8 GHz +8 dBm 0.25 dB
8 GHz to 12.5 GHz +8 dBm 0.30 dB

12.5 GHz to 20 GHz +8 dBm 0.55 dB

Test port compression at 0.1 dB

300 kHz to 10 MHz +5 dBm
10 MHz to 1 GHz +9 dBm
1 GHz to 12.5 GHz +10 dBm

12.5 GHz to 20 GHz +9 dBm

14

Table 7. Test port input (Continued)

Description

Specifications Typicals

Option 240 Option 245 Option 240 Option245

Trace noise magnitude

Ratioed measurement, nominal power at test port.

100 kHz IF bandwidth

300 kHz to 10 MHz .015 dB rms. .030 dB rms
10 MHz to 10.5 GHz .006 dB rms .008 dB rms .004 dB rms. .005 dB rms

10.5 GHz to 20 GHz .010 dB rms .014 dB rms .007 dB rms. .009 dB rms

600 kHz IF bandwidth

300 kHz to 10 MHz .015 dB rms. .030 dB rms
10 MHz to 10.5 GHz .013 dB rms. .015 dB rms

10.5 GHz to 20 GHz .017 dB rms. .023 dB rms

100 kHz IF bandwidth

Measured at maximum specified power
300 kHz to 10 MHz .005 dB rms. .010 dB rms
10 MHz to 2 GHz .001 dB rms. .003 dB rms
2 GHz to 10.5 GHz .002 dB rms. .003 dB rms

10.5 GHz to 20 GHz .006 dB rms. .009 dB rms

Trace noise phase

Ratioed measurement, nominal power at test port.

100 kHz IF bandwidth

300 kHz to 10 MHz .110 deg rms. .180 deg rms
10 MHz to 10.5 GHz .05 deg rms .07 deg rms .025 deg rms. .035 deg rms

10.5 GHz to 20 GHz .08 deg rms .10 deg rms .050 deg rms. .060 deg rms

600 kHz IF bandwidth

300 kHz to 10 MHz .110 deg rms. .180 deg rms
10 MHz to 10.5 GHz .080 deg rms. .100 deg rms

10.5 GHz to 20 GHz .120 deg rms. .160 deg rms

100 kHz IF bandwidth

Measured at maximum specified power
300 kHz to 10 MHz .040 deg rms. .050 deg rms
10 MHz to 2 GHz .007 deg rms. .012 deg rms
2 GHz to 10.5 GHz .012 deg rms. .015 deg rms

10.5 GHz to 20 GHz .040 deg rms. .060 deg rms

Reference level magnitude

Range ±200 dB ±200 dB
Resolution .001 dB .001 dB

Reference level phase

Range ±500° ±550°
Resolution .01° .01°

Stability magnitude

Stability as defined as a ratio measurement made at the test port.
300 kHz to 10 MHz ±.015 dB/° C
10 MHz to 2 GHz ±.010 dB/° C
2 GHz to 4 GHz ±.015 dB/° C
4GHz to 16 GHz ±.020 dB/° C
16 GHz to 19 GHz ±.025 dB/° C
19 GHz to 20 GHz ±.030 dB/° C

15

Table 7. Test port input (Continued)

Description

Specifications Typicals

Option 240 Option 245 Option 240 Option245

Stability phase

Stability as defined as a ratio measurement made at the test port.
300 kHz to 10 MHz ±.360 dB/° C
10 MHz to 45 MHz ±.020 dB/° C
45 MHz to 500 MHz ±.030 dB/° C
500 MHz to 2 GHz ±.050 dB/° C
2 GHz to 4 GHz ±.100 dB/° C
4GHz to 8 GHz ±.150 dB/° C
8 GHz to 16 GHz ±.300 dB/° C
16 GHz to 20 GHz ±.350 dB/° C

Description

Typicals

Option 240 Option245

Damage input level

Test port 1, 2, 3, and 4 +27 dBm or ±16 VDC +27 dBm or ±16 VDC
Receivers R, A, B, C, D +15 dBm or ±16 VDC
Source out (reference) +20 dBm or ±16 VDC
Source out (test ports) +27 dBm or ±16 VDC
Coupler thru +27 dBm or ±16 VDC
Coupler arm +15 dBm or ±0 VDC

16

Table 8. Dynamic Accuracy (specification)

Accuracy of the test port input power reading relative to the reference input power level.
Dynamic accuracy is verified with the following measurements:

• Compression over frequency

• IF linearity at a single frequency of 1.195 GHz using a reference level of –20 dBm
for an input power range of 0 to –110 dBm

Dynamic Accuracy 0.045 GHz

Magnitude

0.01

0.1

1

10

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (dB)

N5230A Option 240 or 245

■

-10 dBm at 0.045 GHz

◆ -20 dBm at 0.045 GHz

▲ -30 dBm at 0.045 GHz

● -40 dBm at 0.045 GHz

Phase

0.1

1

10

100

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (degrees)

N5230A Option 240 or 245

■

-10 dBm at 0.045 GHz

◆ -20 dBm at 0.045 GHz

▲ -30 dBm at 0.045 GHz

● -40 dBm at 0.045 GHz

Testport power (dBm)

Testport power (dBm)

17

Table 8. Dynamic Accuracy (continued)

Dynamic Accuracy 0.500 GHz

Magnitude

0.01

0.1

1

10

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (dB)

N5230A Option 240 or 245

■

-10 dBm at 0.500 GHz

◆ -20 dBm at 0.500 GHz

▲ -30 dBm at 0.500 GHz

● -40 dBm at 0.500 GHz

Phase

0.1

1

10

100

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (degrees)

N5230A Option 240 or 245

■

-10 dBm at 0.500 GHz

◆ -20 dBm at 0.500 GHz

▲ -30 dBm at 0.500 GHz

● -40 dBm at 0.500 GHz

Testport power (dBm)

Testport power (dBm)

18

Table 8. Dynamic Accuracy (continued)

Dynamic Accuracy 1 to 2 GHz

Magnitude

0.01

0.1

1

10

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (dB)

N5230A Option 240 or 245

■

-10 dBm (1 to 2 GHz)

◆ -20 dBm (1 to 2 GHz)

▲ -30 dBm (1 to 2 GHz)

● -40 dBm (1 to 2 GHz)

Phase

0.1

1

10

100

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (degrees)

N5230A Option 240 or 245

■

-10 dBm (1 to 2 GHz)

◆ -20 dBm (1 to 2 GHz)

▲ -30 dBm (1 to 2 GHz)

● -40 dBm (1 to 2 GHz)

Testport power (dBm)

Testport power (dBm)

19

Table 8. Dynamic Accuracy (continued)

Dynamic Accuracy 2 to 12.5 GHz

Magnitude

0.01

0.1

1

10

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (dB)

■

-10 dBm (2 to 12.5 GHz)

◆ -20 dBm (2 to 12.5 GHz)

▲ -30 dBm (2 to 12.5 GHz)

● -40 dBm (2 to 12.5 GHz)

Phase

0.1

1

10

100

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (degrees)

N5230 Option 240 or 245

■

-10 dBm (2 to 12.5 GHz)

◆ -20 dBm (2 to 12.5 GHz)

▲ -30 dBm (2 to 12.5 GHz)

● -40 dBm (2 to 12.5 GHz)

N5230 Option 240 or 245

Testport power (dBm)

Testport power (dBm)

20

Table 8. Dynamic Accuracy (continued)

Dynamic Accuracy 12.5 to 20 GHz

Magnitude

0.01

0.1

1

10

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (dB)

N5230A Option 240 or 245

■

-10 dBm (12.5 to 20 GHz)

◆ -20 dBm (12.5 to 20 GHz)

▲ -30 dBm (12.5 to 20 GHz)

● -40 dBm (12.5 to 20 GHz)

Phase

0.1

1

10

100

-120-110-100-90-80-70-60-50-40-30-20-10010

Accuracy (degrees)

■

-10 dBm (12.5 to 20 GHz)

◆ -20 dBm (12.5 to 20 GHz)

▲ -30 dBm (12.5 to 20 GHz)

● -40 dBm (12.5 to 20 GHz)

Testport power (dBm)

N5230A Option 240 or 245

Testport power (dBm)

21

Table 9. Test port input (group delay)

1

Description Specification Supplemental information (typ.)
Aperture (selectable) (frequency span)/(number of points –1)
Maximum aperture 20% of frequency span
Range 0.5 x (1/minimum aperture)

Maximum delay Limited to measuring no more than 180° of

phase change within the minimum aperture

Accuracy See graph below. Char.

The following graph shows characteristic group delay accuracy with full 2-port calibration and
a 10 Hz IF bandwidth. Insertion loss is assumed to be < 2 dB and electrical length to be ten meters.

For any S

ij

group delay measurement, Sii= 0, Sij= 0, Skl= 0 for all kl ≠ ij

In general, the following formula can be used to determine the accuracy, in seconds, of specific
group delay measurement:

±Phase Accuracy (deg)/[360° Aperture (Hz)]

Depending on the aperture and device length, the phase accuracy used is either incremental
phase accuracy or worst case phase accuracy.

Group delay (typical)

0.001

0.01

0.1

1

10

100

0.01 0.1 1 10 100

Accuracy (nsec)

N5230A 245 with 85052B

Frequency = 1 GHz

IF Bandwidth = 10 Hz; Average factor = 1

Cal power = -5 dBm; Meas power = -5 dBm; Electrical length = 10 m

Aperture (MHz)

22

General Information

Table 10. Miscellaneous information

Description Specification Supplemental information
System IF bandwidth range 1 Hz to 600 kHz, nominal
CPU Intel® 500 MHz Pentium® III

Table 11. Front panel information

Description Supplemental information
RF connectors

Type Option 240 or 245: 3.5 mm (male), 50 ohm, (nominal)
Center pin recession 0.002 in. (characteristic)

Display

Size 21.3 cm (8.4 in) diagonal color active matrix LCD;

640 (horizontal) X 480 (vertical) resolution

Refresh rate Vertical 59.83 Hz; Horizontal 31.41 kHz

Display range

Magnitude ±500 dB (at 20 dB/div), max
Phase ±500°, max
Polar 10 pUnits, min

1000 Units, max

Display resolution

Magnitude 0.001 dB/div, min
Phase 0.01°/div, min

Marker resolution

Magnitude 0.001 dB, min
Phase 0.01°, min
Polar 0.01 mUnit, min; 0.01°,min

23

Table 13. Rear panel information

Description Supplemental information
10 MHz Reference in

Connector BNC, female
Input frequency 10 MHz ± 10 ppm, typical
Input level –15 dBm to +20 dBm, typical
Input impedance 200 Ω, nom.

10 MHz Reference out

Connector BNC, female
Output frequency 10 MHz ± 1 ppm, typical
Signal type Sine Wave, typical
Output level +10 dBm ± 4 dB into 50 Ω, typical
Output impedance 50 Ω, nominal
Harmonics < –40 dBc, typical

VGA Video output

Connector 15-pin mini D-Sub; Drives VGA compatible monitors

Devices supported

Resolutions:

Flat panel (TFT) 1024 X 768, 800 X 600, 640 X 480
Flat panel (DSTN) 800 X 600, 640 X 480
CRT monitor 1280 X 1024, 1024 X 768, 800 X 600, 640 X 480

Simultaneous operation of the internal and external displays is allowed,
but with 640 X 480 resolution only. If you change resolution, you can only
view the external display (internal display will "white out").

Test set IO

25-pin D-Sub connector, female, available for external test set control

Aux IO

25-pin D-Sub connector, male, analog and digital IO

Handler IO

36-pin parallel I/O port; all input/output signals are default set to
negative logic; can be reset to positive logic via GPIB command

GPIB

24-pin D-sub (Type D-24), female; compatible with IEEE-488.

Parallel port (LPT1)

25-pin D-Sub miniature connector, female; provides connection to
printers or any other parallel port peripherals

Serial Port (COM 1)

9-pin D-Sub, male; compatible with RS-232

USB Port

One port on front panel and five ports on rear panel. Universal Serial Bus

jack, Type A configuration (4 contacts inline, contact 1 on left); female
Contact 1 Vcc: 4.75 to 5.25 VDC, 500 mA, maximum
Contact 2 –Data
Contact 3 +Data
Contact 4 Ground

LAN

10/100BaseT Ethernet, 8-pin configuration; auto selects between the

two data rates

Line power A third-wire ground is required.

Frequency 50/60/400 Hz
Voltage 120/240 VAC (Power supply is auto switching.)
Max 500 Watts

Note: Option H08 and Option H11 are not available with the N5230A network analyzer.

24

Table 13. Analyzer environment and dimensions

Description Supplemental information
General environmental

RFI/EMI susceptibility Defined by CISPR Pub. 11, Group 1, Class A, and IEC 50082-1
ESD Minimize by using static-safe work procedures and an antistatic bench mat
Dust Minimize for optimum reliability

Operating environment

Temperature 0 °C to +40 °C

Instrument powers up and displays no error messages within this

temperature range (except for "source unleveled" error message that

may occur at temperatures outside the specified performance

temperature range of 25 ± 5 °C).
Error-corrected temperature range 23 °C ± 3 °C with less than 1 °C deviation from calibration temp.
Humidity 5% to 95% at +40 °C
Altitude 0 to 4500 m (14,760 ft.)

Non-operating storage environment

Temperature –40 °C to +70 °C
Humidity 0% to 90% at +65 °C (non-condensing)
Altitude 0 to 4500 m (14,760 ft.)

Cabinet dimensions

Height Width Depth

Excluding front and rear panel hardware and feet 267 mm 426 mm 427 mm

10.5 in 16.75 16.8 in
As shipped - includes front panel connectors, 280 mm 435 mm 470 mm
rear panel bumpers, and feet. 11 in 17.10 in 18.5 in
As shipped plus handles 280 mm 458 mm 501 mm

11 in 18 in 19.7 in

As shipped plus rack-mount flanges 280 mm 483 mm 470 mm

11 in 19 in 18.5 in

As shipped plus handles and rack-mount flanges 280 mm 483 mm 501 mm

11 in 19 in 19.7 in

Weight

Net
N5230A 24.9 kg (55 lb), nominal
Shipping
N5230A 36.3 kg (80 lb), nominal

25

Measurement Throughput Summary

Table 14. Typical cycle time1(ms) for measurement completion

Number of Points

201 401 801 1601 16,001

Start 8 GHz, stop 18 GHz, 600 kHz IF bandwidth

Uncorrected 26.2 26.7 27.6 29.2 76.5
4-Port cal 93.0 104.1 125.2 164.0 939.6

Start 300 kHz, stop 10 GHz, 600 kHz IF bandwidth

Uncorrected 24.8 28.0 30.4 35.0 91.8
4-Port cal 87.5 109.0 134.6 180.5 990.8

Start 300 kHz, stop 20 GHz, 600 kHz IF bandwidth

Uncorrected 38.3 40.2 43.6 46.6 93.8
4-Port cal 140.2 158.3 190.0 224.2 1012.3

Start 8 GHz, stop 18 GHz, 100 kHz IF bandwidth

Uncorrected 43.1 56.9 60.9 62.1 193.4
4-Port cal 160.4 222.2 248.8 274.5 1291.1

Start 300 kHz, stop 10 GHz, 100 kHz IF bandwidth

Uncorrected 41.8 48.3 51.1 53.7 209.9
4-Port cal 155.1 180.0 214.2 260.5 1362.7

Start 300 kHz, stop 20 GHz, 100 kHz IF bandwidth

Uncorrected 51.4 76.4 94.0 99.8 211.4
4-Port cal 190.3 292.4 379.8 419.8 1378.7

Start 8 GHz, stop 18 GHz, 50 kHz IF bandwidth

Uncorrected 47.1 75.1 94.6 97.3 380.9
4-Port cal 171.6 290.1 381.0 410.0 1894.4

Start 300 kHz, stop 10 GHz, 50 kHz IF bandwidth

Uncorrected 49.1 67.2 72.7 75.9 395.1
4-Port cal 180.0 261.4 293.1 330.6 1941.2

Start 300 kHz, stop 20 GHz, 50 kHz IF bandwidth

Uncorrected 54.9 87.1 131.2 154.4 396.3
4-Port cal 207.0 337.7 523.9 633.6 1948.2

1. Includes sweep time, retrace time and band-crossing time. Analyzer display turned off with
DISPLAY:ENABLE OFF. Add 21 ms for display on. Data for one trace (S11) measurement.

26

Table 15. Cycle Time vs IF Bandwidth

Applies to the preset condition (201 points, correction off) except for the following changes:

• CF = 10 GHz

• Span = 100 MHz

• Display off (add 21 ms for display on)

Description Typical performance
IF Bandwidth (Hz) Cycle time (ms)

1

Trace noise

600,000 7.523394495 0.003533948
360,000 7.54179941 0.002688865
280,000 7.5703125 0.002287365
200,000 7.71344 0.002102872
150,000 7.762206897 0.001696417
100,000 7.806733333 0.001284263
70,000 7.874966555 0.001170092
50,000 9.076777778 0.000987238
30,000 11.46182377 0.0008445
20,000 14.72636574 0.000647383
15,000 17.5863125 0.000534657
10,000 28.64310448 0.000477914
7000 37.16706481 0.000439644
5000 48.58746512 0.000350175
3000 72.52639344 0.00030881
2000 102.2277778 0.000279538
1500 130.7245 0.00015128
1000 218.5535 0.000154337
700 294.1385333 0.000135211
500 399.9245455 0.000125675
300 636.411 0.000103409
200 932.7632
100 1826.966667
30 6004.446
10 17903.564
1 178398.611

1. Cycle time includes sweep and retrace time.

27

Table 16. Cycle time vs number of points

1

Applies to the preset condition (correction off) except for the following changes:

• CF = 10 GHz

• Span = 100 MHz

• Display off (add 21 ms for display on)

IF Bandwidth (Hz) Number of points Cycle time (ms)

2

30,000 3 6.7

11 7.4

51 6.9
101 7.8
201 11.2
401 18.3
801 32.4

1,601 59.4
6,401 224.7

16,001 556.9

100,000 3 6.7

11 6.6

51 6.8
101 7
201 7.5
401 9
801 13.5

1,601 22.9
6,401 75.3

16,001 180.3

600,000 3 6.5

11 6.6

51 6.8
101 6.9
201 7.3
401 8.1
801 9.4

1,601 12
6,401 27.7

16,001 59.3

1. Cycle time includes sweep and retrace time.

28

Table 17. Data transfer time (ms)

1

Number of points

201 401 1601 16,001

SCPI over GPIB (program executed on external PC)

32-bit floating point 7 12 43 435
64-bit floating point 12 22 84 856
ASCII 64 124 489 5054

SCPI (program executed in the analyzer)

32-bit floating point 1 2 3 30
64-bit floating point 2 2 4 40
ASCII 29 56 222 2220

COM (program executed in the analyzer)

32-bit floating point < 0.4 0.4 0.5 1.9
Variant type 0.7 1 3 32

DCOM over LAN (program executed on external PC)

32-bit floating point < 0.8 1 1.5 7.1
Variant type 1.8 2.7 8.5 80

Note: Specifications for recall and sweep speed are not provided for the N5230A analyzers.

29

Specifications: Front-Panel Jumpers

Table 18: Measurement receiver inputs (rcvr A In, rcvr B In, rcvr C in, rcvr D in)

0.1 dB Typical compression

Typical
Description Specification Option 245
Maximum input level

300 kHz to 10 MHz –11 dBm
10 MHz to 1 GHz –7 dBm
1 GHz to 12.5 GHz –6 dBm

12.5 GHz to 20 GHz –7 dBm

Damage level

N5230A +15 dBm

Maximum DC level

N5230A ±16 V

Table 19: Reference receiver input (rcvr in)

at maximum specified output power

Typical
Description Specification Option 245
Maximum input level

300 kHz to 10 MHz –15 dBm
10 MHz to 45 MHz –15 dBm
45 MHz to 500 MHz –15 dBm
500 MHz to 4 GHz –15 dBm
4 GHz to 6 GHz –16 dBm
6 GHz to 10.5 GHz –20 dBm

10.5 GHz to 15 GHz –21 dBm
15 GHZ to 20 GHz –27 dBm

Damage level

N5230A +15 dBm

Maximum DC level

N5230A ±16 V

Table 20: Reference output (source out)

at maximum specified output power

Typical
Description Specification Option 245
Maximum output level

300 kHz to 10 MHz –15 dBm
10 MHz to 45 MHz –15 dBm
45 MHz to 500 MHz –15 dBm
500 MHz to 4 GHz –15 dBm
4 GHz to 6 GHz –15 dBm
6 GHz to 10.5 GHz –20 dBm

10.5 GHz to 15 GHz –21 dBm
15 GHZ to 20 GHz –27 dBm

Damage level

N5230A +27 dBm

Maximum DC level

N5230A ±16 V

30

Table 21: Source outputs (port 1 source out, port 2 source out, port 3 source out, port 4 source out)

at maximum specified output power

Typical
Description Specification Option 245
Maximum output level

300 kHz to 10 MHz +10 dBm
10 MHz to 45 MHz +10 dBm
45 MHz to 500 MHz +10 dBm
500 MHz to 4 GHz +10 dBm
4 GHz to 6 GHz +9 dBm
6 GHz to 10.5 GHz +4 dBm

10.5 GHz to 15 GHz +1 dBm
15 GHZ to 20 GHz –4 dBm

Damage level

N5230A +27 dBm

Maximum DC level

N5230A ±16 V

Table 22: Coupler inputs (port 1 cplr thru, port 2 cplr thru, port 3 cplr thru, port 4 cplr thru)

Insertion loss of coupler thru

Typical
Description Specification Option 245
Insertion loss to test port

300 kHz to 10 MHz 1.5 dB
10 MHz to 45 MHz 1.5 dB
45 MHz to 500 MHz 1.5 dB
500 MHz to 4 GHz 2.0 dB
4 GHz to 6 GHz 2.5 dB
6 GHz to 10.5 GHz 2.5 dB

10.5 GHz to 15 GHz 3.0 dB
15 GHZ to 20 GHz 3.0 dB

Damage level

N5230A +27 dBm

Maximum DC level

N5230A ±16 V

Table 23: Coupler outputs (port 1 cplr arm, port 2 cplr arm, port 3 cplr arm, port 4 cplr arm)

Typical
Description Specification Option 245
Damage level

N5230A +15 dBm

Maximum DC level

N5230A 0 V

31

Test Set Block Diagrams

N5230A Option 240
(standard test set and standard power range)
network analyzer

N5230A Option 245
(configurable test set and extended power range)
network analyzer

Source

Switch

PORT 4

Coupler arm
Receiver D in

Source out
Coupler thru

PORT 3

Coupler arm
Receiver C in

Source out
Coupler thru

PORT 2
Coupler thru

Source out

Receiver B in
Coupler arm

PORT 1

Coupler thru
Source out

Receiver A in
Coupler arm

D

R

Reference
receiver

Source out
Receiver R in

C

A

B

60 dB

Source

Switch

PORT 4

PORT 3

PORT 2

PORT 1

R

Reference
receiver

C

A

B

D

Intel®and Pentium®are US registered trademarks of
Intel Corporation.

I

www.agilent.com/find/emailupdates

Get the latest information on the products
and applications you select.

Web Resources

Visit our Web sites for additional product
information and literature.

PNA-L network analyzers:

www.agilent.com/find/pnal

PNA microwave network analyzers:

www.agilent.com/find/pna

Electronic calibration (ECal):

www.agilent.com/find/ecal

Test and measurement solutions:

www.agilent.com/find/accessories

www.agilent.com

Agilent Technologies’ Test and Measurement Support, Services, and Assistance

Agilent Technologies aims to maximize the value you receive, while minimizing your risk and problems. We strive to
ensure that you get the test and measurement capabilities you paid for and obtain the support you need. Our extensive
support resources and services can help you choose the right Agilent products for your applications and apply them suc­cessfully. Every instrument and system we sell has a global warranty. Two concepts underlie Agilent’s overall support
policy: “Our Promise” and “Your Advantage.”

Our Promise

Our Promise means your Agilent test and measurement equipment will meet its advertised performance and
functionality. When you are choosing new equipment, we will help you with product information, including realistic
performance specifications and practical recommendations from experienced test engineers. When you receive your
new Agilent equipment, we can help verify that it works properly and help with initial product operation.

Your Advantage

Your Advantage means that Agilent offers a wide range of additional expert test and measurement services, which
you can purchase according to your unique technical and business needs. Solve problems efficiently and gain a
competitive edge by contracting with us for calibration, extra-cost upgrades, out-of-warranty repairs, and onsite educa­tion and training, as well as design, system integration, project management, and other professional engineering servic­es. Experienced Agilent engineers and technicians worldwide can help you maximize your productivity, optimize the
return on investment of your Agilent instruments and systems, and obtain dependable measurement accuracy for the
life of those products.

www.agilent.com/find/open

Agilent Open simplifies the process of connecting and programming test systems to help engineers design, validate
and manufacture electronic products. Agilent offers open connectivity for a broad range of system-ready instruments,
open industry software, PC-standard I/O and global support, which are combined to more easily integrate test system
development.

For more information on Agilent Technologies’ products,
applications or services, please contact your local Agilent office.

Phone or Fax

United States: Korea:

(tel) 800 829 4444 (tel) [phone]
(fax) 800 829 4433 (fax) [phone]

Canada: Latin America:

(tel) 877 894 4414 (tel) [phone]
(fax) 800 746 4866 Taiwan:
China: (tel) 0800 047 866
(tel) 800 810 0189 (fax) 0800 286 331
(fax) 800 820 2816 Other Asia Pacific

Europe: Countries:

(tel) 31 20 547 2111 (tel) (65) 6375 8100
Japan: (fax) (65) 6755 0042
(tel) (81) 426 56 7832 Email: [e-mail]
(fax) (81) 426 56 7840

Contacts revised: 05/27/05

The complete list is available at:
www.agilent.com/find/contactus

Product specifications and descriptions in this document
subject to change without notice.

© Agilent Technologies, Inc. 2003, 2004, 2005
Printed in USA, July 21, 2005
5989-1695EN

www.agilent.com/find/agilentdirect

Quickly choose and use your test equipment
solutions with confidence.

Agilent Direct

Agilent Open
