Technical Specifications for the N3381A, N3382A, N3383A

Definitions....................................................................................................................................2

Corrected System Performance.................................................................................................3

Table 1. System Dynamic Range........................................................................................3

Corrected System Performance with Type-N Connectors..................................................4

Table 2. Corrected System Performance With 85032F Calibration Kit.........................4

Table 3. Corrected System Performance With 85092C ECal Module............................5

Corrected System Performance with 3.5 mm Conn ecto rs...................................................6

Table 4. Corrected System Performance With 85033E Calibration Kit........................6

Table 5. Corrected System Performance With 85093C Ecal Module.............................7

Table 6. Corrected System Performance With 85038A Calibration Kit........................8

Table 7. Uncorrected Instrument Performance................................................................9

Test Port Output Characteristics (Sourc e)...............................................................................9

Table 8. Test Port Output Frequency................................................................................9

Table 9. Test Port Output Power .....................................................................................10

Table 10. Test Port Output Signal Purity........................................................................10

Test Port and Receiver Input Characteristics........................................................................11

Table 11. Test Port and Receiver Input Levels...............................................................11

Table 11. Test Port and Receiver Input Levels...............................................................12

Table 12. Test Port Input (Trace Noise)..........................................................................12

Table 13. Test Port Input (Reference Level and Stability)............................................13

Table 14. Test Port Input (Dynamic Accuracy specification)........................................14

Table 15. Test Port Input (Group Delay)........................................................................15

General Information.................................................................................................................15

Table 16. System Bandwidths...........................................................................................15

Table 17. Front Panel Information..................................................................................16

Table 18. Rear Panel Information....................................................................................17

Table 19. Rear Panel Information (continued)...............................................................18

Table 20. Analyzer Environment and Dimensions.........................................................19

Measurement Throughput Summary.....................................................................................20

Table 21. Typical Cycle Time (ms)...................................................................................20

Table 22. Cycle Time vs. IF Bandwidth...........................................................................20

Table 23. Cycle Time vs. Number of Points

a

...................................................................21

Table 24. Data Transfer Timea (ms)................................................................................22

Table 25. Recall and Sweep Speed...................................................................................23

N3381A, N3382A, and N3383A Simplified Test Set Block Diagram...................................24

N3381A, N3382A, and N3383A with Option 014 Simplified Test Set Block Diagram ......25

1

This is a complete list of the N3381A, N3382A, and N3383A network analyzer technical specifications.

• To optimize viewing of uncertainty curves, click the Maximize button.

• To view or print the PNA Series Data Sheet (a condensed version of the specifications), visit our web

site at http://www.agilent.com/find/pna, select your analyzer model, and click on the link for the data
sheet.

• The uncertainty curves contained in this document apply only to the setup conditions listed. Please
download our free Uncertainty Calculator from http://www.agilent.com/find/na_calculator
curves for your PNA setup. View the equations



used to generate the uncertainty curves.

to generate the

Definitions

All specifications and characteristics apply over a 25 °C ±5 °C range (unless otherwise stated) and 90 minutes
after the instrument has been turned on.

Specification (spec.): Warranted performance. Specifications include guardbands to account for the expected
statistical performance distribution, measurement uncertainties, and changes in performance due to
environmental conditions.

Characteristic (char.): A performance parameter that the product is expected to meet before it leaves the
factory, but that is not verified in the field and is not covered by the product warranty. A characteristic includes
the same guardbands as a specification.

Typical (typ.): Expected performance of an average unit which does not include guardbands. It is not covered
by the product warranty.

Nominal (nom.): A general, descriptive term that does not imply a level of performance. It is not covered by the
product warranty.

Calibration: The process of measuring known standards to characterize a network analyzer's systematic
(repeatable) errors.

Corrected (residual): Indicates performance after error correction (calibration). It is determined by the quality of
calibration standards and how well "known" they are, plus system repeatability, stability, and noise.

Uncorrected (raw): Indicates instrument performance without error correction. The uncorrected performance
affects the stability of a calibration.

Standard: When referring to the analyzer, this includes no options unless noted otherwise.

2

Corrected System Performance

Note: This document provides technical specifications for the following calibration kits only: 85032F, 85092C,

85033E, 85093C and 85038A.
The specifications in this section apply for measurements made with the N3381A, N3382A, and N3383A

analyzer with the following conditions:

• 10 Hz IF bandwidth

• No averaging applied to data

• Environmental temperature of 25 °C ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Table 1. System Dynamic Range

Description Specification (dB) Characteristic (dB)
Dynamic rangea (at test port)

300 kHz to 25 MHz
25 MHz to 3 GHz
3 GHz to 6 GHz 118
6 GHz to 9 GHz 115

Dynamic rangec (at receiver input)

300 kHz to 25 MHz
25 MHz to 3 GHz
3 GHz to 6 GHz
6 GHz to 9 GHz

b

125

b

128

d

d

140
143
133
130

a

The test port dynamic range is calculated as the difference between the test port rms noise floor and the source maximum output power.

The effective dynamic range must take measurement uncertainties and interfering signals i nto acc ount.

b

May be limited to 100 dB at particular frequencies below 750 MHz due to spurious receiver residuals.

c

The receiver input dynamic range is calculated as the difference between the receiver rms noise floor and the source maximum output
power. The effective dynamic range must take measurement uncertainties and interfering si gnals i nto acc ount. This set-up should onl y be
used when the receiver input will never exceed its damage level. When the analyzer is in segment sweep mode, frequency segments can be
defined with a higher power level when the extended dynamic range is required (i.e. the portion of the device's response with high insertion
loss), and reduced power when receiver damage may occur (i.e. the portion of the devices's response with low insertion loss). Specification
applies only when power is sourced from Port 1. If power is sourced from either Port 2 or Port 3, dynamic range decreases by 3 dB.

d

May be limited to 115 dB at particular frequencies below 750 MHz due to spurious receiver residuals.

Note: Receiver Dynamic Range specifications are not included in this N3381/2/3A document.

3

Corrected System Performance with Type-N Connectors

Table 2. Corrected System Performance With Type-N Device Connectors, 85032F Calibration
Kit

Applies to the N3381A, N3382A, and N3383A analyzer, 85032F (Type-N, 50Ω) cali brat ion kit, N6314A test port cable, and a full 2-port
calibration. Also applies to the following conditions:

• IF bandwidth = 10 Hz

• No averaging applied to data

• Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Specification (dB) Description
300 kHz to

1.3 GHz

Directivity 49 46 40 38
Source Match 41 40 36 35
Load Match 49 45 39 37
Reflection Tracking ±0.011 ±0.021 ±0.032 ±0.054
Transmission
Tracking

Transmission Uncertainty (Specifications)

±0.012 ±0.020 ±0.055 ±0.083

1.3 GHz to
3 GHz

3 to
6 GHz

6 to
9 GHz

Reflection Uncertainty (Specifications)

4

Table 3. Corrected System Performance With Type-N Device Connectors, 85092C Electronic
Calibration Module

Applies to the N3381A, N3382A, and N3383A analyzer, 85092C (Type-N, 50Ω) electronic cal i bration (ECal) m odul e, N6314A test port cable,
and a full 2-port calibration. Also applies to the following conditions:

• IF bandwidth = 10 Hz

• No averaging applied to data

• Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Specification (dB) Description
300 kHz to

1.3 GHz

Directivity 52 54 52 47
Source Match 45 44 41 36
Load Match 47 47 44 39
Reflection Tracking ±0.040 ±0.040 ±0.060 ±0.070
Transmission
Tracking

Transmission Uncertainty (Specifications)

±0.039 ±0.039 ±0.068 ±0.136

1.3 GHz to
3 GHz

3 to
6 GHz

6 to
9 GHz

a

Reflection Uncertainty (Specifications)

5

Corrected System Performance with 3.5 mm Connectors

Table 4. Corrected System Performance With 3.5 mm Device Connector Type, 85033E
Calibration Kit

Applies to the N3381A, N3382A, and N3383A analyzer, 85033E (3.5 mm, 50Ω) calibration kit, N6314A test port cable, and a full 2-port
calibration. Also applies to the following conditions:

• IF bandwidth = 10 Hz

• No averaging applied to data

• Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Directivity 46 44 38 38
Source Match 43 40 37 36
Load Match 46 44 38 38
Reflection Tracking ±0.006 ±0.007 ±0.009 ±0.010
Transmission
Tracking

Transmission Uncertainty (Specifications)

Specification (dB) Description
300 kHz to

1.3 GHz

±0.012 ±0.021 ±0.057 ±0.075

1.3 GHz to
3 GHz

3 to
6 GHz

6 to
9 GHz

Reflection Uncertainty (Specifications)

6

Table 5. Corrected System Performance With 3.5 mm Device Connector Type, 85093C
Electronic Calibration Module

Applies to the N3381A, N3382A, and N3383A analyzer, 85093C (3.5 mm, 50Ω) electronic calibration (ECal) module, N6314A test port
cable, and a full 2-port calibration. Also applies to the following conditions:

• IF bandwidth = 10 Hz

• No averaging applied to data

• Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Specification (dB) Description
300 kHz to

1.3 GHz

Directivity 52 52 51 47
Source Match 44 44 39 34
Load Match 47 47 44 40
Reflection Tracking ±0.030 ±0.040 ±0.050 ±0.070
Transmission
Tracking

Transmission Uncertainty (Specifications)

±0.039 ±0.049 ±0.068 ±0.117

1.3 GHz to
3 GHz

3 to
6 GHz

6 to

a

9 GHz

Reflection Uncertainty (Specifications)

7

Table 6. Corrected System Performance With 7-16 Device Connector Type, 85038A Calibration
Kit

Applies to the N3381A, N3382A, and N3383A analyzer, 85038A (7-16, 50Ω) calibration kit, N6314A test port c abl e, and a full 2-port
calibration. Also applies to the following conditions:

• IF bandwidth = 10 Hz

• No averaging applied to data

• Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration temperature

• Isolation calibration not omitted

Specification (dB) Description
300 kHz to

1.3 GHz

Directivity 40 40 36 36
Source Match 37 37 34 34
Load Match 39 39 35 35
Reflection Tracking ±0.089 ±0.089 ±0.115 ±0.115
Transmission
Tracking

Transmission Uncertainty (Specifications)

±0.024 ±0.033 ±0.082 ±0.103

1.3 GHz to
3 GHz

3 to
6 GHz

6 to
9 GHz

a

Reflection Uncertainty (Specifications)

8

Table 7. Uncorrected Instrument Performance

Specification (dB) Description
300 kHz to
1 MHz

Directivity 30 33 27 20 13
Source Match
Ports 1 and 2
Source Match
Port 3 only
Load Match
Ports 1 and 2
Load Match
Port 3 only
Reflection
Tracking
Transmission
Tracking

18 18 17 14 12
18 18 17 14 12
20 20 17 13.5 11.5
20 20 17 13.5 11.5
±1.5 ±1.5 ±1.5 ±2.5 ±3.0
±1.5 ±1.5 ±1.5 ±2.5 ±3.0

1MHz to

1.3 GHz

1.3 GHz to
3 GHz

3 GHz to
6 GHz

6 GHz to
9 GHz

Test Port Out put Characteristics (Source )

Table 8. Test Port Output Frequency

Description Specification Supplemental Information
Range:

N3381A 300 kHz to 3.0 GHz
N3382A 300 kHz to 6.0 GHz
N3383A 300 kHz to 9.0 GHz

Resolution
Source Stability

Source Stability
(Option 1E5)

CW Accuracy
CW Accuracy

(Option 1E5)

1 Hz

±3 ppm

±1 ppm

±1 ppm, 0° to 40 °C, typical
±1ppm/year maximum
±0.05 ppm, 0° to 40 °C, typical
±0.1 ppm/year maximum

9

Table 9. Test Port Output Power

a

Description Specification Supplemental Information
Level Accuracy

Variation from 0 dBm in power range
0
(step attenuator at 0 dB)

±1.5dB below 10 MHz

300 kHz to 6 GHz ±1.0 dB
6 GHz to 9 GHz ±2.0 dB

Level Linearity

Variation from 0 dBm in power range
0

300 kHz to 9 GHz ±0.3 dB -15 to +5 dBm
300 kHz to 1 MHz ±1.0 dB +5 to +10 dBm
1 MHz to 6 GHz ±0.5 dB +5 to +10 dBm
6 GHz to 9 GHz ±0.5 dB +5 to +7 dBm

Range

300 kHz to 6 GHz -15 to +10 dBm
6 GHz to 9 GHz -15 to +7 dBm

Range

b

b

(Option 1E1)
300 kHz to 6 GHz -85 to +10 dBm

6 GHz to 9 GHz -85 to +7 dBm

Sweep Range

Port 1:
300 kHz to 6 GHz 25 dB

6 GHz to 9 GHz 22 dB

Level Resolution

a

Source output performance on port 1 only. Port 2 and port 3 output performance is typically 3 dB less.

b

Power to which the source can be set and phase lock is assured.

0.01 dB

Table 10. Test Port Output Signal Purity

Description Specification Supplemental Information
Harmonics (2nd or 3rd)

at max output power (< 25 MHz)
at max output power (25 MHz to

9 GHz)
at 0 dBm output

at -10 dBm output

Non-harmonic Spurious

at max output
at -10 dBm output

a

Typical below 25 MHz.

< -25 dBc, typical
< -25 dBc, characteristic

a

< -35 dBc, typical
< -38 dBc, typical, in power

range 0

-30 dBc, typical for offset freq>1kHz

-50 dBc, typical for offset freq >1kHz

10

Test Port and Receiver Input Characteristics

Table 11. Test Port and Receiver Input Levels

Description Specification Supplemental Information
Maximum Test Port Input Level

300 kHz to 25 MHz +10 dBm <0.6 dB compression
25 MHz to 3 GHz +10 dBm <0.4 dB compression
3 GHz to 6 GHz +10 dBm <0.7 dB compression
6 GHz to 9 GHz +7 dBm <0.7 dB compressi on

Damage Level

Test Port 1, 2. 3
R, A, B, C (Opt. 014)
Coupler Thru (Opt. 014)

Test Port Noise Floor

300 kHz to 25 MHz
10 Hz IF Bandwidth -115 dBm

1 kHz IF Bandwidth -95 dBm
25 MHz to 3 GHz

10 Hz IF Bandwidth -118 dBm
1 kHz IF Bandwidth -98 dBm
3 GHz to 9 GHz

10 Hz IF Bandwidth
1 kHz IF Bandwidth

Receiver Noise Floor

300 kHz to 25 MHz
10 Hz IF Bandwidth

1 kHz IF Bandwidth
25 MHz to 3 GHz

10 Hz IF Bandwidth -133 dBm,
1 kHz IF Bandwidth -113 dBm,
6 GHz to 9 GHz

10 Hz IF Bandwidth
1 kHz IF Bandwidth

a

b

b

a

c

c

≤ -108 dBm
≤ -88 dBm

≤ -130 dBm,

characteristic
≤ -110 dBm,

characteristic

characteristic
characteristic

≤ -123 dBm,
characteristic

≤ -103 dBm,
characteristic

+30 dBm or ±30 VDC, typ.
+15 dBm or ±5 VDC, typ.
+33 dBm or ±0 VDC, typ.

11

Table 11. Test Port and Receiver Input Levels

Description Specification Supplemental Information
Crosstalk

(S21, S31):
300 kHz to 1 MHz <-120 dB

1 MHz to 25 MHz <-125 dB
25 MHz to 3 GHz <-126 dB
3 GHz to 6 GHz <-117 dB
6 GHz to 9 GHz <-106 dB
(S12, S13):

300 kHz to 1 MHz <-120 dB
1 MHz to 25 MHz <-125 dB
25 MHz to 3 GHz <-126 dB
3 GHz to 6 GHz <-113 dB
6 GHz to 9 GHz <-106 dB
(S23, S32):

300 kHz to 1 MHz <-120 dB
1 MHz to 3 GHz <-125 dB
3 GHz to 6 GHz <-115 dB
6 GHz to 9 GHz <-107 dB

Maximum Receiver Input Level (A, B, R, C)

300 kHz to 6 GHz
6 GHz to 9 GHz

Reference Input Level (R)

300 kHz to 9 GHz

d

6 dBm, typical
9 dBm, typical

-10 to -35 dBm, typical

Maximum Coupler Input Level (Opt 014)

300 kHz to 9 GHz

a

Total average (RMS) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.

b

May be limited to -90 dBm at particular frequencies below 750 MHz due to spurious receiver residuals.

c

May be limited to -105 dBm at particular frequencies below 750 MHz due to spurious receiver residuals.

d

Input level to maintain phase lock.

+33 dBm, typical

Table 12. Test Port Input (Trace Noise)

Description Specification Supplemental Information
Trace Noisea Magnitude

1 kHz IF Bandwidth < 0.002 dB rms
10 kHz IF Bandwidth < 0.005 dB rms

Trace Noisea Phase

1 kHz IF Bandwidth < 0.010° rms
10 kHz IF Bandwidth < 0.035° rms

a

Trace noise is defined as a ratio measurement of a through or a full reflection, with the source set to 0 dBm.

12

Table 13. Test Port Input (Reference Level and Stability)

Description Specification Supplemental Information
Reference Level Magnitude

Range ±200 dB
Resolution 0.001 dB

Reference Level Phase

Range ±500°
Resolution 0.01°

Stability Magnitude

300 kHz to 3 GHz
3 GHz to 6 GHz
6 GHz to 9 GHz

Stability Phase

300 kHz to 3 GHz
3 GHz to 6 GHz
6 GHz to 9 GHz

a

Stability is defined as a ratio measurement at the test port.

a

a

0.02 dB/°C, typical

0.04 dB/°C, typical

0.06 dB/°C, typical

0.2°/°C, typical

0.3°/°C, typical

0.6°/°C, typical

13

Table 14. Test Port Input (Dynamic Accuracy specificationa)

• Accuracy of the test port input power reading is relative to the reference input power level. Applies to input ports 1 and 2 with the

following conditions: IF bandwidth = 10 Hz, and Environmental temperature 25° ±5 °C, with < 1 °C deviation from calibration
temperature

300 kHz to 3 GHz 300 kHz to 3 GHz

300 kHz to 6 GHz 300 kHz to 6 GHz

300 kHz to 9 GHz 300 kHz to 9 GHz

a

Dynamic accuracy is verified with the following measurements:

• compression over frequency

• IF linearity at a single frequency of 1.195 GHz and a reference level of -20 dBm

14

Table 15. Test Port Input (Group Delay)

Description Specification Supplemental Information

Aperture
(selectable)

Maximum
Aperture
Range 0.5 x (1/minimum

Maximum Delay

Accuracy
The following graph shows group delay accuracy with type-N full 2-port calibration

and a 10 Hz IF bandwidth. Insertion loss is assumed to be < 2 dB and electrical
length to be ten meters.

(frequency
span)/(number of
points -1)
20% of frequency
span

aperture)

Limited to measuring no more than 180° of
phase change within the minimum
aperture.)
See graph below. Char.

a

In general, the following formula can be used to determine the accuracy, in
seconds, of specific group delay measurement:

±Phase Accuracy (deg)/[360 × Aperture (Hz)]
Depending on the aperture and devic e len gth, the phas e accur ac y used is either

incremental phase accuracy or worst case phase accuracy.

a

Group delay is computed by measuring the phase change within a specified frequency step (determined by the frequency span and the

number of points per sweep).

General Information

Table 16. System Bandwidths

Description Specification Supplemental Information
IF Bandwidth Settings

Range

1 Hz to 40 kHz in a 1, 2, 3, 5, 7,10 sequence up to 30 kHz,
35 kHz, 40kHz, nominal

15

Table 17. Front Panel Information

Description Supplemental Information
RF Connectors

Type
Center Pin Protrusion 0.204 to 0.207 in., characteristic

Probe Power

Connector 3-pin connector, male
Positive Supply +15 VDC ±2%, 400 mA, max, characteristic
Negative Supply -12.6 VDC ±5%, 300 mA, max, characteristic

Display

Size 21.3 cm (8.4 in) diagonal color active matrix LCD; 640
Refresh Rate Vertical 59.83 Hz; Horizontal 31.41 Hz

Display Range

Magnitude

Phase ±180°, max
Polar

Display Resolution

Magnitude 0.001 dB/div, min
Phase 0.01°/div, min

Marker Resolution

Magnitude 0.001 dB, min
Phase 0.01°, min
Polar 0.01 mUnit, min; 0.01°,min

Type-N, female; 50 Ω, nominal

(horizontal) X 480 (vertical) resolution

±200 dB (at 20 dB/div), max

10 pUnits, min
1000 Units, max

16

Table 18. Rear Panel Information

Description Supplemental Information
10 MHz Reference In

Connector BNC, female
Input Frequency 10 MHz ± 1 ppm, typical
Input Level -15 dBm to +20 dBm, typical
Input Impedance

10 MHz Reference Out

Connector BNC, female
Output Frequency 10 MHz ± 10 ppm, typical
Signal Type Sine Wave, typical
Output Level
Output Impedance
Harmonics <-40 dBc, typical

VGA Video Output

Connector 15-pin mini D-Sub; Drives VGA compatible monitors
Devices Supported: Resolutions:
Flat Panel (TFT) 1024 X 768, 800 X 600, 640 X 480
Flat Panel (DSTN) 800 X 600, 640 X 480
CRT Monitor 1280 X 1024, 1024 X 768, 800 X 600, 640 X 480

Test Set IO
Aux IO

Handler IO

GPIB
Parallel Port (LPT1)
Serial Port (COM 1)

USB Port

Contact 1 Vcc: 4.75 to 5.25 VDC, 500 mA, maximum
Contact 2 -Data
Contact 3 +Data
Contact 4 Ground

LAN

Line Power

Frequency at 110/115 V 50/60/400 Hz
Frequency at 230/240 V 50/60Hz
Maximum Watts 350 W

a

A third-wire ground is required.

b

Power supply has a voltage autoswitching feature.

Note: Option H08 and Option H11 specifications are not provided in this N3381/2/3A specifications document.

a, b

200 Ω, nom.

+10 dBm ± 4 dB into 50 Ω, typical
50 Ω, nominal

Simultaneous operation of the internal and external
displays is allowed, but with 640 X 480 resolution only.
If you change resolution, you can only view the external
display (internal display will "white out").
25-pin D-Sub connector, available for external test set
control
25-pin D-Sub connector, male, analog and digital IO
36-pin IDC D-ribbon socket connector; all input/output
signals are default set to negative logic; can be reset to
positive logic via GPIB command
24-pin D-sub (Type D-24), female; compatible with
IEEE-488.
25-pin D-Sub connector, female; provides connection to
printers or any other parallel port peripherals
9-pin D-Sub, male; compatible with RS-232

Universal Serial Bus jack, Type A configuration (4
contacts inline, contact 1 on left); female

10/100BaseT Ethernet, 8-pin configuration; auto selects
between the two data rates

17

Table 19. Rear Panel Information (continued)

Description Supplemental Information
External AM Input

Description Input provides low-frequency AM modulation to test port output

signal, or shifts the test port output. Zero volts input gives the
power level set by the instrument, a positive voltage gives a
higher level, and a negative voltage gives a lower level.

Connector BNC, female
Input Sensitivity 8 dB/V, typical
Bandwidth 1 kHz, typical
Input Impedance

External Detector Input

Description Input from an external, negative polarity diode detector provides
Connector BNC, female

Input Sensitivity -500 mV yields approximately -3 dBm at detector's input, typical
Bandwidth 50 kHz, typical
Input Impedance

1 kΩ, nominal

ALC for a test port remote from instrument's front panel

1 kΩ, typical

18

Table 20. Analyzer Environment and Dimensions

Description Supplemental Information
General Environmental

RFI/EMI Susceptibility Defined by CISPR Pub. 11, Group 1, Class A, and IEC

50082-1

ESD Minimize using static-safe work procedures and an

antistatic bench mat

Dust Minimize for optimum reliability

Operating Environment

Temperature

Error-Corrected Temperature Range 25°C ± 5°C
Humidity 5% to 95% at +40 °C

Altitude 0 to 4500 m (14,760 ft.)

Non-Operating Storage Environment

Temperature -40 °C to +70 °C
Humidity 0% to 90% at +65 °C (non-condensing)
Altitude 0 to 15,240 m (50,000 ft.)

Cabinet Dimensions

Excluding front and rear
panel hardware and feet
As shipped - includes front
panel connectors, rear
panel bumpers, and feet.
As shipped plus handles 235 mm

As shipped plus rack­mount flanges
As shipped plus handles
and flanges

Weight

Net 24 kg (54 lb), nominal
Shipping 32 kg (70 lb), nominal

Note: "Misc. Information" specifications are not included in this N3381/2/3A document.

Height Width Depth

223 mm

8.75 in
235 mm

9.25 in

9.25 in
235 mm

9.25 in
235 mm

9.25 in

0 °C to +40 °C
Instrument powers up, phase locks, and displays no

error messages within this temperature range.
with less than 1°C deviation from calibration temp.

426 mm

16.75 in
435 mm

17.10 in
458 mm

18 in
483 mm
19 in
483 mm
19 in

427 mm

16.8 in
470 mm

18.5 in
501 mm

19.70 in
470 mm

18.5 in
501 mm

19.70 in

19

Measurement Throughput Summary

Table 21. Typical Cycle Time

Start 1.8 GHz, Stop 2 GHz, 35 kHz IF bandwidth

Uncorrected,
1-port cal
2-Port cal 27 36 55 164

Start 300 kHz, Stop 3 GHz, 35 kHz IF bandwidth

Uncorrected,
1-port cal
2-Port cal 103 119 145 254

Start 300 kHz, Stop 9 GHz, 35 kHz IF bandwidth

Uncorrected,
1-port cal
2-Port cal 99 119 133 212

a Typical performance.
b Includes sweep time, retrace time and band-crossing time. Analyzer display turned off with

DISPLAY:ENABLE OFF. Add 21 ms for display on. Data for one trace (S11) measurement.
c Option 010 only. Analyzer display turned off with DISPLAY:ENABLE OFF. Add 21 ms for display on. Data for one trace (S11)
measurement.

Number of Points
101 201 401 1601

8 11 17 53

48 54 64 104

45 55 61 99

Table 22. Cycle Time vs. IF Bandwidth

Applies to the Preset c onditi on (201 points, correction off) except for the following changes:

a,b

(ms)

a

• CF = 1 GHz

• Span = 100 MHz

• Display off (add 21 ms for display on)

IF
Bandwidth
(Hz)

Cycle Time

b

(ms)

40,000 8
35,000 9
30,000 11
20,000 13
10,000 28
7000 36
5000 48
3000 72
1000 196
300 620
100 1875
30 8062
10 17877

a

Typical performance.

b

Cycle time includes sweep and retrace time.

20

Table 23. Cycle Time vs. Number of Points

Applies to the Preset condition (35 kHz IF bandwidth, correction off) except for t he following changes:

a

• CF = 1 GHz

• Span = 100 MHz

• Display off (add 21 ms for display on)

Number of
Points

Cycle Time (ms)

b

3 4
11 4
51 5
101 6
201 9
401 16
801 29
1601 52

a

Typical performance.

b

Cycle time includes sweep and retrace time.

21

Table 24. Data Transfer Timea (ms)

SCPI over GPIB
(program executed on external PC)

32-bit floating point 3 7 12 43
64-bit floating point 4 12 22 84
ASCII 7 64 124 489

SCPI over 100 Mbit/s LAN
(program executed on external PC)

32-bit floating point 1 1 1 1
64-bit floating point 1 1 1 2
ASCII 5 15 26 96

SCPI (program executed in the analyzer)

32-bit floating point 1 1 2 3
64-bit floating point 1 2 2 4
ASCII 8 29 56 222

COM (program executed in the analyzer)

32-bit floating point 1 1 1 1
Variant type 1 1 2 6

DCOM over 100 Mbit/s LAN
(program executed on external PC)

32-bit floating point
Variant type

a

Typical performance of unit with 500 MHz Pentium III processor.

b

Measured using a VEE 5.0 program running on a 600 MHz HP Kayak, National InstrumentsTM GPIB card.

Transferred complex S11 data , using "CALC:DATA?SDATA".

c

Measured using a VEE 5.0 program running on a 600 MHz HP Kayak. Transferred complex S11 data,

using "CALC:DATA?SDATA". Speed dependent on LAN traffic, if connected to network.

d

Measured using a VEE 5.0 program running inside PNA Series Analyzer. Transferred complex S11 data,

using "CALC: DATA?SDATA".

e

Measured using a Visual Basic 6.0 program running inside PNA Series Analyzer. Transferred complex S11

data.

f

Measured using a Visual Basic 6.0 program running on a 600 MHz HP Kayak. Transferred

complex S11 data. Speed dependent on LAN traffic, if connected to network.

g

Used IArray Transfer.getComplex method for 32-bit floating point.

h

Used meas.getData method for Variant data type.

h

g

1 3 6 19

Number of Points
51 201 401 1601

b

b

d

e

f

1 1 1 2

22

Table 25. Recall and Sweep Speed

Operations

Number of
Window(s)

a

Number of
Trace(s)

Recall
Time (ms)

Recall 1 1 49
Recall and Sweep 1 1 59

Recall 1 2 82
Recall and Sweep 1 2 96

Recall 1 4 159
Recall and Sweep 1 4 203

Recall 2 2 93
Recall and Sweep 2 2 115

Recall 3 4 158
Recall and Sweep 3 4 218

Recall 4 4 187
Recall and Sweep 4 4 247

Recall 4 8 340
Recall and Sweep 4 8 507

a

CF=177MHz, Span=200 MHz, 201 points, 35 kHz IF BW

23

N3381A, N3382A, and N3383A Simplified Test Set Block Diagram

24

N3381A, N3382A, and N3383A with Option 014 Simplified Test Set Block Diagram

25
