HP N1020A—at a glance 2
Installing the Probe 4
Normalizing the Probe 6
Probe Characteristics 10
Replaceable Parts 11
Contacting HP 12
Safety Symbols 14

HP N1020A TDR Probe

HP N1020Aat a glance
The HP N1020A TDR Probe facilitates accurate, repeat­able time domain reflectometry measurements in situa­tions where RF connectors are unavailable. It is ideal for use with the HP 54753A and HP 54754A TDR plug-in modules.
Figure 1. HP N1020A TDR Probe
The HP N1020A TDR Probe includes the following items:
RF cable (SMA, 36-inch)
Calibration substrate (quantity 2)
Grounding pin
Tweezer
2
Figure 2. Probe tip and grounding pin

Accessories available

The following accessories are available from Cascade Microtech®.
Internet address: http://www.cascademicrotech.com
Fixed-pitch compliant 50 hybrids, and MCMs. Bandwidth from dc to 20 GHz. Order FPC-GSG-xxxx probe.
Fine-pitch active 100k brids, and MCMs. Bandwidth from dc to 2.5 GHz. Or­der FPA-10X probe.
DC coaxial microprobes
Fine-pitch microprobes
Fine-pitch DC needle holder
probe for testing SMTs,
probe for testing SMTs, hy-
3

Installing the Probe

Locate the
1
grounding pin supplied with the probe.
As explained in
2
the following caution statement, insert the long end of the grounding pin into one of the holes that are located in the tip of the probe. Select any hole that is located in the spiral pattern.
CAUTION
connected by a spring. To avoid damaging the grounding pin, always insert the longest solid end into the probe tip.
Using tweezers, gently push the pin until it is fully
3
seated into the hole.
Connect the supplied SMA cable to the TDR probe.
4
CAUTION
can be damaged by electrostatic discharge.
Discharge any static buildup on the SMA cable.
5
Momentarily short the center and outer conductors of the cable together. Avoid touching the front-panel input connectors without first touching the frame of the instrument.
4
The grounding pin consists of two solid end pieces
The input circuits on the HP 83480A plug-in modules
6 Connect the other end of the SMA cable to the TDR
plug-in module’s Channel input connector.

Moving the grounding pin

The probe comes with a movable grounding pin to make connections to the ground plane easier. Use the follow­ing steps to move of grounding pin:
1 Using the supplied tweezers, gently pull the pin out
of the probe tip.
2 Insert the pin into one of the adjacent, conveniently-
located holes. Notice that these holes are in a spiral pattern.
3 Using the tweezers, gently push the pin until it is
fully seated into the hole.
5

Normalizing the Probe

Normalizing the probe ensures accurate measurements with HP 54753A and HP 54754A TDR plug-in modules. To learn more about normalization, refer to the
HP 83480A User’s Guide and the HP 54753A and HP 54754A User’s Guide. For the most recent version
of these books, visit the following Internet web site http:/ /www.hp.com/go/lightwave, and click on Support.
The TDR probe comes with two identical calibration substrates. During the normalization procedure, the cal­ibration substrate is used to move the measurement plane from the module’s input connector to the end of the probe tip. Each calibration substrate provides one
short pad, three 28
75
pads for probing. Three pads of each type are pro­vided in the event that pads becomes damaged or worn out with use.
When probing, always connect the probes ground to the larger side of the resistant pad.
pads, three 50Ω pads, and three
Figure 3. Calibration substrate
6
The 28
and 75Ω pads are provided so that you can verify measurement normalization on devices that have a characteristic impedance other than 50Ω. For exam­ple, Rambus®
*
technology has a 28Ω characteristic
impedance. Regardless of the characteristic impedance
of the device being measured, always use the 50
ter-
mination pad during the normalization procedure.
CAUTION
Do not touch the 75Ω, 50Ω, or 28Ω pads. These pads are precision resistors. Their values can be altered by contamination (such as oils and dirt) or electrostatic discharge.

To normalize the probe

1 Press the Setup key and then Default setup on the
HP 83480A mainframe.
2 Remove any connections from the HP 54753A or
HP 54754A front-panel channel input connectors.
3 Press Utility, Calibrate, and then Calibrate plug-in.
4 Select the plug-in module to be calibrated, press 1
and 2 or 3 and 4.
5 Press Start cal to start the calibration, and follow the
on-screen instructions. This step completes a plug­in module vertical calibration.
CAUTION
The input circuits on the HP 83480A plug-in modules can be damaged by electrostatic discharge.
6 Discharge any static buildup on the TDR probe’s
SMA cable. Momentarily short the center and outer conductors of the cable together. Avoid touching the front-panel input connectors without first touching
*. Rambus® is a trademark of Rambus Inc.
7
the frame of the instrument.
7 Connect the SMA cable on the probe to the TDR
plug-in module’s Channel input connector.
8 Press Setup on the TDR plug-in module. Press
Stimulus and select 1 only. Press Enter and then Preset TDR/TDT.
9 Connect the TDR probe to the device that you are
testing.
10 Use the HP 83480A’s Time base key to adjust the time
scale and position so that the desired response is displayed. Changing the time base setting after the calibration voids the calibration.
The following two steps perform a normalization rou­tine. These steps move the measurement plane from the modules input connector to the end of the probe tip.
11 Press Setup on the plug-in module. Press Normalize
response and then Establish normalization & ref plane.
12 Follow the onscreen instructions (upper left-hand
corner). Use the short and 50 calibration substrate for short and 50 terminations.
pads on the
NOTE
and 50 procedure, you can use the 28 ment accuracy for devices having a characteristic impedance of 28Ω or 75Ω.
The following two steps activate the normalized response.
8
During the normalization procedure, use only the short
termination pads on the calibration substrate. After the
pad or 75Ω pad to verify measure-
13 Press Setup on the TDR plug-in module.
14 Press Normalize Response and then set TDR normalize to
on.
15 Press Channel 1/3 and then set Display to off. This step
is optional.
16 On the HP 83480A mainframe, press Marker. Set Mode
to TDR/TDT.
17 Set
+
Source to response 1 and then press Enter.
18 Set Reference so that ref plane is selected.
19 Press
20 Press
21 Set × Source to response 1 and then press Enter.
Use the following optional steps to simulate the imped­ance profile of the device that you are testing as a func­tion of the incident TDR step rise time.
22 Press Setup on the TDR plug-in module.
23 Press Normalize response and then Risetime.
24 Enter the desired rise time, and then press Enter.
Setting the rise time value too fast results in a noisy normalized waveform. This is because the bandwidth of the system has been exceeded. Increase the rise time until the noise on the normalized waveform disappears.
+
Position, the 0 key, and then the Enter key that
is located next to the numeric keypad.
×
Position, the 0 key, and then the Enter key that
is located next to the numeric keypad.
+
and × markers should now be visible on the
The displayed normalized response.
9

Probe Characteristics

There are no specifications for HP N1020A TDR Probe. (Product specifications describe warranted perfor­mance.) However, the following characteristics provide useful information by giving functional, but nonwar­ranted, performance parameters.
Table 1. Characteristics of TDR Probe
Description Characteristic
Bandwidth DC to 6 GHz
.Insertion loss < 1.5 dB
Return loss > 16 dB
Connector 3.5 mm SMA
Weight 1.3 kg
Joystick travel 17 x 17 x 13 mm
Arm reach 100 to 220 mm
Arm sweep angle
Probe pitch 1.5 to 5.0 mm
10
+90
°

Replaceable Parts

The following table lists the replaceable parts for the probe. Notice that the grounding pin must be ordered from Inter-Continental Microwave Company:
Phone: . . . . . . . . . . . . . . . . . . . . . . . . . . . (408) 727-1596
Fax number: . . . . . . . . . . . . . . . . . . . . . . (408) 727-0105
Internet address: . . . . . . . . . . http://www.icmicrowave.com
Email address: . . . . . . . . . . . . . . . . . . ICMfixture@aol.com
Table 2. Replaceable Parts and Accessories
Description Part Number
Grounding pin
SMA cable (m) 36 (91.4 cm) 8120-4977
Calibration substrate 1NB7-8474
Tweezer 8710-1308
*. Order from Inter-Continental Microwave Co.
*
41112542
11

Contacting HP

To learn about other signal integrity test solutions, visit our Internet web site at the following address:
http://www.hp.com/go/tdr
Before returning the probe for service, call the HP Instrument Support Center at (800) 403-0801. Always call the HP Instrument Support Center first to initiate service before returning your probe to a service office. This ensures that the repair can be properly tracked and that your probe will be returned to you as quickly as possible. Call this number regardless of where you are located.
If the instrument is still under warranty or is covered by an HP maintenance contract, it will be repaired under the terms of the warranty or contract. If the instrument is no longer under warranty or is not covered by an HP maintenance plan, Hewlett-Packard will notify you of the cost of the repair after examining the unit. When an instrument is returned to a Hewlett-Packard service office for servicing, it must be adequately packaged and have a complete description of the failure.
12

Warranty

This Hewlett-Packard instrument product is warranted against defects in material and workmanship for a period of one year from date of shipment. During the warranty period, Hewlett-Packard Company will, at its option, either repair or replace products which prove to be defective. For warranty service or repair, this prod­uct must be returned to a service facility designated by Hewlett-Packard. Buyer shall prepay shipping charges to Hewlett-Packard and Hewlett-Packard shall pay ship­ping charges to return the product to Buyer. However, Buyer shall pay all shipping charges, duties, and taxes for products returned to Hewlett-Packard from another country.

Limitation of Warranty.

The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by Buyer, Buyer-supplied software or interfacing, unautho­rized modification or misuse, operation outside of the environmental specifications for the product, or improper site preparation or maintenance.
No other warranty is expressed or implied. Hewlett­Packard specifically disclaims the implied warranties of merchantability and fitness for a particular purpose.

Exclusive Remedies.

The remedies provided herein are buyer's sole and exclusive remedies. Hewlett-Packard shall not be liable for any direct, indirect, special, incidental, or conse­quential damages, whether based on contract, tort, or any other legal theory.
13

Safety Symbols

CAUTION
to a procedure which, if not correctly performed or adhered to, could result in damage to or destruction of the product. Do not proceed beyond a caution sign until the indicated conditions are fully understood and met.
WARNING
The caution sign denotes a hazard. It calls attention
The
warning
attention to a procedure which, if not correctly
performed or adhered to, could result in injury
or loss of life. Do not proceed beyond a
warning sign until the indicated conditions are
fully understood and met.
sign denotes a hazard. It calls
14
© Copyright Hewlett-Packard Company 1999 All Rights Reserved. Reproduction, adaptation, or trans­lation without prior written permission is prohibited, except as allowed under copyright laws.
