Agilent
8960 Series 10
Wireless Communications Test Set
Configuration Guide
This configuration guide describes how to configure
a new 8960 test set for single or multiple wireless
formats and lists the upgrades available for
existing 8960 test sets.
Notice
For the newest 8960 configuration information,
select the 8960 Configuration guide from the
Key Library at www.agilent.com/find/8960
The building blocks of the 8960 are an E5515 test set mainframe and mobile test applications (TAs) or lab applications (LAs). Test applications provide parametric test capability.
Lab applications test parametric performance and add signaling functionality.
Wireless Test Manager is a family of easy-to-use 8960 test automation software.
Wireless Test Manager runs on a Windows
®
PC.
Tables 1 and 2 show the recommended or required options to purchase with a new 8960
for testing various wireless formats. Table 1 is for testing parametric performance with a
TA. Table 2 is for testing parametric performance and signaling functionality with an LA.
Table 3 lists LA annual contracts. An annual contract provides early LA releases and LA
upgrades for the term of the contract.
If adding a TA or LA to an existing E5515 mainframe, refer to the section entitled, Adding
wireless technology formats to your 8960 test set.
2
Configuring a New 8960
for Your Application
8960 Series 10 Wireless
Test Set – Mainframe,
Applications, and
Software
Table 1. Configuring a new 8960 with a test application
Wireless technology format TA model Mainframe Mainframe options Wireless
(Parametric performance) (option) model (model no. - option) Test Manager
Required Required Required Recommended
AMPS/136 (TDMA) E1961A E5515C1or B
1
002, 003
2
E6563A
cdma2000/IS-95/AMPS E1962B E5515C
1
003 002 E6560C/67C
Release A: New control channels E1962B-401 E5515C
1
003 002 E6560C/67C
Advanced AMPS E1962B-402 E5515C
1
003 002 E6560C/67C
Authentication E1962B-403 E5515C
1
003 002 E6560C/67C
Fast device tune
4
E1999A, E1999A-201 E5515C
1
003 002
W-CDMA E1963A E5515C
1
003 002 E6562C/68C
W-CDMA video test E1963A-401 E5515C
1
003 002
HSDPA test mode E1963A-403 E5515C
1
003 002
Fast device tune
4
E1999A, E1999A-201 E5515C
1
003 002
1xEV-DO E1966A E5515C
1
003 002 E6564C/67C
Release A E1966A-102 E5515C
1
003 002
Fast device tune
4
E1999A, E1999A-201 E5515C
1
003 002
GSM/GPRS
3
E1968A
3
E5515C1or B1002 003
2
E6566C/68C
GSM E1968A-101 E5515C1or B1002 003
2
E6566C/68C
GPRS E1968A-102 E5515C1or B1002 003
2
E6566C/68C
EGPRS E1968A-103 E5515C1or B1002 003
2
E6566C/68C
GSM and GPRS E1968A-201 E5515C1or B1002 003
2
E6566C/68C
GSM, GPRS, and EGPRS E1968A-202 E5515C1or B1002 003
2
E6566C/68C
PAvT E1968A-410 E5515C1or B1002 003
2
Test application fast switching5E1987A E5515C
1
002, 003 E6569C
UMTS Test Application Suite
6
E1993A E5515C
1
002, 003 E6568C
cdma2000®/1xEV-DO TA Suite7E1996A E5515C
1
003 002 E6569C
Test Application Suite
8
E1991B E5515C
1
002, 003 E6569C
1. New E5515s will not work with older revision or discontinued applications. For information on application compatibility, go to
www.agilent.com/find/E5515 and select either E5515B or E5515C Release Notes from the Key Library.
2. Option 003 is not available to order on new E5515Bs.
3. Must order at least one format option (-101, 102, 103, 201 or 202) with E1968A GSM/GPRS TA.
4. Fast device tune is for calibration of specific chipsets. Contact you Agilent Representative for detailed information.
5. E1987A allows fast switching across all TA technology formats.
6. E1993A UMTS TA Suite includes TAs for W-CDMA, GSM, GPRS, EGPRS, and fast switching. Model numbers included are E1963A,
E1968A-202, and E1987A. Does not include E1963A-401, 403, E1968A-410, or E1999A-201. Order feature options separately.
7. E1996A cdma2000_1xEV-DO Suite includes TAs for cdma2000, 1xEV-DO, and fast switching. Model numbers included are E1962B,
E1966A, and E1987A. Does not include E1962B-401, 402, 403, E1966A-102, or E1999A-201. Order feature options separately.
8. E1991B TA Suite includes TAs for cdma2000, 1xEV-DO, IS-95, W-CDMA, GSM, GPRS, EGPRS, 136 (TDMA), AMPS, and fast switching.
Model numbers included are E1961A, E1962B, E1963A, E1966A, E1968A-202, and E1987A. Does not include feature options
E1962B-401, 402, 403, E1963A-401, 403, E1966A-102, E1968A-410, or E1999A-201. Order feature options separately.
3
Table 2. Configuring a new 8960 with a lab application
Wireless technology format LA model Mainframe Mainframe options Wireless
(Parametric and signaling) (option) model (model no. - option) Test Manager
Required Required Required Recommended
GSM/GPRS E6701E E5515C1or B1002 003
2
E6566C/68C
EGPRS
4
E6704A E5515C1or B1002 003
2
E6566C/68C
cdma2000 E6702B E5515C
1
003 002 N5880A
cdma2000 fading
3
E6702B E5515C
1
003, 004 002 N5880A
W-CDMA E6703D E5515C
1
003 002 N5882A
W-CDMA fading
3
E6703D E5515C
1
003, 004 002 N5882A
HSDPA 3.6 Mbps IP data Contact Agilent
1xEV-DO E6706A E5515C
1
003 002 N5884A
1xEV-DO fading
3
E6706A E5515C
1
003, 004 002 N5884A
Release A E6706A-102 E5515C
1
003 002
2.4 Mbps IP data Contact Agilent
cdma2000/1xEV-DO LA Suite5E6716A E5515C
1
003 002 N5880A & 84A
UMTS Lab Application Suite
6
E6717B E5515C
1
002, 003 E6568C/69C
Lab Application Suite
7
E6719D E5515C
1
002, 003 E6569C
Lab application fast switching8E6785D E5515C
1
002, 003 E6569C
1. New E5515s will not work with older revision or discontinued applications. For information on application compatibility, go to E5515
Release Notes at www.agilent.com/find/E5515releasenotes.
2. Option 003 is not available to order on new E5515Bs.
3. More information on fading is on the Web. Go to www.agilent.com/find/E6702B for cdma2000 fading. Go to
www.agilent.com/find/E6703D for W-CDMA fading.
4. E6701E LA required for E6704A LA.
5. E6716A cdma2000/1xEV-DO LA Suite includes LAs for cdma2000 and 1xEV-DO. Model numbers included are E6702B and E6706A.
Does not include E6706-102. Order E6706A-102 Release A separately.
6. E6717B UMTS LA Suite includes LAs for W-CDMA, GSM, GPRS, EGPRS, and fast switching. Model numbers included are E6701E,
E6703D, E6704A, and E6785D.
7. E6719D LA Suite includes LAs for cdma2000, W-CDMA, GSM, GPRS, EGPRS, and limited fast switching. Model numbers included are
E6701E, E6702B, E6703D, E6704A, E6706A, and E6785D. Does not include E6706-102. Order E6706A-102 Release A separately.
8. E6785D fast switches between GSM/GPRS and W-CDMA. Requires E6701E and E6703D LAs. Order E6704A LA to add EGPRS
to fast switching.
Table 3. Lab application annual contracts and extensions
Format Application Annual contract Annual contract extension
1
GSM/GPRS (EGPRS) E6701 (E6704) E6720A-001 E6720A-201
W-CDMA E6703 E6720A-003 E6720A-203
1xEV-DO E6706 E6720A-006 E6720A-206
UMTS E6717 (E6701/E6703) E6720A-017 E6720A-217
1. When renewing, order the annual contract extension to avoid overlapping existing and new terms.
Test Set Mainframes
Test set mainframe options
Standard warranty
Optional warranty
Optional calibration
Operational verification
Accessories
4
E5515C 8960 Series 10 mainframes. (Require at least one Agilent
E5515B Technologies test or lab application. E5515C is required for CDMA
capability in a new test set. Older revision and discontinued
applications are not compatible with new E5515s. Trying to run
incompatible applications will cause new E5515s to lock-up.
For more information on application compatibility, go to
www.agilent.com/find/8960 and select E5515C or E5515B Release
Notes from the Key Library.
E5515B-002 Second RF source. (Required for all GSM, GPRS, and EGPRS
E5515C-002 applications.)
E5515C-003 Flexible CDMA base station emulator. (Required for all cdma2000/
IS-95/AMPS, W-CDMA, and 1xEV-DO applications. Not available in
new E5515Bs.)
E5515C-004 Digital Bus. (Enables fading in cdma2000, 1xEV-DO, and W-CDMA
LAs. Requires E5515C-003. Not available in E5515B.)
E5515C-370 E6571A Wireless Test Manager run-time license. Compatible with
E656xA/B/C Wireless Test Manager models. Requires a PC with
parallel port.
E5515B-ABA Documentation for applications purchased with a mainframe.
E5515C-ABA Includes all 8960 test and lab application documentation. Consists of
a CD-ROM with programming guides, getting started guides, and
paper copies of GPIB syntax guides. US-English localization.
To download documentation in other languages, go to
www.agilent.com/find/8960, select product model, Key Libraries,
and download the Help files. Not all languages are available.
E5515B-0B0 Delete documentation on applications purchased with a mainframe.
E5515C-0B0
E5515B-AX4 Rack flange kit without handles.
E5515C-AX4
E5515B-AX5 Rack flange kit with handles.
E5515C-AX5
E5515B-UK6 Commercial calibration certificate with test data.
E5515C-UK6
R-51B-001-C 1-year return-to-Agilent warranty
R-51B-001-3C 1-year return-to-Agilent warranty extended to 3 years
R-50C-011-3 Agilent Calibration Upfront Support Plan 3 year coverage
R-50C-021-3 Z540 Calibration Upfront Support Plan 3 year coverage
E5515B-B8A Operation verification at installation. Contact your Agilent Sales
E5515C-B8A Representative for more information.
Programmed test SIM cards
E5515-61286 UMTS (W-CDMA) USIM card. Included with E6703C
08922-61887 GSM SIM card (programmed micro-size, 15 mm x 25 mm)
08922-80047 GSM SIM card (programmed, credit card size)
Test Applications and
Feature Options
5
E1961A AMPS/136 mobile test application. (Requires E5515C or E5515B.)
E1962B cdma2000/IS-95/AMPS mobile test application. (Requires E5515C
and E5515C-003.)
E1962B-401 cdma2000 Rel A New Control Channels. (Requires E5515C
and E5515C-003.)
E1962B-402 Advanced AMPS. (Requires E5515C and E5515C-003.)
E1962B-403 cdma2000 authentication. (Requires E5515C and E5515C-003.)
E1963A W-CDMA mobile test application. (Requires E5515C and E5515C-003.)
E1963A-401 W-CDMA video phone test. (Requires E5515C and E5515C-003.)
E1963A-403 HSDPA test modes. (Requires E5515C and E5515C-003.)
E1966A 1xEV-DO terminal test application. (Requires E5515C and E5515C-003.)
E1966A-102 1xEV-DO Release A. (Requires E5515C and E5515C-003.)
E1968A E1968A GSM/GPRS mobile test application. GSM, GPRS and EGPRS wireless
technology functionality is available. Must specify an option for a specific
format or combination of formats.
E1968A-101 GSM functionality. (Requires E5515C and E5515C-002, or
E5515B and E5515B-002.)
E1968A-102 GPRS functionality. (Requires E5515C and E5515C-002, or
E5515B and E5515B-002.)
E1968A-103 EGPRS functionality. (Requires E5515C and E5515C-002, or
E5515B and E5515B-002.)
E1968A-201 GSM/GPRS functionality. (Requires E5515C and
E5515C-002, or E5515B and E5515B-002.)
E1968A-202 GSM/GPRS/EGPRS functionality. (Requires E5515C and
E5515C-002, or E5515B and E5515B-002.)
E1968A-410 EGPRS phase and amplitude versus time. (Requires E5515C
and E5515C-002, or E5515B and E5515B-002.)
E1987A Fast switching test application. Fast switches across all TA formats. (Requires
at least two TAs, E5515C, and E5515 options for the wireless formats to
be switched.)
E1991B 8960 test application suite. Includes TAs for GSM, GPRS, EGPRS, AMPS,
136 (TDMA), cdma2000, IS-95, 1xEV-DO, W-CDMA and fast switching.
Contains E1968A, E1968A-202, E1961A, E1962B, E1963A, E1966A and E1987A
TAs. (Requires E5515C, and E5515C-202, and E5515C-003. E1991B is for
installation on a single 8960 test set. TA feature options such as E1962B-401,
402, 403, E1963A-401, 403, E1966A-102, E1968A-410, E1999A, and E1999A-201
are ordered separately; they are not included in the E1991B TA suite.)
E1993A 8960 UMTS test application suite. Includes TAs for GSM, GPRS, EGPRS,
AMPS, W-CDMA and fast switching. Contains E1968A-202, E1963A, and
E1987A TAs. (Requires E5515C, and E5515C-002, and E5515C-003. E1993A is for
installation on a single 8960 test set. TA feature options such as E1963A-401,
403, E1968A-410, E1999A, and E1999A-201 are ordered separately; they are not
included in the E1993A TA suite.)
E1996A 8960 cdma2000/1xEV-DO test application suite. Includes TAs for cdma2000,
IS-95, 1xEV-DO, AMPS and fast switching. Contains E1962B, E1966A, and
E1987A TAs. (Requires E5515C, and E5515C-003. E1996A is for installation
on a single 8960 test set. TA feature options such as E1962B-401, 402, 403,
E1966A-102, E1999A, and E1999A-201 are ordered separately; they are not
included in the E1996A TA suite.)
E1999A E5515 application features.
E1999A-201 Fast device tune measurement. Enables fast device tune
measurement in E1962B, E1963A, E1966A, and E1987A TAs.
(Requires E1962B, E1963A, or E1966A TA.)
Note: If adding a test application to an existing mainframe, see the section
entitled, Adding wireless technology formats to your 8960 test set.
Test application includes
Test application options available
when ordered standalone
(without an E5515 mainframe)
• Test application license.
• 8960 documentation set. (Includes documentation for all 8960 TAs and LAs. Must
specify language localization option. When ordered with an E5515 mainframe use
E5515 application documentation options.)
• If ordering more than one TA, specify language localization option for one TA and order
Option 0B0 on the other TAs to avoid receiving multiple 8960 documentation sets.
TA Model#-010 Test application installation set for test applications purchased
standalone. (CD-ROM with the necessary files and utilities needed
for loading test applications. Test applications can be downloaded
from www.agilent.com/find/8960ta. Option 010 is recommended
if you do not have high-speed Internet access.)
TA Model#-ABA Documentation for test applications purchased standalone. Includes
all test and lab application documentation. Consists of CD-ROM
with programming guides, getting started guides, and paper copies
of GPIB syntax guides. US-English localization. To download
document in other languages, go to www.agilent.com/find/8960,
select Key Libraries and download the Help files. Not all languages
are available.
TA Model#-0B0 Delete documentation.
6
7
Lab Applications and
Feature Options
Annual contracts include
E6701E GSM/GPRS lab application. (Requires E5515C and E5515C-002, or E5515B and
E5515B-002. Order E5515C-004 to enable fading.)
E6702B cdma2000 lab application. (Requires E5515C and E5515C-003.)
E6703D W-CDMA lab application. (Requires E5515C and E5515C-003. Order E5515C-004
to enable fading.) Includes E5515-10007 UMTS (W-CDMA) USIM card.
E6704A EGPRS lab application. (Requires E6701E and E5515C with E5515C-002 or
E5515B with E5515B-002.)
E6706A 1xEV-DO lab application. (Requires E5515C, E5515C-003. Order E5515C-004
to enable fading.)
E6706A-102 1xEV-DO Release A. (Requires E5515C and E5515C-003.)
E6785D Fast switching lab application for GSM/GPRS/EGPRS_W-CDMA. (Requires
E6701E, E6703D, E5515C, E5515C-002, and E5515C-003. For EGPRS capability,
add E6704A. Order E5515C-004 to enable fading.)
E6716A cdma2000/1xEV-DO lab application suite. Includes LAs for cdma2000 and
1xEV-DO. Contains E6702B and E6706A LAs. Feature option E6706A-102 for
1xEV-DO Release A is ordered separately; E6706A-102 is not included in the
E6716A Suite. (Requires E5515C and E5515C-003. Order E5515C-004 to enable
fading. E6716A is for installation on a single test set.)
E6717B 8960 lab application UMTS suite. Includes LAs for GSM, GPRS, EGPRS, and
W-CDMA. Contains E6701E, E6703D, E6704A, and E6785D fast switching LA.
(Requires E5515C, E5515C-002, and E5515C-003. Order E5515C-004 to enable
fading. E6717B is for installation on a single 8960 test set.)
E6719D Lab application suite. Includes LAs for GSM, GPRS, EGPRS, cdma2000,
W-CDMA, 1xEV-DO, and fast switching. Contains E6701E, E6702B, E6703D,
E6704A, and E6706A LAs plus E6785D fast switching LA. Feature option
E6706A-102 for 1xEV-DO Release A is ordered separately; E6706A-102 is
not included in E6719D Suite. (Requires E5515C, E5515C-002, and E5515C-003.
Order E5515C-004 to enable fading. E6719D is for installation on a single 8960
test set.)
E6720A Annual upgrade contracts for 8960 lab applications. Must specify an option for
each format. For contract renewals, order the contract extension to avoid
overlap of existing and renewal terms.
E6720A-001 For E6701 GSM/GPRS and E6704A EGPRS LAs
E6720A-002 For E6703 W-CDMA LA
E6720A-006 For E6706 1xEV-DO LA
E6720A-017 For E6701 GSM/GPRS, E6704A EGPRS, E6703 W-CDMA LAs
E6720A-201 Contract extension for E6701 GSM/GPRS and E6704A EGPRS LAs
E6720A-202 Contract extension for E6703 W-CDMA LA
E6720A-206 Contract extension for E6706 1xEV-DO LA
E6720A-217 Contract extension for E6701 GSM/GPRS, E6704A EGPRS,
E6703 W-CDMA LAs
Note: If adding a lab application to an existing mainframe, see the section
entitled, Adding wireless technology formats to your 8960 test set.
• Individualized early notification of new LA models and revisions
• LA subscription releases give early access to new features and enhancements
• LA upgrades and licenses (if required) over the term of the contract at no additional
charge
• New applications and licenses delivered electronically on demand via the Web
8
Wireless test managers require a specific model and revision of TA and LA. See the
individual test manager (WTM) data sheet or overview to determine compatible
TAs and LAs at www.agilent.com/find/wtmanagers. Wireless test managers run
Visual Basic .NET
®
and utilize a USB security key.
Formats WTM model
TA and LA wireless test managers
cdma2000/IS-95/AMPS E6560C, E6560C-100
1xEV-DO E6564C, E6564C-100
W-CDMA E6562C, E6562C-100
GSM/GPRS/EGPRS E6566C, E6566C-100
W-CDMA/GSM/GPRS/EGPRS E6568C, E6568C-100
cdma2000/IS-95/1xEV-DO E6567C, E6567C-100
Run-Time License for all formats E6571C
LA wireless test managers
cdma2000/IS-95 AMPS N5880A, N5880A-100
1xEV-DO N5884A, N5884A-100
W-CDMA N5882A, N5882-100
Lab applications include
Lab application options available
when ordered standalone
(without an E5515 mainframe)
Wireless protocol applications
(WPA) ordered standalone
(without an LA)
• Lab application license.
• Wireless protocol advisor (WPA) software for specified format. WPA is PC software
that works with 8960 lab applications to capture and analyze wireless protocols.
• 8960 application documentation. (Must specify localization option. When ordered
with E5515 mainframe use E5515 application documentation options.)
• If ordering more than one LA, specify language localization option for one LA and
order Option 0B0 on the other LAs to avoid receiving multiple 8960 documentation sets.
LA Model#-010 Lab application installation set. (CD-ROM with the necessary files
and utilities needed for loading lab applications. LAs can be
downloaded from www.agilent.com/find/8960la. Option 010 is
recommended if you do not have high-speed Internet access.)
LA Model#-ABA Documentation for lab applications purchased standalone. Includes
all test and lab application documentation. Consists of CD-ROM
with programming guides, getting started guides, and paper copies
of GPIB syntax guides. US-English localization. To download
document in other languages, go to www.agilent.com/find/8960,
select Key Libraries, and download the Help files. Not all
languages are available.
LA Model#-0B0 Delete documentation.
E6584A PC software that works with 8960 lab applications to capture and analyze
wireless protocols. (Included with LA. To order without LA, order E6584A
and option to specify format.)
E6584A-001 GSM/GPRS/EGPRS decodes for WPA software.
E6584A-002 cdma2000 decodes for WPA software
E6584A-003 W-CDMA decodes for WPA software
E6584A-006 1xEV-DO decodes for WPA software
Wireless Test Manager
Software
Find your software
development platform and
select your products...
9
Upgrading an Existing
8960 Test Set
1. Updating a TA or LA revision
to get new features
The 8960 is a flexible test set that can be upgraded to meet your changing wireless test
needs. There are four types of 8960 upgrades
1. updating an existing test/lab application
2. upgrading an application to a new model number
3. upgrading a test application to a lab application
4. adding a wireless technology format
To get timely information about 8960 application improvements, register for Agilent Email
Updates at www.agilent.com/find/emailupdates.
TAs and LAs are periodically revised to add new features, improve performance, or
resolve known issues. Some new features are a free upgrade. Other new features
require a TA option upgrade, LA model upgrade, LA option upgrade, or an E5515 mainframe hardware upgrade. To determine if a hardware (HW) upgrade may be required to
enable a feature, refer to Table 4 for TAs and Table 5 for LAs. Contact your Agilent Sales
Representative to specify and order hardware upgrades.
TA and LA downloads are available at www.agilent.com/find/8960ta. A valid applica-
tion or feature option license is required. Contact your Agilent Sales Representative for
application upgrade information.
Table 4. New TA feature upgrades
TA format Feature Application Feature option upgrade
1
HW capable?
2
cdma2000 cdma2000 Rel A new control channels E1962B E1962BU-401 Yes
Advanced AMPS E1962B E1962BU-402 Yes
Authentication E1962B E1962BU-403 Yes
Real time vocoder E1962B None Check
Fast device tune E1962B E1999A, E1999A-201 Check
W-CDMA Video test E1963A E1963AU-401 Check
BLER with asymmetrical RMCs E1963A None Check
HSDPA test modes E1963A E1963AU-403 Check
Default DPCH offset (DOFF) E1963A None Check
Band 7 E1963A None Check
Fast device tune E1963A E1999A, E1999A-201 Check
1xEV-DO Release A E1966A E1966AU-102 Check
Fast device tune E1966A E1999A, E1999A-201 Check
GSM/GPRS/EGPRS PAvT E1968A E1968A-410 Yes
Digital ORFS E1968A None Check
Class 10 measurements E1968A
3
None Check
1. Some TA features are enabled by a feature option. Required feature options are listed. If no feature option is listed, the
feature is standard in the current revision of the specified TA and no feature option is required.
2. This feature may require an E5515 hardware upgrade to run on some E5515s. “Yes” means any E5515 capable of running the
application model will run the specified feature. “Check” means the E5515 may need a hardware upgrade to run the specified
feature. Contact your Agilent representative for more information.
3. E1968A plus required technology format feature option (e.g. E1968A-101, 102, 103, 201, or 202).
10
Table 5. New LA feature upgrades
1. Some LA features are enabled by a feature option. Required feature options are listed. If no
feature option is listed, the feature is standard in the current revision of the specified LA.
2. “Check” means an E5515 may require a hardware upgrade to the specified feature. “Yes” means
any E5515 capable of running the application model will run the specified feature. Contact your
Agilent representative for more information.
3. Add E6704A for EGPRS.
4. E6703T, E6701T, E6702T, and E6706T require a special E5515 hardware configuration. Please
contact your Agilent Representative for more information.
Upgrading a TA or LA to new model number (e.g. E1985B to E1987A or E6701C to E6701D)
offers important new features and functionality. LA upgrades to newer model numbers
are offered as an upgrade product. TA upgrades may be free downloads or upgrade
products. TA and LA upgrades are customer-installable. Refer to Table 6 for available TA
model upgrades and Table 7 for available LA upgrades. Some TA and LA model upgrades
may require an E5515 hardware upgrade to run or enable specific features. Contact your
Agilent Sales Representative for specific application upgrade information.
Table 6. TA model number upgrades
LA format Feature Application/feature option
1
HW capable?
2
GSM/GPRS/EGPRS
3
PAvT E6701E/E6704A
3
Ye s
Digital ORFS E6701E/E6704A
3
Check
Class 10 measurements E6701E/E6704A
3
Check
EGPRS Class 12 signaling E6701E/E6704A
3
Check
Runs on special E5515 high data rate hardware E6701T4/E6704A
3
Check
cdma2000 Fading E6702B Check
cdma2000 Rel A new control channels E6702B Yes
Advanced AMPS E6702B Yes
Authentication E6702B Yes
Real time vocoder E6702B Check
Fast device tune E6702B Check
Runs on special E5515 high data rate hardware E6702T
4
Check
W-CDMA 384 K data throughput E6703D Check
BLER with asymmetrical RMCs E6703D Check
Fading E6703D Check
Video test E6703D Check
HSDPA test modes E6703D Check
Band 7 E6703D Check
Fast device tune E6703D Check
3.6 Mbps HSDPA IP data E6703T
4
Check
1xEV-DO Fading E6706A Check
Fast device tune E6706A Check
Release A E6706AU/E6706AU-102 Check
2.4 Mbps IP data E6706T
4
Check
1. E5515B with serial number < GB40470001 or < US40350001 may require a hardware upgrade.
Please contact an Agilent Sales Representative for more information.
2. Download free upgrades at www.agilent.com/find/8960ta.
3. E5515C with serial number < GB45070001, E5515B with serial number < GB45080001 or any US
serial number may require a hardware upgrade. Please contact an Agilent Sales Representative
for more information.
2. Upgrading an existing
application to a new model number
TA format Application Upgrade to order
From To
GSM TA E1960A E1968A-101 Free upgrade
1, 2
GPRS TA E1964A E1968A-102 Free upgrade
1, 2
Fast switch TA E1985A, B, C, D, or E E1987A Free upgrade
2, 3
11
Table 7. LA model number upgrades
Upgrading a TA to an LA (e.g. E1962B to E6702B) is customer-installed. Some TA to LA upgrades
may require an E5515 mainframe hardware upgrade. TA to LA upgrades must be customer installed,
they cannot be ordered pre-installed on new instruments. Contact your Agilent Sales Representative
for compatibility information.
Table 8. TA to LA upgrades
You can add any TA or LA to an existing E5515B or E5515C. Being able to purchase another wireless
format for your existing E5515 may save considerable expense when compared to purchasing a new
test set. Adding a new TA or LA to an existing E5515B or E5515C may require a hardware upgrade.
Contact your Agilent Sales Representative for details and delivery information.
Important: Existing TAs and LAs installed on an E5515B or E5515C may have to be updated to a
newer revision or new model after a hardware upgrade. Older LA models may not work on an
upgraded E5515. Before ordering an E5515 hardware upgrade, check with your Agilent Sales
Representative to make sure you've ordered the necessary LA upgrades to run on the upgraded
E5515 hardware.
1. May require an E5515 hardware upgrade to run or enable certain features.
2. E5515C with serial number < GB45070001, E5515B with serial number < GB45080001 or any US
serial number may require a hardware upgrade. Please contact an Agilent Sales Representative
for more information.
1. May require an E5515 hardware upgrade to run or enable certain features.
2. E5515C with serial number < GB45070001, E5515B with serial number < GB45080001 or any US
serial number may require a hardware upgrade. Please contact an Agilent Sales Representative
for more information.
LA format Application Upgrade to order
From To
GSM/GPRS LA E6701D E6701E E6701EU-001
1
GSM/GPRS LA E6701C E6701E E6701EU-002
1
cdma2000 LA E6702A E6702B E6702BU-002
W-CDMA LA E6703A E6703D E6703DU-002
1
W-CDMA LA E6703B E6703D E6703DU-003
1
W-CDMA LA E6703C E6703D E6703DU-004
1
Fast switching E6785A, B or C E6785D Free upgrade
1, 2
Format Application Order
From To
cdma2000 TA to LA E1962B E6702B E6702BU-001
W-CDMA TA to LA E1963A E6703D E6703DU-001
1
1xEV-DO TA to LA E1966A E6706A E6706AU-001
1, 2
Fast switching E1987A E6785D Free upgrade
1, 2
3. Upgrading a test application to
a lab application
4. Adding wireless technology formats
to your 8960 test set
For more product information visit
our Web site at:
www.agilent.com/find/8960
Windows and Visual Basic .NET are U.S. registered
trademarks of Microsoft Corp.
cdma2000 is a registered certification mark of the
Telecommunications Industry Association. Used
under license.
Remove all doubt
Our repair and calibration services will get
your equipment back to you, performing
like new, when promised. You will get full
value out of your Agilent equipment
throughout its lifetime. Your equipment
will be serviced by Agilent-trained
technicians using the latest factory
calibration procedures, automated repair
diagnostics and genuine parts. You will
always have the utmost confidence in
your measurements.
Agilent offers a wide range of additional
expert test and measurement services for
your equipment, including initial start-up
assistance onsite education and training,
as well as design, system integration,
and project management.
For more information on repair and
calibration services, go to
www.agilent.com/find/removealldoubt
www.agilent.com
For more information on Agilent
Technologies’ products, applications
or services, please contact your local
Agilent office. The complete list is
available at:
www.agilent.com/find/contactus
Phone or Fax
United States:
(tel) 800 829 4444
(fax) 800 829 4433
Canada:
(tel) 877 894 4414
(fax) 800 746 4866
China:
(tel) 800 810 0189
(fax) 800 820 2816
Europe:
(tel) 31 20 547 2111
Japan:
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Korea:
(tel) (080) 769 0800
(fax) (080) 769 0900
Latin America:
(tel) (305) 269 7500
Taiwan:
(tel) 0800 047 866
(fax) 0800 286 331
Other Asia Pacific Countries:
(tel) (65) 6375 8100
(fax) (65) 6755 0042
Email: tm_ap@agilent.com
Revised: 11/08/06
Product specifications and descriptions
in this document subject to change
without notice.
© Agilent Technologies, Inc. 2002-2007
Printed in USA, March 26, 2007
5968-7873E
www.agilent.com/find/emailupdates
Get the latest information on the products
and applications you select.
www.agilent.com/find/agilentdirect
Quickly choose and use your test
equipment solutions with confidence.
www.agilent.com/find/open
Agilent Open simplifies the process of
connecting and programming test systems
to help engineers design, validate and
manufacture electronic products. Agilent
offers open connectivity for a broad range
of system-ready instruments, open industry
software, PC-standard I/O and global
support, which are combined to more easily
integrate test system development.
Agilent Email Updates
Agilent Direct
Agilent
Open
Loading...
