HP E5346A/E5351A
High-Density Adapter Cable
Installation Note
High-density adapter cables provide a convenient way to connect two
HP logic analyzer probe cables to a small area of a target system. The
HPE5346A cable has RCR networks in the cable end that connects to
the high-density AMP Mictor (Matched Impedance ConnecTOR)
connector. The HP E5351A cable does not have RCR networks, so
terminations must be made on the target system.
1
Installation overview
1 Attach the Mictor connector(s) to the target system. Use 38-pin
surface mount receptacles, AMP part number 2-767004-2.
2 Align the Mictor connector with the support shroud. Note pin 1
orientation for both connector and shroud.
3 Attach the support shroud around the Mictor connector. Use HP
Part Number E5346-44701 support shroud.
4 Connect the high-density adapter cable to the Mictor connector
and then to the logic analyzer.
Tabs on the support shroud lock the high-density adapter cable into
the Mictor connector to provide dependable connections and prevent it
from inadvertently being disconnected. They also protect the flexible
end of the adapter from being bent and damaged.
Reference
• Refer to HP publication number 5962-8620E Minimizing
Intrusion Effects when Probing with a Logic Analyzer for
help on the terminations when using the HP E5351A cable.
• Use the illustrations on the following pages to plan and layout
your target system.
Examples of target system layouts
2
HP E5346A/E5351A High-Density Adapter Cable Installation Note
High-density adapter cable dimensions
Notice the holes for mounting the support shrouds in the following
illustration. One of the holes is off center to allow 0.40 in. (1.02 mm)
centers when using multiple connectors.
Board pad details of Mictor connector and support shroud
3
HP E5346A/E5351A High-Density Adapter Cable Installation Note
Mictor connector dimensions
Support shroud dimensions
4
HP E5346A/E5351A High-Density Adapter Cable Installation Note
Top view surface mount receptacle
Pin 1 and pin 3. Do not use these pins.
Pins 5, 7, 9, ... 37. These pins are even numbered logic probe inputs.
CLKe is the clock probe input used in state analysis. D15e to D0e on
the even side are probe data inputs.
Pin 2 and pin 4. Do not connect these pins. They are SCL and SDA,
which are used by the HP logic analyzer with an emulator or analysis
probe (preprocessor) to program or read target information.
Pins 6, 8, 10, ... 38. These pins are odd numbered logic probe inputs.
CLKo is clock probe input used in state analysis. D15o to D0o on the
odd side are probe data inputs.
Grounds. There are five through-hole connections that are the ground
returns for the 32 data and 2 clock probe inputs. This connection
should be made to the target’s digital ground plane as close to the
target as possible.
5
HP E5346A/E5351A High-Density Adapter Cable Installation Note
HP E5346A/E5351A High-Density Adapter Cable Pin Assignments
AMP Mictor-38 Connector Logic Analyzer Pods
Signal Name Pin Number J1 (Even Pod) J2 (Odd Pod)
CLOCK even 5 3
D15 even 7 7
D14 even 9 9
D13 even 11 11
D12 even 13 13
D11 even 15 15
D10 even 17 17
D9 even 19 19
D8 even 21 21
D7 even 23 23
D6 even 25 25
D5 even 27 27
D4 even 29 29
D3 even 31 31
D2 even 33 33
D1 even 35 35
D0 even 37 37
CLOCK odd 6 3
D15 odd 8 7
D14 odd 10 9
D13 odd 12 11
D12 odd 14 13
D11 odd 16 15
D10 odd 18 17
D9 odd 20 19
D8 odd 22 21
D7 odd 24 23
D6 odd 26 25
D5 odd 28 27
D4 odd 30 29
D3 odd 32 31
D2 odd 34 33
D1 odd 36 35
D0 odd 38 37
6
HP E5346A/E5351A High-Density Adapter Cable Installation Note
HP E5346A/E5351A High-Density Adapter Cable Pin Assignments
AMP Mictor-38 Connector Logic Analyzer Pods
Signal Name Pin Number J1 (Even Pod) J2 (Odd Pod)
GROUND 39-43 All even pins All even pins
These pins are +5 volt supply and DC return for analysis probes.
+5 VDC 1 1, 39 1, 39
GROUND 3 2, 40 2, 40
Do not connect the following pins. They are used by the HP logic analyzer with an
emulator or analysis probe to program or read target information.
SCL 2 5
SDA 4 5
Logic Analyzer Pod
7
