Frequency reference (Opt. 1D5)
Aging ±2×10–6/year ±1×10–7/year
Temperature stability ±5×10
–6
±1×10
–8
Settability ±5×10
–7
±1×10
–8
Frequency readout accuracy
(Start, Stop, Center, Marker) ±(frequency indication x
frequency reference error
1
+ span
accuracy
+15% of RBW + 10 Hz + 1 Hz x N
4
)
Marker frequency counter
2
Accuracy
3
±(marker frequency × frequency
reference error
1
+ counter
resolution)
Counter resolution Selectable from 1 Hz to 100 kHz
Frequency span
Range 0 Hz (zero span), 100 Hz to the
range of the spectrum analyzer
Resolution Four digits or 2 Hz × N
4
whichever is greater
Accuracy ±0.5% of span
(8192 sweep points)
Frequency sweep time
Range 1 ms to 4000 s
Span = 0 Hz 10 µs to 4000 s
(Opt. AYX) 50 ns to 4000 s
(Opt. B7D) 25 ns to 4000 s
Accuracy ±1%
Sweep trigger Free run, Single, Line, Video,
External, Delay, Gate (Opt.1D6),
and TV (Opt. B7B)
Delay trigger range 1 µs to 400 s
Sweep (trace) point range 101 to 8192
Span = 0 Hz 2 to 8192
Resolution bandwidth 1 kHz to 5 MHz (–3 dB) in 1-3-10
sequence.
9 kHz and 120 kHz (–6 dB) EMI
bandwidths.
Option 1DR Adds 10, 30, 100, and 300 Hz (–3 dB)
bandwidths and 200 Hz (–6 dB)
EMI bandwidth.
Accuracy
1 kHz to 3 MHz ±15%
5 MHz ±30%
10 Hz to 300 Hz (Opt. 1DR) ±10%
Selectivity (characteristic)
–60 dB/–3 dB
10 Hz to 300 Hz <5:1
6
1 kHz to 5 MHz <15:1
6
Video bandwidth range 30 Hz to 3 MHz
6
in 1-3-10
sequence
1 Hz to 3 MHz
6
(Opt. 1DR)
Stability
Noise sidebands (1 kHz RBW, 30 Hz VBW and sample detector)
≥10 kHz offset from CW signal ≤–90 dBc/Hz + 20 Log N
4
≥20 kHz offset from CW signal ≤–98 dBc/Hz + 20 Log N
4
≥30 kHz offset from CW signal ≤–100 dBc/Hz + 20 Log N
4
≥100 kHz offset from CW signal ≤–112 dBc/Hz + 20 Log N
4
Residual FM
1 kHz RBW, 1 kHz VBW ≤150×N
4
Hz pk-pk in 100 ms
Option 1D5 ≤100×N
4
Hz pk-pk in 100 ms
Option 1DR ≤10×N
4 Hz6
pk-pk in 20 ms
Option 1DR and 1D5 ≤2×N
4
Hz pk-pk in 20 ms
System-related sidebands
≥30 kHz offset from CW signal ≤–65 dBc + 20 Log N
4
Amplitude specifications
Amplitude range
Measurement range Displayed average noise level
(DANL) to maximum safe input level
Input attenuator range
E4401B 0 to 60 dB, in 5 dB steps
E4402B/04B/05B/07B 0 to 65 dB, in 5 dB steps
Maximum safe input level
Average continuous power
(input attenuator ≥15 dB)
E4401B +30 dBm (1 W)
E4401B (75 Ω Opt. 1DP) +75 dBmV (0.4 W)
(input attenuator ≥5 dB)
E4402B/04B/05B/07B +30 dBm (1 W)
Peak pulse power
(input attenuator ≥30 dB)
E4401B +30 dBm (1 W)
E4401B (75 Ω Opt. 1DP) +75 dBmV (0.4 W)
E4402B/04B/05B/07B +50 dBm (100 W)
dc
E4401B, E4402B 100 Vdc
E4401B (75 Ω Opt. 1DP) 100 Vdc
E4404B, E4405B 0 Vdc (dc coupled)
50 V (ac coupled)
E4407B 0 Vdc
1 dB gain compression (total power at input mixer
5
)
50 MHz to 6.7 GHz 0 dBm
6.7 GHz to 13.2 GHz –3 dBm
13.2 GHz to 26.5 GHz –5 dBm
Figure 1. Noise sidebands for E4402B, E4404B, E4405B, and E4407B
