Agilent Technologies
6000L Series Low-Profile Oscilloscopes
Data Sheet
The most space efficient
LXI C compliant oscilloscopes
Four channels in only 1U space
Industry-leading performance:
• 4-channel digital storage oscilloscope (DSO) models
• Low profile, high density 1U (4.45 cm, 1.75 inches) package
• LXI class C compliant
• 100 MHz, 500 MHz and 1 GHz analog bandwidth
• Up to 4 GSa/s sample rate
• Standard 8 Mpts MegaZoom III deep memory
• Full-scale connectivity – Standard USB, LAN, GPIB interface with XGA
video output
• 8-bit vertical resolution (extensible to 12 bits)
• Mixed signal analysis option supporting integrated 4-scope and
16-logic channels
• Built-in Web browser control
• Optional secure environment mode
• IVI-COM driver
• 100% software compatible with 6000A Series portable oscilloscopes
The Agilent 6000L Series
oscilloscopes give you just the
right performance in a compact
(1U) package. This family of
oscilloscopes consists of three
4-channel models for simple
digitizing applications. They
provide unbeatable performance
and measurement capabilities
ideal for automated test and
manufacturing test environments.
2
Low-profile, high-density package
saves rack space
The 6000L Series oscilloscopes
provide up to 1-GHz bandwidth
in a space-saving 1U-high 19-inch
wide package so it saves your
valuable rack space. The
oscilloscopes have side and rear
air vents (no top or bottom air
vents) so other instruments can
be mounted directly above or
below them. Rack mount brackets
and rack rails are standard with
every unit.
LXI class C compliant
LAN eXtensions for
Instrumentation (LXI) is the
architecture for test systems
that’s based on proven, widely
used standards such as Ethernet.
By specifying the interaction of
those standards, LXI enables fast,
efficient, cost-effective creation
and reconfiguration of test
systems. The 6000L Series
oscilloscopes are fully LXI class C
compliant. The 6000L Series
oscilloscopes follow specified
LAN protocols, and adhere to LXI
requirements such as a built-in
Web control server, IVI driver
software, and more.
Easy system integration and
configuration
To simplify system development,
the 6000L Series oscilloscopes
come standard with an IVI-COM
(Interchangeable Virtual
Instruments) driver, and they
support easy-to-use SCPI
commands. The standard Agilent
I/O Library Suite makes it easy
to configure and integrate
instruments into your system –
even if your system includes
instruments from other vendors.
Figure 1. Make the most of your rack space with an Agilent 6000L Series oscilloscope.
Figure 2. Establish instrument connection faster with
Agilent I/O Library Suite.
3
Built-in Web control
The built-in Web server provides
remote access and control of
the instrument via a standard
Java-enabled Web browser
on your computer. You can
communicate with the scope
over the scope’s built-in LAN
interface. Using the Web browser
you can set up measurements,
monitor waveforms, capture
screen images and operate the
scope remotely. You can also send
SCPI commands over the LAN to
control your scope. Wherever you
are, your 6000L Series scope is as
close as the nearest Web browser.
Optional secure environment mode
The optional secure environment
mode provides the highest level of
security by ensuring that internal
memory is clear of all setup and
trace settings in compliance with
National Industrial Security
Program Operating Manual
(NISPOM) Chapter 8
requirements. You can move the
instrument out of a secure area
with confidence. When this
option is installed, it will store
setups and traces to internal
volatile memory only. To
permanently store data, you can
save it to an external memory
device via the oscilloscope’s
front-panel USB port.
Figure 3. Remotely display and control your 6000L oscilloscope
from any Java-enabled web browser over the oscilloscope’s
built-in LAN interface.
Up to 12 bits of resolution
High resolution mode offers up to
12 bits of resolution in real-time
mode, which reduces noise and
increases vertical resolution.
When operating at slow time
base ranges, the 6000L Series
oscilloscopes serially filter
sequential data points and
map the filtered results to the
display. In certain situations,
user-controlled averaging can also
be used to obtain greater than
8-bits of resolution.
Time base Bits of resolution
< 100 nsec/div 8
500 nsec/div 9
2 µsec/div 10
10 µsec/div 11
≥ 50 µsec/div 12
4
Powerful acquisition with
MegaZoom III deep memory
8 Mpt of MegaZoom deep
memory comes standard so you
can capture long, non-repeating
signals, while maintaining high
sample rates and good timing
resolution. This lets you quickly
zoom in on areas of interest.
In single-channel mode, the
DSO6104L can capture a signal
over a 2 msec period with a
sampling rate of 4 GSa/s
Figure 4. MegaZoom III deep memory helps you find details buried in complex signals. You can view fast waveform updates of signals
by means of an external dislpay connected to the oscilloscope’s XGA out port.
(0.25 nsec period). The fast
sample rate and deep memory
ensure that all high-frequency
signal components, up to the
full bandwidth of the scope,
are captured.
5
Mixed signal analysis option
If you work with both analog and
digital circuitry, the Agilent
6000L Series oscilloscope can
help you see more signal activity
in your designs. You can upgrade
the 6000L Series oscilloscope to
a 4 scope +16 logic timing
channel mixed signal oscilloscope
(MSO). Both the MSO and the
4-channel DSO models are
optimized with the capabilities
you need for verifying and
debugging designs that include
embedded system components.
With the MSO you can trigger on
any combination of its scope and
logic channels.
Easy transition from 6000A to 6000L
One of the biggest challenges in
a new product’s life cycle is the
transition of its test system from
development to manufacturing.
With LXI, the transition can be
achieved much more easily and
cost effectively than with
cardcage-based systems.
Engineers can use the LXI class C
compliant 6000A Series portable
oscilloscope during the R&D
phase, using the display, keypad
and knobs to quickly access
a wealth of measurement
capabilities. When your product
moves to manufacturing, you can
use a system-optimized 6000L
Series LXI oscilloscope without
a display. Because the 6000A
and 6000L are 100% software
compatible, your manufacturing
system can use the software and
test routines developed in R&D
without any modification.
Figure 5. The MSO option lets you see the complex interactions
among your signals on up to 20 channels at the same time.
Figure 6. The 6000A and 6000L Series oscilloscopes are 100% software compatible,
enabling smooth test system transition.
XGA video out port
6
Agilent 6000L Series Oscilloscopes:
The most space efficient LXI C compliant oscilloscopes
Four channels in only 1U space
Status indicators
Standard rack
mount brackets
Side air vents
AutoProbe Interface
Built-in USB port
Intensity control
(for external display)
Optional 16 logic timing channels (MSO)
Standard LAN, USB and GPIB ports
Ext Trig in, Trig out and
10 MHz ref in/out
7
Performance characteristics
Scope input
Channels Ch 1, 2, 3 and 4 simultaneous acquisition
Bandwidth (–3 dB)* DSO6014L: DC to 100 MHz
DSO6054L: DC to 500 MHz
DSO6104L: DC to 1 GHz
Maximum input CAT I 300 Vrms, 400 Vpk, CAT II 100 Vrms, 400 Vpk
With 10073C/10074C 10:1 probe: CAT I 500 Vpk, CAT II 400 Vpk
5 Vrms with 50 Ω input
Full Scale range
1
DSO6014L: 1 mV/div to 5 V/div (1 MΩ)
DSO6054L: 2 mV/div to 5 V/div (1 MΩ or 50 Ω)
DSO6104L: 2 mV/div to 5 V/div (1 MΩ), 2 mV/div to 1 V/div (50 Ω)
Input impedance DSO6014L
2
: 1 MΩ ± 1% || 11pF
DSO6054L/6104L: 1 MΩ ± 1% || 14pF or 50 Ω ± 1.5%, selectable
Coupling AC, DC
Offset range ±5 V on ranges < 10 mV/div
±25 V on ranges 10 mV/div to 200 mV/div
±75 V on ranges ≥ 200 mV/div
Connector BNC
BW limit DSO6014L: 20MHz
DSO6054L/6104L: 25 MHz selectable
Noise peak-to-peak DSO6014L: 3% full scale or 2 mV, whichever is greater
DSO6054L: 3% full scale or 3.6 mV, whichever is greater
DSO6104L: 3% full scale or 4.5 mV, whichever is greater
* Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and ±10 °C from firmware calibration temperature.
1 1 mV/div is a magnification of 2 mV/div. 2 mV/div is a magnification of 4 mV/div setting. For vertical accuracy calculations, use full scale of 16 mV for 1 mV/div sensitivity
setting and 32 mV for 2 mV/div sensitivity setting.
2 Four 50 Ω termination adapters are supplied with DSO6014L.
Logic channels (with MSO option)
Number of channels 16 logic timing channels – labeled D15 - D0
Maximum input frequency 250 MHz
Sample rate 2 GSa/sec one pod, 1 GSa/sec each pod
Standard memory depth 2.5 Mpts one pod, 1.25 Mpts each pod
Vertical resolution 1 bit
Threshold selections TTL, CMOS, ECL, user-definable (selectable by pod)
Maximum input voltage ±40 V peak CAT I
Glitch detection 2 ns (min pulse width)
8
Performance characteristics (continued)
Analog to digital conversion
Vertical resolution 8 bits
Sample rate DSO6014L: 2 GSa/sec
DSO6054L/6104L: 4 GSa/sec half channel, 2 GSa/sec each channel
Equivalent-time sample rate: 400 GSa/s (when realtime mode is turned off)
Standard memory depth 8 Mpts per half channel, 4 Mpts per each channel
Time range 5 nsec/div to 50 sec/div (DSO6014L)
1 nsec/div to 50 sec/div (DSO6054L)
500 psec/div to 50 sec/div (DSO6104L)
Acquisition
Acquisition mode Normal, Peak Detect, Averaging, High Resolution
Peak detection DSO6014L: 1 nsec peak detect
DSO6054L/6104L: 250 psec peak detect
Averaging Selectable from 2,4,8,16,32,64… to 65536
High resolution mode Time base Bits of resolution
< 100 nsec/div 8
500 nsec/div 9
2 µsec/div 10
10 µsec/div 11
≥ 50 µsec/div 12
Filter Sinx/x interpolation
Trigger system
Sources DSO6xx4L: Ch 1, 2, 3, 4, line, ext and D0 - D15 for MSO enabled DSO
Modes Auto, Normal, Single
Holdoff time range ~60 ns to 10 seconds
Trigger jitter 15 psec rms
Selections Edge, pulse width, pattern, TV, duration, sequence, CAN, LIN, USB, I2C, SPI, Nth edge burst
Scope channel triggering
Range (internal) ±6 div from center screen
Sensitivity* < 10 mV/div: greater of 1 div or 5 mV
≥ 10mV/div: 0.6 div
Coupling AC (~10 Hz), DC, noise reject, HF reject and LF reject (~ 50 kHz)
* Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and ±10 °C from firmware calibration temperature.
9
Performance characteristics (continued)
Logic (D15 - D0) channel triggering (with MSO option)
Threshold range (user defined) ±8.0 V in 10 mV increments
Threshold accuracy* ±(100 mV + 3% of threshold setting)
Predefined thresholds TTL = 1.4 V, CMOS = 2.5 V, ECL = –1.3 V
* Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and ±10 °C from firmware calibration temperature.
External (EXT) triggering
Input resistance 1.015 kΩ ± 5% (DSO6014L)
2.14 kΩ ± 5% (DSO6054L/6104L)
Maximum input ±15 V
Range ±5 V
Sensitivity DC to 100 MHz: 500 mV (DSO6014L)
DC to 500 MHz: 500 mV (DSO6054L/6104L)
Coupling AC (~ 3.5 Hz), DC, noise reject, HF reject and LF reject (~ 50 kHz)
Probe ID Auto probe sense (DSO6014L)
Auto probe sense and AutoProbe interface (DSO6054L/6104L)
Measurement features
Automatic measurements Measurements are continuously updated. Cursors track last selected measurement.
Voltage (scope channels only) Peak-to-peak, maximum, minimum, average, amplitude, top, base, overshoot, preshoot, RMS,
standard deviation (AC RMS)
Time Frequency, period, + width, – width and duty cycle on any channels
Rise time, fall time, X at max Y (time at max volts), X at min Y (time at min volts), delay, and
phase on scope channels only
Counter Built-in 5-digit frequency counter on any scope channel. Counts up to the scope’s bandwidth
(1 GHz max). The counter resolution can be increased to 8 digits with an external 10 MHz
reference.
Threshold definition Variable by percent and absolute value; 10%, 50%, 90% default for time measurements
Cursors Manually or automatically placed readout of horizontal (X, ∆X, 1/∆X) and vertical (Y, ∆Y)
Additionally logic or scope channels can be displayed as binary or hex values
Waveform math One function of 1-2, 1x2, FFT, differentiate, integrate.
Source of FFT, differentiate, integrate: scope channels 1 or 2, 1-2, 1+2, 1x2
10
Performance characteristics (continued)
FFT
Points Fixed at 1000 points
Source of FFT Scope channels 1, 2, 3 or 4, 1+2, 1-2, 1x2
Window Rectangular, flattop, Hanning
Noise floor –50 to –90 dB depending on averaging
Amplitude Display in dBV, dBm at 50 Ω
Frequency resolution 0.05/(time per div)
Maximum frequency 50/(time per div)
Storage
Save/recall (non-volatile) 10 setups and traces can be saved and recalled internally. Secure environment mode (-SEC)
ensures setups and traces are stored to volatile memory.
Storage type and format USB 1.1 drive on front (/drive0) and rear (/drive5) panels
Image formats: BMP (8 bit), BMP (24 bit) and PNG (24 bit)
Data formats: X and Y (time/voltage) values in CSV, ASCII XY and binary format
Trace/setup formats: Recalled
I/O
Standard ports USB 2.0 high speed, 10/100-BaseT LAN, IEEE488.2 GPIB, XGA video output
Max transfer rate IEEE488.2 GPIB: 500 kbytes/sec
USB (USBTMC-USB488): 3.5 Mbytes/sec
100 Mbps LAN (TCP/IP): 1 Mbytes/sec
General characteristics
Rack mounting Supplied with all necessary hardware (except tools) for installation into a standard EIA 19-inch
rack
Physical size 43.5 cm W x 27 cm D x 4.2 cm H (without brackets)
Weight Net: 2.45 kg (5.4 lbs.)
Shipping: 6.2 kg (13.6 lbs.)
Probe comp output Frequency ~2 kHz
Amplitude ~5 V
11
Performance characteristics (continued)
General characteristics (continued)
Trigger out
When Triggers is selected 0 to 5 V into high impedance
(delay ~17 ns) 0 to 2.5 V into 50 Ω
When Source Frequency or 0 to 580 mV into high impedance
Source Frequency/8 is selected 0 to 290 mV into 50 Ω
Max frequency output 350 MHz (in source frequency mode when terminated in 50 Ω)
125 MHz (in source frequency/8 mode when terminated in 50 Ω)
10 MHz ref in/out TTL out, 180 mV to 1 V amplitude within 0 to 2 V offset
Power requirements
Line voltage range 96-144 V/48-440 Hz, 192-288V/48-66 Hz, automatic selection
Line frequency 50/60 Hz, 100-240 VAC; 440 Hz, 100-132 VAC
Power usage 100 W max
Environmental characteristics
Ambient temperature Operating –10 °C to +50 °C; non-operating –51 °C to +71 °C
Humidity Operating 95% RH at 40 °C for 24 hours; Non-operating 90% RH at 65 °C for 24 hours
Altitude Operating to 4,570 m (15,000 ft); non-operating to 15,244 m (50,000 ft)
Vibration Agilent class GP and MIL-PRF-28800F; Class 3 random
Shock Agilent class GP and MIL-PRF-28800F; (operating 30 g, 1/2 sine, 11-ms duration, 3 shocks/axis
along major axis. Total of 18 shocks)
Pollution degree 2 Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation must be expected.
Indoor use This instrument is rated for indoor use only
Other
Installation categories CAT I: Mains isolated
CAT II: Line voltage in appliance and to wall outlet
EMC IEC 61326-1:1997, EN 61326-1:1997
Safety IEC 61010-1:2001, EN 61010-1:2001
Canada: CSA-C22.2 No. 1010.1:1992
UL 61010-1:2003
Supplementary information The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC
and the EMC Directive 89/336/EEC, and carries the CE-marking accordingly.
12
Ordering information
Model number Description
DSO6104L 1 GHz 4-ch DSO
DSO6054L 500 MHz 4-ch DSO
DSO6014L 100 MHz 4-ch DSO
Accessories included:
Model number DSO6104L/6054L DSO6014L
User’s guide, Service guide, √√
Programmer’s guide
Power cord √√
10:1 divider passive probe per √√
scope channel
Agilent IO Libraries Suite 14.2 √√
Standard 1 year warranty √√
GPIB extender √√
50 Ω termination adapter √
Crossover LAN cable √√
Rack mount hardware √√
Available options
Option number Description DSO6054L/6104L DSO6014L
N2914A* MSO upgrade kit for DSO6014L √
N2915A* MSO upgrade kit for DSO6054L/6104L √
-SEC Secure environment mode (factory installed option) √√
N5423A (-LSS) I2C/SPI decode option √√
N5424A (-AMS) CAN/LIN decode option √√
N5406A FPGA dynamic probe √√
* Includes a 54620-68701 logic cable kit, a label and an upgrade key code to activate the MSO features
13
Ordering information (continued)
Warranty and calibration options
All models include a standard 1-year warranty. Contact local sales office for prices of extended options:
Option number Description
R-51B-001-3C 1-year return-to-Agilent warranty, extended to 3 years
Passive probes
Product number Description
10070C 1:1 passive probe with ID
10074C 10:1 150MHz passive probe with ID (shipped standard with DSO6014L model)
10073C 10:1 500 MHz passive probe with ID (shipped standard with DSO6054L/6104L models)
Current probes
Product number Description
1146A 100-kHz current probe, ac/dc
1147A 50-MHz current probe, ac/dc with AutoProbe interface (power supply not required)
N2774A 50-MHz current probe, ac/dc
N2775A Power supply for N2774A
High-voltage probes
Product number Description
10076A 100:1, 4 kV, 250-MHz probe with ID
N2771A 1000:1, 15 kV, 50-MHz high-voltage probe
Logic probes
Product number Description
10085-68701 16:16 logic cable and terminator
54620-68701 16:2 x 8 logic input probe assembly
14
Related Literature
Publication Title Publication Type Publication Number
Agilent 6000 Series Oscilloscopes Data Sheet 5989-2000EN/EUS
Agilent 6000 Series and 54600 Series Data Sheet 5968-8153EN/EUS
Oscilloscope Probes and Accessories
Option SEC N5427A Secure Environment Data Sheet 5968-5558EN
Mode Option
Next-Generation Test Systems Application Note 5989-2802EN
LXI: Going Beyond GPIB, PXI and VXI Application Note 5989-4371EN
Optimizing Test Systems for Highest Throughput, Application Note 5989-4886EN
Lowest Cost and Ease of Integration with
LXI Instruments
Open the Door to Simpler System Creation Brochure 5989-2042EN
Ordering information (continued)
Active single-ended probes
Product number Description
1144A 800-MHz active probe
1145A 2-channel 750-MHz active probe
1142A Power supply for 1144A and 1145A
1156A 1.5-GHz active probe with AutoProbe interface (power supply not required)
Active differential probes
Product number Description
N2772A 20 MHz differential probe
N2773A Differential probe power supply for N2772A
1130A 1.5 GHz InfiniiMax differential probe amplifier with AutoProbe interface (Order one or more
InfiniiMax probe heads or connectivity kits per amplifier.)
www.agilent.com
For more information on Agilent
Technologies’ products, applications
or services, please contact your local
Agilent office. The complete list is
available at:
www.agilent.com/find/contactus
Phone or Fax
United States:
(tel) 800 829 4444
(fax) 800 829 4433
Canada:
(tel) 877 894 4414
(fax) 800 746 4866
China:
(tel) 800 810 0189
(fax) 800 820 2816
Europe:
(tel) 31 20 547 2111
Japan:
(tel) (81) 426 56 7832
(fax) (81) 426 56 7840
Korea:
(tel) (080) 769 0800
(fax) (080) 769 0900
Latin America:
(tel) (305) 269 7500
Taiwan:
(tel) 0800 047 866
(fax) 0800 286 331
Other Asia Pacific Countries:
(tel) (65) 6375 8100
(fax) (65) 6755 0042
Email: tm_ap@agilent.com
Revised: 09/14/06
Product specifications and descriptions
in this document subject to change
without notice.
© Agilent Technologies, Inc. 2006
Printed in USA, December 12, 2006
5989-5470EN
www.agilent.com/find/emailupdates
Get the latest information on the products
and applications you select.
www.agilent.com/find/quick
Quickly choose and use your test
equipment solutions with confidence.
www.agilent.com/find/open
Agilent Open simplifies the process of
connecting and programming test systems
to help engineers design, validate and
manufacture electronic products. Agilent
offers open connectivity for a broad range
of system-ready instruments, open industry
software, PC-standard I/O and global
support, which are combined to more easily
integrate test system development.
Microsoft
®
and Windows®are U.S.
registered trademarks of Microsoft
Corporation.
Pentium®is a U.S. registered trademark of
Intel Corporation.
Agilent Email Updates
t
Remove all doubt
Our repair and calibration services will get
your equipment back to you, performing
like new, when promised. You will get full
value out of your Agilent equipment
throughout its lifetime. Your equipment
will be serviced by Agilent-trained
technicians using the latest factory
calibration procedures, automated repair
diagnostics and genuine parts. You will
always have the utmost confidence in
your measurements.
Agilent offers a wide range of additional
expert test and measurement services for
your equipment, including initial start-up
assistance onsite education and training,
as well as design, system integration,
and project management.
For more information on repair and
calibration services, go to
www.agilent.com/find/removealldoubt
Agilent Direc
Agilent Open
Loading...
