Programmer’s Guide

HP 8702D Lightwave Component Analyzer

HP Part No. 08702-90042 Printed in USA April 1997

Hewlett-Packard Company Lightwave Operations 1400 Fountaingrove Parkway Santa Rosa, CA 95403-1799, USA (707) 577-1400

Notice.

The information contained in this document is subject to change without notice. Companies, names, and data used in examples herein are fictitious unless otherwise noted. Hewlett-Packard makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. HewlettPackard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

Restricted Rights Legend.

Use, duplication, or disclosure by the U.S. Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 for DOD agencies, and subparagraphs (c) (1) and (c) (2) of the Commercial Computer Software Restricted Rights clause at FAR 52.227-19 for other agencies.

Safety Symbols.

CAUTION

The

caution

sign denotes a hazard. It calls attention to a procedure which, if not correctly performed or adhered to, could result in damage to or destruction of the product. Do not proceed beyond a caution sign until the indicated conditions are fully understood and met.

WARNING

The

warning

sign denotes a hazard. It calls attention to a procedure which, if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a warning sign until the indicated conditions are fully understood and met.

The instruction manual symbol. The product is marked with this warning symbol when it is necessary for the user to refer to the instructions in the manual.

The laser radiation symbol. This warning symbol is marked on products which have a laser output.

The AC symbol is used to indicate the required nature of the line module input power.

The ON symbols are

used to mark the positions of the instrument power line switch.

The OFF symbols

❍

are used to mark the positions of the instrument power line switch.

The CE mark is a registered trademark of the European Community.

The CSA mark is a registered trademark of the Canadian Standards Association.

This text denotes the

ISM1-A

instrument is an Industrial Scientific and Medical Group 1 Class A product.

Typographical Conventions.

The following conventions are used in this book:

Key type

for keys or text located on the keyboard or instrument.

Softkey type

for key names that are displayed on the instrument’s screen.

Display type

for words or characters displayed on the computer’s screen or instrument’s display.

User type

for words or charac-

ters that you type or enter.

Emphasis

type for words or characters that emphasize some point or that are used as place holders for text that you type.

The HP 8702D—At a Glance

HP 8702D Programmer’s Guide

The ment. The programming syntax conforms to the

tal Interface for Programmable Instrumentation

Chapter 1, “Writing Programs” provides information on addressing the instrument, debugging programs, and other important tasks. Each programming command is documented in Chapter 3, “Language Reference”. Chapter 4, “Graphics Language Reference” documents graphics commands for drawing objects on the display. Refer to Chapter 2, “Examples” for a list of practical examples using common measurement tasks.

shows you how to program the instru-

IEEE 488.2 Standard Digi-

iii

The HP 8702D—At a Glance

The HP 8702D—At a Glance iii

1 Writing Programs

General Information 1-4 Selecting the HP-IB Device Mode 1-9 Making Measurements 1-11 Reading Data 1-14 Data-Processing Chain 1-21 Controlling Command Execution 1-25 Calibrating for Measurements 1-27 Debugging Programs 1-30 Understanding File Names 1-31 Drawing Graphics on the Display 1-33 Monitoring the Instrument 1-34 Response to IEEE-488 Universal Commands 1-40

2 Examples

Preparing Measurement Settings 2-4 Verifying Measurement Settings 2-6 S11 1-Port Measurement Calibration 2-8 Full 2-Port Measurement Calibration 2-13 Data Transfer Using Markers 2-18 Data Transfer Using ASCII Format 2-22 Data Transfer Using Floating-Point Numbers 2-25 Data Transfer Using Frequency-Array Information 2-28 Data Transfer Using Internal Binary Format 2-32 Using Error Queue 2-34 Generating Interrupts 2-37 Power Meter Calibration 2-41 Using the Learn String 2-45 Reading Calibration Data 2-48 Using Instrument States 2-52 Setting a List Frequency Sweep 2-56 Selecting a Single Segment 2-61 Setting up Limit Lines 2-65 Performing Pass/Fail Tests 2-69 Operation Using Talker/Listener Mode 2-73

Contents-1

Contents

Controlling Peripherals 2-76 Printing Via the Serial Port 2-80 Plotting Data 2-83 Reading Plot Files from Disk 2-86 Reading ASCII Instrument Files 2-94

3 Language Reference

4 Graphics Language Reference

5 Tables and Charts

HP-IB Requirements 5-3 Programming Commands by Functional Group 5-8 Key Definitions 5-26

Contents-2

Writing Programs

This chapter provides a general introduction to programming the HP 8702D. It covers topics such as command syntax, addressing the instrument, initializing the instrument, and returning measurement results to the computer.

Before you begin programming, you should first become proficient at making manual measurements as explained in the learn the techniques and softkey presses needed to make a measurement, you can refer to Table 5-4, “Keys versus Programming Commands,” on page 5-26 to locate the equivalent programming command.

NOTE:

HP 8702D User’s Guide

. Once you

The HP 8702D conforms to IEEE 488.1 and IEC-625 standards for interfacing instruments.

1-2

What you’ll find in this chapter

General Information 1-4

To select the communication mode 1-8 To change the HP-IB address 1-8

Selecting the HP-IB Device Mode 1-9

To change the HP-IB device mode 1-10 Making Measurements 1-11 Reading Data 1-14 Data-Processing Chain 1-21 Controlling Command Execution 1-25 Calibrating for Measurements 1-27

To calibrate the instrument 1-27 Debugging Programs 1-30

To start debugging mode 1-30 Understanding File Names 1-31 Drawing Graphics on the Display 1-33 Monitoring the Instrument 1-34 Response to IEEE-488 Universal Commands 1-40

Writing Programs

1-3

Writing Programs

General Information

The HP 8702D occupies two HP-IB addresses: the instrument itself and the display. The display address is derived from the instrument address as described in “Drawing Graphics on the Display” on page 1-33. These addresses are stored in short-term, non-volatile memory and are not affected when you

PRESET

press device 16, and the display address is device 17.

There is also an address for the system controller. This address refers to the controller when the HP 8702D is being used in pass-control mode. This is the address that control is passed back to when the HP 8702D-controlled operation is complete.

You can change the HP-IB address from the front panel as described in “To change the HP-IB address” on page 1-8.

or cycle the power. The default address for the HP 8702D is

HP-IB status lights

When the HP 8702D is connected to the HP-IB, the front-panel HP-IB status lights indicate the current status of the HP 8702D. These lights have the following definitions:

R = Remote operation

L = Listen mode

T = Talk mode

S = Service request (SRQ) asserted by the HP 8702D

Remote mode and front-panel lockout

Whenever the instrument is controlled by a computer, the front-panel HP-IB remote status light, R, is turned on, and the instrument keys are disabled. Press the

Consult the documentation for your programming environment to determine which commands are used to put an instrument in the remote and local lockout modes. These are not HP 8702D commands; they control HP-IB control lines and do not send any characters to the HP 8702D.

1-4

LOCAL

key to restore front panel control of the instrument.

Writing Programs

General Information

Initialize the instrument at the start of every program

It is good practice to initialize the instrument at the start of every program. This ensures that the bus and all appropriate interfaces are in a known state. HP BASIC provides a CLEAR command which clears the interface buffer and also resets the instrument’s parser. (The parser is the program that reads the instructions that you send.) Whenever the instrument is under remote programming control, it should be in the single measurement acquisition mode. This is automatically accomplished when the RST is used. The RST command initializes the instrument to the factory preset state:

CLEAR 716 OUTPUT 716;”RST”

Notice in the example above, that the commands are sent to an instrument address of 716. This indicates address 16 on an interface with select code 7. Pressing the

SET

key resets the instrument to either the factory preset state or a user-

PRESET

key does not change the HP-IB address. Pressing the

PRE-

defined preset state.

Rules for writing commands

The HP 8702D accepts letters, changing lowercase to uppercase, numbers, decimal points, +, –, semicolons, carriage returns and line feeds. Leading zeros, spaces, carriage returns, and unnecessary terminators are ignored, except when inserted between a command and a numerical or string argument. If the analyzer does not recognize a character as appropriate, it generates a syntax error message and recovers at the next terminator.

For example, the CHAN command must be entered as CHAN1 or CHAN2. Inserting a space in the syntax (CHAN 1) results in an error. However, a space must be entered between the MARK2 command and its argument. For example, MARK2 1.4GHZ.

Units and terminators

The HP 8702D outputs data in basic units and assumes these basic units when it receives an input (unless the input is otherwise qualified). The basic units and allowable expressions can be found below. Both uppercase and lowercase letters are acceptable.

1-5

Writing Programs

General Information

Table 1-1. Terminator Codes

S Seconds HZ Hertz

MS Milliseconds KHZ Kilohertz

US Microseconds MHZ Megahertz

NS Nanoseconds GHZ Gigahertz

PS Picoseconds DB dB or dBm

FS Femtoseconds V Volts

Terminators are used to indicate the end of a command. This allows the HP 8702D to recover to the next command in the event of a syntax error. The semicolon (;) is the recommended command terminator. The line-feed character (LF) and the HP-IB EOI line can also be used as terminators. Again, the HP 8702D will ignore the carriage-return character (CR).

1-6

General Information

Table 1-2. HP-IB Interface Capabilities

Capability Description

SH1 Full-source handshake.

AH1 Full-acceptor handshake.

T6 Basic talker, answers serial poll, unaddresses if MLA is issued. No talk-only mode.

L4 Basic listener, unaddresses if MTA is issued. No listen-only mode.

SR1 Complete service request (SRQ) capabilities.

RL1 Complete remote/local capability including local lockout.

PP0 Does not respond to parallel poll.

DC1 Complete device clear.

DT1 Responds to a Group Execute Trigger (GET) in the hold-trigger mode.

Writing Programs

C1,C2,C3 System controller capabilities in system-controller mode.

C10 Pass control capabilities in pass-control mode.

E2 Tri-state drivers.

LE0 No extended listener capabilities.

TE0 No extended talker capabilities.

1-7

Writing Programs

General Information

To select the communication mode

Press the

Press

LOCAL

key.

TALKER/LISTENER

so that this softkey is underlined.

To change the HP-IB address

Press the

Press

Use the front-panel knob or keys to enter the new HP-IB address.

LOCAL

key.

SET ADDRESSES.

ADDRESS: 8702

1-8

Writing Programs

Selecting the HP-IB Device Mode

Three different device modes are possible for the HP 8702D:

• talker/listener mode

• system-controller mode

• pass-control mode

Performing an instrument preset does not affect the selected bus mode, although the bus mode will return to talker/listener mode if the line power is cycled.

Tal k er /li st e ne r mo d e

This is the mode that is normally used for remote programming of the HP 8702D. In talker/listener mode, the HP 8702D and all peripheral devices are controlled from an external instrument controller. The controller can command the HP 8702D to talk and other devices to listen. The HP 8702D and peripheral devices cannot talk directly to each other unless the computer sets up a data path between them. This mode allows the HP 8702D to act as either a talker or a listener, as required by the controlling computer for the particular operation in progress.

While in this mode, the HP 8702D can make a plot or print using the

PLOT;

addressed to talk by the system controller and then dump the display to a plotter/printer that the system controller has addressed to listen. Use of the commands controller.

OUTPPRIN;

PLOT;

commands. The HP 8702D will wait until it is

PRINALL;

and

require control to be passed to another

OUTP-

System-controller mode

Do not attempt to use this mode for programming. This mode allows the HP 8702D to control peripherals directly in a stand-alone environment (without an external controller). This mode can only be selected manually from the HP 8702D’s front panel. It can only be used if no active computer or instrument controller is connected to the system via HP-IB. If an attempt is made to set the HP 8702D to the system-controller mode when another controller is

1-9

Writing Programs

Selecting the HP-IB Device Mode

connected to the interface, the following message is displayed on the HP 8702D’s display screen:

ON HP-IB"

The HP 8702D must be set to the system-controller mode in order to access peripherals from the front panel. In this mode, the HP 8702D can directly control peripherals (for example, plotters, printers, disk drives, and power meters) and the HP 8702D may plot, print, store on disk or perform power meter functions.

Pass-control mode

This mode allows the computer to control the HP 8702D via HP-IB (as with the talker/listener mode), but also allows the HP 8702D to take control of the interface in order to plot, print, or access a disk. During an HP 8702D-controlled peripheral operation, the host computer is free to perform other internal tasks (for example, data or display manipulation) while the HP 8702D is controlling the bus. After the HP 8702D-controlled task is completed, the HP 8702D returns control to the system controller.

In pass-control mode, the HP 8702D can request control from the system controller and take control of the bus if the controller addresses it to take control. This allows the HP 8702D to take control of printers, plotters, and disk drives on an as-needed basis. The HP 8702D sets event-status-register bit 1 when it needs control of the interface, and the HP 8702D will transfer control back to the system controller at the completion of the operation. It will pass control back to its controller address, specified by ADDRCONT.

"CAUTION: ANOTHER SYSTEM CONTROLLER

To change the HP-IB device mode

Press the

Press

1-10

LOCAL

key.

SET ADDRESSES.

Writing Programs

Making Measurements

This section explains how to organize instrument commands into a measurement sequence. A typical measurement sequence consists of the following steps:

Setting up the instrument

Calibrating the test setup

Connecting the device under test

Taking the measurement data

Post-processing the measurement data

Transferring the measurement data

Step 1. Setting up the instrument

Define the measurement by setting all of the basic measurement parameters. These include:

• sweep type

• frequency span

• sweep time

• number of points (in the data trace)

• RF power level

• type of measurement

• IF averaging

• IF bandwidth

You can quickly set up an entire instrument state, using the save/recall registers and the learn string. The learn string is a summary of the instrument state compacted into a string that the computer reads and retransmits to the analyzer. Refer to “Using the Learn String” on page 2-45.

1-11

Writing Programs

Making Measurements

Step 2. Calibrating the test setup

After you have defined an instrument state, you should perform a measurement calibration. Although it is not required for the measurement of O/E and E/O devices, a measurement calibration is required to obtain useful measurements.

The following list describes several methods to calibrate the analyzer:

• Stop the program and perform a calibration from the analyzer’s front panel.

• Use the computer to guide you through the calibration, as discussed in “S11 1Port Measurement Calibration” on page 2-8 and “Full 2-Port Measurement Calibration” on page 2-13.

• Transfer the calibration data from a previous calibration back into the analyzer, as discussed in “Using Instrument States” on page 2-52.

Step 3. Connecting the device under test

After you connect your test device, you can use the computer to speed up any necessary device adjustments such as limit testing, bandwidth searches, and trace statistics.

Step 4. Taking the measurement data

Measure the device response and set the analyzer to hold the data. This captures the data on the analyzer display.

By using the single-sweep command (SING), you can insure a valid sweep. When you use this command, the analyzer completes all stimulus changes before starting the sweep, and does not release the HP-IB hold state until it has displayed the formatted trace. Then when the analyzer completes the sweep, the instrument is put into hold mode, freezing the data. Because single sweep is OPC-compatible, it is easy to determine when the sweep has been completed.

The number-of-groups command (NUMGn) triggers multiple sweeps. It is designed to work the same as the single-sweep command. NUMGn is useful for making a measurement with an averaging factor n (n can be 1 to 999). Both the single-sweep and number-of-groups commands restart averaging.

1-12

Writing Programs

Making Measurements

Step 5. Post-processing the measurement data

Figure 1-1 on page 1-22 shows the process functions used to affect the data

after you have made an error-corrected measurement. These process functions have parameters that can be adjusted to manipulate the error-corrected data prior to formatting. They do not affect the analyzer’s data gathering. The most useful functions are trace statistics, marker searches, electrical-delay offset, time domain, and gating.

After performing and activating a full 2-port measurement calibration, any of the four S-parameters may be viewed without taking a new sweep.

Step 6. Transferring the measurement data

Read your measurement results. All the data-output commands are designed toensure that the data transmitted reflects the current state of the instrument.

1-13

Writing Programs

Reading Data

Output queue

Whenever a output-data command is received, the HP 8702D puts the data into the output queue (or buffer) where it is held until the system controller outputs the next read command. The queue, however, is only one event long; the next output-data command will overwrite the data already in the queue. Therefore, it is important to read the output queue immediately after every interrogation or data request from the HP 8702D.

Command interrogate

All instrument functions can be interrogated to find the current ON/OFF state or value. For instrument state commands, append the question mark character (?) to the command to interrogate the state of the functions. Suppose the operator has changed the power level from the HP 8702D’s front panel. The computer can ascertain the new power level using the HP 8702D’s commandinterrogate function. If a question mark is appended to the root of a command, the HP 8702D will output the value of that function. For instance,

POWE 7 DB;

RF source power at the test port. When the HP 8702D receives prepares to transmit the current RF source power level. This condition illuminates the HP 8702D front-panel talk light (T). In this case, the HP 8702D transmits the output power level to the controller.

ON/OFF commands can be also be interrogated. The reply is a one (1) if the function is ON or a zero (0) if it is OFF. For example, if a command controls an active function that is underlined on the HP 8702D display, interrogating that command yields a one (1) if the command is underlined or a zero (0) if it is not. As another example, there are nine options on the format menu and only one option is underlined at a time. Only the underlined option will return a one (1) when interrogated. For instance, send the command string the HP 8702D. If dual-channel display is switched ON, the HP 8702D will return a one (1) to the instrument controller.

sets the source power to 7 dB, and

POWE?;

outputs the current

POWE?;

, it

DUAC?;

1-14

Writing Programs

Reading Data

Similarly, to determine if phase is being measured and displayed, send the command string

PHAS?;

to the HP 8702D. In this case, the HP 8702D will return a one (1) if phase is currently being displayed. Since the command only applies to the active channel, the response to the

PHAS?;

query depends on

which channel is active.

Output syntax

The following three types of data are transmitted by the HP 8702D in ASCII format:

• response to interrogation

• certain output commands

• ASCII floating-point (form 4) array transfers Marker-output commands and interrogated commands are output in ASCII format only, meaning that each character and each digit is transmitted as a separate byte, leaving the receiving computer to reconstruct the numbers and strings. Numbers are transmitted as 24-character strings, consisting of:

-DDD.DDDDDDDDDDDDDDDE-DD

When multiple numbers are sent, the numbers are separated by commas.

Table 1-3. Form 4 (ASCII) Data-Transfer Character Definitions

Character(s)* Definition

Sign – for negative, blank for positive.

3 digits Digits to the left of the decimal point.

Decimal point

15 digits Digits to the right of the decimal point.

E Exponent notation.

Sign – for negative, + (or blank) for positive.

Exponent Two digits for the exponent.

* The items in this column are separated by commas and delimited (terminated) with a line feed character (LF).

1-15

Writing Programs

Reading Data

Marker data

The HP 8702D offers several options for outputting trace-related data. Trace information can be read out of the HP 8702D in several different formats. Data can be selectively read from the trace using the markers, or the entire trace can be read by the controller. If only specific information is required (such as a single point on the trace or the result of a marker search), the marker output command can be used to read the information.

To read the trace data using the marker, the marker must first be assigned to the desired frequency. This is accomplished using the marker commands. The controller sends a marker command followed by a frequency within the tracedata range. If the actual desired frequency was not sampled, the markers can be set to continuous mode and the desired marker value will be linearly interpolated from the two nearest points. This interpolation can be prevented by putting the markers into discrete mode. Discrete mode allows the marker to only be positioned on a measured trace-data point.

As an alternative, the HP 8702D can be programmed to choose the stimulus value by using the or bandwidths search can be automatically determined with

MARKER SEARCH

function. Maximum, minimum, target value,

MARKER SEARCH

To continually update the search, switch the marker tracking ON. The tracemaximum search will remain activated until:

• The search is switched OFF

• The tracking is switched OFF

• All markers are switched OFF

Marker data can be output to a controller with a command to the HP 8702D. This set of commands causes the HP 8702D to transmit three numbers: marker value 1, marker value 2, and marker stimulus value. In log-magnitude display mode we get the log magnitude at marker 1, zero, and the marker frequency. Refer to “Units as a Function of Display Format” on page 1-17 for a complete listing of all the possibilities for values 1 and 2. The three possibilities for the third parameter are:

•frequency

• time (as in time domain)

• CW time

1-16

Table 1-4. Units as a Function of Display Format

OUTPMARK OUTPFORM Marker Readout

Display Format Marker Mode

Value 1 Value 2 Value 1 Value 2 Value

Writing Programs

Reading Data

AUX

Value

LOG MAG dB † dB † dB

PHASE degrees † degrees †

DELAY seconds † seconds †

SMITH CHART LIN MKR lin mag degrees real imag lin mag degrees

LOG MKR dB degrees real imag dB degrees

Re/Im real imag real imag real imag

R + jX real ohms imag ohms real imag real ohms imag ohms

G + jB real

Siemens

POLAR LIN MKR lin mag degrees real imag lin mag degrees

LOG MKR dB degrees real imag dB degrees

Re/Im real imag real imag real imag

LIN MAG lin mag † lin mag † lin mag †

REAL real † real † real

SWR SWR † SWR † SWR

* The marker readout values are the marker values displayed in the upper right-hand corner of the display. They also correspond to the value and auxiliary value associated with the fixed marker.

†

Value 2 is not significant in this format, though it is included in data transfers.

imag

Siemens

real imag real

degrees †

seconds †

Siemens

†

imag

Siemens

†

1-17

Writing Programs

Reading Data

Array-data formats

The HP 8702D can transmit and receive arrays in the HP 8702D’s internal binary format, as well as four different numeric formats. The current format is set with the FORM command. This command does not affect learn-string transfers, calibration-kit string transfers, or non-array transfers, such as command interrogate, or output marker values. A transmitted array will be output in the current format, and the HP 8702D will attempt to read incoming arrays according to the current format. Each data point in an array is a pair of numbers, usually a real/imaginary pair. The number of data points in each array is the same as the number of points in the current sweep.

The five formats are described below:

The HP 8702D’s internal binary format, 6 bytes-per-data point. The array is preceded by a four-byte header. The first two bytes represent the string the standard block header. The second two bytes are an integer representing the number of bytes in the block to follow. FORM 1 is best applied when rapid data transfers, not to be modified by the computer nor interpreted by the user, are required.

IEEE 32-bit floating-point format, 8 bytes-per-data point. The data is preceded by the same header as in FORM 1. Each number consists of a 1-bit sign, an 8bit biased exponent, and a 23-bit mantissa. FORM 2 is the format of choice if your computer supports single-precision floating-point numbers.

"#A"

IEEE 64-bit floating-point format, 16 bytes-per-data point. The data is preceded by the same header as in FORM 1. Each number consists of a 1-bit sign, an 11-bit biased exponent, and a 52-bit mantissa. This format may be used with double-precision floating-point numbers. No additional precision is available in the HP 8702D data, but FORM 3 may be a convenient form for transferring data to your computer.

ASCII floating-point format. The data is transmitted as ASCII numbers, as described in “Output syntax” on page 1-15. There is no header. The HP 8702D uses FORM 4 to transfer data that is not related to array transfers (for example, marker responses and instrument settings).

PC-DOS 32-bit floating-point format with 4 bytes-per-number, 8 bytes-per-data point. The data is preceded by the same header as in FORM 1. The byte order is reversed to comply with PC-DOS formats.

controller, FORM 5 is the most effective format to use.

If you are using a PC-based

The HP 8702D terminates each transmission by asserting the EOI interface line with the last byte transmitted. Table 1-5 on page 1-19 offers a comparative overview of the five array-data formats.

1-18

Table 1-5. HP 8702D/Option 011 Array-Data Formats

Writing Programs

Reading Data

Format Type Type of Data

1 Internal Binary 3 6 1206 1210

2 IEEE 32-bit

Floating-Point

3 IEEE 64-bit

Floating-Point

4 ASCII Numbers 24 50 10,050 10,050

5 PC-DOS 32-bit

Floating-Point

a. There are two data values (real and imaginary) for every data point. b. No header is used in form 4.

Bytes per Data

Value

4 8 1608 1612

8 16 3216 3220

4 8 1608 1612

Bytes per Data

Point

Bytes per 201

Point Trace

Trace-data transfers

Transferring trace data from the HP 8702D using an instrument controller can be divided into three steps:

allocating an array to receive and store the data

commanding the HP 8702D to transmit the data

accepting the transferred data

Total Bytes

with Header

Data residing in the HP 8702D is always stored in pairs for each data point (to accommodate real/imaginary pairs). The real value is first, followed by the imaginary value. Hence, the receiving array has to be two elements wide, and as deep as the number of points in the array being transferred. Memory space for the array must be declared before any data can be transferred from the HP 8702D to the computer. When reading logarithmic amplitude and phase, save the first value of each data point pair and discard the second value.

As mentioned earlier, the HP 8702D can transmit data over HP-IB in five different formats. The type of format affects what kind of data array is declared (real or integer), because the format determines what type of data is transferred. “Data Transfer Using Markers” on page 2-18 illustrates an ASCII transfer using Form 4. For more information on the various data formats, refer to “Array-data formats” on page 1-18. For information on the various types of data that can be obtained (raw data, error-corrected data, etc.), refer to “Data levels” on page 1-23.

1-19

Writing Programs

Reading Data

Frequency-related arrays

Frequency-related values are calculated for the HP 8702D displays. The only data available to the programmer are the start and stop frequencies, or center and span frequencies, of the selected frequency range.

In a linear frequency range, the frequency values can be easily calculated because the trace data points are equally spaced across the trace. Relating the data from a linear frequency sweep to frequency can be done by interrogating the start frequency, the frequency span, and the number of points in the trace.

Given that information, the frequency of point n in a linear-frequency sweep is represented by the equation:

F=Start frequency + (n–1) × Span/(Points–1)

In most cases, this is an easy solution for determining the related frequency value that corresponds with a data point. This technique is illustrated in “Data Transfer Using Markers” on page 2-18.

When using log sweep or a list-frequency sweep, the points are not evenly spaced over the frequency range of the sweep. In these cases, the frequencies can be read directly out of the instrument with the

OUTPLIML

command. “Data Transfer Using Frequency-Array Information” on page 2-28 demonstrates this technique.

Executing

OUTPLIML;

reports the limit-test results by transmitting:

• the stimulus point tested

• a number indicating the limit-test results

• the upper test limit at the stimulus point (if available)

• the lower test limit at the stimulus point (if available)

The numbers used to indicate the limit-test results are:

• a negative one (–1) for no test

• a zero (0) for fail

• a positive one (1) for pass

If there are no limits available, the HP 8702D transmits zeros.

This data is very useful when testing with limit lines. It provides a method of obtaining accurate frequency-stimulus values to correspond with the trace data. The other limit-related values may be discarded and the stimulus values used with the trace-data points.

1-20

Writing Programs

Data-Processing Chain

This section describes the manner in which the HP 8702D processes measurement data. It includes information on data arrays, common output commands, data levels, the learn string, and the calibration kit string.

Data arrays

Figure 1-1 on page 1-22 shows the different kinds of data available within the

instrument:

• raw measured data

• error-corrected data

• formatted data

• trace memory

• calibration coefficients

Trace memory can be directly output to a controller with cannot be directly transmitted back.

OUTPMEMO;

, but it

1-21

Writing Programs

Data-Processing Chain

Figure 1-1. The data-processing chain

All the data-output commands are designed to insure that the data transmitted reflects the current state of the instrument:

OUTPDATA, OUTPRAW

•

, and

OUTPFORM

will not transmit data until all format-

ting functions have completed.

OUTPLIML, OUTPLIMM

•

, and

OUTPLIMF

will not transmit data until the limit

test has occurred (if activated).

OUTPMARK

•

will activate a marker if a marker is not already selected. It will also insure that any current marker searches have been completed before transmitting data.

OUTPMSTA

•

insures that the statistics have been calculated for the current trace before transmitting data. If the statistics are not activated, it will activate the statistics long enough to update the current values before deactivating the statistics.

1-22

Writing Programs

Data-Processing Chain

OUTPMWID

•

insures that a bandwidth search has been executed for the current trace before transmitting data. If the bandwidth-search function is not activated, it will activate the bandwidth-search function long enough to update the current values before switching OFF the bandwidth-search functions.

Data levels

Different levels of data can be read out of the instrument. Refer to the dataprocessing chain in Figure 1-1 on page 1-22.

The following list describes the different types of data that are available from the HP 8702D.

Raw data

Error-corrected data

Formatted data

The basic measurement data, reflecting the stimulus parameters, IF averaging, and IF bandwidth. If a full 2-port measurement calibration is activated, there are actually four raw arrays kept: one for each raw S-parameter. The data can be output to a controller with the commands

OUTPRAW3, OUTPRAW4

. Normally, only raw 1 is available, and it holds the cur-

OUTPRAW1, OUTPRAW2

rent parameter. If a 2-port measurement calibration is active, the four arrays refer to S

, S21, S12, and S22 respectively. This data is represented in real/

imaginary pairs.

This is the raw data with error-correction applied. The array represents the currently measured parameter, and is stored in real/imaginary pairs. The error-corrected data can be output to a controller with the mand. The

OUTPMEMO;

command reads the trace memory, if available. The

OUTPDATA;

com-

trace memory also contains error-corrected data. Note that neither raw nor error-corrected data reflect such post-processing functions as electrical-delay offset, trace math, or time-domain gating.

This is the array of data actually being displayed. It reflects all post-processing functions such as electrical delay and time domain. The units of the array output depend on the current display format. Refer to Table 1-4, “Units as a Function of Display Format,” on page 1-17 for the various units defined as a function of display format.

1-23

Writing Programs

Data-Processing Chain

Calibration coefficients

The results of a measurement calibration are arrays containing calibration coefficients. These calibration coefficients are then used in the error-correction routines. Each array corresponds to a specific error term in the error model. The

HP 8702D User’s Guide

details which error coefficients are used for specific calibration types, as well as the arrays those coefficients can be found in. Not all calibration types use all 12 arrays. The data is stored as real/ imaginary pairs.

Generally, formatted data is the most useful of the four data levels, because it is the same information the operator sees on the display. However, if post-processing is unnecessary (possibly in cases involving smoothing), error-corrected data may be more desirable. Error-corrected data also affords the user the opportunity to input the data to the HP 8702D and apply post-processing at another time.

Learn string and calibration-kit string

The learn string is a summary of the instrument state. It includes all the frontpanel settings, the limit-test tables, and the list-frequency table for the current instrument state. It does not include calibration data or the information stored in the save/recall registers.

The learn string can be output to a controller with the

OUTPLEAS;

executable, which commands the HP 8702D to start transmitting the binary string. The string has a fixed length for a given firmware revision. It can not be more than 3000 bytes in length. The array has the same header as in Form 1.

The calibration kit is a set of key characteristics of the calibration standards used to increase the calibration accuracy. There are default kits for several different connector types. There is also space for a user-defined calibration kit. The command

OUTPCALK

outputs the currently active calibration kit as a binary string in Form 1. As with the learn string, the calibration-kit string has a fixed length for a given firmware revision. It can not be longer than 1000 bytes.

1-24

Writing Programs

Controlling Command Execution

Some HP 8702D commands require relatively longer execution times due to measurement sweeps or other processes and, occasionally, there is a need to know when certain HP 8702D operations have been completed. There is an operation-complete function (OPC) that allows a synchronization of programs with the execution of certain key commands. Table 1-6 on page 1-26 lists all the OPC-compatible commands for the instrument.

Synchronized program execution with OPC command

Issue an byte or ESR operation-complete bit will then be set after the execution of the OPC-compatible command. For example, issuing bit to be set when the single sweep is finished. Issuing

OPC;

is complete.

Addressing the HP 8702D to talk after issuing

addressed to talk without selecting output

HP 8702D will halt the computer by not transmitting the one (1) until the command has completed. For example, executing immediately interrogating the HP 8702D, causes the bus to halt until the instrument preset is complete and the HP 8702D outputs a one (1).

As another example, consider the timing of sweep completion. Send the command string HP 8702D sweep time to 3 seconds, and then waits for completion of a single sweep to respond with a one (1). The computer is programmed to read the one (1) response from the HP 8702D as the completion of the single sweep. The program then waits until the sweep is completed before continuing operation. At this point a valid trace exists and the trace data can be read into the computer.

OPC;

, causes the HP 8702D to output a one (1) when the command execution

OPC?;

SWET 3 S;OPC?;SING;

prior to an OPC-compatible command. The status

OPC;SING;

OPC?;

to the HP 8702D. This string sets the

will not cause an

OPC?;PRES;

causes the OPC

OPC?;

, in place of

error, but the

, and then

1-25

Writing Programs

Controlling Command Execution

OPC-compatible commands delay execution of other commands

The HP 8702D cannot process other commands while executing OPC-compatible commands. Once a OPC-compatible command is received, the HP 8702D reads new commands into the input buffer, but it will not begin the execution of any commands until the completion of the OPC-compatible command. When the 15-character input buffer is full, the HP 8702D holds off the bus until it is able to process the commands in the buffer.

Table 1-6. OPC-Compatible Commands

CHAN HARM REFD

CLASS

CLEARALL ISOD

DATI MANTRIG RST

DONE NOOP SAV

EDITDONE NUMG SAVC

EXTTOFF PRES SAVE

EXTTON RAID SAVEREG

EXTTPOIN

FREQOFF

FWDI

FWDM

INSM RESPDONE

REV

RAIRESP

RAIISOL

SING

STAN

RECA TRAD

RECAREG WAIT

a. The CLASS commands are OPC-compatible if there is only one standard in the class.

1-26

Writing Programs

Calibrating for Measurements

Measurement calibration over HP-IB follows the same command sequence as a calibration from the front panel. Since different cal kits can have a different number of standards in a given class, any automated calibration sequence is valid only for a specific cal kit. Table 1-7 on page 1-28 indicates the relation- ship between calibration and classes. Table 1-8 on page 1-29 describes the cal- ibration arrays.

To calibrate the instrument

Select a calibration kit, such as 50 ohm type N ( a calibration standard definition from disk or enter the coefficients for O/E and E/O measurements.

Select a calibration type, such as S

Call each class used by the calibration type, such as

CLASS11A

( transmission, and isolation subsequences must be opened before the classes in the subsequence are called, and then closed at the end of each subsequence.

If a class has more than one standard in it, select a standard from the menu presented (

STANA

The a sweep. If a class has only one standard in it, which means that it will trigger a sweep when called, the class command will be held also.

If, during a calibration, two standards are measured to satisfy one class, the class must be closed with

Declare the calibration done, such as with HP-IB).

over HP-IB). During a 2-port calibration, the reflection,

STANA

STANG

commands are all held commands because they trigger

over HP-IB).

DONE;

1-port (

CALKN50;

CALIS111;

DONE 1-PORT CAL (SAV1;

over HP-IB). Load

over HP-IB).

FORWARD: OPEN

over

1-27

Writing Programs

Calibrating for Measurements

Table 1-7. Relationship Between Calibration and Classes

Class Response

Response

and

Isolation

S11

1-port

S22

1-port

One path

2-port

Full 2-port TRL*/LRM*

Response

and Match

E/O

and Match

Reflectiona:•• •

S11A, RE FW MTCH • • • • • •

S11B, LN FW MTCH • • • • • •

S11C, LN FW TRAN • • • • • •

S22A, LN RV MTCH • • • •

S22B, LN RV TRAN • • • •

S22C, LN RV TRAN • • • •

Transmission: • • •

Forward match • • • •

Forward trans • • • • •

Reverse match • •

Reverse trans • •

Isolation:

Forward • • • • •

Reverse • •

•• •

Response

O/E

Response •

Response and isolation:

Response •

Isolation •

a. These subheadings must be called when doing 2-port calibrations.

1-28

Writing Programs

Calibrating for Measurements

Table 1-8. Calibration Arraysa

Array Response

1ER or ETE

3 E

7 E

8 E

9 E

10 E

11 E

12 E

a. Meaning of first subscript: D=directivity , S=source match , R=reflection tracking, X=crosstalk, L=load match , T=transmissio n tracking. b. Meaning of second subscript: F=forward, R=reverse. c. One path, 2-port cal duplicates arrays 1 to 6 in arrays 7 to 12. d. Response and isolation corrects for crosstalk and transmission tracking in transmission measurements, and for directivity and reflection

tracking in reflection measurements.

Response and

Isolation

(ED)

(ER)ESFE

Response and

Match E/O

Response and

Match O/E

1-port 2-port

TRL*/LRM*

EDF

ESF

ERF

ELF

ETF

ESR

ERR

EXR

ELR

ETR

1-29

Writing Programs

Debugging Programs

An HP-IB diagnostic feature (debug mode) is available in the HP-IB menu. Activating the debug mode causes the analyzer to scroll incoming HP-IB commands across the display. Nonprintable characters are represented with an

character. Any time the analyzer receives a syntax error, the commands halt,

and a pointer indicates the misunderstood character.

To start debugging mode

Press the

Press

LOCAL

key.

HP-IB DIAG ON OFF

so that ON its highlighted.

1-30

Writing Programs

Understanding File Names

Disk files created by the analyzer consist of a state name of up to eight characters, such as FILTER, appended with up to two characters. In LIF format, the file name is FILTERXX. In DOS format, the filename is FILTER.XX. The first appended character is the file type, telling the kind of information in the file. The second appended character is a data index, used to distinguish files of the same type. Data and calibration files are Form 3 data (without a header) which can be read off the disk. The other files are not meant to be decoded.

Table 1-9 on page 1-32 lists the appended characters and their meanings.

1-31

Writing Programs

Understanding File Names

Table 1-9. Disk File Names

Appended

Character 1

I Instrument state

G Graphics 1 Display graphics

D Error corrected data 1 Channel 1

R Raw data 1 to 4 Channel 1, raw arrays 1 to 4

F Formatted data 1 Channel 1

M Memory trace 1 Channel 1

P Instrument state appendix

CCal kit K

1 Cal data, channel 1 0 Stimulus state

Definition

Appended

Character 2

0 Graphics index

2 Channel 2

5 to 8 Channel 2, raw arrays 1 to 4

2 Channel 2

1 to 9 Coefficients 1 to 9

A Coefficient 10

Definition

B Coefficient 11

C Coefficient 12

2 Cal data, channel 2 0 to C Same as channel 1

1-32

Writing Programs

Drawing Graphics on the Display

You can use the HP 8702D’s screen as a graphics display for showing connection diagrams or custom instructions to an operator. For programming purposes, consider the display as a separate device; it has its own HP-IB address. The display’s address is configured automatically based on the address of the HP 8702D.

The display’s default HP-IB address is 17. If you change the HP 8702D’s default address, you can determine the display’s new address with the following instructions. If the HP 8702D address is an even number, add 1 to the address. If the HP 8702D address is an odd number, subtract 1 from the address.

The display accepts a subset of Hewlett-Packard Graphics Language (HP-GL) commands. These commands are documented in Chapter 4, “Graphics Language Reference”. Some HP-GL commands are accepted but ignored. These commands are documented in Table 1-10 on page 1-34.

When using the graphics commands, you will need to specify positions on the display. The origin (0, 0) is located in the display’s lower left corner.

Graticule:

• length: 350 to 4915

• height: 150 to 3950

Complete Display (includes annotation and softkeys):

• length: 0 to 5850

• height: 0 to 4095

1-33

Writing Programs

Monitoring the Instrument

Table 1-10. Ignored but Accepted HP-GL Commands

Command Description

IM Input service request mask

IP Input P1,P2 scaling points

IW Input window

OC Output current pen position

OE Output error

OI Output identity

OS Output status

SL Character slant

SR Relative character size

Monitoring the Instrument

Almost every program that you write will need to monitor the HP 8702D for its operating status and errors. This includes querying execution or command errors and determining whether or not measurements have been completed. Several status registers and queues are provided to accomplish these tasks. In this section, you’ll learn how to enable and read these registers. You’ll also learn about reading the error messages in the error queue.

1-34

Writing Programs

Monitoring the Instrument

Figure 1-2. Status reporting structure

1-35

Writing Programs

Monitoring the Instrument

The Status Byte

The analyzer has a status-reporting mechanism that reports information about specific analyzer functions and events. The status byte (consisting of summary bits) is the top-level register. Each bit reflects the condition of another register or queue. If a summary bit is set (equals 1), the corresponding register or queue should be read to obtain the status information and clear the condition. Reading the status byte does not affect the state of the summary bits. The summary bits always reflect the condition of the summarized queue or register. The status byte can be read by a serial poll or by using the command

OUTPSTAT

operator during the execution of a test sequence.

. When using this command, the sequencing bit can be set by the

OUTPSTAT

does not automatically put the instrument in remote mode, thus giving the operator access to the analyzer’s front-panel functions.

The status byte:

• summarizes the error queue

• summarizes two event-status registers that monitor specific conditions inside the instrument

• contains a bit that is set when the instrument is issuing a service request (SRQ) over HP-IB

• contains a bit that is set when the analyzer has data to transmit over HP-IB

Any bit in the status byte can generate a service request

Any bit in the status byte can be selectively enabled to generate a service request (SRQ) when set. Setting a bit in the service-request-enable register with the

SREnn;

executable enables the corresponding bit in the status byte. The units variable nn represents the binary equivalent of the bit in the status byte. For example,

3+24

= 24) and disables all the other bits. SRE will not affect the state of the

SRE24;

enables status-byte bits 3 and 4 (since

status-register bits.

The status byte summarizes two queues

The status byte also summarizes two queues: the output queue and the error queue. (The error queue is described in “Error Messages” on page 1-39.) When the analyzer outputs information, it puts the information in the output queue where it resides until the controller reads it. The output queue is only one event long. Therefore, the next output request will clear the current data. The summary bit is set whenever there is data in the output queue.

1-36

Writing Programs

Monitoring the Instrument

Table 1-11. Bits in the Status Byte

Bit Definition

0 Waiting for reverse GET. A one path, 2-port measurement calibration is active, and the

instrument has stopped, waiting for the operator to connect the device for reverse measurement.

1 Waiting for forward GET. A one path, 2-port measurement calibration is active, and the

instrument has stopped, waiting for the operator to connect the device for forward measurement.

2 Check event-status-register B. One of the enabled bits in event status register B has

been set.

3 Check error queue. An error has occurred and the message has been placed in the error

queue, but has not been read yet.

4 Message in output queue. A command has prepared information to be output, but it has

not been read yet.

5 Check event-status register. One of the enabled bits in the event-status register has been

set.

6 Request service. One of the enabled status-byte bits is causing an SRQ.

7 Preset. An instrument preset has been executed.

The Event-Status Register and Event-Status-Register B

The event-status register and event-status register B are the other two registers in the status-reporting structure. They are selectively summarized by bits in the status byte via enable registers. The event-status registers consist of latched bits. A latched bit is set at the beginning of a specific trigger condition in the instrument. It can only be cleared by reading the register. The bit will not be reactivated until the condition occurs again. If a bit in one of these two registers is enabled, it is summarized by the summary bit in the status byte. The registers are enabled using the commands which work in the same manner as

SRE

the binary equivalent of the bit in the status byte.

If a bit in one of the event-status registers is enabled, and therefore, summary bit in the status byte is enabled, an SRQ will be generated. The SRQ will not be cleared until one of the five following conditions transpire:

The event-status register is read, clearing the latched bit.

ESEnn;

. The units variable nn represents

and

ESNBnn;

, both of

1-37

Writing Programs

Monitoring the Instrument

The summary bit in the status byte is disabled.

The event-status-register bit is disabled.

The status registers are cleared with the

An instrument preset is performed.

CLES;

command.

Service requests generated when there are error messages or when the instrument is waiting for the Group Execute Trigger (GET) command are cleared by:

• reading the errors

• issuing GET (disabling the bits)

• clearing the status registers

Table 1-12. Bits in the Event-Status Register

Bits Definition

0 Operation complete. A command, for which OPC has been enabled, has completed

operation.

1 Request control. The analyzer has been commanded to perform an operation that

requires control of a peripheral, and needs control of HP-IB. Requires pass-control mode.

2 Query error. The analyzer has been addressed to talk but there is nothing in the output

queue to transmit.

3 Sequence bit. A sequence has executed the assert SRQ command.

4 Execution error. A command was received that could not be executed.

5 Syntax error. The incoming HP-IB commands contained a syntax error. The syntax error

can only be cleared by a device clear or an instrument preset.

6 User request. The operator has pressed a front-panel key or turned the RPG.

7 Power on. A power-on sequence has occurred since the last read of the register.

1-38

Writing Programs

Monitoring the Instrument

Table 1-13. Bits in the Event-Status Register B

Bit Definition

0 Single sweep, number of groups, or calibration step complete. A single sweep, group, or

calibration step has been completed since the last read of the register.

1 Service routine waiting or done. An internal service routine has completed operation, or

is waiting for an operator response.

2 Data entry complete. A terminator key has been pressed or a value entered over HP-IB

since the last read of the register.

3 Limit failed, Channel 2. Limit test failed on Channel 2.

4 Limit failed, Channel 1. Limit test failed on Channel 1.

5 Search failed, Channel 2. A marker search was executed on Channel 2, but the target

value was not found.

6 Search failed, Channel 1. A marker search was executed on Channel 1, but the target

value was not found.

Error Messages

7 Copy Complete. A copy has been completed since the last read of the register.

When an error condition is detected in the analyzer, a message is generated, displayed on the analyzer’s display screen, and placed in the error queue. Error messages consist of an error number followed by an ASCII string no more than 50 characters long. The string contains the same message that appears on the analyzer’s display. The error queue holds up to 20 error messages in the order in which they occur. The error messages remain in the error queue until the errors are read by the system controller using the command

OUTPERRO

. The

OUTPERRO

command outputs one error message.

The error queue can only be cleared by performing an instrument preset or by cycling the line power. In order to keep the queue up-to-date, it is important to read all of the messages out of the queue each time errors are detected.

1-39

Writing Programs

Response to IEEE-488 Universal Commands

Abort

Device Clear

Local

Local Lockout

Parallel Poll

Pass Control

The HP 8702D responds to the abort message (IFC) by halting all listener, talker, and controller functions.

The HP 8702D responds to the device clear commands (DCL, SDC) by clearing the input and output queues, and clearing any HP-IB errors. The status registers and the error queue are unaffected.

The HP 8702D will go into local mode if: the local command (GTL) is received, the remote line is unasserted, or the front-panel ing the HP 8702D’s HP-IB status from remote to local does not affect any of the front-panel functions or values.

If the HP 8702D receives the local-lockout command (LLO) while it is in remote mode, it will disable the entire front panel except for the line power switch. A local-lockout condition can only be cleared by releasing the remote line, although the local command (GTL) will place the instrument temporarily in local mode.

The HP 8702D does not respond to parallel-poll configure (PPC) or parallelpoll unconfigure (PPU) messages.

If the HP 8702D is in pass-control mode, is addressed to talk, and receives the take-control command (TCT) from the system, it will take active control of the bus. If the HP 8702D is not requesting control, it will immediately pass control to the system controller’s address.

LOCAL

key is pressed. Chang-

Remote

The HP 8702D will go into remote mode when the remote line is asserted and the HP 8702D is addressed to listen. While the HP 8702D is held in remote mode, all front-panel keys (with the exception of ing the HP 8702D’s HP-IB status from remote to local does not affect any front-panel settings or values.

1-40

LOCAL

) are disabled. Chang-

Writing Programs

Response to IEEE-488 Universal Commands

Serial Poll

Trigger

The HP 8702D will respond to a serial poll with its status byte, as defined in the “The Status Byte” on page 1-36. To initiate the serial-poll sequence, address the HP 8702D to talk and issue a serial-poll enable command (SPE). Upon receiving this command, the HP 8702D will return its status byte. End the sequence by issuing a serial-poll disable command (SPD). A serial poll does not affect the value of the status byte, and it does not set the instrument to remote mode.

In hold mode, the HP 8702D responds to device trigger by taking a single sweep. If a one-path, 2-port measurement calibration is active, the HP 8702D will set the waiting-for-Group-Execute-Trigger bits in the status byte. If waiting-for-forward-GET is set, the HP 8702D will assume the device is connected for forward measurement and take a sweep when GET is received. Similarly, if the waiting-for-reverse-GET bit is set, the HP 8702D will assume the device is connected for reverse measurement. The HP 8702D responds only to selected-device trigger (SDT). This means that it will not respond to group execute-trigger (GET) unless it is addressed to listen. The HP 8702D will not respond to GET if it is not in hold mode.

1-41

Writing Programs

Response to IEEE-488 Universal Commands

1-42

Examples

Programming Examples

The examples documented in this chapter can be found on the disk that was provided with your instrument. The example disk includes versions of these programs for each of the following languages:

• HP BASIC (LIF format)

• Microsoft’s QuickBASIC (DOS format)

Microsoft

• Microsoft’s QuickC (DOS format)

For the HP BASIC language, examples are written for the HP 82335B interface card.

For the QuickBASIC and QuickC languages, examples are provided for both the HP 82335B Interface and Command Library card and the National Instruments card.

is a U.S. registered trademark of Microsoft Corp.

2-2

What you’ll find in this chapter

Examples

Programming Examples

Measurement Setup

Measurement Calibration

Measurement Data Transfer

Measurement Process Synchronization

System Setups

Limit-Line Testing

Preparing Measurement Settings 2-4 Verifying Measurement Settings 2-6

S11 1-Port Measurement Calibration 2-8 Full 2-Port Measurement Calibration 2-13

Data Transfer Using Markers 2-18 Data Transfer Using ASCII Format 2-22 Data Transfer Using Floating-Point Numbers 2-25 Data Transfer Using Frequency-Array Information 2-28 Data Transfer Using Internal Binary Format 2-32

Using Error Queue 2-34 Generating Interrupts 2-37 Power Meter Calibration 2-41

Using the Learn String 2-45 Reading Calibration Data 2-48 Using Instrument States 2-52

Setting a List Frequency Sweep 2-56 Selecting a Single Segment 2-61 Setting up Limit Lines 2-65 Performing Pass/Fail Tests 2-69

Report Generation

Operation Using Talker/Listener Mode 2-73 Controlling Peripherals 2-76 Printing Via the Serial Port 2-80 Plotting Data 2-83 Reading Plot Files from Disk 2-86 Reading ASCII Instrument Files 2-94

2-3

Examples

Preparing Measurement Settings

File Name

Description

EXAMP1A.BAS

Use the same command sequence used for manually setting up measurements for remotely setting up measurements via HP-IB. There is no required order, as long as you set the desired frequency range, number of points, and power level prior to performing a measurement calibration.

This example sets the following parameters:

• reflection log magnitude on channel 1

• reflection phase on channel 2

• dual channel display mode

• frequency range from 100 MHz to 500 MHz

The following is the program’s algorithm:

• The system is initialized.

• The analyzer is adjusted to measure return loss on channel 1 and display it in log magnitude.

• The analyzer is adjusted to measure return loss on channel 2 and display the phase.

• The dual-channel display mode is activated.

• The system operator is prompted to enter the frequency range of the measurement.

• The displays are autoscaled.

• The analyzer is released from remote control and the program ends.

This example program initializes the analyzer and the operator is queried for the measurement’s start and stop frequencies. The analyzer is set up to display the S

over the selected frequency range. The displays are autoscaled and the program ends.

2-4

reflection measurement as a function of log magnitude and phase

Examples

Preparing Measurement Settings

10 ! This program selects the S-parameter to be measured, the display 20 ! format and then sets the specified start and stop frequencies. 30 ! The analyzer display is then autoscaled. 40 ! 50 ! EXAMP1A 60 ! 70 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 80 ! 90 CLEAR SCREEN 100 ! Initialize the system 110 ABORT 7 ! Generate an IFC (Interface Clear) 120 CLEAR @Nwa ! SDC (Selected Device Clear) analyzer 130 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 140 ENTER @Nwa;Reply ! Read in the 1 returned 150 ! 160 ! Set up measurement and display 170 OUTPUT @Nwa;”CHAN1;” ! Channel 1 180 OUTPUT @Nwa;”S11;” ! Return Loss measurement 190 OUTPUT @Nwa;”LOGM;” ! Log magnitude display 200 ! 210 OUTPUT @Nwa;”CHAN2;” ! Channel 2 220 OUTPUT @Nwa;”S11;” ! Return Loss measurement 230 OUTPUT @Nwa;”PHAS;” ! Phase display 240 ! 250 OUTPUT @Nwa;”DUACON;” ! Dual channel display 260 ! 270 ! Request start and stop frequency 280 INPUT “ENTER START FREQUENCY (MHz):”,F_start 290 INPUT “ENTER STOP FREQUENCY (MHz):”,F_stop 300 ! 310 ! Program the analyzer settings 320 OUTPUT @Nwa;”STAR”;F_start;”MHZ;” ! Set the start frequency 330 OUTPUT @Nwa;”STOP”;F_stop;”MHZ;” ! Set the stop frequency 340 ! 350 ! Autoscale the displays 360 OUTPUT @Nwa;”CHAN1;AUTO;” ! Autoscale channel 1 display 370 OUTPUT @Nwa;”CHAN2;AUTO;” ! Autoscale channel 2 display 380 ! 390 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 400 ENTER @Nwa;Reply ! Read the 1 when complete 410 LOCAL @Nwa ! Release HP-IB control 420 END

2-5

Examples

Verifying Measurement Settings

File Name

Description

EXAMP1B.BAS

This example shows how to read analyzer settings into your program. Information on the command formats and operations is located in Chapter 1, “Writing Programs”. Appending a question mark (?) to a command that sets an analyzer parameter will return the value of that setting from the analyzer to the controller. Parameters that are set as ON or OFF when queried will return a one (1) if active or a zero (0) if OFF. Parameters are returned in ASCII format, Form 4. This format varies in length from 1 to 24 characters-per-value. In cases of marker or other multiple responses, these values are separated by commas.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The number of points in the trace is queried and printed on the controller display.

• The start frequency is queried and printed on the controller display.

• The averaging function state is queried and printed on the controller display.

• The analyzer is released from remote control and the program ends.

The analyzer is preset. The preset values are returned for the number of points, the start frequency, and the state of the averaging function. The analyzer is released from remote control and the program ends.

2-6

Examples

Verifying Measurement Settings

10 ! This program performs some example queries of analyzer 20 ! settings. The number of points in a trace, the start frequency 30 ! and, if averaging is turned on, are determined and displayed. 40 ! 50 ! EXAMP1B 60 ! 70 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 80 ! 90 CLEAR SCREEN 100 ! Initialize the system 110 ABORT 7 ! Generate an IFC (Interface Clear) 120 CLEAR @Nwa ! SDC (Selected Device Clear) 130 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 140 ENTER @Nwa;Reply ! Read in the 1 returned 150 ! 160 ! Query analyzer parameters 170 OUTPUT @Nwa;”POIN?;” ! Read in the default trace length 180 ENTER @Nwa;Num_points 190 PRINT “Number of points “;Num_points 200 PRINT 210 ! 220 OUTPUT @Nwa;”STAR?;” ! Read in the start frequency 230 ENTER @Nwa;Start_f 240 PRINT “Start Frequency “;Start_f 250 PRINT 260 ! 270 OUTPUT @Nwa;”AVERO?;” ! Averaging on? 280 ENTER @Nwa;Flag 290 PRINT “Flag =”;Flag;” “; 300 IF Flag=1 THEN ! Test flag and print analyzer state 310 PRINT “Averaging ON” 320 ELSE 330 PRINT “Averaging OFF” 340 END IF 350 ! 360 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 370 ENTER @Nwa;Reply ! Read the 1 when complete 380 LOCAL @Nwa ! Release HP-IB control 390 END

2-7

Examples

S11 1-Port Measurement Calibration

File Name

Description

EXAMP2A.BAS

This section shows you how to coordinate a measurement calibration over HP-IB. You can use the following sequence for performing either a manual measurement calibration, or a remote measurement calibration via HP-IB:

Select the calibration type.

Measure the calibration standards.

Declare the calibration done.

The actual sequence depends on the calibration kit and changes slightly for full 2-port measurement calibrations, which are divided into three calibration sub-sequences.

Calibration Kits

The calibration kit tells the analyzer what standards to expect at each step of the calibration. The set of standards associated with a given calibration is termed a “class”. For example, measuring the short during an S

1-port mea-

surement calibration is one calibration step. All of the shorts that can be used for this calibration step make up the class, which is called class S11B. For the 7-mm and 3.5-mm cal kits, class S11B uses only one standard. For Type-N cal kits, class S11B contains two standards: male and female shorts.

When doing an S calibration kit. Selecting

1-port measurement calibration, use a 7-mm or 3.5-mm

SHORT

automatically measures the short because the class contains only one standard. When doing the same calibration in Type-N, selecting

SHORT

brings up a second menu, allowing the operator to select which standard in the class is to be measured. The sex listed refers to the test port. If the test port is female, then the operator selects the female short option.

Doing an S

1-port measurement calibration over HP-IB is very similiar. When

using a 7-mm or 3.5-mm calibration kit, sending CLASS11B will automatically measure the short. In Type-N, sending CLASS11B brings up the menu with the

2-8

Examples

S11 1-Port Measurement Calibration

male and female short options. To select a standard, use STANA or STANB. The STAN command is appended with the letters A through G, corresponding to the standards listed under softkeys 1 through 7, softkey 1 being the topmost softkey.

The STAN command is OPC-compatible. A command that calls a class is only OPC-compatible if that class has only one standard in it. If there is more than one standard in a class, the command that calls the class brings up another menu, and there is no need to query it.

Example

This example shows you how to coordinate an S

1-port measurement cali-

bration over HP-IB, using the HP 85032B 50Ω Type-N calibration kit.

Set up the desired instrument state.

Run the program.

Connect the standards as prompted.

Press

ENTER

on the controller keyboard to measure the standard.

NOTE

Some computers may have a RETURN hardkey as the activating switch for carriage return/line feed. Throughout this section, the carriage-return/line-feed hardkey is represented by ENTER.

Information on selecting calibration standards can be found in Chapter 1, “Writing Programs”.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The appropriate calibration kit is selected.

• The softkey menu is deactivated.

•The S

1-port measurement calibration sequence is run.

1-port measurement calibration data is saved.

• The softkey menu is activated.

• The analyzer is released from remote control and the program ends.

2-9

Examples

S11 1-Port Measurement Calibration

Running the Program

This program assumes the following test port characteristics:

• 50 ohm

• Type-N connectors

•Female

The prompts appear just above the message line on the analyzer’s and the controller’s display. Pressing

ENTER

on the controller continues the program and measures the standard. The program displays a message when the measurement calibration is complete.

2-10

Examples

S11 1-Port Measurement Calibration

10 ! This program performs a 1-port calibration on the HP 8702D. 20 ! It guides the operator through a 1-port calibration 30 ! using the HP 85032B 50 ohm type N calibration kit. 40 ! 50 ! The routine Waitforkey displays a message on the instrument’s 60 ! display and the console, to prompt the operator to connect the 70 ! calibration standard. Once the standard is connected, the 80 ! ENTER key on the computer keyboard is pressed to continue. 90 ! 100 ! EXAMP2A 110 ! 120 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 130 ! 140 CLEAR SCREEN 150 ! Initialize the system 160 ABORT 7 ! Generate an IFC (Interface Clear) 170 CLEAR @Nwa ! SDC (Selected Device Clear) 180 ! 190 OUTPUT @Nwa;”CALKN50;” ! Select CAL kit type 200 OUTPUT @Nwa;”MENUOFF;” ! Turn softkey menu off. 210 ! 220 OUTPUT @Nwa;”CALIS111;” ! S11 1 port CAL initiated 230 ! 240 CALL Waitforkey(“CONNECT OPEN AT PORT 1”) 250 OUTPUT @Nwa;”CLASS11A;” ! Open reflection CAL 260 OUTPUT @Nwa;”OPC?;STANB;” ! Select the second standard, B 270 ENTER @Nwa;Reply ! Read in the 1 returned 280 ! 290 CALL Waitforkey(“CONNECT SHORT AT PORT 1”) 300 OUTPUT @Nwa;”CLASS11B;” ! Short reflection CAL 310 OUTPUT @Nwa;”OPC?;STANB;” ! Select the second standard, B 320 ENTER @Nwa;Reply ! Read in the 1 returned 330 ! 340 CALL Waitforkey(“CONNECT LOAD AT PORT 1”) 350 OUTPUT @Nwa;”OPC?;CLASS11C;” ! Reflection load CAL 360 ENTER @Nwa;Reply ! Read in the 1 returned 370 ! 380 OUTPUT 717;”PG;” ! Clear the analyzer display 390 ! 400 DISP “COMPUTING CALIBRATION COEFFICIENTS” 410 ! 420 OUTPUT @Nwa;”DONE;” ! Finished with the CAL cycle 430 OUTPUT @Nwa;”OPC?;SAV1;” ! Save the ONE PORT CAL 440 ENTER @Nwa;Reply ! Read in the 1 returned 450 ! 460 DISP “S11 1-PORT CAL COMPLETED. CONNECT TEST DEVICE.” 470 OUTPUT @Nwa;”MENUON;” ! Turn on the softkey menu 480 ! 490 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 500 ENTER @Nwa;Reply ! Read the 1 when complete 510 LOCAL @Nwa ! Release HP-IB control 520 ! 530 END 540 ! 550 ! **************************** Subroutines ****************************** 560 !

2-11

Examples

S11 1-Port Measurement Calibration

570 Waitforkey: ! Prompt routine to read a keypress on the controller 580 SUB Waitforkey(Lab$) 590 ! Position and display text on the analyzer display 600 OUTPUT 717;”PG;PU;PA390,3700;PD;LB”;Lab$;”, PRESS ENTER WHEN READY_;” 610 ! 620 DISP Lab$&” Press ENTER when ready”; ! Display prompt on console 630 INPUT A$ ! Read ENTER key press 640 ! 650 OUTPUT 717;”PG;” ! Clear analyzer display 660 SUBEND

2-12

Full 2-Port Measurement Calibration

Examples

File Name

Description

EXAMP2B.BAS

The following example shows how to perform a full 2-port measurement calibration using the HP 85032B calibration kit. The main difference between this example and the S

2-port measurement calibration process allows removal of both the forwardand reverse-error terms, so that all four S-parameters of the device under test can be measured. PORT 1 is a female test port and PORT 2 is a male test port.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The appropriate calibration kit is selected.

• The softkey menu is deactivated.

• The 2-port calibration sequence is run.

• The operator is prompted to choose or skip the isolation calibration.

• The softkey menu is activated.

• The analyzer is released from remote control and the program ends.

Running the Program

The program assumes the following situation:

• test ports are Type-N

1-Port Measurement Calibration example is that the full

• PORT 1 is a female test port

• PORT 2 is a male test port

• HP 85032B 50Ω Type-N calibration kit is used

The prompts appear just above the message line on the analyzer’s display, as well as the computer’s console. Pressing tinues the program and measures the standard. You have the option of omitting the isolation portion of the measurement calibration. If you perform the

ENTER

on the computer keyboard con-

2-13

Examples

Full 2-Port Measurement Calibration

isolation portion of the calibration, averaging is automatically employed to insure a valid calibration. The program will display a message when the measurement calibration is complete.

2-14

Examples

Full 2-Port Measurement Calibration

10 ! This program performs a full 2-port measurement calibration. 20 ! It guides the operator through a full 2-port calibration 30 ! using the HP 85032B 50 ohm type N calibration kit. 40 ! The routine Waitforkey displays a message on the instrument’s 50 ! display and the console to prompt the operator to connect the 60 ! calibration standard. Once the standard is connected, the 70 ! ENTER key on the computer keyboard is pressed to continue. 80 ! 90 ! EXAMP2B 100 ! 110 ASSIGN @Nwa TO 716 ! Assign an I/O path to the analyzer 120 ! 130 CLEAR SCREEN 140 ! Initialize the analyzer 150 ABORT 7 ! Generate an IFC (Interface Clear) 160 CLEAR @Nwa ! SDC (Selected Device Clear) 170 ! 180 OUTPUT @Nwa;”CALKN50;MENUOFF;” ! Select CAL kit type and turn off menu 190 ! 200 OUTPUT @Nwa;”CALIFUL2;” ! Full 2 port CAL 210 ! 220 OUTPUT @Nwa;”REFL;” ! Reflection CAL 230 ! 240 CALL Waitforkey(“CONNECT OPEN AT PORT 1”) 250 OUTPUT @Nwa;”CLASS11A;” ! S11 open CAL 260 OUTPUT @Nwa;”OPC?;STANB;” ! Select the second standard, B 270 ENTER @Nwa;Reply ! Read in the 1 returned 280 ! 290 CALL Waitforkey(“CONNECT SHORT AT PORT 1”) 300 OUTPUT @Nwa;”CLASS11B;” ! S11 short CAL 310 OUTPUT @Nwa;”OPC?;STANB;” ! Select the second standard, B 320 ENTER @Nwa;Reply ! Read in the 1 returned 330 ! 340 CALL Waitforkey(“CONNECT LOAD AT PORT 1”) 350 OUTPUT @Nwa;”OPC?;CLASS11C;” ! S11 load CAL 360 ENTER @Nwa;Reply ! Read in the 1 returned 370 ! 380 CALL Waitforkey(“CONNECT OPEN AT PORT 2”) 390 OUTPUT @Nwa;”CLASS22A;” ! S22 open CAL 400 OUTPUT @Nwa;”OPC?;STANA;” ! Select the first standard, A 410 ENTER @Nwa;Reply ! Read in the 1 returned 420 ! 430 CALL Waitforkey(“CONNECT SHORT AT PORT 2”) 440 OUTPUT @Nwa;”CLASS22B;” ! S22 short CAL 450 OUTPUT @Nwa;”OPC?;STANA;” ! Select the first standard, A 460 ENTER @Nwa;Reply ! Read in the 1 returned 470 ! 480 CALL Waitforkey(“CONNECT LOAD AT PORT 2”) 490 OUTPUT @Nwa;”OPC?;CLASS22C;” ! S22 load CAL 500 ENTER @Nwa;Reply 510 ! 520 DISP “COMPUTING REFLECTION CALIBRATION COEFFICIENTS” 530 ! 540 OUTPUT @Nwa;”REFD;” ! Reflection portion complete 550 ! 560 OUTPUT @Nwa;”TRAN;” ! Transmission portion begins

2-15

Examples

Full 2-Port Measurement Calibration

570 ! 580 CALL Waitforkey(“CONNECT THRU [PORT1 TO PORT 2]”) 590 DISP “MEASURING FORWARD TRANSMISSION” 600 OUTPUT @Nwa;”OPC?;FWDT;” ! Measure forward transmission 610 ENTER @Nwa;Reply ! Read in the 1 returned 620 ! 630 OUTPUT @Nwa;”OPC?;FWDM;” ! Measure forward load match 640 ENTER @Nwa;Reply ! Read in the 1 returned 650 ! 660 DISP “MEASURING REVERSE TRANSMISSION” 670 OUTPUT @Nwa;”OPC?;REVT;” ! Measure reverse transmission 680 ENTER @Nwa;Reply ! Read in the 1 returned 690 ! 700 OUTPUT @Nwa;”OPC?;REVM;” ! Measure reverse load match 710 ENTER @Nwa;Reply ! Read in the 1 returned 720 ! 730 OUTPUT @Nwa;”TRAD;” ! Transmission CAL complete 740 ! 750 INPUT “SKIP ISOLATION CAL? Y OR N.”,An$ 760 IF An$=”Y” THEN 770 OUTPUT @Nwa;”OMII;” ! Skip isolation cal 780 GOTO 940 790 END IF 800 ! 810 CALL Waitforkey(“ISOLATE TEST PORTS”) 820 ! 830 OUTPUT @Nwa;”ISOL;” ! Isolation CAL 840 OUTPUT @Nwa;”AVERFACT10;” ! Average for 10 sweeps 850 OUTPUT @Nwa;”AVEROON;” ! Turn on averaging 860 DISP “MEASURING REVERSE ISOLATION” 870 OUTPUT @Nwa;”OPC?;REVI;” ! Measure reverse isolation 880 ENTER @Nwa;Reply ! Read in the 1 returned 890 ! 900 DISP “MEASURING FORWARD ISOLATION” 910 OUTPUT @Nwa;”OPC?;FWDI;” ! Measure forward isolation 920 ENTER @Nwa;Reply ! Read in the 1 returned 930 ! 940 OUTPUT @Nwa;”ISOD;AVEROOFF;” ! Isolation complete averaging off 950 OUTPUT 717;”PG;” ! Clear analyzer display prompt 960 ! 970 DISP “COMPUTING CALIBRATION COEFFICIENTS” 980 OUTPUT @Nwa;”DONE;” ! End the CAL sequence 990 OUTPUT @Nwa;”OPC?;SAV2;” ! Save THE TWO PORT CAL 1000 ENTER @Nwa;Reply ! Read in the 1 returned 1010! 1020 DISP “DONE WITH FULL 2-PORT CAL. CONNECT TEST DEVICE.” 1030 OUTPUT @Nwa;”MENUON;” ! Turn softkey menu on 1040 ! 1050 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 1060 ENTER @Nwa;Reply ! Read the 1 when complete 1070 LOCAL @Nwa ! Release HP-IB control 1080! 1090 END 1100! 1110! ************************* Subroutines ******************************* 1120!

2-16

Examples

Full 2-Port Measurement Calibration

1130 SUB Waitforkey(Lab$) 1140 ! Position and display prompt on the analyzer display 1150 OUTPUT 717;”PG;PU;PA390,3700;PD;LB”;Lab$;”, PRESS ANY KEY WHEN READY_;” 1160 ! 1170 DISP Lab$&” Press ENTER when ready”; ! Display prompt on console 1180 INPUT A$ ! Read ENTER keypress on controller 1190 OUTPUT 717;”PG;” ! Clear analyzer display 1200 SUBEND

2-17

Examples

Data Transfer Using Markers

File Name

Description

EXAMP3A.BAS

There are two methods that can be used to read trace information from the analyzer:

• selectively, using the trace markers

• completely, using the trace-data array

If only specific information (such as a single point on the trace or the result of a marker search) is required, the marker output command can be used to read the information.

Trace-Data Formats and Transfers

Refer to Table 1-5, “HP 8702D/Option 011 Array-Data Formats,” on page 1-19. This table shows the number of bytes required to transfer a 201-point trace in the different formats. As you will see in the first example Form 4, ASCII data is the easiest to transfer, but the most time consuming due to the number of bytes in the trace. If you are using a PC-based controller, a more suitable format would be Form 5. To use any trace data format other than Form 4 (ASCII data) requires some care in transferring the data to the computer. Data types must be matched to read the bytes from the analyzer directly in to the variable array. The computer must be told to stop formatting the incoming data and treat it as a binary-data transfer. All of the other data formats also have a four byte header to deal with. The first two bytes are the ASCII characters that indicate that a fixed length block transfer follows, and the next two bytes form an integer containing the number of bytes in the block to follow. The header must be read in to separate the header from the rest of the block data to be mapped into an array. “Array-data formats” on page 1-18, discusses the different types of formats and their compositions.

Data may also be transferred from several different locations in the trace-processing chain. These examples will illustrate formatted-data transfers, but other locations in the trace-data processing chains may be accessed. Refer to Figure 5-1 on page 5-5.

"#A"

2-18

Examples

Data Transfer Using Markers

In this section, an example of each of the data formats will be shown for comparison. A general rule of thumb is to use Form 1 (internal binary format) for traces that are not being utilized for data content. Learn strings, state transfers, and calibration data that are being transferred to a file and back are good examples. Refer to “Data Transfer Using Frequency-Array Information” on page 2-28.

Arrays which will be interpreted or processed within your program should be in Form 2, 3 or 5, whichever is appropriate for your computer. “Data Transfer Using Floating-Point Numbers” on page 2-25 shows how to transfer a trace in these formats.

In “Data Transfer Using ASCII Format” on page 2-22 and “Data Transfer Using Floating-Point Numbers” on page 2-25, the frequency counterpart of each data point in the array is also determined. Many applications generate a frequency and magnitude, or a phase array for the test results. Such data may be required for other data processing applications (such as comparing data from other measurements).

In “Data Transfer Using ASCII Format” on page 2-22, the frequency data is constructed from the frequency span information. Alternatively, it is possible to read the frequencies directly out of the instrument with the command.

OUTPLIML

reports the limit-test results by transmitting the stimu-

OUTPLIML

lus point tested, a number indicating the limit-test results, and then the upper and lower limits at that stimulus point (if available). The number indicating the limit results is a –1 for no test, 0 for fail, and 1 for pass. If there are no limits available, the analyzer transmits zeros. For this example, we delete the limit test information and keep the stimulus information.

In “Data Transfer Using Floating-Point Numbers” on page 2-25, the limit-test array is read into the controller and used to provide the values directly from the analyzer memory. Reading from the limit-test array is convenient, although it outputs the results in ASCII format (Form 4), which may be slow. If there is no other way to obtain the frequency data, this transfer time may be acceptable. Frequency information becomes more difficult to determine when not using the linear sweep mode. Log-frequency sweeps and list-frequency sweeps have quite different values for each data point. For these special cases, the additional time spent reading out the limit test results is an acceptable solution for obtaining the valid frequency information for each data point in the trace.

2-19

Examples

Data Transfer Using Markers

Example

Markers are the simplest form of trace-data transfer. You can position a marker in the following locations on the trace:

• a frequency location

• an actual data point location

• a trace data value

The marker data is always returned in Form 4, ASCII format. Each number is sent as a 24-character string; each character being a digit, sign, or decimal point. In the case of markers, three numbers are sent. The display format determines the values of the marker responses. Refer to Figure 5-1 on page 5-5 for additional information.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The selected frequency span is swept once.

• The marker is activated and placed on the maximum trace value.

• The three marker values (value 1, value 2, and stimulus) are output to the controller and displayed.

• The instrument is returned to local control and the program ends.

Running the Program

Execute the program. After performing an instrument preset, the analyzer switches into the log-magnitude mode and measures the S

reflection values

of the device under test.

The three values returned to the controller are:

reflection, in dB

a non-significant value

the stimulus frequency at the maximum point

A non-significant value means that the analyzer returned a value that is meaningless in this data format.

Table 5-2 on page 5-6, provides an easy reference for the types of data returned with the various data-format operational modes.

2-20

Examples

Data Transfer Using Markers

10 ! This program takes a sweep on the analyzer and turns on a marker. 20 ! The marker is positioned on the trace maximum and the marker data 30 ! is output in ASCII format. 40 ! 50 ! EXAMP3A 60 ! 70 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 80 ! 90 CLEAR SCREEN 100 ! Initialize the analyzer 110 ABORT 7 ! Generate an IFC (Interface Clear) 120 CLEAR @Nwa ! SDC (Selective Device Clear) 130 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 140 ENTER @Nwa;Reply ! Read in the 1 returned 150 ! 160 OUTPUT @Nwa;”OPC?;SING” ! Single sweep mode and wait 170 ENTER @Nwa;Reply ! Read 1 when sweep complete 180 ! 190 OUTPUT @Nwa;”MARK1;” ! Turn on marker 1 200 OUTPUT @Nwa;”SEAMAX;” ! Find the maximum 210 ! 220 OUTPUT @Nwa;”OUTPMARK;” ! Request the current marker value 230 ENTER @Nwa;Value1,Value2,Stim ! Read three marker values 240 ! 250 ! Show the marker data received. 260 PRINT “ Value 1”,” Value 2”,” Stimulus (Hz)” 270 PRINT Value1,Value2,Stim ! Print the received values 280 PRINT 290 PRINT “ Compare the active marker block with the received values” 300 ! 310 LOCAL @Nwa ! Release HP-IB control 320 END

2-21

Examples

Data Transfer Using ASCII Format

File Name

Description

EXAMP3B.BAS

This example shows you how to transfer a trace array from the analyzer using Form 4, an ASCII data transfer.

Table 5-2 on page 5-6 shows the relationship of the two values-per-point that are transferred to the analyzer. When Form 4 is used, each number is sent as a 24-character string (each character represented by a digit, sign, or decimal point). Since there are two numbers-per-point, plus a comma and line-feed, a 201-point transfer in Form 4 takes 10,050 bytes. This form is useful only when input-data formatting is difficult with the instrument controller. Refer to Table 1-5, “HP 8702D/Option 011 Array-Data Formats,” on page 1-19 for a comparison with the other formats.

Another example is included with the ASCII data transfer. A fairly common requirement is to create frequency-amplitude data pairs from the trace data. No frequency information is included with the trace-data transfer. Relating the data from a linear frequency sweep to frequency can be done by interrogating the analyzer start frequency, the frequency span, and the number of points. Given that information, the frequency of point n in a linear frequency sweep is defined by the equation:

F=Start frequency + (n–1) × Span/(Points–1)

This example illustrates the technique of generating corresponding frequency data. This is a straight-forward solution for linear uniform sweeps. For other sweep types, frequency data is more difficult to construct and may be best read from the analyzer directly from the limit-test array. See “Data Transfer Using Frequency-Array Information” on page 2-28 for an example of this technique.

2-22

Examples

Data Transfer Using ASCII Format

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The trace-data array is allocated.

• The trace length is set to 11.

• The selected frequency span is swept once.

• The Form 4, ASCII format is set.

• The formatted trace is read from the analyzer.

• The frequency increments between the points are calculated.

• The marker is activated and placed at 30 kHz.

• The instrument is returned to local control and the program ends.

Running the Program

Run the program and watch the controller console. The analyzer will perform an instrument preset. The program will then print out the data values received from the analyzer. The marker is activated and placed at the left-hand edge of the analyzer display. Position the marker with the knob and compare the values read with the active marker with the results printed on the controller console. The data points should agree exactly. Keep in mind that no matter how many digits are displayed, the analyzer is specified to measure:

• magnitude to a resolution of 0.001 dB

• phase to a resolution of 0.01 degrees

• group delay to a resolution of 0.01 ps

Changing the display format will change the data sent with the

OUTPFORM

transfer. See Table 1-5, “HP 8702D/Option 011 Array-Data Formats,” on page 1-19 for a list of the specific data that is provided with each format. The data

OUTPFORM

from

reflects all the post processing such as:

• time domain

• gating

• electrical delay

• trace math

• smoothing

NOTE

Note that if time domain (option 110 only) is deactivated, operation is limited to 201 points in the lowpass mode.

2-23

Examples

Data Transfer Using ASCII Format

10 ! This program shows an ASCII format trace data transfer using form 4. 20 ! The data is received as a string of ASCII characters, 24 characters 30 ! per data point and transferred into a real array in the controller. The 40 ! corresponding frequency data is calculated from the analyzer settings. 50 ! 60 ! EXAMP3B 70 ! 80 ASSIGN @Nwa TO 716 ! Assign an I/O path to the analyzer 90 ! 100 CLEAR SCREEN 110 ! Initialize 120 ABORT 7 ! Generate an IFC (Interface Clear) 130 CLEAR @Nwa ! SDC (Selective Device Clear) 140 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer 150 ENTER @Nwa;Reply ! Read the 1 when complete 160 ! 170 ! Trace values are two elements per point, display format dependent 180 DIM Dat(1:11,1:2) ! Trace data array 190 ! 200 OUTPUT @Nwa;”POIN 11;” ! Set trace length to 11 points 210 OUTPUT @Nwa;”OPC?;SING;” ! Single sweep mode and wait 220 ENTER @Nwa;Reply ! Read reply 230 ! 240 OUTPUT @Nwa;”FORM4;” ! Set form 4 ASCII format 250 OUTPUT @Nwa;”OUTPFORM;” ! Send formatted trace to controller 260 ENTER @Nwa;Dat(*) ! Read in data array from analyzer 270 ! 280 ! Now to calculate the frequency increments between points 290 OUTPUT @Nwa;”POIN?;” ! Read number of points in the trace 300 ENTER @Nwa;Num_points 310 OUTPUT @Nwa;”STAR?;” ! Read the start frequency 320 ENTER @Nwa;Startf 330 OUTPUT @Nwa;”SPAN?;” ! Read the span 340 ENTER @Nwa;Span 350 ! 360 F_inc=Span/(Num_points-1) ! Calculate fixed frequency increment 370 ! 380 PRINT “Point”,”Freq (MHz)”,” Value 1”,” Value 2” 390 IMAGE 3D,7X,5D.3D,3X,3D.4D,3X,3D.4D ! Formatting for controller display 400 ! 410 FOR I=1 TO Num_points ! Loop through data points 420 Freq=Startf+(I-1)*F_inc ! Calculate frequency of data point 430 PRINT USING 390;I,Freq/1.E+6,Dat(I,1),Dat(I,2)! Print analyzer data 440 NEXT I 450 ! 460 OUTPUT @Nwa;”MARKDISC;” ! Discrete marker mode 470 OUTPUT @Nwa;”MARK1 3E+4;” ! Position marker at 30 KHz 480 ! 490 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 500 ENTER @Nwa;Reply ! Read the 1 when complete 510 LOCAL 7 ! Release HP-IB control 520 ! 530 PRINT 540 PRINT “Position the marker with the knob and compare the values” 550 ! 560 END

2-24

Data Transfer Using Floating-Point Numbers

Examples

File Name

Description

EXAMP3C.BAS

This example program illustrates data transfer using Form 3 in which data is transmitted in the floating-point formats. Form 2 is nearly identical except for the IEEE 32-bit format of 4 bytes-per-value. Form 5 reverses the order of the bytes to conform with the PC conventions for defining a real number.

The block-data formats have a four-byte header. The first two bytes are the ASCII characters and the next two bytes form an integer containing the number of bytes in the block to follow. The header must be read in so that data order is maintained.

This transfer is more than twice as fast than a Form 4 transfer. With the Form 4 transfer, 10,050 bytes are sent (201 points × 2 values-per-point × 24 bytes-per-value). Using Form 2 to transfer the data, only 1612 bytes are sent (201 points × 2 values-per-point × 4 bytes-per-value). Refer to Table 1-5, “HP 8702D/Option 011 Array-Data Formats,” on page 1-19 to compare the formats.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The integer variables are defined to contain the header information.

• The number of points in the trace is set to 11.

• The selected frequency span is swept once.

• Data-transfer format 3 is set.

• The headers are read from the trace.

• The array size is calculated and allocated.

• The trace data is read in and printed on the controller display.

• The marker is activated and placed at 30 kHz.

• The instrument is returned to local control and the program ends.

that indicate that a fixed-length block transfer follows,

2-25

Examples

Data Transfer Using Floating-Point Numbers

Running the Program

Run the program. The computer displays the number of elements and bytes associated with the transfer of the trace, as well as the first 10 data points. Position the marker and examine the data values. Compare the received values with the analyzer’s marker values.

2-26

Examples

Data Transfer Using Floating-Point Numbers

10 ! This program shows how to read in a data trace in IEEE 64 bit 20 ! format. The array header is used to determine the length of the 30 ! array and to allocate the array size. 40 ! 50 ! EXAMP3C 60 ! 70 CLEAR SCREEN 80 ! Initialize the analyzer 90 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 100 ASSIGN @Nwadat TO 716;FORMAT OFF ! Binary data path definition 110 ! 120 ABORT 7 ! Generate an IFC (Interface Clear) 130 CLEAR @Nwa ! SDC (Selected Device Clear) 140 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 150 ENTER @Nwa;Reply ! Read the 1 when completed 160 ! 170 INTEGER Dheader,Dlength ! Integer variables for header info 180 Numpoints=11 ! Number of points in the trace 190 OUTPUT @Nwa;”POIN”;Numpoints;”;” ! Set number of points in trace 200 ! 210 ! Set up data transfer 220 OUTPUT @Nwa;”OPC?;SING” ! Single sweep and wait 230 ENTER @Nwa;Reply ! Read the 1 when completed 240 ! 250 OUTPUT @Nwa;”FORM3;” ! Select form 3 format 260 OUTPUT @Nwa;”OUTPFORM;” ! Send formatted output trace 270 ! 280 ENTER @Nwadat;Dheader,Dlength ! Read headers from trace data 290 ! 300 ALLOCATE Dat(1:Dlength/16,1:2) ! Use length to determine array size 310 ENTER @Nwadat;Dat(*) ! Read in trace data 320 ! 330 PRINT “Size of array “;Dlength/16;” elements” 340 PRINT “Number of bytes “;Dlength 350 ! 360 ! Print out the data array 370 PRINT “Element”,”Value 1”,” Value 2” 380 IMAGE 3D,6X,3D.4D,6X,3D.4D 390 FOR I=1 TO Numpoints ! Loop through the data points 400 PRINT USING 380;I,Dat(I,1),Dat(I,2) 410 NEXT I 420 ! 430 OUTPUT @Nwa;”MARKDISC;” ! Discrete marker mode 440 OUTPUT @Nwa;”MARK1 3E+4;” ! Position marker at 30 KHz 450 ! 460 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 470 ENTER @Nwa;Reply ! Read the 1 when complete 480 LOCAL @Nwa ! Release HP-IB control 490 ! 500 PRINT 510 PRINT “Position the marker with the knob and compare the values.” 520 ! 530 END

2-27

Examples

Data Transfer Using Frequency-Array Information

File Name

Description

EXAMP3D.BAS

This example explains how to use the limit-test array to read the corresponding frequency values for the completed trace array into the controller. The analyzer is set to sweep from 10 MHz to 200 MHz in log-frequency mode with the number of points in the trace set to 11. This makes it very difficult to compute the frequency-point spacing in the trace. The points are equally spaced across the trace, but not equally spaced in relation to frequency (because the frequency span is displayed in a logarithmic scale, as opposed to a linear scale). The limit-test data array may be read from the analyzer to provide the frequency values for each data point. Four values are read for each data point on the analyzer. The test results and limit values are not used in this example, only the frequency values are used. This technique is the only method of obtaining the non-linear frequency data from the analyzer display. The test data and frequencies are printed on the controller display and the marker is enabled to allow the operator to examine the actual locations on the analyzer display.

2-28

Data Transfer Using Frequency-Array Information

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The integer variables for the header information are defined.

• The number of points in the trace is set to 11.

• The frequency span (10 MHz to 200 MHz) is selected.

• The log-frequency sweep is selected.

• The data-transfer format 3 is set.

• The headers are read from the trace.

• The array size is calculated and allocated.

• The trace data is read in.

• The limit-test array is calculated and allocated.

• The limit-line test array is read in.

• The table header is printed.

• The program cycles through the trace values.

• The trace data and frequency are printed.

• The discrete-marker mode is activated.

• The marker is activated and placed at 10 MHz.

• The instrument is returned to local control and the program ends.

Running the Program

Run the program. Observe the controller display. The corresponding frequency values are shown with the trace-data values. Position the marker and observe the relationship between the frequency values and the point spacing on the trace. Compare the trace-data values on the analyzer with those received by the controller.

Examples

2-29

Examples

Data Transfer Using Frequency-Array Information

10 ! This program shows how to read in a trace and create the frequency 20 ! value associated with the trace data value. EXAMP3C is used to 30 ! read in the data from the analyzer. The start and stop 40 ! frequencies are set to provide two decades of log range. Log sweep 50 ! is set and the frequency data points are read from the limit test 60 ! array and displayed with the data points. 70 ! 80 ! EXAMP3D 90 ! 100 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 110 ASSIGN @Nwadat TO 716;FORMAT OFF ! Binary path for data transfer 120 ! 130 CLEAR SCREEN 140 ! Initialize the analyzer 150 ABORT 7 ! Generate an IFC (Interface Clear) 160 CLEAR @Nwa ! SDC (Selective Device Clear) 170 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 180 ENTER @Nwa;Reply ! Read the 1 when completed 190 ! 200 INTEGER Dheader,Dlength ! Integer variables for header info 210 ! 220 OUTPUT @Nwa;”POIN 11;” ! Set trace length to 11 points 230 OUTPUT @Nwa;”STAR 10.E+6;” ! Start frequency 10 MHz 240 OUTPUT @Nwa;”STOP 200.E+6;” ! Stop frequency 200 MHz 250 OUTPUT @Nwa;”LOGFREQ;” ! Set log frequency sweep 260 ! 270 ! Set up data transfer 280 OUTPUT @Nwa;”OPC?;SING” ! Single sweep and wait 290 ENTER @Nwa;Reply ! Read the 1 when completed 300 ! 310 OUTPUT @Nwa;”FORM3;” ! Select form 3 trace format 320 OUTPUT @Nwa;”OUTPFORM;” ! Output formatted trace 330 ! 340 ENTER @Nwadat;Dheader,Dlength ! Read headers from trace data 350 ! 360 ALLOCATE Dat(1:Dlength/16,1:2) ! Use length to determine array size 370 ENTER @Nwadat;Dat(*) ! Read in trace data 380 ! 390 ! Create the corresponding frequency values for the array 400 ! 410 ! Read the frequency values using the limit test array 420 ALLOCATE Freq(1:Dlength/16,1:4) ! Limit line results array 430 ! Limit line values are frequency, test results, upper and lower limits 440 ! 450 OUTPUT @Nwa;”OUTPLIML;” ! Request limit line test results 460 ENTER @Nwa;Freq(*) ! Read 4 values per point 470 ! 480 ! Display table of freq and data 490 ! 500 PRINT “ Freq (MHz)”,”Mag (dB)” ! Print table header 510 FOR I=1 TO 11 ! Cycle through the trace values 520 Freqm=Freq(I,1)/1.E+6 ! Convert frequency to MHz 530 PRINT USING “4D.6D,9X,3D.4D”;Freqm,Dat(I,1) ! Print trace data 540 NEXT I 550 ! 560 ! Set up marker to examine frequency values

2-30

Examples

Data Transfer Using Frequency-Array Information

570 OUTPUT @Nwa;”MARKDISC;” ! Discrete marker mode 580 OUTPUT @Nwa;”MARK1 10.E+6;” ! Turn on marker and place at 10 MHz 590 ! 600 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 610 ENTER @Nwa;Reply ! Read the 1 when complete 620 LOCAL @Nwa ! Release HP-IB control 630 PRINT ! Blank line 640 PRINT “Position marker and observe frequency point spacing” 650 ! 660 END

2-31

Examples

Data Transfer Using Internal Binary Format

File Name

Description

EXAMP3E.BAS

Form 1 is used for rapid I/O transfer of analyzer data. It contains the least number of bytes-per-trace and does not require reformatting in the analyzer. This format is more difficult to convert into a numeric array in the controller. Analyzer-state information, such as learn strings and calibration arrays, may be easily transferred in this format because data conversion is not required. Recalling an instrument state that has been stored in a file and transferring instrument-state information to the analyzer are excellent applications of a Form 1 data transfer.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The integer variables for the header information are defined.

• The string variable for the header is defined.

• The selected frequency span is swept once.

• The internal-binary format is selected.

• The error-corrected data is output from the analyzer.

• The two data-header characters and the two length bytes are read in.

• The string buffer is allocated for data.

• The trace data is read into the string buffer.

• The analyzer is restored to continuous-sweep mode and queried for command completion.

• The instrument is returned to local control and the program ends.

Running the Program

Run the program. The analyzer is initialized. The header and the number of bytes in the block transfer are printed on the controller display. Once the transfer is complete, the number of bytes in the data string is printed. Compare the two numbers to be sure that the transfer was completed.

2-32

Examples

Data Transfer Using Internal Binary Format

10 ! This program is an example of a form 1, internal format data 20 ! transfer. The data is stored in a string dimensioned to the 30 ! length of the data being transferred. 40 ! 50 ! EXAMP3E 60 ! 70 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 80 ASSIGN @Nwa_bin TO 716;FORMAT OFF ! Binary path for data transfer 90 ! 100 CLEAR SCREEN 110 ! Initialize the analyzer 120 ABORT 7 ! Send IFC (Interface Clear) 130 CLEAR @Nwa ! SDC (Selective Device Clear) 140 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 150 ENTER @Nwa;Reply ! Read the 1 when completed 160 ! 170 INTEGER Length ! Header length 2 bytes 180 DIM Header$[2] ! Header string 2 bytes 190 ! 200 OUTPUT @Nwa;”OPC?;SING;” ! Single sweep and wait 210 ENTER @Nwa;Reply ! Read the 1 when completed 220 ! 230 OUTPUT @Nwa;”FORM1;” ! Select internal binary format 240 OUTPUT @Nwa;”OUTPDATA;” ! Output error corrected data 250 ! 260 ! Read in the data header two characters and two bytes for length 270 ! “#,2A” 280 ! # no early termination, terminate when ENTER is complete 290 ! 2A read two chars 300 ! 310 ENTER @Nwa_bin USING “#,2A”;Header$ ! Read header as 2 byte string 320 ENTER @Nwa_bin;Length ! Read length as 2 byte integer 330 PRINT “Header “;Header$,”Array length”;Length 340 ! 350 ALLOCATE Data$[Length] ! String buffer for data bytes 360 ! “+,-K” format statement 370 ! + EOI as a terminator LF is suppressed and read as data 380 ! -K All characters are read and not interpreted LF is included 390 ENTER @Nwa_bin USING “+,-K”;Data$ ! Read trace into string array 400 ! 410 PRINT “Number of bytes received “;LEN(Data$) 420 ! 430 OUTPUT @Nwa;”CONT;” ! Restore continuous sweep 440 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 450 ENTER @Nwa;Reply ! Read the 1 when complete 460 ! 470 LOCAL @Nwa ! Release HP-IB control 480 END

2-33

Examples

Using Error Queue

File Name

Description

EXAMP4A.BAS

The error queue holds up to 20 instrument errors and warnings in the order that they occurred. Each time the analyzer detects an error condition, the analyzer displays a message on the analyzer’s display, and puts the error in the error queue. If there are any errors in the queue, bit 3 of the status byte will be set. The errors can be read from the queue with the

OUTPERRO

the oldest error in the queue.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The error-message string is allocated.

• The analyzer is released from remote control.

• The program begins an endless loop to read the error queue.

• The status byte is read with a serial poll.

• The program tests to see if an error is present in the queue.

• The error-queue bit is set.

• The program requests the contents of the error queue.

• The error number and string are read.

• The error messages are printed until there are no more errors in the queue.

• The instrument is returned to local control.

• The controller emits a beep to attract the attention of the operator and resumes searching for errors.

causes the analyzer to transmit the error number and message of

OUTPERRO

command.

Running the Program

Run the program. The analyzer goes through the preset cycle. Nothing will happen at first. The program is waiting for an error condition to activate the error queue. To cause an error, press a blank softkey. The message

INVALID KEY

and print two error messages. The first line will be the invalid key error message, and the second line will be the queue, you can either loop until the

2-34

will appear on the analyzer’s display. The computer will beep

NO ERRORS

message. To clear the error

message is received, or until

CAUTION:

Examples

Using Error Queue

the bit in the status register is cleared. In this case, we wait until the status bit in the status register is clear. Note that while the program is running, the analyzer remains in the local mode and the front-panel keys may be accessed.

The error queue will hold up to 20 errors until all the errors are read out or the instrument is preset. It is important to clear the error queue whenever errors are detected. Otherwise, old errors may be mistakenly associated with the current instrument state.

SYSTEM

Press

and then the unlabeled key several times quickly and watch the display. The number of errors observed should correspond to the number of times you pressed the key.

As another example, press

RESPONSE

calibration. Press

CAL,

then the

DONE: RESPONSE

CALIBRATE MENU

key. Select the

without performing any calibrations. Note the error message on the analyzer and on the controller display. Push the

THRU

key and then

DONE: RESPONSE

. We are not concerned with the validity of the calibration, just setting a simple calibration on the analyzer. Note that press

COR

is displayed in the upper left-hand section of the graticule. Now,

START

and ↑. This will generate an error because the start frequency has been changed, invalidating the calibration. This error is reported on the controller display as well. A complete list of error messages and their descriptions can be found in "Error Messages" in the

HP 8702D Reference

manual.

The program is in an infinite loop waiting for errors to occur. End the program by pressing

RESET

BREAK

on the controller keyboard.

NOTE

Not all messages displayed by the analyzer are put in the error queue; operator prompts and cautions are not included.

2-35

Examples

Using Error Queue

10 ! This program is an example of using the error queue to detect 20 ! errors generated by the analyzer. The status byte is read and 30 ! bit 3 is tested to determine if an error exists. The error queue 40 ! is printed out and emptied. 50 ! 60 ! EXAMP4A 70 ! 80 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 90 ! 100 CLEAR SCREEN 110 ! Initialize the analyzer 120 ABORT 7 ! Generate an IFC (Interface Clear) 130 CLEAR @Nwa ! SDC (Selective Device Clear) 140 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 150 ENTER @Nwa;Reply ! Read the 1 when complete 160 ! 170 DIM Error$[50] ! String for analyzer error message 180 ! 190 LOCAL @Nwa ! Release analyzer from remote control 200 ! 210 LOOP ! Endless loop to read error queue 220 REPEAT 230 Stat=SPOLL(@Nwa) ! Read status byte with serial poll 240 UNTIL BIT(Stat,3) ! Test for error queue present 250 ! 260 ! Error queue bit is set 270 REPEAT ! Loop until error number is 0 280 OUTPUT @Nwa;”OUTPERRO;” ! Request error queue contents 290 ENTER @Nwa;Err,Error$ ! Read error number and string 300 PRINT Err,Error$ ! Print error messages 310 UNTIL Err=0 ! No more errors in queue 320 ! 330 LOCAL @Nwa ! Release analyzer from remote 340 BEEP 600,.2 ! Beep to attract attention 350 END LOOP ! Repeat error search 360 ! 370 END

2-36

Generating Interrupts

Examples

Generating Interrupts

File Name

Description

EXAMP4B.BAS

Interrupts can be generated using the status-reporting mechanism. The status-byte bits can be enabled to generate a service request (SRQ) when set. In turn, the instrument controller can be set up to generate an interrupt on the SRQ and respond to the condition which caused the SRQ.

To generate an SRQ, a bit in the status byte is enabled using the mand. A one (1) in a bit position enables that bit in the status byte. Hence,

ESNBn

SRE 8;

;

enables an SRQ on bit 3, the check-error queue, since the

enables bits in event-status-register B so that they will be summa-

ESE 32;SRE 32;

enables the syntax-error bit. When the

executing decimal value 8 equals 00001000 in binary representation. Whenever an error is put into the error queue and bit 3 is set, the SRQ line is asserted, illuminating the (S) indicator in the HP-IB status block on the front panel of the analyzer. The only way to clear the SRQ is to disable bit 3, re-enable bit 3, or read out all the errors from the queue.

A bit in the event-status register can be enabled so that it is summarized by bit 5 of the status byte. If any enabled bit in the event-status register is set, bit 5 of the status byte will also be set. For example, executing enables bits 1 and 6 of the event-status register, since in binary, the decimal number 66 equals 01000010. Hence, whenever active control is requested or a front-panel key is pressed, bit 5 of the status byte will be set. Similarly, executing rized by bit 2 in the status byte.

To generate an SRQ from an event-status register, enable the desired eventstatus-register bit. Then enable the status byte to generate an SRQ. For instance, executing syntax-error bit is set, the summary bit in the status byte will be set. This will, in turn, enable an SRQ on bit 5 of the status byte, the summary bit for the event-status register.

SREn;

ESE 66;

com-

2-37

Examples

Generating Interrupts

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The status registers are cleared.

• The event-status register bit 5 is enabled.

• The status-register bit 5 is enabled.

• The interrupt pointer is enabled and points to a subroutine.

• A bad command is sent to the analyzer to generate errors.

• The controller reads a serial-poll byte from HP-IB in the event of an interrupt.

• The program tests for an SRQ.

• If the SRQ is not generated by the analyzer, the subroutine stops and displays,

SRQ FROM OTHER DEVICE

• If the SRQ was generated by the analyzer, the program reads the status byte and event-status register.

• If bit 5 in the event-status register is set, program prints,

FROM ANALYZER

• If bit 5 in the event-status register is NOT set, program prints,

BIT NOT SET.

SYNTAX ERROR

• The SRQ interrupt is re-enabled on the bus.

• At the finish, the interrupt is deactivated.

• The analyzer is released from remote control and the program ends.

Running the Program

Run the program. The computer will preset the analyzer, then pause for a second or two. After pausing, the program sends an invalid command string,

STIP 2GHZ; 2 GHZ;

, to cause a syntax error. This command is intended to be,

. The computer will display a series of messages from the SRQ-han-

dler routine. The analyzer will display

CAUTION: SYNTAX ERROR

STOP

and the

incorrect command, pointing to the first character it did not understand.

The SRQ can be cleared by reading the event-status register and clearing the latched bit, or by clearing the enable registers with the

CLES;

command. The syntax-error message on the analyzer display can only be cleared by the HP-IB Device Clear (DCL) message or Selected Device Clear (SDC) message. Device Clear is not commonly used because it clears every device on the bus. Selected Device Clear can be used to reset the input and output queue and the registers of a specific instrument on the bus. This will also clear all the interrupt definitions.

2-38

Examples

Generating Interrupts

10 ! This program is an example of using an SRQ based interrupt to 20 ! detect an error condition in the analyzer. In this example, a 30 ! syntax error is generated with an invalid command. The status byte 40 ! is read in and tested. The error queue is read, printed out and 50 ! then cleared. 60 ! 70 ! EXAMP4B 80 ! 90 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 100 ! 110 CLEAR SCREEN 120 ! Initialize the analyzer 130 ABORT 7 ! Generate an IFC (Interface Clear) 140 CLEAR @Nwa ! SDC (Selective Device Clear) 150 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 160 ENTER @Nwa;Reply ! Read the one from the analyzer 170 ! 180 DIM Error$[50] ! String for analyzer error message 190 ! Set up syntax error interrupt 200 OUTPUT @Nwa;”CLES;” ! Clear the status registers 210 ! 220 ! Generate SRQ when bit 5 is set 230 OUTPUT @Nwa;”ESE 32;” ! Event status register bit 5 enabled 240 ! 250 ! Generate bit 5 in status register when syntax error occurs 260 OUTPUT @Nwa;”SRE 32;” ! Status register bit 5 enabled 270 ! 280 ! Setup the interrupt pointer to a subroutine 290 ON INTR 7 GOSUB Srq_det ! When interrupt occurs go to Srq_det 300 Stat=SPOLL(@Nwa) ! Clear any pending SRQs 310 ENABLE INTR 7;2 ! Set interrupt on HP-IB bit 2 (SRQ) 320 ! 330 DISP “Waiting for bad syntax” 340 WAIT 2 ! Pause for 2 seconds 350 ! 360 OUTPUT @Nwa;”STIP 2GHZ;;” ! Send bad STOP command syntax 370 ! 380 WAIT 2 ! Pause for 2 seconds 390 DISP ““ ! Clear display line 400 GOTO Finish ! Exit program example 410 ! 420 !************************** Subroutines ****************************** 430 ! 440 Srq_det: ! SRQ handler 450 Stat=SPOLL(@Nwa) ! Read serial poll byte from HP-IB 460 PRINT “Stat from Serial Poll”;Stat 470 IF BIT(Stat,6) THEN ! Test for SRQ 480 PRINT “SRQ received from analyzer” 490 ELSE ! No SRQ from analyzer 500 PRINT “SRQ from other device” 510 STOP ! Stop if not from analyzer 520 END IF 530 ! 540 IF BIT(Stat,5) THEN ! Event status register bit set 550 PRINT “Event Status Register caused SRQ” 560 ELSE ! Some other bit set

2-39

Examples

Generating Interrupts

570 PRINT “Some other bit caused the SRQ” 580 STOP ! Stop if bit not set 590 END IF 600 ! 610 REPEAT 620 OUTPUT @Nwa;”OUTPERRO;” ! Read analyzer error queue 630 ENTER @Nwa;Err,Error$ ! Read error number and string 640 PRINT Err,Error$ ! Print error message 650 UNTIL Err=0 ! No more errors in queue 660 ! 670 PRINT ! White space 680 ENABLE INTR 7;2 ! Re-enable SRQ interrupt on HP-IB 690 RETURN 700 ! 710 !************************** End Subroutines ****************************** 720 ! 730 Finish: ! End of program and exit 740 DISP “Finished” 750 OFF INTR 7 ! Turn off interrupt 760 LOCAL @Nwa ! Release HP-IB control 770 END

2-40

Power Meter Calibration

Examples

Power Meter Calibration

File Name

Description

EXAMP4C.BAS

For increased accuracy of the analyzer’s calibration is available. This measurement-accuracy enhancement technique is described in the "Error Messages" section of the ual. The example described will perform the sample and sweep calibration under HP-IB remote control.

The power meter is usually connected to ments. Its address must be set correctly and it must be connected to the HP-IB. The power meter address can be set by pressing:

ADDRESS P MTR/HPIB

plete the process. The appropriate command must be selected for the model number of the power meter being used. Press being used is displayed between the brackets. The correction factors for the power sensor are entered into the analyzer. All of these steps are explained in the "Error Messages" section of the

The number of readings-per-point must also be selected before starting. The number of points directly affects the measurement time of the calibration sequence. The power meter must interact with the analyzer for each of the selected points and read the number of values specified for each trace point. Typically, two readings-per-point is considered appropriate. More than two readings-per-point could lead to unacceptable processing time.

To control a power meter calibration via HP-IB, the analyzer must be set to pass-control mode. The analyzer must position the local oscillator to a point in the sweep and read the power present at the power meter sensor. For this operation to take place, the system controller must set up the measurement and then pass control to the analyzer to read each data point in the sweep. After reading the data point from the power meter, the analyzer passes control back to the system controller. The analyzer then sets up to measure the next point and again requests control from the system controller. This process continues until the analyzer signals that the entire sweep has been measured point-by-point.

and using the ↑ and ↓ keys or the numeric key pad to com-

PORT

1-output power, a power meter

HP 8702D Reference

PORT

1 for the forward measure-

POWER MTR: [ ]

HP 8702D Reference

LOCAL

SET ADDRESSES,

until the model

manual.

man-

2-41

Examples

Power Meter Calibration

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The number of points in the trace is set.

• The number of readings-per-point is set.

• The frequency span is set.

• The reference channel is measured.

• The power meter-calibration array is allocated.

• The power meter model is chosen.

• The status registers are cleared.

• The request-control summary bit is enabled.

• The pass-control mode is enabled.

• A calibration sweep is taken to begin the sequence.

• The status byte is read until control is requested.

• The computer passes control to the analyzer.

• The display is cleared and the analyzer is set to talker/listener mode.

• The HP-IB interface status is read until control is returned.

• The program loops until all the points have been measured.

• The power meter calibration is enabled.

• The calibration data is output to the controller in Form 4, ASCII format.

• The power meter-calibration factors are read into the controller.

• The analyzer is released from remote control and the program ends.

Running the Program

The analyzer is preset and the power meter-calibration routine begins. The analyzer displays the message,

WAITING FOR HP-IB CONTROL

requesting control. The system controller display prints,

trol,

when control is passed to the analyzer. The controller displays,

ing for request

while the analyzer has control and is reading the power

Passing Con-

when it is

Wait-

meter.

The interaction of the messages and the movement of the cursor allow observation of the calibration process. Once the calibration is complete, the analyzer displays,

POWER METER CAL IS COMPLETE

controller displays,

Finished with Power meter Cal

and the system

The power meter-calibration mode (with one sweep of correction data) is enabled and the calibration is switched ON. At the completion of the program, talker/listener mode is restored, the event-status registers are cleared (to halt the status-byte interaction), the power meter correction factors are displayed, the sweep is placed in continuous-sweep mode, the analyzer is released from HP-IB control, and the program ends.

2-42

Examples

Power Meter Calibration

10 ! This routine does a power meter cal using pass control. 20 ! A measurement cycle takes place on each point of the trace. The 30 ! point is measured by the power meter and the measured value read 40 ! into the analyzer. The command TAKCS; arms this measurement mode. 50 ! The number of measurements is determined by the number of points in 60 ! the trace, the number of readings per point and an extra measurement 70 ! cycle to release the power meter. 80 ! Control is passed to the analyzer, the point is measured and 90 ! the data is transferred to the analyzer. Control is passed back to 100 ! the controller and the cycle begins again. Serial poll is used to 110 ! read the status byte of the analyzer and test the logic. 120 ! The HP-IB interface status register is monitored to determine when 130 ! control is returned to the interface from the analyzer. 140 ! 150 ! EXAMP4C 160 ! 170 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 180 ! 190 CLEAR SCREEN 200 ! Initialize the analyzer 210 ABORT 7 ! Generate an IFC (Interface Clear) 220 CLEAR @Nwa ! SDC (Selective Device Clear) 230 OUTPUT @Nwa;”OPC?;PRES;” ! Preset the analyzer and wait 240 ENTER @Nwa;Reply ! Read the 1 when complete 250 ! 260 INTEGER Stat 270 ! 280 ! Set up the analyzer parameters 290 Numpoints=11 ! Number of points in the trace 300 Numreads=2 ! Number of readings per point 310 Startf=1.00E+8 ! Start frequency 320 Stopf=5.0E+8 ! Stop frequency 330 ! 340 OUTPUT @Nwa;”POIN”;Numpoints;”;” ! Set trace length to numpoints 350 OUTPUT @Nwa;”NUMR”;Numreads;”;” ! Set number of readings per point 360 OUTPUT @Nwa;”STAR”;Startf ! Set start frequency 370 OUTPUT @Nwa;”STOP”;Stopf ! Set stop frequency 380 OUTPUT @Nwa;”MEASR;” ! Measure the reference channel 390 ! 400 ALLOCATE Pmcal(1:Numpoints) ! Create power meter cal array 410 ! 420 ! Store the original trace for comparison 430 OUTPUT @Nwa;”DATI;” 440 OUTPUT @Nwa;”DISPDATM;” 450 OUTPUT @Nwa;”AUTO;” 460 ! 470 ! Select the power meter being used for cal 480 ! OUTPUT @Nwa;”POWM ON;” ! Select 436A power meter 490 OUTPUT @Nwa;”POWMOFF;DEBUON;” ! Select 437B/438A power meter 500 ! 510 ! Set analyzer HP-IB, status regs to interrupt on pass control 520 OUTPUT @Nwa;”CLES;” ! Clear status registers 530 OUTPUT @Nwa;”ESE2;” ! Enable request control summary bit 540 OUTPUT @Nwa;”SRE32;” ! SRQ on events status register 550 ! 560 PRINT “Beginning Power Meter CAL”

2-43

Examples

Power Meter Calibration

570 OUTPUT @Nwa;”USEPASC;” ! Enable pass control operation 580 OUTPUT @Nwa;”TAKCS;” ! Take Cal Sweep 590 ! 600 FOR I=1 TO Numpoints*Numreads+1 ! Points * Number of readings plus 1 610 ! Serial poll does not place analyzer in remote operation 620 ! and does not require the analyzer to process the command. 630 ! 640 REPEAT ! Repeat until SRQ detected 650 Stat=SPOLL(@Nwa) ! Serial poll to read status byte 660 DISP “Stat “;Stat;” Waiting for request” 670 UNTIL BIT(Stat,6) ! SRQ detected for request control 680 OUTPUT @Nwa;”ESR?;” ! Read status register to clear 690 ENTER @Nwa;Reply ! Read and discard register value 700 ! 710 PRINT “Passing Control” ! status read and passing control 720 PASS CONTROL @Nwa ! Pass control to analyzer 730 ! 740 REPEAT 750 ! Read HP-IB interface state information register. 760 STATUS 7,6;Hpib ! Test HP-IB register for control 770 ! 780 ! Reading the interface status register does not interact with the 790 ! analyzer. Bit 6 is set when control is returned. 800 ! 810 DISP “Waiting for control” 820 UNTIL BIT(Hpib,6) ! Loop until control is returned 830 NEXT I 840 ! 850 PRINT “Finished with Power meter Cal” 860 DISP ““ ! Clear display message 870 ! 880 OUTPUT @Nwa;”TALKLIST;” ! Restore Talker/Listener operation 890 OUTPUT @Nwa;”CLES;” ! Clear and reset status byte operation 900 ! 910 OUTPUT @Nwa;”PWMCONES;” ! Power meter cal correct one sweep 920 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 930 ENTER @Nwa;Reply ! Read the 1 when complete 940 ! 950 ! Read the power meter cal correction factors 960 OUTPUT @Nwa;”FORM4;” ! ASCII data format to read cal data 970 OUTPUT @Nwa;”OUTPPMCAL1;” ! Request the power meter cal factors 980 ENTER @Nwa;Pmcal(*) ! Read the factors 990 ! 1000! Display the power meter cal factors 1010 PRINT “Point”,”Factor” 1020 FOR I=1 TO Numpoints ! Cycle throught the factors 1030 PRINT I,Pmcal(I) 1040 NEXT I 1050! 1060 LOCAL @Nwa ! Release HP-IB control 1070 END

2-44

Using the Learn String

Examples

Using the Learn String

File Name

Description

EXAMP5A.BAS

This section provides several different examples of performing analyzer system setups.

NOTE

The most efficient option for storing and recalling analyzer states is using the analyzer’s internal registers to save the CAL data. Recalling these registers is the fastest solution to restoring analyzer setups. Refer to “Chapter 8, “Saving Data, States, and the Display” in the

HP 8702D User’s Guide

registers. In the event that all the registers have been used, the internal disk drive is not used, or if internal memory limitations exist, then these external solutions become viable.

The purpose of this example is to demonstrate several programming options for storing and recalling entire instrument states over HP-IB. The examples describe two different processes for storing and recalling instrument states. The first example accomplishes the task using the learn string. The second example involves reading both the learn string and the calibration arrays out of the analyzer and storing them to disk or storing them in the system controller itself.

Using the learn string is a very rapid way of saving the instrument state, but using direct disk access has the advantage of automatically storing calibrations, cal kits, and data along with the instrument state.

A complete analyzer setup requires sending the learn string and a calibration array to set the analyzer parameters. The CAL array may also be placed in the analyzer, just as if a calibration was performed. By sending both sets of data, the analyzer may be quickly setup for a measurement.

for detailed information on the analyzer’s internal storage

2-45

Examples

Using the Learn String

Several different measurements may be required in the course of testing a device. An efficient way of performing multiple measurements is to send both the calibration array and the learn string, and then perform the measurements.

Example

The learn string is a very fast and easy way to read an instrument state. The learn string includes all front-panel settings, the limit table for each channel, and the list-frequency table. It can be read out of the analyzer with the command

OUTPLEAS

, and input to the analyzer with the command

INPULEAS

This array is always transmitted in Form 1, the internal format for the analyzer. It cannot be longer than 3000 bytes. The example for a Form 1 transfer could also have been used. However, the “Using the Learn String” example is the simplest solution for reading the learn string from the analyzer.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The string storage is allocated.

• The learn string is requested.

• The string is read without any processing.

• The analyzer is released from remote control.

• The instrument state is changed by the operator.

• The learn string is sent back to the analyzer.

• The analyzer is released from remote control and the program ends.

Running the Program

Run the program. When the program stops, change the instrument state and

ENTER

press

on the controller. The analyzer will be returned to its original state

by sending the learn string to the analyzer.

2-46

Examples

Using the Learn String

10 ! This program shows how to retrieve a learn string from the analyzer 20 ! into a string array. The state of the analyzer is then changed and the 30 ! learn string reloaded to return the analyzer to the previous settings. 40 ! 50 ! EXAMP5A 60 ! 70 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 80 ! 90 CLEAR SCREEN 100 ! Initialize the analyzer 110 ABORT 7 ! Generate an IFC (Interface Clear) 120 CLEAR @Nwa ! SDC (Selected Device Clear) 130 ! 140 DIM State$[3000] ! Define a string for contents 150 ! 160 OUTPUT @Nwa;”OUTPLEAS;” ! Output the learn string 170 ENTER @Nwa USING “+,-K”;State$ ! Read the string with no processing 180 ! + Terminate on EOI only 190 ! -K ignore LF as terminator treat as data 200 ! 210 LOCAL @Nwa ! Release HP-IB control 220 ! 230 INPUT “Change state and press ENTER”,A$ 240 ! 250 OUTPUT @Nwa;”INPULEAS;”;State$; ! Send the learn string to analyzer 260 DISP “Analyzer state has been restored!” 270 ! 280 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for the analyzer to finish 290 ENTER @Nwa;Reply ! Read the 1 when complete 300 LOCAL @Nwa ! Release HP-IB control 310 END

2-47

Examples

Reading Calibration Data

File Name

Description

EXAMP5B.BAS

This example demonstrates:

• how to read measurement calibration data out of the analyzer

• how to read it back into the analyzer

• how to determine which calibration is active

The data used to perform measurement-error correction is stored inside the analyzer in one (or more) of twelve calibration-coefficient arrays. Each array is a specific error coefficient, and is stored and transmitted as an error-corrected data array. Each point is a real/imaginary pair, and the number of points in the array is the same as the number of points in the trace. The five arraydata formats also apply to the transfer of calibration-coefficient arrays. "Printing, Plotting, or Saving Measurement Results" in the contains information on the storage locations for calibration coefficients and different calibration types.

A computer can read out the error coefficients using the commands

OUTPCALC01, OUTPCALC02

uses only as many arrays as required, beginning with array 1. Hence, it is necessary to know the type of calibration about to be read out. Attempting to read an array not being used in the current calibration causes the

DATA NOT CURRENTLY AVAILABLE

A computer can also store calibration coefficients in the analyzer. To do this, declare the type of calibration data about to be stored in the analyzer just as if you were about to perform that calibration. Then, instead of calling up different classes, transfer the calibration coefficients using the mands. The variables representing a calibration number from cients are stored in the analyzer, activate the calibration by issuing the mne-

SAVC

monic

;

, and trigger a sweep on the analyzer.

, ... through,

are a data pair appended to the command

OUTPCALC12

warning.

through 12. When all the coeffi-

HP 8702D User’s Guide

. Each calibration type

REQUESTED

INPUCALC

nn;

com-

2-48

Examples

Reading Calibration Data

This example reads the calibration coefficients into a very large array, from which they can be examined, modified, stored, or put back into the instrument. If the data is to be directly stored on to disk, it is usually more efficient to use Form 1 (analyzer’s internal-binary format), and to store each coefficient array as it is read in.

The following is an outline of the program’s processing sequence:

• The system is initialized.

• The calibration types and number of arrays are defined.

• The integer variables for reading the headers are defined.

• The calibration type and number of arrays are read by the controller.

• The output is formatted in Form 3.

• The number of points in the trace is read.

• The memory is allocated for the calibration arrays.

• Each calibration array is requested from the analyzer.

• The elements from each calibration array are read in.

• The next calibration array is requested until all the arrays have been read.

• The calibration type is sent to the analyzer.

• Each calibration array is sent.

• The calibration is activated.

• The analyzer is released from remote control and the program ends.

Running the Program

Before executing the program, perform a calibration.

The program is able to detect which type of calibration is active. With that information, it predicts how many arrays to read out. When all the arrays have been sent to the computer, the program prompts the operator. The operator then switches OFF the calibration or performs a completely different calibration on the analyzer and continues the program. The computer reloads the old calibration. The operator should not preset the analyzer because the instrument settings must be the same as those that were present when the calibration was taken.

NOTE

The retransmitted calibration is associated with the current instrument state; the instrument has no way of knowing the original state associated with the calibration data. For this reason, it is recommended that the learn string be used to store the instrument state whenever calibration data is stored. The next example demonstrates how to reload the analyzer state with both the learn string and the calibration arrays.

2-49

Examples

Reading Calibration Data

10 ! This program shows how to manipulate calibration data from the analyzer. 20 ! It demonstrates how to read calibration data from the analyzer, and 30 ! how to replace it. The type of calibration active is determined and 40 ! the program reads in the correct number of arrays. The number of points 50 ! in the trace, and in the cal array, is determined and used to dimension 60 ! storage arrays. 70 ! 80 ! EXAMP5B 90 ! 100 ASSIGN @Nwa TO 716 ! Assign an I/O path for the analyzer 110 ASSIGN @Nwa_bin TO 716;FORMAT OFF ! Assign binary path 120 ! 130 CLEAR SCREEN 140 ! Initialize the analyzer 150 ABORT 7 ! Generate an IFC (Interface Clear) 160 CLEAR @Nwa ! SDC (Selected Device Clear) 170 ! 180 ! Data for determining CAL type and number of arrays 190 DATA “CALIRESP”,1,”CALIRAI”,2,”CALIS111”,3 200 DATA “CALIS221”,3,”CALIFUL2”,12 210 DATA “NOOP”,0 220 ! 230 INTEGER Hdr,Lgth,I,J ! Integers for reading headers 240 ! 250 READ Calt$,Numb ! Read CAL type from data statement 260 IF Numb=0 THEN GOTO 690 ! If no CAL type is present Exit 270 OUTPUT @Nwa;Calt$;”?;” ! Query if CAL type is active 280 ENTER @Nwa;Active ! Read 1 if active 290 IF NOT Active THEN GOTO 250 ! Load another CAL type and re-try 300 ! 310 PRINT Calt$,Numb ! Active CAL and number of arrays 320 ! 330 OUTPUT @Nwa;”FORM3;” ! Form 3 IEEE 64 bit floating point 340 OUTPUT @Nwa;”POIN?;” ! Request trace length 350 ENTER @Nwa;Poin ! Read number of points 360 ALLOCATE Cal(1:Numb,1:Poin,1:2) ! Arrays for CAL arrays 370 ! Number of arrays, number of points real and imag value per point 380 ! 390 FOR I=1 TO Numb ! Read arrays 400 OUTPUT @Nwa USING “K,ZZ”;”OUTPCALC”,I ! Format I to add 0 in command 410 ENTER @Nwa_bin;Hdr,Lgth ! Read header & length from array 420 FOR J=1 TO Poin ! Read elements for CAL array 430 ENTER @Nwa_bin;Cal(I,J,1),Cal(I,J,2) ! Read real & imag pair elements 440 NEXT J ! Next location in array 450 NEXT I ! Next CAL array 460 ! 470 ! All CAL arrays have been read 480 ! 490 INPUT “PRESS RETURN TO RE-TRANSMIT CALIBRATION”,Dum$ 500 ! 510 OUTPUT @Nwa;”FORM3;” ! Use same format as read 520 OUTPUT @Nwa;Calt$;”;” ! Send CAL type to analyzer 530 ! 540 FOR I=1 TO Numb ! Send each array in CAL 550 DISP “TRANSMITTING ARRAY: “,I ! Show array number 560 OUTPUT @Nwa USING “K,ZZ”;”INPUCALC”,I ! Send array number 0 format

2-50

Examples

Reading Calibration Data

570 OUTPUT @Nwa_bin;Hdr,Lgth ! Send header & array length 580 FOR J=1 TO Poin ! Send each array element 590 OUTPUT @Nwa_bin;Cal(I,J,1),Cal(I,J,2) ! Real and Imag pair 600 NEXT J ! Next element in array 610 NEXT I ! Next array 620 ! 630 OUTPUT @Nwa;”SAVC;” ! Activate CAL 640 ! 650 OUTPUT @Nwa;”CONT;” ! Restore continuous sweep 660 OUTPUT @Nwa;”OPC?;WAIT;” ! Wait for analyzer to finish 670 ENTER @Nwa;Reply ! Read the 1 when complete 680 ! 690 DISP “Finished with CAL transfer” 700 LOCAL @Nwa ! Release HP-IB control 710 END

2-51

Examples

Using Instrument States

File Name

Description

EXAMP5C.BAS

NOTE

The instrument state may also be stored in the analyzer’s internal registers. This is the fastest and most efficient method for toggling between instrument states. This example is for use when the analyzer’s internal memory is full, or when there are other internalmemory limitations.

This example demonstrates using both the learn string and the calibration arrays to completely re-program the analyzer state. If you were performing two entirely different measurements on a device and wanted to quickly change between instrument states and perform the measurements, this example program is a potential solution.

The example will request the learn string and a calibration array from the analyzer and store them in a disk file on the system controller. Once the storage is complete, the operator will be prompted to change the state of the analyzer and then reload the state that was previously stored in the disk file. Once the file is created on the disk, the state information can be retrieved from the controller and restored on the analyzer.

NOTE

The disk file can only be created once. Errors will occur if the operator repeatedly tries to recreate the file.

For this example, only a thru response calibration will be performed and transferred. This means only one calibration array will be read from the analyzer and written to the disk file with the instrument state. To work with more

2-52

Agilent 8702D Programmers Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Writing Programs

General Information

To select the communication mode

To change the HP-IB address

Selecting the HP-IB Device Mode

To change the HP-IB device mode

Making Measurements

Reading Data

Data-Processing Chain

Controlling Command Execution

Calibrating for Measurements

Debugging Programs

Understanding File Names

Drawing Graphics on the Display

Monitoring the Instrument

Response to IEEE-488 Universal Commands

Preparing Measurement Settings

Verifying Measurement Settings

S11 1-Port Measurement Calibration

Full 2-Port Measurement Calibration

Data Transfer Using Markers

Data Transfer Using ASCII Format

Data Transfer Using Floating-Point Numbers

Data Transfer Using Frequency-Array Information

Data Transfer Using Internal Binary Format

Using Error Queue

Generating Interrupts

Power Meter Calibration

Using the Learn String

Reading Calibration Data

Using Instrument States
