User’s Guide

Publication number 16500-97007 First Edition, February 1994

For Safety information, Warranties, and Regulatory information, see the pages behind the index

HP 16500B /16501A Logic Analysis System

HP 16500B—At a Glance

cards with a wide range of state, tim in g,

A system of measurement modules

The HP 16500B is the mainframe of the Hewlett-Packard Logic Analysis System. It offers a modular structure for pl ug-i n

oscilloscope, and patter n generator capabilities.

A powerful, easy-to-use int erface

The touchscreen interfa ce off ers popup menus and color graphics to lead you through measurement configurations withou t hav in g to remember lots of steps. You can add a keyboard or mouse to speed data input and measurement confi guration.

The HP 16501A expands mod ule

capacity

connected, they form a single ten-card

The HP 16501A is the add-on mainf ram e for expanding the module ca paci ty of the HP 16500B. When the two are

system that is turned on and control l ed by the HP 16500B.

Intermodule measusu rem ent capability

The HP 16500B offers intermodule measurement features that allow you to capture complex system activity. Modules can

be armed by an external instrument,

•

be armed by another module in the

•

HP16500B or HP16501A frames, or be used to arm an external

•

instrument.

iii

Install measurement modules in any

slot

Single card analyzers, osc illoscopes,

and other options can go in any slot of

the HP 16500B or HP 1 6501A. You should

generally begin installing cards starting

with the bottom-most slot an d wo rking up.

Some measurement mo dul es hav e multiple cards. A multiple-card module must be installed into adjacent slots in

the same mainframe—that is, you cannot install one card of the modul e into the HP 16500B and the other int o the HP 16501A.

Calibrate measurement modules after installation

Some measurement mo dul es are sensitive to temperature and voltage variations between different mainframes. Thus, when you install such a module in the mainfram e, you should calibrate it before usi ng it to ensure maximum measurem ent precision and accuracy .

See the Service Guide for each measurement module for installation and calibration procedures.

In This Book

Chapter 1, “Triggering,” shows you how to

File Management

Concepts

Solving Problems

Application Notes

Glossary

Index

This User’s Guide shows you how to use the HP 16500B Logic Analysis System in

your everyday debugging work.

set up the analyzer to trigger on the various kinds of events present in your system. Advanced triggering capability allows you to look at only the program states of interest when you are solving a particular problem.

Chapter 2, “Intermodule Measurements,” shows you how to configure multiple HP 16500 modules and external measurement instruments into a single measurement system in which modules trigger each other.

Chapter 3, “File Management,” shows you how to transfer files to and from the HP 16500B using flexible disks, LAN interfaces, and other interfaces.

Chapter 4,“Concepts,” gives you a brief introduction to the ideas underlying the trigger sequencer and the inverse assembler, two important components of sophisticated logic analysis.

Chapter 5, “Solving Problems,” shows you how to diagnose and correct the more common types of problems that might occur while you are making a measurement.

Chapter 6, “Application Notes,” lists the various application notes that HP has published regarding the HP 16500B and other similar HP logic analyzers. These

Triggering

Intermodule Measure m ents

notes will give you more information about specific application problems and

how to solve them using an HP logic analyzer.

See Also For general information on setup and operation of the HP 16500B, see the

HP 16500B /16501A Logic Analysis System User’s Reference. For information on programming the HP 16500B using a computer controller

such as a workstation or personal computer, see the HP 16500B/16501A Logic Analysis System Programmer’s Guide.

For information on logic analyzers, oscilloscopes, preprocessors, and other logic analysis system options, see the User’s Reference manual for those options.

Con tents

1Trig ger ing

To cap ture a trace of ac tiv ity as so ci ated with a write of known bad data to a

To ver ify that all stacks and reg is ters are re stored cor rectly bef ore ex it ing a

To store and time the exe cu tion of a sub rou tine 1–3 To trig ger on the nth it era tion of a loop 1–5 To trig ger on the nth re cur sive call of a re cur sive func tion 1–7 To trig ger on en try to a func tion 1–9

par ticu lar vari able 1–11 To trig ger on a loop that oc ca sion ally runs too long 1–12

sub rou tine 1–13 To trig ger af ter all status bus lines fin ish tran si tion ing 1–15 To find the nth oc cur rence of as sert ing a chip se lect line 1–16 To ver ify that the chip se lect line of a mem ory chip is strobed af ter the ad dress on the ad dress bus is sta ble 1–17 To trig ger when ex pected data does not ap pear on the data bus from a re mote de vice when re quested 1–18 To test mini mum and maxi mum pulse lim its 1–20 To de tect a hand shake vio la tion 1–22 To de tect bus con ten tion 1–23

Cross- Arming Trig ger Ex am ples 1–24

To ex am ine soft ware exe cu tion when a tim ing vio la tion oc curs 1–25 To look at con trol and status sig nals dur ing exe cu tion of a rou tine 1–26

2In ter mod ule Meas ure ments

In ter mod ule Meas ure ment Ex am ples 2–4

To set up a group run of mod ules within the HP 16500B 2–5 To start a group run of mod ules from an ex ter nal trig ger source 2–7 To start an ex ter nal in stru ment on com mand from a mod ule within the HP 16500 and 16501 main frame 2–9 To see the status of a mod ule within an in ter mod ule meas ure ment 2–11 o see time cor re la tion of each mod ule within an in ter mod ule meas ure ment 2–12 To use a tim ing ana lyzer to de tect a glitch 2–13

To use two state ana lyz ers to moni tor the ac tiv ity of co proc es sors in a tar get

Contents

viii

To cap ture the wave form of a glitch 2–14 o cap ture state flow show ing how your tar get sys tem pro cesses an in ter rupt 2–15 Us ing stimulus- response to test a cir cuit 2–17 To use a state ana lyzer to trig ger tim ing analy sis of a count- down on a set of data lines 2–19

sys tem 2–20

Spe cial dis plays 2–21

To in ter leave trace lists 2–22 To view trace lists and wave forms to gether on the same dis play 2–24

Skew Ad just ment 2–26

To ad just for mini mum skew be tween two mod ules in volved in an in ter mod -

ule meas ure ment 2–27

3 File Man age ment

Trans fer ring Files Us ing the Flexi ble Disk Drive 3–3

To save a meas ure ment con figu ra tion 3–4 To load a meas ure ment con figu ra tion 3–6 To save a trace list in AS CII for mat 3–8 To save a menu or meas ure ment as a graphic im age 3–10 To load sys tem soft ware 3–12

Us ing the HP 16500L LAN In ter face 3–13

To set up the HP 16500B 3–14 To trans fer data files from the HP 16500B sys tem to your com puter 3–16 To trans fer graph ics files from the HP 16500B sys tem to your com puter 3–18

4Con cepts

The Trig ger Se quencer 4–3

The In verse As sem bler 4–10

Con figu ra tion Trans la tion for Ana lyzer Mod ules 4–13

5 If You Have a Prob lem

Ana lyzer Prob lems 5–3

In ter mit tent data er rors 5–3 Un wanted trig gers 5–3 No Setup/Hold field on for mat screen 5–4 No ac tiv ity on ac tiv ity in di ca tors 5–4 Ca paci tive load ing 5–4 No trace list dis play 5–5

Contents

Pre proc es sor Prob lems 5–6

Tar get sys tem will not boot up 5–6 Slow clock 5–7 Er ratic trace meas ure ments 5–7

In verse As sem bler Prob lems 5–9

No in verse as sem bly or in cor rect in verse as sem bly 5–9 In verse as sem bler will not load or run 5–10

In ter mod ule Meas ure ment Prob lems 5–11

An event was n't cap tured by one of the mod ules 5–11

Mes sages 5–12

“De fault Cali bra tion Fac tors Loaded” (HP 16540, 16541, and 16542) 5–12 “. . . In verse As sem bler Not Found” 5–12 “Meas ure ment Ini tiali za tion Er ror” 5–13 “No Con figu ra tion File Loaded” 5–14 “Se lected File is In com pati ble” 5–14 “Slow or Miss ing Clock” 5–14 “State Clock Vio lates Over drive Speci fi ca tion” 5–15 “Time from Arm Greater Than 41.93 ms” 5–15

Contents

“Wait ing for Trig ger” 5–15

6Ap pli ca tion Notes

Triggering

As you begin to understand a problem in your system, you may realize that certain conditions must occur before the problem occurs. You can use sequential triggering to ensure that those conditions have occurred before the analyzer recognizes its trigger and captures information.

You set up sequential triggering as follows:

• Select the Trigger menu for the module you are using.

• In the Trigger menu, define terms and associated values to be used

when searching through the sequence.

• In the Trigger menu, select the number of the state sequence level

you want to modify, and enter the appropriate store qualification, sequence-advance specification, and sequence-Else specification.

If you aren’t familiar with the trigger menus, try working through the examples in the Logic Analyzer Training Kit manual, or refer to the User’s Reference for your analyzer.

Triggering

To store and time the execution of a sub routi ne

To store and time the execution of a subroutine

Most systems software of any kind is composed of a hierarchy of functions and procedures. During integration, testing, and performance evaluation, you will want to look at specific procedures to verify that they are executing correctly and that the implementation is efficient. The analyzer allows you to do this by triggering on entry to the address range of the subroutine and counting the elapsed time since the trigger state.

Select the state analyzer Trigger menu.

1 2 Set Count to Time.

Setting the Count to Time causes the state analyzer to store a time stamp for each data point that is stored in trace memory. The trace list will show these time stamps next to each state.

Define a range term, such as Range1, to represent the address range

of the subroutine of interest.

You may need to examine the structure of your code to help determine this. If your subroutine calls are really procedure calls, then there is likely to be some code at the beginning of the routine that adjusts the stack for local variable allocation. This will precede the address of the first statement in the procedure. If your subroutine has no local storage and is called by a jump or branch, then the first statement will also be the entry address.

Under State Sequence Levels, enter the following sequence

specification:

While storing “no state” Trigger on “In_range1” 1 time

•

While storing “In_range1” Then find “Out_range1” 1 time

•

Store “no state”

•

Example Suppose you want to trigger on entry to a routine called MY_SUB. You can

define the address of MY_SUB in the Format menu, allowing you to reference the symbol name when setting up the trace specification. Assume that MY_SUB extends for 0A hex locations. You can set up the trigger sequencer as shown in the display.

Triggering

To store and time the execution of a subr outi ne

Trigger Setup for Storing Execution of a Subroutine

For processors that do prefetching of instructions or have pipelin ed architectures, you may want to add part or all of the depth of the pipeline to the start address for In_Range 1 to en sure t hat t he anal yzer does not trigger on a prefetched but unexecuted state.

Triggering

To trigger on the nth iteration of a loop

Traditional debugging requires print statements around the area of interest. This is not possible in most embedded systems designs. But, the analyzer allows you to view the system’s behavior when a particular event occurs. Suppose that your system behaves incorrectly on the last iteration of a loop, which, in this instance, happens to be the 10th iteration. You can use the analyzer’s triggering capabilities to capture that iteration and subsequent processor activity.

Select the state analyzer Trigger menu.

1 2 Define the terms LP_START and LP_END to represent the start and

end addresses of statements in the loop, and LP_EXIT to represent the first statement executed after the loop terminates.

3 Under State Sequence Levels, enter the following sequence

specification:

While storing “no state” Find LP_END 1 time

•

While storing “anystate” TRIGGER on LP_START 9 times; Else on

•

“LP_EXIT” go to level 1

Store “anystate”

•

The above sequence specification has some advantages and a potential problem. The advantages are that a pipelined processor won't trigger until it has executed the loop 10 times. Requiring LP_END to be seen at least once first ensures that the processor actually entered the loop; then, 9 more iterations of LP_START is really the 10th iteration of the loop. Also, no trigger occurs if the loop executes less than 10 times: the analyzer sees LP_EXIT and restarts the trigger sequence. The potential problem is that LP_EXIT may be too near LP_END and thus appear on the bus during a prefetch. The analyzer will constantly restart the sequence and will never trigger. The solution to this problem depends on the structure of your code. You may need to experiment with different trigger sequences to find one that captures only the data you wish to view.

Triggering

To trigger on the nth iteration of a loop

Trigger Setup for Triggering on the 10th Iteration of a Loop

Triggering

To trigger on the nth recursive call of a recurs ive function

To trigger on the nth recursive call of a recursive function

1 Select the state analyzer Trigger menu. 2 Define the terms CALL_ADD, F_START, and F_END to represent the

called address of the recursive function, and the start and end addresses of the function. Define F_EXIT to represent the address of the first program statement executed after the original recursive call has terminated.

Typically, CALL_ADD is the address of the code that sets up the activation record on the stack, F_START is the address of the first statement in the function, and F_END is the address of the last instruction of the function, which does not necessarily correspond to the address of the last statement. If the start of the function and the address called by recursive calls are the same, or you are not interested in the function initialization code, you can use F_START for both CALL_ADD and F_START.

Under State Sequence Levels, enter the following sequence

specification:

While storing “no state” Find “F_END” 1 time

•

While storing “anystate” Then find “F_START” 1 time

•

While storing “anystate” TRIGGER on “CALL_ADD” 20 times Else on

•

“F_EXIT” go to level 1

Store “anystate”

•

As with the trigger specification for “To trigger on the nth iteration of a loop,” this specification helps avoid potential problems on pipelined processors by requiring that the processor already be in the first recursive call before advancing the sequencer. Depending on the exact code used for the calls, you may need to experiment with different trigger sequences to find one that captures only the data you wish to view.

Triggering

To trigger on the nth recursive call of a recurs ive function

Trigger ing on the 22nd Ca ll of a Recursive Function

Triggering

To trigger on entry to a function

This sequence triggers on entry to a function only when it is called by one particular function.

Select the state analyzer Trigger menu.

1 2 Define the terms F1_START and F1_END to represent the start and

end addresses of the calling function. Define F2_START to represent the start address of the called function.

3 Under State Sequence Levels, enter the following sequence

specification:

While storing “anystate” Find “F1_START” 1 time

•

While storing “anystate” TRIGGER on “F2_START” 1 time Else on

•

“F1_END” go to level 1

Store “anystate”

•

This sequence specification assumes there is some conditional logic in function F1 that chooses whether or not to call function F2. Thus, if F1 ends without the analyzer having seen F2, the sequence restarts.

The specification also stores all execution inside function F1, whether or not F2 was called. If you are interested only in the execution of F1, without the code that led to its invocation, you can change the storage specification from “anystate” to “nostate” for the second sequence term.

Triggering

To trigger on entry to a function

Trigger ing on Entry to a Function

Triggering

ith

To capture a trace of activity associ ated w

particular variable

To capture a trace of activity associated with a write of known bad data to a particular variable

The trigger specification ANDs the bad data on the data bus, write transaction on the status bus, and address of the variable on the address bus.

Select the state analyzer Trigger menu.

1 2 Define the terms BAD_DATA, WRITE, and VAR_ADDR to represent

the bad data value, write status, and the address of the variable.

3 Under State Sequence Levels, enter the following sequence

specification:

While storing “anystate” TRIGGER on “BAD_DATA • WRITE •

•

VAR_ADDR” one time (you use the Combination trigger term to do this)

Store “anystate”

•

a write of kno

Capturing a Bad W rite to a Variable

111

Triggering

To trigger on a loop that occasionall y runs too long

To trigger on a loop that occasionally runs too long

This example assumes the loop normally executes in 14 µs.

Select the state analyzer Trigger menu.

2 Define terms LP_START, LP_END, and Timer1 to represent the start

and end addresses of the loop, and the normal duration of the loop.

You can make the sequence specification closer to the problem domain by renaming Timer1 to LOOP_DUR.

Under State Sequence Levels, enter the following sequence

specification:

While storing “anystate” Find “LP_START” 1 time

•

While storing “anystate” TRIGGER on “LOOP_DUR 14.00 µs” 1 time Else

•

on “LP_END” go to level 1

You will need to start the LOOP_DUR timer (Timer1) upon entering this state. You do this using the Timer Control field in the menu for sequence level 2.

Store “anystate”

•

Triggering

To verify that all stacks and registers are restore

subroutine

Triggering on a Loop Overrun

To verify that all stacks and registers are restored correctly before exiting a subroutine

The exit code for a function will often contain instructions for deallocating stack storage for local variables and restoring registers that were saved during the function call. Some language implementations vary on these points, with the calling function doing some of this work, so you may need to adapt the procedure to suit your system.

Select the state analyzer Trigger menu.

1 2 Define terms SR_START and SR_END to represent the start and end

addresses of the subroutine.

3 Under State Sequence Levels, enter the following sequence

specification:

While storing “anystate” Find “SR_START” 1 time

•

correctly

While storing “anystate” Then find “SR_END” 1 time

•

While storing “anystate” TRIGGER on “≠ SR_START” 1 time Else on

•

“SR_START” go to level 2

113

Store “anystate”

Triggering

To verify that all stacks and registers are restored correctly before exit ing a subroutine

•

Verifying Correct Return from a Function Call

Only three sequence term s are sh ow n on the display at a time. You can scroll

through the terms using the knob when the “State Sequence Levels” fiel d is light blue.

Triggering

To trigger after all status bus lines f ini sh tran si tio ning

To trigger after all status bus lines finish transitioning

In some applications, you will want to trigger a measurement when a particular pattern has become stable. For example, you might want to trigger the analyzer when a microprocessor’s status bus has become stable during the bus cycle.

Select the timing analyzer Trigger menu and define a term called

PATTERN to represent the value to be found on the label representing the status bus lines.

2 Under Timing Sequence Levels, enter the following sequence

specification:

TRIGGER on “PATTERN” > 40 ns

115

Triggering

To find the nth occurrence of asserting a chip select line

1 Select the timing analyzer Trigger menu. 2 Define the glitch/edge1 term to represent the asserting transition on

the chip select line.

You can rename the Edge1 term to make it correspond more closely to the problem domain, for example, to CHIP_SEL.

Under Timing Sequence Levels, enter the following sequence

specification:

TRIGGER on “CHIP_SEL” 10 times

Triggering on the 10th Assertion of a Chip Select Line

Triggering

hip i

To verify that the chip select line of a mem ory c

on the address bus is stable

To verify that the chip select line of a memory chip is strobed after the address on the address bus is stable

1 Select the timing analyzer Trigger menu. 2 Define a term called ADDRESS to represent the address in question

and the Edge1 term to represent the asserting transition on the chip select line.

You can rename the Edge1 term to suit the problem, for example, to MEM_SEL.

Under Timing Sequence Levels, enter the following sequence

specification:

Find “ADDRESS” > 80 ns

•

TRIGGER on “MEM_SEL” 1 time Else on “≠ ADDRESS” go to level 1

•

s stro

Verifying Setup Time for Memory Address

117

Triggering

To trigger when expected data does not appear on the data bus from a rem ote device when requested

To trigger when expected data does not appear on the data bus from a remote device when requested

1 Select the timing analyzer Trigger menu. 2 Define a term called DATA to represent the expected data, the Edge1

term to represent the chip select line of the remote device, and the Timer1 term to identify the time limit for receiving expected data.

You can rename the Edge1 and Timer1 terms to match the problem domain, for example, to REM_SEL and ACK_TIME.

Under Timing Sequence Levels, enter the following sequence

specification:

Find “REM_SEL” 1 time

•

TRIGGER on “ACK_TIME > 16.00 µs” 1 time Else on “DATA” go to level 1

•

You will need to use the Timer Control field in the sequence setup for sequence level 2 to start the ACK_TIME timer upon entering that sequence level.

This sequence specification causes the analyzer to trigger when the data does not occur in 16 µs or less. If it does occur within 16 µs, the sequence restarts.

Specifications of this type are useful in finding intermittent problems. You can set up and run the trace, then cycle the system through temperature and voltage variations, using automatic equipment if necessary. The failure will be captured and saved for later review.

he d

device when requested

Triggering

To trigger when expected data does not appear on t

ata

Trigge ri n g W h en I/O D at a N o t Retu rned

119

Triggering

To test minimum and maximum puls e li m its

To test minimum and maximum pulse limits

1 Select the timing analyzer Trigger menu. 2 Define the Edge1 term to represent the positive-going transition, and

define the Edge2 term to represent the negative-going transition on the line with the pulse to be tested.

You can rename these terms to POS_EDGE and NEG_EDGE.

Define the Timer1 term to represent the minimum pulse width, and the Timer2 term to represent the maximum pulse width.

You can rename these terms to MIN_WID and MAX_WID. In this example, Timer1 was set to 496 ns and Timer2 was set to 1 µs. Both timers start when sequence level 2 is active.

Under Timing Sequence Levels, enter the following sequence

specification:

Find “POS_EDGE” 1 time

•

Then find “NEG_EDGE” 1 time

•

TRIGGER on “MIN_WID 496 ns + MAX_WID 1.00 µs” 1 time Else on

•

“anystate” go to level 1

Because both timers start when entering sequence level 2, they start as soon as the positive edge of the pulse occurs. Once the negative edge occurs, the sequencer transitions to level 3. If at that point, the MIN_WID timer is less than 496 ns or the MAX_WID timer is greater than 1 µs, the pulse width has been violated and the analyzer should trigger. Otherwise, the sequence is restarted.

Measurement of Minimum and Maxim um Pulse Width Limits

Triggering

To test minimum and maximum puls e li mits

Trigger ing when a Pulse Exceeds Minimum or Ma ximum Limits

121

Triggering

To detect a handshake violation

1 Select the timing analyzer Trigger menu. 2 Define the Edge1 term to represent either transition on the first

handshake line, and the Edge2 term to represent either transition on the second handshake line.

You can rename these terms to match your problem, for example, to REQ and ACK.

Under Timing Sequence Levels, enter the following sequence

specification:

Find “REQ” 1 time

•

TRIGGER on “REQ” 1 time Else on “ACK” go to level 1

•

Triggering on a Handshake Violation

Triggering

To detect bus contention

In this sequencer setup, the trigger occurs only if both devices assert their bus transfer acknowledge lines at the same time.

Select the timing analyzer Trigger menu.

1 2 Define the Edge1 term to represent assertion of the bus transfer

acknowledge line of one device, and Edge2 term to represent assertion of the bus transfer acknowledge line of the other device.

You can rename these to BTACK1 and BTACK2.

Under Timing Sequence Levels, enter the following sequence specification:

TRIGGER on “BTACK1 • BTACK2” 1 time

Trigger ing on Bus Contention

123

Cross-Arming Trigger Examples

The following examples use cross arming to coordinate measurements between two instruments. The cross-arming is set up in the Arming Control menu (obtained by selecting Arming Control in the Trigger menu). When coordinating measurements between two or more analyzers, select Count Time so you can correlate the measurements made by the two analyzers.

See Also Chapter 2, “Intermodule Measurements.”

Triggering

imi

To examine software execution when a t

To examine software execution when a timing violation occurs

The timing analyzer triggers when the timing violation occurs, and when it

triggers, it also sets its “arm” level to true. When the state analyzer receives the arm signal, it triggers immediately on the present state.

Select the timing analyzer Trigger menu.

1 2 Define the Edge1 term to represent the control line where the timing

violation occurs.

3 Under Timing Sequence Levels, enter the following sequence

specification:

TRIGGER on “glitch/edge1” 1 time

Select the state analyzer Trigger menu and accept the default (anystate) definition for term a.

5 Under State Sequence Levels, enter the following sequence

specification:

ng violation occ

While storing “anystate” TRIGGER on “arm • a” 1 time

•

Store “anystate”

•

125

Triggering

To look at control and status signals during execution of a routine

The state analyzer will trigger on the start of the routine whose control and status signals are to be examined with finer resolution than once per bus

cycle. When it triggers, it will switch its “arm” level true. The timing analyzer will trigger when it receives the true arm level and detects the transition represented by glitch/edge1.

Select the state analyzer Trigger menu and define term R_START to

represent the starting address of the routine.

2 Under State Sequence Levels, enter the following sequence

specification:

While storing “anystate” TRIGGER on “R_START” 1 time

•

Store “anystate”

•

Select the timing analyzer Trigger menu.

4 Define the Edge1 term to represent a transition on one of the control

signals.

5 Under Timing Sequence Levels, enter the following sequence

specification:

TRIGGER on “arm • Edge1” 1 time

Intermodule Measurements

An intermodule measurement is a measurement that is coordinated between two or more modules to capture different types of information related to a problem you are trying to solve. This chapter shows you how to make several kinds of intermodule measurements.

Intermodule measurements can involve state analyzers, timing analyzers, oscilloscopes, and pattern generators. The measurement may be as simple as coordinating the startup of several modules during a measurement; it may be quite complex and include multiple arming sequences between modules and external equipment.

For example, you may have a timing analyzer detect the occurrence of a glitch, and at the same time, have an oscilloscope capture the glitch waveform and a state analyzer capture the program flow before and after the occurrence of the glitch. With several types of information obtained from various analysis modules, you can discover problems that would otherwise be difficult to identify.

The figure on the opposite page shows how intermodule bus arming signals are connected between modules inside the HP 16500B and HP 16501A. Note that any arm input can be driven by any slot, and that the port input line can drive any slot.

If you are unfamiliar with the basic operation of the Intermodule Menu, try working the examples in the Logic Analyzer Training Kit.

Intermodule Bus Block Functional Diagram

Intermodule Measurements

Intermodule Measurement Examples

To set up an intermodule measurement, you must use the Intermodule

menu. All modules that will participate in the intermodule measurement must be represented in this menu and their relationships must be shown under the Group Run field.

Intermodule Measurements

To set up a group run of modules within the HP 16500 B

To set up a group run of modules within the HP 16500B

Modules are armed in the configuration tree by either an individual module or the Group Run field. When armed, a module begins searching for the input that will satisfy its trigger specification. To obtain a specification that triggers

on the arm signal, specify to trigger on “anystate.”

Select the Intermodule menu.

1 2 Select the second field down from the top on the left, then select

Group Run.

3 Select the name of each module you want to include in the

measurement.

The modules are listed under “Modules” on the right side of the menu.

a Select Group Run if you want to arm this module immediately when

the Group Run begins.

b Select the name of another module if you want the other module to

arm the present one when the other module finds its trigger.

c Select Independent if this module should not be included in the

intermodule measurement.

Select the Group Run field in the upper right hand corner.

The group run begins. The modules attached directly to the Group Run field immediately begin searching for their respective trigger conditions. When a module finds its trigger, it arms any modules attached to it in the Group Run tree.

The analyz er in slot B is arm e d when the oscilloscope in slot D finds i ts trigger condition.

Intermodule Measurements

To set up a group run of modules within t he HP 16 50 0B

Oscilloscope Arms State Analyzer in Group Run

Intermodule Measurements

To start a group run of modules from an exte rna

To start a group run of modules from an external trigger source

1 Connect the arm signal from the external instrument or system to the

PORT IN BNC connector on the rear panel of the HP 16500 frame.

2 Select the Intermodule menu. 3 Set up the group run specification. 4 Select the PORT IN/OUT field.

a Select the field under PORT IN Level, then select the level that

matches the external signal that will be applied to the PORT IN BNC on the HP 16500B rear panel.

The choices are TTL, ECL, and User. The latter allows you to specify a voltage from −4.00 V to +5.00 V using an onscreen keypad.

b Select the field under PORT IN Edge to change from Rising to Falling

edge and vice-versa for the rear-panel input signal.

c Select Done to leave the PORT IN/OUT Setup menu.

Select the Group Run field in the upper right hand corner.

The modules attached directly to the Group Run Armed from PORT IN field wait for a signal from the PORT IN field.

Start the external instrument or system.

When the external instrument sends the proper signal to the PORT IN BNC, the internal modules attached directly to the Group Run Armed from PORT IN field are armed and begin searching for their respective trigger conditions.

trigger sou

Modules are armed by modules above them, either an individu al module or the field named Group Run Armed from PORT IN. That is, in the intermodule di splay, an arrow pointing to a module to be arm ed ori gi nates in the module providing

the arm signal. See the f igure “Oscilloscope Arms State Analyzer in Group Run” on page 2-6. When armed, a module begins searching for the input that will satisfy its trigger specificat io n. To obtain a specification of “trigger on the arm signal,” specify a trigger that equates to “trigger on anything.”

See Also “To set up a group run of modules within the HP 16500B.”

Both the analyzer in slot B and the oscilloscope in slot D are armed when the PORT IN signal arrives.

Intermodule Measurements

To start a group run of modules from an ext ernal trigger source

State Analyzer and Oscill oscope armed from PORT IN

See Also “To set up a group run of modules within the HP 16500B” in this chapter.

Intermodule Measurements

d f

To start an external instrument on comman

HP 16500 and 16501 mainfr a me

To start an external instrument on command from a module within the HP 16500 and 16501 mainframe

You can set up a module in a group run so that it sends a pulse through the PORT OUT rear panel BNC. The pulse can be used to start or stop a measurement in an external instrument or system.

Set up the group run specification.

See “To start a group run of modules within the HP 16500B” or “To start a group run of modules from an external trigger source.”

Select PORT IN/OUT.

The PORT IN/OUT Setup menu appears.

Select the PORT OUT field.

Select Off if no module should drive PORT OUT.

•

Select the name of the module you want to have drive PORT OUT.

•

Select Done in the PORT IN/OUT Setup menu.

The output from the PORT OUT BNC is an active high TTL level.

rom a mo

See Also “To set up a group run of modules within the HP 16500B” or “To start a group

run of modules from an external trigger source” in this chapter.

The analyz er in slot B drives port out after finding its trigger.

Intermodule Measurements

To start an external instrument on command from a module within the H P 16500 and 16501 mainframe

Driving the Port Out BNC in an Intermodule Measu rement

Intermodule Measurements

To see the status of a module within an

To see the status of a module within an intermodule measurement

1 Select the Intermodule menu. 2 Find the name of the module under the “Modules” list, and read the

status under the module name.

The status can be either Running or Stopped. You can interpret these indications as follows:

If a module was running and is now stopped, assume it received its arming

•

signal, triggered, and finished its measurement properly.

If a module located below a stopped module on the intermodule

•

configuration tree has received an arming signal and is still running, either it is still waiting to satisfy its trigger specification or it has not captured enough information to fill its memory.

If a module below a running module on the intermodule configuration tree

•

has not received its arming signal, it will not begin running until the upper module finds its trigger condition.

ntermodule measur

Both modules are running because neither has found its respective trigger condition.

Module Stat us

211

Intermodule Measurements

To see time correlation of each mod ule w ith in an in termodule measurement

To see time correlation of each module within an intermodule measurement

Time correlation in the intermodule menu can help you see when the trigger occurred for each module and the relative time range of data captured by that module.

Select Time in the Count field of the trigger menu of each logic state

analyzer whose measurement will be time-correlated with the other modules.

Timing analyzers and digitizing oscilloscopes implicitly count time because their sampling is driven by an internal clock, rather than an external state clock. See the User’s Reference for your logic state analyzer for details on how to count time with the analyzer.

Select the Intermodule menu.

2 3 Select the Group Run field in the upper right hand corner.

Once the measurement has started, view the time correlation bars at the

bottom of the Intermodule Menu. The “T” in each bar indicates the relative time at which that module found its trigger condition. The yellow portion of each bar indicates the start and stop points of the acquisition window of the associated module relative to the other modules in the measurement.

This portion of the bar indicates the relative time range of data acquired by this module.

T indicates the time at which the tr igger was found.

Intermodule Measurements

To use a timing analyzer to detect a gli tch

To use a timing analyzer to detect a glitch

The following setup uses a state analyzer to capture state flow occurring at the time of the glitch. This can be useful in troubleshooting. For example, you might find that the glitch is ground bounce caused by a number of simultaneous signal transitions.

Select the Intermodule menu.

1 2 Select the timing analyzer from the Modules list and set it to Group

Run. Select the state analyzer and set it to respond to the arm signal from the timing analyzer.

You must have fully independent state and timing analyzers to make this type of measurement. For example, though the HP 16550A can be configured to use some of its channels for a state analyzer and some for a timing analyzer, it cannot present those analyzers independently for intermodule measurements.

Select the timing analyzer Trigger menu.

3 4 Select an Edge term. Then assign glitch detection “*” to the channels

of interest represented by the Edge term.

5 Select the state analyzer Trigger menu. 6 Set the analyzer to trigger on any state and store any state. 7 Select Group Run in the upper right corner of the display.

If you don’t see the activity of interest in the state trace, try changing the trigger position using the Acquisition Control field in the Trigger menu of the state analyzer. By changing the Acquisition mode to manual, you can position the trigger at any state relative to analyzer memory.

The timing analyzer can detect gli tch activity on a waveform. A glitch is defi ned as two or more transitions acros s th e log ic thres hol d between adjacent timing analyzer samples.

213

Intermodule Measurements

To capture the waveform of a glitch

The following setup uses the triggering capability of the timing analyzer and the acquisition capability of the oscilloscope.

Select the Intermodule Menu.

1 2 Select the timing analyzer from the Modules list and set it to Group

Run. Select the oscilloscope module and set it to respond to the arm signal from the timing analyzer.

3 Select the timing analyzer module. 4 Select the Trigger menu, and within the menu, select an Edge term. 5 Assign glitch detection “*” to the channel of interest represented by

the Edge term.

This will usually be the same channel monitored by the oscilloscope.

Select the oscilloscope Trigger menu, and set Mode to Immediate.

7 Select the Group Run field in the upper right corner.

If you have trouble capturing the glitch waveform on the oscilloscope, try adjusting the skew in the Intermodule menu, so the oscilloscope triggers earlier.

A timing analyzer can trigger on a gl itch and capture it, but a timing analyzer doesn’t have the voltage or timing resolution to display the glitch in detail. An oscilloscope can display a gli tch waveform with fine resolution, but cannot trigger on glitches, combin ations of glitches, or sophisticated pat terns in volving many channels.

Intermodule Measurements

To capture state flow showing how your target system proce

To capture state flow showing how your target system processes an interrupt

Use an oscilloscope with a sample rate faster than the microprocessor clock rate to trigger on the asynchronous interrupt request.

Select the Intermodule menu.

1 2 Select the oscilloscope from the Modules list and set it to Group Run.

Select the state analyzer module and set it to respond to the arm signal from the oscilloscope module.

3 Select the oscilloscope module. 4 Select the Trigger menu, and set the mode to Edge trigger. 5 Select the state analyzer module. 6 Select the Trigger menu of the state analyzer, and set the analyzer to

trigger on any state and store any state.

7 Select Group Run from the upper right corner of the display.

When the interrupt occurs, the oscilloscope will trigger, subsequently triggering the state analyzer.

If the analyzer doesn’t capture the expected interrupt activity, ensure that the interrupt isn’t masked due to the actions of other program code.

This setup can help you answer questions like the following:

• Does the processor branch to the proper interrupt handling routine?

• Are registers and status inform ation saved properly?

• How long does it take to service the interrupt?

• Is the interrupt acknowledge d properl y?

• After the interrupt is serviced, does the processor restore registers and status information and continue with the interrupted routine as expected?

You can use the state analyzer to check the address of the interrupt routi ne as well as to see if interrupt process in g is done as expected. Using a preprocessor and inverse assembler wit h the s tat e anal yzer w i ll make it easier to read the program flow.

215

Intermodule Measurements

To capture state flow showing how your target system processes an inte rrupt

Interrupt Capture Setup

Using stimulus-response to test a circuit

Intermodule Measurements

Using stimulus-respons e to t est a circui t

1 Select the Intermodule menu. 2 Select the pattern generator from the Modules list and set it to Group

Run. Select the oscilloscope module and set it to respond to the arm signal from the pattern generator. Select the state analyzer and set it to respond to the arm signal from the pattern generator.

3 Load the pattern generator with the proper patterns to simulate the

signals from the driving hardware.

4 Insert the “Signal IMB” instruction at the desired point in the pattern

generator program.

The arm signal is programmable. It can occur anywhere in the pattern generator cycle.

Select the oscilloscope Trigger Menu. Set the oscilloscope to trigger

on signals of interest in the circuit under test.

6 Select the state analyzer Trigger Menu. Set the analyzer to trigger on

addresses, data, or status conditions of interest, and to store any state or states of interest.

7 Select Group Run from the upper right corner of the display.

The pattern generator will begin its cycle, and will arm the oscilloscope and state analyzer.

In the early stages of system desi gn and i ntegration, you may want to test a circuit when the driving hardw are that will stimulate it has not yet been designed or fabricated. You can als o use t he patt ern generators with the logic analyzer to test PC boards when no board-test system is available.

The HP 16520A and HP 16521A patte rn generators for the HP 16500B avoid the inconvenience of having to stack s everal signal generators on top of each other, with all of the cable connections required for those signal gen erators. Additionally, you have a sing le interface to access all the test modules in you r measurement.

217

Intermodule Measurements

Using stimulus-respons e to t est a circui t

Stimulus -Response Setup

See Also The HP 16520A User’s Reference for the procedures for operating the

pattern generator.

Intermodule Measurements

lysi

To use a state analyzer to trigger tim ing ana

data lines

To use a state analyzer to trigger timing analysis of a count-down on a set of data lines

1 Select the Intermodule menu. 2 Select the state analyzer from the Modules list and set it to Group

Run. Select the timing analyzer and set it to respond to the arm signal from the state analyzer.

3 Select the state analyzer Trigger menu. 4 Set the state analyzer to trigger on the label and term that identify the

start of the count-down routine.

If you are not familiar with the procedures for setting up a trigger condition, see chapter 1.

In the timing analyzer Trigger Menu, set the timing analyzer to trigger

on any state and store any state.

6 Select Group Run from the upper right corner of the display.

s of a count-

Your target system may inclu de various state machines that are started by system events: interrupt processing, I/O activity, and the like. The state analyzer is ideal for recognizing the system events; the timing analyzer is ideal for examining the step-by-s tep operation of the state machines.

219

Intermodule Measurements

To use two state analyzers to moni tor t he acti vi ty of coprocessors in a target system

To use two state analyzers to monitor the activity of coprocessors in a target system

1 Select the Intermodule menu. 2 Select the first state analyzer from the Modules list and set it to

Group Run. Select the second state analyzer and set it to respond to the arm signal from the first analyzer.

3 Select the Trigger menu of the first analyzer. 4 Set the first analyzer to trigger on the problem condition.

Some problems may involve complex sequences of conditions. See chapter 1,

“Triggering,” for more information on defining a trigger sequence.

Select the Trigger menu of the second analyzer.

5 6 Set the second analyzer to trigger on any state and store any state. 7 Select Group Run from the upper right corner of the display.

After the measurement is complete, you can interleave the trace lists of both state analyzers to see the activity executed by both coprocessors during related clock cycles.

You can use a similar procedure if you have only one processor, but wish to monitor its activity with that of other system nodes, such as chip-select lines, I/O activity, or behavior of a watchdog timer. In some instances it may be easier to look at related activity with a timing analyzer.

See Also “Special Displays” in this chapter.

“To use a state analyzer to trigger timing analysis of a count-down on a set of data lines” in this chapter.

Debugging coprocessor systems can be a complex task. Replicated systems and contention for shared re sources increase the potential probl em s. Us i ng two state analyzers with preprocessors can make it much easier to discover the source of such problems . For example, you may wish to set up one analyzer to trigger only when a certain problem occurs, and set up the other analyzer to be armed by the first analyzer so that it ta kes its tr ace onl y when the first analyzer recognizes its trigger. This will let you observe the behavior of both coprocessors during th e occurrence of a problem.

Special displays

Interleaved Trace Lists

Interleaved trace lists allow you to view data captured by two or more analyzers in a single trace list. When you interleave the traces, you see each state that was captured by each analyzer. These states are shown on consecutive lines.

You can interleave state listings from HP 16510B, 16540A, 16540D, and 16550A state analyzers, when two or more are used together in a group run. Interleaved state listings are useful when you are using multiple analyzers to look at interaction between two or more processors. They are also useful when you need more analysis width than is available in one analyzer.

Mixed Display Mode

The Mixed Display mode allows you to show state listings and waveforms together on screen, if all were obtained by modules within the HP 16500B and 16501A frame. State listings are shown at the top of the screen and waveform displays are shown at the bottom. You can interleave state listings from two analyzers at the top of the screen, if desired. You can display waveforms from two oscilloscopes or timing analyzers at the bottom of the screen.

221

Intermodule Measurements

To interleave trace lists

1 Set up the analyzers whose data you wish to interleave as part of a

group run.

You won’t need to do this if the two measurement modules for which you want mixed display are really part of the same module. For example, you might have an HP 16550A state/timing analyzer configured as two separate analyzers, one a state analyzer, the other a timing analyzer. You can use mixed display to view the timing analyzer waveform with the trace lists from the state analyzer.

Select the first state analyzer whose trace list will be shown in the

interleaved display.

3 Select Trigger from the menu field and set Count to Time.

The system uses the time stamps stored with each state to determine the ordering of states shown in an interleaved trace list.

Repeat steps 2 and 3 for the second state analyzer.

4 5 Select Listing Display from the Menu field. 6 Select one of the label fields in the trace list display, then select

Interleave.

7 Select the name of the analyzer whose trace list will be interleaved

with the first analyzer. Then choose the label that you want to interleave from the selected analyzer.

Interleaved data is displayed in yellow. Trace list line numbers of interleaved data are indented. The labels identifying the interleaved data are shown above the labels for the current analyzer, and are displayed in yellow.

If you have problems with the procedure, and you are using two independent analyzers, first ensure that the analyzers are set up as part of a group run. Ensure that each analyzer is set to Count Time and that each analyzer has an independent clock from the target system.

You can interleave trace lists fr om sta te analyzers that were configured as part of a group run or from state analyze rs tha t are configured as separate analyzers within the same measurement module. In the first case, you might have t wo HP 16550A analyzers confi gured i n a group run; in the second, you might have a single HP 16550A configured as two state analyzers. The interleaved trace li sts are shown as a time-correlat ed, sta te-t o-st ate display.

Labels for the interleaved states are shown above those for the primary analyzer.

Interleaved states are shown in yel low w ith line number s indented from those of the primary an alyzer.

Intermodule Measurements

To interleave trace lists

Interl eaved Trace Lists on the HP 16550A

See Also “To set up a group run of modules within the HP 16500B” in this chapter.

223

Intermodule Measurements

To view trace lists and waveforms together on the s ame display

To view trace lists and waveforms together on the same display

1 Set up the modules whose data you wish to view as part of a group

run.

Select the module for which you wish to show waveforms.

This might be an oscilloscope module or a timing analyzer.

Select the label field to the left of the waveform display area twice,

then choose the waveforms to be shown.

When you double-select the label field to the left of the waveform display area, a new menu appears that allows you to insert and delete signals and choose the relative display size and position for the signals.

Select the state analyzer.

4 5 Set the Trigger menu of the state analyzer and set the Count field to

Time.

Timing analyzers and digitizing oscilloscopes implicitly count time because their sampling is driven by an internal clock, rather than an external state clock. See the manual for your logic state analyzer for details on how to count time with the analyzer.

To insert state listings, select any label field from the state listing.

From the popup that appears, select the desired label to insert.

7 Select Mixed Display from the menu field. 8 Select Group Run from the upper right corner of the display.

You can position X and O Time markers on the waveform display, if desired. Once set, the time markers will be displayed in both the listing and the waveform display areas. Note that even if you set X and O Time markers in another display, you must also set the Time markers in the Mixed Display if Time markers are desired.

Skew Adjustment

You can modify the skew or timing deviation between modules within the intermodule measurement. This allows you to compensate for any known delay of the system under test, or to compare two signals by first removing any displayed skew between the signal channels.

Skew adjustments can correct module delays to within 2 ns of other modules. Note that the module or channel that is used as the trigger is normally the reference channel, and adjustments are normally made to deskew the nonreference channels.

Intermodule Measurements

dul

To adjust for minimum skew bet ween two mo

measurement

To adjust for minimum skew between two modules involved in an intermodule measurement

1 Connect an input signal from each module to the same signal.

An ideal signal for testing skew is a single-shot signal with fast risetime. Such a signal simplifies triggering and makes it easier to correlate the input event between the modules. Ensure that you use proper probe grounding for maximum signal fidelity.

Select the Intermodule menu.

2 3 Set up both modules so they will begin searching for the trigger

immediately when a group run begins.

This setup focuses mostly on trying to eliminate probe skew and internal triggering delays. You can use other intermodule setups as well. For example, you may be interested in nullifying the effects of the internal arming delay in a setup where one module arms another.

Set up the trigger conditions for each module.

This will depend upon your input signal. For example, if you are adjusting intermodule skew using a single-shot pulse with a rising edge, set a timing analyzer to trigger on a rising edge using the Edge1 term, and the oscilloscope to trigger on a positive slope.

Select the Display or Waveform menu in one of the modules.

5 6 Set up the display so that both input waveforms are displayed

simultaneously.

You do this by selecting the label field to the left of the display twice. The second selection brings up a new menu that allows you to insert or delete waveforms. You can delete all but the waveform of interest from the first module, then add the waveform of interest from the second module. Select Done when finished.

Select Group Run.

You may now need to trigger the signal of interest, if, for example, it is activated by a push button. You may need multiple events to capture good waveforms for both measurement modules. Remember that the oscilloscope captures far more accurate waveform data than the timing analyzer. Thus, if the waveforms do not match exactly, it may only be because the waveform edge did not meet the timing analyzer’s setup and hold time specifications for a particular sampling period.

es involv

227

Intermodule Measurements

To adjust for minimum skew bet ween two modules involved in an inte rm odule measurement

Record the difference between waveform events shown by the two modules.

You can use the X and O markers to measure the differences in delays.

Select the Intermodule Menu.

10 Select Skew, then enter a skew correction value for one of the

modules using the knob or the keyboard.

11 Return to the module waveform display and recheck the skew

adjustment.

You will need to repeat steps 7 through 11 as needed until the trigger events on the two waveforms match as closely as possible.

Before making an intermo dul e me asurement, you should remove skew between the modules to ensure that a simu ltaneous arm signal to both modules results in captures of the same events around the trigger.

Skew Removal Between Timing Analyzer and Oscil loscope

File Management

A host computer such as a PC or UNIX workstation can enhance the

HP 16500B in many ways. You can use the host to store configuration files or measurement results for later review. Screen images from the HP 16500B can be saved in bitmap files for inclusion in reports developed using word processors or desktop publishing tools. Or, you can develop programs on the PC that manipulate measurement results to satisfy your problem-solving needs.

This chapter shows you some examples of how to transfer files between a host computer and the HP 16500B, using the flexible disk drive and the optional HP 16500L LAN Interface. If you aren’t familiar with basic flexible disk drive operations, see the HP 16500B/16501A User’s Reference. If you need help setting up or understanding the use of the HP 16500L LAN Interface, see the HP 16500L LAN

Interface User’s Guide.

You can also use a host computer to send the HP 16500B complex

command sequences—allowing you to automate your measurement tasks. If you want to program the HP 16500B using a host computer, see the HP 16500B/16501A Logic Analysis System Programmer’s Guide and the HP 16500L LAN User’s Guide.

Transferring Files Using the Flexible Disk Drive

Because the flexible disk drive on the HP 16500B will read and write double-sided, double density or high-density disks in MS-DOS format, it is a useful tool for transferring images to and from IBM PCcompatible computers as well as other systems that can read and write MS-DOS format. You can save measurement configuration files, measurement results, and even menu and measurement images from the screen.

This section shows you how to use the flexible disk drive to:

• save a measurement configuration

• load a measurement configuration

• save a trace list in ASCII format

• save a screen image (such as an oscilloscope display or menu)

• load system software

If you need more information on the basic flexible disk drive operations, see the HP 16500B/16501A Logic Analysis System

User’s Reference.

File Management

To save a measurement conf iguration

To save a measurement configuration

You can save measurement configurations on a 3.5" disk or on the internal hard disk for later use. This is especially useful for automating repetitive measurements for production testing.

Select System from the module field.

1 2 Select Hard Disk or Flexible Disk from the menu field. 3 Select Store from the disk operations field. 4 Select the module for which you want to save the configuration from

the module list.

You can save the configuration for individual modules. The choice “System” saves only the mainframe configuration. The choice “All” saves the mainframe configuration and that of all measurement modules.

Specify a file name into which to save the configuration using the “to

file” field.

6 Specify a descriptive comment for the file using the “file description”

field.

7 Select Execute.

Saving the Oscilloscope Configuration for Skew Testing

File Management

To save a measurement conf iguration

If you want to save your file in a directory other t han the root, you can select Change Directory from the disk operations field. Then type the name of the desired directory in the direc tory nam e fiel d, or select it from the list of visible directories using the knob.

File Management

To load a measurement confi guration

To load a measurement configuration

You can quickly load a previously saved measurement configuration, saving the trouble of manually setting up the measurement parameters for each module.

Select System from the module field.

1 2 Select Hard Disk or Flexible Disk from the Menu field.

Your choice here depends on where you saved the configuration.

Select Load from the disk operations field.

4 Select the module for which you want to load a configuration from

the module list.

You can load configurations for individual modules. The choice “System” loads only the mainframe configuration. The choice “All” loads the mainframe configuration and that of all measurement modules.

However, you can only load configurations that are defined in the configuration file itself. Thus, if you select System, then select a file that contains only an analyzer configuration, the configuration will fail.

If you save an analyzer configuration as “All,” then attempt to reload that configuration into a particular measurement module, configuration will fail. Also, configurations are slot dependent. If you save a configuration for a particular module, rearrange the modules within the HP 16500B, then try to reload the configuration, the configuration will not load.

Specify a file name from which to load the configuration using the

“from file” field.

6 Select Execute.

File Management

To load a measurement confi guration

Loading Configuration for all HP 16500B Modules and the System

File Management

To save a trace list in ASCII format

Some HP 16500B displays, such as file lists and trace lists, contain columns of ASCII data that you may want to move to a PC for further manipulation or analysis. You can save these displays as ASCII files, using a procedure similar to that for creating graphics images. While a graphics capture saves only the data shown onscreen, saving the display as an ASCII file captures all data in the list, even if it is offscreen.

Insert a DOS-formatted 3.5" disk in the flexible disk drive.

1 2 Set up the menu you want to capture, or run a measurement from

which you want to save data.

Remember that only displays that present lists of textual data can be captured as ASCII files.

Select Print Disk from the Print menu.

3 4 Select the Filename field and specify a file name to which the screen

will be printed.

5 Select ASCII (ALL) from the Output Format field.

If the current display contents can’t be saved as an ASCII file, this option will not be present in the Output Format field.

Select Flexible Disk from the Output Disk menu.

6 7 Select Execute.

File Management

To save a trace list in ASCII format

68332EVS - State Listing

Label ADDR CPU32 Mnemonic STAT __________ _____ ______________________________________ _________________

0 406F4 ANDI.L #********,(A6)+ Opcode Fetch 1 0FF7A 0004 data write Data Write 2 0FF7C 06F6 data write Data Write 3 40992 BSR.B 0004093E Opcode Fetch 4 40994 nu MOVE.B ********,(****,A7) Opcode Fetch 5 0FF76 0004 data write Data Write 6 0FF78 0994 data write Data Write 7 4093E MOVE.W #03FF,00FFFA46 Opcode Fetch 8 40940 03FF pgm read Opcode Fetch 9 40942 00FF pgm read Opcode Fetch 10 40944 FA46 pgm read Opcode Fetch 11 40946 MOVE.W #6B70,00FFFA72 Opcode Fetch 12 40948 6B70 pgm read Opcode Fetch 13 4094A 00FF pgm read Opcode Fetch 14 4094C FA72 pgm read Opcode Fetch 15 4094E RTS Opcode Fetch 16 40950 nu MOVE.L D1,-(A7) Opcode Fetch 17 0FF76 0004 data read Data Read 18 0FF78 0994 data read Data Read 19 40994 MOVE.B 00020001,(0004,A7) Opcode Fetch 20 40996 0002 pgm read Opcode Fetch 21 40998 0001 pgm read Opcode Fetch 22 4099A 0004 pgm read Opcode Fetch

Part of a Trace Listing Saved as an ASCII File

File Management

To save a menu or measureme nt as a graphic image

To save a menu or measurement as a graphic image

You can save menus and measurements to disk in one of four different graphics formats.

Insert a DOS-formatted flexible disk in the flexible disk drive.

1 2 Set up the menu whose image you want to capture, or run a

measurement from which you want to save data.

3 Select Print Disk from the Print menu. 4 Select the Filename field and specify a file name to which the screen

will be printed.

5 Select the Output Format field and specify the output format for the

graphics file.

Choose one of the following formats:

B/W TIF (SCREEN) is a black and white Tagged Image File Format file in

•

TIFF version 5.0 format

Color TIF (SCREEN) is a color TIFF file in TIFF version 5.0 format

•

PCX (SCREEN) is a color PCX file (PCX is the PC Paintbrush and

•

Publisher’s Paintbrush format from ZSoft)

EPS (SCREEN) is a black and white Encapsulated PostScript file

•

Select Flexible Disk from the Output Disk menu.

6 7 Select Execute.

File Management

To save a menu or measureme nt as a graphic image

An Oscilloscope Display Saved as a TIF Image

311

File Management

To load system software

1 Insert the first disk containing the system software. 2 Select System from the module field. 3 Select Hard Disk from the menu field. 4 Select Change Directory from the disk operation field. 5 Select the directory SYSTEM using the knob, and select Execute. 6 Select Flexible Disk from the menu field. 7 Select Copy from the disk operation field. 8 Select the file you want to update using the knob, then select

Execute.

The selected file is copied to the \SYSTEM directory on the hard disk. Repeat steps 7 and 8 for all files you need to update. If you have more than

one disk from which you want to copy files, turn the knob after changing disks. This ensures that the HP 16500B will read the directory on the new disk.

Using the HP 16500L LAN Interface

The HP 16500L LAN Interface option for the HP 16500B extends the Logic Analysis System by making it look like a NFS (Network File System) node. Using NFS utilities for the PC or NFS on a UNIX workstation, you can transfer files to and from the HP 16500B as if it were a disk drive attached to your machine. The LAN Interface also creates virtual directories and files for measurement configurations and measurement results, so you can store and retrieve these as though they were ordinary files.

This section shows you how to use the HP 16500L to do the following:

• set up the HP 16500B configuration

• retrieve measurement data from a module in the HP 16500B

• transfer images of HP 16500B menu and result screens to your host

computer

If you have not connected your HP 16500B to the network, installed network software, or learned basic network commands, see the

HP 16500L User’s Guide and the HP 16500L System Administrator’s Guide before performing the tasks in this chapter.

313

File Management

To set up the HP 16 500B

To set up the HP 16500B

You can set up the HP 16500B from the front panel, or via the LAN. To set up the system via the LAN, you can use one of three methods:

Copy a configuration file from your PC or workstation to one of the files

•

called setup.raw in the HP 16500B directory tree.

Remotely load a configuration file into the system from one of the local

•

disk drives of the HP 16500B.

Program the system directly, using the programming commands described

•

in the HP 16500B System Programmer’s Guide.

Example You want to load a configuration file called “486_bus” from your local

computer into an HP 16550A state/timing module. The HP 16550A is installed in slot B of the HP 16500B mainframe. The mainframe is mounted on your network as disk drive L: (assuming you are using a PC as the host).

To load the configuration file, enter the following at the DOS prompt:

C:\> copy 486_bus L:\slot_b\setup.raw

If you are using a UNIX system, you might use the cp command. In the Microsoft Windows environment, you can use the File Manager.

File Management

To set up the HP 16 500B

Example You want to load a configuration file called “486_bus” from the hard disk of

the HP 16500B into an HP 16550A state/timing module. The HP 16550A is installed in slot B of the HP 16500B mainframe. To load the configuration file from the HP 16500B hard disk, you need to send the programming command to the analyzer. The syntax of the command is:

:MMEMory:LOAD:CONFig <filename>[,<disk drive>][,<slot number>] In this case, the disk drive parameter, will be “INT0,” which indicates the

hard disk. The slot number will be 2, because the HP 16550A is installed in slot B. To load the configuration file, enter the following command at the DOS prompt:

C:\> echo :MEM:LOAD:CON ’486_BUS’,INT0,2 L:\system\program

If you are using a UNIX system, you can use the UNIX echo command.

See Also Chapter 4, “Programming the HP 16500B System via the LAN,” in the

HP 16500L User’s Guide, for more information on programming the system directly.

The HP 16500B System Programmer’s Guide for more information on programming command syntax.

To copy files to the setup.raw file locations, or to send commands to the sy ste m at the \system\program file location, you must be connected to the H P 16500 B system as the control user.

315

File Management

To transfer data files from the HP 165 00 B s ys tem to your com puter

To transfer data files from the HP 16500B system to your computer

You can transfer data from the HP 16500B system to your PC or workstation by copying files. Data files in binary format are available in file locations \slot_x\data.raw. These binary files can be transferred to your computer and then reloaded into the HP 16500B system later.

For some types of measurement modules, data files in ASCII format are also available. The ASCII data files are in file locations

\slot_x\data.asc\{analyzer name}\{label name}.txt

Depending on which measurement module you are using, there might not be a subdirectory corresponding to an analyzer name. There is an ASCII data file corresponding to each label name you have created in the measurement module.

Set up the system for the measurement you want to make.

You can do this from the front panel or remotely.

Run the analyzer to acquire data.

You can do this from the front panel or remotely.

If you would like the data in binary format, copy the file data.raw to

your computer from the file location \slot_{ x }\data.ra w

The x represents the slot in which the measurement module is installed.

If you would like the data in ASCII format, copy the files corresponding to the labels you want to view from the file location

\slot_{x}\da ta.asc\{analyzer name}\{label name}.txt

Depending on which measurement module you are using, there might not be a subdirectory corresponding to an analyzer name.

See Also Chapter 3 of the HP 16500L LAN User’s Guide describes the contents of the

binary data.raw file.

File Management

To transfer data files from the HP 165 00 B syst em to yo ur com p

Example You have an HP 16550A state/timing analyzer installed in slot C of your

HP 16500B mainframe. The name of analyzer 1 of the HP 16550A is 68000_BUS. You have created some labels under analyzer 1 of the

HP 16550A, including one called “addr_lo.” The directory structure of the HP 16500B system looks like this:

After setting up a measurement and acquiring data, you want to analyze the data for label addr_lo on your PC. To copy the ASCII data to your local computer, enter the following command at the DOS prompt:

C:\ copy L:\slot_c\data.asc\68000_bus\addr_lo {local path name}

If you are using a UNIX system, you might use the cp command. In the Microsoft Windows environment, you can use the File Manager.

See Also “Measurement Module Subdirectories,” in chapter 3 of the HP 16500L LAN

User’s Guide, for more information about the files that are available for

measurement modules.

317

To transfer graphics files from the HP 16500B system

The current display of the HP 16500B is available in four different formats.

You can also save the current display to a file on one of the local HP 16500B

disk drives, using the Print to Disk function. You can then transfer the file

These graphics files contain the current display on the HP 16500B scr een. The

one of the graphics files, the display will freeze for a few moments while the

File Management

To transfer graphics files from the H P 165 00 B syst em to your com puter

to your computer

1 Set up the display you want to transfer. 2 Copy the file in the format of your choice from the directory

\system\graphics.

The file screen.tif is a color Tagged Image File Format file, in TIFF version

•

5.0 format. The file screenbw.tif is a black and white TIFF file in TIFF version 5.0

•

format. The file screen.pcx is a color PCX file. (PCX is the standard format of PC

•

Paintbrush and Publisher’s Paintbrush.) The file screenbw.epi is a black and white Encapsulated PostScript file in

•

EPS version 3.0 format.

from the HP 16500B drive to your computer.

contents of the files change whenever you change the display. Whe n you copy HP 16500B is copying the current display.

Example To copy a PCX picture of the current screen display to your computer, enter

the following command at the UNIX command prompt:

$ cp /logic/system/graphics/screen.pcx {local path name}

If you are using a DOS system, you can use the copy command. In the Microsoft Windows environment, you can use the File Manager.

Concepts

Understanding how the analyzer does its job will help you use it more effectively and minimize measurement problems. This chapter explains the general operation of the trigger sequencer and the inverse assembler.

The Trigger Sequencer

Logic state and timing analyzer modules for the HP 16500B have triggering and data storage features that allow you to capture only the system activity of interest. Understanding how these features work will help you set up analyzer trigger specifications that satisfy your measurement needs.

There are several different logic analyzers available for the HP 16500B. This discussion will focus on the HP 16550A, a 100-MHz state/500-MHz timing analyzer. Most HP logic analyzers will be similar, differing only in the number of available states, pattern resources, range resources, and acquisition memory depth.

In the HP 16550A state analyzer, the trigger sequencer is a state machine with a minimum of two states and a maximum of twelve states. The trigger term can be any one of these states except the last. The analyzer searches for a trigger sequence by matching input values on the pods to branch conditions, which control transitions between states. You can insert or delete states to make the trigger sequence as simple or complex as needed for your application.

Trigger Sequence Specification

See the following figure, which shows a sequence specification with four states. To define the trigger sequence, you specify sequenceadvance, sequence-else, storage, and trigger-on specifications.

Concepts

A sequence-else specification can branch to the same state...

to a previous state...

or a later state.

State Analyzer Sequencer with Four State s

Each state, except for the last, has two branch conditions. These are the sequence-advance and sequence-else specification. (The triggeron specification is a special sequence-advance specification that is

described in the section “TRIGGER On Specification.”)

Sequence-advance specifications always branch to the next state.

Each state can have a unique st orage specification.

Sequence-Advance Specification

The sequence-advance branch, sometimes called the “if” branch or primary branch, always branches to the next higher-numbered state. You can specify the following kinds of sequence-advance specifications:

Find (or Then find) “<TERM>” <OCCURS> time(S) Find (or Then fin d) “<TERM>” <TIME PERIOD>

If the Find (or Then find) “<TERM>” is found <OCCURS> number of times, the sequencer advances to the next sequence level.

If the <TERM> remains stable for <TIME PERIOD>, the sequencer advances to the next sequence level.

Concepts

Sequence-Else Specification

The sequence-else branch, sometimes called the “else if” branch or secondary branch, may branch to any other state, including the current state, a previous state, or a later state. The sequence-else specification looks like the following:

Else on “<TERM>” go to level <sequence level>

If the Sequence-Else specification is satisfied before the sequenceadvance specification is satisfied, the sequencer begins at <sequence level>.

The last state may only have a sequence-else branch specification, which may branch to the same state or a prior state.

Storage Specification

In each state, a storage specification determines the data stored by the analyzer while it is searching for the sequence-advance, sequenceelse, and trigger specifications. Storage specifications are defined using the same pattern, range, and timer resources available for defining branching specifications.

While storing “anystate”, “no state”, or “<TERM>”

Note that if you specify “no state,” the analyzer still stores sequenceadvance terms and TRIGGER terms.

TRIGGER On Specification

If there are branch and storage specifications for each sequence level, what does the trigger term mean? The trigger term is a special sequence-advance specification in that, when found, it locks the contents of analyzer acquisition memory. The trigger can be positioned at the beginning, middle, or end of acquisition memory.

The trigger specification can look like the following:

TRIGGER on “<TERM>” <OCCURS> times TRIGGER on “<TERM>” <TIME PERIOD>

If the trigger term is found <OCCURS> times, or if the trigger term remains stable for <TIME PERIOD>, the trigger is captured in memory. Then the sequencer advances to the next sequence level. If

Concepts

you want to capture activity after the trigger is captured, define an additional sequence level and specify the desired storage qualification

for post-trigger activity (for example, store “anystate”).

Analyzer Resources

The sequence-advance, sequence-else, storage, and trigger-on specifications are set by a combination of up to 10 pattern terms, 2 range terms, and 2 timers. Different analyzer models may vary in the number of resources available.

10 Pattern Terms

The pattern terms, a through j, represent single states to be found on labeled sets of bits. For example, you could have an address on the address bits or a status on the status bits.

2 Timers

You can start, stop, continue, or pause the timers upon entry to a sequence state, then use a comparison of current timer value against a preset value to determine whether to branch to another state.

2 Range Terms

The range terms, Range1 and Range2, represent ranges of values to be found on labeled sets of bits. For example, you could have a range of addresses to be found on the address bus or a range of data values to be found on the data bus. Range terms are satisfied by any value within the range for “In_Range,” and any value outside the range for “Out_Range.”

You can combine the pattern terms and range terms with logical operators to form complex pattern expressions in the sequenceadvance, sequence-else, and TRIGGER on specifications.

For example,

Find “<TERM1>+<TERM2>” OR <TERM1> and <TERM2> Find “<TERM1> .<TERM2>” AND <TERM1> and <TERM2>

oncepts

Where <TERM> can be a single value on a set of labels, any value within a range of values on a set of labels, or a glitch or edge transition on a bit or set of bits.

Limitations Affecting Use of Analyzer Resources

There are limitations on the way resources can be combined to form complex pattern expressions. Resources are combined in a four-level hierarchy. First, resources are divided into two groups. The groups can be combined with AND or OR. Second, within these groups, resources are combined into pairs. Pairs can also be logically combined using AND or OR. Third, individual resources are combined into pairs using AND, NAND, OR, NOR, XOR, NXOR. Fourth, individual resources may be included or excluded from participating in a pattern expression. You can also include the logical negation of the resource.

The following table shows how resources are divided in the HP 16550A. Remember that some resources may not be available, depending on the analyzer configuration. For example, if you are using the analyzer as a state analyzer, the Edge1 and Edge2 resources are not available. If the timers are off, the Timer1 and Timer2 resources are not available.

Can combine groups with AND or OR Group 1 Group 2 Can combine pairs with AND or OR within a group Pair 1 Pair 2 Pair 3 Pair 4 Pair 1 Pair 2 Pair 3 Pair 4 Combine Resou rces into pairs using AND, NAND, OR, NOR, NXOR Include or ExcludeResour ces

on,

on, off, neg ate

on,

off,

neg

neg ate

ate

abcRan

on,

off,

neg

ran

ate

ge, out of ran ge

dEdge1eTim

ge1

on, off, neg ate

off,

on,

>, <

off,

neg

neg ate

ate

f ghRan

er1

off,

neg

ran

ate

ge, out of ran ge

iEdge2jTim

ge2

off, >, <

er2

Concepts

So, the following combinations are valid combinations for the state analyzer, if timers are on:

(a+b) • (In_Range2 + Timer2 > 400 ns) (c • Out_Range1) + (f xor g)

The following combinations are not valid, because resources cross pair boundaries:

(a + c) (d + Timer1 < 400 ns)

The first example shows that a and c cannot be combined at the first level. You can get around this, however, by combining them at the second level. The following figure shows the possible combinations of the a, b, c and Range1 terms:

Combining a, b, c, and Range1 Ter ms

The following combination is not valid, because pairs cross group boundaries:

((a+b) + (h • In_Range2)) • (j xor Timer2 > 400 ns)

Note that the analyzer interface will not allow you to enter invalid combinations, however, you need to be aware of what combinations are legal, so that you can make the desired measurement.

Another limitation is that the analyzer cannot handle ranging for input pods that are assigned to different analysis IC’s. For example, if you need to define a 32-bit range term, you must do it using pods 1/2, 3/4,

Concepts

or 5/6. Trying to define a range across pods 2/3, 4/5, or 1/6 will not work.

The Timing Analyzer

When you configure the HP 16550A as a timing analyzer, the trigger sequencer is similar. However, there are between 1 and 10 states available. The trigger term is always the last state. There are two additional resources, Edge1 and Edge2. These can recognize occurrences of a glitch, or occurrences of a rising edge, falling edge, either edge, or no edge on a bit or ORed set of bits represented by a glitch/edge term.

The Inverse Assembler

When the analyzer captures a trace, it captures binary information. The analyzer can then present this information in binary, octal, decimal, hexadecimal, or ASCII. Or, if given information about the meaning of the data captured, the analyzer can inverse assemble the trace. The inverse assembler makes the trace list more readable by presenting the trace results in terms of processor opcodes and data transactions.

The inverse assembly software needs five pieces of information:

• Address bus. The inverse assembler expects to see the label ADDR,

with bits ordered in a particular sequence.

• Data bus. The inverse assembler expects to see the label DATA,

with bits ordered in a particular sequence.

• Status. The inverse assembler expects to see the label STAT, with

bits ordered in a particular sequence.

• Start state for disassembly. This is the first displayed state in the

trace list, not the cursor position. See the figure below.

• Tables indicating the meaning of particular status and data

combinations.

When you press the Invasm key to begin inverse assembly of a trace, the inverse assembler begins with the first displayed state in the trace list. This is called synchronization. It looks at the status bits (STAT) and determines the type of processor operation, which is then displayed under the STAT label. If the operation is an opcode fetch, the inverse assembler uses the information on the data bus to look up the corresponding opcode in a table, which is displayed under the DATA label. If the operation is a data transfer, the data and corresponding operation are displayed under the DATA label. This continues for all subsequent states in the trace list.

The invers e assembler synchronizes at the first line in the trace list...

not at the cursor position

Concepts

Inverse Assembly Synchronization

If you roll the trace list to a new position and press Invasm again, the inverse assembler repeats the above process. However, it does not work backward in the trace list from the starting position. This may cause differences in the trace list above and below the point where you synchronized inverse assembly. The best way to ensure correct inverse assembly is to synchronize using the first state you know to be the first byte of an opcode fetch.

For processors with a pipeline or instruction queue, the information presented to the analyzer can potentially become confusing. Was an instruction executed or not? Active circuitry on some preprocessor models helps by sorting out the order of execution before presenting information to the analyzer. You can set switches on the preprocessor to control whether this dequeueing is enabled.

411

trace list, the symbol lookup happens independently of inverse as sembl y. Thus,

Concepts

Symbols

When you specify symbols as the format for displaying the address bus in the you can have symbols in the addr ess fiel d wit hout inverse-assembled data and

status. The HP E2450A symbol download utility allows you to download symbols from OMF (Object Module Format) files.

Configuration Translation for Analyzer Modules

Configuration files provide an easy way for you to save and restore measurement setups, simplifying repeated measurements. However, sometimes you might change analyzer modules in the HP 16500B Logic Analysis System to gain additional measurement features. Or, you might want to use a configuration file from one HP 16500B system on another HP 16500B with a different analyzer module. But, the analyzer configuration files cannot be transferred directly from one type of analyzer to the next. Each analyzer has internal architectural differences, reflected in the number of pods, clock configurations, trigger sequencer features, analyzer resources, and so on.

To help you move configuration files from one analyzer to another, some analyzer measurement modules for the HP 16500B Logic Analysis System support automatic translation of analyzer configurations. If you save an analyzer configuration from one kind of analyzer module, then load that configuration into a module that supports configuration translation, the translator will adjust the configuration as required to account for differences between the modules.

The configuration translator needs to account for many aspects of the analyzer architecture. Some of the considerations are as follows:

• For some analyzers, demultiplexing data will require separate

analyzer pods, because a master clock and a slave clock can’t be assigned on the same pod to perform the demultiplexing. The translator may display messages on the analyzer screen that ask you to reconnect pod cables in a different configuration.

• When a range term is split across multiple pods, the term must span

adjacent odd/even pairs, starting with 1. Thus, terms could span pods 1 and 2, 3 and 4, 5 and 6, or 7 and 8, but not 2 and 3. Again, the translator may display messages asking you to reconnect cables in a different configuration.

• When loading a configuration into an analyzer with fewer pods than

the one on which the configuration was saved, the translator must

413

Concepts

remove pod assignments. Which pods are removed from the configuration will depend on the widths of each pod in the original analyzer and new analyzer.

The configuration translation also needs to account for many differences in the format and trace menus between the analyzers, including

• label names,

• polarities,

• thresholds,

• symbols,

• clocking,

• number of sequence levels,

• branch conditions, and

• patterns,

among others.

To ensure that trace measurements act as expected when you move configuration files from one analyzer to another, follow these recommendations:

• Ensure that the analyzer pods are hooked up as required by the

configuration translation and the new analyzer. The onscreen messages given by the translator will help you identify which analyzer pods must be swapped. If you are using an HP preprocessor, the Preprocessor User’s Guide may contain information showing the cable connections for different analyzer modules.

• Review all trace format and trigger menu settings to verify that they

will meet your measurement requirements. You should check label assignments, channel masks, pattern and range definitions, sequencer setup, and general analyzer configuration (which pods are mapped to each analyzer).

for future reference, see “To sa ve a tr ace l ist in ASC II format” in chapter 3.

Concepts

When you move a configurati on fil e from one analyzer to another, the trace data from previous measurements is not moved. If you need to store trace data

415

Agilent 16500B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

HP 16500B—At a Glance

In This Book

Con tents

Triggering

To store and time the execution of a sub routi ne

To trigger on the nth iteration of a loop

To trigger on the nth recursive call of a recurs ive function

To trigger on entry to a function

To capture a trace of activity associated with a write of known bad data to a particular variable

To trigger on a loop that occasionall y runs too long

To verify that all stacks and registers are restored correctly before exiting a subroutine

To trigger after all status bus lines f ini sh tran si tio ning

To find the nth occurrence of asserting a chip select line

To verify that the chip select line of a memory chip is strobed after the address on the address bus is stable

To trigger when expected data does not appear on the data bus from a rem ote device when requested

To test minimum and maximum puls e li m its

To detect a handshake violation

To detect bus contention

Cross-Arming Trigger Examples

To examine software execution when a timing violation occurs

To look at control and status signals during execution of a routine

Intermodule Measurements

Intermodule Measurement Examples

To set up a group run of modules within the HP 16500 B

To start a group run of modules from an external trigger source

To start an external instrument on command from a module within the HP 16500 and 16501 mainframe

To see the status of a module within an intermodule measurement

To see time correlation of each mod ule w ith in an in termodule measurement

To use a timing analyzer to detect a gli tch

To capture the waveform of a glitch

To capture state flow showing how your target system processes an interrupt

Using stimulus-response to test a circuit

To use a state analyzer to trigger timing analysis of a count-down on a set of data lines

To use two state analyzers to moni tor t he acti vi ty of coprocessors in a target system

Special displays

To interleave trace lists

To view trace lists and waveforms together on the s ame display

Skew Adjustment

To adjust for minimum skew between two modules involved in an intermodule measurement

File Management

Transferring Files Using the Flexible Disk Drive

To save a measurement conf iguration

To load a measurement confi guration

To save a trace list in ASCII format

To save a menu or measureme nt as a graphic image

To load system software

Using the HP 16500L LAN Interface

To set up the HP 16 500B

To transfer data files from the HP 165 00 B s ys tem to your com puter

To transfer graphics files from the H P 165 00 B syst em to your com puter

Concepts

The Trigger Sequencer

The Inverse Assembler

Configuration Translation for Analyzer Modules

If You Have a Problem
