HP 16048A Test Leads
Operation Manual
Second Edition
Hewlett-Packard Japan, LTD.
HP PN 16048-90001
November 1998
Printed in: Japan
Notices
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright.All
rights are reserved. No part of this document may be photocopied, reproduced, or
translated to another language without the prior written consent of the
Hewlett-Packard Company.
Hewlett-Packard Japan, LTD.
Kobe Instrument Division
1-3-2, Murotani, Nishi-Ku, Kobe-shi, Hyogo, 651-2241 Japan
© Copyright 1990, 1998 Hewlett-Packard Japan, LTD.
Manual Printing History
The manual’s printing date and part number indicate its current edition. The
printing date changes when a new edition is printed. (Minor corrections and
updates that are incorporated at reprint do not cause the date to change.) The
manual part number changes when extensive technical changes are incorporated.
1990 First Edition
November 1998 Second Edition
Safety Summary
The following general safety precautions must be observed during all phases of
operation, service, and repair of this instrument. Failure to comply with these
precautions or with speci fic WARNINGS elsewhere in this manual may im pair the
protection provided by the equipment. In addition it violates safety standards of
design, manufacture, and intended use of the instrument.
The Hewlett-Packard Company assumes no liability for the customer’s failure to
comply with these requirements.
• Ground The Instrument
To avoid electric shock hazard, the instrument chassis and cabinet must be
connected to a safety earth ground by the supplied power cable with earth
blade.
2
• DO NOT Operate In An Explosive Atmosphere
Do not operate the instrument in the presence of flammable gasses or fumes.
Operation of any electrical instrument in such an environment constitutes a
definite safety hazard.
• Keep Away From Live Circuits
Operating personnel must not remove instrument covers. Component
replacement and internal adjustments must be made by qualified maintenance
personnel. Do not replace component s with the power ca ble connected. Under
certain conditions, dangerous voltages may exist even with the power cable
removed. To avoid injuries, always disconnect power and discharge circuits
before touching them.
• DO NOT Service Or Adjust Alone
Do not attempt internal servi ce or adjus tment unl ess ano ther pe rson, ca pab le of
rendering first aid and resuscitation, is present.
• DO NOT Substitute Parts Or Modify Instrument
Because of the danger of introducing additional hazards, do not install
substitute parts or perform unau thorized mod ifications to the instrument.
Return the in strument to a Hewlett-Packard Sales and Service Office for
service and repair to ensure that safety features are maintained.
WARNING
• Dangerous Procedure Warnings
Warnings, such as the example below, precede potentially dangerous
procedures throughout this manual. Instructions contained in the warnings
must be followed.
Dangerous voltages, c apabl e o f ca usi ng de ath, are presenting thi s inst rument .
Use extreme caution when handling, testing, and adjusting this instrument.
Certification
Hewlett-Packard Company certifies that this product met its published
specifications at the time of shipment from the factory. Hewlett-Packard further
certifies that its calibration measurements are traceable to the United States
National Institute of Standards and Technology, to the extent allowed by the
Institution’s calibration facility, or to the calibration faciliti es of othe r Inte rnationa l
Standards Organization members.
3
Warranty
This Hewlett-Packard instrument product is warranted against defects in material
and workmanship for a peri od corresponding to the individual warranty periods of
its component products. Instruments are warranted for a period of one year.
Fixtures and adapters are warranted for a period of 90 days. During the warranty
period, Hewlett-Packard Company will, at its option, either repair or replace
products that prove to be defective.
For warranty service or repair, this product must be returned to a service facility
designated by HP. Buyer shall prepay shipping charges to HP and HP shall pay
shipping charges to return the product to Buyer. However, Buyer shall pay all
shipping charges, duties, and taxes for products returned to HP from another
country.
HP warrants that its software and firmware designated by HP for use with an
instrument will execute its programming instruction when property installed on
that instrument. HP does not warrant that the operation of the instrument, or
software, or firmware will be uninterrupted or error free.
IMPORTANT
Limitation Of Warranty
The foregoing warranty shall not apply to defects resulting from improper or
inadequate maintenance by Buyer, Buyer-supplied software or interfacing,
unauthorized modification or misuse, operation outside the environmental
specifications for the product, or improper site preparation or maintenance.
No other warranty is expressed or implied. HP specifical ly disclaims the implied
warranties of merchantability and fitness for a particular purpose.
Exclusive Remedies
The remedies provided herein are buyer’s sole and exclusive remedies. HP shall
not be liable for a ny direct, indirect, sp eci al , i nci dental, or consequential da mages ,
whether based on contract, tort, or any other legal theory.
4
Assistance
Product maintenance agreements and other customer assistance agreements are
available for Hewlett-Packard products.
For any assistance, co ntact your neare st Hewlett-Packard Sales and Serv ice Office.
Addresses are provided at the back of this manual.
Safety Symbol
General definitions of safety symbols used on the instrument or in manuals are listed below.
Instruction Manual symbol: the product is marked with this symbol when it is
!
necessary for the user to refer to the instrument manual.
WARNING
CAUTION
NOTE
This warning sign denotes a h azard. It calls at tention to a pr o cedur e, practic e,
condition or the like, which, if not correctly performed or adhered to, could
result in injury or death to personnel.
This Caution sign denotes a hazard. It calls attention to a procedure, practice,
condition or the like, which, if not correctly performed or adhered to, could result
in damage to or destruction of part or all of the product.
Note denotes important information. It calls attention to a procedure, practice,
condition or the like, which is essential to highlight.
5
6
Contents
1. Operation
Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Typical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Compensation for Fixture Residual Impedance Error . . . . . . . . . . . . . . . . . . . . . 13
2. Service
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7
Contents
8
1 Operation
This operating note provi des compl et e inf or mati on on t he HP 16048A T es t Lea ds.
The HP 16048A is shown pictorially in Figure 1-1, its physical dimensions are
given in Table 1-1, and typical characteristics related to offset error are given in
Table 1-2. To order additional copies of this operating note, use the part number
listed on th e rear cover.
9
Operation
Product Description
Product Description
The HP 16048A consists of a direct attachment, 4-t er minal pair type fixture which
is equipped w ith four BNC (m) terminated-coaxial test leads. These test leads are
used to attach user-fabricated test fixtures. DC bias levels of up to ±40V can be
applied to the HP 16048A. Cable length is 1 meter. The HP 16048A is shown in
Figure 1-1.
Figure 1-1 Product Overview
10 Chapter 1
Specifications
Table 1-1 Specifications of the HP 16048A
Function: For use with 4 terminal-pair LCR Meters and
Connector Type: BNC male Cable Length: Approximately 1m Maximum Voltage: ± 40V peak max. (AC+DC) Weight: 315 g
Operation
Specifications
Impedance Analyzers.
Chapter 1 11
Operation
0.02f10
----- -
×
2
±
Typical Characteristics
Typical Characteristics
Table 1-2 Typical Characteristics
Incremental error at freq. ≥1 MHz
Parameter reading
Offset value for D
error (%)
2
f
----- -
5
±
×
10
NOTE f is the meas urement frequency in megahertz. The increm ental errors calculated
from the equation in the table for measurements at frequencies above 1 MHz are
additive.
Figure 1-2
12 Chapter 1
Operation
Compensation for Fixture Residual Impedance Error
Compensation for Fixture Residual Impedance Error
The HP 16048A has inherent stray capacitance, residual inductance, and residual
resistance that affect the accuracy of measured values. To compensate for, or
negate, these residuals to minimize measurement error, the instrument’s
Open/Short compensati on p roc edure should be performed. The procedure is given
in the instrument’s operating manual .
Chapter 1 13
Operation
Compensation for Fixture Residual Impedance Error
14 Chapter 1
2 Service
15
Service
Maintenance
Maintenance
An exploded view of the HP 16048A (for parts identification) is shown in Figure
2-1. Do not disassemble any further than shown. Maintenance consists principally
of cleaning contact s a nd replacing worn or damaged par ts. Take special care when
cleaning contacts. To order parts, use the Hewlett-Packard part numbers listed in
Table 2-1. If a faulty part is located in an assembly that cannot be disassembled,
order the next higher assembly or return the whole device to the nearest
Hewlett-Packard Sales/Service Office for repair or replacement.
16 Chapter 2
Figure 2-1 Parts Identification
Service
Maintenance
Chapter 2 17
Service
Maintenance
Table 2-1 Parts Identification
Reference HP Part No. Qty. Description Note
1 * 4 SLEEVE 2 * 4 NUT 3 * 4 NUT 4* 4WASHER 5* 4WASHER 6 2360-0192 2 SCREW 7 * 1 COVER-BOTTOM 8 * 4 INSULATOR 9 * 2 CONNECTOR-BNC 10 * 2 CONNECTOR-BNC 11 2200-0105 1 SCREW 12 2190-0206 1 WASHER 13 16047-40000 1 STOPPER 15 16048-04000 1 COVER-TOP 16 1400-01719 2 TIE RAP 17 * 1 GROMMET 18 * 1 CABLE 19 * 1 BUSHING 21 2360-0113 1 SCREW 22 3050-0010 1 WASHER 23 16021-50021 1 CABLE CRAMP 24 16021-50022 1 CABLE CRAMP 25 * 4 BOOT-BNC 26 * 4 SLEEVE 27 * 4 SLEEVE 28 * 4 INSULATOR 29 1250-0089 4 CONTACT 30 1250-0052 4 CONNECTOR-BNC
16048-60010 1 TEST LEAD 1 thru 30
18 Chapter 2
Maintenance
Reference HP Part No. Qty. Description Note
31 1250-0118 4 CONNECTOR-BNC
FEMALE 32 2360-0115 2 SCREW 1 thru 30 33 16032-10021 1 PLATE 34 2190-0016 4 WASHER 35 2950-0001 4 NUT 36 16032-10022 1 PLATE 37 16032-60001 1 BNC BRACKET 31thru36
*: Not separately replaceable. Order 16048-60010
Service
Chapter 2 19
Service
Maintenance
20 Chapter 2
