Agasio A501W User Manual

AAggaassiioo AA550011WW IIPP CCaammeerra

a

IP Camera Centralization

Management

Client Application

(IPCMonitor)

May, 2011 Version 1.3

User Manual

INDEX

1 Introduction ...................................................................................................................... 3

2 Computer Requirement.................................................................................................. 3

3 Installation ........................................................................................................................ 3

4 Device Management ...................................................................................................... 4

4.1 Adding A Device ...................................................................................................... 4

4.2 Adding Multiple Devices in LAN ............................................................................ 6

4.3 Modifying Devices ................................................................................................... 6

4.4 Deleting Device ........................................................................................................ 7

4.5 Further Notifications for Device List Window ...................................................... 7

5 Video view ........................................................................................................................ 7

5.1 Start the Video ......................................................................................................... 8

5.2 Alarm Trigger ............................................................................................................ 8

5.3 Video Recording Trigger ........................................................................................ 9

5.4 Stop the Video .......................................................................................................... 9

6 Device Control ................................................................................................................. 9

6.1 Base Operation ........................................................................................................ 9

6.2 Device Control Panel ............................................................................................ 10

7 Channel Management .................................................................................................. 10

8 Other Settings ............................................................................................................... 11

8.1 System Setting ....................................................................................................... 11

8.2 History Log.............................................................................................................. 12

9 Further Notifications ..................................................................................................... 12

1 Introduction

IPCMonitor is a centralization management software provided by the manufacturer. It
provides the central control of monitoring, video capture, alarm testing, etc for multiple IP
cameras on LAN or WAN.
Before using this software, please ensure the devices can be access by web browsers
from LAN or WAN, please consult the user manual of the IP Camera to know the IP
Camera belongs to which series（support Q/B/H series products）. This article provides a
how-to on viewing the IP Camera's video by using this dedicated client application.

2 Computer Requirement

Using IPCMonitor, your computer should meet the following configuration:

 CPU: Dual-core CPU
 RAM: 1GB or above
 Hard disk: 160GB or above
 OS: “Windows XP or higher
 Resolution of display: ≧1024*768

3 Installation

Figure 1: Application User Interface
Insert the bundled CD to the drive, double click IPCMonitor, a pop-up window will be
shown, please follow the instruction on the window to finish the software installation. After

a successful installation, run the application and the user interface will be shown as Figure

1.

4 Device Management

The following steps are required before using this application:
1） Plan and install the IP Camera(s) which intend to be monitored.
2） Login to the IP Camera(s) by web browser and set the IP address, port, username &

password, alarm setting, system time etc.

3） DDNS setting is a plus whenever you intent to visit the devices by WAN.

In this application, Device Management tab is shown as Figure 2:

4.1 Adding A Device

1） Basic configuration

Figure 2: Devices Management

Figure 3: Adding A Device tab

Click the button shown on Figure 2, information of the device will be prompted to
