B245/B276/B277
PARTS CATALOG
002707MIU
PARTS CATALOG
B245/B276/B277
B245/B276/B277
PARTS CATALOG
002707MIU
It is the reader's responsibility when discussing the information contained
within this document to maintain a level of confidentiality that is in the best
interest of Ricoh Corporation and its member companies.
NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY
FASHION AND DISTRIBUTED WITHOUT THE PRIOR
PERMISSION OF RICOH CORPORATION.
All product names, domain names or product illustrations, including desktop images,
used in this document are trademarks, registered trademarks or the property of their
respective companies.
They are used throughout this book in an informational or editorial fashion only and for
the benefit of such companies. No such use, or the use of any trade name, or web
site is intended to convey endorsement or other affiliation with Ricoh products.
© 2007 RICOH Corporation. All rights reserved.
PRODUCT CODE COMPANY
*B245 DSm715 LD315 MP 1500 N/A
B276 DSm716 LD316 Aficio MP 1600 9016
B277 DSm721d LD320d Aficio MP 2000 9021d
B384 Paper Tray Unit PS450
B385 Paper Tray Unit PS460
B406 Platen Cover Type 1018
B621 Sorter PT340
B813 Document Feeder DF2000
B814 Document Feeder DF2010
B843-17 Feature Expansion Board Type 2000
B865/B866 Printer/Scanner DDST Unit Type A/B
B867 Printer/Scanner Unit Type 2000
B868 Fax Option Type 2000
*Latin America Only
LEGEND
GESTETNER LANIER RICOH SAVIN
DOCUMENTATION HISTORY
REV. NO. DATE COMMENTS
*
1 01/2007 B276/B277 Launch
06/2006 Original Printing
B245/B276/B277
TABLE OF CONTENTS
B245/B276/B277 PARTS LOCATION AND LIST
Location of Unit ...................................................... 3
1.EXTERIOR 1 ....................................................... 8
2.EXTERIOR 2 ...................................................... 10
3.OPERATION PANEL.......................................... 12
4.OPTICS SECTION 1 .......................................... 14
5.OPTICS SECTION 2 .......................................... 16
6.OPTICS SECTION 3 .......................................... 18
7.LASER UNIT ...................................................... 20
8.BY-PASS FEED SECTION ................................ 22
9.PAPER CASSETTE ........................................... 24
10.PAPER REGISTRATION .................................. 26
11.1ST PAPER FEED SECTION ........................... 28
12.2ND PAPER FEED SECTION (B277)............... 30
13.VERTICAL TRANSPORT (B277)...................... 32
14.PCU 1 ................................................................ 34
15.PCU 2 ................................................................ 36
16.TONER SUPPLY UNIT ..................................... 38
17.FUSING UNIT.................................................... 40
18.PAPER EXIT SECTION .................................... 42
19.DUPLEX UNIT 1 (B277).................................... 44
20.DUPLEX UNIT 2 (B277).................................... 46
21.DUPLEX UNIT 3 (B277).................................... 48
22.DRIVE SECTION............................................... 50
23.ELECTRICAL SECTION 1 ................................ 52
24.ELECTRICAL SECTION 2 ................................ 54
25.FRAME SECTION 1 .......................................... 56
26.FRAME SECTION 2 (B277) .............................. 58
27.DDST UNIT........................................................ 60
28.BICU BOARD (B245)......................................... 62
29.BICU BOARD (B276/B277) ............................... 74
30.DECAL AND DOCUMENT ................................ 86
31.SPECIAL TOOLS .............................................. 88
B245/B276/B277 PARTS INDEX
PARTS INDEX.......................................................... 2
B384 PAPER TRAY UNIT PS450 PARTS LOCATION AND
LIST
1.EXTERIOR (B384)............................................... 2
2.PAPER TRAY (B384) .......................................... 4
3.PAPER FEED/TRANSFER (B384)...................... 6
4.ELECTRICAL SECTION 1 (B384)....................... 8
5.ELECTRICAL SECTION 2 (B384)...................... 10
6.ELECTRICAL SECTION 3 (B384)...................... 12
7.DECAL AND DOCUMENT (B384) ..................... 14
B384 PAPER TRAY UNIT PS450 PARTS INDEX
PARTS INDEX.......................................................... 2
B385 PAPER TRAY UNIT PS460 PARTS LOCATION AND
LIST
1.EXTERIOR (B385) ............................................... 2
2.PAPER TRAY (B385)........................................... 4
3.PAPER FEED SECTION (B385).......................... 6
4.ELECTRICAL/DRIVE SECTION (B385) .............. 8
5.DECAL AND DOCUMENT (B385) ...................... 10
B385 PAPER TRAY UNIT PS460 PARTS INDEX
PARTS INDEX .......................................................... 2
B406 PLATEN COVER TYPE 1018 PARTS LOCATION AND
LIST
1.Platen Cover Type 1018 (B406)........................... 2
B406 PLATEN COVER TYPE 1018 PARTS INDEX
PARTS INDEX .......................................................... 2
B621 SORTER PT340 PARTS LOCATION
AND LIST
1.1BIN TRAY (B621) ............................................... 2
B621 SORTER PT340 PARTS INDEX
PARTS INDEX .......................................................... 2
B813 DOCUMENT FEEDER DF2000 PARTS LOCATION
AND LIST
1.Exterior (B813) ..................................................... 2
2.Original Feed Section 1 (B813)............................ 4
3.Original Feed Section 2 (B813)............................ 6
4.Original Transfer And Frame (B813).................... 8
5.Electrical Section (B813)..................................... 10
6.Decals And Documents (B813) ........................... 12
B813 DOCUMENT FEEDER DF2000 PARTS INDEX
PARTS INDEX .......................................................... 2
B814 DOCUMENT FEEDER DF2010 PARTS
LOCATION AND LIST
1.ARDF 1 (B814)..................................................... 2
2.ARDF 2 (B814)..................................................... 4
3.ARDF 3 (B814)..................................................... 6
4.ARDF 4 (B814)..................................................... 8
5.ARDF 5 (B814).................................................... 10
6.ARDF 6 (B814).................................................... 12
7.ARDF 7 (B814).................................................... 14
8.Decals And Documents (B814) ........................... 16
B814 DOCUMENT FEEDER DF2010 PARTS
INDEX
PARTS INDEX .......................................................... 2
B843-17 FEATURE EXPANSION BOARD TYPE 2000 PARTS
LOCATION AND LIST
1.Feature Expansion Board 1 (B84317).................. 2
2.Feature Expansion Board 2 (B84317).................. 4
3.Controller Board (B84317) ................................... 6
B843-17 FEATURE EXPANSION BOARD TYPE 2000 PARTS
INDEX
PARTS INDEX .......................................................... 2
B865/B866 PRINTER/SCANNER DDTS UNIT TYPE A/B
PARTS LOCATION AND LIST
1.DDST Unit (B865/B866) ........................................ 2
B865/B866 PRINTER/SCANNER DDTS UNIT TYPE A/B
PARTS INDEX
PARTS INDEX ......................................................... 2
B867 PRINTER/SCANNER UNIT TYPE 2000 PARTS
LOCATION AND LIST
1.Printer/Scanner Unit (B867) ................................ 2
B867 PRINTER/SCANNER UNIT TYPE 2000 PARTS
INDEX
PARTS INDEX ......................................................... 2
B868 FAX OPTION TYPE 2000 PARTS LOCATION AND LIST
1.Fax Option (B868) ............................................... 2
B868 FAX OPTION TYPE 2000 PARTS INDEX
PARTS INDEX ......................................................... 2
B245/B276/B277
PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
LOCATIONS OF UNITS LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
1. EXTERIOR 1
4. OPTICS SECTION 1
See Page 9
2. EXTERIOR 2
See Page 11
5. OPTICS SECTION 2
3. OPERATION PANEL
See Page 13
6. OPTICS SECTION 3
See Page 15
B245/B276/B277 3 Parts Location and List
See Page 17
See Page 19
LOCATIONS OF UNITS LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
7. LASER UNIT
See Page 21
10. PAPER REGISTRATION
8. BY-PASS FEED SECTION
See Page 23
11. 1ST PAPER FEED SECTION
9. PAPER CASSETTE
See Page 25
12. 2ND PAPER FEED SECTION
See Page 27
B245/B276/B277 4 Parts Location and List
See Page 29
See Page 31
LOCATIONS OF UNITS LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
13. VERTICAL TRANSPORT (B277)
See Page 33
16. TONER SUPPLY UNIT
14. PCU 1
See Page 35
17. FUSING UNIT
15. PCU 2
See Page 37
18. PAPER EXIT SECTION
See Page 39
B245/B276/B277 5 Parts Location and List
See Page 41
See Page 43
LOCATIONS OF UNITS LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
LOCATIONS OF UNITS
19. DUPLEX UNIT 1 (B277)
See Page 45
22. DRIVE SECTION
20. DUPLEX UNIT 2 (B277)
See Page 47
23. ELECTRICAL SECTION 1
21. DUPLEX UNIT 3 (B277)
See Page 49
24. ELECTRICAL SECTION 2
See Page 51
B245/B276/B277 6 Parts Location and List
See Page 53
See Page 55
LOCATIONS OF UNITS LOCATIONS OF UNITS
LOCATIONS OF UNITS LOCATIONS OF UNITS LOCATIONS OF UNITS
25. FRAME SECTION 1
See Page 57
26. FRAME SECTION 2 (B277)
See Page 59
B245/B276/B277 7 Parts Location and List
1.EXTERIOR 1
101
101
101
1
101
101
101
101
101
21
101
101
101
101
5
4
2
2
22
3
6
101
7
101
19
8
23
101
9
101
15
24
18
14
16
25
23
B245/B276/B277 8 Parts Location and List
13
101
14
101
13
101
12
11
101
101
10
101
1.EXTERIOR 1
Index
No.
1 B121 1316 Left Cove NA 1
1 B121 1315 Left Cover EU 1
2 B276 1332 Left Scanner Cover: NA [TSB#016] 1
2 B039 1302 Left Scanner Cover EU 1
3 B276 1354 Exit Cover NA [TSB#016] 1
3 B121 1353 Exit Cover EU 1
4 B276 1333 Rear Scanner Cover: NA [TSB#016] 1
4 B039 1303 Rear Scanner Cover EU 1
5 B121 1314 Application Cap 1
6 B276 1337 Rear Cover: NA [TSB#016] 1
6 B121 1336 Rear Cover B EU 1
7 B121 1313 IC Card Cap 1
8 B121 1348 Paper Bank Cap 1
9 B276 1335 Right Scanner Cover: NA [TSB#016] 1
9 B039 1304 Right Scanner Cover EU 1
10 B276 1347 Right Rear Cover: NA [TSB#016] 1
10 B039 1317 Rear Cover EU 1
11 B276 1339 Cover - Front Right Upper: NA [TSB#016] 1
11 B039 1309 Front Right Upper Cover EU 1
12 B276 1351 Cover - Front NA [TSB#016] 1
12 B243 1350 Cover - Front EU 1
13 B039 1366 Cover Magnet 2
14 B039 1361 Magnet Catch 2
15 B243 1253 Door - Front EU 1
15 B243 1254 Door - Front NA 1
15 B268 1253 Door - Front EU 1
16 B245 7410 Model Name Plate - GES (ASIA) 1
16 B245 7412 Model Name Plate - GES (NA) 1
16 B245 7420 Model Name Plate - GES (EU) 1
16 B245 7421 Model Name Plate - NSA 1
16 B245 7422 Model Name Plate - REX 1
16 B245 7424 Model Name Plate - LAN 1
16 B245 7426 Model Name Plate - INF RIC 1
16 B245 7427 Model Name Plate - RIC 1
16 B268 7410 Model Name Plate - GES 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
16 B268 7424 Model Name Plate - LAN 1
16 B268 7427 Model Name Plate - RIC 1
16 B268 7429 Model Name Plate - INF 1
16 B276 7411 Model Name Plate - SVN 1
16 B276 7412 Model Name Plate - GES (NA) 1
16 B276 7420 Model Name Plate - GES (EU) 1
16 B276 7421 Model Name Plate - NSA 1
16 B276 7422 Model Name Plate - REX 1
16 B276 7424 Model Name Plate - LAN 1
16 B276 7426 Model Name Plate - INF 1
16 B276 7427 Model Name Plate - RIC 1
18 B039 1365 Sheet - Operation Instructions 1
19 B039 1367 Rivet - M6 2
20 B039 1364 Rivet - M7 1
21 B121 1322 Left Upper Cover B 1
22 B276 1368 Rear Cover:Exit NA [TSB#016] 1
22 B121 1367 Rear Exit Cover B EU 1
23 GA00 3035 Energy Decal 1
24 B039 1362 Main Switch Cover 1
25 B132 1531 Panel:Logo 1
101 0451 3008N Tapping Screw - M3x8
102 0450 4008N Tapping Screw - M4x8
Part No.
Description
Rev. 10/08/2007
Q’ty Per
Assembly
B245/B276/B277 9 Parts Location and List
2.EXTERIOR 2
101
1
101
101
101
3
31
14
16
18
101
25
101
26
101
2
5
101
4
103
27
6
32
7
101
101
101
29
24
23
8
101
17
9
14
15
28
30
13
101
13
B245/B276/B277 10 Parts Location and List
19
102
101
12
20
102
102
21
101
11
101
33
22
101
10
101
101
2.EXTERIOR 2
Index
No.
1 B121 1315 Left Cover EU 1
2 B276 1316 Left Cover NA [TSB#016] 1
3 B121 1354 Exit Cover NA 1
3 B121 1353 Exit Cover EU 1
4 B039 1333 Rear Scanner Cover 1
5 B121 1314 Application Cap 1
6 B277 1339 Rear Cover NA [TSB#016] 1
6 B122 1338 Rear Cover EU 1
7 B121 1313 IC Card Cap 1
8 B122 1349 Paper Bank Cap 1
9 B039 1335 Right Scanner Cover 1
9 B039 1304 Right Scanner Cover 1
10 B277 1347 Right Rear Cover NA [TSB#016] 1
10 B122 1346 Right Rear Cover EU 1
11 B277 1310 Right Upper Front Cover NA [TSB#016] 1
11 B122 1309 Right Upper Front Cover EU 1
12 B276 1351 Front Cover (NA) 1
12 B243 1350 Cover - Front EU 1
13 B039 1366 Cover Magnet 2
14 B039 1361 Magnet Catch 2
15 B243 1253 Door - Front EU 1
15 B243 1254 Door - Front NA 1
15 B268 1253 Door - Front EU 1
16 B269 7410 Model Name Plate - GES 1
16 B269 7424 Model Name Plate - LAN 1
16 B269 7427 Model Name Plate - RIC 1
16 B269 7429 Model Name Plate - INF 1
16 B277 7411 Model Name Plate - SVN 1
16 B277 7412 Model Name Plate - GES (NA) 1
16 B277 7420 Model Name Plate - GES (EU) 1
16 B277 7421 Model Name Plate - NSA 1
16 B277 7422 Model Name Plate - REX 1
16 B277 7424 Model Name Plate - LAN 1
16 B277 7426 Model Name Plate - INF 1
16 B277 7427 Model Name Plate - RIC 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
17 B276 6139 Rear Lower Cover NA [TSB#016] 1
17 B040 6138 Rear Lower Cover EU 1
18 B039 1365 Sheet - Operation Instructions 1
19 B276 6136 Left Lower Cover NA [TSB#016] 1
19 B040 6135 Left Lower Cover EU 1
20 B040 6126 Front Lower Cover 1
21 B040 6131 Cover - Right Lower Front 1
22 B040 6140 Cover - Right Lower Rear 1
23 B039 1364 Rivet - M7 1
24 B039 1367 Rivet - M6 2
25 B122 1323 Left Upper Cover 1
26 B277 1370 Rear Exit Cover NA [TSB#016] 1
26 B122 1369 Rear Exit Cover EU 1
27 B277 1372 Sorter Cover NA [TSB#016] 1
27 B122 1371 Sorter Cap EU 1
28 GA00 3035 Energy Decal 1
29 B039 1304 Right Scanner Cover (EU) 1
29 B039 1335 Right Scanner Cover (NA) 1
30 B039 1362 Main Switch Cover 1
31 B132 1531 Panel:Logo 1
32 B121 7450 Decal - Weee 1
33 B121 1380 Seal - Lifing Grip 1
101 0451 3008N Tapping Screw - M3x8
102 0451 3006N Tapping Screw - 3x6
103 0450 4008N Tapping Screw - M4x8
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 11 Parts Location and List
3.OPERATION PANEL
Rev. 07/09/2010
1
14
5
101
102
102
10
16
20
102
4
17
11
12
8
9
13
15
7
15
15
7
19
15
6
101
15
102
101
15
15
B245/B276/B277 12 Parts Location and List
3.OPERATION PANEL
Index
No.
1 B243 1461 Cover:Printer:Basic 1
1 B243 1466 Cover - CPS NA 1
1 B243 1462 Cover - CPS 1
4 B245 1421 Operation Panel Unit NA 1
4 B245 1422 Operation Panel Unit EU 1
4 B245 1423 Operation Panel Unit ASIA 1
4 B268 1423 Operation Panel Unit ASIA 1
4 B269 1413 Operation Panel Unit ASIA 1
4 B276 1421 Operation Panel Unit NA 1
4 B276 1422 Operation Panel Unit EU 1
4 B277 1411 Operation Panel Unit NA 1
4 B277 1412 Operation Panel EU 1
5 B039 1452 Lower Cover - Operation Panel 1
6 B243 1425 Cover - Operation Panel 1
7 B039 1469 Ground Plate 2
8 B229 1453 Keytop - Start 1
9 B229 1454 Keytop - Clear/stop 1
10 B229 1475 Keytop - 10key 1
10 B229 1526 Keytop - 10key NA 1
10 B229 1557 Keytop - 10key ASIA 1
11 B229 1525 Keytop - Initial 1
12 B229 1537 Keytop - Clear Modes 1
13 B243 1458 Keytop - Power Source 1
14 B243 1459 Keytop - Cursor 1
15 B259 1499 Tapping Screw - M3x8 7
16 B243 1472 Sheet - Operation Panel 1
16 B245 1473 Sheet: Operation Panel: A:EU 1
17 B229 1521 Sheet-Power Source - NA 1
17 B229 1522 Sheet-Power Source - EU 1
19 B243 1487 PCB Operation Panel: 1
B276/B277 GW [TSB#019]
19 B245 1487 PCB Operation Panel: 1
B245/B276/B277 Basic Non-GW [TSB#019]
20 B243 1451 Case: Operation Sub-Unit 1
Part No.
Description
Q’ty Per
Assembly
Rev. 07/09/2010
Index
No.
101 0451 3008N Tapping Screw - M3x8
102 0353 0050N Screw-m3x5
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 13 Parts Location and List
4.OPTICS SECTION 1
Rev. 03/04/2010
19
B245/B276/B277 14 Parts Location and List
4.OPTICS SECTION 1
Index
No.
1 B390 1759 Shaft: Scale 1
2 B268 1749 Scale - Left 1
3 B039 1710 Left Scanner Bracket 1
4 AW02 0156 Photointerruptor:EE-SX4235A-P2 1
5 A193 1793 Scanner Home Sensor Stopper 1
6 GW02 0020 Photointerruptor:LG248Nl1 2
7 A250 1821 Heater - 9W 1
7 A250 1822 Heater - 9W 1
8 B121 1808 Inner Cover 1
9 B259 1813 Holder: Lens: Ass’y 1
10 A250 1752 Exposure Glass 1
11 B268 1751 Scale - Inner Back 1
12 B039 1666 Bracket - Operation Panel 1
13 B243 1804 Harness - FFC 1
14 B039 1712 Right Scanner Bracket 1
15 5442 1924 Exposure Glass Cushion 2
16 B039 1658 Rear Scale Bracket 1
17 B121 1069 Support Bracket 1
18 B039 1068 ADF Bracket 1
19 B238 1845 Seal: Exposure Glass [TSB#029] 2
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - M3x6
102 0454 3006Q Tapping Screw With Washer - M3x6
Part No.
Description
Rev. 07/20/2010
Q’ty Per
Assembly
B245/B276/B277 15 Parts Location and List
5.OPTICS SECTION 2
Rev. 02/08/2007
B245/B276/B277 16 Parts Location and List
5.OPTICS SECTION 2
Index
No.
1 B039 1787 2nd Mirror 2
2 B039 1781 2nd Mirror Holder 4
3 B039 1785 Scanner Drive Pulley 4
4 B121 1782 Flexible Board Guide 1
5 B259 1768 Carriage No.2 Ass'y 1
6 B039 1784 Scanner Drive Belt 2
7 B259 1778 Idler Belt Pulley Bracket - Rear 1
8 B039 1790 Tension Spring 2
9 B259 1776 Idler Belt Pulley Bracket - Front 1
10 B121 1757 Xenon Lamp MM8 26000/70 1
11 B039 1758 Timing Belt Holder - Front 1
12 B121 1751 No.1 Carriage Ass'y 1
13 B039 1759 Timing Belt Holder - Rear 1
14 B121 1766 No.1 Mirror Clamp 2
15 B121 1762 No.1 Mirror 1
16 B259 1763 Xenon Lamp Stabilizer 1
17 B259 5223 Harness - Stabilizer 1
18 G570 2730 Slider - Scanner 8
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 17 Parts Location and List
6.OPTICS SECTION 3
B245/B276/B277 18 Parts Location and List
6.OPTICS SECTION 3
Index
No.
1 AW01 0126 Original Sensor:H=2-66 2
2 B243 5222 Harness - Scanner (B268/B269/B276/B277) 1
2 B245 5222 Harness - Scanner (B245) 1
3 B039 1703 Pulley - 37Z 2
4 B039 1701 Bracket - Idler 2
5 B039 1704 Spring - Timing Pulley 2
6 B121 1667 Lens Stay Bracket 2
7 B039 1697 Timing Belt - 1058.25XL 2
8 B121 1696 Timing Belt L147 1
9 B039 1695 Flange - Pulley 1
10 B039 1694 Pulley - 37/41Z 1
11 B259 1691 Scanner Drive Shaft 1
12 B039 1692 Pulley - 37Z 1
13 B039 1668 Bracket - Stabilizer Harness 1
14 B121 1664 Bracket - Timing Belt 1
15 B039 1699 Scanner Drive Motor – MM42: 2.9W 1
16 B259 1702 Pulley Shaft 2
17 B039 1683 Tension Spring - Stepper Motor 1
18 B121 1680 Gear - 53Z/60Z 1
19 B039 1662 Front Scanner Frame 1
20 B039 1663 Rear Scanner Frame 1
Part No.
Description
Q’ty Per
Assembly
Rev. 06/09/2010
Index
No.
101 0451 3006N Tapping Screw - 3x6
102 0454 3006Q Tapping Screw With Washer - M3x6
103 1105 0511 Harness Clamp - LWS-0306ZC
104 1105 0487 Harness Clamp
105 0805 3530 Bearing 8x22x7
106 0720 0060E Retaining Ring - M6
107 0360 3006N Screw - M3X6
108 0453 3006N Tapping Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 19 Parts Location and List
7.LASER UNIT
B245/B276/B277 20 Parts Location and List
7.LASER UNIT
Index
No.
* B283 1876 Imaging Unit 1
1 B276 1251 Shield Glass Cover: NA [TSB#016] 1
2 B039 1905 Adjusting Plate 1
3 B259 2381 Discharge Lamp - Ql 1
4 B121 5204 Harness - Discharge Lamp 1
5 B039 1088 Sheet - Duct 1
6 B039 1961 Shield Glass 1
7 G029 1980 Decal - LD 1
8 AC03 0139 Sync Detector Mirror 1
9 AC02 4009 Cylindrical Lens 1
10 B039 1942 Cylindrical Lens Holder 1
11 B039 1954 Holder - Sync Detector Mirror 1
12 B039 1971 Optical Housing Cover 1
13 B121 5439 Harness - Polygon Mirror Motor 1
14 B121 5250 Harness - LDD 1
15 B276 1917 Laser Diode Unit 1
16 AX06 0323 Polygon Motor - 23622rpm 1
17 AC03 0138 2nd Mirror 1
18 B039 1953 2nd Mirror Holder 2
19 AC02 0095 Sync Detector Lenz 1
20 B121 1975 Rubber Bushing 2
Part No.
Description
Q’ty Per
Assembly
101 0452 3010N Tapping Bind Screw - M3x10
102 0450 3012N Tapping Screw -3x12
103 0450 3020N Tapping Screw:M3x20
104 0452 3014N Tapping Screw - M3x14
Index
No.
Part No.
Description
Rev. 10/20/2008
Q’ty Per
Assembly
B245/B276/B277 21 Parts Location and List
8.BY-PASS FEED SECTION
Rev. 03/04/2008
21
B245/B276/B277 22 Parts Location and List
8.BY-PASS FEED SECTION
Index
No.
* B259 2601 Manual Feed Table Ass'y 1
1 B039 2631 Front Side Fence 1
2 B039 2628 Bottom Plate Pad 1
3 B039 2632 Rear Side Fence 1
4 B039 2630 Tray Bottom Plate 1
5 B039 2638 Rack - Rear Side Fence 1
6 B039 2637 Rack - Front Side Fence 1
7 G012 3050 Side Fence Gear 1
8 AA06 3643 Spring - By-pass Feed Table 2
9 B039 2645 Rotary Switch 1
10 B039 2629 Stay - Tray Bottom Plate 1
11 B039 2620 Paper Guide - Extension 1
12 B039 2621 Paper Guide 1
13 B121 2617 Magnet Catch - By-pass Feed 1
14 B039 2619 By-pass Feed Table 1
15 G020 2784 Lever - By-pass Feed Table 1
16 B039 2643 Link - By-pass Feed Table 2
17 B039 2633 Decal - By-pass Feed 1
18 5447 2681 Snap Ring 3
19 B259 2642 Pin - Mm6 2
20 B259 2786 Lever Shaft 1
21 B238 2753 Decal: Side Fence: Manual Feed [TSB#021] 1
Part No.
Description
Q’ty Per
Assembly
Rev. 06/09/2010
Index
No.
101 0451 3008N Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 23 Parts Location and List
9.PAPER CASSETTE
B245/B276/B277 24 Parts Location and List
9.PAPER CASSETTE
Index
No.
* B243 2840 Paper Tray Unit EU 1
* B243 2841 Paper Tray Unit NA 1
1 G020 2644 End Fence 1
2 B039 2704 Front Stopper Lever 1
3 B039 2701 Tray Bottom Plate 1
4 B039 2707 Spring Plate - Side Fence 1
5 B039 2734 Side Fence - Front 1
6 5215 2621 Snap Ring - M6 1
7 B039 2712 Ground Plate - Tray Bottom Plate 1
8 B039 2731 Side Fence - Rear 1
9 B039 2821 Rear Stopper Lever 1
10 B259 2737 Paper Feed Roller Shaft Ass'y 2
11 B039 2740 Paper Feed Roller 2
12 A267 2869 Gear - 16Z 1
13 B039 2719 Spring - Tray Bottom Plate 1
14 B039 2742 Ground Plate - Paper Feed Roller 1
15 B039 2823 Joint - Paper Feed Roller 1
16 B039 2727 Bushing - 8x12x10 2
17 B039 2732 Spring - Paper Feed Roller 1
18 B039 2711 Friction Pad 1
19 B039 2713 Spring - Friction Pad 1
20 B039 2724 Paper Size Detector - A4 1
20 B039 2829 Paper Size Detector - LT 1
21 A250 2808 Stopper Base 1
22 G020 2599 Spring - Release Lever 1
23 B039 2739 Shaft - Joint 1
24 B039 2720 Decal - Cassette Operation DLT 1
25 B039 2721 Decal - Cassette Operation 1
26 B243 2702 Cover - Paper Tray 1
27 5215 2713 Bottom Plate Pad 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0805 0088 Retaining Ring - M6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 25 Parts Location and List
10.PAPER REGISTRATION
20
101
22
Rev. 11/30/2006
28
21
101
3
2
101
15
16
18
17
102
1
3
5
4
2
8
3
11
10
6
7
12
3
101
25
19
24
35
34
37
24
32
8
23
36
103
13
14
9
27
26
29
31
38
B245/B276/B277 26 Parts Location and List
10.PAPER REGISTRATION
Index
No.
1 B039 2575 Bracket - Registration Roller 1
2 AA06 2254 Registration Roller Spring 2
3 5447 2681 Snap Ring 2
4 AB01 2312 Gear - 16Z 1
5 AA08 0342 Fornt Bushing-registration Roller 1
6 AA08 0267 Bushing - 8x12x18 1
7 AB01 2311 Gear - 18Z 1
8 AA10 0015 Snap Ring - M6 2
9 B121 3804 Transfer Unit 1
10 AA06 6342 Registration Sensor Spring 1
11 B039 2570 Registration Feeler 1
12 B039 2567 Guide - Right Registration Roller 1
13 GW02 0020 Photointerruptor:LG248NL1 1
14 B121 5202 Harness - Registration Sensor 1
15 B039 2560 Registration Cleaning Mylar 1
16 B039 2572 Guide - Left Registration Roller 1
17 B039 2558 Driven Roller 1
18 B259 2571 Registration Roller Driven - Dia16 1
19 B259 2562 Registration Roller Drive 1
20 B039 1130 Development Sensor Bracket 1
21 B121 5248 Harness - Development Sensor 1
22 AA08 0343 Rear Bushing-registration Roller 1
23 AA08 2110 Bushing - 8x12x22 1
24 AA06 3607 Pressure Spring 2
25 B039 3820 Transfer Roller 1
26 B259 3890 Density Sensor 1
27 B039 3891 ID Sensor Cover 1
28 B259 1131 Screw:PCU 1
29 B121 5206 Harness - Density Sensor 1
31 B039 3867 Roller - Transfer Unit 2
32 B039 3863 Quenching Terminal Plate 1
33 B043 2554 Registration Guide Spacer 1
34 B121 3860 Harness Cover 1
35 B039 3864 Quenching Terminal Plate-front 1
36 B039 3865 Transfer Terminal Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
37 B120 3862 Front Discharge Brush 1
38 B039 3866 Pressure Cover 1
101 0450 3008N Tapping Screw - M3x8
102 0450 3012N Tapping Screw:3x12
103 1105 0522 Edge Saddle - Les0510
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 27 Parts Location and List
11.1ST PAPER FEED SECTION
B245/B276/B277 28 Parts Location and List
11.1ST PAPER FEED SECTION
Index
No.
1 B039 2754 Bracket - Paper Size Sensor 1
2 G800 3035 Push Sw - Paper Size 1
3 B039 2736 Bracket - Paper End Sensor 1
4 B039 2730 Paper End Sensor 1
5 B121 5215 Harness - Paper End Sensor No.1 1
6 5447 2681 Snap Ring 2
7 B039 2585 Exit Guide Plate 1
8 B039 1142 Housing - Paper Feed 1
9 B039 2766 Guide Plate - Transport Roller 1
10 B039 2797 Guide Plate - Transport Roller 1
11 B039 2558 Driven Roller 2
12 B039 2795 Guide Plate - Transport 1
13 B039 2825 Ground Plate - Vertical Transport 1
14 AX20 0265 Magnetic Clutch 0.35n M Z31 1
15 AA08 2101 Bushing - 6x10x6 5
16 B259 2577 Transport Roller 1
17 B039 2583 Vertical Transport Feeler 1
18 B259 1194 Manual Feed Drivebracket 1
19 B039 1191 Gear - 19Z 1
20 B259 1190 Shaft - Drive Manual Feed 1
21 B259 1183 Shaft - Drive Paper Feed 1
22 B121 1188 Bushing 1
23 B259 1178 Paper Feed Drive Bracket 1
24 B039 1187 Gear - 30Z 1
25 B039 1186 Gear - 46Z 1
26 B276 1150 Magnetic Clutch:Paper Feed:Drive:Ass'y 1
27 B039 2813 Lower Bracket - Relay Sensor 1
28 B039 2812 Upper Bracket - Relay Sensor 1
29 GW02 0020 Photointerruptor:LG248NL1 1
30 B121 5201 Harness - Registration Sensor 1
31 B039 1193 Bushing - By-pass Feed 1
32 B039 1199 Spring - By-pass Feed 1
33 B039 1192 Gear - 57Z 1
34 B039 2830 Right Rail 1
35 B121 2607 Manual Feed Magnetic Clutch Ass'y 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
36 B039 2587 Mylar - Exit Guide Plate 1
37 B039 2834 Decal - Exit Paper Feed 1
101 0451 3006N Tapping Screw - 3x6
102 0454 3006Q Tapping Screw With Washer - M3x6
103 0720 0040E Retaining Ring - M4
104 0805 0097 Ring Separator
105 1105 0511 Harness Clamp - LWS-0306ZC
106 0450 3008N Tapping Screw - M3x8
107 1105 0487 Harness Clamp
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 29 Parts Location and List
12.2ND PAPER FEED SECTION (B277)
B245/B276/B277 30 Parts Location and List
12.2ND PAPER FEED SECTION (B277)
Index
No.
1 B040 6150 Guide Plate - Upper Paper Feed 1
2 B040 6058 Stay - Paper End Sensor 1
3 B040 6066 Vertical Transport Cover 1
4 AG07 0514 Magnet Catch 1
5 AA06 3334 Spring - Vertical Transport 2
6 AA08 0249 Bushing - Vertical Transport 2
7 B040 6069 Transport Driven Roller 1
8 B277 6067 Guide Plate: Paper Feed: Right 1
9 B260 6093 Paper Feed Roller Drive Shaft 1
10 AA08 2101 Bushing - 6x10x6 3
11 B039 2730 Paper End Sensor 1
12 AX20 0296 Magnetic Clutch - 46z 1
13 B040 6091 Bracket - Vertical Transport Roller 1
14 AB01 2314 Gear - 25Z 3
15 AA06 0228 Spring - Transfer Drum Cleaning Sol 1
16 B040 6096 Tightener Bracket 1
17 AB03 0702 Timing Pulley - 30Z 1
18 AB03 0701 Gear/pulley - 24/30Z 1
19 AA04 3527 Timing Belt - 230XL 1
20 B040 6049 Bracket - Vertical Transport 1
21 A250 2779 Pin - M6 1
23 AA08 0252 Bushing - M4 1
24 B040 6074 Transport Roller Bracket 1
25 G020 5626 Push Switch 1
26 B040 6078 Bracket - Vertical Paper Sensor 1
27 AW02 0181 Paper Feed Sensor 1
28 B040 6071 Guide Plate - Vertical Transport 1
29 5447 2681 Snap Ring 2
30 5206 2686 Snap Ring 1
31 B260 6038 Transport Roller:Connecting:No.2:Ass'y 1
Part No.
Description
Q’ty Per
Assembly
Rev. 11/02/2006
Index
No.
101 0450 3008N Tapping Screw - M3x8
102 0451 3006N Tapping Screw - 3x6
103 1105 0511 Harness Clamp - LWS-0306ZC
104 0720 0040E Retaining Ring - M4
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 31 Parts Location and List
13.VERTICAL TRANSPORT (B276)
Rev. 08/14/2008
31
B245/B276/B277 32 Parts Location and List
13.VERTICAL TRANSPORT (B276)
Index
No.
1 AF02 2138 Vertical Transport Roller 1
2 AA08 0268 Bushing - Vertical Transport 2
3 AA06 3399 Spring - Vertical Transport 2
4 B282 2655 Guide: Vertical Transport 1
5 B039 2653 Vertical Transport Guide 1
6 B039 2592 Lower Guide Plate - By-pass Feed 1
7 AA06 3398 Spring - Friction Pad 1
8 B039 2596 Friction Pad 1
9 A232 3962 Spring Plate - Band Stopper 1
10 B039 2660 Band - Right Door 1
11 B039 2594 Upper Guide Plate - By-pass Feed 1
12 B259 2594 Shaft - Feed 1
13 AB01 2313 Gear - 25Z 1
14 B121 4470 Right Lower Exit Guide Plate 1
16 B039 2658 Sponge - By-pass Feed 2
17 AF03 1060 By-pass Feed Roller 1
18 AA08 2101 Bushing - 6x10x6 2
19 B039 2610 Bracket - Paper End Sensor 1
20 AA06 6343 Spring - Paper End Sensor 1
21 B039 2611 Feeler - Paper End Sensor 1
22 GW02 0020 Photointerruptor:LG248NL1 1
23 B121 5259 Harness - Paper End Sensor 1
24 AG07 0514 Magnet Catch 1
25 B039 2651 Right Door Lever 1
26 A250 1388 Spring 1
27 B039 2670 Right Door 1
28 B039 2558 Driven Roller 2
29 B039 4488 Jam Removal Decal 1
30 B039 4480 Stepped Screw - M5 2
31 B259 2648 Door: Right: C2B: Ass’y [TSB#023] 1
Part No.
Description
Q’ty Per
Assembly
101 0450 3008N Tapping Screw - M3x8
102 0451 3006N Tapping Screw - 3x6
103 0720 0040E Retaining Ring - M4
Index
No.
Part No.
Description
Rev. 08/14/2008
Q’ty Per
Assembly
B245/B276/B277 33 Parts Location and List
14.PCU 1
6
4
101
3
101
5
101
1
9
12
7
101
9
11
11
8
101
101
2
102
101
10
B245/B276/B277 34 Parts Location and List
13
14.PCU 1
Index
No.
* B259 2210 PCU Ass’y 1
1 B259 2371 Rear Drum Stay 1
2 A267 3440 Development Joint 1
3 B039 2361 Front Side Plate - Drum 1
4 B039 2367 Drum Shutter Spring 1
5 B039 2362 Drum Shutter Gear 1
6 B259 3052 Development Roller Ass'y 1
7 B039 3159 Case: Development Roller: Ass’y 1
8 B259 3170 Development Case Ass'y 1
9 B039 3062 Idler Gear - 16z 2
10 B259 3390 Density Sensor:K-C2.5:Ass'y 1
11 B039 3245 Gear - 15Z 2
12 B039 3060 Development Roller Gear 1
13 B121 9640 Developer Type 28 Black (Asia) [TSB#012] 1
13 B121 9645 Developer Type 28 Black (NA,EU) [TSB#012] 1
Part No.
Description
Q’ty Per
Assembly
Rev. 05/02/2008
Index
No.
101 0360 3006N Screw - M3X6
102 0452 3008N Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 35 Parts Location and List
15.PCU 2
1
2
Rev. 02/12/2010
14
11
13
1
25
2
8
4
24
104
7
5
24
1
04
10
16
103
9
15
101
18
3
23
6
19
101
22
19
21
17
20
B245/B276/B277 36 Parts Location and List
15.PCU 2
Index
No.
1 B121 2311 PCU Toner Supply Shutter 1
2 B039 2312 Shutter Spring 1
3 B039 2343 Drum Shutter 1
4 B039 2293 Pin - Front Pressure Arm 1
5 B039 2272 Recycled Toner Coil 1
6 B039 2321 Front PCU Cover 1
7 B039 2274 Recycled Toner Plate 1
8 B121 2313 Toner Supply Seal 1
9 B039 2276 Rear Bushing - Toner Coil 1
10 B039 2350 Drum Holder 1
11 AA14 3444 Stepped Screw 1
12 AB01 1403 Gear - 13Z 1
13 AB01 1402 Gear - 14Z 1
14 B039 2335 Pickoff Pawl 2
15 AD04 2059 Cleaning Blade Ass'y 1
16 B039 2288 Cam - Cleaning Blade 1
17 B039 9510 OPC Drum 1
18 B039 2295 Rear Pressure Arm - Charge Roller 1
19 B039 2287 Charge Roller Spring 2
20 B039 2292 Front Pressure Arm - Charge Roller 1
21 AD02 7018 Roller:Charge:A3 1
22 AD04 2058 Charge Cleaner Brush Roller 1
23 B259 2325 OPC Drum Shutter Plate 1
24 B039 2329 Spacer - M3 1
25 B121 2252 Upper PCU Case [TSB#028] 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
102 0452 3008N Tapping Screw - M3x8
103 0736 0610 Bushing 6x10
104 0452 3012N Binding Self-tapping Screw:M3x12
Part No.
Description
Rev. 02/12/2010
Q’ty Per
Assembly
B245/B276/B277 37 Parts Location and List
16.TONER SUPPLY UNIT
B245/B276/B277 38 Parts Location and List
16.TONER SUPPLY UNIT
Index
No.
1 B259 3031 Toner Supply Unit 1
2 B039 3360 Cam - Handle 1
3 A184 3420 Bottle Chuck 1
4 A184 3421 Chuck Shaft 1
5 B259 3422 Shaft:Slide 1
6 B039 1141 Shaft - Paper Feed Frame 1
7 A267 3556 Chuck Spring - Tonner Bottle 1
8 G020 3334 Slider Ass`y 1
9 B243 5233 Harness - High Voltage Line C/T 1
10 B039 3870 Terminal - Transfer 1
11 B039 2578 Grounding Plate 1
12 B039 3380 Cover - Toner Supply Unit 1
13 B121 5219 Harness - Ground Wire 1
14 B039 2382 Quenching Lamp Terminal 1
15 B039 3392 Guide Plate - Toner Supply Unit 1
16 AX31 0046 Total Counter:7fig:24v 1
17 B039 3395 Ground Plate - Toner Supply Unit 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0450 3008N Tapping Screw - M3x8
102 0452 3008N Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 39 Parts Location and List
17.FUSING UNIT
101
103
105
32
105
4
2
1
2
105
3
102
8
7
10
105
37
101
15
33
29
7
12
12
9
11
101
101
5
13
5
101
14
11
101
101
A
17
18
19
20
23
24
26
101
A
101
25
28
27
16
21
34
22
17
36
35
6
25
27
26
31
104
102
101
30
101
102
101
101
101
36
35
B245/B276/B277 40 Parts Location and List
17.FUSING UNIT
Index
No.
* B259 4002 Fusing Unit (120V) 1
* B259 4004 Fusing Unit (230V) 1
1 B039 4102 Fusing Exit Guide 1
2 AA14 3716 Stepped Screw 2
3 AW10 0073 Thermistor 1
4 B039 4118 Front Ground Plate 1
5 B039 4120 Thermostat 2
6 B259 4015 Fusing Cleaning Roller 1
7 A232 2374 Spur 4
8 AA06 6637 Stripper Pawl Spring 5
9 AE04 4062 Stripper Pawls 5
10 B121 4111 Front Electrode Plate 1
11 B121 4120 Thermostat Ass'y 2
12 B121 4113 Short Electrode Plate 2
13 B121 4112 Long Electrode Plate 1
14 B121 4114 Rear Electrode Plate 1
15 B259 4091 Rear Heater Holder 1
16 B259 4028 Heater - 230V/550W 1
16 B259 4210 Heater - 120V/550W 1
17 G029 4140 External Circlip 2
18 B039 4171 Gear - 41Z 1
19 G052 4618 Bearing 30x42x7 2
20 AE01 1113 Hot Roller MM30 1
21 B121 4090 Front Heater Holder 1
22 AE02 0150 Pressure Roller 1
23 B039 4107 Fusing Exit Door 1
24 AA06 6635 Spring - Fusing Exit Guide 1
25 B039 4135 Pressure Roller Lever 2
26 AA06 2324 Pressure Spring 2
27 G029 4174 Pressure Roller Bushing 2
28 B245 4054 Frame: Pressure: Printing 1
29 B039 4170 Stripper Pawls Roller 5
30 B259 4115 Fusing Entrance Guide Plate 1
31 B039 4117 Discharge Brush 1
32 B039 4114 Rear Ground Plate 1
Part No.
Description
Q’ty Per
Assembly
Rev. 06/09/2010
Index
No.
33 B039 4168 Stripper Pawls Stopper 5
34 B259 4214 Heater - 230V/600W 1
34 B259 4215 Heater - 120V/600W 1
35 AA06 3570 Tension Spring 2
36 AA08 2073 Roller Busing 2
37 B121 4103 Frame: Fusing 1
101 0804 6123 Hexagonal Bolt: w/Washer: M3x8
102 0954 3010N Screw: Polished Round/Spring: M3x10
103 0452 3008N Tapping Screw - M3x8
104 0313 0060N Screw - M3X6
105 0954 3010N Screw: Polished Round/Spring: M3x10
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 41 Parts Location and List
18.PAPER EXIT SECTION
21
2
1
3
29
102
18
102
106
6
101
105
5
103
17
101
104
8
Model B043
41
102
19
23
31
102
39
40
31
35
33
19
22
5
31
34
20
26
43
41
25
24
B269/B277
102
102
27
B269/B277
13
9
14
10
11
104
32
41
15
16
42
42
36
37
38
44
7
12
B245/B276/B277 42 Parts Location and List
18.PAPER EXIT SECTION
Index
No.
1 B121 1084 Heater Wire Cover 1
2 B039 1234 Fusing Cover B245/B276 [TSB#024] 1
2 B123 1301 Fusing Cover B277 [TSB#024] 1
3 B259 4471 Exit Roller 2 1
4 B039 4473 Ring: Exit Roller 6
5 B120 2063 Bushing – 4mm 2
6 B039 1082 Door Switch Bracket 1
7 B121 5205 Harness - Front Door Switch 1
8 B039 1096 Door Switch Lever - 7 1
9 B039 1123 Door Switch Lever - 8 1
10 B039 1095 Door Switch Lever - 6 1
11 B039 1094 Door Switch Lever - 5 1
12 B039 1098 Door Switch Spring 1
13 B039 1093 Door Switch Lever - 4 1
14 B039 1092 Door Switch Lever - 3 1
15 B039 1099 Door Switch Lever - 2 1
16 B039 1090 Door Switch Lever - 1 1
17 B039 4119 Fusing Grounding Harness 1
18 B039 4116 Ground Plate - Fusing Unit 1
19 B121 4503 Exit Photointerruptor Bracket 1
20 B121 4451 Exit Middle Guide Plate 1
21 B121 5238 Harness - Paper Feed Sensor 1
22 G361 5570 Photointerruptor - Duplex 1
23 B043 4979 Exit Roller 4
24 B261 4983 Gate Pawl 1
25 AA06 6641 Gate Pawl Spring 1
26 B039 1163 Pulley - 23Z 1
27 B121 1132 Fusing Drive Release Bracket 1
29 B121 4473 Exit Roller Ring Mm14 2
31 G052 4873 Outer Exit Cover Roller 2
32 B121 4465 Short Front Outer Holder 1
33 B121 4469 Long Rear Middle Holder 1
34 B121 4477 Short Rear Outer Holder 1
35 B121 4467 Long Front Middle Holder 1
36 B121 4461 Exit Lower Guide Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
37 G029 4176 Turn Roller - Exit Sub-unit 2
38 B039 4459 Exit Roller Holder - Inner 2
39 G800 4854 Exit Roller 2
40 B123 4508 Middle: Reverse Holder 2
41 B122 4492 Large Exit Discharge Brush 2
42 B122 4493 Small Exit Discharge Brush 2
43 B121 1126 Harness Guide 1
44 B122 4460 Lower Exit Guide Plate 1
101 1204 2521 Micro Switch
102 0450 3008N Tapping Screw - M3x8
103 0451 3006N Tapping Screw - 3x6
104 0450 3012N Tapping Screw:3x12
105 0720 0030E Retaining Ring - M3
106 0450 4008N Tapping Screw - M4x8
Part No.
Description
Rev. 07/20/2010
Q’ty Per
Assembly
B245/B276/B277 43 Parts Location and List
19.DUPLEX UNIT 1 (B277)
B245/B276/B277 44 Parts Location and List
19.DUPLEX UNIT 1 (B277)
Index
No.
1 AF02 2138 Vertical Transport Roller 1
2 AA08 0268 Bushing - Vertical Transport 2
3 AA06 3399 Spring - Vertical Transport 2
4 B039 2558 Driven Roller 2
5 B282 4662 Guide Plate - Vertical Transport 1
6 B043 4676 Bracket - Duplex Entrance Sensor 1
7 G060 2641 Transport Driven Roller - Middle 3
8 AA08 0313 Driven Roller Bushing 6
9 B043 4647 Lower Spring Plate - Driven Roller 1
10 B123 4675 Exit Duplex Sensor Bracket 1
11 AW02 0181 Paper Feed Sensor 2
12 B123 4640 Driven Duplex Guide Plate Ass'y 1
14 B123 4670 Right Lower Exit Guide Plate Ass'y 1
18 B043 4645 Spring - 2n 2
19 B043 4646 Upper Spring Plate - Driven Roller 1
20 B043 4651 Door Lever 1
21 A250 1388 Spring 1
22 B043 4671 Bracket - Upper Guide Plate 2
23 B123 4679 Exit Sensor Cover 1
24 B043 4674 Cover - Duplex Entrance Sensor 1
25 B123 4977 Right Upper Exit Guide Plate Ass'y 1
26 B123 4617 Entrance Duplex Guide Plate 1
27 B123 4691 Decal 1
28 B123 5245 Harness:Duplex:Ground Wire 2
29 B043 4692 Grip Decal 1
30 B043 4642 Stopper - Guide Plate 1
31 B039 4480 Stepped Screw - M5 2
Part No.
Description
Q’ty Per
Assembly
Rev. 11/30/2006
Index
No.
101 0450 3008N Tapping Screw - M3x8
102 0451 3006N Tapping Screw - 3x6
103 1105 0511 Harness Clamp - LWS-0306ZC
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 45 Parts Location and List
20.DUPLEX UNIT 2 (B277)
32
102
22
6
1
3
102
10
14
12
11
27
12
15
104
13
103
16
102
101
19
17
103
18
19
17
102
101
4
5
9
102
17
20
20
17
21
7
8
104
17
28
24
102
105
103
102
29
23
30
103
101
102
102
17
35
31
25
103
2
101
17
17
103
26
104
103
102
34
106
101
B245/B276/B277 46 Parts Location and List
20.DUPLEX UNIT 2 (B277)
Index
No.
1 B043 4609 Duplex Lower Stay 1
2 B261 4710 Stepper Motor 1
3 B043 4667 By-pass Feed Guide - Lower 1
4 B043 4685 Spring - 2.8n 1
5 B261 4650 Separation Pad 1
6 B261 4624 Transport Roller:Drive:Duplex:Exit 1
7 B261 4623 Transport Roller - Connecting 1
8 B261 4625 Transport Roller:Drive:Duplex:Entrance 1
9 B043 4684 By-pass Feed Guide - Upper 1
10 B039 2610 Bracket - Paper End Sensor 1
11 B123 5252 Harness - Duplex Paper End Sensor 1
12 GW02 0020 Photointerruptor:LG248Nl1 1
13 B039 2611 Feeler - Paper End Sensor 1
14 AA06 6343 Spring - Paper End Sensor 1
15 AF03 1060 By-pass Feed Roller 1
16 B261 4686 Manual Feed Drive Shaft 1
17 AA08 2101 Bushing - 6x10x6 8
18 B043 4624 Pulley - 30Z 1
19 B123 4505 Timing Belt - 40S2M290 2
20 AB03 0569 Pulley - 30T 2
21 AG07 0514 Magnet Catch 1
22 B123 4661 Rear Duplex Inner Cover 1
23 B043 4714 Gear - 25Z 1
24 B043 4633 Gear - 22Z 1
25 B043 4713 Gear - 25Z 1
26 B043 4631 Gear - 38Z 1
27 B123 4697 Tension Spring 27n 1
28 B123 4627 Adhesion Duplex Cover 1
29 B123 5241 Harness - Duplex Unit 1
30 B043 4632 Coupled Gear 25/59z 1
31 B261 4705 Stepper Motor Bracket 1
32 B123 4693 Duplex Unit Stopper Ass'y 1
34 B043 4694 Chain Bracket 1
35 B043 4698 Cap - 30x36 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
102 0450 3008N Tapping Screw - M3x8
103 0720 0040E Retaining Ring - M4
104 1105 0511 Harness Clamp - LWS-0306ZC
105 1105 0009 Nylon Clamp - 5n
106 0433 0060N Pan Self-tapping Screw:3x6
107 0451 3006N Tapping Screw - 3x6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 47 Parts Location and List
21.DUPLEX UNIT 3 (B277)
1
16
105
104
102
3
106
104
2
4
18
105
5
15
9
6
7
103
12
14
102
11
8
10
103
102
17
102
17
13
102
B245/B276/B277 48 Parts Location and List
21.DUPLEX UNIT 3 (B277)
Index
No.
1 B043 4993 Reverser Shelf 1
2 B261 4989 Reverse Roller 1
3 B121 4490 Antistatic Brush 1
4 B043 4975 Gear - 18Z 1
5 B123 4981 Left Upper Reverse Guide Plate 1
6 B123 4973 Reverse Paper Feed Sensor Bracket 1
7 B123 5245 Harness:Duplex:Ground Wire 1
8 B043 4998 Rail - Reverser Shelf 1
9 GW01 0007 Photo Refiection Sensor:Exit 1
10 B043 4991 Coupled Gear - 15/51z 1
11 B261 4994 Stepper Motor Bracket 1
12 B261 4710 Stepper Motor 1
13 B261 4984 DC Solenoid:Ass'y 1
14 B123 4502 Middle Reverse Guide Plate 1
15 B123 5253 Harness - Duplex Sensor 1
16 B122 5255 Harness - 1bin Machine Or Copier 1
17 G104 5141 Knob Screw:M3 2
18 B123 4506 Reverse Roller Ground Plate 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3008N Tapping Screw - M3x8
102 0450 3008N Tapping Screw - M3x8
103 0313 0060N Screw - M3X6
104 0805 3383 Bushing - M5
105 0720 0040E Retaining Ring - M4
106 0451 3006N Tapping Screw - M3x6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 49 Parts Location and List
22.DRIVE SECTION
B245/B276/B277 50 Parts Location and List
22.DRIVE SECTION
Index
No.
1 B276 1055 Brushless Motor DC24V/20W 1
2 B259 1135 DC Solenoid Ass'y 1
3 B039 1162 Timing Belt - 226XL 1
4 AX20 0297 Magnetic Clutch - 39z 1
5 B039 1170 Gear - 63Z 1
6 B276 3310 Toner Bottle DC Motor 1
7 B039 1144 Bushing - 8x16x9 1
8 B039 1135 Development Terminal 1
9 B282 1128 OPC Drum Ground Plate 2 Ass'y 1
10 B121 1161 Large Spring 1
11 B259 1157 Fusing Swivel Bracket 1
12 B039 1156 Coupled Gear - 20/49z (12) 1
13 B039 1148 Drum Shaft (02) 1
14 B039 1145 Coupled Gear - 34/63z (01) 1
15 B039 1146 Coupled Gear - 32/71z (04) 1
16 B039 1155 Gear/pulley - 61/34Z (11) 1
17 B259 1174 Development Drive Shaft (03) 1
18 B039 1154 Coupled Gear - 37/97z (05) 1
19 B039 1173 Gear - 78Z (06) 1
20 B039 1168 Gear - 32Z (10) 1
21 B039 1167 Gear - 22Z (09) 1
22 B039 1165 Coupled Gear - 49/59/38z (08) 1
23 B039 1166 Gear - 37Z (07) 1
24 5304 1639 Bushing - 8mm 1
25 B121 1140 Main Drive Housing 1
26 AA10 0015 Snap Ring - M6 1
27 B121 1145 Harness Hook 1
28 B121 1162 Small Spring 1
Part No.
Description
Q’ty Per
Assembly
Rev. 10/11/2010
Index
No.
101 0450 4010N Tapping Screw: M4x10
102 0454 3008Q Tapping Screw
103 0720 0060E Retaining Ring - M6
104 0450 3008N Tapping Screw - M3x8
105 1105 0488 Harness Clamp
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 51 Parts Location and List
23.ELECTRICAL SECTION 1
Rev. 06/02/2008
101
112
102
4
3
112
102
102
102
102
102
25
102
6
5
2
Option
102
11
1
10
102
106
105
13
14
108
102
1
113
102
14
102
12
15
102
107
16
230V
21
23
20
26
114
102
19
22
102
102
104
18
9
24
102
8
111
17
18
B245/B276/B277 52 Parts Location and List
23.ELECTRICAL SECTION 1
Index
No.
1 B121 5208 Harness - Ground Wire Scanner 1
1 B122 5208 Ground Wire (B269/B277) 1
2 B121 5822 Guide Mylar 1
3 AX64 0145 Fan DC24V/1.92W 1
4 B121 5240 Harness - Document Feeder 1
5 B039 5831 ADF Plug Bracket 1
6 B123 1102 Rear Fan Bracket 1
8 B121 5215 Harness - Paper End Sensor No.1 1
9 B245 5101 PCB BICU: GW: EXP: Ass’y 1
9 B245 5103 PCB BICU: GW: EXP: Ass’y ASIA 1
9 B276 5101 PCB: BICU: US/EU [TSB#015] 1
9 B276 5103 PCB: BICU ASIA [TSB#015] 1
10 B121 5810 BICU Bracket 1
11 B243 5261 Harness - Key Counter 1
11 B243 5262 Harness - Key Counter Lan 1
12 B243 5217 Harness - AC Fusing EU 1
12 B243 5218 Harness - AC Fusing NA 1
13 AZ23 0200 Power Supply Unit (100V) 1
13 AZ23 0219 Power Supply Unit(230V) 1
14 B243 5018 Choke Coil - B2435018 1
15 B243 5228 Harness - AC Dehumidifier EXP 1
15 B244 5228 Harness - AC Dehumidifier EXP 1
16 B243 5226 Harness - AC Switch 187 1
17 B243 5230 Harness - Power Supply Unit 1
18 B121 5742 Power Supply Cord Stopper NA Ass'y 1
18 B039 5743 Power Supply Cord - 230v 1
19 B121 5825 Power Supply Cord Bracket 1
20 B121 5200 Harness - Scanner Motor 1
21 B243 5203 Harness - Main Motor 1
22 B122 5211 Harness - Paper Feed No.2 1
23 B121 5212 Harness - Manual Feed 1
24 B121 5220 Harness - Hps 1
25 B122 5821 Box Holder 1
26 B121 5205 Harness-Front Door Switch [TSB#022] 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3008N Tapping Screw - M3x8
102 0451 3006N Tapping Screw - M3x6
104 AA14 3592 Philips Pan Head Screw - M4x6
105 1105 0487 Harness Clamp
106 1105 0511 Harness Clamp - LWS-0306ZC
107 1107 1063 Fuse: ET-2.5A
107 1107 1083 Fuse: SST 4
108 1107 0629 Fuse: 15A:125V
112 0451 3030N Tapping Screw: 3x30
113 1204 2608 Rocker Switch: Sddje33900
114 1407 5299 RAM: FM1608-120-P [TSB#013R] 1
Part No.
Description
Rev. 05/21/2009
Q’ty Per
Assembly
B245/B276/B277 53 Parts Location and List
24.ELECTRICAL SECTION 2
101
101
103
15
101
18
101
17
101
101
3
104
101
102
101
7
4
6
11
101
101
101
9
8
10
102
102
19
20
101
101
16
101
1
15
101
2
12
101
101
14
5
101
B269/B277
101
B245/B276/B277 54 Parts Location and List
24.ELECTRICAL SECTION 2
Index
No.
1 B123 5243 Harness Duplex Ass'y 1
2 B244 5155 PCB DCB 1
3 B039 1073 Right Door Stopper 2
4 B121 1110 Upper Main Duct 1
5 B122 1075 Front Reverse Sub-unit Holder 1
6 B121 1112 Frame Duct 1
7 B121 1108 Lower Main Duct Ass'y 1
8 B259 1119 Tapping Screw:M3x33 2
9 B259 1106 Fan Motor - MM80 1
10 B121 1107 Exhaust Duct 1
11 B121 1109 Left Duct Ass'y 1
12 B123 5851 Dcu Bracket 1
14 B039 5887 Heater Switch Cover 1
15 B121 5841 Bct Power Pack Bracket 1
16 AZ32 0152 Power Pack Bct 1
17 G020 5871 Spacer - KGLS-12RF 2
18 B243 5232 Harness - High Voltage Line B 1
19 B243 5233 Harness - High Voltage Line C/T 1
20 B243 5231 Harness - High Voltage 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
102 0450 3008N Tapping Screw - M3x8
103 1105 0487 Harness Clamp
104 1105 0499 Support Spacer - M3x29
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 55 Parts Location and List
25.FRAME SECTION 1
Rev. 08/23/2010
101
102
101
101
101
103
101
1
104
101
3
104
3
103
101
4
4
104
103
101
103
8
103
104
103
101
7
109
105
9
104
11
105
4
10
106
4
3
101
12
3
105
106
14
105
105
5
107
101
13
101
101
5
Option
104
15
16
108
B245/B276/B277 56 Parts Location and List
2
103
5
102
101
101
101
101
101
6
101
101
101
25.FRAME SECTION 1
Index
No.
1 B121 1368 Rear Cover:Exit NA 1
1 B121 1367 Rear Exit Cover B EU 1
1 B122 1370 Rear Exit Cover NA 1
1 B122 1369 Rear Exit Cover EU 1
2 B259 6058 Heater:Paper Feed:No.1:EU:Ass'y 1
3 B039 1072 Grip 4
4 B121 1070 Grip Bracket 2 4
5 AH01 0009 Rubber Pad - H5 4
6 B259 1053 Shaft:Door:Right Front:Ass'y 1
7 B121 5802 Guide Plate Bracket 1
8 B243 5018 Choke Coil - B2435018 1
9 B121 5801 Power Supply Unit Bracket 1
10 B121 4201 Front Heater Bracket 1
11 B180 2801 Holder:Paper Tray 1
12 B259 1058 Shaft:Door:Right Rear:Ass'y 1
13 G020 5626 Push Switch 1
14 B121 1128 OPC Drum Ground Plate 2 Ass'y 1
15 B039 2782 Tray Heater 120V 1
15 B039 2783 Tray Heater 220V 1
16 B243 5260 Harness - AC Dehumidifier 120V 1
16 B244 5229 Harness - AC Dehumidifier 220V 1
17 Deleted Use item #15 [TSB#031]
17 Deleted Use item #15 [TSB#031]
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
102 0451 3008N Tapping Screw - M3x8
103 0454 3006Q Tapping Screw With Washer - M3x6
104 1105 0511 Harness Clamp - LWS-0306ZC
105 1105 0487 Harness Clamp
106 1105 0197 Wire Saddle
107 0450 3008N Tapping Screw - M3x8
108 0950 3006N Screw:Spring Washer:M3x6
109 1105 0488 Harness Clamp
Part No.
Description
Rev. 08/23/2010
Q’ty Per
Assembly
B245/B276/B277 57 Parts Location and List
26.FRAME SECTION 2 (B277)
B245/B276/B277 58 Parts Location and List
26.FRAME SECTION 2 (B277)
Index
No.
1 B040 6143 Right Bracket - Rear Lower Cover 1
2 B040 6054 Left Rail 1
3 B040 6052 Right Rail 1
4 B040 6144 Left Bracket - Rear Lower Cover 1
5 B039 2754 Bracket - Paper Size Sensor 1
6 G800 3035 Push Sw - Paper Size 1
7 B040 6149 Lower Heater Bracket 1
8 B244 5229 Harness - AC Dehumidifier 1
9 B180 2801 Holder:Paper Tray 1
10 AH01 0009 Rubber Pad - H5 4
11 B040 6046 Support Bracket - Paper Switch 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - M3x6
102 1105 0511 Harness Clamp - LWS-0306ZC
103 0950 3006N Sem,s Screw - M3 X 6
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 59 Parts Location and List
27.DDST UNIT
Rev. 10/11/2007
78
9
101
4
101
3
101
1
101
2
101
101
101
101
101
5
101
6
101
101
101
101
101
101
103
101
B245/B276/B277 60 Parts Location and List
101
27.DDST UNIT
Index
No.
1 B622 5880 Cover - Expand 1
2 B865 5171 PCB Gdi-Basic (B865) (RLA only) 1
2 B866 5171 PCB Gdi-NOB (B866) 1
3 B243 5870 PCB Bracket 1
4 B622 5872 Rail Holder 1
5 B243 5879 Cover - Card 1
6 B243 5874 Cover - PCB (B865) (RLA only) 1
6 B243 5875 Cover - GDI (B866) 1
7 B243 1466 Cover - CPS NA 1
7 B243 1468 Cover - CPS EU 1
8 B865 8592 Operating Instructions - Printer 1
9 B895 5171 PCB: Dongle: Ass’y [TSB#017] 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0451 3006N Tapping Screw - 3x6
103 Deleted EEPROM:AT24C64A-10PU-2.7 [TSB#013R]
Part No.
Description
Rev. 09/20/2010
Q’ty Per
Assembly
B245/B276/B277 61 Parts Location and List
28.BICU BOARD (B245)
CAPACITOR
SYMBOL
NO.
C1 185
C2 185
C3 172
C4 185
--- ---
--- --C7 172
C8 182
--- ---
--- ---
INDEX
NO.
CAPACITOR
SYMBOL
NO.
--- ---
--- ---
C73 199
--- ---
C75 182
INDEX
NO.
SYMBOL
NO.
--- --C12 185
--- ---
--- ---
--- ---
--- --C17 185
--- ---
--- --C20 184
SYMBOL
NO.
C81 185
--- ---
--- --C84 185
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C21 185
--- ---
--- ---
--- ---
--- ---
--- ---
--- --C28 185
--- ---
--- ---
SYMBOL
NO.
C91 181
C92 187
C93 185
C94 185
C95 185
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- --C32 185
--- --C34 185
--- ---
--- --C37 182
--- --C39 199
C40 182
SYMBOL
NO.
C101 185
C102 182
C103 182
C104 179
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C41 182
--- --C43 185
C44 185
C45 185
C46 185
C47 185
C48 182
C49 185
C50 185
SYMBOL
NO.
C111 182
C112 173
C113 173
--- ---
C115 185
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C51 185
C52 185
C53 185
C54 185
C55 185
C56 185
C57 185
C58 185
C59 178
C60 178
SYMBOL
NO.
C121 182
--- ---
--- ---
--- ---
C125 187
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C61 183
C62 178
C63 183
C64 182
C65 187
C66 187
C67 182
--- ---
--- ---
--- ---
SYMBOL
NO.
C131 182
C132 182
C133 185
C134 185
C135 185
INDEX
NO.
INDEX
NO.
C76 187
C77 187
C78 185
--- ---
C80 175
B245/B276/B277 62 Parts Location and List
--- --C87 185
C88 182
C89 185
C90 182
C96 185
C97 182
C98 185
C99 185
C100 185
C106 187
C107 182
C108 187
C109 182
C110 182
C116 185
C117 187
C118 187
C119 187
--- ---
C126 187
C127 187
C128 180
C129 180
C130 187
C136 185
C137 178
C138 185
C139 201
--- ---
28.BICU BOARD (B245)
CAPACITOR
SYMBOL
NO.
C141 182
--- ---
C143 187
C144 187
C145 182
C146 179
C147 179
C148 182
C149 187
C150 182
INDEX
NO.
CAPACITOR
SYMBOL
NO.
C211 178
C212 178
C213 178
C214 179
C215 182
INDEX
NO.
SYMBOL
NO.
C151 187
C152 185
C153 185
C154 182
C155 185
C156 179
C157 187
C158 182
C159 187
C160 182
SYMBOL
NO.
--- ---
--- ---
C223 185
--- ---
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C161 187
C162 182
C163 182
C164 187
--- ---
C166 185
--- --C168 187
C169 185
C170 185
SYMBOL
NO.
--- --C232 182
C233 182
C234 182
C235 182
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C171 184
C172 179
C173 179
C174 179
C175 243
C176 179
C177 179
C178 179
C179 179
C180 179
SYMBOL
NO.
C241 179
C242 244
C243 186
C244 179
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C181 179
C182 179
C183 179
C184 244
C185 182
C186 177
C187 179
--- --C189 178
C190 182
SYMBOL
NO.
C251 179
C252 182
C253 179
--- ---
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C191 178
--- --C193 182
C194 185
C195 182
--- ---
--- ---
--- --C199 182
C200 185
SYMBOL
NO.
C261 185
C262 187
C263 187
C264 187
C265 185
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- ---
--- ---
C205 183
C206 183
--- ---
C208 180
--- ---
C210 182
SYMBOL
NO.
--- --C272 187
C273 187
C274 187
C275 179
INDEX
NO.
INDEX
NO.
C216 185
--- ---
--- --C219 185
C220 182
B245/B276/B277 63 Parts Location and List
--- ---
--- ---
--- --C229 201
C230 201
C236 185
C237 185
C238 185
--- ---
C240 185
C246 178
C247 178
C248 178
C249 178
C250 178
--- --C257 182
C258 179
--- --C260 185
C266 185
C267 185
C268 173
C269 172
C270 185
C276 182
--- --C278 173
C279 182
C280 182
28.BICU BOARD (B245)
CAPACITOR
SYMBOL
NO.
C281 182
--- ---
C283 185
--- ---
--- ---
C286 184
C287 184
C288 182
C289 185
C290 182
INDEX
NO.
CAPACITOR
SYMBOL
NO.
C351 185
--- --C353 185
C354 185
--- ---
INDEX
NO.
SYMBOL
NO.
C291 187
C292 179
C293 181
C294 179
C295 182
C296 187
C297 182
C298 179
C299 182
C300 179
SYMBOL
NO.
C361 179
C362 179
C363 182
--- ---
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C301 187
C302 179
C303 179
C304 182
C305 185
C306 179
C307 179
C308 179
C309 179
C310 179
SYMBOL
NO.
C371 185
C372 185
C373 182
C374 185
C375 182
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C311 179
C312 179
C313 179
C314 179
C315 176
C316 182
C317 179
C318 179
C319 179
C320 179
SYMBOL
NO.
C381 182
--- --C383 182
C384 182
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C321 179
C322 179
C323 179
C324 182
C325 185
C326 182
--- ---
--- --C329 185
C330 182
SYMBOL
NO.
--- --C392 182
--- --C394 246
--- ---
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
C331 179
C332 179
C333 187
C334 182
C335 187
C336 182
--- ---
C338 182
--- ---
--- ---
SYMBOL
NO.
C401 174
C402 246
C403 174
C404 186
C405 246
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- ---
C344 179
--- ---
--- --C347 179
C348 179
C349 200
C350 200
SYMBOL
NO.
C411 174
C412 174
C413 246
C414 246
C415 246
INDEX
NO.
INDEX
NO.
C356 182
C357 185
C358 179
C359 182
--- ---
B245/B276/B277 64 Parts Location and List
C366 185
--- ---
--- ---
--- ---
C370 182
C376 179
--- ---
--- ---
C379 185
--- ---
C386 182
C387 182
C388 185
C389 175
--- ---
--- --C397 175
C398 246
C399 174
C400 246
C406 174
C407 245
C408 246
C409 174
C410 174
--- ---
--- --C418 246
C419 174
C420 246
28.BICU BOARD (B245)
CAPACITOR
CONNECTOR
SYMBOL
NO.
C421 174
C422 174
C423 246
C424 174
C425 246
--- ---
--- ---
--- --C429 179
C430 185
SYMBOL
NO.
--- ---
CN 132 104
--- ---
CN 134 108
--- ---
CN 136 104
CN 137 111
CN 138 103
--- ---
--- ---
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
C431 182
C432 174
C433 175
C434 175
C435 182
C436 174
--- ---
--- --C439 174
C440 174
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- --C444 185
C445 185
--- ---
--- ---
--- ---
--- ---
--- ---
INDEX
DIODECONNECTOR FIL
SYMBOL
NO.
CN 141 106 D 1 136
INDEX
NO.
SYMBOL
NO.
D 2 136
D 3 134
D 4 136
D 5 137
D 6 137
D 7 136
D 8 137
D 9 136
D 10 136
INDEX
NO.
NO.
SYMBOL
NO.
--- ---
--- ---
--- ---
C614 245
SYMBOL
NO.
D 11 136
D 12 136
D 13 136
--- --D 15 136
D 16 136
D 17 136
--- --D 19 136
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
CN 101 122
CN 102 117
--- --CN 104 123
CN 105 113
--- --CN 107 121
--- --CN 109 114
--- ---
SYMBOL
NO.
FI L1 189
FI L2 188
FI L3 171
FI L4 171
--- ---
--- ---
FI L7 191
FI L8 190
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
CN 111 119
CN 112 113
--- --CN 114 108
CN 115 109
CN 116 115
CN 117 110
CN 118 102
--- --CN 120 107
IC
SYMBOL
NO.
--- ---
I C2 157
I C3 146
I C4 149
--- ---
I C6 154
--- ---
--- ---
I C9 248
I C10 142
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
CN 121 101
CN 122 118
CN 123 116
CN 124 120
CN 125 102
CN 126 109
--- ---
CN 128 112
--- ---
CN 130 105
SYMBOL
NO.
I C11 139
I C12 151
IC13 3
I C14 247
I C15 142
I C16 140
I C17 247
I C18 140
I C19 158
--- ---
INDEX
INDEX
NO.
NO.
B245/B276/B277 65 Parts Location and List
28.BICU BOARD (B245)
IC
OSC Q
RESISTOR
SYMBOL
NO.
I C21 143
I C22 139
I C23 140
I C24 145
I C25 148
I C26 139
IC27 2
I C28 141
I C29 150
I C30 146
INDEX
RESISTOR
SYMBOL
NO.
R11 214
R12 215
R13 215
R14 229
R15 229
INDEX
NO.
NO.
SYMBOL
NO.
IC31 1
I C32 124
I C32 250
I C33 141
I C34 147
--- ---
--- ---
--- ---
I C38 249
--- ---
SYMBOL
NO.
R21 213
R22 214
R23 219
R24 226
R25 226
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
I C40 159
I C41 144
I C42 144
LED
SYMBOL
NO.
LE D 2 138
SYMBOL
NO.
R31 214
R32 218
R33 218
R34 212
R35 226
INDEX
NO.
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
OS C1 160 Q 1 125
SYMBOL
NO.
R41 214
R42 214
R43 221
R44 221
R45 221
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
Q2 131
Q3 132
Q4 128
Q5 126
Q6 126
Q7 127
Q8 131
Q9 131
Q10 130
SYMBOL
NO.
R51 213
--- --R53 214
--- --R55 213
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
Q11 131
Q12 129
SYMBOL
NO.
--- ---
R62 219
R63 237
R64 239
R65 228
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R1 213
R2 216
--- --R4 212
R5 218
R6 218
R7 213
R8 222
R9 226
R10 214
SYMBOL
NO.
R71 219
R72 214
--- ---
R74 222
R75 213
INDEX
NO.
INDEX
NO.
--- --R17 213
R18 213
--- --R20 213
B245/B276/B277 66 Parts Location and List
R26 226
R27 219
R28 219
R29 223
R30 226
R36 218
R37 229
R38 226
R39 222
--- ---
R46 221
R47 229
R48 214
R49 213
--- ---
R56 214
R57 213
R58 235
R59 234
--- ---
R66 226
R67 237
R68 242
R69 238
R70 239
R76 235
R77 234
R78 213
R79 218
R80 229
28.BICU BOARD (B245)
RESISTOR
SYMBOL
NO.
R81 221
R82 213
R83 221
R84 207
R85 214
R86 221
R87 221
R88 221
R89 214
R90 213
INDEX
RESISTOR
SYMBOL
NO.
--- ---
--- ---
--- --R154 206
R155 219
INDEX
NO.
NO.
SYMBOL
NO.
R91 214
R92 214
R93 214
R94 214
R95 214
R96 213
R97 214
R98 223
R99 226
R100 226
SYMBOL
NO.
R161 198
R162 208
R163 209
R164 209
R165 221
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R101 223
R102 221
R103 215
R104 229
R105 214
R106 213
R107 214
R108 227
R109 215
R110 218
SYMBOL
NO.
--- --R172 222
R173 214
R174 221
R175 229
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R111 213
R112 213
R113 213
R114 213
R115 213
R116 213
R117 213
R118 214
R119 213
--- ---
SYMBOL
NO.
R181 214
R182 221
R183 214
--- ---
R185 221
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R121 226
R122 213
R123 214
R124 214
--- ---
--- ---
R127 215
--- --R129 214
R130 221
SYMBOL
NO.
R191 224
R192 214
R193 221
R194 222
R195 214
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- --R132 214
R133 229
R134 229
R135 221
R136 221
R137 215
R138 213
R139 223
R140 226
SYMBOL
NO.
R201 221
R202 221
R203 222
R204 221
R205 213
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R141 226
R142 214
R143 222
R144 222
R145 214
R146 214
R147 226
R148 219
R149 219
R150 221
SYMBOL
NO.
R211 163
R212 161
--- ---
--- ---
--- ---
INDEX
NO.
INDEX
NO.
R156 219
R157 226
R158 226
R159 214
R160 214
B245/B276/B277 67 Parts Location and List
R166 214
--- --R168 221
R169 229
--- ---
R176 214
R177 214
--- --R179 162
R180 221
R186 214
R187 229
R188 220
R189 221
R190 216
R196 221
R197 221
R198 221
R199 229
R200 221
R206 213
R207 213
R208 240
R209 236
R210 233
R216 221
R217 221
R218 221
R219 221
R220 213
28.BICU BOARD (B245)
RESISTOR
SYMBOL
NO.
R221 217
R222 230
--- --R224 221
R225 209
R226 209
R227 217
R228 230
R229 214
R230 214
INDEX
RESISTOR
SYMBOL
NO.
R291 232
R292 232
R293 232
R294 213
R295 214
INDEX
NO.
NO.
SYMBOL
NO.
--- ---
--- ---
--- --R234 221
R235 213
R236 214
R237 221
R238 221
R239 221
R240 221
SYMBOL
NO.
R301 221
R302 213
R303 221
R304 221
R305 215
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R241 221
R242 221
R243 229
R244 221
R245 229
R246 214
R247 229
R248 221
R249 214
R250 226
SYMBOL
NO.
--- ---
--- --R313 215
R314 215
R315 221
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- --R252 221
R253 214
--- --R255 214
R256 213
R257 213
R258 214
R259 214
R260 218
SYMBOL
NO.
--- --R322 214
R323 226
R324 226
R325 229
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R261 223
R262 213
--- --R264 231
R265 214
R266 241
R267 213
R268 204
--- --R270 214
SYMBOL
NO.
R331 198
R332 213
R333 214
R334 229
R335 213
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
--- --R272 213
R273 226
R274 226
R275 214
R276 226
--- ---
--- ---
--- --R280 214
SYMBOL
NO.
R341 197
R342 197
R343 209
R344 221
R345 214
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R281 221
--- ---
--- --R284 213
R285 221
R286 221
R287 222
R288 214
--- --R290 198
SYMBOL
NO.
R351 205
R352 206
R353 206
R354 206
R355 206
INDEX
NO.
INDEX
NO.
R296 226
R297 214
R298 229
R299 162
R300 213
B245/B276/B277 68 Parts Location and List
R306 214
--- --R308 221
R309 221
--- ---
R316 221
R317 221
--- --R319 232
R320 232
R326 226
R327 214
R328 214
R329 229
R330 229
R336 229
R337 214
R338 226
R339 213
R340 229
R346 198
--- ---
--- --R349 198
R350 208
--- --R357 211
R358 202
R359 206
R360 207
28.BICU BOARD (B245)
RESISTOR
REG RN
SYMBOL
NO.
R361 207
R362 203
R363 206
R364 214
R365 225
--- ---
--- ---
--- --R369 232
R370 198
RN
SYMBOL
NO.
RN31 170
RN32 194
RN33 194
RN34 194
RN35 165
INDEX
NO.
INDEX
NO.
SYMBOL
NO.
R371 205
R372 232
--- --R374 229
R375 229
R376 229
R377 210
R378 213
R379 214
--- ---
SYMBOL
NO.
RN41 168
RN42 168
RN43 168
RN44 193
RN45 193
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
--- ---
--- --R383 214
R384 214
SYMBOL
NO.
R N51 166
R N52 168
R N53 168
R N54 168
--- ---
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
RE G 1 155
RE G 2 152
RE G 3 156
RE G 4 153
SYMBOL
NO.
R N61 195
R N62 194
--- --R N64 196
R N65 168
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
--- ---
--- --RN3 167
RN4 167
RN5 167
RN6 167
RN7 167
RN8 167
RN9 167
RN10 167
SYMBOL
NO.
RN71 165
--- ---
RN73 167
RN74 167
RN75 170
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
RN11 167
RN12 167
RN13 167
RN14 167
RN15 167
RN16 169
RN17 194
RN18 194
RN19 167
RN20 170
SYMBOL
NO.
RN81 192
RN82 192
RN83 192
RN84 192
RN85 192
INDEX
INDEX
NO.
NO.
SYMBOL
NO.
RN21 167
RN22 167
RN23 167
RN24 167
--- ---
RN26 170
RN27 166
RN28 168
RN29 194
RN30 167
SYMBOL
NO.
RN91 167
RN92 167
RN93 193
RN94 167
RN95 167
INDEX
INDEX
NO.
NO.
--- ---
--- ---
--- ---
--- ---
--- ---
B245/B276/B277 69 Parts Location and List
RN46 194
--- --RN48 168
RN49 194
RN50 194
R N56 168
R N57 168
R N58 168
--- ---
--- ---
R N66 196
R N67 192
R N68 196
R N69 192
R N70 194
RN76 196
RN77 196
RN78 196
RN79 196
RN80 196
RN86 164
RN87 168
RN88 169
RN89 169
RN90 194
RN96 168
RN97 194
RN98 194
RN99 193
RN100 169
28.BICU BOARD (B245)
RN ZD
SYMBOL
NO.
RN 101 167
RN 102 167
--- --RN 104 194
RN 105 165
RN 106 165
RN 107 167
RN 108 167
RN 109 169
RN 110 169
INDEX
NO.
SYMBOL
NO.
RN 111 167
RN 112 167
RN 113 168
RN 114 168
RN 115 192
RN 116 193
RN 117 168
RN 118 192
RN 119 192
RN 120 193
INDEX
NO.
SYMBOL
NO.
RN 121 168
--- ---
RN 123 167
--- ---
--- ---
--- --RN 127 194
RN 128 193
RN 129 193
INDEX
NO.
SYMBOL
NO.
ZD 1 135
ZD 2 135
ZD 3 133
INDEX
NO.
B245/B276/B277 70 Parts Location and List
28.BICU BOARD (B245)
Index
No.
* B245 5101 PCB BICU 1
* B245 5103 PCB BICU ASIA 1
1 B040 5506 IC:IMAC_K:RF5C789 1
2 B121 5501 IC:Scratch:KS6M2U1651CBP 1
3 B121 5502 LSI:TRIO:UPD65945GD-103-LML-A 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 1102 4201 Connector - 2P
102 1102 4203 CT Header - 4P
103 1102 4205 CT Header - 6P
104 1102 4207 Connector - 8P
105 1102 5301 Connector - 2P
106 1102 5302 Connector - 3P
107 1102 5303 Connector - 4P
108 1102 6295 Connector - 2P
109 1102 6297 Connector - 4P
110 1102 6299 Connector - 6P
111 1102 6396 Connector - 1P
112 1102 8545 Connector - 1-353297-6
113 1102 8655 Connector - 9P 353297-9
114 1102 8661 Connector - FCN-564P068-G/SC-4V
115 1102 9108 Connector - 353297-3
116 1102 9109 Connector - 353297-4
117 1102 9110 Connector - 353297-6
118 1102 9111 Connector - 353297-7
119 1102 9112 Connector - 353297-8
120 1102 9114 Connector - 353297-1
121 1102 9132 Connector - 353303-7
122 1103 3179 Connector:FH12-50S-0.5SV(89)
123 1103 3733 Connector:SLD5R-1LF
124 1104 0588 DIP Socket - 28p
125 1400 0702 Transistor - DTD143EK
126 1400 0789 Transistor - IMT17
127 1400 0901 Transistor - DTC144VUA
128 1400 0953 Transistor - 2SC4081S
129 1400 0962 Transistor - 2SB1412
130 1400 1163 Transistor - 2SA1979UF
131 1400 1174 Transistor - SRC1219UF
132 1401 1228 Fet:SI3433DV-E3
133 1402 1511 Zenerdiode - MTZJ13B
134 1402 1565 Diode - RB
135 1402 1662 Diode:PTZ6.2B
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 71 Parts Location and List
Index
No.
Part No.
Description
Q’ty Per
Assembly
136 1402 1911 Diode - SDS511
137 1402 1912 Diode - SDS142WMF
138 1403 1266 LED - KPT-1608EC
139 1407 2187 TTLIC - SN74LS07NS
140 1407 2219 IC - TD62003AP
141 1407 5353 IC - SN74LV244APW
142 1407 5368 IC - 74LVC245A TSSOP
143 1407 5376 IC - SN74LV32APW
144 1407 5382 CMOS Logic - SN74LV373APW
145 1407 5454 IC - SN74LV86APW
146 1407 5469 IC - SN74LV07APW
147 1407 5555 IC - SN74AHCT126PW
148 1407 6032 IC - SN74LV161APW
149 1407 6525 CPU - HD6412320VF25V
150 1407 6584 IC - STK672-400B-E
151 1408 1204 IC - TA8083P
152 1408 1290 Regulator - TA7805S
153 1408 1428 Regulator - TA78M12S
154 1408 1550 IC - LM2902PW
155 1408 1669 Series Regulator:R1170H331B
156 1408 1850 Regulator - R1170H181B
157 1408 1911 Comparator - LM2903PW
158 1408 1929 IC - R3112Q441A
159 1408 2316 IC - R3112Q381A-FA
160 1503 0993 Crystal Oscilator- 14.7456Mhz
161 1600 1334 Resistor-220Ω±5%2W
162 1600 1682 Resistor - 680 Ω ±5% 2W
163 1601 5492 Resistor - 47Ω ±5% 2W
164 1601 7875 Resistor Array - 150Ω ±5%
165 1601 7877 Resistor Array 4.7k Ω ±5% 1/32W
166 1601 7886 Resistor Array 3.3k Ω ±5% 1/32W
167 1601 7887 Resistor Array - 10K Ω ±5% 1/32W
168 1601 7898 Resistor Array
169 1601 7943 Resistor Array - 68 Ω ±5% 1/32W
170 1601 7959 Resistor
Index
No.
Part No.
171 1602 7026 Capacitor - 1000pF ±20% 100V
172 1604 5524 Capacitor - 100μF±20% 50V
173 1604 5526 Capacitor - 47μF±20% 10V
174 1605 1137 Capacitor - 470pF ±10% 50V
175 1605 1148 Capacitor - 0.1μF+80-20% 50V
176 1605 1166 Capacitor - 0.015μF±10% 50V
177 1605 1190 Resistor - 0.022μF±10% 50V
178 1605 1201 Capacitor - 12pF ±5% 50V
179 1605 1206 Capacitor - 47pF ±5% 50V
180 1605 1208 Capacitor:100pF:±5%:50V
181 1605 1209 Capacitor - 150pF ±5% 50V
182 1605 1221 Capacitor - 0.1 UF+80-20%16V
183 1605 1293 Capacitor - 27pF±5%50V
184 1605 1295 Capacitor:10uf:+80-20%:10V
185 1605 1303 Capacitor - 0.01μF+80-20% 50V
186 1605 1347 Capacitor - 1UF:+80-20%:16V
187 1605 1447 Resistor - 470pF ±5% 50V
188 1607 0069 Fuse - BL02RN2-R62-PB
189 1607 1002 IC - NFM60R30T222
190 1607 1107 IC - LC0805L104M
191 1607 1298 Filter - LCZ0805S224M7
192 1609 0005 Registor:33 Ω:±5%:1/16W
193 1609 0006 Registor:10k Ω:±5%:1/16W
194 1609 0007 Resistor - 68Ω ±5% 1/16W
195 1609 0019 Registor:0 Ω:1608
196 1609 0027 Resistor - 100KΩ±5% 1/16W
197 1633 0000 Resistor - 0 Ω 1/10W
198 1634 0000 Resistor - 0 Ω 1/16W
199 1640 0101 Capacitor - 100μF10V
200 1640 5470 Capacitor - 47μF±20% 50V
201 1642 5100 Capacitor - 10μF±20% 50V
202 1650 2472 Chip Resistor-4.7k
203 1650 2620 Resistor - 62Ω ±5% 1/4W
204 1650 3201 Resistor - 200Ω ±5% 1/8W
205 1650 4102 Resistor - 1KΩ ±5% 1/10W
Description
Q’ty Per
Assembly
B245/B276/B277 72 Parts Location and List
Index
No.
Part No.
Description
Q’ty Per
Assembly
206 1650 4103 Resistor - 10KΩ ±5% 1/10W
207 1650 4104 Resistor - 100KΩ±5%1/10W
208 1650 4220 Chip Resistor - 22Ω ±5% 1/10W
209 1650 4330 Chip Resistor - 33Ω ±5% 1/10W
210 1650 4331 Resistor - 330Ω±5%1/10W
211 1650 4472 Resistor - 4.7KΩ ±5% 1/10W
212 1650 5100 Chip Resistor - 10 Ω±5%1/16W
213 1650 5102 Chip Resistor - 1kΩ±5%1/16W
214 1650 5103 Chip Resistor - 10kΩ±5%1/16W
215 1650 5104 Chip Resistor - 100kΩ±5%1/16W
216 1650 5105 Chip Resistor - 1mΩ±5%1/16W
Index
No.
241 1655 7871 Resistor - 7.87K Ω ±1% 1/16W
242 1655 9101 Resistor - 9.1K Ω ±1% 1/16W
243 1660 2120 Capacitor - 12 pF ±5% 50V
244 1660 2270 Capacitor - 27pF ±20% 35V
245 1660 2470 Capacitor - 47pF ±5% 50V
246 1660 8104 Capacitor - 0.1μF+80-20% 25V
247 1902 0070 SRAM - 1M:X8:3.3V:G2
248 1906 0094 Flash Memory - S29AL016D70TFI020
249 1907 0012 SDRAM - 128M 2MX16X4 133Mhz
250 1407 5299 RAM:FM1608-120-P
217 1650 5203 Resistor - 20KΩ ±5% 1/16W
218 1650 5222 Resistor - 2.2KΩ ±5% 1/16W
219 1650 5243 Resistor - 24KΩ ±5% 1/16W
220 1650 5244 Resistor:240k Ω:±5%:1/16w:1005
221 1650 5330 Chip Resistor - 33Ω±5%1/16W
222 1650 5331 Resistor - 330Ω ±5% 1/16W
223 1650 5332 Resistor - 3.3KΩ ±5% 1/16W
224 1650 5391 Resistor - 390Ω ±5% 1/16W
225 1650 5470 Chip Resistor 47Ω ±5% 1/16W
226 1650 5472 Chip Resistor:4.7kΩ:±5%:1/16W
227 1650 5511 Resistor - 510Ω ±5% 1/16W
228 1650 5624 Resistor - 620KΩ ±5% 1/16W
229 1650 5680 Resistor - 68
Ω ±5% 1/16W
230 1650 5750 Chip Resistor:75Ω:±5%:1/16W
231 1650 5751 Resistor:750 Ω:±5%:1/16W:1005
232 1655 0000 Chip Resistor - 0Ω±0%1/16W
233 1655 1001 Chip Resistor - 1kΩ ±1% 1/16W
234 1655 1002 Chip Resistor - 10kΩ±1%1/16W
235 1655 1003 Chip Resistor - 100kΩ±1%1/16W
236 1655 1302 Resistor - 13K Ω ±1% 1/16W
237 1655 1801 Resistor - 1.8K Ω ±1% 1/16W
238 1655 2551 Resistor - 2.55K Ω ±1% 1/16W
239 1655 3301 Resistor - 3.3K Ω ±1% 1/16W
240 1655 6041 Resistor - 6.04K Ω ±1% 1/16W
Part No.
Description
Q’ty Per
Assembly
B245/B276/B277 73 Parts Location and List
29.BICU BOARD (B276/B277)
IC JP LED OSC
SYMBOL
NO.
C1 196
C2 196
C3 183
C4 196
C5 190
INDEX
NO.
SYMBOL
NO.
C11 196
C12 196
C13 196
C14 196
C15 196
INDEX
NO.
IC JP JP
SYMBOL
NO.
C21 196
C22 196
C23 196
C24 196
C25 196
INDEX
NO.
SYMBOL
NO.
C31 196
C32 196
C33 190
C34 196
--- ---
INDEX
NO.
SYMBOL
INDEX
NO.
C41 193
--- --C43 196
C44 196
C45 196
NO.
SYMBOL
NO.
C51 196
C52 196
C53 196
C54 196
C55 196
INDEX
NO.
SYMBOL
NO.
C61 194
C62 189
C63 194
C64 193
C65 198
INDEX
NO.
--- --C7 183
C8 193
C9 196
C10 196
C16 196
C17 196
C18 196
C19 196
C20 190
Q RESISTOR
SYMBOL
NO.
--- ---
--- ---
C73 210
--- ---
C75 193
C76 198
C77 198
C78 196
C79 190
C80 186
INDEX
NO.
SYMBOL
NO.
C81 196
C82 196
C83 196
C84 196
C85 196
C86 196
C87 196
C88 193
C89 196
C90 193
INDEX
NO.
C26 196
C27 196
C28 196
C29 196
C30 196
C36 190
C37 193
C38 190
C39 210
C40 193
C46 196
C47 196
C48 193
C49 196
C50 196
C56 196
C57 196
C58 196
C59 189
C60 189
C66 198
C67 193
--- ---
--- ---
--- ---
Q RESISTOR RESISTOR RESISTOR RESISTOR
SYMBOL
NO.
C91 192
C92 198
C93 196
C94 196
C95 196
C96 196
C97 193
C98 196
C99 196
C100 196
INDEX
NO.
SYMBOL
NO.
C101 196
C102 193
C103 193
C104 190
--- ---
C106 198
C107 193
C108 198
C109 193
C110 193
INDEX
NO.
SYMBOL
NO.
C111 193
C112 184
C113 184
--- ---
C115 196
C116 196
C117 198
C118 198
C119 198
C120 190
INDEX
NO.
SYMBOL
NO.
C121 193
C122 196
C123 196
--- ---
C125 198
C126 198
C127 198
C128 191
C129 191
C130 198
INDEX
NO.
SYMBOL
NO.
C131 193
C132 193
C133 196
C134 196
C135 196
C136 196
C137 189
C138 196
C139 212
--- ---
INDEX
NO.
B245/B276/B277 74 Parts Location and List
29.BICU BOARD (B276/B277)
CAPACITOR
SYMBOL
NO.
C141 193
--- ---
C143 198
C144 198
C145 193
INDEX
NO.
SYMBOL
NO.
C151 198
C152 196
C153 196
C154 193
C155 196
INDEX
NO.
SYMBOL
NO.
C161 198
C162 193
C163 193
C164 198
--- ---
INDEX
NO.
SYMBOL
NO.
C171 195
C172 190
C173 190
C174 190
C175 255
INDEX
NO.
SYMBOL
NO.
C181 190
C182 190
C183 190
C184 256
C185 193
INDEX
NO.
SYMBOL
NO.
C191 189
C192 190
C193 193
C194 196
C195 193
INDEX
NO.
SYMBOL
NO.
C201 190
C202 195
--- --C204 198
C205 194
INDEX
NO.
C146 190
C147 190
C148 193
C149 198
C150 193
CAPACITOR
SYMBOL
NO.
C211 189
C212 189
C213 189
C214 190
C215 193
C216 196
--- --C218 196
C219 196
C220 193
INDEX
NO.
C156 190
C157 198
C158 193
C159 198
C160 193
SYMBOL
NO.
--- ---
--- --C223 196
C224 190
C225 196
C226 196
C227 196
C228 196
C229 212
C230 212
INDEX
NO.
C166 196
--- --C168 198
C169 196
C170 196
SYMBOL
NO.
--- --C232 193
C233 193
C234 193
C235 193
C236 196
C237 196
C238 196
C239 243
C240 196
INDEX
NO.
C176 190
C177 190
C178 190
C179 190
C180 190
SYMBOL
NO.
C241 190
C242 256
C243 197
C244 190
--- ---
C246 189
C247 189
C248 189
C249 189
C250 189
INDEX
NO.
C186 188
C187 190
--- --C189 189
C190 193
SYMBOL
NO.
C251 190
C252 193
C253 190
--- ---
--- ---
--- --C257 193
C258 190
--- --C260 196
INDEX
NO.
C196 190
C197 190
C198 190
C199 193
C200 196
SYMBOL
NO.
C261 196
C262 198
C263 198
C264 198
C265 196
C266 196
C267 196
C268 184
C269 183
C270 196
INDEX
NO.
C206 194
--- ---
C208 191
--- ---
C210 193
SYMBOL
NO.
--- --C272 198
C273 198
C274 198
C275 190
C276 193
--- --C278 184
C279 193
C280 193
INDEX
NO.
B245/B276/B277 75 Parts Location and List
29.BICU BOARD (B276/B277)
CAPACITOR
SYMBOL
NO.
C281 193
--- --C283 196
C284 190
C285 198
INDEX
NO.
SYMBOL
NO.
C291 198
C292 190
C293 192
C294 190
C295 193
INDEX
NO.
SYMBOL
NO.
C301 198
C302 190
C303 190
C304 193
C305 196
INDEX
NO.
SYMBOL
NO.
C311 190
C312 190
C313 190
C314 190
C315 187
INDEX
NO.
SYMBOL
NO.
C321 190
C322 190
C323 190
C324 193
C325 196
INDEX
NO.
SYMBOL
NO.
C331 190
C332 190
C333 198
C334 193
C335 198
INDEX
NO.
SYMBOL
NO.
C341 190
--- ---
--- ---
C344 190
--- ---
INDEX
NO.
C286 195
C287 195
C288 193
C289 196
C290 193
CAPACITOR
SYMBOL
NO.
C351 196
--- --C353 196
C354 196
--- ---
C356 193
C357 196
C358 190
C359 193
--- ---
INDEX
NO.
C296 198
C297 193
C298 190
C299 193
C300 190
SYMBOL
NO.
C361 190
C362 190
C363 193
--- ---
--- ---
C366 196
--- ---
--- ---
--- ---
C370 193
INDEX
NO.
C306 190
C307 190
C308 190
C309 190
C310 190
SYMBOL
NO.
C371 196
C372 196
C373 193
C374 196
C375 193
C376 190
--- ---
--- ---
C379 196
--- ---
INDEX
NO.
C316 193
C317 190
C318 190
C319 190
C320 190
SYMBOL
NO.
C381 193
--- --C383 193
C384 193
--- ---
C386 193
C387 193
C388 196
C389 186
--- ---
INDEX
NO.
C326 193
--- ---
--- --C329 196
C330 193
SYMBOL
NO.
--- --C392 193
--- --C394 258
--- ---
C396 257
C397 186
C398 258
C399 185
C400 258
INDEX
NO.
C336 193
--- --C338 193
C339 190
C340 190
SYMBOL
NO.
C401 185
C402 258
C403 185
C404 197
C405 258
C406 185
C407 257
C408 258
C409 185
C410 185
INDEX
NO.
--- --C347 190
C348 190
C349 211
C350 211
SYMBOL
NO.
C411 185
C412 185
C413 258
C414 258
C415 258
--- ---
--- --C418 258
C419 185
C420 258
INDEX
NO.
B245/B276/B277 76 Parts Location and List
29.BICU BOARD (B276/B277)
CAPACITOR
SYMBOL
NO.
C421 185
C422 185
C423 258
C424 185
C425 258
INDEX
NO.
SYMBOL
NO.
C431 193
C432 185
C433 186
C434 186
C435 193
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- --C444 196
C445 196
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- ---
C614 257
INDEX
NO.
CONNECTOR
SYMBOL
NO.
CN 101 130
CN 102 122
CN 103 125
CN 104 132
CN 105 118
INDEX
NO.
SYMBOL
NO.
CN 111 124
CN 112 118
CN 113 113
CN 114 109
CN 115 110
INDEX
NO.
SYMBOL
NO.
CN 121 101
CN 122 123
CN 123 121
CN 124 126
CN 125 103
INDEX
NO.
--- ---
--- ---
--- --C429 190
C430 196
CONNECTOR
SYMBOL
NO.
CN 131 112
CN 132 105
--- ---
CN 134 109
CN 135 102
CN 136 105
CN 137 114
CN 138 104
--- ---
CN 140 116
INDEX
NO.
C436 185
--- ---
--- --C439 185
C440 185
SYMBOL
NO.
CN 141 107
CN 142 131
INDEX
NO.
--- ---
--- ---
--- ---
--- ---
--- ---
CN 106 129
CN 107 128
--- --CN 109 119
CN 110 123
DIODE FILTER IC
SYMBOL
NO.
D 1 145
D 2 145
D 3 143
D 4 145
D 5 146
D 6 146
D 7 145
D 8 146
D 9 145
D 10 145
INDEX
NO.
SYMBOL
NO.
D 11 145
D 12 145
D 13 145
D 14 145
D 15 145
D 16 145
D 17 145
--- --D 19 145
INDEX
NO.
SYMBOL
NO.
FI L 1 200
FI L 2 199
FI L 3 182
FI L 4 182
--- ---
--- ---
FI L 7 202
FI L 8 201
INDEX
NO.
CN 116 120
CN 117 111
CN 118 103
CN 119 115
CN 120 108
SYMBOL
NO.
I C1 148
I C2 167
I C3 156
I C4 159
--- ---
I C6 164
--- --I C8 150
I C9 260
I C10 152
INDEX
NO.
CN 126 110
CN 127 127
CN 128 117
CN 129 123
CN 130 106
SYMBOL
NO.
I C11 148
I C12 161
IC13 3
I C14 259
I C15 152
I C16 149
I C17 259
I C18 149
I C19 168
--- ---
INDEX
NO.
B245/B276/B277 77 Parts Location and List
29.BICU BOARD (B276/B277)
IC RESISTOR
SYMBOL
NO.
I C21 153
I C22 148
I C23 149
I C24 155
I C25 158
I C26 148
IC27 2
I C28 150
I C29 160
I C30 156
INDEX
NO.
SYMBOL
NO.
IC31 1
I C32 262
I C32 133
I C33 150
I C34 157
I C35 151
I C36 151
--- ---
I C38 261
--- ---
INDEX
NO.
SYMBOL
NO.
I C40 169
I C41 154
I C42 154
LED
SYMBOL
NO.
LE D 2 147
INDEX
NO.
INDEX
NO.
OSC Q
SYMBOL
NO.
OS C1 170 Q 1 134
INDEX
NO.
SYMBOL
NO.
Q2 140
Q3 141
Q4 137
Q5 135
Q6 135
Q7 136
Q8 140
Q9 140
Q10 139
INDEX
NO.
SYMBOL
NO.
Q11 140
Q12 138
INDEX
NO.
SYMBOL
INDEX
NO.
R1 225
R2 228
R3 238
R4 224
R5 230
R6 230
R7 225
R8 234
R9 238
R10 226
NO.
RESISTOR
SYMBOL
NO.
R11 226
R12 227
R13 227
R14 241
R15 241
--- --R17 225
R18 225
--- --R20 225
B245/B276/B277 78 Parts Location and List
INDEX
NO.
SYMBOL
NO.
R21 225
R22 226
R23 231
R24 238
R25 238
R26 238
R27 231
R28 231
R29 235
R30 238
INDEX
NO.
SYMBOL
NO.
R31 226
R32 230
R33 230
R34 224
R35 238
R36 230
R37 241
R38 238
R39 234
--- ---
INDEX
NO.
SYMBOL
NO.
R41 226
R42 226
R43 233
R44 233
R45 233
R46 233
R47 241
R48 226
R49 225
--- ---
INDEX
NO.
SYMBOL
NO.
R51 225
R52 225
R53 226
--- ---
--- ---
R56 226
R57 225
R58 247
R59 246
--- ---
INDEX
NO.
SYMBOL
NO.
--- --R62 231
R63 249
R64 251
R65 240
R66 238
R67 249
R68 254
R69 250
R70 251
INDEX
NO.
SYMBOL
NO.
R71 231
R72 226
--- --R74 234
R75 225
R76 247
R77 246
R78 225
R79 230
R80 241
INDEX
NO.
29.BICU BOARD (B276/B277)
RESISTOR
SYMBOL
NO.
R81 233
R82 225
R83 233
R84 218
R85 226
INDEX
NO.
SYMBOL
NO.
R91 226
R92 226
R93 226
R94 226
R95 226
INDEX
NO.
SYMBOL
NO.
R101 235
R102 233
R103 227
R104 241
R105 226
INDEX
NO.
SYMBOL
NO.
R111 225
R112 225
R113 225
R114 225
R115 225
INDEX
NO.
SYMBOL
NO.
R121 238
R122 225
R123 226
R124 226
R125 233
INDEX
NO.
SYMBOL
NO.
R131 233
R132 226
R133 241
R134 241
R135 233
INDEX
NO.
SYMBOL
NO.
R141 238
R142 226
R143 234
R144 234
R145 226
INDEX
NO.
R86 233
R87 233
R88 233
R89 226
R90 225
RESISTOR
SYMBOL
NO.
R151 233
R152 233
R153 244
R154 217
R155 231
R156 231
R157 238
R158 238
R159 226
R160 226
INDEX
NO.
R96 225
R97 226
R98 235
R99 238
R100 238
SYMBOL
NO.
R161 209
R162 219
R163 220
R164 220
R165 233
R166 226
--- --R168 233
R169 241
--- ---
INDEX
NO.
R106 225
R107 226
R108 239
R109 227
R110 230
SYMBOL
NO.
--- --R172 234
R173 226
R174 233
R175 241
R176 226
R177 226
R178 244
R179 172
R180 233
INDEX
NO.
R116 225
R117 225
R118 226
R119 225
R120 225
SYMBOL
NO.
R181 226
R182 233
R183 226
R184 233
R185 233
R186 226
R187 241
R188 232
R189 233
R190 228
INDEX
NO.
R126 233
R127 227
--- --R129 226
R130 233
SYMBOL
NO.
R191 236
R192 226
R193 233
R194 234
R195 226
R196 233
R197 233
R198 233
R199 241
R200 233
INDEX
NO.
R136 233
R137 227
R138 225
R139 235
R140 238
SYMBOL
NO.
R201 233
R202 233
R203 234
R204 233
R205 225
R206 225
R207 225
R208 252
R209 248
R210 245
INDEX
NO.
R146 226
R147 238
R148 231
R149 231
R150 233
SYMBOL
NO.
R211 173
R212 171
--- ---
--- ---
--- ---
R216 233
R217 233
R218 233
R219 233
R220 225
INDEX
NO.
B245/B276/B277 79 Parts Location and List
29.BICU BOARD (B276/B277)
RESISTOR
SYMBOL
NO.
R221 229
R222 242
--- --R224 233
R225 220
INDEX
NO.
SYMBOL
NO.
--- ---
--- ---
--- --R234 233
R235 225
INDEX
NO.
SYMBOL
NO.
R241 233
R242 233
R243 241
R244 233
R245 241
INDEX
NO.
SYMBOL
NO.
--- --R252 233
R253 226
--- --R255 226
INDEX
NO.
SYMBOL
NO.
R261 235
R262 225
R263 233
R264 243
R265 226
INDEX
NO.
SYMBOL
NO.
--- --R272 225
R273 238
R274 238
R275 226
INDEX
NO.
SYMBOL
NO.
R281 233
R282 241
R283 233
R284 225
R285 233
INDEX
NO.
R226 220
R227 229
R228 242
R229 226
R230 226
RESISTOR
SYMBOL
NO.
--- ---
--- ---
--- --R294 225
R295 226
R296 238
R297 226
R298 241
R299 172
R300 225
INDEX
NO.
R236 226
R237 233
R238 233
R239 233
R240 233
SYMBOL
NO.
R301 233
R302 225
R303 233
R304 233
R305 227
R306 226
--- --R308 233
R309 233
--- ---
INDEX
NO.
R246 226
R247 241
R248 233
R249 226
R250 238
SYMBOL
NO.
--- --R312 244
R313 227
R314 227
R315 233
R316 233
R317 233
R318 241
--- ---
--- ---
INDEX
NO.
R256 225
R257 225
R258 226
R259 226
R260 230
SYMBOL
NO.
R321 241
R322 226
R323 238
R324 238
R325 241
R326 238
R327 226
R328 226
R329 241
R330 241
INDEX
NO.
R266 253
R267 225
R268 215
R269 233
R270 226
SYMBOL
NO.
R331 209
R332 225
R333 226
R334 241
R335 225
R336 241
R337 226
R338 238
R339 225
R340 241
INDEX
NO.
R276 238
R277 233
--- --R279 227
R280 226
SYMBOL
NO.
R341 208
R342 208
R343 220
R344 233
R345 226
--- --R347 223
R348 220
R349 209
R350 219
INDEX
NO.
R286 233
R287 234
R288 226
--- ---
--- ---
SYMBOL
NO.
R351 216
R352 217
R353 217
R354 217
R355 217
--- --R357 222
R358 213
R359 217
R360 218
INDEX
NO.
B245/B276/B277 80 Parts Location and List
29.BICU BOARD (B276/B277)
RESISTOR
SYMBOL
NO.
R361 218
R362 214
R363 217
R364 226
R365 237
INDEX
NO.
SYMBOL
NO.
R371 216
R372 244
--- --R374 241
R375 241
INDEX
NO.
SYMBOL
NO.
--- --R382 244
R383 226
R384 226
INDEX
NO.
REG RN
SYMBOL
NO.
REG 1 165
REG 2 162
REG 3 166
REG 4 163
INDEX
NO.
SYMBOL
INDEX
NO.
RN 1 177
RN 2 177
RN 3 177
RN 4 177
RN 5 177
NO.
SYMBOL
NO.
RN 11 177
RN 12 177
RN 13 177
RN 14 177
RN 15 177
INDEX
NO.
SYMBOL
NO.
RN 21 177
RN 22 177
RN 23 177
RN 24 177
RN 25 178
INDEX
NO.
--- ---
--- ---
--- --R369 244
R370 209
RN
SYMBOL
NO.
RN 31 180
RN 32 205
RN 33 205
RN 34 205
RN 35 175
RN 36 178
RN 37 178
RN 38 175
RN 39 175
RN 40 177
INDEX
NO.
R376 241
R377 221
R378 225
R379 226
--- ---
SYMBOL
NO.
RN 41 178
RN 42 178
RN 43 178
RN 44 204
RN 45 204
RN 46 205
RN 47 178
RN 48 178
RN 49 205
RN 50 205
INDEX
NO.
SYMBOL
NO.
RN 51 176
RN 52 178
RN 53 178
RN 54 178
RN 55 178
RN 56 178
RN 57 178
RN 58 178
RN 59 178
--- ---
INDEX
NO.
SYMBOL
NO.
RN 61 206
RN 62 205
--- --RN 64 207
RN 65 178
RN 66 207
RN 67 203
RN 68 207
RN 69 203
RN 70 205
INDEX
NO.
RN 6 177
RN 7 177
RN 8 177
RN 9 177
RN 10 177
SYMBOL
NO.
RN 71 175
--- --RN 73 177
RN 74 177
RN 75 180
RN 76 207
RN 77 207
RN 78 207
RN 79 207
RN 80 207
INDEX
NO.
RN 16 179
RN 17 205
RN 18 205
RN 19 177
RN 20 180
SYMBOL
NO.
RN 81 203
RN 82 203
RN 83 203
RN 84 203
RN 85 203
RN 86 174
RN 87 178
RN 88 179
RN 89 179
RN 90 205
INDEX
NO.
RN 26 180
RN 27 176
RN 28 178
RN 29 205
RN 30 177
SYMBOL
NO.
RN 91 177
RN 92 177
RN 93 204
RN 94 177
RN 95 177
RN 96 178
RN 97 205
RN 98 205
RN 99 204
RN 100 179
INDEX
NO.
B245/B276/B277 81 Parts Location and List
29.BICU BOARD (B276/B277)
RN ZD
SYMBOL
NO.
RN 101 177
RN 102 177
--- --RN 104 205
RN 105 175
RN 106 175
RN 107 177
RN 108 177
RN 109 179
RN 110 179
INDEX
NO.
SYMBOL
NO.
RN 111 177
RN 112 177
RN 113 178
RN 114 178
RN 115 203
RN 116 204
RN 117 178
RN 118 203
RN 119 203
RN 120 204
INDEX
NO.
SYMBOL
NO.
RN 121 178
RN 122 178
RN 123 177
--- --RN 125 178
RN 126 181
RN 127 205
RN 128 204
RN 129 204
INDEX
NO.
SYMBOL
NO.
ZD 1 144
ZD 2 144
ZD 3 142
INDEX
NO.
B245/B276/B277 82 Parts Location and List
Loading...
