Page 1
Model: VSF 110D-S Series
6” Duct
Static Pressure (inches w.g.)
0.1
0.25
Air Volume (CFM)
110
79
Noise (sones)
0.6
n/a
Power Consumption (Watts)
11
11
Energy Efficiency (CFM/Watts)
10
7.2
Current (AMPS)
0.2
0.2
ENERGY STAR rated
Yes
Grille Dimensions
13 3/8” x 13 3/8”
Model
Qty
Comments
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
Specifications
VSF 110D-S SERIES
Super Quiet Slim Fit Bathroom Fan
ETL Listed for installation over tub/shower enclosure with
GFCI circuit wiring.
Description: Super quiet DC (Direct Current) bathroom fan
with adjustable speed control (80-140 CFM) engineered for
continuous run Ceiling or wall mount Suitable for new
construction or remodeling HVI certified ENERGY STAR
qualified ETL listed for use in insulated ceilings (Type I.C.).
Motor/Blower: Permanently lubricated enclosed brushless DC
motor engineered for continuous energy efficient operation;
power rating 120v/60Hz; motor equipped with thermal shut off.
Housing: Rugged 26 GA galvanized steel; detachable 4” and 6”
duct connector with built-in back draft dampener; 2 anti-vibration
hangar bar brackets adjustable to 24” span included.
Grille: Contemporary design; low maintenance, wipe clean UV
inhibiting polymeric resin; attaches to housing with torsion
springs.
Finishes: White (W); Satin Nickel (SN); Oil Rubbed Bronze
(OR).
Installation: Must be installed by a licensed professional.
Complete installation instructions included.
Warranty: 6 Years
Architect’s Specifications: Ventilation fan will be ceiling or wall
mount, ENERGY STAR qualified, adjustable speed of 80-140
CFM and no more than 0.6 sones at 110 CFM as certified by HVI
at 0.1 Ps (inches water gauge). Power consumption shall be no
greater than 11 watts and ENERGY STAR rated with an
efficiency rating of no less than 10 CFM/watt. The motor will be
enclosed brushless DC motor, engineered for continuous
operation. Duct diameter will be 4” or 6” round. CFM switch tab
will allow for 5 separate airflow (CFM) settings for 4” or 6” duct.
Fan shall be ETL/cETL listed for tub/shower enclosure when
used with GFCI branch circuit wiring and shall be ETL/cETL
listed for use in insulated ceiling (Type I.C.). Fan shall be
ASHRAE 62.2, LEED, CalGreen, and WA Ventilation Code
compliant.
