Model: AP 80 RVL
4” Duct
Static Pressure (inches w.g.)
0.1
0.25
Air Volume (CFM)
80
68
Noise (sones)
1.2
n/a
Power Consumption (Watts)
20
18.5
Energy Efficiency (CFM/Watts)
4
3.7
Current (AMPS)
0.2
0.19
ENERGY STAR rated
No
Bulb NOT included
Model
Qt y
Comments
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
Specifications
AP 80 RVL
Super Quiet Bathroom Fan with Recessed Light
ETL Listed for installation over tub/shower enclosure
with GFCI circuit wiring and used with a PAR30L
75W (max) CFL.
ENERY STAR compliant when used with a GU24
Kit. ( GU24 Kit not included. )
Description: Low RPM, low noise, ceiling mount bathroom fan
with recessed light engineered for continuous run Suitable for new
construction or remodeling HVI certified ETL listed for use in
insulated ceilings (Type I.C.).
Motor/Blower: Permanently lubricated enclosed motor engineered
for continuous energy efficient operation; power rating 120v/60Hz;
motor equipped with thermal shut off.
Housing: Rugged 26 GA galvanized steel; expandable 4” to 5” duct
connector with built-in back draft dampener; 2 anti-vibration hangar
bar brackets adjustable to 24” span included.
Trim Ring: Low maintenance, wipe clean UV inhibiting polymeric
resin. Mounts flush to ceiling. Accepts any of the following bulbs:
75W, PAR30, PAR30L, 14W (max) LED.
Light: Bulb not included. Accepts any of the following bulbs: 75W,
PAR30, PAR30L, BR30 14W (max) LED. For ENERGY STAR
compliance GU24 Kit. GU24 Kit not included.
Finishes: White (W).
Installation: Must be installed by a licensed professional.
Complete installation instructions included.
Warranty: 6 Years.
Architect’s Specifications: Ventilation fan will be ceiling mount
and no more than 1.2 sones at 80 CFM as certified by HVI at 0.1 Ps
(inches water gauge). Power consumption shall be no greater than 20
watts with an efficiency rating of no less than 4 CFM/watt. The
motor will be permanently lubricated, engineered for continuous
operation. Light/fan to operate separately or in combination.
Light/fan must use a 75W Max. PAR30, 14W Max. BR30 LED, or
75W Max. PAR30L (for use over tub/shower.) Duct diameter will be
4” to 5” expandable. Fan shall be ETL/cETL listed for tub/shower
enclosure when used with GFCI branch circuit wiring and shall be
ETL/cETL listed for use in insulated ceiling (Type I.C.). Fan can be
used to Comply with CA Title 24.
Aero Pure, L L C 10 0 6 B a n k t on Circle S t e B H a n ahan, SC 2 9 4 1 0 8 4 3 . 3 7 7.8642
www.a e r o p u ref a n s . c om
