Model: ABF 0511 D Series
4” Duct
Static Pressure (inches w.g.)
0.1
0.25
Air Volume (CFM)
80
80
Noise (sones)
0.4
0.9
Power Consumption (Watts)
7.4
11.5
Energy Efficiency (CFM/Watts)
10.9
7.0
Speed (RPM)
852
1100
ENERGY STAR rated
Yes
Grille Dimensions
13” x 13”
Model
Qty
Comments
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
Specifications
ABFS 0511 L6 Series
Low Profile Adjustable Speed Ceiling/Wall
Bathroom Fan with LED Light/Night Light
ETL/cETL Listed for installation over tub/shower
enclosure when used with GFCI circuit wiring
Description: Quiet DC (Direct Current) bathroom fan with
adjustable speed control (50-80-110 CFM) engineered for continuous
run Fits 2”x4” construction 10W 3000K 850 Lumens dimmable
LED light and 0.7W night light Ceiling or wall mount Suitable for
new construction or remodeling HVI certified ENERGY STAR
certified ETL/cETL listed for use in insulated ceilings (Type I.C.).
Motor/Blower: Brushless high performance DC motor engineered
for continuous energy efficient operation; power rating 120v/60Hz;
motor equipped with thermal shut off.
Housing: Galvanized steel body; 4: oval duct connector; built-in
back draft dampener; patented quick mounting anti-vibration bracket
included; designed for installation in ceilings with minimum of 4”
clearance.
Grille: Low maintenance, wipe clean; attaches to housing with torsion
springs.
Finish: White (W)
Light: Energy efficient dimmable 10W LED with 0.7W night light
Ventilating Area: For bathrooms up to 110 sq ft.
Installation: Must be installed by licensed professional. Complete
installation instructions included.
Warranty: 6 Years
Architect’s Specifications: Ventilation fan will be ceiling mount,
ENERGY STAR qualified, adjustable speed of 50-80-110 CFM, with
no less than 80 CFM and no more than 0.4 Sones as certified by HVI
at 0.1 static pressure in inches water gauge. Power consumption shall
be no greater than 7.4 watts and ENERGY STAR rated with an
efficiency rating of no less than 10.9 CFM/watt. Light shall be 10W
3000K LED and include one 0.7W dimmable LED night light. The
motor will be enclosed brushless DC motor engineered for continuous
operation. CFM switch tab will allow for 3 separate airflow (CFM)
settings for 4” oval duct. Fan shall be listed for tub/shower enclosure
when used with GFCI branch circuit wiring and shall be ETL/cETL
listed for use in insulated ceiling (Type I.C.). Fan shall be ASHRAE
62.2, LEED, California Title 24/JA8, and Washington VIAQ
compliant.
Aero Pure, LLC 1006 Bankton Circle Ste B Hanahan, SC 29410 843.377.8642
www.aeropurefans.com
L6 (W) Grille
