AeroComm RM024 Users Manual

RM024 Compliance Section

Family

US/FCC

CANADA/IC

RM024

KQL-RM024

2268C-RM024

*PART #

FORM FACTOR

TX OUTPUT

ANTENNA

RM024-S125-C-XX

Surface Mount

125mW

U.FL

RM024-S125-M-XX

Surface Mount

125mW

U.FL or chip

RM024-P125-C-XX

Pluggable

125mW

U.FL

RM024-P125-M-XX

Pluggable

125mW

U.FL or chip

RM024-S50-C-XX

Surface Mount

50mW

U.FL

RM024-S50-M-XX

Surface Mount

50mW

U.FL or chip

RM024-P50-C-XX

Pluggable

50mW

U.FL

RM024-P50-M-XX

Pluggable

50mW

U.FL or chip

*Last two slots "XX" in Part # are used for custom setups. Can be values 01-99

Item

Part Number

Mfg.

Type

Gain (dBi)

1

WIC2450-A

Laird Technologies

Chip

2 2 NZH2400-MMCX

Laird Technologies

Microstrip

1 3 ID2450-RS36

Laird Technologies

Panel

9

3

IG2450-RS36

Laird Technologies

Omni

6

4

S151FC-L-(132)PX-2450S

Nearson

Dipole

5

RM024 FCC / IC Information

Agency Identification Numbers

RM024 FAMILY

Antenna Information

RM024 family has been designed to operate with the antennas listed below and having a maximum
gain of 9dBi. The required antenna impedance is 50 ohms.

The OEM is free to choose another vendor’s antenna of like type and equal or lesser gain as

an antenna appearing in the table and still maintain compliance. Refer ence FCC Part

15.204(c)(4) for further information on this topic.

To reduce potential radio interference to other users, the antenna type and gain should be

chosen so that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication.

POWER EXPOSURE INFORMATION

In general, there are two agency classifications for RF radiation exposure in wireless applications;
portable and mobile.

Mobile – A mobile device is defined as a transmitting device designed to be used in such a way that a
separation distance of at least 20 centimeters is normally maintained between the transmitter's
radiating structures and the body of the user or nearby persons. The RM024 is fully modular approved
for mobile and fixed applications. Reference FCC Part 2.1091 for further details on mobile devices.

Portable – Portable is a classification of equipment where the user, in general, will be within 20 cm of
the transmitting antenna. Portable equipment is further broken down into two classes; within 2.5 cm of
human contact and beyond 2.5 cm. The RM024 does not hold a portable approval classification due to
its peak output power and modular approval restrictions. Further RF evaluation is required by
customers who want to use the RM024 in portable applications. Contact a qualified test house or a
Laird Technologies representative for further information on this topic. Reference FCC Part 2.1093 for

further details on portable devices.

Maximum Permissible Exposure report has been created which shows the minimum distances for
Public and Occupational use of the RM024.

Occupational Limit Minimum Distance = 4cm
Public Limit Minimum Distance = 9cm

Full MPE report available upon request

OEM RESPONSIBILITIES

WARNING: The OEM must ensure that FCC labeling requirements are met. This includes a clearly visible

label on the outside of the OEM enclosure specifying the appropriate Laird Technology FCC identifier for this
product as well as the FCC notice below.

Contains FCC ID: KQL-RM024
This enclosed device complies with Part 15 of the FCC Rules, Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation

Label and text information should be in a size of type large enough to be readily legible, consistent with
the dimensions of the equipment and the label. However, the type size for the text is not required to be
larger than eight point.

CAUTION: The OEM should have their device which incorporates the RM024 tested by a qualified test
house to verify compliance with FCC Part 15 Subpart B limits for unintentional radiators.

WARNING: This device has been tested with an U.FL connector and the antennas listed in the table
above. When integrated into the OEM’s product, these fixed antennas require professional installation
preventing end-users from replacing them with non-approved antennas. Any antenna not listed in the
above table must be evaluated for compliance with FCC Part 15.203 for unique antenna connectors.
Contact Laird Technology for assistance.
