AEOTEC ZWA010 UM

Z-Stick 7

ZWA010-A

Used in this guide.

Artículos utilizados en este manual / Utilisé dans ce guide
/ In dieser Gebrauchsanweisung verwendete
Bezeichnungen / Usato in questa guida / Gebruikt in
deze handleiding / Används i den här handboken.

Important safety information.

Please read this and the online guide(s) at
support.aeotec.com/zs7 carefully. Failure
to follow the recommendations set forth by
Aeotec Limited may be dangerous or
cause a violation of the law. The
manufacturer, importer, distributor, and / or

reseller will not be held responsible for any
loss or damage resulting from not following
any instruction in this guide or in other
materials.

Z-Stick 7 is intended for indoor use in dry
locations only. Do not use in damp, moist,
and / or wet locations.

Quick start.

The following will step you through using
Z-Stick 7 when it is attached to a host
controller as a primary controller.

Please make sure the host controller is
pre-installed; this includes any drivers that
the corresponding operating system may
need. In most cases, the host controller
automatically installs the required USB
driver. If not, the USB driver can be
downloaded from www.silabs.com part
CP2102N. Expanded quick start steps are
available at support.aeotec.com/zs7.

1. Plug Z-Stick 7 into a host controller (that
can be a PC, Mac, Raspberry Pi, etc).

2. Determine the virtual port that your
Z-Stick 7 is connected to.

Windows - You would look at Ports

●

& LPT under Device Manager.
Usually, Z-Stick 7 shows as a COMX
device (where X can be 0-1000).

●

Linux - under cmd prompt, type in
“dmesg | grep tty” which will give you
a list of all tty devices connected.
Usually Z-Stick 7 shows as a
/dev/ttyUSB0 device.

OSX - Choose Apple > System

●

Preferences, then click Network. You
can find Z-Stick 7 as a USB Modem
device (/dev/cu.usbmodem).

3. Open the selected third party software.

4. Following your third party software
instructions for connecting a Z-Wave
USB Adapter. Select the COM or virtual
port Z-Stick 7 is associated to.

In most cases, any devices already paired
with Z-Stick 7 network will automatically
show up in the software’s interface.

To include a new device into the system.

1. Set the third party software into its ‘add
device’ mode in order to connect a
Z-Wave device to your Z-Wave system.
Refer to the third party software
instructions if you are unsure of how to
perform this step.

2. Press Action Button on Aeotec Z-Wave
device which you want to add into the
Z-Wave network. If it is non-Aeotec
Z-Wave device, please refer to its
manual for inclusion operation.

3. You will see the name of the device on
the software’s interface when it is
successfully added.

4. Repeat step 2 and 3 to include any
further devices.

How Z-Stick 7 controls paired Z-Wave

devices ultimately depends on the
control scheme set by the third party
Z-Wave software you choose.

Get help & learn more.

Should you encounter any problem with
Z-Stick 7, visit support.aeotec.com/zs7
or contact our support team via
aeotec.com/contact. You can also learn
more about Z-Stick 7 features,
configuration options, and technical
specifications at the link.

Gateway compatibility.

To see if this device is known to be
compatible with your Z-Wave gateway,
please refer to
aeotec.com/z-wave-gateways.

Declaration of Conformity. Aeotec Limited
declares that ZWA01
essential requirements and other relevant
provisions of RED 2014/53/EU, RoHS
2011/65/EU, IEC 62321:2008, E50581:2012 and
ErP Directive 2009/125/EC, No 1275/2008
AMENDMENT 801/2013. The full text of the
declaration is available from
support.aeotec.com/zs7/doc

Specifications. Z-Wave devices operate
between 908.44-916.045 MHz depending on
local restrictions. Full information on device
specifications and certifications at
support.aeotec.com/zs7/specs

Declaración de conformidad. Aeotec Limited
declara que ZWA010 cumple con los
requerimientos esenciales y otras provisiones
relevantes de RED 2014/53/EU, RoHS
2011/65/EU, IEC 62321:2008, E50581:2012 y la
directiva ErP 2009/125/EC, Nro. 1275/2008
ENMIENDA 801/2013. El texto completo de esta
declaración está disponible en
support.aeotec.com/zs7/doc

Especificaciones. Los dispositivos Z-Wave
operan entre 908.44-916.045 MHz dependiendo

0 is in compliance with the

de las restricciones locales. Toda la info
sobre las especificaciones del dispositivo y sus
certificaciones puede encontrarse en
support.aeotec.com/zs7/specs

Déclaration de conformité. Aeotec Limited déclare
que ZWA010 est conforme aux exigences
essentielles et autres dispositions pertinentes de
RED 2014/53/EU, RoHS 2011/65/EU, IEC
62321:2008, E50581:2012 et ErP Directive
2009/125/EC, No 1275/2008 AMENDMENT
801/2013. Le texte intégral de la déclaration est
disponible sur support.aeotec.com/zs7/doc

Spécifications. Les appareils Z-Wave fonctionnent
entre 908.44-916.045 MHz selon les restrictions
locales. Informations complètes sur les
spécifications et certifications des appareils sur
support.aeotec.com/zs7/specs

Konformitätserklärung. Aeotec Limited erklärt,
dass der ZWA010 den grundlegenden
Anforderungen und anderen relevanten
Bestimmungen von RED 2014/53/EU, RoHS
2011/65/EU, IEC 62321:2008, E50581:2012 und
ErP-Richtlinie 2009/125 entspricht / EG, Nr.
1275/2008 ÄNDERUNGSANTRAG 801/2013. Der
vollständige Wortlaut der Erklärung ist unter
folgender Internetadresse

rmación

s

upport.aeotec.com/zs7/doc

Spezifikationen. Z-Wave Geräte arbeiten zwischen

908.44-916.045 Mhz in Abhängigkeit von lokalen
Beschränkungen. Vollständige Informationen über
Gerätespezifikationen und Zertifizierungen finden
Sie auf support.aeotec.com/zs7/specs

Dichiarazione di Conformità. Aeotec Limited
dichiara che il dispositivo ZWA010 rispetta tutti i
requisiti essenziali e le disposizioni rilevanti RED
2014/53/EU, RoHS 2011/65/EU, IEC 62321:2008,
E50581:2012 e la Direttiva ErP 2009/125/EC, Num.
1275/2008 EMENDAMENTO 801/2013. Il testo
completo della dichiarazione è disponibile
all’indirizzo support.aeotec.com/zs7/doc

Specifiche. I dispositivi Z-Wave operano tra

908.44-916.045 MHz, in base alle regolamentazioni
locali. Informazioni complete e certificazioni del
dispositivo sono disponibili all’indirizzo
support.aeotec.com/zs7/specs

Conformiteitsverklaring. Aeotec Limited verklaart
dat ZWA010 voldoet aan de minimale vereisten en
andere bepalingen die relevant zijn voor RODE
2014/53/EU, RoHS 2011/65/EU, IEC 62321:2008,
E50581:2012 en ErP-richtlijn 2009/125/EG, nr.

1

275/2008 AMENDEMENT 801/2013. Den
fullständiga texten till deklarationen är tillgänglig
från support.aeotec.com/zs7/doc

Specificaties. Z-Wave apparaten functioneren
tussen de 908.44-916.045 MHz, afhankelijk van de
lokale beperkingen. Kijk voor volledige informatie
over de productspecificaties en certificeringen op
support.aeotec.com/zs7/specs

Försäkran om Överensstämmelse. Aeotec Limited
försäkrar att ZWA010 överensstämmer med de
grundläggande kraven och andra relevanta
bestämmelser i RED 2014/53/EU, RoHS
2011/65/EU, IEC 62321:2008, E50581:2012 och
ErP Direktiv 2009/125/EC, nr 1275/2008 TILLÄGG
801/2013. Den fullständiga texten för försäkran är
tillgänglig på support.aeotec.com/zs7/doc

Specifikationer. Z-Wave-enheter arbetar mellan

908.44-916.045 MHz beroende på lokala
begränsningar. Fullständig information om
enhetsspecifikationer och certifieringar finns på
support.aeotec.com/zs7/specs

FCC ID: 2AOGIZWA010

In Europe contact Aeotec Group GmbH; Große
Johannisstraße 7, 20457 Hamburg, Germany.

© & ™ Aeotec Limited Version: 501001000001 - AA
