Aemc instruments MN211, MN210 User Manual

AC Current Probe
Models MN210 and MN211

User Manual

DESCRIPTION

The MN210/MN211 (Catalog #2115.72 and #2115.73) are the latest in compact AC Current probes.
Designed to meet the most stringent demands in industry and electrical contracting, they also meet the
latest safety and performance standards. The probes have a measurement range up to 240 Arms which
makes them perfect tools for measurement with DMMs, recorders, power and harmonic meters. The
Models MN210/MN211 are compatible with any AC ammeter, multimeter, or other current measurement
instrument with an input impedance lower than 1. To achieve the stated accuracy, use the
MN210/MN211 with an ammeter having an accuracy of 0.75% or better.

WARNING

These safety warnings are provided to ensure the safety of personnel and proper operation of the
instrument.

• Read the instruction manual completely and follow all the safety information before attempting
to use or service this instrument.

• Use caution on any circuit: Potentially high voltages and currents may be present and may pose
a shock hazard.

• Read the Safety Specifications section prior to using the current probe. Never exceed the
maximum voltage ratings given.

• Safety is the responsibility of the operator.

• ALWAYS connect the current probe to the display device before clamping the probe onto the

sample being tested.

• ALWAYS inspect the instrument, probe, probe cable, and output terminals prior to use. Replace
any defective parts immediately.

• NEVER use the current probe on electrical conductors rated above 600V in overvoltage
category III (CAT III). Use extreme caution when clamping around bare conductors or bus bars.

INTERNATIONAL ELECTRICAL SYMBOLS

This symbol signifies that the current probe is protected by double or reinforced insulation. Use
only factory specified replacement parts when servicing the instrument.

This symbol signifies CAUTION! and requests that the user refer to the user manual before
using the instrument.

This is a type A current sensor. This symbol signifies that application around and removal from
HAZARDOUS LIVE conductors is permitted.

DEFINITION OF MEASUREMENT CATEGORIES
Cat. II: For measurements performed on circuits directly connected to the electrical distribution system.

Examples are measurements on household appliances or portable tools.

Cat. III: For measurements performed in the building installation at the distribution level such as on

hardwired equipment in fixed installation and circuit breakers.

Cat. IV: For measurements performed at the primary electrical supply (<1000V) such as on primary

overcurrent protection devices, ripple control units, or meters.

RECEIVING YOUR SHIPMENT

Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify
your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately
with the carrier and notify your distributor at once, giving a detailed description of any damage.

ELECTRICAL SPECIFICATIONS

Nominal Range: 200 A
Measurement Range: 0.5 to 240 A AC
Transformation Ratio: 1000:1
Output Signal: 1 mA/A on 1
Accuracy and Phase Shift*:

Accuracy: 0.5 to 10 A: 3.0% Reading ± 0.5 A
10 to 40 A: 2.5% Reading ± 0.5 A
40 to 100 A: 2.0% Reading ± 0.5 A
100 to 240 A: 1.0% Reading ± 0.5 A

Phase Shift: 0.5 to 10 A: Not Specified
10 to 40 A: ≤ 5°
40 to 100 A: ≤ 3°
100 to 240 A: ≤ 2.5°

(*Reference conditions:18°C to 28°C, 20 to 75% RH,
external magnetic field < 40 A/m, 48 to 65 Hz sine
wave, distortion factor less than 1%, no DC
component, no external current carrying conductor,
test sample centered.) Load impedance 1.

Overload: 240 A for 10 min ON, 30 min OFF
Frequency Range: 40 to 10 kHz

Limit Operating Conditions:

200 A permanently to 1 kHz
Derating above 3 kHz: 200 A x (1/0.333 F), F in kHz

Crest Factor:

3 @ 200 Arms with an error (due to CF) of 4%

Working Voltage: 600 Vrms
Common Mode Voltage: 600 Vrms
Influence of Adjacent Conductor:

< 15 mA/A at 50 Hz

Influence of DC (< 20 A) on AC signal:

< 5%

Influence of Conductor Position in Jaw:

0.5% of mA output @ 50/60 Hz

Influence of Load:

< 3% of mA output from 40 Hz to 1 kHz
< 12% of mA output from 1 kHz to 10 kHz

Influence of Temperature:

≤ 150 ppm/°K, or 0.15% of mA output per 10°K

Influence of Humidity (10 - 90% RH):

≤ 0.2% of mA output per 10°K @ 18°C to 28°C

MECHANICAL SPECIFICATIONS

Operating Temperature:

14° to 131°F (-10° to +55°C)

Storage Temperature:

-40° to 158°F (-40° to +70°C)

Operating Relative Humidity:

10-35°C 85% RH (without roll-off above 35°C)

Maximum Cable Diameter:

One Ø 0.78” (20 mm), bus bar 20 x 5 mm

Case Protection:
IP 40 (IEC 529)

Drop Test:

Test per IEC 68-2-32: 1.0 m drop on 38 mm of
Oak on concrete.

Mechanical Shock:

Test per IEC 68-2-27

Vibration:

Test per IEC 68-2-6

Dimensions:

5.47 x 2.00 x 1.18" (139 x 51 x 30 mm)

Weight: 180 g (6.5 oz)
Polycarbonate Material:

Jaws: Polycarbonate with 10% fiberglass charge,

Red UL 94 V0

Case: Polycarbonate 920A Gray

Opening Operations - Life: > 50,000
Output:

MN210: Two standard safety banana jacks (4 mm)
MN211: Double/reinforced insulated 5 ft. (1.5 m)

lead with safety 4mm banana plug

SAFETY SPECIFICATIONS

Electrical:

Double insulation or reinforced insulation between
the primary or secondary and the outer case of the
handle conforms to IEC 1010-2-32.

Common Mode Voltage:

600 V Category III, Pollution Degree 2

Dielectric Strength:

5550 V, 50/60 Hz between primary, secondary
and the outer case of the handle

Electromagnetic Compatibility:

EN 50081-1 Class B
EN 50082-2 Electrostatic discharge
IEC 1000-4-2
Radiated field IEC 1000-4-3
Fast transients IEC 1000-4-4
Magnetic field at 50/60 Hz IEC 1000-4-8

E192383

ORDERING INFORMATION

AC Current Probe MN210................. Cat #2115.72

AC Current Probe MN211................. Cat #2115.73

Both models include a user manual and a
product warranty and registration card.

Accessories:

Leads, set of 2, 5 ft safety (1000V)..... Cat #2111.29

Banana plug adapter

(to nonrecessed plug) ........................ Cat #1017.45

OPERATION

Please make sure that you have already read and fully understand the WARNING section on page 1.

Making Measurements with the AC Current Probe Models MN210/MN211

• Connect the black lead of the current probe to “common” and the red lead to the AC current input on
your DMM or other current measuring instrument. Select the appropriate current range (400 mA AC
range). Clamp the probe around the conductor to be tested with the arrow pointed toward the load. If the
reading is less than 400 mA, select the lower range until you obtain the best resolution. Read the value
display on the DMM and multiply it by the probe ratio (1000/1). (If reading = 0.159 A, the current flowing
through the probe is 0.159 A x 1000 = 159 A AC)

• For best accuracy, avoid if possible, the proximity of other conductors which may create noise.

Tips for Making Precise Measurements

• When using a current probe with a meter, it is important to select the range that provides the best
resolution. F

ailure to do this may result in measurement errors.

• Make sure that probe jaw mating surfaces are free of dust and contamination. Contaminants cause air
gaps between the jaws, increasing the phase shift between primary and secondary. It is very critical for
power measurement.

MAINTENANCE:
Warning

• For maintenance use only original factory replacement parts.

• To avoid electrical shock, do not attempt to perform any servicing unless you are qualified to do so.

• To avoid electrical shock and/or damage to the instrument, do not get water or other foreign agents
into the probe

Cleaning

To ensure optimum performance, it is important to keep the probe jaw

mating surfaces clean at all times.

Failure to do so may result in error in readings. To clean the probe jaws, use very fine sand paper (fine

600) to avoid scratching the jaw, then gently clean with a soft oiled cloth.

REPAIR AND CALIBRATION

You must contact our Service Center for a Customer Service Authorization number (CSA#). This will
ensure that when your instrument arrives, it will be tracked and processed promptly. Please write the CSA#
on the outside of the shipping container. If the instrument is returned for calibration, we need to know if you
want a standard calibration, or a calibration traceable to N.I.S.T. (includes calibration certificate plus
recorded calibration data).

Chauvin Arnoux

®

, Inc. d.b.a. AEMC® Instruments

15 Faraday Drive • Dover, NH 03820 USA
Tel: [phone] (Ext. 360)

[phone] (Ext. 360)

Fax: [phone] or [phone]

[e-mail]
(Or contact your authorized distributor)
Costs for repair, standard calibration, and calibration traceable to N.I.S.T. are available.

NOTE: All customers must obtain a CSA# before returning any instrument.
TECHNICAL AND SALES ASSISTANCE

If you are experiencing any technical problems, or require any assistance with the proper use or
application of this instrument, please call our technical hotline:

[phone] • [phone] • Fax [phone]
Chauvin Arnoux

®

, Inc. d.b.a. AEMC® Instruments
[e-mail]
www.aemc.com

99-MAN 100137.v7 09/16
