Aemc instruments 8336 User Manual
PowerPad® III
Model 8336
Quick Start Guide
ENGLISH
IMPORTANT WARRANTY NOTE:
By registering online within 30 days from the date of
purchase, your warranty will be extended to 3 years
www.aemc.com
®
CHAUVIN ARNOUX GROUP
Shipping Contents:
PRODUCT PACKAGING
Cat. #2136.30 / Cat. #2136.31 / Cat. #2136.32
(1) PowerPad
(5) Black Test Leads and Alligator Clips
(12) Color-coded ID Markers
Also Includes:
•4 GB USB Stick (DataView/User Manual)
•9.6V NiMh Battery - installed
•2 GB SD-Card - installed
•High Voltage Warning/Caution Card
®
III Model 8336
Cat. #2140.43
Cat. #2140.45
(1) Extra Large Classic Tool Bag
Cat. #2133.73
(1) Soft Carrying Pouch
Cat. #2140.15
(1) Power Adapter 110/240V
w/ Power Cord
Cat. #5000.19
Kit (Cat. #2136.31) also includes:
•(4) AmpFlex® Model 193-24-BK
Kit (Cat. #2136.32) also includes:
•(4) AC Current Probe Model MN193-BK
(1) 5 ft USB Cable
Cat. #2140.46
USB STICK: DataView® software and complete user manual for the Model 8336
can be located on the USB stick supplied with the instrument.
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair
and calibration section at www.aemc.com.
Serial #: ________________________________
Catalog #: 2136.30 / 2136.31 / 2136.32
Model #: 8336
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due:
_______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC® Instruments
www.aemc.com
Thank you for purchasing an AEMC® PowerPad® III Model 8336.
For best results from your instrument and for your safety, read the enclosed operating
instructions carefully and comply with the precautions for use. These products must be only
used by qualified and trained users.
WARNING, risk of DANGER! The operator must refer to these
instructions whenever this danger symbol appears.
CAUTION! Risk of electric shock. The voltage at the
parts marked with this symbol may be dangerous.
Equipment is protected by double insulation.
Must not be applied to or removed from bare conductors carrying dangerous voltages. Type B current sensor as per EN 61010-2-032.
Application or withdrawal authorized on conductors carrying dangerous
voltages. Type A current sensor per IEC 61010-2-032.
USB socket.
SD Card.
Ground/Earth.
Important instructions to read and to fully understand.
Useful information or hint to read.
The CE marking guarantees conformity with European directives and with
regulations covering EMC.
The trash can with a line through it means that in the European Union, the
product must undergo selective disposal for the recycling of electric and
electronic material, in compliance with Directive WEEE 2002/96/EC.
Definition of Measurement Categories (CAT)
CAT IV Measurement category IV corresponds to measurements taken at the source of
low-voltage installations.
Example: power feeders, counters and protection devices.
CAT III Measurement category III corresponds to measurements on building
installations.
Example: distribution panel, circuit-breakers, machines or fixed industrial
devices.
CAT II Measurement category II corresponds to measurements taken on circuits
directly connected to low-voltage installations.
Example: power supply to domestic electrical appliances and portable tools.
