ENGLISH User Manual
■
THERMOMETER DATA LOGGER
1821
1823
1822
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments certifies that
this instrument has been calibrated using standards and
instruments traceable to international standards.
We guarantee that at the time of shipping your instrument has
met its published specifications.
An N.I.S.T. traceable certificate may be requested at the
time of purchase, or obtained by returning the instrument to
our repair and calibration facility, for a nominal charge.
The recommended calibration interval for this instrument is 12
months and begins on the date of receipt by the customer. For
recalibration, please use our calibration services. Refer to our
repair and calibration section at www.aemc.com.
Serial #:
Catalog #:
Model #:
Please fill in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
®
d.b.a AEMC
www.a
emc.com
Instruments
2 Thermometer Data Logger Models 1821, 1822, 1823
CONTENTS
PRECAUTIONS ................................................................................................................................................................... 4
RECEIVING YOUR SHIPMENT ........................................................................................................................................... 5
ORDERING INFORMATION ................................................................................................................................................ 5
1. GETTING STARTED ........................................................................................................................................................ 6
1.1. Battery Installation .................................................................................................................................................... 6
1.2. Instrument Front Panel .............................................................................................................................................. 7
1.2.1. Models 1821 and 1822 .....................................................................................................................................7
1.2.2. Model 1823 .....................................................................................................................................................8
1.3. Ins trument Functions ................................................................................................................................................ 8
1.4. Turning the Instrument ON/OFF ............................................................................................................................... 9
1.5. Function Buttons ...................................................................................................................................................... 9
1.6. Display ..................................................................................................................................................................... 9
2. SETUP ........................................................................................................................................................................... 10
2.1. DataView Installation .............................................................................................................................................. 10
2.2. Connecting the Instrument to a Computer.............................................................................................................. 10
2.3. Instrument Date/Time ............................................................................................................................................. 11
2.4. Auto OFF ................................................................................................................................................................ 11
2.5. Measurement Units ................................................................................................................................................ 11
2.6. Alarms .................................................................................................................................................................... 11
2.7. Sensor Type ........................................................................................................................................................... 11
3. STANDALONE OPERATION ........................................................................................................................................ 12
3.1. Sensor Installation .................................................................................................................................................. 12
3.2. Making Measurements ........................................................................................................................................... 13
3.2.1. Temperature Difference (Model 1822) .......................................................................................................... 13
3.2.2. MAX-MIN Mod e ............................................................................................................................................. 13
3.2.3. HOLD ............................................................................................................................................................ 13
3.3. Recording Measurements ...................................................................................................................................... 14
3.4. Alarms .................................................................................................................................................................... 14
3.5. Errors ..................................................................................................................................................................... 14
4. DATAVIEW .................................................................................................................................................................... 15
5. TECHNICAL CHARACTERISTICS ............................................................................................................................... 16
5.1. Reference Conditions ............................................................................................................................................. 16
5.2. Electrical Specifications.......................................................................................................................................... 16
5.2.1. Models 1821 and 1822 .................................................................................................................................. 16
5.2.2. Model 1823 ................................................................................................................................................... 17
5.3. Memory .................................................................................................................................................................. 17
5.4. USB ........................................................................................................................................................................ 17
5.5. Bluetooth ................................................................................................................................................................ 18
5.6. Power Supply ......................................................................................................................................................... 18
5.7. Environmental Conditions ...................................................................................................................................... 18
5.8. Mechanical Specifications ...................................................................................................................................... 18
5.9. Compliance with International Standards ............................................................................................................... 18
5.10. Electromagnetic Compatibility (CEM) ................................................................................................................... 18
6. MAINTENANCE ............................................................................................................................................................. 19
6.1. Cleaning ................................................................................................................................................................. 19
6.2. Maintenance ........................................................................................................................................................... 19
6.3. Battery Replacement .............................................................................................................................................. 19
6.4. Firmware Update .................................................................................................................................................... 19
REPAIR AND CALIBRATION .............................................................................................................................................. 20
TECHNICAL AND SALES ASSISTANCE ......................................................................................................................... 20
LIMITED WARRANTY ........................................................................................................................................................ 21
Thermometer Data Logger Models 1821, 1822, 1823 3
Thank you for purchasing the Model 1821 or Model 1822 thermocouple thermometer data logger, or Model 1823
resistance thermometer data logger.
read these operating instructions carefully
comply with the precautions for use
WARNING, risk of DANGER! The operator must refer to these instructions whenever this
danger symbol appears.
Information or useful tip.
Battery.
Magnet.
The product has been declared recyclable after analysis of its life cycle in accordance with
the ISO14040 standard.
For best results from your instrum ent:
AEMC has adopted an Eco-Design approach in order to design this appliance. Analysis of
the complete lifecycle has enabled us to control and optimize the effects of the product on
the environment. In particular this appliance exceeds regulation requirements with respect
to recycling and reuse.
Indicates conformity with European directives and with regulations covering EMC.
Indicates that, in the European Union, the instrument must undergo selective disposal in
compliance with Directive WEEE 2002/96/EC. This instrument must not be treated as
household waste.
Precautions
This instrument is compliant with safety standard IEC 61010-2-030, for voltages up to 5V with respect to ground.
Failure to observe the following safety instructions may result in electric shock, fire, explosion, and damage to
the instrument and/or the installation in which it is locat ed.
The operator and/or the responsible authority must carefully read and clearly understand the all
precautions to be taken in use. Thorough knowledge and awareness of electrical hazards are essential
when using this instrument.
Observe the conditions of use, including temperature, relative humidity, altitude, degree of pollution, and
place of use.
Do not use the instrument if it appears damaged, incomplete, or poorly closed.
Before each use, check the condition of the housing and accessories. Any item on which the insulation is
deteriorated (even partially) must be set aside for repair or scrapping.
Do not take measurements on bare live conductors. Use a non-contact or properly insulated sensor.
Always wear personal protective equipment (PPE), in particular insulating gloves, if there is any doubt about
the voltage levels to which the temperature sensor is connected.
All troubleshooting and metrological checks must be done by competent, accredited personnel.
4 Thermometer Data Logger Models 1821, 1822, 1823
Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your
distributor of any missing items. If the equipment appears to be damaged, file a claim immediately with the
carrier and notify your distributor at once, giving a detailed description of any damage. Save the damaged
packing container to substantiate your claim.
Ordering Information
Thermocouple Thermometer Data Logger Model 1821….………………….…………..…...... Cat. #2121.74
Includes soft carrying pouch, three AA alkaline batteries, 6 ft. (1.8m) USB cable, one thermocouple K Type,
quick start guide, USB thumb-drive with DataView
The
rmocouple Thermometer Data Logger Model 1822….………………….……..…….......... Cat. #2121.75
Includes soft carrying pouch, three AA alkaline batteries, 6 ft. (1.8m) USB cable, two thermocouple K Type,
quick start guide, USB thumb-drive with DataView
®
software and user manual.
®
software and user manual.
RTD Th
Includes soft carrying pouch, three AA alkaline batteries, 6 ft. USB cable, one 3 prong flexible RTD,
quick start guide, USB thumb-drive with DataView
Repl
ermometer Data Logger Model 1823….…………………………………..…….............. Cat. #2121.76
®
software and user manual.
acement Parts:
Thermocouple – Flexible (1M), K Type, -58 to 480 °F (-50 to 249 °C)…….............…................ Cat. #2126.47
able – Replacement 6 ft. (1.8m) USB…………….………………………….............…................Cat. #2138.66
C
Pouch – Replacement Carrying Pouch………………..…..…………….………..…....................... Cat. #2154.71
3-Prong Mini Flat Pin Connector for RTD …………….............................................…................ Cat. #5000.82
Acce
ssories:
Multifix Universal Mounting System …...….…………..……………..…………..............................Cat. #5000.44
Adapter – US Wall Plug to USB……………....…………..……….…...………..………….............. Cat. #2153.78
Shock Proof Housing…………………………........…..….….…………...………..……..………….. Cat. #2122.31
Case – General Purpose Carrying Case ……........…….….…………...………..……..…............. Cat. #2118.09
Thermocouple – Needle, 7.25 x 0.5” K Type, -58° to 1292 °F ……...…..….….…………............. Cat. #2126.46
he accessories and replacement parts, visit our web site: www.aemc.com
For t
Thermometer Data Logger Models 1821, 1822, 1823 5
1. GETTING STARTED
1.1. Battery Installation
The instrument accepts three AA or LR6 alkaline batteries.
1. “Tear-drop” notch to hang instrument
2. Non-skid pads
3. Magnets for mounting to a metallic surface
4. Battery compartment cover
To change the batteries:
1. Press the tab of the battery compartment cover and lift it clear.
2. Remove the battery compartment cover.
3. Insert the new batteries, ensuring correct polarity.
4. Close the battery compartment cover; ensuring it is completely and correctly closed.
6 Thermometer Data Logger Models 1821, 1822, 1823
1.2. Instrument Front Panel
1.2.1. Models 1821 and 1822
1. T1 thermocouple input
2. T2 thermocouple input
3. Backlit LCD
4. Keypad
5. ON/OFF button
6. Type B micro-USB connector
Thermometer Data Logger Models 1821, 1822, 1823 7
1.2.2. Model 1823
1. RTD probe input
2. Backlit LCD
3. Keypad
4. ON/OFF button
5. Type B micro-USB connector
1.3. Instrument Functions
The Models 1821 and 1822 are thermocouple-based thermometers with one and two channels, respectively.
They operate with sensor types K (Chromel/Alumel), J (iron/Constantan), T (copper/Constantan), E
(Chromel/Constantan), N (Nicrosil/Nisil), R (platinum-rhodium/platinum), and S (platinum-rhodium/platinum) and
can measure temperatures from -418 to +3213°F (-250 to +1767°C) depending on sensor.
The Model 1823 is a single channel resistive-probe thermometer (RTD100 or RTD1000). It measures
temperatures from -148 to +752°F (-100 to +400°C).
These stand alone instruments can:
Display temperature measurements in °C or °F
Record minimum and maximum temperatures in a specified period
Record and store measurements
Communicate with a computer via Bluetooth or USB cable
DataView
®
with the Data Logger Control Panel software can be installed on a computer to allow you to
configure the instruments, view measurements in real time, download data from the instruments, and create
reports.
8 Thermometer Data Logger Models 1821, 1822, 1823
