AEMC SL261 Operating Manual

COMPATIBLE CURRENT

PROBES & SENSORS FOR POWER QUALITY METERS

193-24-BK 193-36-BK

J93 MA193-10-BK MA193-14-BK

MN93-BK MN193-BK MR193-BK

SL261-BK

SR193-BK

ENGLISH

User Manual

No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.

Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments 15 Faraday Drive • Dover, NH 03820 USA Tel: (800) 945-2362 or (603) 749-6434 • Fax: (603) 742-2346

This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise. Chauvin Arnoux®, Inc. has made every reasonable effort to ensure that this documentation is accurate; but does not warrant the accuracy or completeness of the text, graphics, or other information contained in this documentation. Chauvin Arnoux®, Inc. shall not be liable for any damages, special, indirect, incidental, or inconsequential; including (but not limited to) physical, emotional or

monetary damages due to lost revenues or lost prots that may result from the use of this documentation, whether or not

the user of the documentation has been advised of the possibility of such damages.

Thank you for purchasing an AEMC current probe.

For best results from your instrument and for your safety, read the enclosed operating instructions carefully and comply with the precautions for use. These

products must be only used by qualied and trained users.

WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger symbol appears.

CAUTION! Risk of electric shock. The voltage at the parts marked with this symbol may be dangerous.

Application or withdrawal authorized on conductors carrying dangerous voltages. Type A current sensor as per IEC 61010-2-032.

Must not be applied to or removed from conductors at dangerous voltages. Type B current sensor as per IEC 61010-2-032.

Equipment is protected by double insulation.

Battery

Important instructions to read and to fully understand.

Useful information or tip to read.

The CE marking guarantees conformity with European directives and with regulations covering EMC.

The trash can with a line through it means that in the European Union, the product must undergo selective disposal for the recycling of electric and electronic material, in compliance with Directive WEEE 2002/96/EC.

Denition of Measurement Categories (CAT)

CAT IV Measurement category IV corresponds to measurements taken at the

source of low-voltage installations. Example: power feeders, counters and protection devices.

CAT III Measurement category III corresponds to measurements on building

installations. Example: distribution panel, circuit-breakers, machines or xed industrial devices.

CAT II Measurement category II corresponds to measurements taken on cir-

cuits directly connected to low-voltage installations. Example: power supply to domestic electrical appliances and portable tools.

PRECAUTIONS BEFORE USE

The protection assured by the current probe can be compromised if it is used in a way that is not recommended by the manufacturer.

■ Comply with the rated maximum voltage and current, and the measurement category. Do not use the current probe on networks where the voltage or

category exceeds those specied.

■ Comply with the conditions of use (e.g. temperature, humidity, altitude, degree of pollution, location).

■ Do not use the current probe if its housing is open, deteriorated, or incorrectly reassembled. Before each use, check the integrity of the insulation of the unit, jaws, clamps, housing, and leads.

■ Do not subject the current probe to water or other liquids.

■ Keep the jaw contacts of the clamp absolutely clean.

■ Use suitable personal protective equipment when hazardous voltages may be accessible in the installation where the measurement is made.

■ Any repairs must be carried out by accredited skilled personnel.

Table of Contents

1. INTRODUCTION .....................................................................4

1.1 Receiving Your Shipment......................................................................4

1.2 Ordering Information .............................................................................4

2. PRODUCT FEATURES ............................................................5

2.1 Control Features ...................................................................................5

2.1.1 AmpFlex® Model 193-24-BK & 193-36-BK ...............................5

2.1.2 MiniFlex® Model MA193-BK .....................................................6

2.1.3 AC/DC Current Probe Model J93 .............................................7

2.1.4 AC Current Probe Models MN93-BK & MN193-BK ..................8

2.1.5 AC Current Probe Model MR193-BK ........................................9

2.1.6 AC Current Probe Model SL261 .............................................10

2.1.7 AC Current Probe Model SR193-BK ......................................11

3. OPERATION .......................................................................... 12

4. SPECIFICATIONS .................................................................14

4.1 Electrical .............................................................................................14

4.2 Environmental .....................................................................................15

4.3 Mechanical..........................................................................................15

4.4 Safety..................................................................................................16

5. MAINTENANCE ....................................................................17

5.1 Cleaning..............................................................................................17

5.2 Battery Replacement ..........................................................................17

5.2.1 Model MR193 .........................................................................17

5.2.2 Model SL261 ..........................................................................17

5.2.3 Model J93 ...............................................................................18

5.3 Repair and Calibration ........................................................................19

5.4 Technical and Sales Assistance ..........................................................19

5.5 Limited Warranty .................................................................................20

5.6 Warranty Repairs ................................................................................20

Current Probes & Sensors for Power Quality Meters

1. INTRODUCTION

1.1 Receiving Your Shipment

Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your distributor of any missing items. If the equipment appears

to be damaged, le a claim immediately with the carrier and notify your distributor

at once, giving a detailed description of any damage. Save the damaged packing container to substantiate your claim.

1.2 Ordering Information

NOTE: The current probes in this manual are compatible only with AEMC® Power Analyzers (see § 4 for meter compatibility).

AmpFlex® Sensor 24" Model 193-24-BK .......................................... Cat. #2140.34

AmpFlex® Sensor 36" Model 193-36-BK .......................................... Cat. #2140.35

MiniFlex® Sensor 10" Model MA193-10-BK......................................Cat. #2140.48

MiniFlex® Sensor 14" Model MA193-14-BK ......................................Cat. #2140.50

AC/DC Current Probe Model J93 ..................................................... Cat. #2140.49

AC Current Probe Model MN93-BK..................................................Cat. #2140.32

AC Current Probe Model MN193-BK................................................Cat. #2140.36

AC Current Probe Model MR193-BK................................................Cat. #2140.28

AC Current Probe Model SR193-BK ................................................ Cat. #2140.33

AC/DC Current Probe Model SL261* ............................................... Cat. #1201.51

* Adapter for SL261 - BNC Adapter ............................................Cat. #2140.40

4 Current Probes & Sensors for Power Quality Meters

2. PRODUCT FEATURES

2.1 Control Features

2.1.1 AmpFlex® Model 193-24-BK & 193-36-BK

1. Flexible sensor

2. Sensor opening connector

3. Shielded lead

4. Custom 4-pin input connector

Current Probes & Sensors for Power Quality Meters

2.1.2 MiniFlex® Model MA193-BK
