Model OT-1
Model OT-1
The Outlet Tester Model OT-1 detects faulty wire in 3-wire receptacles. It
detects open ground and neutrals as well as reversed hot/ground connections.
Ideal for use on 100 to 125V
AC receptacles.
Model OT-2
The Outlet/GFCI Model OT-2 tester examines GFCI for proper operation.
It detects faulty wiring in 120V 3-wire receptacles. It detects open grounds
and neutrals as well as reversed hot/ ground connections. Ideal for use on
100 to 125V
AC receptacles.
Features
• Detects faulty wiring in 3-wire
receptacles
• Detects open grounds and neutrals
• Detects reversed hot/ground
connections
• Simply plug in and watch red and
amber indicators
• For use on 100 to 125V
AC
Model OT-2
• Test GFCI for proper operation
• 120V — 3-wire US
Outlet Tester
Models OT-1 & OT-2
ORDERING INFORMATION CATALOG NO.
Outlet Tester Model OT-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat. #2121.02
Outlet/GFCI Tester Model OT-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat. #2121.03
Models OT-1 & OT-2 (pdf) 08/02
Technical Assistance (800) 343-1391 www.aemc.com1of 2
Model OT-2
Outlet Tester Model OT-1 detecting faulty
wire in a 3-wire receptacle.
Models OT-1 & OT-2 (pdf) 08/02
Technical Assistance (800) 343-1391 www.aemc.com2of 2
