AEMC JM830A Data sheet

AC Current Probes Model JM830A (pdf) Rev. 03 10/05
Technical Assistance (800) 343-1391 www.aemc.com1of 4
AC Current Probe Model JM830A
The Model JM830A is a high performance AC current probe for higher currents. Excellent transformation and low phase shift, plus a broad frequency response, permit accurate measurements of current and power. The high quality magnetic cores and uniform windings provide for accurate measurements up to 3600A
AC. The
“squared” jaw permits multiple conductor or bus bar positioning. The Model JM830A provides excellent True RMS capabilities and reliable signal reproduction.
The Model JM830A works as a tradi­tional current transformer providing current outputs (mA) over a broad range of transformation ratios. The Model JM830A is designed for use on DMMs, power and harmonic meters, recorders or instruments with AC current ranges.
Features
Nominal range: up to 2400AAC
(continuous cycle for the full temperature range)
• Transformation ratio: 3000:1
Output: 0.333mA/A
Designed for use on DMMs, power
and harmonic meters, recorders or
instruments with AC current ranges
Applications
Field testing
Electrical utility
HVAC
Industrial maintenance
Laboratory
Plant maintenance
AC Current Probes Model JM830A (pdf) Rev. 03 10/05
Technical Assistance (800) 343-1391 www.aemc.com2of 4

Specifications

MODEL JM830A
ELECTRICAL
Nominal Range 2400A Measurement Range 1 to 3600AAC Transformation Ratio 3000:1 Output Signal 0.333mA
AC/AAC
(1A @ 3000A)
Accuracy (500A Range)
150A 1.5% of Reading 600A 0.75% of Reading
3000A 0.5% of Reading
Phase Shift (500A Range)
150A 1.5° 600A 0.75°
3000A 0.5°
Overload 3600A for 5 min Frequency Range 30Hz to 5kHz; current
derating above 1kHz
for continuous use
Load Impedance 5Ω Working/Common
Mode Voltage
600V
AC
Output Termination 5 ft Lead
MECHANICAL
Operating Temperature 14° to 122°F (-10° to 50°C) Storage Temperature -13° to 176°F (-25° to 80°C) Jaw Opening 3.54" (90mm) Maximum Conductor Size Cable: 2.52" Ø max (64mm); Bus bar: 1.97 x 5.31" (50 x 135mm); 2.52 x 3.94" (64 x 100mm) Dimensions 4.72 x 12.40 x 1.89" (120 x 315 x 48mm) Weight 2.65 lbs (1200g) Polycarbonate Material Handles: 10% fiberglass charged polycarbonate UL94 VO; Jaws: ABS UL V2
SAFETY
Electrical EN61010-2-32 Electromagnetic EN 50081-1 Class B; EN 50082-2 Electrostatic discharge IEC 100-4-2;
Compatibility Radiated field IEC 1000-4-3; Fast transients IEC 1000-4-4; Magnetic field at 50/60Hz IEC 1000-4-4
Double Insulation Yes
CE Mark Yes
Note: Reference conditions:
23°C ± 3°K, 20 to 85% RH, 48 to 65Hz, external magnetic field < 40A/m, no DC component, no external current carrying conductor, test sample centered. Load impedance 5Ω.
AC Current Probes Model JM830A (pdf) Rev. 03 10/05
Technical Assistance (800) 343-1391 www.aemc.com3of 4
Ø=2.52" (64mm)

ORDERING INFORMATION CATALOG NO.

AC Current Probe Model JM830A (Lead – .333mA/A – 3000A max) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat. #2110.83
Includes a user manual
Accessories (Optional)
Banana plug adaptor (to nonrecessed plug) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat. #1017.45
Banana/BNC Connector XF-SS (4mm banana plug) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat. #2111.32
Leads:
Double/reinforced 5 ft (1.5m) lead with safety 4mm banana plug
Cable max.
1.97 x 5.31" (50 x 135mm) or
2.52 x 3.94" (64 x 100mm) Bus Bar max.
P1 P2
12.01"
(305mm)
4.72"
(120mm)
1.89"
(48mm)
AC Current Probes Model JM830A (pdf) Rev. 03 10/05
Technical Assistance (800) 343-1391 www.aemc.com4of 4
