ELECTRICAL TEST TOOLS
ELECTRICAL TEST TOOLS
R
A
T
I
N
G
S
A
F
E
T
Y
PHASE AND MOTOR ROTATION METERS
MODELS , &
Ideal for installing rotating machinery or
motors, and for checking generator output
phase direction
SPECIFICATIONS
MODELS
ELECTRICAL
Operating Voltage
Frequency Range
Power Supply Self-powered via the
MECHANICAL
Dimensions
Weight
ENVIRONMENTAL
Operating
Temperature
Storage
Temperature
SAFETY
Safety Ratings
Electrical Safety
PRODUCT INCLUDES
&
Carrying case, three test
leads (4ft), three alligator
clips and a user manual.
Soft carrying case, meter with
attached test leads (black, red
& blue) with alligator clips, 9V
battery and user manual.
6608 6609 6610
40 to 850Vac
between phases
measurement inputs
4.5oz (130g) 6oz (170g)
IEC 61010-1, DIN VDE 0411;
IEC 61557-7, DIN VDE 0413-7;
With leads connected:
40 to 600Vac between
phases
15 to 400Hz 45 to 65Hz
9V Alkaline battery
(included)
5.1 x 2.7 x 1.3"
(130 x 69 x 32mm)
32° to 104°F
(0° to 40°C)
-4° to 122°F
(-20° to 50°C);
< 80% RH
Tightness: IP40
600V CAT III
Static induction
One 9V Alkaline battery
(included)
5.0 x 2.8 x 1.8"
(128 x 72 x 44mm)
13.4oz (380g)
battery included
14° to 122°F
(-10° to 50°C);
max. 80% RH
-4° to 140°F
(-20° to 60°C);
max. 80% RH
EN 61010-1,
EN 61326-1
1000V CAT III;
600V CAT IV
IP
40
(Model 6610 Only)
FEATURES
• Voltage sensing detector clips – no metal
contact points to promote greater safety
(Model 6610)
• Indication of live phase presence or
phase absence
• Designed for checking a wider range of
3-phase power source from 75V to 1000V
AC
(Model 6610)
• Determination of a motor's rotation
direction (Model 6609)
• Automatic testing as soon as the instrument
is connected
• Terminals and cables identified by colorcoding to simplify connection (test leads
are attached to Model 6610)
• Phase rotation indicators (Model 6608)
• Phase and motor rotation indicators
(Models 6609 & 6610)
• Color-coded leads (red, black, blue) and
alligator clips (black)
• Color-coded jacks for common U.S.
phase colors
• Line supplied - no battery needed
(Model 6608)
• Protected internally by high impedance
circuit to limit the current to user safe limits
CATALOG NO. DESCRIPTION
2121.10 Phase Rotation Meter Model 6608
2121.11 Phase & Motor Rotation Meter Model 6609
2121.12 Phase Rotation Meter Model 6610 (Non-contact)
56
FEATURES
• Avoids splitting lines - makes reading
current easy
• Increases sensitivity of clamp-on current
probes and clamp-on meters ten times in
X10 mode
• Direct reading X1 mode
• Voltmeter input jacks
• Integral ground conductor
• Facilitates reading current draw of device
plugged into it
• Facilitates reading current draw through
extension cords
• 120V, 15A capacity
ELECTRICAL TEST TOOLS
TESTER, SPLITTER AND DETECTOR
AC LINE SPLITTER
MODEL ALS
For use with clamp-on
meters & multimeters
using current probes
NONCONTACT AC VOLTAGE DETECTOR
MODEL NC
CATALOG NO. DESCRIPTION
2121.05 AC Line Splitter Model ALS-1
2121.09 Non-Contact AC Voltage Detector Model NC-1
57
SPECIFICATIONS
MODEL NC
Voltage Sensitivity 120 to 240VAC
Frequency 50/60Hz
Detection Distance <5mm
Over Voltage 600V CAT III
Battery 2 x 1.5V AAA Alkaline (included)
Safety
For indoor use and in accordance with
over voltage 600V CAT III, Pollution Degree 2
ELECTRICAL TEST TOOLS
NONCONTACT HIGH VOLTAGE DETECTOR
MODEL HVD
Warns the operator of live conductors with
the use of its detection sensor
SPECIFICATIONS
MODEL HVD
ELECTRICAL
Detection Frequency 45 to 70Hz
Ranges 240V, 2kV, 6kV, 11kV, 22kV,
Detection Selection range is detected at approximately 10" (25cm)
from the voltage. Greater detection distances can be
Power Source Three 1.5V C cell batteries (included)
MECHANICAL
Self Test User selectable
Indicators Bright red LED and audible buzzer
ENVIRONMENTAL
Operating Temperature 5° to 130°F (-15° to 55°C)
Storage Temperature -4° to 150°F (-20° to 65°C)
Humidity 0 to 93% RH @ 104°F (40°C)
33kV, 132kV, 275kV
obtained at lower voltage positions
FEATURES
• Non-contact high voltage detector
• Wide range of detection; 80V to 275kV; one instrument fits
all applications
• Eight switch-selectable voltage sensitivity ranges
• Lightweight, minimizes sway at the end of long hot sticks
• Audible and visual (LED) indication of live voltage
• Self-test ensures that all system functions and indicators are
working properly by energizing the complete system
• Designed for use with hot sticks incorporating a shotgun adapter
Note: Not designed to work on shielded cable or enclosure.
PRODUCT INCLUDES
Hard carrying case, 3 C cell
batteries, shotgun adapter
and user manual.
CATALOG NO. DESCRIPTION
21 31.1 2 Non-Contact High Voltage Detector Model 275HVD (240V to 275kV) Manual self-test
58
IP
65
FEATURES
• Full autotest
• Voltage detection, LED display:
12V
ac ≤ U ≤ 1000Vac
12V
dc ≤ U ≤ 1400Vdc
• Frequency: DC, 16.67 to 800Hz
• Detection of stray voltages
• Unipolar phase detection
(a single contact)
• Two-pole phase-sequence testing with
2-wire method = a third hand
is not required
• Continuity test with audible and visual
indication (R <100Ω)
• Extended continuity test with visual
indication for R <2kΩ, 60kΩ and 300kΩ
(Model C.A 771) R <0.5Ω to 2.999kΩ
(Model C.A 773)
• RCD trip test
• Complies with EN 61243-3 & IEC 61010
1000V CAT IV
• Climatic conditions: -25.6° to 140°F (-30° to
60°C) (Class S) (Model C.A 771) and 5° to
113°F (-15° to 45°C) (Class N) (Model C.A 773)
• Battery life > 5000 x 10s (Model C.A 771)
2500 x 10s (Model C.A 773) measurements
• Removable lead and test probe
• Delivered complete and
ready to use
ELECTRICAL TEST TOOLS
VOLTAGE ABSENCE TESTERS VATs
MODEL C.A & C.A
An essential tool for electricians to ensure no voltage
is present before working on any electrical installation
connected to the network
SPECIFICATIONS
MODELS C.A C.A
ELECTRICAL
Display LEDs LEDs + backlit digital display
Voltage Absence Testing (VAT) 12V
Voltage 12 to 1000Vac
Frequency DC, 16.67 to 800Hz
Impedance > 500kΩ
Max. Peak Current 3.5mA RMS
Polarity Indication Yes
Redundant Hazardous
Voltage Indication
Stray Voltage Detection Yes (by low-impedance load switching)
GFI Tripping up to 30mA
Phase/Neutral Identification Above 50V (45 to 65Hz); Above 150V (16.67 to 45Hz)
CONTINUITY & RESISTANCE
Buzzer Trigger Threshold 100Ω typical (150Ω max.)
Extended Continuity Test
(Resistance)
Test Current/
Open-circuit Voltage
Phase Rotation 2-wire method with microprocessor
Ph/Ph Voltage 50V ≤ U ≤ 1000V
Buzzer Intermittent beep for Voltage Detection
Standards & Electrical Safety IEC 61243-3, EN 61243-3, IEC 61010 1000V CAT IV
Operating Temperatures -25.6° to 140°F
Power Source 2 x AA batteries (included) or NiMH batteries
Environment Storage: -40° to 158°F (-40° to 70°C)
Dimensions/Weight 7.72 x 3.54 x 1.85" (196 x 90 x 47.1mm) / 570g
The ELV (Extra-Low Voltage) LED indicates that the voltage
(Safety Ex tra-Low Voltage) with the rate at which it flashes
(-30° to 60°C) (Class S)
ac ≤ U ≤ 1000Vac; 12Vdc ≤ U ≤ 1400Vdc
12 to 1400Vdc
is higher than the SELV
proportional to the voltage level
2kΩ, 60kΩ, 300kΩ 0.5Ω to 2999kΩ
≤ 1mA / ≤ 3.3V
ac (45 to 400Hz)
Continuous beep for continuity
5° to 113°F
(-15° to 45°C) (Class N)
PRODUCT INCLUDES
2 x 1.5V LR06/AA batteries, velcro strap, set of
removable test probes Ø 2mm with crystal safety
cover, probe-tip protection, and user manual in
5 languages.
CATALOG NO. DESCRIPTION
2121.14 Voltage Tester Model C.A 771
2121.15 Voltage Tester Model C.A 773
59
ELECTRICAL TEST TOOLS
TACHOMETERS
C.A & C.A
Simple to use and offers numerous measurement
capabilities with or without contact
SPECIFICATIONS
MODELS C.A & C.A
MEASUREMENTS
Rotational Speed
Function
Linear Speed
Function
Frequency
Function
Period Function
Duty Cycle
Function
Count function
GENERAL
Power Source
Battery life
Data Storage
Dimensions
Weight
Weatherproofing
Environment
SENSOR
Optical
Mechanical
Resolution: 0.0006 to 6m/min depending on range
±0.2% of scale from 50 to 125Hz / ±1% of scale otherwise
Range: 0 to 99,999 events; Accuracy: ±1 event (Model C.A 172 7)
Measurement distance: 0.4 x 19.7" (1 to 50cm). The maximum distance is given for a reflective adhesive strip
Measurement angle: ±15° in relation to the perpendicular of the reflective surface.
Mechanical adapter: End-fittings: elastomer with a durometer hardness of 80
Pressure on moving part: between 2 and 40N; maximum speed: 10,000rpm
Service life: approx. 1000 hours at 3000rpm wi th a pressure of 20N
Conical end-fitting accessory: Minimum diameter of measurement shaft: 0.2" (5mm)
Cylindrical end-fitting accessory: Spee d measurements on shafts with a diameter greater than 0.2" (5mm)
End-fitting accessory with wheel; Wheel diameter : 1.19" (30.183mm);
Wheel development: 3.94" ±0.004" (10cm ±0.1mm)
Range: 6 to 100,000rpm
Resolution: 0.0006 to 6rpm depending on range
Accuracy: ±1x10-4 of Reading ±6 counts
Range: 0.1 to 10,000m/min or ft/min
Accuracy: ±1x10-4 of Reading ±1 increment
Resolution: 0.0004 to 0.4Hz depending on range
Resolution: 0.0003 to 0.3ms depending on range
250 x 5 min measurements with optical sensor;
600 x 5 min measurements with external sensor
Range: 0.1 to 10,000Hz
Accuracy: ±4x10-5 of Reading ±4 counts
Range: 0.1 to 10,000ms
Accuracy: ±1x10-4 of Reading ±5 counts
Range: 10 to 10,000%
Resolution: 0.1 to 1% depending on range
Accuracy: ±0.1% of scale from 0.2 to 50Hz
9V battery Alkaline (included)
4000 measurements (Model C.A 1727 )
8.5 x 2.83 x 1.85" (216 x 72 x 47mm)
8.8oz (250g)
Storage: -4 to +158°F (-20 to +70°C) 95% RH;
Operation: 32 to 131°F (0 to 55°C) 90% RH
Reflective area: 10 to 90% of the target area.
with a minimum area of 10cm2.
IP51
or flat-ended shafts
IP
51
FEATURES
• Measurements up to 100,000 RPM
• Multiple functions and automatic
routines for data acquisition and
storage: measurement of rotational
speed, linear speed, count,
frequency and period
• Extensive programming possibilities
• Digital display with analog bargraph
• USB interface for processing results
on a PC (Model C.A 1727)
• Includes TachoGraph software on
CD-ROM (Model C.A 1727)
download memory only
• Stores up to 4000 measurements
results (Model C.A 1727)
ACCESSORIES
MECHANICAL ACCESSORIES KIT
Mechanical adapter, calibrated wheel, conical
end fitting and cylindrical end fitting
Catalog #1749.02
PRODUCT INCLUDES
Hard case, FRB F connector, 9V battery, set of fifteen reflective strips, quick start guide and user manual.
The Model C.A 1727 also includes a USB cable and TachoGraph software.
CATALOG NO. DESCRIPTION
174 8.10 Tachometer Model C.A 1725
174 8. 30 Tachometer Model C.A 1727
174 9.02 Mechanical accessories kit
60
