AEMC 1510 Operating Manual
ENGLISH User Manual
■
AIR QUALITY LOGGER
1510
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments certifies that
this instrument has been calibrated using standards and
instruments traceable to international standards.
We guarantee that at the time of shipping your instrument
has met its published specifications.
An N.I.S.T. traceable certificate may be requested at
the time of purchase, or obtained by returning the
instrument to our repair and calibration facility, for a
nominal charge.
The recommended calibration interval for this instrument is
12 months and begins on the date of receipt by the
customer. For recalibration, please use our calibration
services. Refer to our repair and calibration section at
www.aemc.com.
Serial #:
Catalog #:
Model #: 1510
Please fill in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
®
d.b.a AEMC
www.a
emc.com
Instruments
2
Air Quality Logger Model 1510
CONTENTS
PRECAUTIONS ............................................................................................................................................................................... 4
RECEIVING YOUR SHIPMENT ....................................................................................................................................................... 5
ORDERING INFORMATION ............................................................................................................................................................ 5
1. GETTING STARTED .................................................................................................................................................................... 6
1.1. Battery Installation ............................................................................................................................................................. 6
1.2. Instrument Front Panel ........................................................................................................................................................ 6
1.3. Ins trument Functions ......................................................................................................................................................... 7
1.4. Turning the Instrument ON/OFF ........................................................................................................................................ 7
1.5. Function Buttons ................................................................................................................................................................ 7
1.6. Display ............................................................................................................................................................................... 8
2. OPERATION ................................................................................................................................................................................ 9
2.1. Making a Measurement ..................................................................................................................................................... 9
2.1.1. Selecting Temperature Units ............................................................................................................................9
2.2. Portable Mode ................................................................................................................................................................... 9
2.3. 1D and 3D Modes .............................................................................................................................................................. 9
2.3.1. 1D and 3D Modes Activation ............................................................................................................................9
2.3.2. Visible and Audible Warnings .......................................................................................................................... 10
2.4. ECO (Energy Saving) Mode ............................................................................................................................................ 11
2.5. P_REC (Programmed Recording) Mode .......................................................................................................................... 11
2.6. MIN MAX Function ........................................................................................................................................................... 12
2.7. HOLD Function ................................................................................................................................................................ 12
2.8. M_REC (Manual Recording) Function ............................................................................................................................. 13
2.9. Backlight .......................................................................................................................................................................... 13
2.10. Alarm Buzzer ................................................................................................................................................................. 13
2.11. Error Messages ............................................................................................................................................................. 14
2.11.1. OL (Overload) Symbol .................................................................................................................................. 14
2.11.2. Err (Error) Symbol ......................................................................................................................................... 14
2.11.3. MEM_FULL (Memory Full) Symbol ............................................................................................................... 14
3. DATAVIEW ................................................................................................................................................................................ 15
3.1. DataView Installation ....................................................................................................................................................... 15
3.2. Connecting the Instrument to a Computer ....................................................................................................................... 15
4. SPECIFICATIONS ..................................................................................................................................................................... 16
4.1. Reference Conditions ...................................................................................................................................................... 16
4.2. Measurement Characteristics .......................................................................................................................................... 16
4.2.1. CO2 Measurements ........................................................................................................................................ 16
4.2.2. Influences on the measurements of CO2. ....................................................................................................... 16
4.2.3. Temperature Measurements ............................................................................................................................ 16
4.2.4. Humidity Measurement ................................................................................................................................... 16
4.2.5. Influence of the temperature on the relative humidity measurement ................................................................ 17
4.3. Measurement Modes ....................................................................................................................................................... 17
4.4. Power Supply ................................................................................................................................................................... 17
4.5. Recording ........................................................................................................................................................................ 18
4.6. Environment Conditions ................................................................................................................................................... 18
4.7. Mechanical Characteristics .............................................................................................................................................. 18
4.8. Compliance with International Standards......................................................................................................................... 18
4.9. Electromagnetic Compatibility .......................................................................................................................................... 18
5. MAINTENANCE ......................................................................................................................................................................... 19
5.1. Cleaning ........................................................................................................................................................................... 19
5.2. Battery Replacement ....................................................................................................................................................... 19
REPAIR AND CALIBRATION .......................................................................................................................................................... 20
TECHNICAL AND SALES ASSISTANCE ..................................................................................................................................... 20
LIMITED WARRANTY .................................................................................................................................................................... 21
Air Quality Logger Model 1510 3
Thank you for purchasing the Air Quality Logger Model 1510. For best results from your instrument:
read these operating instructions carefully
comply with the precautions for use
WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger
symbol appears.
Information or useful tip.
Battery.
Magnet.
The product has been declared recyclable after analysis of its life cycle in accordance with the
ISO14040 standard.
AEMC has adopted an Eco-Design approach in order to design this appliance. Analysis of the
complete lifecycle has enabled us to control and optimize the effects of the product on the
environment. In particular this appliance exceeds regulation requirements with respect to recycling
and reuse.
Indicates conformity with European directives and with regulations covering EMC.
Indicates that, in the European Union, the instrument must undergo selective disposal in compliance
with Directive WEEE 2002/96/EC. This instrument must not be treated as household waste.
Definition of measurement categories
CAT IV corresponds to measurements taken at the source of low-voltage installations.
Example: power feeders and protection devices.
CAT III corresponds to measurements on building installations.
Example: distribution panel, circuit-breakers, machines or fixed industrial devices.
CAT II corresponds to measurements taken on circuits directly connected to low-voltage
installations.
Example: power supply to electro-domestic devices and portable tools.
Precautions
This instrument is compliant with safety standard IEC 61010-2-030, for voltages up to 5V with respect to
ground. Failure to observe the following safety instructions may result in electric shock, fire, explosion, and
damage to the instrument and/or the installation in which it is located.
The operator and/or the responsible authority must carefully read and clearly understand all
precautions to be taken prior to using the instrument. Thorough knowledge and awareness of
electrical hazards are essential when using this instrument.
Observe the conditions of use, including temperature, relative humidity, altitude, pollution degree,
and location of use.
Do not use the instrument if it appears damaged, incomplete, or improperly closed.
Before each use, check the condition of the housing and accessories. Any item on which the
insulation is deteriorated (even partially) must be set aside for repair or disposal.
Never make measurements in atmospheres contaminated by solvents, which could damage the
sensor.
All troubleshooting and metrological checks must be done by accredited personnel.
4
Air Quality Logger Model 1510
Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your
distributor of any missing items. If the equipment appears to be damaged, file a claim immediately with the
carrier and notify your distributor at once, giving a detailed description of any damage. Save the damaged
packing container to substantiate your claim.
Ordering Information
Air Quality Logger Model 1510 (gray)…………..….….………………….…..…..….......…….. Cat. #2138.08
Air Quality Logger Model 1510 (white)….……………..….….…………………..….….......….. Cat. #2138.09
Both models include soft carrying pouch, two AA batteries, 6 ft. USB cable, quick start guide, USB drive
with DataView® software and user manual.
Replacement Parts:
Cable – Replacement 6 ft. (1.8m) USB…………….…..……….….............................…........ Cat. #2138.66
Soft Carrying Pouch...................................……………..….……….......………….................. Cat. #2154.71
Accessories:
Adapter, Bluetooth USB for Simple Logger II 4-Channel Models,
Models 6417, 1510 & L452 ….………………………………………..………………………… Cat. #2126.45
Wall Mount for Models 1510 & L452 (black) ....………..…………………….........………....... Cat. #2138.61
Desk Stand for Model 1510 (white)..............................................………............……….......Cat.
Calibration Kit for Model 1510 (includes calibration software CD)………...............…….......Cat. #2138.63
Metal Carrying Case .................
Wall Mount for Model 1510 (white) ................………….…...….….………..............……....... Cat. #2138.67
Adapter – US Wall Plug to USB…….…………………….…...….….……….............……....... Cat. #2153.78
For the accessories and replacement parts, visit our web site: www.aemc.com
…….…………………….…...….….……….............……....... Cat. #2138.65
#2138.62
Air Quality Logger Model 1510 5
1. GETTING STARTED
2 1 3
4
1.1. Battery Installation
The instrume nt accepts two AA or LR6 alkaline batteries.
1. Non-skid pads
2. “Tear-drop” notch to hang
instrument
3. Battery compartment cover
4. Magnets for mounting to a
metallic surface
To change the batteries:
1. Press the tab of the battery compartment cover and lift it clear.
2. Remove the battery compartment cover.
3. Insert the new batteries, ensuring correct polarity.
4. Close the battery compartment cover; ensuring it is completely and correctly closed.
1.2. Instrument Front Panel
1. Temperature and humidity sensors
1
2
3
4
7
8
9
2. LCD display
3. MODE/temperature units button
4. Backlight/ECO mode button
5. Record button
6. ON/OFF button
7. CO
8. Activate/deactivate buzzer
9. HOLD/Bluetooth enable/disable
10. MAX/MIN button
sensor
2
button
5
6
6
10
Air Quality Logger Model 1510
1.3. Instrument Functions
you cannot turn OFF the instrument when it is in HOLD or in recording mode.
Starts manual recording.
buzzer.
Long press activates/deactivates Bluetooth.
Long press exits MAX MIN mode.
The Model 1510 measures:
Concentration of carbon dioxide (CO2) in the air
Ambient temperature
Relative humidity
The instrument uses these measurements to determine and display the current comfort level.
DataView with the Data Logger Control Panel software can be installed on a computer to allow you to
configure the instrument, view measurements in real time, download data from the instrument, and create
reports.
1.4. Turning the Instrument ON/OFF
ON: Press the button.
OFF: Press the button for >2 seconds when the instrument is ON. Note that
In Portable mode, the instrument automatically turns OFF after 15 minutes of inactivity. This
feature is de-activated in other modes (1D or 3D, ECO, P_REC, MIN MAX, and M_REC), if
the instrument is actively communicating via Bluetooth or USB, or is running on USB power.
1.5. Function Buttons
On each button, a short press activates the top function and a long press (>2 seconds) activates the lower
function.
Button Function
Short press enables 1D and 3D modes.
Long press changes temperature units.
Pressing this button while holding down activates/deactivates alarm buzzer.
REC
MAX
MIN
Short press turns on the backlight.
Long press enables/disables energy-saving mode.
Holding down this button and then pressing activates/deactivates alarm
Short press freezes the display.
Short press enters MAX MI N mode; measurement values continue to be
displayed.
Second press displays the maximum value.
Third press displays minimum value.
Fourth press returns to normal measurement operation.
Air Quality Logger Model 1510 7
1.6. Display
Steady: recording
MIN MAX function: detection of minimum and maximum values
Blinking: Batteries low
or of the USB connection.
1
2
3
Symbol Function
1. CO2 measurement
2. Temperature
3. Relative humidity
MEM_FULL
1D
3D
MAX
MIN
ECO
P_REC
M_REC
HOLD
MIN MAX
ppm
Memory full
Monitor CO2 level
Monitor CO2, temperature, and humidity comfort zone thresholds
Maximum value
Minimum value
Energy-saving operating mode
Programmed recording
Blinking: waiting to start recording
Manual recording
Hold of the display
Unit of concentration of CO2 in the air in parts per million
Buzzer active
Bluetooth
Blinking: waiting for connection
Steady:
connected.
Steady: Indicator of external power supply by connection of the mains adapter
High threshold passed
Low threshold passed
Air quality/comfort level indi c ator
8
Air Quality Logger Model 1510
Loading...
