AEG-Electrolux WASL1E101, WASL2E101, EWS126511W User Manual

user manual

Washing Machine

WA SL1 E 101
WA SL2 E 101

2 electrolux

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

Contents

Safety information 2
Product description 4
Control panel 4
Personalization 6
First use 7
Daily use 7
Helpful hints and tips 11
Washing programmes 12

Subject to change without notice

Care and cleaning 16
What to do if… 19
Technical data 22
Consumption values 23
Installation 23
Electrical connection 26
Environment concerns 27

Safety information

Important! Read carefully & keep for future
reference.

• The safety of Your appliance complies with
the industry standards and with legal re­quirements on the safety of appliances.
However, as manufacturers, we feel it is
our duty to provide the following safety
notes.

• It is most important that this instruction
book should be retained with the appli­ance for future reference. Should the ap­pliance be sold or transferred to another
owner, or should you move house and
leave the appliance, always ensure that the
book is supplied with the appliance in or­der that the new owner can get to know
the functioning of the appliance and the
relevant warnings.

• You MUST read them carefully before in­stalling or using the appliance.

• Before first starting up, check the appli­ance for any damage incurred during
transport. Never connect up a damaged
appliance . If parts are damaged, contact
your supplier.

• If the appliance is delivered in the winter
months when there are minus tempera­tures. Store it at room temperature for 24
hours before using for the first time.

General safety

• It is dangerous to alter the specifications or
attempt to modify this product in any way.

• During high temperature wash pro­grammes the door glass may get hot. Do
not touch it!

• Make sure that small pets do not climb into
the drum. To avoid this, please check into
the drum before using.

• Any objects such as coins, safety pins,
nails, screws, stones or any other hard,
sharp material can cause extensive dam­age and must not be placed into the ma­chine.

• Only use the advised quantities of fabric
softener and detergent. Damage to the
fabric can ensue if you over-fill. Refer to the
manufacturer’s recommendations of
quantities.

• Wash small items such as socks, laces,
washable belts etc in a washing bag or pil­low case as it is possible for such items to
slip down between the tub and the inner
drum.

• Do not use your washing machine to wash
articles with whalebones, material without
hems or torn material.

• Always unplug the appliance and turn off
the water supply after use, cleaning and
maintenance.

• Under no circumstances should you at­tempt to repair the machine yourself. Re­pairs carried out by inexperienced people
may cause injury or serious malfunction­ing. Contact your local Service Centre. Al­ways insist on genuine spare parts.

electrolux 3

Installation

• This appliance is heavy. Care should be
taken when moving it.

• When unpacking the appliance, check that
it is not damaged. If in doubt, do not use it
and contact the Service Centre.

• All packing and transit bolts must be re­moved before use. Serious damage can
occur to the product and to property if this
is not adhered to. See relevant section in
the user manual.

• After having installed the appliance, check
that it is not standing on the inlet and drain
hose and the worktop is not pressing the
electrical supply cable against the wall.

• If the machine is situated on a carpeted
floor, please adjust the feet in order to al­low air to circulate freely under the appli­ance.

• Always be sure, that there is no water leak­age from hoses and their connections after
the installation.

• If the appliance is installed in a location
subject to frost, please read the “dangers
of freezing” chapter.

• Any plumbing work required to install this
appliance should be carried out by a quali­fied plumber or competent person.

• Any electrical work required to install this
appliance should be carried out by a quali­fied electrician or competent person.

Use

• This appliance is designed for domestic
use. It must not be used for purposes other
than those for which it was designed.

• Only wash fabrics which are designed to
be machine washed. Follow the instruc­tions on each garment label.

• Do not overload the appliance. See the
Washing Programme Table.

• Before washing, ensure that all pockets
are empty and buttons and zips are fas­tened. Avoid washing frayed or torn arti­cles and treat stains such as paint, ink,
rust, and grass before washing. Under­wired bras must NOT be machine washed.

• Garments which have been in contact with
volatile petroleum products should not be
machine washed. If volatile cleaning fluids
are used, care should be taken to ensure
that the fluid is removed from the garment
before placing in the machine.

• Never pull the power supply cable to re­move the plug from the socket; always
take hold of the plug itself.

• Never use the appliance if the power sup­ply cable, the control panel, the working
surface or the base are damaged so that
the inside of the washing machine is ac­cessible.

Child safety

• This appliance is not intended for use by
person (including children) with reduced
physical sensory or mental capabilities or
lack of experience and knowledge unless
they have been given supervision or in­struction concerning use of the appliance
by a person responsible for their safety.

• The packaging components (e.g. plastic
film, polystyrene) can be dangerous to chil­dren - danger of suffocation! Keep them
out of children’s reach.

• Keep all detergents in a safe place out of
children’s reach.

• Make sure that children or pets do not
climb into the drum. To prevent children
and pets becoming trapped inside the
drum the machine incorporates a special
feature. To activate this device, rotate the
button (without pressing it) inside the door
clockwise until the groove is horizontal. If
necessary use a coin.

To disable this device and restore the pos­sibility of closing the door, rotate the but­ton counterclockwise until the groove is
vertical.

4 electrolux

Product description

Your new appliance meets all modern re­quirements for effective treatment of laundry
with low water, energy and detergent con­sumption.

1

The NEW JET system allows total use of de­tergent and reduces water consumption so
saving energy.

2

3

4

6

1 Detergent dispenser drawer
2 Control panel
3 Door opening handle

Detergent dispenser drawer

Compartment for detergent used for pre-

wash. The prewash detergent is added at

the beginning of the wash programme.

Compartment for powder or liquid deter-

gent used for main wash .

Compartment for liquid additives (fabric

softener, starch).

Compartment for stain remover used for

main wash with STAIN - option .

Control panel

Below is a picture of the control panel. It
shows the programme selector dial as
well as the buttons and the display.

5

4 Rating plate
5 Drain pump
6 Adjustable feet

These are presented by relevant num­bers on the following pages.

9

1234567 8

electrolux 5

1 Programme selector dial
2 TEMPERATURE button ( TEMP. )
3

SPIN reduction button ( U/MIN. - ES-
SORAGE )

4 OPTION button ( OPTION - OPTIONS )
5

OK button ( OK )

7

START/PAUSE button ( START/PAUSE

- DEPART/PAUSE )

8

DELAY START button ( ZEITVORWAHL

- DEPART DIFFERE )

9 Display

6 TIME SAVING button ( ZEITSPAREN -

TEMPS )

Symbols on the control panel :

= Handwash

= Child Lock

Display

9.1 9.2 9.3 9.9

9.4 9.5 9.6 9.7 9.8

9.1 - Temperature indicator and COLD
symbol

9.2 - Spin Speed indicator, RINSE HOLD

, NIGHT CYCLE - symbols

9.3 - Programme progress display: PRE-

WASH
SPIN

, MAIN WASH , RINSE ,

, DRAIN , OVERDOSAGE

• The programme progress display shows
the washing phases of the selected pro­gramme.

6 electrolux

• During a washing cycle, a black line blinks
under the washing phase symbol of the
running programme. At the end of each
washing phase, the line under the corre­sponding symbol becomes fixed.

If the OVERDOSAGE symbol lights up at
the end of the programme, it indicates
that too much detergent has been used.

9.4 - Options: PREWASH

SENSITIVE

9.5 - DOOR - symbol (Door locked)

• This symbol indicates if the door can be
opened:
– the symbol is on: the door cannot be

opened. The appliance is performing a
washing programme.

– the symbol is off: the door can be

opened. The washing programme is fin­ished.

9.6 - TIME SAVING

9.7 - The display shows the following infor-

mation:

• Duration of the selected programme
– After selecting a programme, the dura-

tion is displayed in hours and minutes
(for example
culated automatically on the basis of the
maximum recommended load for each
type of fabric.

– After the programme has started, the

time remaining is updated every minute.

, EXTRA RINSE

, STAIN ,

- option symbol

. The duration is cal-

• Delay start
– The selected delay (20 hours max) set

by means of the relevant button appears
on the display for about 3 seconds (for

example
previously selected programme is dis­played.

– The DELAY START symbol will appear

on the display.

– The delay time value decreases by one

unit every hour and then, when remains
1 hour, the time decreases every mi­nute.

• Incorrect option selection
– If an option which is not compatible with

the set wash programme is selected,
the message Err is displayed for about
2 seconds and the yellow light of button
7 starts blinking.

•Alarm codes
– In the event of operating problems,

some alarm codes can be displayed, for
example

if...»).

• End of the programme
– When the programme has finished a

blinking zero
symbol disappears and the door can be
opened.

9.8 - DELAY START

9.9 - CHILD SAFETY LOCK

), then the duration of the

(see chapter «What to do

is displayed, the DOOR

- symbol

- symbol

Personalization

Acoustic signals

The machine is provided with an acoustic
device, which sounds in the following cases:

• at the end of the cycle

• in the event of operating problems.
By pressing the 3 and 4 buttons simultane­ously for about 6 seconds, the acoustic sig­nal is deactivated (except for the events of
operating problems). By pressing these two
buttons again, the acoustic signal is reacti­vated.

Child safety lock

This device permits you to leave the appli­ance unattended and not to worry that chil-

dren might be injured by or cause damage to
the appliance.
This function remains able also when the
washing machine is not working.
There are two different ways to set this op­tion:

• Before pressing button 7 : it will be impos­sible to start the machine.

• after pressing button 7 : it will be impossi­ble to change any other programme or op­tion.

To enable or disable this option press simul­taneously for about 6 seconds buttons 4 and
5 until the symbol 9.5 appears or disappears
on or from the display.

First use

• Ensure that the electrical and water
connections comply with the installa­tion instructions.

• Remove the polystyrene block and
any material from the drum.

• Before the first wash, run a cotton cy­cle at the highest temperature without

Daily use

Load the laundry

1. Open the door by carefully pulling the
door handle outwards. Place the laundry
in the drum, one item at a time, shaking
them out as much as possible.

2. Close firmly the door. You must hear a
click during closing.

electrolux 7

any laundry in the machine, to remove
any manufacturing residue from the
drum and tub. Pour 1/2 a measure of
detergent into the main wash com­partment and start the machine.

Warning! Do not embed the laundry
between the door and the rubber joint.

Measure out the detergent and the
fabric softener

Your new appliance was designed to reduce
water, energy and detergent consumption.
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent re­quired, pour it into the main wash compart­ment
prewash phase, pour the detergent into the
compartment marked

and, if you wish to carry out the

.

If you wish to perform the stain function,
pour the stain remover into the compartment

marked with an arrow.

If required, pour fabric softener into the com­partment marked

not exceed the MAX mark in the drawer).

Close the drawer gently.

(the amount used must

8 electrolux

Select the required programme by
means of programme selector dial (1)

You can choose the right programme for any
type of laundry following the descriptions on
the washing programme tables (see «Wash­ing Programmes»).
Turn the programme selector dial to the re­quired programme. The programme selector
determines the type of washing cycle (e.g.
water level, drum movement, number of rin­ses) and the washing temperature according
to the type of laundry.
The pilot light of button 7 starts blinking and
the display shows the duration of the selec­ted programme.
The selector dial can be turned either clock-

wise or anticlockwise. Position

to Reset

programme/ Switching OFF of the machine.

At the end of the programme the selec­tor dial must be turned to position ,

to switch the machine off.

If you turn the programme selector dial
to another programme when the ma­chine is working, the yellow pilot light of
button 7 will blink 3 times and the mes­sage Err is displayed on the display to
indicate a wrong selection. The machine
will not perform the new selected pro­gramme.

Select the desired TEMPERATURE
(Button 2)

When selecting a programme, the appli­ance automatically proposes the default
temperature provided for that pro­gramme.

Press this button repeatedly to increase or
decrease the temperature, if you want your
laundry to be washed at a temperature dif­ferent from the one proposed by the washing
machine.
The symbol of cold wash corresponds to - ­(

) .

For the maximum and the minimum
available wash water temperature, see
«Washing programmes».

Select the spin speed, NIGHT CYCLE or
RINSE HOLD option (button 3)

When the required programme has been
selected, your appliance automatically

proposes the maximum spin speed pro­vided for that programme.

Press this button repeatedly to change the
spin speed, if you want your laundry to be
spun at a speed different from the one pro­posed by the washing machine.
RINSE HOLD: by selecting this option the
water of the last rinse is not emptied out to
prevent the fabrics from creasing. At the end

of the programme,

and RINSE HOLD sym­bol appear on the display, DOOR symbol
(door locked) remains lit, the pilot light of but­ton 7 goes off and the door is blocked to in­dicate that the water must be emptied out.
NIGHT CYCLE: by selecting this option, the
machine will not drain the water of the last
rinse, so as not to wrinkle the laundry. As all
spinning phases are suppressed, this wash­ing cycle is very noiseless and it can be se­lected at night or in times with a more eco­nomical power rate. In some programmes
the rinses will be performed with more water.

At the end of the programme,

and RINSE
HOLD symbol appear on the display, the
DOOR symbol remains lit, the pilot light of
button 7 goes off and the door is blocked to
indicate that the water must be emptied out.

To empty out the water, please read
chapter «At the end of the programme».

Programme option buttons

Depending on the programme, different
functions can be combined.

Warning!

Not all the options are compatible among
themselves. The symbols of the incompatible
options disappear.
Anyway, if an option, which is not compatible
with the set washing programme or any other
option, is selected, the Err message is dis­played for few seconds and the yellow pilot
of button 7 light starts blinking.
You must select the options after you have
selected the programme but before pressing
the button 7 . Press the button 4 : all the op­tion symbols appear on the display.
To scroll all the available options, press the
button 4 . The corresponding symbol ap­pears on the display and starts blinking.
Press the button 5 to activate and confirm
your choice. A black dash appears under the
selected symbol to indicate that this option

electrolux 9

has been set. Press the same button to de­activate the option.
After selecting the options, wait about few
seconds until the display gets back to the
default status. The selected options appear
on the display.

For the compatibility among the options
and the washing programmes see chap­ter «Washing Programmes».

PREWASH option

Select this option if you wish your laundry to
be prewashed at 30°C before the main wash.
The Prewash ends with a short spin in pro­grammes for cotton and synthetic fabrics,
whereas in the programmes for delicate fab­rics the water is only drained.
The relevant symbol will appear on the dis­play.
This option is recommended for heavily
soiled laundry.

STAIN option

Select this option to treat heavily soiled or
stained laundry with stain remover (extended
main wash with time optimized stain action
phase). The relevant symbol will appear on
the display.
This option is not available with a tempera­ture lower than 40°C.
If you wish to perform a programme with the
stain option, pour stain remover into stain

compartment

marked with an arrow.

SENSITIVE option

By selecting this option the washing intensity
will be reduced. The machine adds one rinse
in the programmes for cottons and synthet­ics. The relevant symbol will appear on the
display.
This option cannot be selected together with
Extra Rinse option.
This option is recommended for non fast col­oured items and for frequently washed items.

EXTRA RINSE option (additional rinse)

This appliance is designed for saving water.
However, for people with a very delicate skin
(allergic to detergents) it may be necessary
to rinse the laundry using an extra quantity of
water (extra rinse). The relevant symbol will
appear on the display and this option is active
for selected washing programme.

If you wish to activate this option permanently
press simultaneously buttons 2 and 3 for
some seconds: the relevant symbol appears
on the display. If you wish to cancel it press
the same buttons until the symbol disap­pears.

Select the TIME SAVING option (button

6)

This option allows you to modify the washing
time, automatically proposed by the appli­ance.
By pressing this button you can select the
following options:
DAILY: by pressing button 6 once, the cor­responding symbol appears on the display
and the washing duration will be reduced to
wash daily soiled laundry. Reduced washing
time is presented on the display.
SUPER QUICK: by pressing button 6 twice,
the corresponding symbol remains lit on the
display and the washing duration will be re­duced to wash lightly soiled laundry or items
that have been used or worn for a short time.
Reduced washing time is presented on the
display.

Select the START/PAUSE (button 7)

To start the selected programme, press the
button 7 , the corresponding red pilot light
stops blinking.
The DOOR symbol appears on the display to
indicate that the appliance has started oper­ating and the door is locked.
To interrupt a programme which is running,
press the button 7 : the corresponding red
pilot light starts blinking.
To restart the programme from the point at
which it was interrupted, press the button 7
again. If you have chosen a delayed start the
machine will begin the countdown.
If an incorrect option is selected, the yellow
pilot light of the button 7 blinks 3 times and
the message Err is displayed for a few sec­onds.

Select the DELAY START (button 8)
Before you start the programme , if you

wish to delay the start, press the button re­peatedly, to select the desired delay.
The corresponding symbol will appear on the
display. The wash programme can be de­layed from 30 min - 60 min - 90 min, 2 hours

10 electrolux

and then by 1 hour up to a maximum of 20
hours by means of this button.
The selected delay time value will appear on
the display for about 3 seconds, then the du­ration of the programme will appear again.
You must select this option after you have set
the programme and before you press the
button 7 .
You can modify or cancel the delay time at
any moment, before you press the button 7 .
The door will be locked throughout the delay
time. If you wish to add laundry in the ma­chine during the delay time, press the button
7 to set the machine to pause. When the
Door symbol disappears, the door can be
opened. Add the laundry, close the door and
press the button 7 again.
Selecting the delayed start.

• Select the programme and the required
options.

• Select the delay start.

•Press button 7 : the appliance starts its
hourly countdown. The programme will
start after the selected delay has expired.

Cancelling the delayed start

• Set the washing machine to PAUSE by
pressing the button 7 ;

•

Press button 8 until the symbol

’ is dis-

played;

• Press the button 7 again to start the pro­gramme.

Important! The selected delay can be
changed only after selecting the washing
programme again.

The Delay Start can not be selected with
Drain programme.

Altering an option or a running
programme

It is possible to change some options before
the programme carries them out. Before you
make any change, you must pause the
washing machine by pressing the button 7 .
Changing a running programme is possible
only by resetting it . Turn the programme

selector dial to

and then to the new pro-

gramme position. Start the new programme
by pressing the 7 button again. The washing
water in the tub will not emptied out.

Interrupting a programme

Press the button 7 to interrupt a programme
which is running, the corresponding light

starts blinking. Press the button again to re­start the programme.

Cancelling a programme

Turn the selector dial to

to cancel a pro­gramme which is running. Now you can se­lect a new programme.

Opening the door after the programme
has started

When the machine is working and through­out the delay time the door is locked. If, for
any reason, you wish to open the door, set
firstly the machine to pause by pressing the
button 7 .

• If the DOOR symbol disappears, the door

can be opened;

• If the DOOR symbol doesn’t go off, it

means that the machine is already heating
or that the water level is too high. In this
case the door cannot be opened;

• If you cannot open the door but you need

to open it, you have to switch the machine
off by turning the selector dial to

. After

a few minutes the door can be opened

(pay attention to the water level and
temperature!) ;

After closing the door, it is necessary to se­lect the programme again and to press but­ton 7 .

At the end of the programme

The machine stops automatically, the pilot
light of button 7 pilot light goes off, a blinking

appears on the display and the acoustic
signal sounds for some minutes.
If you have chosen a programme or an option
that ends with water in the tub, follow the

below instruction to empty the water
out:

•

turn the programme selector dial to

• select the DRAINING or SPINNING pro-

gramme

• reduce the spin speed if needed, by

means of the relevant button

•press the button 7

• when the programme has finished the dis-

play shows a blinking

. On the display
the DOOR symbol disappears and the
door can be opened.

Turn the programme selector dial to to
switch the machine off. Remove the laundry
from the drum and carefully check that the
drum is empty.

electrolux 11

If you do not intend to carry out another
wash, close the water tap. Leave the door

Stand by : once the programme has finished
after a few minutes the energy saving system
will be enabled. The brightness of the display

Helpful hints and tips

Sorting out the laundry

Follow the wash code symbols on each gar­ment label and the manufacturer’s washing
instructions. Sort the laundry as follows:
whites, coloureds, synthetics, delicates,
woollens.

Before loading the laundry

Never wash whites and coloureds together.
Whites may lose their «whiteness» in the
wash.
New coloured items may run in the first wash;
they should therefore be washed separately
the first time.
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long
tapes.
Remove persistent stains before washing.
Rub particularly soiled areas with a special
detergent or detergent paste.
Treat curtains with special care. Remove
hooks or tie them up in a bag or net.

Removing stains

Stubborn stains may not be removed by just
water and detergent. It is therefore advisable
to treat them prior to washing.
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a
special detergent then rub in the soap and
water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and
dab the stain; treat several times.
Dried grease stains: moisten with turpen­tine, lay the garment on a soft surface and
dab the stain with the fingertips and a cotton
cloth.
Rust: oxalic acid dissolved in hot water or a
rust removing product used cold. Be careful
with rust stains which are not recent since the
cellulose structure will already have been
damaged and the fabric tends to hole.

open to prevent the formation of mildew and
unpleasant smells.

is reduced. By pressing any button the ap­pliance will come out of the energy saving
status.

Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with ace-

1)

tone

, lay the garment on a soft cloth and

dab the stain.
Lipstick: moisten with acetone as above,
then treat stains with methylated spirits.
Treat any residual marks with bleach.
Red wine: soak in water and detergent,
rinse and treat with acetic or citric acid, then
rinse. Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten

the fabric first with acetone

1)

, then with acetic
acid; treat any residual marks on white fab­rics with bleach and then rinse thoroughly.
Tar stains: first treat with stain remover, me­thylated spirits or benzine, then rub with de­tergent paste.

Detergents and additives

Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the en­vironment.
Although biodegradable, detergents contain
substances which, in large quantities, can
upset the delicate balance of nature.
The choice of detergent will depend on the
type of fabric (delicates, woollens, cottons,
etc.), the colour, washing temperature and
degree of soiling.
All commonly available washing machine de­tergents may be used in this appliance:

• powder detergents for all types of fabric

• powder detergents for delicate fabrics

(60°C max) and woollens

• liquid detergents, preferably for low tem-

perature wash programmes (60°C max)
for all types of fabric, or special for wool­lens only.

1) do not use acetone on artificial silk

12 electrolux

The detergent and any additives must be
placed in the appropriate compartments of
the dispenser drawer before starting the
wash programme.
If using liquid detergents, a programme
without prewash must be selected.
Your appliance incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.
Follow the product manufacturer’s recom­mendations on quantities to use and do not

exceed the «MAX» mark in the detergent
dispenser drawer .

Quantity of detergent to be used

The type and quantity of detergent will de­pend on the type of fabric, load size, degree
of soiling and hardness of the water used.
Follow the product manufacturers’ instruc­tions on quantities to use.

Washing programmes

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Fabrics Load
Type of Laundry

KOCH-/BUNTWÄSCHE - BLANC COULEURS

COTTON / LINEN
95° - Cold
Main wash - Rinses - Long spin
Max. load 8 kg - Reduced load 4 kg

White and coloured cotton (normally soiled items).

HYGIENE

HYGIENE
60°
Main wash - Rinses - Long spin
Max. load 8 kg
The washing programme for white cottons. This pro­gram eliminates the micro-organisms thanks to the
washing by 60°C and an additional rinse. In this way
the action is more effective. Put into the compartment
Stain a special additive for hygiene and select the op­tion Stain.

Use less detergent if:

• you are washing a small load

• the laundry is lightly soiled

• large amounts of foam form during wash-

ing.

Degrees of water hardness

Water hardness is classified in so-called “de­grees” of hardness. Information on hardness
of the water in your area can be obtained
from the relevant water supply company, or
from your local authority. If the water hard­ness degree is medium or high we suggest
you to add a water softener following always
the manufacturer’s instructions. When the
degree of hardness is soft, readjust the quan­tity of the detergent.

Options

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

SENSITIVE

EXTRA RINSE

TIME SAVING

SPIN REDUCTION

RINSE HOLD

PREWASH

STAIN

STAIN

1)

2)

1)

Detergent Com-

partment

3)

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Fabrics Load
Type of Laundry

40- 60 MIX

MIXED FABRICS
40°
Main wash - Rinses - Long spin
Max. load 8 kg
White and coloured cotton This programme can be
used for laundry, which should be washed at 40°C or
60°C separately. The maximum load capacity can be
put into the drum in order to save energy and water.
The same good washing result will be obtained as for
normal programme at 60°C.

JEANS

JEANS
60° - Cold
Main wash - Rinses - Long spin
Max. load 4 kg
With this programme it is possible to wash items like
pants, shirts or jackets in Jeans and also jersey realized
with hi-tech materials (the Extra Rinse option will be
activated automatically).

PFLEGELEICHT -SYNTHETIQUES

SYNTHETICS
60°- Cold
Main wash - Rinses - Short spin
Max. load 4 kg - Reduced load 2 kg
Synthetic or mixed fabrics: underwear, coloured
garments, non-shrink shirts, blouses.

LEICHTBÜGELN PLUS - REPASSAGE FACILE
PLUS

EASY IRON PLUS
60° - Cold
Main wash - Rinses - Short spin
Max. load 1,5 kg

Synthetic fabrics to be gentle washed and spun.

Selecting this programme the laundry is gently washed
and spun to avoid any creasing. In this way ironing is
easier. Furthermore the machine will perform additional
rinses.

FEINWÄSCHE - DELICATS

DELICATES
40° - Cold
Main wash - Rinses - Short spin
Max. load kg 4 - Reduced load kg 2

Delicate fabrics: acrylics, viscose, polyester.

Options

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

1)

STAIN

SENSITIVE

EXTRA RINSE

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

1)

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

STAIN

1)

2)

SENSITIVE

EXTRA RINSE

TIME SAVING

3)

SPIN REDUCTION

RINSE HOLD

PREWASH

1)

EXTRA RINSE

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

EXTRA RINSE

TIME SAVING

STAIN

1)

2)

3)

electrolux 13

Detergent Com-

partment

14 electrolux

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Fabrics Load
Type of Laundry

VISKOSE - VISCOSE

VISCOSE
40° - Cold
Main wash - Rinses - Short spin
Max. load kg 4
Special gentle programme for fabrics such a viscose,
cupro, lyocell. It performs an cleaning action more in­tensive than the handwash programme.

FEINSPÜLEN - RINÇAGES DELICATS

DELICATE RINSES
Rinses - Short spin
Max. load 8 kg
With this programme it is possible to rinse and spin
garments which have been washed by hand. The ma­chine performs some rinses, followed by a final spin.

PUMPEN - VIDANGE

DRAIN
Draining of water
Max. load 8 kg
For emptying out the water of the last rinse in pro­grammes with the option selected, that ends with water
left in the tub.

SCHLEUDERN - ESSORAGE

SPIN
Drain and long spin
Max. load 8 kg
Separate spin for hand washed cotton garments and
after programmes with the option selected that ends
with water left in the tub. The selector dial must be

turned to

. You can choose the spin speed by
pressing the relevant button to adapt it to the fabrics to
be spun.

DAUNEN - COUETTE

DUVETS
40° - 30°
Main wash - Rinses - Short spin
Max. load 2 kg
Special programme for a single synthetic blanket, du­vet, bedspread and so on.

WOLLE PLUS - LAINE PLUS ( Handwash)
WOOL PLUS
40° - Cold
Main wash - Rinses - Short spin
Max. load 2 kg
Washing programme for machine washable wool as
well as for hand washable woollens and delicate fab­rics.
Note: a single or bulky item may cause imbalance. If
the appliance doesn’t perform the final spin phase, add
more items, redistribute the load manually and then se­lect the spinning programme.

Options

Detergent Com-

partment

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

STAIN

1)

2)

EXTRA RINSE

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

EXTRA RINSE

SPIN REDUCTION

SPIN REDUCTION

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Fabrics Load
Type of Laundry

DESSOUS - LINGERIE (Handwash)

LINGERIE
40° - Cold
Main wash - Rinses - Short spin
Max. load 1 kg
This programme is suitable for very delicate items, as
lingerie, bras and underwear etc.

OUTDOOR - BLOUSONS

OUTDOOR SPORTS
40° - Cold
Main wash - Rinses - Short spin
Max. load 2,5 kg
Special program for sport clothes. By selecting this
program, do not add any additives.

SPORT INTENSIV - SPORT

SPORT INTENSIVE
40° - Cold
Prewash - Main wash - Rinses - Short spin
Max. load 2,5 kg
Special programme is suitable for washing heavily
soiled sport items. The machine will add automatically
a prewash phase before the main wash to eliminate
mud stains. We recommend you NOT to put the de­tergent into the

compartment of the detergent

drawer.

20 MIN. - 3 KG

30°
Main wash - Rinses - Short spin
Max. load 3 kg
This programme may be used for a quick washing of
sport items or cotton and synthetic items , lightly soiled
or worn once.

SCHNELL INTENSIV - INTENSIF

QUICK INTENSIVE
60° - 40°
Main wash - Rinses - Short spin
Max. load 5 kg
Quick washing programme, to be used for lightly soiled
white/fast coloured cottons and mixed fabrics.

Options

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

SPIN REDUCTION

RINSE HOLD

EXTRA RINSE

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

EXTRA RINSE

SPIN REDUCTION

SPIN REDUCTION

RINSE HOLD

EXTRA RINSE

electrolux 15

Detergent Com-

partment

16 electrolux

Programme
Maximum and Minimum Temperature
Cycle Description
Maximum Fabrics Load
Type of Laundry

SUPER ECO

Cold
Main wash - Rinses - Short spin
Max. load 3 kg
Mixed fabrics (cotton and synthetic). Cold wash
programme designed for saving energy, water and
time. This programme is suitable with detergents that
becomes effective at low temperature. The detergent
must be used with the supplied or a suitable detergent
dosing cap (use the amount of the detergent recom­mended by detergent's manufacturer). The appliance
automatically runs a short heating phase if the water
temperature is lower than 6°C only.

ENERGIESPAREN - ECONOMIQUE

COTTON ECONOMY
60°
Main wash - Rinses - Long spin
Max. load 8 kg
White and fast coloured cotton .
This programme can be selected for slightly or normally
soiled cotton items. The temperature will decrease and
the washing time will be extended. This allows to obtain
a good washing efficiency so saving energy.

/ AUS ARRET = OFF

For cancelling the programme which is running or to
switch the machine off .

1) If using liquid detergents, a programme without prewash must be selected.

2) Stain option can be selected only at the temperature of 40°C or higher.

3) If you select the Super Quick option by pressing button 5 , we recommend that you reduce the

maximum load as indicated. Full loading is possible however with somewhat reduced cleaning results.

Options

SPIN REDUCTION

RINSE HOLD

EXTRA RINSE

SPIN REDUCTION

NIGHT CYCLE

RINSE HOLD

PREWASH

SENSITIVE

EXTRA RINSE

1)

STAIN

Detergent Com-

partment

Care and cleaning

You must DISCONNECT the appliance from
the electricity supply, before you can carry
out any cleaning or maintenance work.

Descaling

The water we use normally contains lime. It
is a good idea to periodically use a water
softening powder in the machine. Do this
separately from any laundry washing, and
according to the softening powder manufac­turer's instructions. This will help to prevent
the formation of lime deposits.

After each wash

Leave the door open for a while. This helps
to prevent mould and stagnant smells form­ing inside the appliance. Keeping the door

open after a wash will also help to preserve
the door seal.

Maintenance wash

With the use of low temperature washes it is
possible to get a build up of residues inside
the drum.
We recommend that a maintenance wash be
performed on a regular basis.
To run a maintenance wash:

• The drum should be empty of laundry.

• Select the hottest cotton wash pro­gramme.

• Use a normal measure of detergent, must
be a powder with biological properties.

electrolux 17

External cleaning

Clean the exterior cabinet of the appliance
with soap and water only, and then dry thor­oughly.

Important! Do not use methylated spirits,
solvents or similar products to clean the
cabinet.

Detergent dispenser drawer

The detergent dispenser drawer should be
cleaned regularly.

1. Remove the detergent dispenser drawer
by pulling it firmly.

2. Remove the conditioner insert from the
middle compartment.

3. Clean all parts with water.

4. Put the conditioner insert in as far as it will
go, so that it is firmly in place.

5. Clean all parts of the washing machine,
especially the nozzles in the top of the
washing-in chamber, with a brush.

6. Insert the detergent dispenser drawer in
the guide rails and push it in.

1. Remove any rust deposits on the drum
with a cleaning agent for stainless steel.

2. Run a washing cycle without any washing
to clean off any cleaning agent residues.
Programme: Short Cotton Programme at
maximum temperature and add approx.
1/4 measuring cup of detergent.

Door seal

Check from time to time the door seal and
eliminate eventual possible objects that
could be trapped in the fold.

Drain pump

The pump should be inspected regularly and
particularly if:

• the machine does not empty and/or spin

• the machine makes an unusual noise dur-

ing draining due to objects such as safety
pins, coins etc. blocking the pump.

Proceed as follows:

1. Disconnect the appliance.

2. If necessary wait until the water has

cooled down.

3. Open the pump door.

Washing drum

Rust deposits in the drum may occur due to
rusting foreign bodies in the washing or tap
water containing iron.

Important! Do not clean the drum with
acidic descaling agents, scouring agents
containing chlorine or iron or steel wool.

4. Place a container close to the pump to

collect any spillage.

5. Release the emergency emptying hose,

place it in the container and remove its
cap cover.

18 electrolux

6. When no more water comes out, un­screw the pump and remove it. Always
keep a rag nearby to dry up spillage of
water when removing the pump.

7. Remove any objects from the pump im­peller by rotating it.

9. Screw the pump fully in.

10. Close the pump door.

Warning! When the appliance is in use
and depending on the programme
selected there can be hot water in the
pump. Never remove the pump cover
during a wash cycle, always wait until the
appliance has finished the cycle, and is
empty. When replacing the cover,
ensure it is securely re-tightened so as
to stop leaks and young children being
able to remove it.

Cleaning the water inlet filters
Important! If the appliance doesn't fill, takes

long to fill water, the starting button blinks
yellow or the display (if available) shows the
relevant alarm (see chapter "What to do if..."
for more details), check if the water inlet filters
are blocked .

To clean the water inlet filters:

1. Turn off the water tap.

8. Put the cap back on the emergency
emptying hose and place the latter back
in its seat.

2. Unscrew the hose from the tap.

3. Clean the filter in the hose with a stiff
brush.

4. Screw the hose back onto the tap. Make
sure the connection is tight.

5. Unscrew the hose from the machine.
Keep a rug nearby because some water
may flow.

6. Clean the filter in the valve with a stiff
brush or with the piece of cloth.

7. Screw the hose back to the machine and
make sure the connection is tight.

8. Turn on the water tap.

Emergency emptying out

If the water is not discharged, proceed as
follows to empty out the machine:

electrolux 19

1. pull out the plug from the power socket;

2. close the water tap;

3. if necessary, wait until the water has
cooled down;

4. open the pump door;

5. place a bowl on the floor and place the
end of the emergency emptying hose into
the bowl. Remove its cap. The water
should drain by gravity into the bowl.
When the bowl is full, put the cap back
on the hose. Empty the bowl. Repeat the
procedure until water stops flowing out;

6. clean the pump if necessary as previously
described;

7. replace the emergency emptying hose in
its seat after having plugged it;

8. screw the pump again and close the
door.

Frost precautions

If the machine is installed in a place where the
temperature could drop below 0°C, proceed
as follows:

1. close the water tap and unscrew the wa­ter inlet hose from the tap;

2. place the end of the emergency emptying
hose and that of the inlet hose in a bowl
placed on the floor and let water drain
out;

3. screw the water inlet hose back on and
reposition the emergency emptying hose
after having put the cap on again.

By doing this, any water remaining in the ma­chine is removed, avoiding ice forming and
consequently damage to the appliance.
When you use the machine again, make sure
that the ambient temperature is above 0°C.

What to do if…

Certain problems are due to lack of simple
maintenance or oversights, which can be
solved easily without calling out an engineer.
Before contacting your local Service Centre,
please carry out the checks listed below.
During machine operation it is possible that
the yellow pilot light of button 7 blinks, one
of the following alarm codes appears on the
display and at the same time some acoustic
signals sound every 20 seconds to indicate
that the machine is not working:

•

: problem with the water supply

•

: problem with the water draining

•

: door open

•

: anti-flooding system has activated

Once the problem has been eliminated,
press the button 7 to restart the programme.
If after all checks, the problem persists, con­tact your local Service Centre.

20 electrolux

Problem Possible cause/Solution

The washing machine does not start:

The machine does not fill:

The machine fills then empties immediately:

The machine does not empty and/or does not
spin:

The door has not been closed.

• Close the door firmly.
The plug is not properly inserted in the power
socket.

• Insert the plug into the power socket.
There is no power at the socket.

• Please check your domestic electrical installa­tion.

The main fuse has blown.

• Replace the fuse.

The selector dial is not correctly positioned and
the button 7 has not been depressed.

• Please turn the selector dial and press the but­ton 7 again.

The delay start has been selected.

• If the laundry is to be washed immediately,
cancel the delay start.

The Child Safety lock has been activated.

• Deactivate this device.

The water tap is closed.

• Open the water tap.

The inlet hose is squashed or kinked.

• Check the inlet hose connection.

The filter in the inlet hose or the inlet valve filter are
blocked .

• Clean the water inlet filters (see "Cleaning the
water inlet filters" for more details) .

The door is not properly closed.

• Close the door firmly .

The end of the drain hose is too low.

• Refer to relevant paragraph in «Water drain­age» section.

The drain hose is squashed or kinked.

• Check the drain hose connection.

The drain filter is clogged.

• Clean the drain filter.

An option or a programme that ends with the wa­ter still in the tub or a that eliminates all the spin­ning phases has been selected.

• Select the draining or the spinning programme.

The laundry is not evenly distributed in the drum.

• Redistribute the laundry.

Problem Possible cause/Solution

There is water on the floor:

Unsatisfactory washing results:

The door will not open:

The machine vibrates or is noisy:

electrolux 21

Too much detergent or unsuitable detergent (cre­ates too much foam) has been used.

• Reduce the detergent quantity or use another
one.

Check whether there are any leaks from one of
the inlet hose fittings. It is not always easy to see
this as the water runs down the hose; check to
see if it is damp.

• Check the water inlet hose connection.

The drain hose is damaged.

• Change it with a new one.

The cap on the emergency emptying hose has
not been replaced or the filter has not been prop­erly screwed in after cleaning action.

• Put the cap back on the emergency emptying
hose or screw the filter fully in.

Too little detergent or unsuitable detergent has
been used.

• Increase the detergent quantity or use another
one.

Stubborn stains have not been treated prior to
washing.

• Use commercial products to treat the stubborn
stains.

The correct temperature was not selected.

• Check if you have selected the correct tem­perature.

Excessive laundry load.

• Introduce into the drum less laundry.

The programme is still running.

• Wait the end of washing cycle.

The door lock has not been released.

• Wait until the door symbol 9.5 has gone off.

There is water in the drum.

• Select drain or spin programme to empty out
the water.

The transit bolts and packing have not been re­moved.

• Check the correct installation of the appliance.

The support feet have not been adjusted

• Check the correct levelling of the appliance.

The laundry is not evenly distributed in the drum.

• Redistribute the laundry.

Maybe there is very little laundry in the drum.

• Load more laundry.

22 electrolux

Problem Possible cause/Solution

Spinning starts late or the machine does not
spin:

The machine makes an unusual noise:

No water is visible in the drum:

The display shows the alarm code :

If you are unable to identify or solve the prob­lem, contact our service centre. Before tele­phoning, make a note of the model, serial
number and purchase date of your machine:
the Service Centre will require this informa­tion.

The electronic unbalance detection device has
cut in because the laundry is not evenly distrib­uted in the drum. The laundry is redistributed by
reverse rotation of the drum. This may happen
several times before the unbalance disappears
and normal spinning can resume. If, after some
minutes, the laundry is still not evenly distributed
in the drum, the machine will not spin.

• Redistribute the laundry.

The load is too small.

• Add more items, redistribute the load manually
and then select the spinning programme.

The machine is fitted with a type of motor which
makes an unusual noise compared with other
traditional motors. This new motor ensures a soft­er start and more even distribution of the laundry
in the drum when spinning, as well as increased
stability of the machine.

Machines based on modern technology operate
very economically using very little water without
affecting performance.

Anti-flooding system has activated.

• Pull out the plug from the power socket, close
the water tap and contact the Service Force
Centre.

Technical data

Dimensions Width

Electrical connection
Voltage - Overall power - Fuse

Water supply pressure Minimum

Maximum Load Cotton 8 kg

Height
Depth
Depth (Overall dimensions)

Information on the electrical connection is given on the rating plate,
on the inner edge of the appliance door.

Maximum

60 cm
85 cm
60 cm
63 cm

0,05 MPa
0,8 MPa

electrolux 23

Spin Speed Maximum 1600 rpm

Consumption values

Programme Energy consumption

White Cottons 95° 2.5 62

Cottons 60° 1.7 63

Cotton Energy Saving
Programme 60°

Cottons 40° 0.97 62

Synthetics 40° 0.55 51

Delicates 40° 0.53 68

Wool/ Handwash 30° 0.32 64

1) «Cotton Energy Saving programme » at 60°C with a load of 8 kg is the reference programme for the
data entered in the energy label, in compliance with EEC 92/75 standards.

1)

(KWh)

1.2 57

The consumption data shown on this chart is to be considered purely indicative, as it
may vary depending on the quantity and type of laundry, on the inlet water temperature
and on the ambient temperature.

Water consumption

(litres)

Programme duration

(Minutes)

For the duration of

the programmes,

please refer to the

display on the con-

trol panel.

Installation

Unpacking

All transit bolts and packing must be re­moved before using the appliance.
You are advised to keep all transit devices so
that they can be refitted if the machine ever
has to be transported again.

1. After removing all the packaging, carefully

lay machine on it’s back to remove the
polystyrene base from the bottom.

2. Remove the power supply cable and the
draining hose from the hose holders on
the rear of the appliance.

3. Unscrew the three bolts with the key sup­plied with the machine.

24 electrolux

4. Slide out the relevant plastic spacers.

5. Open the porthole, take out the inlet hose
from the drum and remove the polystyr­ene block fitted on the door seal.

plug caps supplied in the bag containing
the instruction booklet.

7. Connect the water inlet hose as descri­bed under the paragraph «Water inlet».

Positioning and levelling

Install the machine on a flat hard floor.
Make sure that air circulation around the ma­chine is not impeded by carpets, rugs etc.
Before placing it on small tiles, apply a rubber
coating.
Never try to correct any unevenness in the
floor by putting pieces of wood, cardboard
or similar materials under the machine.
If it is impossible to avoid positioning the ma­chine next to a gas cooker or coalburning
stove, an insulating panel covered with alu­minium foil on the side facing the cooker or
stove, must be inserted between the two ap­pliances.
The machine must not be installed in rooms
where the temperature can drop below 0°C.
The water inlet hose and the drain hose must
not be kinked.
Please ensure that when the appliance is in­stalled, it is easily accessible for the engineer
in the event of a breakdown.
Carefully level by screwing the adjustable feet
in or out. Never place cardboard, wood or
similar materials under the machine to com­pensate for any unevenness in the floor.

6. Fill the smaller upper hole and the two
large ones with the corresponding plastic

Water inlet

An inlet hose is supplied and can be found
inside the machine drum.

Caution! This appliance must be
connected to a cold water supply.
Do not use the hose from your pre­vious machine to connect to the wa­ter supply.

1. Open the porthole and extract the inlet
hose.

2. Connect the hose with the angled con­nection to the machine.

Caution! Do not place the inlet hose
downwards. Angle the hose to the
left or right depending on the
position of your water tap.

3. Set the hose correctly by loosening the
ring nut. After positioning the inlet hose,
be sure to tighten the ring nut again to
prevent leaks.

electrolux 25

4. Connect the hose to a tap with a 3/4”
thread. Always use the hose supplied
with the appliance.

The inlet hose must not be lengthened.
If it is too short and you do not wish to
move the tap, you will have to purchase
a new, longer hose specially designed
for this type of use.
Installation should comply with local wa­ter authority and building regulations re­quirements. Check the minimum water
pressure required for safe operation of
the appliance in the chapter "Technical
Data".

Water-stop device

The inlet hose is provided with a water stop
device, which protects against damage
caused by water leaks in the hose which
could develop due to natural ageing of the
hose. This fault is shown by a red sector in
the window «A» . Should this occur, turn the
water tap off and refer to your Service Centre
to replace the hose.

26 electrolux

Water drainage

The end of the drain hose can be positioned
in three ways:

1. Hooked over the edge of a sink using

the plastic hose guide supplied with
the machine.

In this case, make sure the end cannot
come unhooked when the machine is
emptying. This could be done by tying it

to the tap with a piece of string or attach­ing it to the wall.

2.

In a sink drain pipe branch. This
branch must be above the trap so that the
bend is at least 60 cm above the ground.

3. Directly into a drain pipe at a height
of not less than 60 cm and not more than
90 cm.

The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain
pipe must be larger than the outside diameter
of the drain hose. The drain hose must not
be kinked.

Important! The drain hose may be extended
to a maximum of 4 metres. An additional

Electrical connection

Information on the electrical connection is
given on the rating plate on the inner edge of
the appliance door.
Check that your domestic electrical installa­tion can take the maximum load required, al­so taking into account any other appliances
in use.

drain hose and joining piece is available from
your local Service Centre.

Connect the machine to an earthed
socket.

The manufacturer does not accept
any responsibility for damage or
injury through failure to comply with
the above safety precaution.

electrolux 27

The power supply cable must be
easily accessible after installing the
machine.

Environment concerns

The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.

Packaging materials

The materials marked with the symbol
recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene

are

Should the appliance power supply
cable need to be replaced, this must
be carried out by a Service Centre.

This means that they can be recycled by dis­posing of them properly in appropriate col­lection containers.

Ecological hints

To save water, energy and to help protect the
environment, we recommend that you follow
these tips:

• Normally soiled laundry may be washed

without prewashing in order to save deter­gent, water and time (the environment is
protected too!).

• The machine works more economically if it

is fully loaded.

• With adequate pre-treatment, stains and

limited soiling can be removed; the laundry
can then be washed at a lower tempera­ture.

• Measure out detergent according to the

water hardness, the degree of soiling and
the quantity of laundry being washed.

www.electrolux.com

electrolux.ch

132948860- 00 -062010
