AEG-Electrolux WAGLES7000 User Manual

User manual

Wasching machine

WAGLE S7000

3

Welcome to the world of Electrolux

Thank you for choosing a first class product from Electrolux, which hopefully will
provide you with lots of pleasure in the future. The Electrolux ambition is to offer a
wide variety of quality products that make your life more comfortable. You find some
examples on the cover in this manual. Please take a few minutes to study this manual
so that you can take advantage of the benefits of your new machine. We promise that
it will provide a superior User Experience delivering Ease-of-Mind. Good luck!

4

The following symbols are used in this manual:

Important information concerning your personal safety and information on how to
avoid damaging the appliance

General information and tips

Environmental information

Contents

Contents

Instruction for the user 8

Safety information 8-10

Product description 11

Detergent dispenser drawer 11

Control panel 12

First use 12

Personalization 13

Acoustic signals 13
Child safety lock 13

Daily use 14

Laod the laundry 14
Measure out the detergent and the fabric softener 14
Select the required programme 15
Select the spin speed or the Rinse Hold option 15
Programm option button 16
Select the Prewash option 16
Select the Stain option 16
Select the Sensitive option 16
Select the Time saving option 17
Display 17-18
Select the Start/Pause 18
Select the Delay Start 19
Programme progress display 20
Select an additional rinse 20
Altering an option or a running programme 20
Interrupting a programme 20
Cancelling a programme 21

5

Contents

6

Opening the door after the programme has started 21
At the end of the programme 21

Washing programmes 22-23

Programme informations 24

Preparing the wash cycle 25-29

Sorting out the laundry 25
Temperatures 25
Before loading the laundry 25
Maximum loads 26
Laundry weights 26
Removing stains 27
Detergents and additives 28
Quantity of detergent to be used 28
Degrees of water hardness 29

International wash code symbols 3

Care and cleaning 31-35

Descaling 31
After each wash 31
Maintenance wash 31
External cleaning 31
Detegent dispenser drawer 31
Washing drum 32
Door seal 32
Drain pump 33-34
Water inlet filter 34
Emergency emptying out 34-35
Frost precautions 35

Something not working 36-38

Techinical Data 40

Contents

Consumption value 41

Installation 42-46

Unpacking 42
Positioning and levelling 43
Water inlet 43-44
Water-stop device 44
Water drainage 44-45
Electrical connection 45
Permanent connection 45

Enviroment concerns 46

Packaging materials 46
Old machine 46
Ecological hints 46

Guarantee 47-48

7

Customer service centres 50

Safety information

8

Instruction for the user

Safety information

Prior to using for the first time

● The safety of ELECTROLUX appliances complies with the industry standards

and with legal requirements on the safety of appliances. However, as
manufacturers, we feel it is our duty to provide the following safety notes.
You MUST read them carefully before installing or using the appliance.

● It is most important that this instruction book should be retained with the

appliance for future reference. Should the appliance be sold or transferred to
another owner, or should you move house and leave the appliance, always
ensure that the book is supplied with the appliance in order that the new
owner can get to know the functioning of the appliance and the relevant
warnings.

● You MUST read them carefully before installing or using the appliance.

● Before first starting up, check the machine for any damage incurred during

transport. Never connect up a damaged machine. If parts are damaged,
contact your supplier.

● If the appliance is delivered in the winter months when there are minus

temperatures: Store the washing machine at room temperature for 24 hours
before using for the first time.

General safety

● It is dangerous to alter the specifications or attempt to modify this product in

any way.

● During high temperature wash programmes the door glass may get hot. Do

not touch it!

● Make sure that small pets do not climb into the drum. To avoid this, please

check into the drum before using.

● Any objects such as coins, safety pins, nails, screws, stones or any other hard,

sharp material can cause extensive damage and must not be placed into the
machine.

● Only use the advised quantities of fabric softener and detergent. Damage to

the fabric can ensue if you over-fill. Refer to the manufacturer’s
recommendations of quantities.

● Wash small items such as socks, laces, washable belts etc in a washing bag or

pillow case as it is possible for such items to slip down between the tub and
the inner drum.

● Do not use your washing machine to wash articles with whalebones, material

without hems or torn material.

● Always unplug the appliance and turn off the water supply after use, clean

and maintenance.

● Under no circumstances should you attempt to repair the machine yourself.

Repairs carried out by inexperienced persons may cause injury or serious
malfunctioning. Contact your local Service Centre. Always insist on genuine
spare parts.

Installation

● This appliance is designed for domestic use. It must not be used for purposes

other than those for which it was designed.

● When unpacking the appliance, check that it is not damaged. If in doubt, do

not use it and contact the Service Centre.

● All packing and transit bolts must be removed before use. Serious damage can

occur to the product and to property if this is not adhered to. See relevant
section in the user manual.

● After having installed the appliance, check that it is not pressing or standing on

its electrical supply cable, inlet hose and drain hose.

● If the machine is situated on a carpeted floor, please adjust the feet in order to

allow air to circulate freely

● Always be sure, that there is no water leakage from hoses and their connections

after the installation.

● If the appliance is installed in a location subject to frost, please read the

«dangers of freezing» chapter.

● Any plumbing work required to install this appliance should be carried out by a

qualified plumber or competent person.

● Any electrical work required to install this appliance should be carried out by a

qualified electrician or competent person.

Safety information

9

Use

● This appliance is designed for domestic use. It must not be used for purposes

other than those for which it was designed.

● Only wash fabrics which are designed to be machine washed. Follow the

instructions on each garment label.

Safety information

10

● Do not overload the appliance. See the relevant section in the user manual.

● Before washing, ensure that all pockets are empty and buttons and zips are

fastened. Avoid washing frayed or torn articles and treat stains such as paint,
ink, rust, and grass before washing. Underwired bras must NOT be machine
washed.

● Garments which have been in contact with volatile petroleum products should

not be machine washed. If volatile cleaning fluids are used, care should be
taken to ensure that the fluid is removed from the garment before placing in
the machine.

● Never pull the power supply cable to remove the plug from the socket; always

take hold of the plug itself.

● Never use the washing machine if the power supply cable, the control panel,

the working surface or the base are damaged so that the inside of the washing
machine is accessible.

Child Safety

● This appliance is not intended for use by person (including children) with

reduced physical sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

● Young children should be supervised to ensure that they do not play with the

appliance.

● The packaging components (e.g. plastic film, polystyrene) can be dangerous to

children - danger of suffocation! Keep them out of children’s reach.

● Keep all detergents in a safe place out

of children’s reach.

● Make sure that children or pets do not

climb into the drum. To avoid this the
machine incorporates special feature. To
activate this device, rotate the button
(without pressing it) inside the door
clockwise until the groove is horizontal.
If necessary use a coin. To disable this

device and restore the possibility of
closing the door, rotate the button anti-clockwise until the groove is vertical.

Product description

Product description

Your new appliance meets all modern requirements for effective treatment of
laundry with low water, energy and detergent consumption.

EECCOO vvaallvvee

The
consumption so saving energy.

system allows total use of detergent and reduces water

11

Detergent dispenser drawer

1

Control panel

2
3

Door opening handle

Detergent dispenser drawer

The prewash detergent is added at the beginning of the wash programme. The
stain remover is added during the STAIN-Action phase in the main wash.

Compartment for powder or liquid detergent used for main wash.
Compartment for liquid additives (fabric softener, starch).

Rating plate

4
5

Drain pump

6

Adjustable feet

Control panel

12

Control panel

1 2 3 4 5 6 7 8 9 10

1

Programme selector dial

2

Spin reduction button (U/MIN. ­Essorage)

«Prewash» button (Vorwasche

3

Prélavage)

4

«Stain» button (Flecken Taches)

5

«Sensitive» button (Sensitiv Peaux
sensibles)

6

«Time saving» button (Zeitsparen
Temps)

7

Display (Laufzeit Temps restant)
«Start/Pause» button (Start/Pause

8

Départ/Pause)

9

«Delay Start» button (Zeitvorwahl
Départ différé)

10

Programme progress display

First Use

Ensure that the electrical and water connections comply with the installation
instructions.

Remove the polystyrene block and any material from the drum.
Pour 2 litres of water into the main wash compartment of the detergent drawer

in order to activate the ECO valve. Then run a cotton cycle at maximum
temperature, without any laundry in the machine, to remove any manufacturing
residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser
drawer and start the machine.

Personalization

Acoustic signals

The machine is provided of an acoustic device, which sounds in the following
cases:

● at the end of the cycle

● in the event of operating problems

By pressing the «Prewash» and «Stain» buttons simultaneously for about 6
seconds, the acoustic signal is deactivated (except for the events of operating
problems). By pressing these 2 buttons again, the the acoustic signal is
reactivated.

Child safety lock

This device permits you to leave the appliance unsupervised without having the
worry that children might be injured by or cause damage to the appliance.

This function remains able also when the washing machine is not working.
There are two different ways to set this option:

● before pressing the «Start/Pause»: it will be impossible to start the machine.

● after pressing the «Start/Pause» it will be impossible to change any other

programme or option.

To enable (disable) this option press simoultaneously for about 6 seconds «Stain»
and «Sensitive» buttons until the icon appears (disappears) on (from) the
display.

Use

13

Use

14

Daily Use

Load the laundry

1. Open the door by carefully pulling the door
handle outwards. Place the laundry in the drum,
one item at a time, shaking them out as much
as possible.

2. Close firmly the door. You must hear a click
during closing.
Attention! Do not embed the laundry between the door and the rubber
joint.

Measure out the detergent and the fabric softener

Your new appliance was designed to reduce water, energy and detergent
consumption.

1. Pull out the dispenser drawer until it
stops. Measure out the amount of
detergent required, pour it into the main
wash compartment and, if you wish
to carry out the prewash phase or to
perform the stain function , pour it into
the compartment marked .

2. If required, pour fabric softener into the
compartment marked (the amount
used must not exceed the MAX mark in
the drawer). Close the drawer gently.

Select the required programme

You can choose the right programme for any type of laundry following the
descriptions on the washing programme tables (see Washing Programmes).

Turn the programme selector dial to the required programme. The programme
selector determines the type of washing cycle (e.g. water level, drum movement,
number of rinses) and the washing temperature according to the type of laundry.

The Start/Pause light starts to flash and the Display shows the duration of the
selected programme.

The selector dial can be turned either clockwise or anticlockwise. Position O (Aus

Arrêt) to Reset programme/Switching OFF of the machine.
At the end of the programme the selector dial must be turned to

position O (Aus Arrêt), to switch the machine off.
Attention!

If you turn the programme selector dial to another programme when the

machine is working, the Yellow Start/Pause pilot light will flash 3 times and the
message Err is displayed on the display to indicate a wrong selection. The
machine will not perform the new selected programme.

Select the spin speed or the rinse hold option

Press the Spin button repeatedly to change the spin speed, if you want your
laundry to be spun at a speed different from the one proposed by the washing
machine. The relevant light will light up. The maximum spin speed is 1200 rpm.

Use

15

For the maximum spin speed forseen for each programme consult the
chapter«Washing programmes».

Rinse Hold (Spülstopp/Anti-Froissage): by selecting this option the water of
the last rinse is not emptied out to prevent the fabrics from creasing. When the
programme has finished the display shows a

0 flashing, the pilot light Door

(Tür/Porte) illuminates, the Start/Pause and «Washing» (Waschen/Lavage) lights
go off and the door is blocked to indicate that the water must be emptied out.

To empty the water out:

● turn the programme selector dial to O

● select the Drain or Spin programme

● reduce the spin speed if needed, by means of the relevant button

● depress Start/Pause button

● when the programme has finished the display shows a 0 flashing. The pilot light

Door goes off and the door can be opened.

Use

16

Programme option button

Depending on the programme, different functions can be combined. These must
be selected after choosing the desired programme and before depressing the
Start/Pause button.

When these buttons are pressed, the corresponding pilot lights come on. When
they are pressed again, the pilot lights go out.

If an incorrect option is selected, the integrated yellow pilot light of the
Start/Pause button flashes for 3 times and the Err message appears on the
display for some seconds.

Important!

For the compatibility among the washing programmes and the options see
chapter Washing Porgrammes.

Select the Prewash option

Select this option if you wish your laundry to be prewashed at 30°C before the
main wash. The Prewash ends with a short spin in programmes for cotton and
synthetic fabrics, whereas in the programmes for delicate fabrics the water is
only drained.

The relevant light will light up.

Select the Stain option

Select this option to treat heavily soiled or stained laundry with stain remover
(extended main wash with time optimised stain action phase). The relevant light
will light up.

This option is not available with the «Prewash» and with a temperature lower
than 40°C.

Attention! If you wish to perform a programme with the stain option, pour
stain remover into compartment .

Select the Sensitive option

By depressing this button the washing intensity will be reduced. The machine
adds one rinse in the programmes for Cotton and Synthetics. The relevant light
will light up.

This option is recommended for non fast coloureds items.
This option is not available with the «Extra Rinse» (Extraspülen/Rinçage plus).

Select the Time Saving option

This option allows you to modify the washing time, automatically proposed by
the washing machine.

Daily: by pressing this button once, the relative pilot light comes on and the
washing duration will be reduced to wash daily soiled laundry. On the display will
be visualized the decreased washing time.

Super Quick: by pressing this button twice, the relative pilot light remains lit,
the washing duration will be reduced to wash lightly soiled laundry or items that
have been used or worn for a short time. On the display will be visualized the
decreased washing time.
We recommend you to reduce the maximum load up to 3 kg for cottons and to
1,5 kg for synthetics and delicates.

Display

The display shows the following information:

Duration of the selected programme

After selecting a programme, the duration is displayed in hours and minutes (for
example
automatically on the basis of the
maximum recommended load for each
type of fabric.

After the programme has started, the time
remaining is updated every minute.

2.05). The duration is calculated

Use

17

Delay

The selected delay (20 hours max) set by means of the relevant button appears
on the display for about 3 seconds, then the duration of the previously selected
programme is displayed.

The Delay Start icon will appear on the
display.

The delay time value decreases by one unit
every hour and then, when 1 hours
remain, the time decreases every minute.

Use

18

Incorrect option selection

If an option which is not compatible with
the set wash programme is selected, the
message Err is displayed for about 2
seconds and the yellow Start/Pause light
start flashing.

Alarm codes

In the event of operating problems, some
alarm codes can be displayed, for example

E20 (see paragraph «Something not

working»).

End of programme

When the programme has finished a
flashing zero is displayed, the «Door» pilot
light and the Start/Pause light go out and
the door can be opened.

Select the «Start/Pause»

To start the selected programme, press the Start/Pause button; the corresponding
red pilot light stops flashing.

The washing pilot light «Waschen/Lavage» is on to indicate that the appliance
starts operating.

The door pilot light «Tür/Porte» is on to indicate the door is locked.
To interrupt a programme which is running, depress the Start/Pause button: the

corresponding red pilot light starts to flash.
To restart the programme from the point at which it was interrupted, press the

Start/Pause button again.
If you have chosen a delayed start, the machine will begin the countdown.
If an incorrect option is selected, the yellow pilot light of the Start/Pause button

flashes for 3 times the message Err is displayed for about 2 seconds.

Select the Delay Start

Before you start the programme, if you wish to delay the start, press the
Delay Start button repeatedly, to select the desired delay.

The selected delay time value (up to 20 hours) will appear on the display for
about 3 seconds, then the duration of the programme will appear again.

You must select this option after you have set the programme and before you
press the Start/Pause button.

The wash programme can be delayed from 30 min - 60 min - 90 min, 2 hours
and then by 1 hour up to a maximum of 20 hours by means of this button.

If you wish to add laundry in the machine during the delay time, press
Start/Pause button to put the machine in pause, then wait until the «Door» pilot
light goes off before opening the door. Add the laundry, close the door and press
Start/Pause button again.

Selecting the delayed start.

● Select the programme and the required options.

● Select the delay start.

● Depress «Start/Pause» button: the machine starts its hourly countdown. The

programme will start after the selected delay has expired.

Cancelling the delayed start

● set the washing machine to PAUSE by pressing the Start/Pause button;

● depress Delay Start button once until the symbol 0’ is displayed.;

● press the Start/Pause button again to start the programme.

Important!

● The selected delay can be changed only after selecting the washing programme

again.

● The door will be locked throughout the delay time. If you need to open the

door, you must first set the washing machine to PAUSE by pressing the
Start/Pause button and then wait until the DOOR light goes off. After you
have closed the door, press the Start/Pause button again.

The Delay Start can not be selected with Drain programme

.

Use

19

Use

20

Programme progress display

After having pressed the Start/Pause button, the «washing» (Waschen/Lavage) pilot
lights comes on.

When the pilot light «washing» comes on this means that the machine is
performing the washing cycle.

The «Door» (Tür/Porte) pilot light indicates if the door can be opened:

● light on: the door cannot be opened. The appliance is running.

● light off: the door can be opened. The washing programme has finished.

When the appliance is performing additional rinses the Extra Rinse
(Extraspülen/Rinçage plus) pilot light comes on.

Select an additional rinse

This appliance is designed for saving water. However, for people with a very
delicate skin (allergic to detergents) it may be necessary to rinse the laundry
using an extra quantity of water (extra rinse).

Press simultaneously the Spin and Prewash buttons for some seconds: the
Extra Rinse pilot light comes on in the programme progress display. This func­tion stays permanently on. To remove it press the same buttons again until the
Extra Rinse light goes off.

Altering an option or a running programme

It is possible to change any option before the programme carries it out. Before
you make any change, you must pause the washing machine by pressing the
Start/Pause button.

Changing a running programme is possible only by resetting it. Turn the
programme selector dial to «O» and then to the new programme position. Start
the new programme by depressing the Start/Pause button again. The washing
water in the tub will not emptied out.

Interrupting a programme

Depress the Start/Pause button to interrupt a programme which is running, the
corresponding light starts to flash. Depress the button again to restart the
programme.

Cancelling a programme

Turn the selector dial to O to cancel a programme which is running. Now you
can select a new programme.

Opening the door after the programme has started

First set the machine to pause by pressing the Start/Pause button. If the «Door»
light goes off, the door can be opened.

If the «Door» light doesn’t go off and the door remains locked, this means that
the machine is already heating, that the water level is above the bottom edge of
the door. In this case the door can not be opened.

If you cannot open the door but you need to open it you have to switch the
machine off by turning the selector dial to O. After about some minutes the
door can be opened (pay attention to the water level and temperature!).

After closing the door, it is necessary to select the programme and the options
again and to press Start/Pause button.

At the end of the programme

The machine stops automatically, the Start/Pause light and the «Washing» light
go off and a flashing

If the Rinse Hold option have been selected, the «Door» pilot light illuminates, a
flashing
remains locked to indicate that the water must be emptied out before opening
the door.

To empty out the water please read the steps on the Rinse Hold option
paragraph.

Turn the programme selector dial to «O» to switch the machine off.
Remove the laundry from the drum and carefully check that the drum is empty.
If you do not intend to carry out another wash, close the water tap. Leave the

door open to prevent the formation of mildew and unpleasant smells.

0 will appear on the display, the Start/Pause light goes off and the door

0 will appear on the display. The buzzer sounds.

Use

21

Washing programmes

22

Washing programmes

PPrrooggrraammmmee//
TTeemmppeerraattuurree

Cottons (Koch­/Buntwäsche
Blanc couleurs)
95°-60°

Cottons (Koch­/Buntwäsche
Blanc couleurs)
60°-40°-30°

40-60 MIX
40°C

Synthetics
(Pflegeleicht
Synthétiques)

60°-50°-40°-30°

Synthetics
Easy Iron
(Leichtbügeln

Repassage facile
plus) 40°

Delicates
(Feinwäsche
Linge délicats)
40°-30°

TTyyppee ooff llaauunnddrryy OOppttiioonnss

White cotton heavily
soiled

Coloured cotton

normally soiled

Coloured cotton and
synthetics normally

soiled

Synthetic or mixed
fabrics

Synthetics to be gentle
washed and spun.

Delicate fabrics: for
example curtains

Spin speed/Rinse hold

Prewash, Stain, Sensitive

Time saving, Extra Rinse

Spin speed/Rinse hold

Prewash, Stain*,

Sensitive, Time saving,

Spin speed/Rinse hold

Prewash, Stain,

Sensitive, Extra Rinse

Spin speed/Rinse hold

Prewash, Stain*,

Sensitive, Time saving,

Spin speed/Rinse hold

Prewash, Extra Rinse

Spin speed/Rinse hold

Prewash, Stain*, Time

saving, Extra Rinse

Extra Rinse

Extra Rinse

DDeessccrriippttiioonn ooff

pprrooggrraammmmee

Main wash
Rinses
Long spin at the
maximum speed

Main wash
Rinses
Long spin at the
maximum speed

Main wash
Rinses
Long spin at the
maximum speed

Main wash
Rinses
Short spin

Main wash
Rinses
Short spin

Main wash
Rinses
Short spin

(Handwash)
Wool
(Wolle plus Laine
Plus)
40°- 30°- Cold

(Kalt Froid)

For hand washing
fabrics. and for wool
garments bearing the
«Pure new wool, non­shrink, machine
washable» label.

Spin speed/Rinse hold

Main wash
Rinses
Short spin

* Stain option can be selected only at the temperature of 40°C or higher.

**

If you select the SUPER QUICK option by means of TIME SAVING button, we rec­commend you, to reduce the maximum load as indicated. Full loading is possible
however with somewhat reduced cleaning results.

Washing programmes

Washing programmes

23

PPrrooggrraammmmee//
TTeemmppeerraattuurree

Delicate Rinses
(Feinspülen
Rinçages
délicats)

Drain
(Pumpen
Vidange)

Spin
(Schleudern
Essorage)

30 MIN.-3 Kg
Raifraîchir

30°

ECO
Energiesparen
Economique

60°

Off/O

TTyyppee ooff llaauunnddrryy OOppttiioonnss

Separate rinse cycle for
hand washed items.

For emptying out the
last rinse water in
programmes with the
Rinse Hold option.

Separate spin for cotton
fabric.

Quick wash for sport
items, or cotton and
synthetics items lightly
soiled or worn once.

White and fast
coloured cotton
economy, lightly-

mormally soiled items

For cancelling the programme which is running
or to switch the machine off.

Spin speed/Rinse hold

Extra Rinse

Spin speed

Spin speed

Spin speed/Rinse hold

Prewash, Stain,

Sensitive, Extra Rinse

DDeessccrriippttiioonn ooff

pprrooggrraammmmee

3 rinses
Short spin

Draining of water

Drain and long spin at
the maximum speed

Main wash
Rinses
Short spin

Main wash
Rinses
Long spin at the
maximum speed

Type of fabric Max. Load

Cottons and Energiesparen/Economique 6 kg

40-60 Mix 6 kg

Synthethics and Delicates 3 kg

40° Easy Iron 1 kg

Wool (Handwash) 2 kg

30 MIN.-3Kg 3 kg

Cotton + Super Quick option 3 kg

Synthethics/Delicates + Super Quick option 1.5 kg

Programme informations

24

Programme informations

Selecting this programme the laundry is gently washed

40° Easy Iron

and spun to avoid any creasing. In this way ironing is
easier. Furthermore the machine will perform additional
rinses.

Wool
(Handwash)

Delicate Rinses

Drain

Spin

30 MIN.-3KG

ECO

Washing programme for machine washable wool as
well as for hand washable woollens and delicate fabrics
with the “hand washing” care symbol .

With this programme it is possible to rinse and spin
garments which have been washed by hand.
The machine performs 3 rinses, followed by a final spin.
The spin speed can be reduced by depressing the Spin
Speed Reduction button.

For emptying out the water of the last rinse in
programmes with the Rinse Hold option.
Turn first the programme selector dial to O, then select
programme Drain and depress the Start/Pause button.

Separate spin for hand washed cotton garments and after
programmes with Rinse Hold option. Before selecting this
programme the selector dial must be turned to O. You can
choose the speed by means of the relevant button to
adapt it to the fabrics to be spun.

This programme can be selected with the following
options: Spin Speed Reduction and Delay Start. This pro­gramme must be used for slightly soiled cotton items.

This programme can be selected for slightly or normally
soiled cotton items. The temperature will decrease and the
washing time will be extended. This allows to obtain a
good washing efficiency by saving energy.

OFF/O

To reset a programme and to switch off the machine turn
the selector dial to O. Now can a new programme be
selected.

Preparing the wash cycle

Preparing the wash cycle

Sorting out the laundry

Follow the wash code symbols on each garment label and the manufacturer’s
washing instructions. Sort the laundry as follows: whites, coloureds, synthetics,
delicates, woollens.

Temperatures

25

95° or 90°

60°/50°

40°-30°- Cold

for normally soiled white cottons and linen (e.g. tea cloths,
towels, tablecloths, sheets...).

for normally soiled, colour fast garments (e.g. shirts, night

dresses, pyjamas....) in linen, cotton or synthetic fibres and

for lightly soiled white cotton (e.g. underwear).

for delicate items (e.g. net curtains), mixed laundry including
synthetic fibres and woollens bearing the label «pure new
wool, machine washable, non-shrink».

Before loading the laundry

Never wash whites and coloureds together. Whites may lose their “whiteness” in
the wash.

New coloured items may run in the first wash; they should therefore be washed
separately the first time.

Make sure that no metal objects are left in the laundry (e.g. hair clips,
safety pins, pins).

Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or
long tapes.

Remove persistent stains before washing.
Rub particularly soiled areas with a special detergent or detergent paste.
Treat curtains with special care. Remove hooks or tie them up in a bag or net.

Preparing the wash cycle

26

Maximum loads

Recommended loads are indicated in the washing programme charts.
General rules:

Cotton, linen: drum full but not too tightly packed;
Synthetics: drum no more than half full

;

Delicate fabrics and woollens: drum no more than one third full.
Washing a maximum load makes the most efficient use of water and energy.
For heavily soiled laundry, reduce the load size.
Washing a maximum load makes the most efficient use of water and energy. For

heavily soiled laundry, reduce the load size.

Laundry weights

The following weights are indicative:

bathrobe

1200 g

100 gnapkin
700 gquilt cover
500 gsheet
200 gpillow case
250 gtablecloth
200 gtowelling towel
100 gtea cloth
200 gnight dress
100 gladies’ briefs
600 gman’s work shirt
200 gman’s shirt
500 gman’s pyjamas
100 gblouse
100 gmen’s underpants

Preparing the wash cycle

Removing stains

Stubborn stains may not be removed by just water and detergent. It is therefore
advisable to treat them prior to washing.

Blood: treat fresh stains with cold water. For dried stains, soak overnight in
water with a special detergent then rub in the soap and water.

Oil based paint::moisten with benzine stain remover, lay the garment on a soft

cloth and dab the stain; treat several times.
Dried grease stains: moisten with turpentine, lay the garment on a soft

surface and dab the stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust removing product used cold. Be

careful with rust stains which are not recent since the cellulose structure will
already have been damaged and the fabric tends to hole.

Mould stains: treat with bleach, rinse well (whites and fast coloureds only).
Grass: soap lightly and treat with bleach (whites and fast coloureds only).
Ball point pen and glue: moisten with acetone (*), lay the garment on a soft

cloth and dab the stain.
Lipstick: moisten with acetone as above, then treat stains with methylated

spirits. Treat any residual marks with bleach.
Red wine: soak in water and detergent, rinse and treat with acetic or citric acid,

then rinse. Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the fabric first with acetone (*), then

with acetic acid; treat any residual marks on white fabrics with bleach and then
rinse thoroughly.

Tar stains: first treat with stain remover, methylated spirits or benzine, then rub
with detergent paste.

(*) do not use acetone on artificial silk.

27

Preparing the wash cycle

28

Detergents and additives

Good washing results also depend on the choice of detergent and use of the
correct quantities to avoid waste and protect the environment.

Although biodegradable, detergents contain substances which, in large
quantities, can upset the delicate balance of nature.

The choice of detergent will depend on the type of fabric (delicates, woollens,
cottons, etc.), the colour, washing temperature and degree of soiling.

All commonly available washing machine detergents may be used in this
appliance:

● powder detergents for all types of fabric,

● powder detergents for delicate fabrics (60°C max) and woollens,

● liquid detergents, preferably for low temperature wash programmes (60°C

max) for all types of fabric, or special for woollens only.

The detergent and any additives must be placed in the appropriate
compartments of the dispenser drawer before starting the wash programme.

If using concentrated powder or liquid detergents, a programme without

prewash must be selected.
The washing machine incorporates a recirculation system which allows an

optimal use of the concentrated detergent.
Pour liquid detergent into the dispenser drawer compartment marked just

before starting the programme.
Any fabric softener or starching additives must be poured into the compartment

marked before starting the wash programme.
Follow the product manufacturer’s recommendations on quantities to use and do

not exceed the «MAX» mark in the detergent dispenser drawer.

Quantity of detergent to be used

The type and quantity of detergent will depend on the type of fabric, load size,
degree of soiling and hardness of the water used.

Follow the product manufacturers’ instructions on quantities to use.
Use less detergent if:

• you are washing a small load,

• the laundry is lightly soiled,

• large amounts of foam form during washing.

Preparing the wash cycle

Degrees of water hardness

Water hardness is classified in so-called “degrees” of hardness. Information on
hardness of the water in your area can be obtained from the relevant water
supply company, or from your local authority.

Note: A water softener must be added when water has a medium-high degree
of hardness (from degree of hardness II). Follow the manufacturer’s instructions.
The quantity of detergent can then always be adjusted to degree of hardness I (=
soft).

DDeeggrreeeess ooff wwaatteerr hhaarrddnneessss

LLeevveell

1
2 medium
3 hard
4 very hard > 21 > 37

Characteristic

soft

GGeerrmmaann

°°ddHH

0-7 0-15

8-14 16-25

15-21 26-37

29

FFrreenncchh

°°TT..HH..

International wash code symbols

95

60

60

40

40

40

30

30

30

International wash code symbols

These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.

Energetic wash

Max. wash

temperature

95°C

Delicate wash

Bleaching Bleach in cold water Do not bleach

Ironing Hot iron

max 200°C

Max. wash

temperature

60°C

Max. wash

temperature

40°C

Warm iron

max 150°C

Max. wash

temperature

30°C

Lukewarm iron

max 110°C

Hand wash Do not

wash
at all

Do not iron

Dry cleaning Dry cleaning

Drying Flat On the line On clothes

in all solvents

Dry cleaning in

perchlorethylene,

petrol, pure alcohol,

R 111 & R 113

hanger

Dry cleaning

in petrol,

pure alcohol

and R 113

Tumble dry

high
temperature

low
temperature

Do not

dry clean

Do not

tumble dry

Care and cleaning

Care and cleaning

You must DISCONNECT the appliance from the electricity supply, before you can
carry out any cleaning or maintenance work.

Descaling

The water we use normally contains lime. It is a good idea to periodically use a
water softening powder in the machine. Do this separately from any laundry
washing, and according to the softening powder manufacturer's instructions.

This will help to prevent the formation of lime deposits.

After each wash

Leave the door open for a while. This helps to prevent mould and stagnant smells
forming inside the appliance. Keeping the door open after a wash will also help
to preserve the door seal.

Maintenance wash

With the use of low temperature washes it is possible to get a build up of
residues inside the drum.

We recommend that a maintenance wash be performed on a regular basis.
To run a maintenance wash:

• The drum should be empty of laundry.

• Select the hottest cotton wash programme.

• Use a normal measure of detergent, must be a powder with biological
properties

.

31

External cleaning

Clean the exterior cabinet of the appliance with soap and water only, and then
dry thoroughly.
Important: do not use methylated spirits, solvents or similar products to clean
the cabinet.

Detergent dispenser drawer

The detergent dispenser drawer should be
cleaned regularly.

1. Remove the detergent dispenser drawer
by pulling it firmly.

Care and cleaning

32

2. Remove the conditioner insert from the middle compartment.

3. Clean all parts with water.

4. Put the conditioner insert in as far as it will go, so that it is firmly in place.

5. Clean all parts of the washing ma-

chine, especially the nozzles in the top
of the washing-in chamber, with a
brush.

6. Insert the detergent dispenser drawer
in the guide rails and push it in.

Washing drum

Rust deposits in the drum may occur due to rusting foreign bodies in the
washing or tap water containing iron.

Important! Do not clean the drum with acidic descaling agents, scouring agents
containing chlorine or iron or steel wool.

1. Remove any rust deposits on the drum with a cleaning agent for stainless
steel.

2. Run a washing cycle without any washing to clean off any cleaning agent
residues. Programme: COTTONS 95, press the Super Quick button, add approx.
1/4 measuring cup of detergent.

Door seal

Check from time to time the door seal and eliminate
eventual possible objects that could be trapped in the
fold.

Drain pump

The pump should be inspected regularly and particularly if

• the machine does not empty and/or spin

• the machine makes an unusual noise during draining due to objects such as
safety pins, coins etc. blocking the pump.

Proceed as follows:

1. Disconnect the appliance.

2. If necessary wait until the water has

cooled down.

3. Open the pump door.

4. Place a container close to the pump to

collect any spillage.

Care and cleaning

33

5. Release the emergency emptying hose,
place it in the container and remove its
cap.

6. When no more water comes out,
unscrew the pump and remove it.
Always keep a rag nearby to dry up
spillage of water when removing the
pump.

7. Remove any objects from the pump
impeller by rotating it.

Care and cleaning

34

8. Put the cap back on the emergency
emptying hose and place the latter
back in its seat.

9. Screw the pump fully in.

10. Close the pump door.

Warning!

When the appliance is in use and
depending on the programme selected
there can be hot water in the pump. Never
remove the pump cover during a wash
cycle, always wait until the appliance has
finished the cycle, and is empty. When
replacing the cover, ensure it is securely retightened so as to stop leaks and
young children being able to remove it.

Water inlet filter

If you notice that the machine is taking longer
to fill, check that the filter in the water inlet
hose is not blocked.

1. Turn off the water tap.

2. Unscrew the hose from the tap.

3. Clean the filter in the hose with a stiff

brush.

4. Screw the hose back onto the tap.

Emergency emptying out

If the water is not discharged, proceed as follows to empty out the machine:

1. pull out the plug from the power socket;

2. close the water tap;

3. if necessary, wait until the water has cooled down;

4. open the the pump door;

5. place a bowl on the floor and place the end of the emergency emptying hose

into the bowl. Remove its cap. The water should drain by gravity into the
bowl. Whe the bowl is full, put the cap back on the hose. Empty the bowl.
Repeat the procedure until water stops flowing out;

Care and cleaning

6. clean the pump if necessary as previously described;

7. replace the emergency emptying hose in its seat after having plugged it;

8. screw the pump again and close the door.

Frost precautions

If the machine is installed in a place where the temperature could drop below
0°C, proceed as follows:

1. Close the water tap and unscrew the water inlet hose from the tap.

2. Place the end of the emergency emptying hose and that of the inlet hose in a

bowl placed on the floor and let water drain out.

3. Screw the water inlet hose back on and reposition the emergency emptying
hose after having put the cap on again

By doing this, any water remaining in the machine is removed, avoiding ice
forming and consequently damage to the appliance.

When you use the machine again, make sure that the ambient temperature is
above 0°C.

Important! Every time you drain the water through the emergency emptying
hose you must pour 2 litres of water into the main wash compartment of the
detergent drawer and then run the drain programme. This will activate the ECO
VALVE device avoiding that part of the detergent remains unused at next
washing.

.

35

Something not working

36

Something not working

Certain problems are due to lack of simple maintenance or oversights, which can be
solved easily without calling out an engineer. Before contacting your local Service Centre,
please carry out the checks listed below.

During machine operation it is possible that the yellow Start/Pause pilot light flashes, one of
the following alarm codes appears on the display and at the same some acoustic signals
sound every 20 seconds to indicate that the machine is not working:

• E10 : problem with the water supply

• E20 : problem with the water draining

• E40 : door open.

Once the problem has been eliminated, press the Start/Pause button to restart the
programme. If after all checks, the problem persists, contact your local Service Centre.

Problem Possible cause/Solution

The door has not been closed. E40

• Close firmly the door.
The plug is not properly inserted in the power socket.

• Insert the plug into the power socket.
There is no power at the socket.

• Please check your domestic electrical installation.
The main fuse has blown.

The washing machine does not
start:

• Replace the fuse.
The selector dial is not correctly positioned and the

Start/Pause button has not been depressed.

• Please turn the selector dial and press the

Start/Pause button again.

The delay start has been selected.

• If the laundry are to be washed immediately, cancel

the delay start.

The Child Lock has been selected.

• Deactive the Child Lock.

The machine does not fill:

The water tap is closed. E10

• Open the water tap.

The inlet hose is squashed or kinked.

• Check the inlet hose connection.

The filter in the inlet hose is blocked.

• Clean the water inlet hose filter.

The door is not properly closed.

• Close firmly the door.

E40

E10

E10

Something not working

Problem Possible cause/Solution

37

The machine fills then empties
immediately:

The machine does not empty
and/or does not spin:

There is water on the floor:

Unsatisfactory washing results:

The end of the drain hose is too low.

• Refer to relevant paragraph in «water drainage»

section.

The drain hose is squashed or kinked. E20

• Check the drain hose connection.

The drain pump is clogged.

• Clean the drain pump.

The option Rinse hold has been selected.

• Disable this option.

The laundry is not evenly distributed in the drum.

• Redistribute the laundry.

Too much detergent or unsuitable detergent (creates
too much foam) has been used.

• Reduce the detergent quantity or use another one.

Check whether there are any leaks from one of the
inlet hose fittings. It is not always easy to see this as
the water runs down the hose; check to see if it is
damp.

• Check the water inlet hose connection.

The drain hose is damaged.

• Change it with a new one.

The cap on the emergency emptying hose has not
been replaced after cleaning the pump.

• Put the cap back on the emergency emptying and

place the latter back in its seat.

Too little detergent or unsuitable detergent has been
used.

• Increase the detergent quantity or use another one.

Stubborn stains have not been treated prior to
washing.

• Use commercial products to treat the stubborn

stains

.

The correct temperature was not selected.

• Check if you have selected the correct temperature.

Excessive laundry load.

• Introduce into the drum less laundry.

E20

No water is visible in the drum:

Machines based on modern technology operate very
economically using very little water without affecting
performance.

Mod. ..........

Prod. No. ...........

Ser. No. .........

M
o
d

. ......

....

P
ro

d
.
N
o

. ..
...

......

S
e
r
. N

o
.
.

.

....

...

P0042 BD

Something not working

38

Problem Cause possible/Solution

The door will not open:

The machine vibrates or is noisy:

Spinning starts late or the machine
does not spin:

The machine makes an unusual
noise

The programme is still running.

• Wait the end of washing cycle.
The door lock has not been released.

• Wait until the «Door» light goes off.
There is water in the drum.

• Select drain or spin programme to empty out the
water.

The transit bolts and packing have not been removed.

• Check the correct installation of the appliance.

The support feet have not been adjusted

• Check the correct levelling of the appliance.

The laundry is not evenly distributed in the drum.

• Redistribute the laundry.

Maybe there is very little laundry in the drum.

• Load more laundry.

The electronic unbalance detection device has cut in
because the laundry is not evenly distributed in the
drum. The laundry is redistributed by reverse rotation
of the drum. This may happen several times before
the unbalance disappears and normal spinning can
resume. If, after some minutes, the laundry is still not
evenly distributed in the drum, the machine will not
spin.

• Redistribute the laundry.

The machine is fitted with a type of motor which
makes an unusual noise compared with other
traditional motors. This new motor ensures a softer
start and more even distribution of the laundry in the
drum when spinning, as well as increased stability of
the machine.

If you are unable to identify or solve the problem,
contact our service centre. Before telephoning,
make a note of the model, serial number and
purchase date of your machine: the Service Centre
will require this information.

Techinical Data

Technical data

39

Dimensions

Electrical connection Voltage ­Overall power - Fuse

Water supply pressure

Maximum Load

Spin Speed

Width
Height
Depth
(door included)

Information on the electrical connection is given on the rating
plate on the inner edge of the appliance door

Minimum
Maximum

Cotton 6 kg

Maximum 1200 rpm

60 cm
85 cm
63 cm

0,05 MPa
0,80 MPa

Consumption value

40

Consumption value

Programme

White Cottons 95°
Cottons 60°
Eco (*) 60°
Cottons 40°
Synthetics 60°
Delicates 40°
Wool (Handwash) 40°

Water consumption

(in litres)

61 2.0

58 1.3

49 1.02

58 0.7

54 1.0

60 0.55

53 0.25

Energy consumption

(in kWh)

Programme duration

The consumption data shown on this chart is to be considered purely indicative, as
it may vary depending on the quantity and type of laundry, on the inlet water
temperature and on the ambient temperature. It refers to the highest temperature
for each wash programme.

(*) «Cottons Eco» at 60°C with a load of 6 kg is the reference programme for the
data entered in the energy label, in compliance with EEC 92/75 standards.

(in minutes)

to the display on the

For the duration of the

programmes, please refer

control panel.

Installation

HEC0008

A

HEC00022

HEC0001

Unpacking

All transit bolts and packing must be removed before using the appliance.
You are advised to keep all transit devices so that they can be refitted if the

machine ever has to be transported again.

1. After removing all the packaging, carefully lay
machine on it’s back to remove the
polystyrene base from the bottom.

2. Remove the power supply cable and the
draining hose from the hose holders on the rear of the
appliance.

Installation

41

3. With the provided spanner unscrew and
remove the central rear bolt A.

Installation

C

C

B

D

HEC0003

B

C

C

HEC0023

E

HEC0010

HEC0005

42

4. Unscrew and remove the two large rear bolts B
and the six smaller bolts C.

5. Remove the bracket D and tighten up the six
smaller bolts C. Slide out the relevant plastic
spacer E.

6. Open the porthole, take out the inlet hose from the
drum and remove the polystyrene block fitted with the
adhesive tape on the door seal.

7. Fill the smaller upper hole and the two large ones with
the corresponding plastic plug caps supplied in the bag
containing the instruction booklet.

8. Connect the water inlet hose as described under the
paragraph «Water inlet».

All the different plug caps are supplied with the appliance in
the plastic bag containing the instruction booklet.

Installation

HEC007S

HEC0006

Positioning and levelling

Install the machine on a flat hard floor.
Make sure that air circulation around the machine is not impeded by carpets,

rugs etc.
Before placing it on small tiles, apply a rubber coating.
Never try to correct any unevenness in the floor by

putting pieces of wood, cardboard or similar
materials under the machine.

If it is impossible to avoid positioning the machine
next to a gas cooker or coal-burning stove, an
insulating panel covered with aluminium foil on the
side facing the cooker or stove, must be inserted
between the two appliances.

The machine must not be installed in rooms where
the temperature can drop below 0.

The water inlet hose and the drain hose must not be kinked.
Please ensure that when the appliance is installed, it is easily accessible for the

engineer in the event of a breakdown.
Carefully level by screwing the adjustable feet in or out. Never place cardboard,

wood or similar materials under the machine to compensate for any unevenness
in the floor.

43

Water inlet

An inlet hose is supplied and can be found inside the machine drum.

Do not use the already employed hoses to connect to the water supply.
This appliance must be connected to a cold water supply.

1. Open the porthole and extract the inlet hose.

2. Connect the hose with the angled connection to the machine.

Do not place the inlet hose downwards. Angle
the hose to the left or right depending on the
position of your water tap.

Installation

A

352

44

3. Set the hose correctly by loosening the ring nut.
After positioning the inlet hose, be sure to tighten
the ring nut again to prevent leaks.

4. Connect the hose to a tap with a 3/4” thread.
Always use the hose supplied with the appliance.

The inlet hose must not be lengthened. If it is too
short and you do not wish to move the tap, you
will have to purchase a new, longer hose specially
designed for this type of use.

Water-stop device

The inlet hose is provided with a water stop
device, which protects against damage caused by
water leaks in the hose which could develop due
to natural ageing of the hose. This fault is shown
by a red sector in the window “AA”. Should this
occur, turn the water tap off and refer to your
Service Centre to replace the hose.

Water drainage

The end of the drain hose can be positioned in three ways:

Hooked over the edge of a sink using the plastic hose guide supplied
with the machine.

In this case, make sure the end cannot come
unhooked when the machine is emptying.

This could be done by tying it to the tap with a piece
of string or attaching it to the wall.

In a sink drain pipe branch. This branch must be
above the trap so that the bend is at least 60 cm above
the ground.

Directly into a drain pipe at a height of not less
than 60 cm and not more than 90 cm.

The end of the drain hose must always be ventilated, i.e. the inside diameter of
the drain pipe must be larger than the outside diameter of the drain hose.

The drain hose must not be kinked.

Installation

P1118

Important!

The drain hose may be extended to a maximum of 4 metres. An additional drain
hose and joining piece is available from your local Service Centre.

Electrical connection

This machine is designed to operate on a 220-230 V, single-phase,
50 Hz supply.

Check that your domestic electrical installation can take the maximum load
required (2.2 kW), also taking into account any other appliances in use.

Connect the machine to an earthed socket.

45

The manufacturer does not accept any responsibility for damage or
injury through failure to comply with the above safety precaution.

Permanent connection

In the case of a permanent connection it is necessary that you install a double pole
switch between the appliance and the electricity supply (mains), with a minimum
gap of 3 mm between the switch contacts and of a type suitable for the required
load in compliance with the current electrical regulations.

The switch must not break the yellow and green earth cable at any point.
This operation must be performed by a qualified electrician.

The power supply cable must be easily accessible after installing the
machine.

Should the appliance power supply cable need to be replaced, this must
be carried out by a Service Centre.

Environment concerns

46

Enviroment concerns

Packaging materials

The materials marked with the symbol are recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of them properly in

appropriate collection containers.

Old machine

Use authorised disposal sites for your old appliance. Help to keep your country tidy!

The symbol on the product or on its packaging indicates that this product may
not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you purchased the
product.

Ecological hints

To save water, energy and to help protect the environment, we recommend that
you follow these tips:

• Normally soiled laundry may be washed without prewashing in order to save

detergent, water and time (the environment is protected too!).

• The machine works more economically if it is fully loaded.

• With adequate pre-treatment, stains and limited soiling can be removed; the

laundry can then be washed at a lower temperature.

• Measure out detergent according to the water hardness, the degree of soiling

and the quantity of laundry being washed.

Garantie/Kundendienst, Garantie/service-clientèle,
Garanzia/Servizio clienti, Guarantee/Customer
Service Centres

47

Servicestellen Points de Service Servizio dopo

vendita

5506 Mägenwil/Zürich
Industriestrasse 10

9000 St.
GallenZürcherstrasse
204 e

4127 Birsfelden
Hauptstrasse 52

6020 Emmenbrücke
Seetalstrasse 11

7000 Chur
Comercialstrasse 19

3018 Bern
Morgenstrasse 131

1028 Préverenges Le
Trési 6

Point of Service

6916 Grancia Zona
Industriale E

Ersatzteilverkauf/Points de vente de rechange/Vendita pezzi di ricambio/
spare parts service:

5506 Mägenwil, Industriestrasse 10, Tel. [phone]

Fachberatung/Verkauf/Demonstration/Vente/Consulente (cucina)/Vendita

8048 Zürich, Badenerstrasse 587, Tel. [phone]

Garantie

Für jedes Produkt gewähren wir ab Verkauf bzw. Lieferdatum an den
Endverbraucher eine Garantie von 2 Jahren. (Ausweis durch Garantieschein,
Faktura oder Verkaufsbeleg). Die Garantieleistung umfasst die Kosten für Material,
Arbeits- und Reisezeit. Die Garantieleistung entfällt bei Nichtbeachtung der
Gebrauchsanweisung und Betriebs-vorschriften, unsachgerechter Installation,
sowie bei Beschädigung durch äussere Einflüsse, höhere Gewalt, Eingriffe Dritter
und Verwendung von Nicht-Original Teilen.

Garantie

Nous octroyons sur chaque produit 2 ans de garantie à partir de la date de livraison
ou de la mise en service au consommateur (documenté au moyen d’une facture,

48

d’un bon de garantie ou d’un justificatif d’achat). Notre garantie couvre les frais
de mains d’œuvres et de déplacement, ainsi que les pièces de rechange.
Les conditions de garantie ne sont pas valables en cas d’intervention d’un tiers non
autorisé, de l’emploi de pièces de rechange non originales, d’erreurs de maniement
ou d’installation dues à l’inobser-vation du mode d’emploi, et pour des dommages
causés par des influences extérieures ou de force majeure.

Garanzia

Per ogni prodotto concediamo una garanzia di 2 anni a partire dalla data di
consegna o dalla sua messa in funzione. (fa stato la data della fattura, del certificato
di garanzia o dello scontrino d’acquisto) Nella garanzia sono comprese le spese di
manodopera, di viaggio e del materiale. Dalla copertura sono esclusi il logoramento
ed i danni causati da agenti esterni, intervento di terzi, utilizzo di ricambi non
originali o dalla inosservanza delle prescrizioni d’istallazione ed istruzioni per l’uso.

Warranty

For each product we provide a two-year guarantee from the date of purchase or
delivery to the consumer (with a guarantee certificate, invoice or sales receipt
serving as proof). The guarantee covers the costs of materials, labour and travel.
The guarantee will lapse if the operating instructions and conditions of use are not
adhered to, if the product is incorrectly installed, or in the event of damage caused
by external influences, force majeure, intervention by third parties or the use of
non-genuine components.

European Guarantee

European Guarantee

This appliance is guaranteed by Electrolux in each of the countries listed at the
back of this user manual, for the period specified in the appliance guarantee
orotherwise by law. If you move from one of these countries to another of the
countries listed, the appliance guarantee will move with you subject to the
following qualifications:

• The appliance guarantee starts from the date you first purchased the appliance

which will be evidenced by production of a valid purchase document issued by
the seller of the appliance.

• The appliance guarantee is for the same period and to the same extent for

labour and parts as exists in your new country of residence for this particular
model or range of appliances.

• The appliance guarantee is personal to the original purchaser of the appliance

and cannot be transferred to another user.

• The appliance is installed and used in accordance with instructions issued by

Electrolux and is only used within the home, i.e. is not used for commercial
purposes.

• The appliance is installed in accordance with all relevant regulations in force

within your new country of residence.
The provisions of this European Guarantee do not affect any of the rights

granted to you by law.

49

Customer service centres

50

www.electrolux.com

à

Albania
Belgique/België/Belgien
Česká republika
Danmark
Deutschland

Eesti
España
France
Great Britain
Hellas
Hrvatska
Ireland
Italia
Latvija
Lietuva
Luxembourg
Magyarország
Nederland
Norge
Österreich
Polska
Portugal
Romania
Schweiz-Suisse-Svizzera
Slovenija
Slovensko
Suomi
Sverige
Türkiye

Россия

 

[phone]
[phone]
[phone]
[phone]
[phone]

[phone]
[phone]

www.electrolux.fr
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
www.electrolux.fi
[phone]
[phone]
[phone]

Rr. Pjeter Bogdani Nr. 7 Tirane
Bergensesteenweg 719, 1502 Lembeek
Budějovická 3, Praha 4, 140 21
Sjællandsgade 2, 7000 Fredericia
Muggenhofer Str. 135, 90429 Nürnberg
Pärnu mnt. 153, 11624 - Tallinn
Carretera M-300, Km. 29,900 Alcalá de Henares Madrid

Addington Way, Luton, Bedfordshire LU4 9QQ
4, Limnou Str., 54627 Thessaloniki
Slavonska avenija 3, 10000 Zagreb
Longmile Road Dublin 12
C.so Lino Zanussi, 26 - 33080 Porcia (PN)
Kr. Barona iela 130/2, LV-1012, Riga
Ozo 10a, LT-08200 Vilnius
Rue de Bitbourg, 7, L-1273 Hamm
H-1142 Budapest XIV, Erzsébet királyné útja 87
Vennootsweg 1, 2404 CG - Alphen aan den Rijn
Risløkkvn. 2 , 0508 Oslo
Herziggasse 9, 1230 Wien
ul. Kolejowa 5/7, Warsaw
Quinta da Fonte - Edificio Gonçalves Zarco - Q35 -2774-518 Paço de Arcos
Str. Garii Progresului 2, S4, 040671 RO
Industriestrasse 10, CH-5506 Mägenwil
Gerbečeva ulica 98, 1000 Ljubljana
Electrolux Slovakia s.r.o., Electrolux Domáce spotrebiče SK, Seberíniho 1, 821 03 Bratislava

Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm
Tarlabași caddesi no : 35 Taksim Istanbul

129090 Москва, Олимпийский проспект, 16, БЦ «Олимпик»

www.electrolux.ch

ANC number: 132 968 830-00-412007
