AEG-Electrolux W80K User Manual
0402
Gebrauchsanweisung
Mode demploi
Instruzioni per luso
Operating instructions
Gebruiksaanwijzing
Instrucciones de manejo
Seite 4
Page 12
Pagina 19
Page 26
Pagina 35
Página 42
DE AT CH LU
FR BE
IT CH
GB
NL
ES
IE
CH LU
207.4887.01
TYP: 803 K
SIBIR
2
Fig 1
3
26
1. Warnings and directions
These warnings are provided in the interest of safety. You must read them
carefully before installing or using the appliance!
This product is designed to be operated by adults. Children should not be
allowed to tamper with the controls or play with the product.
Any electrical work required to install this appliance should be carried out by
a qualified electrician.
It is dangerous to alter the specifications or modify this product in any way.
The absorption refrigerator is designed to be used specifically for the storage
of edible foodstuffs and drinks only.
There are working parts in this product which heat up. Always ensure that
there is adequate ventilation as a failure to do this will result in component
failure and possible food loss (refer to relevant instructions for unit installation
under point 4.).
Before defrosting, cleaning or maintenance work is carried out, be sure to
switch off the appliance and unplug it. Shut down gas operation!
Manufacturers' food storage recommendations should be strictly adhered to.
Refer to relevant instructions for food and drink storage under point 13.
Under no circumstances should you attempt to repair the appliance yourself.
Repairs carried out by inexperienced persons may cause injury or more
serious malfunctioning. This product should be serviced by an authorised
Service Engineer, and only genuine spare parts should be used.
2. Area of use
The unit may not be installed in motor vehicles and boats when using the gas
operation method!
Operation using liquid gas in enclosed spaces in not permitted!
The room should have a capacity (length x width x height) of at least 20 m
3
and have a window (which can be opened) or a door to the outside.
Outdoor use includes tents (awnings) which are well ventilated throughout unit
operation and flat garden terraces.
There are no restrictions on electrical operation.
Site of operation must be protected from rain and other water sources.
GB
Dear customer,
please read the instruction book and all additional information
before using the appliance. It is most important that they should be
retained with the appliance for future reference!
27
3. Storage of gas cylinders
Liquid gas cylinders should never be stored in unventilated areas or below
ground (funnel-shaped holes). Avoid direct sunlight. The gas cylinder should not
be exposed to temperatures in excess of 50°C.
4. Installation
To be installed horizontally on a smooth, firm or any other appropriate surface.
If necessary, adjust/align using a spirit level or a water-filled vessel.
There should be a distance of at least 10cm between the back of the unit and
any other object (wall).
Avoid placing unit in direct sunlight and next to other sources of heat.
Ventilating ducts of the refrigerator should be kept clear of all obstructions to
ensure a good air circulation.
This will result in a good, energy-saving cooling system.
5. Cleaning
Before initial use and after defrosting or before prolonged periods of disuse,
clean the unit containers and door with luke-warm water and, if necessary,
washing-up liquid. Warning: do not inadvertently press or force the opened door
past its stop-point (this could cause the hinges to break). Never use scouring or
corrosive agents to clean the unit. Wipe cleaned surfaces dry with a soft cloth.
6. A/C operation
Do not use any additional form of energy (batteries/gas).
Check that the supply voltage and line voltage data correspond to the type-plate
in the unit.
(The following instructions refer in the main to coolers manufactured for the
United Kingdom).
The mains lead of your refrigerator is fitted with a non-rewirable moulded-on 13
amp plug containing a 3 amp fuse. It is a regular earthed plug for connection to
a regular earthed socket.
Due to the difference in the plugs used, an adapter will be necessary for other
countries.
If the fuse requires replacing at any time, the fuse cover/carrier should be
removed using a small screwdriver to lever it out. The old fuse should be
replaced by a 3 amp ASTA approved BS 1362 fuse and the fuse cover/carrier
must be refitted before the plug is used again.
If the fuse cover/carrier is lost, a replacement can be obtained from the service
shops. The fuse cover/carrier must be of the same colour as that of the coloured
GB
