AEG-Electrolux TC 152 User Manual
SV/E/14. (06.)
FR
DE
IT
GB
200380443
KÜHLSCHRANK - RÉFRIGÉRATEUR - FRIGORIFERO - REFRIGERATOR
GEBRAUCHSANLEITUNG - MODE D`EMPLOI -
LIBRETTO D’ISTRUZIONI - INSTRUCTION BOOK
TC 152
45
Before installing and using the appliance read this user's instruction book carefully. It contains safety
precautions, hints, information and ideas. If the refrigerator is used in compliance with the
instructions written, it will operate properly and provide you with greatest satisfaction.
The symbols below help you to find things more easily:
Safety precautions
Warnings and information at this symbol serve safety for you and your appliance.
Hints, useful information
Environmental information
Symbol for ideas
At this symbol ideas can be found according to food and its storing.
The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product, please contact your
local city office, your household waste disposal service or the shop where you purchased the
product.
GB
46
GB
Cont
Cont
ents
ents
Important safety information ..................................................................................................47
General safety precautions ....................................................................................................47
Precautions for child safety....................................................................................................47
Safety precautions for installation............................................................................................47
Safety precautions for isobutane.............................................................................................47
Instructions for the User.........................................................................................................48
General information..............................................................................................................48
Description of the appliance, main parts ..................................................................................48
Instructions for the Installer....................................................................................................49
Technical data .....................................................................................................................49
Transportation, unpacking.................................................................................................49
Cleaning ........................................................................................................................49
Placement ......................................................................................................................50
Putting it into use .............................................................................................................51
Controlling the temperature, setting ....................................................................................51
Hints for storage ..............................................................................................................51
Storage time and temperature of foods ..............................................................................52
How to use the four-star frozen food compartment................................................................52
Some useful information and advice........................................................................................52
Hints and ideas ...................................................................................................................52
How to save energy .........................................................................................................52
The appliance and environment .........................................................................................52
Maintenance .......................................................................................................................53
Defrosting ......................................................................................................................53
Regular cleaning .............................................................................................................54
When the refrigerator is not in use......................................................................................54
Trouble shooting ..................................................................................................................54
How to change the bulb ...................................................................................................54
If something does not work ...............................................................................................55
Electrical connection........................................................................................................57
Storage time chart (1)............................................................................................................57
Storage time chart (2) ...........................................................................................................58
Warranty and service .............................................................................................................59
Guarantee conditions ...........................................................................................................59
Service and spare parts........................................................................................................59
47
GB
Im
Im
por
portt
ant saf
ant saf
et
et
y inf
y inf
ormation
ormation
General safety precautions
Keep these instructions and they should remain at
the appliance when moving away or changing
owner.
This appliance is designed for storing food,
domestic use and being used according to these
instructions only.
Specialised companies that are qualified to do so
by the manufacturer must carry out service and
repairs including repairing and changing the
power cord. Accessory parts supplied by them
should be used only for repairing. Otherwise the
appliance can be damaged or can cause other
damage or injury.
The appliance is out of circuit only in that case if
the plug is removed from the socket. Before
cleaning and maintenance always unplug it (do
not get it by the cable). If the socket is difficult to
reach, switch off the appliance by cutting off the
current.
Power cord must not be lengthened.
Make sure that the power plug is not
squashed or damaged by the back of the
fridge/freezer.
- A damaged power plug may overheat and cause
a fire.
Do not place heavy articles or the
fridge/freezer itself on the power cord.
- There is a risk of a short circuit and fire.
Do not remove the power cord by pulling on
its lead, particularly when the fridge/freezer
is being pulled out of its niche.
- Damage to the cord may cause a short-circuit,
fire and/or electric shock.
- If the power cord is damaged, it must be
replaced by a certified service agent or qualified
service personnel.
If the power plug socket is loose, do not
insert the power plug.
- There is a risk of electric shock or fire.
Without the lamp cover of interior lighting you
must not operate the appliance.
When cleaning, do not use sharp, pointed or hard
devices, as they can cause damage to the
appliance.
Be careful not to allow liquids to the temperature
control and lighting box.
Do not put hot pot to the plastic parts.
Do not store flammable gas and liquid in the
appliance, because they may explode.
Check and clean the outlet of melting water
coming during defrosting regularly - a label inside
the appliance warns you for this. If it is clogged
the melting water gathered can cause earlier
failure.
Precautions for child safety
Do not allow children to play with the packaging of
the appliance. Plastic foil can cause suffocation.
Adults must handle the appliance. Do not allow
children to play with it or its controlling parts.
If you are discarding the appliance pull the plug
out of the socket, cut the connection cable (as
close to the appliance as you can) and remove
the door to prevent playing children to suffer
electric shock or to close themselves into it.
Safety precautions for
installation
Put the appliance to the wall to avoid touching or
catching warm parts (compressor, condenser) to
prevent possible burn.
When moving the appliance take care of the plug
not to be in the socket.
When placing the appliance take care not to
stand it on the power cord.
Adequate air circulation should be around the
appliance, lacking this leads to overheating. To
achieve sufficient ventilation follow the
instructions relevant to installation.
Safety precautions for isobutane
Warning
The refrigerant of the appliance is isobutane
(R600a) that is inflammable and explosive to a
greater extent.
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than
those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
For the safety of life and property keep the
precautions of these user's instructions as
the manufacturer is not responsible for
damages caused by omission.
48
GB
Ins
Instrtr
uctions f
uctions f
or the User
or the User
General information
The official designation of the appliance is home
refrigerator with a four-star frozen food compartment.
According to this the appliance is suitable for storing
frozen and deep-frozen food, freezing products in
limited quantity at home and making ice.
The appliance can meet the requirements of
standards between different temperature limits
according to the climate class.
The letter symbol for class of climate can be found
on the data label.
Description of the appliance, main parts
1. Glass shelf
2. Defrost water outlet
3. Vegetable box
4. Data label
5. Adjustable feet
6. Butter compartment
7. Lighting box
8. Door shelf
9. Gasket
10. Bottle shelf
11. Egg tray
12. Air circulation
13. Air grid
14. Condenser
15. Evaporative tray
16. Compressor
49
GB
Ins
Instrtr
uctions f
uctions f
or the Ins
or the Instt
aller
aller
Transportation, unpacking
It is recommended to deliver the appliance in original
packaging, in vertical position considering the
protective warning on packaging.
After each transportation the appliance must not be
switched on for approx. 2 hours.
Unpack the appliance and check if there are damages
on it. Report possible damages immediately to the
place you bought it. In that case retain packaging.
Cleaning
Remove every adhesive tape, which ensure the parts
not to move in the appliance.
Wash the inside of the appliance using lukewarm
water and mild detergent. Use soft cloth.
After cleaning wipe out the inside of the appliance.
Technical data
Model
Gross capacity (l)
Net capacity (l)
Width (mm)
Height (mm)
Depth (mm)
Energy consumption (kWh/24h)
(kWh/year)
Energy class, according to EU standards
Rated current (A)
Noise Lc (dB)
Weight (kg)
TC 152
Fresh food comp.: 155
Fresh food comp.: 152
595
850
635
0,326
119
A+
0,55
38
38
