AEG-Electrolux SKS81240F0 User Manual

SKS81240F0

REFRIGERATOR USER MANUAL 2

EN

FRIGORIFERO ISTRUZIONI PER L’USO 19

IT

KJØLESKAP BRUKSANVISNING 37

NO

FRIGORÍFICO MANUAL DE INSTRUCCIONES 54

ES

2

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get
the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of
accessories designed and built to the high quality
standards you would expect, from specialist cookware
to cutlery baskets, from bottle holders to delicate
laundry bags…

Visit the webshop at:
www.aeg-electrolux.com/shop

CONTENTS

Contents

4 Safety information
6 Control panel

9First use
10 Daily use
12 Helpful hints and tips
13 Care and cleaning
15 What to do if…
17 Technical data
17 Installation
18 Environmental concerns

3

The following symbols are used in this
user manual:

Important information concerning
your personal safety and information
on how to avoid damaging the
appliance.

General information and tips

Environmental information

Subject to change without notice

Safety information

4

SAFETY INFORMATION

In the interest of your safety and to ensure the correct use, before installing and first
using the appliance, read this user manual carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents, it is important to ensure that all people using
the appliance are thoroughly familiar with its operation and safety features. Save these
instructions and make sure that they remain with the appliance if it is moved or sold, so
that everyone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by omission.

Children and vulnerable people safety

• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

• Keep all packaging well away from children. There is risk of suffocation.

• If you are discarding the appliance pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent playing
children to suffer electric shock or to close themselves into it.

• If this appliance featuring magnetic door seals is to replace an older appliance having
a spring lock (latch) on the door or lid, be sure to make that spring lock unusable be­fore you discard the old appliance. This will prevent it from becoming a death trap for
a child.

General safety

CAUTION!

Keep ventilation openings clear of obstruction.

• The appliance is intended for keeping foodstuff and/or beverages in a normal house­hold as explained in this instruction booklet.

• Do not use a mechanical device or any artificial means to speed up the thawing process.

• Do not use other electrical appliances (such as ice cream makers) inside of refrigerat­ing appliances, unless they are approved for this purpose by the manufacturer.

• Do not damage the refrigerant circuit.

• The refrigerant isobutane (R600a) is contained within the refrigerant circuit of the ap­pliance, a natural gas with a high level of environmental compatibility, which is never­theless flammable.

During transportation and installation of the appliance, be certain that none of the
components of the refrigerant circuit become damaged.

If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the appliance is situated

Safety information

• It is dangerous to alter the specifications or modify this product in any way. Any dam­age to the cord may cause a short-circuit, fire and/or electric shock.

WARNING!

Any electrical component (power cord, plug, compressor) must be replaced by a certified
service agent or qualified service personnel.

1. Power cord must not be lengthened.

2. Make sure that the power plug is not squashed or damaged by the back of the

appliance. A squashed or damaged power plug may overheat and cause a fire.

3. Make sure that you can come to the mains plug of the appliance.

4. Do not pull the mains cable.

5. If the power plug socket is loose, do not insert the power plug. There is a risk of

electric shock or fire.

6.

You must not operate the appliance without the lamp cover

1)

of interior lighting.

• This appliance is heavy. Care should be taken when moving it.

• Do not remove nor touch items from the freezer compartment if your hands are damp/
wet, as this could cause skin abrasions or frost/freezer burns.

• Avoid prolonged exposure of the appliance to direct sunlight.

•

Bulb lamps

2)

used in this appliance are special purpose lamps selected for household

appliances use only. They are not suitable for household room illumination.

Daily use

• Do not put hot pot on the plastic parts in the appliance.

• Do not store flammable gas and liquid in the appliance, because they may explode.

• Appliance's manufacturers storage recommendations should be strictly adhered to. Re­fer to relevant instructions.

5

Care and cleaning

• Before maintenance, switch off the appliance and disconnect the mains plug from the
mains socket.

• Do not clean the appliance with metal objects.

• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean
the drain. If the drain is blocked, water will collect in the bottom of the appliance.

Installation

For electrical connection carefully follow the instructions given in specific paragraphs.

• Unpack the appliance and check if there are damages on it. Do not connect the appli­ance if it is damaged. Report possible damages immediately to the place you bought
it. In that case retain packing.

• It is advisable to wait at least four hours before connecting the appliance to allow the
oil to flow back in the compressor.

1) If the lamp cover is foreseen.

2) If the lamp is foreseen.

Control panel

6

• Adequate air circulation should be around the appliance, lacking this leads to overheat­ing. To achieve sufficient ventilation follow the instructions relevant to installation.

• Wherever possible the back of the product should be against a wall to avoid touching
or catching warm parts (compressor, condenser) to prevent possible burn.

• The appliance must not be located close to radiators or cookers.

• Make sure that the mains plug is accessible after the installation of the appliance.

•

Connect to potable water supply only.

3)

Service

• Any electrical work required to do the servicing of the appliance should be carried out
by a qualified electrician or competent person.

• This product must be serviced by an authorized Service Centre, and only genuine spare
parts must be used.

Environment Protection

This appliance does not contain gasses which could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The appliance shall not be discarded together
with the urban refuse and rubbish. The insulation foam contains flammable gases: the
appliance shall be disposed according to the applicable regulations to obtain from your
local authorities. Avoid damaging the cooling unit, especially at the rear near the heat
exchanger. The materials used on this appliance marked by the symbol

are recyclable.

CONTROL PANEL

1 2 3 4 5 6

1 ON/OFF button
2 Mode button
3 OK button
4 Temperature colder button
5 Temperature warmer button

6 Display

It is possible to change predefined sound of buttons to a loudly one by pressing together
Mode button and Temperature colder button for some seconds. Change is reversible.

3) If a water connection is foreseen.

Display

7

COOL
MATIC

FROST
MATIC

5

62 431

1 Timer function

2 COOLMATIC function

3 Minute Minder function

4 Child Lock function

5 Alarm indicator

6 Temperature indicator

7 FROSTMATIC function

Switching on

To switch on the appliance do these steps:

1. Connect the mains plug to the power socket.

2. Press the appliance ON/OFF button if the display is off.

3. The alarm buzzer could operate after few seconds.

To reset the alarm refer to "High temperature alarm".

4. The temperature indicators show the set default temperature.
To select a different set temperature refer to "Temperature regulation".

Control panel

7

Switching off

To switch off the appliance do these steps:

1. Press the appliance ON/OFF button for 5 seconds.

2. The display switches off.

3. To disconnect the appliance from the power disconnect the mains plug from the pow-

er socket.

Temperature regulation

The set temperature of the fridge may be adjusted by pressing the temperature button.
Set default temperature:

• +5°C for the fridge
The temperature indicator shows the set temperature.
The set temperature will be reached within 24 hours.

After a power failure the set temperature remains stored.

Minute Minder function

The Minute Minder function is to be used to set an acoustic alarm at the preferred time,
useful for example when a recipe requires to cool down a mixture for a certain lenght of

Control panel

8

time, or when a reminder is needed in order not to forget the bottles pleaced in the freez­er for fast cooling.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The Minute Minder indicator flashes.
The Timer shows the set value (30 minutes) for a few seconds.

2. Press the Timer regulator button to change the Timer set value from 1 to 90 minutes.

3. Press the OK button to confirm.

The Minute Minder indicator is shown.

The Timer start to flash (min).
At the end of the countdown the Minute Minder indicator flashes and an audible alarm
sounds:

1. Remove any drinks contained in the freezer compartment.

2. Switch off the function.
To switch off the function:

1. Press the Mode button until the Minute Minder indicator flashes.

2. Press the OK button to confirm.

3. The Minute Minder indicator goes off.
It is possible to deactivate the function at any time.
It is possible to change the time at any time and before the end by pressing the Tempera­ture colder button and the Temperature warmer button.

Child Lock function

To lock the buttons from unintentional operation select the Child Lock function.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

2. The Child Lock indicator flashes.

3. Press the OK button to confirm.

The Child Lock indicator is shown.
To switch off the function:

1. Press the Mode button until the Child Lock indicator flashes.

2. Press the OK button to confirm.

3. The Child Lock indicator goes off.

Door open alarm

An acoustic alarm will sound if the door is left open for a few minutes. The door open
alarm conditions are indicated by:

• flashing Alarm light

• acoustic buzzer
When normal conditions are restored (door closed), the alarm will stop.
During the alarm, the buzzer can be switched off by pressing alarm button.

First use

COOLMATIC function

If you need to insert a large amount of warm food, for example after doing the grocery
shopping, we suggest activating the COOLMATIC function to chill the products more rap­idly and to avoid warming the other food which is already in the refrigerator.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The COOLMATIC indicator flashes.

The fridge temperature indicator shows the set temperature.

2. Press the OK button to confirm.

The COOLMATIC indicator is shown.
The COOLMATIC function shuts off automatically after approximately 6 hours.
To switch off the function before its automatic end:

1. Press the Mode button until the COOLMATIC indicator flashes.

2. Press the OK button to confirm.

3. The COOLMATIC indicator goes off.
The function switches off by selecting a different fridge set temperature.

FROSTMATIC function

It is possible to place the fresh food to be frozen in all compartments except the lowest.
To switch on the function:

1. Press the Mode button until the corresponding icon appears.

The FROSTMATIC indicator flashes.

The freezer temperature indicator shows

2. Press the OK button to confirm.

The FROSTMATIC indicator is shown.

An animation starts.
This function stops automatically after 52 hours.
To switch off the function before its automatic end:

1. Press the Mode button until the FROSTMATIC indicator flashes.

2. Press the OK button to confirm.

3. The FROSTMATIC indicator goes off.
The function switches off by selecting a different freezer set temperature.

symbol.

9

FIRST USE

Cleaning the interior

Before using the appliance for the first time, wash the interior and all internal accesso­ries with lukewarm water and some neutral soap so as to remove the typical smell of a
brand-new product, then dry thoroughly.

Daily use

10

Do not use detergents or abrasive powders, as these will damage the finish.

DAILY USE

Freezing fresh food

The freezer compartment is suitable for freezing fresh food and storing frozen and deep­frozen food for a long time.
To freeze fresh food activate the FROSTMATIC function at least 24 hours before placing
the food to be frozen in the freezer compartment.
The maximum amount of food that can be frozen in 24 hours is specified on the rating

4)

plate .
The freezing process lasts 24 hours: during this period do not add other food to be frozen.

Storage of frozen food

When first starting-up or after a period out of use, before putting the products in the
compartment let the appliance run at least 2 hours on the higher settings.

In the event of accidental defrosting, for example due to a power failure, if the power
has been off for longer than the value shown in the technical characteristics chart under
"rising time", the defrosted food must be consumed quickly or cooked immediately and
then re-frozen (after cooling).

Thawing

Deep-frozen or frozen food, prior to being used, can be thawed in the refrigerator com­partment or at room temperature, depending on the time available for this operation.
Small pieces may even be cooked still frozen, directly from the freezer: in this case, cook­ing will take longer.

Frozen Food Calendar

The symbols show different types of frozen goods.
The numbers indicate storage times in months for the appropriate types of frozen goods.
Whether the upper or lower value of the indicated storage time is valid depends on the
quality of the foods and treating before freezing.

this appliance is sold in France.
In accordance with regulations valid in this country it must be provided with a special
device (see figure) placed in the lower compartment of the fridge to indicate the coldest
zone of it.

4) Refer to "Technical data".

Movable shelves

The walls of the refrigerator are equipped with a
series of runners so that the shelves can be posi­tioned as desired.
For better use of space, the front half-shelves
can lie over the rear ones.

Daily use

11

Positioning the door shelves

To permit storage of food packages of various sizes, the door shelves can be placed at
different heights.

Positioning the sliding box

The sliding box can be placed at different heights.
To make these adjustments proceed as follow:

1. lift the shelf with the sliding box up-

wards and out of the holders in the door

2. remove the retaining bracket out of the

guide under the shelf

3. Reverse the above operation to insert

the sliding box at a different height.

Helpful hints and tips

12

HELPFUL HINTS AND TIPS

Hints for energy saving

• Do not open the door frequently or leave it open longer than absolutely necessary.

• If the ambient temperature is high and the Temperature Regulator is set to low tem-

perature and the appliance is fully loaded, the compressor may run continuously, caus­ing frost or ice on the evaporator. If this happens, set the Temperature Regulator to­ward warmer settings to allow automatic defrosting and so a saving in electricity con­sumption.

Hints for fresh food refrigeration

To obtain the best performance:

• do not store warm food or evaporating liquids in the refrigerator

• do cover or wrap the food, particularly if it has a strong flavour

• position food so that air can circulate freely around it

Hints for refrigeration

Useful hints:
Meat (all types) : wrap in polythene bags and place on the glass shelf above the vegeta­ble drawer.
For safety, store in this way only one or two days at the most.
Cooked foods, cold dishes, etc..: these should be covered and may be placed on any shelf.
Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw­er(s) provided.
Butter and cheese: these should be placed in special airtight containers or wrapped in
aluminium foil or polythene bags to exclude as much air as possible.
Milk bottles: these should have a cap and should be stored in the bottle rack on the door.
Bananas, potatoes, onions and garlic, if not packed, must not be kept in the refrigerator.

Hints for freezing

To help you make the most of the freezing process, here are some important hints:

• To freeze the maximum quantity shown on the rating plate press the FROSTMATIC

switch 24 hours prior to freezing, or 4 to 6 hours for smaller quantities. The light will
light up .

• The FROSTMATIC switch not need not be pressed for freezing of small quantities.

• only freeze top quality, fresh and thoroughly cleaned, foodstuffs;

• prepare food in small portions to enable it to be rapidly and completely frozen and to

make it possible subsequently to thaw only the quantity required;

• wrap up the food in aluminium foil or polythene and make sure that the packages are

airtight;

• do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding

a rise in temperature of the latter;

• lean foods store better and longer than fatty ones; salt reduces the storage life of food;

Care and cleaning

• water ices, if consumed immediately after removal from the freezer compartment, can

possibly cause the skin to be freeze burnt;

• it is advisable to show the freezing in date on each individual pack to enable you to

keep tab of the storage time.

Hints for storage of frozen food

To obtain the best performance from this appliance, you should:

• make sure that the commercially frozen foodstuffs were adequately stored by the re-

tailer;

• be sure that frozen foodstuffs are transferred from the foodstore to the freezer in the

shortest possible time;

• not open the door frequently or leave it open longer than absolutely necessary.

• Once defrosted, food deteriorates rapidly and cannot be refrozen.

• Do not exceed the storage period indicated by the food manufacturer.

CARE AND CLEANING

CAUTION!

Unplug the appliance before carrying out any maintenance operation.

This appliance contains hydrocarbons in its cooling unit; maintenance and recharging
must therefore only be carried out by authorized technicians.

13

Periodic cleaning

The equipment has to be cleaned regularly:

• clean the inside and accessories with lukewarm water and some neutral soap.

• regularly check the door seals and wipe clean to ensure they are clean and free from

debris.

• rinse and dry thoroughly.
Do not pull, move or damage any pipes and/or cables inside the cabinet.

Never use detergents, abrasive powders, highly perfumed cleaning products or wax pol­ishes to clean the interior as this will damage the surface and leave a strong odour.

Clean the condenser (black grill) and the compressor at the back of the appliance with a
brush or a vacuum cleaner. This operation will improve the performance of the appliance
and save electricity consumption.

Take care of not to damage the cooling system.

Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the
plastics used in this appliance. For this reason it is recommended that the outer casing of
this appliance is only cleaned with warm water with a little washing-up liquid added.
After cleaning, reconnect the equipment to the mains supply.

Care and cleaning

14

Defrosting of the refrigerator

Frost is automatically eliminated from the evaporator of the refrigerator compartment
every time the motor compressor stops, during normal use. The defrost water drains out
through a trough into a special container at the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the defrost
water drain hole in the middle of the refrigera­tor compartment channel to prevent the water
overflowing and dripping onto the food inside.
Use the special cleaner provided, which you will
find already inserted into the drain hole.

Defrosting the freezer

A certain amount of frost will always form around the top compartment.

Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm.

To remove the frost, do these steps:

1. Switch off the appliance.

2. Remove any stored food, wrap it in several layers of newspaper and put it in a cool

place.

3. Open the door.

4. When defrosting is completed, dry the interior thoroughly.

5. Switch on the appliance.

6. Set the temperature regulator to obtain the maximum coldness and run the appli-

ance for two or three hours using this setting.

7. Reload the previously removed food into the compartment.

WARNING!

Never use sharp metal tools to scrape off frost from the evaporator as you could damage
it. Do not use a mechanical device or any artificial means to speed up the thawing proc­ess other than those recommended by the manufacturer. A temperature rise of the fro­zen food packs, during defrosting, may shorten their safe storage life.

Periods of non-operation

When the appliance is not in use for long periods, take the following precautions:

What to do if…

•

disconnect the appliance from electricity supply

• remove all food

defrost

5)

and clean the appliance and all accessories

•

• leave the door/doors ajar to prevent unpleasant smells.
If the cabinet will be kept on, ask somebody to check it once in a while to prevent the
food inside from spoiling in case of a power failure.

WHAT TO DO IF…

WARNING!

Before troubleshooting, disconnect the mains plug from the mains socket.
Only a qualified electrician or competent person must do the troubleshooting that is not
in this manual.

There are some sounds during normal use (compressor, refrigerant circulation).

Problem Possible cause Solution

The appliance is noisy

The appliance does not op­erate. The lamp does not
operate.

The mains plug is not connec-

The appliance has no power.

The lamp does not work.

The lamp is defective. Refer to "Replacing the lamp".

The compressor operates
continually.

The door is not closed correctly. Refer to "Closing the door".
The door has been opened too

The product temperature is too

The room temperature is too

The appliance is not supported
properly

The appliance is switched off. Switch on the appliance.

ted to the mains socket correct­ly.

There is no voltage in the mains
socket.

The lamp is in stand-by. Close and open the door.

The temperature is not set cor­rectly.

frequently.

high.

high.

Check if the appliance stands sta­ble (all the four feet should be
on the floor)

Connect the mains plug to the
mains socket correctly.

Connect a different electrical ap­pliance to the mains socket.
Contact a qualified electrician.

Set a higher temperature.

Do not keep the door open lon­ger than necessary.

Let the product temperature de­crease to room temperature be­fore storage.

Decrease the room temperature.

15

5) If foreseen.

What to do if…

16

Problem Possible cause Solution

The compressor does not
start immediately after
pressing the COOLMATIC
or FROSTMATIC switch, or
after changing the tem­perature.

Water flows on the rear
plate of the refrigerator.

Water flows into the re­frigerator.

Products prevent that water

Temperature cannot be
set .

The temperature in the ap­pliance is too low/high.

The door is not closed correctly. Refer to "Closing the door".
The product temperature is too

Many products are stored at

The temperature in the re­frigerator is too high.

The temperature in the
freezer is too high.

There is too much frost.

The door is not closed correctly. Refer to "Closing the door".
The temperature regulator is

This is normal, no error has oc­curred.

During the automatic defrost­ing process, frost defrosts on
the rear plate.

The water outlet is clogged. Clean the water outlet.

flows into the water collector.
COOLMATIC or FROSTMATIC

functions switched on.

The temperature regulator is
not set correctly.

high.

the same time.
There is no cold air circulation

in the appliance.
Products are too near to each

other.
Food is not wrapped correctly. Wrap the food correctly.

not set correctly.

The compressor starts after a pe­riod of time.

This is correct.

Make sure that products do not
touch the rear plate.

Switch off COOLMATIC or FROST­MATIC manually, or wait to set
the temperature until the func­tion has reset automatically. Re­fer to "COOLMATIC or FROSTMAT­IC function"..

Set a higher/lower temperature.

Let the product temperature de­crease to room temperature be­fore storage.

Store less products at the same
time.

Make sure that there is cold air
circulation in the appliance.

Store products so that there is
cold air circulation.

Set a higher temperature.

Replacing the lamp

The appliance is equipped with a longlife LED interior light.
Only service is allowed to replace the lighting device. Contact your Service Center

Closing the door

1. Clean the door gaskets.

2. If necessary, adjust the door. Refer to "Installation".

Technical data

3. If necessary, replace the defective door gaskets. Contact the Service Center.

TECHNICAL DATA

Dimension of the recess
Height 1225 mm
Width 560 mm
Depth 550 mm
Rising Time 12 h

The technical information are situated in the rating plate on the internal left side of the
appliance and in the energy label.

INSTALLATION

Positioning

WARNING!

If you are discarding an old appliance that has a lock or catch on the door, you must
ensure that it is made unusable to prevent young children being trapped inside.

17

The appliance shall have the plug accessible after installation.

Install this appliance at a location where the ambient temperature corresponds to the
climate class indicated on the rating plate of the appliance:

Climate class Ambient temperature

SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C

Electrical connection

Before plugging in, ensure that the voltage and frequency shown on the rating plate cor­respond to your domestic power supply.
The appliance must be earthed. The power supply cable plug is provided with a contact
for this purpose. If the domestic power supply socket is not earthed, connect the appli­ance to a separate earth in compliance with current regulations, consulting a qualified
electrician.
The manufacturer declines all responsibility if the above safety precautions are not ob­served.
This appliance complies with the E.E.C. Directives.

Environmental concerns

18

Ventilation requirements

The airflow behind the appliance must be suffi­cient.

50 mm

min.
200 cm

2

ENVIRONMENTAL CONCERNS

The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it should be taken to the appropriate collection
point for the recycling of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate
waste handling of this product. For more detailed information about recycling of this
product, please contact your local council, your household waste disposal service or the
shop where you purchased the product.

min.
200 cm

2

PER RISULTATI PERFETTI

Grazie per aver scelto di acquistare questo prodotto
AEG. Lo abbiamo creato per fornirvi prestazioni
impeccabili per molti anni, grazie a tecnologie
innovative che vi semplificheranno la vita - funzioni che
non troverete sui normali elettrodomestici. Vi invitiamo
di dedicare qualche minuto alla lettura per sapere come
trarre il massimo dal vostro elettrodomestico.

ACCESSORI E PRODOTTI DI CONSUMO

All'interno del webshop AEG troverete tutto ciò che vi
serve per fare in modo che i vostri elettrodomestici AEG
siano sempre perfettamente puliti e funzionanti. Non
mancano inoltre una vasta gamma di accessori studiati
e realizzati conformemente agli elevati standard
qualitativi che vi aspettate: pentole, scolaposate,
portabottiglie e sacchi biancheria delicati...

19

Visitate il webshop su
www.aeg-electrolux.com/shop

20

INDICE

Indice

21 Informazioni per la sicurezza
23 Pannello dei comandi
27 Primo utilizzo
27 Utilizzo quotidiano
29 Consigli e suggerimenti utili
30 Pulizia e cura
32 Cosa fare se…
35 Dati tecnici
35 Installazione
36 Considerazioni ambientali

In questo manuale sono riportati i
seguenti simboli:

Informazioni importanti relative alla
prevenzione dei rischi per la salute
personale e dei danni alle
apparecchiature.

Informazioni e consigli generali

Informazioni in materia di sicurezza
ambientale

Con riserva di modifiche

Informazioni per la sicurezza

INFORMAZIONI PER LA SICUREZZA

Per garantire un impiego corretto e sicuro dell'apparecchio, prima dell'installazione e del
primo utilizzo leggere con attenzione il libretto istruzioni, inclusi i suggerimenti e le av­vertenze. Per evitare errori e incidenti, è importante garantire che tutte le persone che
utilizzano l'apparecchio ne conoscano il funzionamento e le caratteristiche di sicurezza.
Conservare queste istruzioni e accertarsi che rimangano unite all'apparecchio in caso di
vendita o trasloco, in modo che chiunque lo utilizzi sia correttamente informato sull'uso
e sulle norme di sicurezza.
Per la sicurezza delle persone e delle cose osservare le precauzioni indicate nelle presenti
istruzioni per l'utente, il produttore non è responsabile dei danni provocati da eventuali
omissioni.

Sicurezza dei bambini e delle persone fragili

• Questo apparecchio non deve essere usato da persone, bambini inclusi, con ridotte ca­pacità fisiche, sensoriali o psichiche, oppure prive di conoscenza e esperienza, a meno
che non siano state istruite all'uso dell'apparecchio da parte dei responsabili della loro
sicurezza, oppure sotto vigilanza di questi.

I bambini devono essere sorvegliati per assicurarsi che non giochino con l'apparecchio.

• Tenere i materiali di imballaggio al di fuori della portata dei bambini. Alcuni materiali
possono creare rischi di soffocamento.

• Qualora l'apparecchio venga demolito, estrarre la spina dalla presa, tagliare il cavo di
collegamento (il più vicino possibile all'apparecchio) e smontare lo sportello per evita­re che i bambini giocando possano subire scosse elettriche o chiudersi dentro l'appa­recchio.

• Se questo nuovo apparecchio, che è dotato di guarnizioni magnetiche nello sportello,
va a sostituirne uno più vecchio avente sportello o coperchio con chiusure a molla, si
deve rendere inutilizzabili tali chiusure prima di eliminare l'apparecchio sostituito, per
evitare che diventi una trappola mortale per i bambini.

21

Norme di sicurezza generali

ATTENZIONE

Accertarsi che le aperture di ventilazione non siano ostruite.

• L'apparecchiatura è progettata per la conservazione domestica di alimenti e/o bevande
nelle modalità descritte nelle presenti istruzioni.

• Non utilizzare dispositivi meccanici o altri mezzi artificiali per accelerare lo sbrinamento.

• Non utilizzare altre apparecchiature elettriche (per esempio gelatiere) all'interno del
frigorifero, salvo quelle approvate per tale scopo dal produttore.

• Non danneggiare il circuito refrigerante.

• Il circuito refrigerante dell'apparecchiatura contiene isobutano (R600a), un gas natura­le con un elevato livello di compatibilità ambientale che, tuttavia, è infiammabile.

Durante il trasporto e l'installazione dell'apparecchiatura, assicurarsi che nessuno dei
componenti del circuito refrigerante venga danneggiato.

In caso di danneggiamento del circuito refrigerante:

Informazioni per la sicurezza

22

– Evitare fiamme libere e scintille
– Aerare bene il locale in cui si trova l'apparecchiatura

• È pericoloso cambiare le specifiche o modificare il prodotto in qualunque modo. Un
danneggiamento del cavo potrebbe provocare cortocircuiti, incendi e/o scosse elettriche.

AVVERTENZA

Tutti i componenti elettrici (cavo di alimentazione, spina, compressore) devono essere so­stituiti da un tecnico certificato o da personale d'assistenza qualificato.

1. Non collegare prolunghe al cavo di alimentazione.

2. Evitare che il lato posteriore dell'apparecchiatura possa schiacciare o danneggiare

la spina, causandone il surriscaldamento con un conseguente rischio di incendio.

3. La spina dell'apparecchiatura deve trovarsi in una posizione accessibile.

4. Evitare di tirare il cavo di alimentazione.

5. Se la presa elettrica non è perfettamente stabile, non inserire la spina. Il collega-

mento potrebbe provocare scosse elettriche o creare un rischio di incendio.

6. L'apparecchiatura non deve essere messo in funzione senza il coprilampada inter-

6)

della luce interna.

no

• Questa apparecchiatura è pesante. Prestare attenzione quando occorre spostarla.

• Evitare di estrarre o di toccare gli alimenti riposti nel vano congelatore con le mani
bagnate o umide; il contatto potrebbe provocare abrasioni o ustioni da freddo.

• Evitare un'esposizione prolungata dell'apparecchiatura alla luce solare diretta.

•

Lampadine

7)

utilizzate in questa apparecchiatura sono lampadine speciali selezionate
per essere usate unicamente negli elettrodomestici. Non sono adatte per l'illuminazio­ne degli ambienti.

Uso normale

• Non appoggiare pentole calde sulle parti in plastica dell'apparecchiatura.

• Non riporre gas o liquidi infiammabili nell'apparecchio: i contenitori potrebbero esplo­dere.

• Osservare rigorosamente le raccomandazioni del produttore riguardo alla conservazio­ne degli alimenti. Leggere attentamente le relative istruzioni.

Pulizia e cura

• Prima di eseguire qualunque intervento di manutenzione, spegnere l'apparecchiatura
ed estrarre la spina dalla presa.

• Non pulire l'apparecchiatura con oggetti metallici.

• Ispezionare regolarmente lo scarico dell'acqua di sbrinamento. Lo scarico deve essere
sempre perfettamente libero. L'ostruzione dello scarico può causare un deposito di ac­qua sul fondo dell'apparecchiatura.

6) Per le apparecchiature che prevedono il coprilampada.

7) Nel caso in cui la lampadina sia prevista.
