FAVORIT 84470 VI

Dishwasher

Instruction book

PERFEKT IN FORM UND FUNKTION

Dear customer,

Please read this User Information carefully and keep it to refer to at a later date. Pass it on to any subsequent owner of the appliance.

The following symbols are used in the text:

Safety instructions

Warning! Notes that concern your personal safety. Attention! Notes that show how to avoid damage to the appliance.

Useful tips and hints

Environmental information

Your dishwasher has the new washing system ”IMPULSE WASHING”. With this dishwashing system the motor speed and spray pressure are varied during the wash cycle to achieve better cleaning of the dishes. It is for this reason that the noise level varies during the dishwashing cycle.

Printed on paper manufactured with environmentally sound processes. He who thinks ecologically acts accordingly...

CONTENTS

Operating instructions 4

Safety instructions 4 Disposal 6 Economical and ecological dishwashing 6 Description of the appliance 7 The control panel 7 Prior to using for the first time 10

Setting the water softener 10 Filling with salt 13 Rinse aid 14

In daily use 17

Loading cutlery and dishes 17 The lower basket 19 The cutlery basket 20 The upper basket 21 Adjusting the height of the upper basket 22 Use of detergent 23 Different kinds of detergent 24

Washing programmes 26 Starting a washing programme 27

Unloading the dishwasher 29

Maintenance and cleaning 30

Cleaning the filters 30

What to do, when... 33

Service 36 Guarantee terms 37

Technical specifications 39

Installation instructions 40

Building-in 40 Levelling 40 Fixing to the adjacent units 40 Water supply connections 41 Water inlet hose with safety valve 42 Water outlet hose connection 43 Electrical connection 44

Hints for test centres 45

Contents

OPERATING INSTRUCTIONS

Safety instructions

The safety of AEG electrical appliances conforms to accepted rules of technology and the Appliance Safety Act. We as manufacturers, however, see ourselves as being obliged to familiarise you with the following safety instructions.

It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.

This information has been provided in the interest of your safety. You MUST read it carefully before installing or using the appliance.

Installation

● Check your dishwasher for any transport damage. Never connect a

damaged machine. If your dishwasher is damaged, you should contact your supplier.

● For safety reasons it is dangerous to alter the specifications or

attempt to modify this product in any way.

● Any electrical and plumbing work required to install this appliance

should be carried out by a qualified and competent person.

● Care must be taken to ensure that the appliance does not stand on

the electrical supply cable.

● The sides of the dishwasher must never be drilled to prevent

damage to hydraulic components.

Child safety

● This appliance is designed to be operated by adults.

● Children should not be allowed to tamper with the controls or play

with the product.

● Packaging parts may be dangerous for children, who could even be

suffocated! You should therefore keep all packaging well away from children.

Operating instructions

● The water in your dishwasher is not for drinking. Detergent residues

may still be present in your machine. Keep children well away from your dishwasher when the door is open.

● Keep all detergents in a safe place out of children’s reach.

Your dishwasher in day-to-day use

● Items that are contaminated by petrol, paint, steel or iron debris,

corrosive, acidic or alkaline chemicals must not be washed in this dishwasher.

● Under no circumstances should you open the door whilst the

appliance is in operation, especially during the washing phase, hot water may escape. However, if the door is opened, a safety device ensures that the machine stops.

● Only use products (detergent, salt and rinse aid) specifically

designed for use in dishwashers.

● Long bladed knives stored in an upright position are a potential

hazard.

● Long and/or sharp items of cutlery such as carving knives must be

positioned horizontally in the upper basket.

● When finishing loading or unloading close the door, as an open

door can be a hazard.

● Do not sit or stand on the open door.

● Isolate the appliance from the power supply and turn off the water

supply after use.

● This product should be serviced by an authorised service engineer,

and only genuine spare parts should be used.

● Under no circumstances should you attempt to repair the machine

yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre. Always insist on genuine spare parts.

Operating instructions

Disposal

Dispose of the dishwasher packaging material correctly. All packaging materials can be recycled.

Plastic parts are marked with standard international abbreviations: >PE< for polyethylene, e.g. sheet wrapping material.

>PS< for polystyrene, e.g. padding material (always CFC-free). >POM< for polyoxymethylene, e.g. plastic clips.

Cardboard packaging is manufactured from recycled paper and should be deposited in the waste paper collection for recycling.

As and when you cease to use your dishwasher and withdraw it from service, your should render it unserviceable before having it disposed of.

Warning! Children at play could lock themselves in your dishwasher or otherwise endanger their lives. Therefore cut off the power supply cable and make the door closing device unusable to prevent children from being trapped inside.

To dispose of the appliance please take it to a recycling centre or to your dealer who may, for a small contribution to the costs, dispose of it for you.

Economical and ecological dishwashing

● Ensure that the water softener is correctly adjusted.

● Do not pre-wash under running water.

● Select the wash programme to suit the nature and degree of the

soiling on the dishes.

● Do not use more detergent, dishwasher salt and rinse aid than is

recommended in these operating instructions and by the manufacturer of the respective product.

Operating instructions

Description of the appliance

Water hardness dial

Detergent dispenser

Filters

Upper spray arm

Lower spray arm

Rating plate

Rinse aid dispenser

Salt container

On/Off button

Programme selection

buttons

Function buttons

Indicator lights

Delay start

option button

The control panel

Digital display

3 IN 1

option button

Operating instructions

Function buttons: in addition to the dishwashing programme

selected and "delay start", the following functions can also be set with the help of these buttons:

- water softener setting,

- deactivation/activation of the rinse aid dispenser,

- deactivation/activation of the audible signals,

- the cancelling of a washing programme.

"Programme selection" buttons: allows the selection of the

desired washing programme (see "Washing programmes" chart).

"Delay start" option button: this option allows the start of the

programme to be delayed from 1 to 19 hours.

The digital display indicates:

- the level of hardness to which the water softener is set

- if the audible signals are activated/deactivated

- if the rinse aid dispenser is activated/deactivated

- the delay start

- the approximate remaining time of the running programme

- fault codes concerning malfunction of the dishwasher

Indicator lights: have the following meanings:

The salt and rinse aid indicator lights are never illuminated while a washing programme is running even if the salt or rinse aid dispenser require refilling.

"3 in 1"option button: this appliance is equipped with the option

"3 in 1", which allows the use of the "3 in 1" combi detergent tablets.

This function can be selected with all washing programmes. With the selection of this function the dosage of rinse aid and salt from each respective supply container is automatically deactivated and also the indicator lights for salt and rinse aid are deactivated. Once selected this option button (indicator light illuminated ) it will remain active also for the following washing programmes, to deactivate the function, press the button (button indicator light off).

Salt refilling indicator light, illuminates when the salt has run out

Rinse aid refilling indicator light, illuminates when the rinse aid has run out

Operating instructions

Audible signals

Audible signals have been introduced to help indicate which operations the dishwasher is performing:

"Setting of the water softener" "End of programme" "Something not working with the machine"

Deactivation/activation of the audible signals

(The dishwasher must be switched off)

1. Press the On/Off button. All programme selection buttons indicator lights will illuminate (setting mode).

If only one programme selection button indicator light is illuminated, this means that a washing programme has been selected. The programme must be cancelled: press simultaneously the function buttons

and 3for about 2 seconds, the indicator light of the set programme button starts flashing for about 2 seconds. After about 2 seconds the indicator lights of all the programme selection buttons will illuminate indicating that the set programme

has been cancelled and that the machine is now in setting mode.

2. Press simultaneously function push buttons 2 and 3, the indicator lights of the function push buttons 1, 2 and 3 start flashing.

3. Press the function button 3, the indicator lights of function buttons 1 and 2 turn off while the indicator light of the button 3 goes on

flashing, the digital display indicates the current setting.

4. To change the current setting, press again the function button 3, the digital display will indicate the new setting.

5. To memorise the operation, switch off the dishwasher by pressing the On/Off button or wait about 60 seconds after which the dishwasher will automatically return to setting mode.

Audible signals deactivated

Audible signals activated (factory set)

Operating instructions

Prior to using for the first time

Before using your dishwasher for the first time:

1. Ensure that the electrical and water connections comply with the installation instructions

2. Remove all packaging from inside the appliance

3. Set the water softener

4. Pour 1 litre of water inside the salt container and then fill with

special dishwasher salt.

5. Fill the rinse aid dispenser.

Setting the water softener

The dishwasher is equipped with a water softener designed to remove minerals and salts from the water supply, which would have a detrimental or adverse effect on the operation of the appliance.

The higher the content of these minerals and salts, the harder your water is. Water hardness is measured in equivalent scales, German degrees, French degrees and mmol/l (millimol per litre).

The softener should be adjusted according to the hardness of the water in your area. Your local Water Authority can advise you on the hardness of the water in your area.

The water softener must be set in both ways: manually, using the water hardness dial and electronically, using the function push buttons on the control panel.

Adjusting the water

hardness setting

9 8 7 6

3 3

no salt

necessary

Manually

Electronically

Number

of audible

signals

2 2

Water hardness

51 - 70 43 - 50 37 - 42 29 - 36 23 - 28

9,0 - 12,5 7,6 - 8,9 6,5 - 7,5 5,1 - 6,4 4,0 - 5,0

11 - 14 1,9 - 2,5 II

< 4 < 0,7 I

4 - 10 0,7 - 1,8 I/II

19 - 22 15 - 18

3,3 - 3,9 2,6 - 3,2

III

5 4

Level indica-

ted in the

digital dis-

play

°dH

(german de-

grees)

91 - 125 76 - 90 65 - 75 51 - 64 40 - 50

19 - 25

< 7

7 - 18

33 - 39 26 - 32

°TH

(french degrees)

mmol/l

(millimol per litre, inter-

national unit for the

hardness of water)

Range

a) Setting manually

1. Open the dishwasher door.

2. Remove the lower basket from the dishwasher.

3. Turn the water hardness dial to

position 1 or 2 (see table).

4. Replace the lower basket. The dishwasher is factory set at

position 2.

b) Setting electronically

(The dishwasher must be switched off) The dishwasher is factory set at level 5.

1. Press the On/Off button. All programme selection buttons indicator lights will illuminate (setting mode).

2. Press simultaneously function buttons 2 and 3, until the indicator lights of function buttons 1, 2 and 3 start flashing.

3. Press function button 1, the indicator lights of function buttons 2 and 3 turn off while the indicator light of the button 1 goes on flashing, the digital display indicates the current level and a sequence of intermittent audible signals are heard . The current level is indicated by the number visible in the display and the number of intermittent audible signals heard.

Example:

displayed + 5 audible signals = level 5.

Operating instructions

AA07

Operating instructions

4. To change the level, press button 1. Each time the button is pressed the level changes. (For the selection of the new level see the chart).

Examples:

if the current level is 5, by pressing button 1 once, level 6 is selected.

if the current level is 10, by pressing button 1 once, level 1 is selected.

5. To memorise the operation, switch off the dishwasher by pressing the On/Off button or wait about 60 seconds after which the dishwasher will automatically return to setting mode.

Operating instructions

Filling with salt

Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in a dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting one of the complete washing programmes. This will prevent any grains of salt or salty water, which may have been spilt, remaining on the bottom of the machine for any period of time, which may cause corrosion.

To fill:

1. Open the door, remove the lower basket and unscrew the

cap of the salt container by turning it anticlockwise.

2. Pour 1 litre of water inside the container (this is necessary only before filling with salt for the first time).

3. Using the funnel provided, pour in the salt until the container is full.

4. Replace the cap making sure that there is no trace of salt on the screw thread or on the gasket.

5. Screw on the cap tightly turning it clockwise until it stops with a click.

The salt container will require topping up periodically. You are reminded of this by the salt indicator light on the control panel which comes on when the salt has finished.

The salt indicator light on the control panel can remain illuminated for 2-6 hours after the salt has been replenished, assuming the dishwasher remains switched on. If you are using salts that take longer to dissolve then this can take longer. The function of the machine is not affected.

Do not worry if water over flows from the unit when filling with salt, this is quite normal.

SALE

ZOUT

SALT

SALZ

SEL

SR14

Operating instructions

Rinse aid

Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying. The dispenser, which is positioned inside the door, holds about 110 ml of rinse aid, which is sufficient for 16 - 40 dishwashing programmes, depending upon the dosage setting.

Filling with rinse aid

1. Open the container by pressing the release button (A).

2. Add the rinse aid until the container is completely full. The

maximum level for filling is indicated by “max”.

Ensure that the lid is closed after every refill.

Clean up any rinse aid spilt during filling with an absorbent cloth to avoid excess foaming during the next wash.

Only use branded rinse aid for dishwashers. Never fill the rinse aid dispenser with any other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance.

BR07

BR14

Operating instructions

Adjusting the dose

According to the finish and drying results obtained, adjust the dose of rinse aid by means of the 6 position selector (position 1 minimum dosage, position 6 maximum dosage).

The dose is factory set in position 4. Increase the dose if there are drops of

water or lime spots on the dishes after washing.

Reduce it if there are sticky whitish streaks on the dishes or a bluish film on glassware or knife blades.

Top up the rinse aid when the indicator light on the control panel illuminates.

BR09
