AEG-Electrolux FAVORIT 80850I-M User Manual
ÖKO_FAVORIT 80850 i
Dishwasher
User Instructions
Dear customer,
Pri
Please read these user instructions carefully.
Please observe the safety instructions on the first few pages of these
user instructions! Please keep these user instructions for later reference.
Pass them on to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, Caution!,
1
Important!) are used to highlight instructions that are important for
your safety or for the function of the appliance. It is imperative that
these instructions are observed.
0 This symbol or numbered instruction steps lead you step by step
through the operation of the appliance.
Next to this symbol you receive additional information and practical
3
tips on using the appliance.
Tips and instructions for the economical and environmentally conscious
2
use of the appliance are marked with a clover leaf.
In the event of a malfunction, these operating instructions contain
information on how to rectify faults yourself, see the "What to do, if..."
section.
If these instructions are insufficient, please contact your AEG Service
Force Centre.
In this respect please read the chapter "Service & Spare Parts".
2
nted on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly ...
Contents
CONTENTS
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Economical and Ecological Dishwashing . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appliance Features and Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Prior to using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Adjust the Water Softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filling with Salt for the Water Softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filling with Rinse Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Adjusting Rinse Aid Dosing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the Audible Signal for the End of the Wash Programme . . . . . . . 15
In Daily Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Loading Cutlery and Dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Loading Cutlery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Loading Pans, Frying Pans and Large Plates . . . . . . . . . . . . . . . . . . . . . . 19
Loading Cups, Glasses and Coffee Services . . . . . . . . . . . . . . . . . . . . . . . 20
Adjusting the Height of the Upper Rack . . . . . . . . . . . . . . . . . . . . . . . . . 21
Filling with Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Bio Wash Programmes and Concentrated Detergents . . . . . . . . . . . . . . 23
AUTO 65° and AUTO BIO 50° Wash Programmes . . . . . . . . . . . . . . . . . . 23
Selecting the Wash Programme (Programme Table) . . . . . . . . . . . . . . . . . . 24
Starting the Wash Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Changing/Interrupting/Cancelling the Wash Programme . . . . . . . . . . . 26
Pause Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting or Changing the Delay Start Timer . . . . . . . . . . . . . . . . . . . . . . . 28
Load Sensing – Sensor Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Switching Off the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Emptying the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cleaning the Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
What to do, if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
...Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
...there are problems with the operation of the dishwasher. . . . . . . . . . . . 33
...the wash result is not satisfactory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3
Contents
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Notes for Test Institutes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Installation and Connection Instructions . . . . . . . . . . . . . . . . 36
Installing the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Dishwashers That Can Be Integrated . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Built-In Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Free-Standing Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Connecting the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Water Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Permitted water pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Connect the inlet hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Water drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Leak Prevention System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Guarantee Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Service & Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4
Operating Instructions
OPERATING INSTRUCTIONS
1 Safety Instructions
The safety aspects of AEG electrical appliances comply with accepted
technical standards and the German Appliance Safety Law. Nevertheless, as a manufacturer we consider it our obligation to make you
aware of the following safety information:
Installation, Connection and Placing into Operation
• The dishwasher may only be transported upright.
• Check the dishwasher for transport damage. Do not in any circum-
stances connect an appliance that is damaged. In the case of damage,
please contact your retailer.
• Before installing the appliance, ensure that the nominal voltage and
type of supply on the rating plate match that of the supply where the
appliance is to be installed. The fuse rating is also to be found on the
rating plate.
• For information on how to correctly install and connect up your dishwasher, please read the “Installation“ section. Adaptors / connectors
and extension cables must not be used.
Child Safety
• This appliance is designed to be operated by adults. Children should
not be allowed to tamper with the controls or play with the product.
• Keep all packaging away from children.
• Keep all detergents in a safe place out of children’s reach.
• The water in your dishwasher is not suitable for drinking. If there are
still remnants of detergent in the appliance, there is a risk of burns!
• When disposing of an old appliance, cut off the power supply cable
and remove any door catches, to prevent young children being
trapped inside.
General Safety
• Repairs to the dishwasher are only to be carried out by qualified service engineers. Improper repairs can give rise to significant hazards for
the user. If your appliance needs repairing, please contact your local
AEG Service Force Centre.
5
Operating Instructions
• Never place the dishwasher in operation if the mains cable, water
inlet or drain hose is damaged; or the control panel, work top or
plinth area is damaged such that the inside of the appliance is freely
accessible.
• If the mains lead is damaged, or is to be replaced for a longer lead,
the cable (obtainable from AEG Service Force) must be changed by a
service engineer authorised by AEG.
• Never unplug the appliance by pulling on the cable, always pull the
plug.
• Additions or modifications to the dishwasher are not permitted for
safety reasons.
• Ensure that the door of the dishwasher is always closed when it is not
being loaded or unloaded. In this way you will avoid anybody tripping
over the open door and hurting themselves.
• Long bladed knives stored in an upright position are a potential hazard.
• Long and/or sharp items of cutlery such as carving knives must be
positioned horizontally in the upper basket.
• When finished loading or unloading, close the door as an open door
can be a hazard.
Correct Use
• Only wash household dishes using the dishwasher. If the appliance is
used for other purposes, or is used incorrectly, the manufacturer cannot accept any liability for any damage caused.
• Only use detergents specifically designed for use in domestic dishwashers.
• Do not put any solvents in the dishwasher. There is a risk of an explosion!
• The anti-flood system provides dependable protection against damage due to leaks. For this system to function correctly, the following
preconditions must be met:
– The appliance must remain connected to the mains even when it is
switched off.
– The dishwasher must be correctly installed.
– Always shut off the water supply at the tap when the dishwasher is
not to be used for longer periods, e.g. when you are away on holiday.
• Do not sit or stand on the open door, the appliance may tip over.
6
Operating Instructions
• In the event of a fault, first close the tap, then switch off the appliance and unplug it from the mains. If the appliance is permanently
wired to the mains: remove the fuse.
2 Disposal
Disposing of the Packaging Material
Dispose of the dishwasher packaging material correctly. All the packaging materials used are harmless to the environment and can be recycled.
• Plastic parts are marked with standard international abbreviations:
– >PE< for polyethylene, e.g. sheet wrapping material
– >PS< for polystyrene, e.g. padding material (always CFC-free)
– >POM< for polyoxymethylene, e.g. plastic clips
• Cardboard packaging is manufactured from recycled paper and
should be deposited in the waste paper collection for recycling.
Disposal of Old Appliances
When disposing of old appliances, remove the plug and ensure that any
locks or catches are removed to prevent young children becoming
trapped inside.
Use an authorised disposal site.
7
Operating Instructions
2 Economical and Ecological Dishwashing
• Ensure that the water softener is correctly adjusted.
• Do not pre-rinse dishes under running water.
• If you wash a small load, the load sensor calculates the amount of
water necessary and shortens the programme. It is more economical
to always wash with a full load.
• Select the wash programme to suit the nature and degree of the soiling on the dishes.
• Do not use more detergent, special salt or rinse aid than is recommended in these operating instructions and by the detergent manufacturer.
• The dishwasher's interior light is always switched on as long as the
door of the appliance is open. To save energy you should therefore
always close the door of the dishwasher after loading or removing
dishes.
8
Operating Instructions
Appliance Features and Control Panel
Top Spray Arm
Rubber Seal for
Connecting the
Water Feed to
the Middle Spray
Arm
Spray Arms
Container for
Salt
Container
for Rinse Aid
Container for
Detergent
Inlet
for Fan
Assisted Drying
Rating Plate
Filters
Interior Lighting
9
Operating Instructions
Si
Control Panel
gnal
Tone
Button
Water Softener
Button
Door
Handle
MultiDisplay
Set Start
Delay
Indicators
Control Panel
Air Outlet for Fan
Assisted Drying
Display for the Individual
Wash Programme Steps
The Control Panel comprises the ON/OFF switch and the programme
buttons with LED indicators.
Signal Tone Button: In addition to the wash program printed on the
front panel, this button can be used to set whether a signal tone is to
indicate that a wash program is finished.
Water Softener Button: In addition to the wash program printed on
the front panel, this button can be used to adjust the dishwasher's
water softener.
The Multi-Display can display,
– the hardness setting to which the water softener is set.
– whether the signal tone is switched on or off.
– the start delay that is set.
– how long the current wash programme can be expected to last.
– which fault has occurred on the dishwasher.
The indicators have the following significance :
SALT Refill with special salt
RINSE AID Refill with rinse aid
WATER Open tap
FILTER Clean the dishwasher's filter system
DOOR The dishwasher door is open
SPRAY ARM The middle spray arm is jammed
10
The FILTER indicator is intended to remind you to check the filters in
3
the dishwasher from time to time and, if necessary, to clean it. The
indicator illuminates at regular intervals, independent of the amount of
soiling of the filters.
Operating Instructions
Prior to using for the first time
Prior to using for the first time, remove all the clips with which the dish
racks are secured for transport.
Then perform the following steps:
0 1. Adjust the water softener
2. Fill with Salt for the Water Softener
3. Fill with Rinse Aid
Adjust the Water Softener
To prevent the build up of scale on dishes and in the dishwasher, the
dishes must be washed with soft, i.e. low lime content water. For this
reason the dishwasher is fitted with a water softener in which tap
water from a hardness of 4 °d (German degree) is softened with the aid
of special salt.
Your local water authority can advise you on the hardness of the water
3
in your area.
0 Adjust the water softener to the setting given in the table that corre-
sponds to the hardness of the water in the area where you live. The
water softener can be adjusted in 10 steps.
Water Hardness
1
in °d
) in ppm2)
41-50
35-40
31-34
27-30
23-26
19-22
15-18
11-14 190-250 2 H 2
4-10 70-180 1 H 1
under 4 under 70
1)(°d) German degree, measure of the hardness of water
2)(ppm) Parts Per Million
*factory setting
730-900
630-720
550-620
480-540
410-470
330-400
260-320
Adjust
to Hardness Setting
9
8
7
6
5
4
3*
0
no salt necessary
Indication on the
Multi-Display
H 9
H 8
H 7
H 6
H 5
H 4
H 3
H 0
11
Operating Instructions
0 1. The dishwasher must be switched off.
2. Press the signal tone and water softener buttons simultaneously and
keep them pressed
3. Press the ON/OFF button. The LED indicators for the signal tone and
water softener buttons flash.
4. Press the softener button again.
The multi-display indicates the hardness setting.
5. Pressing the hardness button increases the hardness setting by 1.
(Exception: Hardness setting 0 follows hardness setting 9).
6. Once the hardness setting is correctly adjusted, press the ON/OFF button.
The hardness setting is then saved.
12
Operating Instructions
Filling with Salt for the Water Softener
Use only special salt for dishwashers. Never fill the salt container with
1
any another type of salt (e.g. culinary salt) or dishwasher detergent, as
this would irreparably damage the water softener.
Prior to filling with salt, please check each time that you really do have
a packet of dishwasher salt in your hand.
Fill with salt:
– Prior to using the dishwasher for the first time
– When the SALT indicator on the control panel is illuminated.
If the water hardness in your area is less than 4 °d, you do not need to
3
use salt.
0 1. Open the door, remove the lower
rack.
2. Undo the lid on the salt container by
turning it anticlockwise.
3. When using for the first time:
fill the salt container with water.
4. Place the funnel supplied on the
container opening.
Fill the container with salt through
the funnel; the capacity of the container is approx. 1.0-1.5 kg depending on the grain size. Do not overfill
the salt container with salt.
SALE
SALT
SALZ
SEL
The water expelled by filling the salt container with special salt runs
3
out of the salt container onto the base of the washing compartment.
This is not a cause for concern, the water will be pumped out at the
start of the next wash programme.
5. Clean any salt remnants on the container opening.
6. Turn the lid clockwise to the stop, otherwise special salt will leak into
the wash water. Dull glasses may result.
7. If you are not going to wash your dishes immediately, you should run
the PRE WASH programme. This will wash away salt water that has run
out of the container and any grains of salt that have been spilt.
Depending on the size of the salt grains, it can take several hours for
3
the salt to dissolve in the water and for the SALT indicator to extinguish.
The setting of the water softener and thus the consumption of salt are
dependent on the hardness of the local water.
13
Operating Instructions
Filling with Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak free drying.
Only use rinse aid specially designed for domestic dishwashers. Never
1
fill the rinse aid container with any other substance as this would damage the appliance.
Fill with rinse aid:
– Prior to using the dishwasher for the first time
– When the RINSE AID indicator on the control panel is illuminated.
The rinse aid container is on the inside of the dishwasher door.
0 1. Open the door
2. Turn the lid of the container
¼ of a turn anticlockwise and
remove.
3. Fill with rinse aid, up to the broken
line (maximum); this line corresponds
to a quantity of approx. 150 ml
4. Replace the lid and tighten by turning clockwise.
5. If rinse aid has been spilt, wipe up
with a cloth. Otherwise there will be
foaming during the washing.
14
6
5
x
4
a
m
3
2
1
Operating Instructions
Adjusting Rinse Aid Dosing
The dose should be adjusted according to the finish and drying results
3
obtained. The dose is factory set at 4, and can adjusted from 1 to 6.
Gradually increase the dose if there are drops of water or lime spots on
the dishes after washing. Reduce if it there are sticky whitish streaks on
the dishes.
0 1. Turn the lid of the container
¼ of a turn anticlockwise and
remove.
2. Adjust the dose setting with a tea
spoon.
3. Replace the lid and tighten by turning clockwise.
4. If rinse aid has run out, wipe up with
a cloth.
Setting the Audible Signal for the End of the Wash
Programme
The dishwasher can be set to exit an audible signal at the end of a wash
cycle.
0 1. The dishwasher must be switched off.
2. Press the signal tone and water softener buttons simultaneously and
keep them pressed.
3. Press the ON/OFF button. The LED indicators for the signal tone and
water softener buttons flash.
4. Press the signal tone button again.
The multi-display indicates the current setting:
b0
b1
5. Pressing the signal tone button changes the setting.
6. Once the multi-display indicates the required setting, press the ON/OFF
button. The setting is then saved.
Signal tone switched off
Signal tone switched on (factory setting)
15
Loading...
