FAVORIT 65070 i
Dishwasher
User information
Dear Customer,
Please read this user information carefully and keep it to refer to later.
Please pass the user information on to any future owner of the appliance.
The following symbols are used in the text:
1 Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3 Useful tips and hints
2 Environmental information
2
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Diagram of Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Prior to Using for the First Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the Water Softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adding dishwasher Salt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Filling Up with Rinse Aid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
In daily use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Loading cutlery and dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting the Height of the Upper Basket . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adding Detergent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using 3in1 detergents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Selecting the dishwashing cycle (Cycle Table) . . . . . . . . . . . . . . . . . . . . . . . . 20
Starting a Dishwashing Cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the Delay Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Switching Off the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Care and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
What to do if.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Remedying small malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
If the Dishwashing Results are not Satisfactory. . . . . . . . . . . . . . . . . . . . . . . 29
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Notes for Test Institutes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Installation and connection instructions. . . . . . . . . . . . . . . . . 34
Safety Information for the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Installing the Dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Connecting the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Electrical Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3
Operating Instructions
1 Safety
Prior to using for the first time
• Follow the ”Instructions for installation and connection”.
Correct Use
• The dishwasher is only intended for washing domestic dishes.
• Additions or modifications to the dishwasher are not permitted.
• Use only special salt, detergent and rinse aid suitable for domestic
dishwashers.
• Do not put any solvents in the dishwasher. This could cause an explosion.
Child Safety
• Keep packaging away from children. There is a risk of suffocation.
• Children often do not recognise the hazards associated with electrical
appliances. Don’t allow children to use the dishwasher unsupervised.
• Make sure that children and pets don’t climb into the dishwasher.
Could endanger life!
• Dishwasher detergents can cause chemical burns to the eyes, mouth
and throat. Could endanger life! Comply with the safety instructions
of the dishwasher detergent manufacturer.
• The water in the dishwasher is not for drinking. Risk of chemical
burns.
4
General Safety
• Repairs to the dishwasher are only to be carried out by qualified/authorised service engineers.
• When the dishwasher is not being used, switch it off and shut off the
water tap.
• Never unplug the appliance by pulling on the cable. Always pull the
plug.
• Ensure that the door of the dishwasher is always closed when it is not
being loaded or unloaded. In this way you will avoid anybody tripping
over the open door and hurting themselves.
• Never sit or stand on the open door.
• If the dishwasher is located in a room where there may be a frost, re-
move the connection hose from the tap after each use of the dishwasher.
5
Diagram of Appliance
Top Spray Nozzle
Upper basket spray arm
and lower spray arm
Water softener
unit.
Salt Container
Detergent
Dispenser
Rinse aid
dispenser
Rating plate
Control Panel
ON/OFF button
The ON/OFF button is used to turn the dishwasher on and off.
6
Filters
Multi-displayProgramme buttons
123
Function buttons
4
Set delay
The Programme buttons are used to select the desired dishwashing cycle.
Function buttons: In addition to the pre-set dishwashing cycle, the
following functions can also be set using these buttons:
Function button 1 Sets the water softener
Function button 2
Function button 3 - not programmed -
Function button 4 Activates/deactivates the 3in1 function
Activates/deactivates rinse aid dispenser
when 3in1 on
The multi-display can indicate:
– the level of hardness to which the water softener is set.
– whether the rinse aid dispenser has been activated/deactivated.
– the start delay that has been set.
– the estimated time remaining for the current dishwashing cycle.
– what type of error has occurred with the dishwasher.
timer
Control
indicators
7
The control indicators have the following meanings:
1)
1)
3 IN 1 3 in 1 function activated
1) These control indicators are never illuminated while a dishwashing cycle is running.
Refill with dishwasher salt
Refill with rinse aid
Prior to Using for the First Time
3
If you wish to use 3 in 1 detergent:
– First read the section “Using 3in1 detergents”.
– Do not fill up with special salt or rinse aid.
If you do not use 3in1 detergent, before using for the first time
1. Set the water softener
2. Fill up with dishwasher salt
3. Fill up with rinse aid
Setting the Water Softener
The water softener must be set manually and electronically:
3 To avoid scale deposits on the dishes and in the dishwasher, the dishes
must be washed with soft water, i.e. water with a low lime content. The
water softener must be set according to the table to the water hardness in the area where you live. Your local water company will be able
to give you information about the water hardness in your area.
The dishwasher must be switched off.
Setting manually:
1. Open the dishwasher door.
2. Remove the lower basket from the
dishwasher.
3. Turn water hardness dial on the left
wall of the dishwasher interior to O
or 1 (see table).
8
Setting electronically:
1. Press the ON/OFF button.
3 If indicators for the programme buttons are lit, a dishwashing cycle is
activated. The cycle must be deactivated:
Press function buttons 2 and 3 simultaneously for approx. 2 seconds.
All additional wash programme button indicators will go out.
2. Press function buttons 2 and 3 simultaneously and keep them pressed.
The LED indicators for function buttons 1 to 4 will flash.
3. Press function button 1.
The LED indicator for function button 1 will flash.
The multi-display will indicate the hardness setting.
4. Pressing function button 1 increases the hardness setting by 1.
(Exception: hardness setting 1 follows hardness setting 10).
5. When the hardness setting is correct, press the ON/OFF button.
The hardness setting is now saved.
If the water softener is set electronically to “1”, this switches off the
control indicator for dishwasher salt.
Water hardness
1)
in °d
51 - 70
43 - 50
37 - 42
29 - 36
23 - 28
19 - 22
15 - 18
11 - 1 4 1,9 - 2,5 II 3 3L
4 - 10 0,7 - 1,8 I/II 2 2L
below 4 below 0.7 I
1) (°d) German degree, measure of the hardness of water
2) [mmol/l] millimol per litre, international unit for water hardness
3) On this setting the length of the dishwashing cycle may be slightly longer.
*) factory setting
in mmol/l
9,0 - 12,5
7,6 - 8,9
6,5 - 7,5
5,1 - 6,4
4,0 - 5,0
3,3 - 3,9
2,6 - 3,2
2)
Range Manual Electronic
IV 1
III
Adjusting the hardness
setting
3)
10
9
8
7
6
5
4*
0*
1
no salt
necessary
Indication on
the multi-dis-
play
10L .
9L
8L
7L
6L
5L
4L
1L
9
Adding dishwasher Salt
To decalcify the water softener, it must be filled up with dishwasher
salt. Use only special salt suitable for domestic dishwashers.
If you do not use 3 in1 detergent, fill up with dishwasher salt:
– Before using the dishwasher for the first time.
– When the control indicator for dishwasher salt is illuminated on the
control panel.
1. Open the door and remove the lower basket.
2. Unscrew the lid on the salt dispenser by turning it anti-clockwise.
3. Only when using the dishwasher
for the first time:
Fill the salt dispenser with water.
4. Place the funnel (supplied) over the
dispenser opening.
Fill the dispenser with dishwasher
salt; the capacity of the dispenser is
approx. 1.0-1.5 kg, depending on
the size of the grains. Do not overfill
the dispenser.
3 If water overflows when filling up with dishwasher salt, this is com-
pletely harmless.
5. Clean away any salt remnants from the dispenser opening.
6. Screw the lid back on in a clockwise direction.
7. Run a dishwashing cycle after filling the salt dispenser with dishwasher salt. This will wash away salt water and salt crystals that have
been spilt.
3 Depending on the size of the salt granules, it can take several hours for
the salt to dissolve in the water and for the control indicator for dishwasher salt to go out.
10
Filling Up with Rinse Aid
Rinse aid causes the rinse water to flow easily from the crockery leaving gleaming dishes and glassware.
If you do not use 3in1 detergent, fill up with rinse aid:
– Before using the dishwasher for the first time.
– When the control indicator for rinse aid is illuminated on the control
panel.
Use only special rinse aid for dishwashers.
1. Open the door.
The rinse aid compartment is located on the inside of the dishwasher
door.
2. Press the release button on the rinse
aid compartment.
3. Open the cover.
4. Pour rinse aid in slowly right up to
the broken “max” line;
this corresponds to a volume of approx. 140 ml when full.
5. Press the lid shut until it clicks into
place.
6. Wipe up any spilt rinse aid with a
cloth. Otherwise there will be too
much foam when rinsing.
11
Setting the Amount of Rinse Aid Required
3 Only change the amount dispensed, if smears, milky spots (reduce the
amount) or dried on water spots (increase the amount) can be seen on
glasses and dishes. (See section “If dishwashing results are not satisfactory”.) The dosage can be set from 1-6. The dosage is pre-set to “4” in
the factory.
1. Open the dishwasher door.
2. Press the release button on the rinse
aid compartment.
3. Open the cover.
4. Set the dosage level.
5. Press the lid shut until it clicks into
place.
6. If rinse aid has leaked out, wipe it
away with a cloth.
Activating/Deactivating the Rinse Aid dispenser
If the 3in1 function is selected, you do not need to deactivate the rinse
aid dispenser.
1. Press the ON/OFF button.
3 If indicators for the programme buttons are lit, a dishwashing cycle is
activated. The cycle must be deactivated:
Press function buttons 2 and 3 simultaneously for approx. 2 seconds.
All additional wash programme button indicators will go out.
2. Press function buttons 2 and 3 simultaneously and keep them pressed.
The LED indicators for function buttons 1 to 4 will flash.
3. Press function button 2.
The LED indicator for function button 2 will flash.
The multi-display will indicate the current setting:
0d Rinse aid dispenser is deactivated
1d Rinse aid dispenser is activated (factory setting)
4. Pressing function button 2 activates and deactivates the rinse aid dispensing function.
5. Once the multi-display is indicating the required setting, press the ON/
OFF button. The setting is now saved.
12
In daily use
Loading cutlery and dishes
1 Sponges, cleaning cloths and any other objects that can absorb water
must not be washed in the dishwasher. Plastic and Teflon-coated dishes
and pans tend to retain water droplets. These dishes and pans therefore
do not dry as well as those made of china and stainless steel.
For washing in the dishwasher, the following cutlery/dishes/pots and pans
are not suitable: are of limited suitability:
• Cutlery with wooden, horn,
china or mother of pearl handles
• Plastic items that are not heat
resistant
• Older cutlery with cement
that is sensitive to temperature
• Dishes or cutlery with glued
parts
• Pewter or copper items
• Lead crystal glass
• Steel items that rust
• Wooden boards/platters
• Items made from synthetic ma-
terials
• Only wash stoneware in the dishwasher if it is
specifically marked by the manufacturer as
being dishwasher-safe.
• Glazed patterns may fade if washed very frequently in the dishwasher.
• Silver and aluminium parts have a tendency to
discolour during washing. Food remains, e.g.
egg white, egg yolk and mustard often cause
discoloration and staining on silver. Therefore
always clean food residues from silver immediately, if it is not to be washed straight after
use.
• Glass can become dull after a large number of
washes.
• Before loading the dishes, you should:
– Remove the worst of the food residues.
– Soak pans with burnt-on food residues.
• When loading the dishes and cutlery, please note:
– Dishes and cutlery must not impede the rotation of the spray arms.
– Load bowls, cups, glasses, pans, etc. with the opening downwards so
that water cannot collect in them
– Dishes and items of cutlery must not lie inside one another or cover
one another
– To avoid damage to glasses, they must not touch one another
– Don’t put small items (e.g. lids) in the baskets for the dishes, but in
the cutlery basket, so that they can’t fall through the holes.
13
Loading cutlery
1 Warning: Sharp knives and other items of cutlery with sharp edges
must be laid in the cutlery rack or in the upper basket to avoid the risk
of injury.
To ensure that all items of cutlery in the cutlery basket can be reached
by the water, you should:
1.Place the grid insert on the cutlery basket
For larger utensils, such as whisks, leave off one half of the cutlery grid.
2.Place forks and spoons in the
cutlery basket's grid insert with
their handles pointing downwards.
14
Pots, Pans, Large Plates
Load larger and heavily soiled dishes
and pans in the lower basket.
(Max. diameter for plates 29 cm).
To make it easier to load larger dishes, the two plate racks on the right
in the lower basket can be folded
down.
Cups, Glasses, Coffee Service
Load smaller, fragile crockery and
long, sharp cutlery in the upper basket.
• Arrange items of crockery on and
under the folding cup racks so
that they are offset from each
other and water can reach all
items.
• The cup racks can be folded up
out of the way for tall crockery
items.
• Lay or hang wine and brandy
glasses in the slots in the cup
racks.
15
Adjusting the Height of the Upper Basket
Maximum height of dishes in the
Upper basket Lower basket
with upper basket raised 22 cm 30 cm
with upper basket lowered 24 cm 29 cm
3 The height of the baskets can also be adjusted when they are loaded.
Depending on the model, your appliance is provided with one of the
following types of upper basket:
Type 1
Raising/Lowering the Upper Basket
1. Pull out the upper basket complete-
ly.
2. Raise the upper basket as far as it
will go and then lower it vertically.
The upper basket will latch into the
lower or the upper position.
Type 2
Raising / Lowering the upper basket
1. Pull out the upper basket complete-
ly.
2. Holding the upper basket by the
handle, raise it as far as it will go
and then lower it vertically.
The upper basket will latch into the
lower or the upper position.
16
Adding Detergent
Detergents remove the dirt from
dishes and cutlery.
The detergent must be added before
the cycle starts.
1 Only use detergent intended for do-
mestic dishwashers.
The detergent compartment is lo-
cated on the inside of the door.
1. If the lid is closed:
Press the release button.
The lid will spring open.
2. Place the detergent in the detergent
dispenser. The markings indicate the
dosing levels for powder detergents:
“20/30” corresponds to approx.
20/30 ml of detergent.
Follow the manufacturer’s instructions with regard to dosing and
storage.
3. Close the lid and press until it locks
into place.
3 In the case of very heavily soiled
dishes, fill the adjoining compartment (1) with additional detergent.
This detergent comes into use during the pre-wash cycle.
17
Concentrated detergents
Today’s detergents for dishwashers are almost exclusively low-alkaline
concentrated detergents with natural enzymes in tablet or powder
form.
2 Using 50°C dishwashing cycles in conjunction with these concentrated
detergents reduces pollution and is good for your dishes, as these dishwashing cycles are specially matched to the dirt-dissolving properties
of the enzymes in concentrated detergents. It is for this reason that using 50 °C dishwashing cycles in conjunction with concentrated detergents can achieve the same cleaning results that can otherwise only be
achieved using 65 °C cycles.
Detergent tablets
3 Detergent tablets from different manufacturers dissolve at different
rates. For this reason, some detergent tablets do not attain their full
cleaning power during short cycles. Therefore please use dishwashing
cycles with pre-wash when using detergent tablets.
Using 3in1 detergents
These products are detergents with a combined cleaning, rinsing and
salt function.
When the 3in1 function is activated,
– the addition of special salt and rinse aid from the respective dispenser
is prevented.
– If the salt and rinse aid dispensers are empty, this is not indicated.
– The dishwashing cycles can be up to 30 minutes longer.
3 If you want to use 3in1 detergents, check whether these detergents are
suitable for your water hardness. (Follow the manufacturer’s instructions.)
If you want to use 3in1 products
1. Press the ON/OFF button.
3 If indicators for the programme buttons are lit, a dishwashing cycle is
activated. The cycle must be deactivated:
Press function buttons 2 and 3 simultaneously for approx. 2 seconds.
All additional wash programme button indicators will go out.
2. Press function buttons 2 and 3 simultaneously and keep them pressed.
The LED indicators for function buttons 1 to 4 will flash.
18
3. Press function button 4.
The 3IN1 indicator indicates the current setting:
Indicator 3 IN1 is lit 3 in 1 function activated
Indicator 3IN1 is not lit
3 in 1 function not activated
(factory setting).
4. Pressing function button 4 changes the setting.
5. If the 3IN1 indicator is indicating the desired setting, press the ON/
OFF button. The setting is now saved.
Before the start of the dishwashing cycle put 3in1 detergent in the de-
tergent dispenser.
3 As the rinse aid inflow is automatically switched off when the 3in1
function is activated, it may come about because of the different quality standards in the 3in1 detergent, that the dishes do not dry sufficiently.
If this happens, proceed as follows (see section “Adding rinse aid”):
• Fill up the dispenser (if this is empty) with rinse aid.
• Set rinse aid dosage to “2” mechanically.
• Activate rinse aid inflow.
If you do not want to use 3in1 products any more
If you want to stop using 3in1 products, please do the following:
• Deactivate the 3in1 function.
• Fill up the dispensers for salt and rinse aid again.
• Switch the water softener to the highest setting and perform up to
three normal cycles without loading any dishes.
• Then set the water softener to the water hardness in your area.
If you want to use 4in1 products
When using "4 in 1" detergents that integrate also anti- glass corrosion
agent into "3 in 1" formula, please follow the same indication as given
for "3 in 1" detergents.
19
Selecting the dishwashing cycle (Cycle Table)
Dishwashing-
cycle
AUTOMATIC
(50° - 65°)
30 MIN.
3)
(60)
Suitable
Dinner service
2)
and cookware
Dishes, excluding
saucepans
for:
Type of
soiling
normally soiled,
dried-on food remains
just used, lightly to
normally soiled
Programme
sequence
Pre-wash
Main wash
Intermediate rinse
• •
1 to 2x
- • - • -
Final rinse
• •
Consumption
values
Drying
Length (minutes)
Energy (kWh)
90 - 110
1,0 - 1,5
30
0,8
1)
heavily soiled,
INTENSIV
CARE 70°
Dinner service
4)
and cookware
dried-on food remains, in particular
protein and starch
• •
2x
• •
1,8 - 2,0
120 - 130
Dinner service
and cookware,
ECO 50°
5)
temperature-sensitive crockery
normally soiled • • • • •
130 - 160
0,95 - 1,05
Dessert dishes
and coffee service, delicate
lightly soiled - •
2x
• •
73
0,9
glassware
1) The consumption values were obtained under standardised conditions. They depend on how
full the baskets for the dishes are. Variations are therefore possible in practice.
2) When using this cycle the degree of water clouding determines the amount of soiling on the
dishes. The length of the cycle and water and energy consumption can vary greatly – depending upon the load and how dirty the dishes are. Depending upon the soiling, the temperature of the water will be automatically adjusted to between 50°C and 65°C.
3) When using this cycle, only load the dishwasher half full.
4) During the final rinse, the temperature is increased to 68° for 10 minutes to sanitize e.g. plastic chopping boards or jam jars.
5) Test programme for Test Institutes
Water (litres)
13 - 25
9
23 - 25
13 - 15
15
20
Selecting a programme
When your dishes look like this, select:
an intensive programme.
a normal or energy-saving programme.
a short programme (e.g. 30 minute
programme).
21
Starting a Dishwashing Cycle
1. Check that the spray arms can turn freely.
2. Turn the water tap on fully.
3. Close the door.
4. Press the ON/OFF button.
5. Select the desired cycle.
The programme indicator comes on. The remaining time expected for
the cycle will be shown in the multi-display.
The selected cycle will begin after approximately 3 seconds.
3 During the dishwashing cycle, the remaining time shown in the multi-
display may be adjusted according to the size of the load, degree of
soiling, etc.
Interrupting or Cancelling a dishwashing cycle
Interrupt a dishwashing cycle that is in progress if it is absolutely necessary.
Interrupting the dishwashing programme by opening the dishwasher door
1 Hot steam may escape when the door is opened. There is a risk of scald-
ing.
1. Open the door carefully. The dishwashing cycle will stop.
2. Close the door. The cycle will continue.
Cancelling the dishwashing cycle
1. Press function buttons 2 and 3 and keep them pressed.
The programme display for the current cycle will flash for several seconds and then go out.
2. Release the function buttons. The dishwashing cycle has been cancelled.
3. If you want to start a new cycle, check whether there is any detergent
in the dispenser.
3 Turning off the dishwasher will only interrupt a selected dishwashing
cycle, not cancel it. The cycle will recommence after turning the dishwasher back on again.
22
Setting the Delay Timer
3 With the delay timer you can delay the start of a dishwashing cycle for
between 1 and 19 hours.
1. Press the Delay Timer button repeatedly until the multi-display shows
the desired time delay, for example 12h, if the cycle is to start in
12 hours. The Delay Timer indicator is illuminated.
2. Select dishwashing cycle.
3. The time remaining to the start of the cycle is continuously displayed
(e. g. 12h, 11h, 10h, … 1h etc.).
To change the time delay:
As long as the cycle has not yet started, you can still change the setting
by pressing the DELAY TIMER button.
Cancelling the time delay:
Press the Delay Timer button repeatedly until the length of the selected
cycle appears in the multi-display. The selected dishwashing cycle will
begin immediately.
To change a dishwashing cycle
As long as the cycle has not yet started, you can still change the dishwashing cycle. First cancel the dishwashing cycle, then re-set the time
delay, lastly select the new dishwashing cycle.
Switching Off the dishwasher
Do not switch off the dishwasher until the multi-display indicates “0”
for the remaining cycle time.
With some dishwashing cycles, the drying fan continues to run even after the end of the cycle.
1. Press the ON/OFF button. All display indicators will go out.
2. Turn off the water tap.
1 Carefully open the door. Hot steam may escape.
• Hot dishes are sensitive to knocks. Therefore leave the dishes to cool
for about 15 minutes before removing them. You also get a better
drying result.
• Dishes dry more quickly if you open the door for a moment after the
cycle has ended and then leave it slightly open.
23
Removing the Dishes
3 It is normal for the inner door and the dispensers to be damp.
• Empty the lower basket first, then the upper basket. This way you
avoid dripping water from the upper basket onto dishes in the lower
basket.
Care and cleaning
1
Do not use furniture care products or aggressive cleaners.
• When necessary, clean the dishwasher’s controls with a soft cloth.
• Occasionally check the internal dispensers, door seal and water inlet
filter (if fitted) for dirt and clean them, if necessary.
Cleaning the filters
3 The filters must be regularly checked
and cleaned. Dirty filters will spoil the
wash results.
1. Open the door and remove the lower
basket.
2. Turn the handle about ¼ of a turn
anticlockwise (A) and remove the filter system (B).
3. Grasp the grip hole on the fine filter
(1) and remove it from the micro-filter (2).
4. Clean all filters thoroughly under
running water.
24
5. Remove the flat filter (3) from the
base of the washing compartment
and clean both surfaces thoroughly.
6. Re-insert the flat filter.
7. Place the fine filter in the micro-fil-
ter and fit the two together.
8. Insert the filter system in place and
lock it by turning the handle clockwise as far as it will go. Ensure that
the flat filter does not protrude
above the base of the washing compartment.
1 Under no circumstances may the dishwasher be used without its filters.
Cleaning the spray arm jets
Regularly check the jets in the spray
arms for blockages. When cleaning is
necessary, remove spray arm from the
fixture and clean jets with a pointed
object (wire or needle). Then rinse out
the spray arm using a strong jet of
water.
3 Do not damage the jet opening.
Upper basket spray arm
1. To remove upper basket spray arm,
tilt it down hard.
2. Clean spray arms jets.
25
3. Place cleaned upper basket spray arm
back in position against the connecting piece: press the two together
firmly, until you feel them snap into
place.
Bottom spray arm
1. To remove bottom spray arm, pull it
upwards out of its catch.
2. Clean spray arm jets.
3. Place bottom spray arm back in posi-
tion against connecting piece and
press down firmly, until you feel it
snap into place.
26
What to do if...
Remedying small malfunctions
If one of the following fault codes is displayed in the multi-display during operation:
– Fault codeÅ10 (Problems with water inlet),
– Fault codeÅ20 (Problems with water drainage),
please have a look at the following table.
When the fault is remedied, press the button for the cycle that has
started. The cycle will continue.
With other fault codes (“Å ” followed by a number):
– Abort the dishwashing cycle.
– Switch the appliance off and on again.
– Re-set the dishwashing cycle.
If the fault is displayed again, please contact your local Service Force
Centre and inform them of the fault code.
Malfunction Possible cause Remedy
The cycle indicator for the
selected dishwashing cycle
is flashing:
fault code
played in the multi-display:
(Problems with water inlet)
The cycle indicator for the
selected dishwashing cycle
is flashing,
fault code
played in the multi-display.
(Problems with water
drainage)
Å10 is dis-
Å20 is dis-
Water tap is blocked with
limescale or faulty.
The tap is turned off. Turn the tap on.
The filter (where present) in
the threaded hose fitting
on the tap is blocked.
Filters in the base of the
dishwasher compartment
are blocked.
Water inlet hose
has not been correctly positioned.
The sink spigot connection
is blocked.
Water drain hose
has not been correctly positioned.
Check the water tap and
have it repaired if necessary.
Clean the filter in the
threaded hose fitting.
Cancel the dishwashing cycle (see chapter: Starting a
dishwashing cycle),
clean filters (see chapter:
Cleaning the filters),
then start the dishwashing
cycle again.
Check the position of the
hose.
Clean the sink spigot outlet.
Check the position of the
hose.
27
Malfunction Possible cause Remedy
Fault code Å30 is dis-
played in the multi-display.
The cycle is not starting.
The anti-flood system has
been triggered.
The mains plug is not
plugged in.
A fuse in the house’s wiring
system is defective.
For dishwasher models with
a delay start timer:
A start time has been selected.
First shut off the water tap,
then switch off the appliance and contact the Customer Care Department.
Plug in mains plug.
Replace fuse.
If the dishes are to be
washed immediately, cancel
the delay start.
The dishwashing compartment is made from rustfree stainless steel. Rust
spots in the dishwashing
Rust spots are visible in
the dishwashing compartment.
compartment are due to
rust particles from external
sources (rust particles from
water pipes, pans, cutlery,
Only wash cutlery, dishes
and pans that are suitable
for dishwasher use.
etc.). Remove such spots
with a commercially-available stainless steel cleaning product.
Decalcify appliance with
commercially available
agents for cleaning dishA whistling noise can be
heard when washing dishes.
The whistling is not a cause
for concern.
washers.
If the noises can still be
heard after decalcifying the
machine, use a different
brand of detergent for
washing cutlery and dishes.
28
If the Dishwashing Results are not Satisfactory
The dishes are still dirty.
• The wrong dishwashing cycle was selected.
• The dishes were loaded is such a way that the dishwashing water did
not reach all items. The baskets for the dishes must not be overloaded.
• The filters in the base of the washing compartment are dirty or incorrectly positioned.
• Good quality detergent was not used, or too little was used.
• In the case of scale deposits on the dishes: The dishwasher salt dis-
penser is empty or the water softening system has been incorrectly
set.
• The drain hose is incorrectly positioned.
• Pollutants from the water in the dishwasher can block the jets in the
spray arms. You have the option of removing the spray arms from
their fixture for cleaning (see section “Care and Cleaning”).
The dishes do not dry and are not shining.
• Poor quality rinse aid was used.
• The rinse aid dispenser is empty.
There are smears, streaks, milky spots or a shiny bluish coating on
glasses and dishes.
• Lower rinse aid dosage.
There are dried water drops on the glasses and dishes.
• Increase rinse aid dosage.
• The detergent may be the cause. Contact the detergent manufactur-
er's customer advice centre.
Glass corrosion
• Contact the detergent manufacturer's customer advice centre.
29
Disposal
Packaging material
2
The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<,
>PS<, etc. Please dispose of the packaging materials in the appropriate
container at your local waste disposal facilities.
2 Old appliance
The symbol
product may not be treated as household waste. Instead it shall be
handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you
purchased the product.
W on the product or on its packaging indicates that this
1 Warning! When your appliance has finished its working life, remove
the plug from the socket. Cut off the cable and plug and dispose of
them.
Break the door lock so that the door no longer shuts. This prevents children from trapping themselves inside and endangering their lives.
30
Technical Data
Capacity: 12 place settings including serving dishes
Permitted water pressure:
Electrical connection: 230 V, 13 A, also see the rating plate on the right-hand side
Total output 2250 W
Dishwashers that can be integrated and built-in
Dimensions: 820 - 880 x 596 x 570 (H x W x D in mm)
Max. weight: 50 kg
1-10 bar (=10-100 N/cm2 = 0.1-1.0 MPa)
of the dishwasher’s interior door .
5 This appliance conforms with the following EU Directives:
– 73/23/EEC dated 19.02.1973 Low Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending
Directive 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE Marking Directive
31
Notes for Test Institutes
Testing in accordance with EN 60704 must be carried out with the
appliance fully loaded and using the test cycle (see “Cycle Table”).
Tests in accordance with EN 50242 must be carried out when the salt
dispenser in the water softener and the rinse aid dispenser have been
filled with salt and rinse aid respectively, and using the test cycle (see
“Cycle Table”).
Full load:
12 place settings
including serving
dishes
Amount of detergent required: 5g + 25g (Type B) 20g (Type B)
Rinse aid setting: 4 (Type III) 4 (Type III)
Example loading arrangements:
Upper basket
*) If there are cup racks in place on the lefthand side or the cutlery tray is in place, re-
move them.
*)
Half load:
6 place settings including
serving dishes, leaving alternate positions in the rack free
32
Lower basket with cutlery basket
*)
Cutlery basket
*) If necessary, you can remove the cup racks on the left-hand side and/or the beer
glass holder.
33
Installation and connection instructions
1 Safety Information for the Installation
• Only transport the dishwasher in an upright position, otherwise salt
water may run out.
• Before using the dishwasher for the first time, check for any damage
caused in transport. Do not under any circumstances connect an appliance that is damaged. In the case of damage, please contact your
supplier.
• Never use the dishwasher if the mains cable, water inlet or drain hose
are damaged; or if the control panel, work top or plinth area are
damaged such that the inside of the appliance is freely accessible.
• Always plug the mains plug into a correctly installed shockproof
socket.
• Permanent connection: a permanent connection must only be installed by a trained electrician.
• Prior to using the appliance for the first time, ensure that the rated
voltage and type of supply on the rating plate match that of the supply where the appliance is to be installed. The fuse rating is also to be
found on the rating plate.
• Multi-way plugs / connectors and extension cables must not be used.
This could constitute a fire hazard through overheating.
• The dishwasher’s cable must only be replaced by a Service Force Engineer.
• A water inlet hose with safety valve must only be replaced by a Service Force Engineer.
34
Installing the Dishwasher
• The dishwasher must be installed on a firm floor and adjusted to ensure that it is stable and level in all directions.
• To compensate for unevenness in
the floor and to match the height
of the appliance to that of surrounding units, extend the threaded feet using a screwdriver.
• Adjust the rear feet of the appliance using a screwdriver from the
front of the appliance. (See installation instructions.)
• The drain hose, inlet hose and
mains cable must be laid so that
they are able to move freely within
the plinth area, and so that they
are not kinked or crushed when the dishwasher is in position.
• The dishwasher must also be screwed tightly to the work surface or to
the adjoining units. This is essential to ensure the dishwasher does
not tip up.
Dishwashers That Can be Integrated
(see installation template supplied)
3 The door of the appliance can be fitted with a wooden door/cupboard
door with the following dimensions:
Width: 591 – 594 mm
Depth: 16 – 24 mm
Height:
(variable)
Weight: max. 8 kg
dependent on – Recess height
– Plinth height
– Adjusting the dishwasher to match the height of
adjoining units
The exact height must be measured at the place of installation from the adjoining units.
35
Connecting the dishwasher
Connecting to the water supply
• The dishwasher can be connected to cold and hot water supplies up
to max. 60°C.
• The dishwasher must not be connected to open hot water appliances
or instantaneous water heaters.
Permitted water pressure
Lowest permitted water pressure:
1 bar (=10 N/cm2 =100 kPa)
Highest permitted water pressure:
10 bar (=100 N/cm2 =1 MPa)
Consult your plumber if the water pressure is less than 1 bar.
If the water pressure is greater than 10
bar, a pressure reduction valve must be
used (available from your dealer).
Connecting the inlet hose
1 The water inlet hose must not be kinked, crushed or entangled when it
is being connected.
Connect the threaded hose fitting (ISO 228-1:2000) on the water inlet
hose to a tap with an external thread (¾ inch). The inlet hose is fitted
with either a plastic or a metal nut:
– Only tighten the nut hand tight.
Then do a visual check for water tightness. (Make sure that the tap is
not dripping.)
3 So that access to the tap in the kitchen is not restricted by the use of
the dishwasher, we recommend installing an additional tap, or fitting a
T-branch to the existing tap.
If you need a longer water inlet hose than that supplied, the following
VDE-approved complete hose sets are to be used. These are available
from your local service centre.
36
Water drainage
Drain hose
1 The drain hose must not be kinked, crushed or entangled.
Connecting the drain hose:
– Maximum permitted height: 1 metre.
– Minimum required height: 40 cm above the bottom edge of the ap-
pliance.
Extension hoses
• Extension hoses are available from
your local Service Force Centre. To
ensure that the function of the appliance is not impeded, the internal
diameter of extension hoses must
be 19 mm.
• Extension hoses must not be laid
more than a maximum distance of
4 metres horizontally; the maximum permitted height for the connection for the drain hose is then
85 cm.
Sink outlet connection
• The outlet of the drain hose (ø 19 mm) fits all commonly available
sink outlet types. The outer diameter of the sink outlet connection
must be at least 15 mm.
• The drain hose must be fixed to the sink outlet connection using the
hose clamp supplied.
Water drainage if the dishwasher is built-in at high level
If the dishwasher is installed at a high level, and the drain hose connection is less than 30 cm from the lower edge of the appliance, adapter
kit ET 111099520 must be fitted by your local Service Force Centre.
Anti-flood system
For protection from water damage, the dishwasher is equipped with a
anti-flood system.
In the event of a fault, the safety valve in the water inlet hose immediately interrupts the supply of water to the appliance and the drain
pump is activated. In this way water can neither escape nor overflow.
The remaining water in the appliance is automatically pumped out.
37
Electrical Connection
G
Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
1 WARNING - This appliance must be earthed.
The manufacturer declines any responsibility should these safety
measures not be observed.
Before switching on make sure the electricity supply voltage is the
same as that indicated on the appliance rating plate.
To isolate the dishwasher from the mains, remove the mains plug.
Important: The plug must still be accessible after the appliance has
been installed.
Changing a fuse
The appliance is supplied with a 13amp plug fitted. In the event of having to change the fuse in the plug supplied, a 13amp ASTA approved
(BS 1363A) fuse must be used.
Should the plug need to be replaced
for any reason, proceed as described
below.
The wires on the mains lead are coloured in accordance with the following code.
Green and Yellow: Earth
Blue: Neutral
Brown: Live
Blue
reen & Yellow
Brown
Cord Clamp
• The wire coloured green and yellow must be connected to the terminal marked with the letter “E“ or by the earth symbol E or coloured
green and yellow.
• The wire coloured blue must be connected to the terminal “N“ or coloured black.
• The wire coloured brown must be connected to the terminal marked
“L“ or coloured red.
• Upon completion there must be no cut, or stray strands of wire
present and the cord clamp must be secure over the outer sheath.
1 WARNING! A cut off plug inserted into a 13 amp socket is a seri-
ous safety (shock) hazard. Ensure that, if it is necessary to cut off
the plug, it is disposed of safely and not retained.
38
Connecting systems
The water inlet hose, drain hose and the mains cable must all be connected to the side of the dishwasher as there is no space for them behind the appliance.
2 connection pieces 45° or
straight, outer ø 19 mm,
water-
inlet
length 30 mm
mains
cable
waterdrainage
double valve water-
drainage
mains socket mains cable
water
inlet
39
Warranty conditions
Great Britain
Standard guarantee conditions
We, AEG, undertake that if within 12 months of the date of the purchase this AEG appliance or
any part thereof is proved to be defective by reason only of faulty workmanship or materials, we
will, at our discretion repair or replace the same FREE OF CHARGE for labour, materials or carriage
on condition that:
• The appliance has been correctly installed and used only on the electricity or gas supply stated
on the rating plate.
• The appliance has been used for normal domestic purposes only, and in accordance with the
manufacturer's operating and maintenance instructions.
• The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any
person not authorised by us.
• All service work under this guarantee must be undertaken by a Service Force Centre. Any appliance or defective part replaced shall become the Company's property.
• This guarantee is in addition to your statutory and other legal rights.
• Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available
outside these hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
• Damage or calls resulting from transportation, improper use or neglect, the replacement of any
light bulbs or removable parts of glass or plastic.
• Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the United Kingdom.
• Appliances found to be in use within a commercial environment, plus those which are subject
to rental agreements.
• Products of AEG manufacture which are not marketed by AEG.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to
your new home subject to the following qualifications:
• The guarantee starts from the date you first purchased your product.
• The guarantee is for the same period and to the same extent for labour and parts as exists in
the new country of use for this brand or range of products.
• This guarantee relates to you and cannot be transferred to another user.
• Your new home is within the European Community (EC) or European Free Trade Area.
• The product is installed and used in accordance with our instructions and is only used domesti-
cally, i.e. a normal household.
• The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new home. They will then ensure that the local Service Organisation is aware of your
move and able to look after you and your appliances.
France Senlis +33 (0) 3 44 62 29 29
Germany Nürnberg +49 (0) 800 234 7378
Italy Pordenone +39 (0) 800 117511
Sweden Stockholm +46 (0) 8 672 5360
UK Luton +44 (0) 8705 350 350
40
414243
Service and Spare Parts
If the event of your appliance requiring service, or if you wish to purchase spare parts, please contact Service Force by telephoning:
0870 5 929 929
Your telephone call will be automatically routed to the Service Force
Centre covering your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit the website at
www. serviceforce.co.uk
Before calling out an engineer, please ensure you have read the details
under the heading „What to do if...“
When you contact the Service Force Centre you will need to give the
following details:
1. Your name, address and post code.
2. Your telephone number.
3. Clear and concise details of the fault.
4. The model and serial number of the appliance (found on the rating
plate)
5. The purchase date.
Please note that a valid purchase receipt or guarantee documentation is
required for in-guarantee service
calls.
Customer Care
For general enquiries concerning
your AEG-Electrolux appliance, or
for further information on AEGElectrolux products please contact
our Customer Care Department by
letter or telephone at the address below or visit our website at
www.aeg.co.uk.
Customer Care Department
Major Appliances
AEG-Electrolux
Domestic Appliances
Addington Way
Luton
Bedfordshire, LU4 9QQ
Tel: 08705 350350 (*)
For Customer Service in the Republic
of Ireland please contact us at the ad-
dress below:
AEG/ Electrolux Group (Ire) Ltd
Long Mile Road/ Dublin 12
Republic of Ireland
Tel: +353 (0) 1 4090754
Email: service.eid@electrolux.ie
(*) Calls may be recorded for training purposes
From the Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor
use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines,
vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more
than 150 countries around the world.
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg-electrolux.de
© Copyright by AEG
822 961 338-00-061005-07
Subject to change without notice
Loading...
