AEG-Electrolux FAV34300W User Manual
ÖKO_FAVORIT 34300
Dishwasher
Lavavajillas
Operating instructions
Instrucciones de uso
Dear customer!
Please read these user instructions carefully.
Above all please observe the safety instructions on the first few pages
of these user instructions! Please keep these user instructions for later
reference. Pass them on to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, caution!,
Important!) are used to highlight instructions that are important for
your safety or for the function of the appliance. It is imperative that
these instructions are observed.
This symbol or numbered instruction steps lead you step by step
through the operation of the appliance.
Next to this symbol you receive additional information and practical
tips on using the appliance.
Tips and instructions for the economical and environmentally
conscious use of the appliance are marked with a clover leaf.
In the event of a malfunction, these operating instructions contain
information on how to rectify faults yourself, see "What to do, when..."
section.
If these instructions are insufficient, please contact your nearest
customer service centre.
In the case of technical problems, our customer service organisation is
available to provide you with assistance at any time.
Printed on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly...
2
Contents
Safety instructions 4
Disposing of packaging and old machine 6
Disposing of the packaging 6
Disposing of your old machine 6
Economical and ecological dishwashing 7
Description of the appliance 8
The inside of the appliance 8
Control panel 9
Before using your dishwasher for the first time 10
Setting the water hardness range 10
Filling with special salt 12
The rinse aid 13
Loading cutlery and dishes 15
The lower basket 16
The upper basket 16
Cutlery basket 17
Use of detergent 18
Phoshate free detergents with enzymes 19
Washing programmes 20
Operating instructions 22
Maintenance and cleaning 24
Internal and external cleaning 24
Cleaning the filters 24
What do do, when... 26
Customer service 28
Technical data 29
Hints for test centres 30
Installation 31
Connection instructions 32
Connecting the water supply 32
Water outlet connection 33
Water protection system 35
Electrical connection 35
3
Safety instructions
The safety of AEG electrical appliances conforms to accepted rules of
technology and the Appliance Safety Act. We as manufacturers, however, see
ourselves as being obliged to familiarise you with the following safety
instructions.
Using your dishwasher for its intended purpose
● Only use your dishwasher for machine washing of household crockery. If
your machine is misused or used for any purposes other than that
for which it is intended, the manufacturer cannot be held liable for any
damage caused.
● For safety reasons, you should not convert or modify your dishwasher in
any way.
Before using your dishwasher for the first time
● Check your dishwasher for any transport damage. Never connect a
damaged machine. If your dishwasher is damaged, you should contact
your supplier.
● Your dishwasher must be correctly installed and connected. Please read
the section on "Installation" to make sure you know all about this.
● Before using your dishwasher for the first time, do not forget that the
nominal voltage and current type indicated on the rating plate of your
machine must be the same as the nominal voltage and current type at the
installation site. The necessary electrical fusing is also given on the rating
plate.
Child safety
● Packaging parts (e.g. foils, styrene foam) may be dangerous for
children,who could even be suffocated! You should therefore keep all
packaging well away from children.
● Children may not recognise the dangers of improper use of electrical
appliances. You should therefore ensure proper supervision during
operation and not allow your children to play with your dishwasher.
● Detergents may have a caustic effect on eyes, mouth and throat and may
even cause suffocation! Keep all detergents in a safe place out of
children’s reach.
4
● The water in your dishwasher should not be used for drinking. Detergent
residues may still be present in your machine. Make sure you do not
splash these caustic residues onto your skin or suffocate yourself! Keep
children well away from your dishwasher when its door is open.
Your dishwasher in day-to-day use
● Never operate your dishwasher if the electrical supply lead, supply or
drainhose, control panel, worktop or plinth are damaged.
● If there is a fault, first turn the water tap off. Then switch off your
machine and pull the plug out of the socket. If there is a fixed
connection, switch off or unscrew the fuse(s).
● Never pull the plug out of the socket by the cable - always hold the plug.
● Dishwasher repairs should only be performed by trained personnel.
Improper repairs may seriously endanger the user. If your dishwasher
needs to be repaired, you should contact our service centre or your
retailer.
● Never place any solvents in your dishwasher or you may cause an
explosion!
● Do not rest or sit on the open door or the machine could tilt.
● Before using special dishwasher salt, detergent or rinse-aid, make sure
that the manufacturer of these products expressly specifies their use in
domestic dishwashers.
● Always turn off the water tap when your dishwasher is left unattended
for any length of time, e.g. when you are away on holiday.
● Only transport the dishwasher in an upright position. Tipping it upside
down during transport could cause salty water to leak into the internal
compartment and lead to the formation of rust.
5
Disposing of packaging and old machine
Disposing of the packaging
Our dishwashers require effective protective packaging in transit, though we
always confine ourselves to what is absolutely necessary.
Warning! Packaging parts (e.g. foils, styrene foam) may be
dangerous for children, who could even be suffocated! You
should therefore keep all packaging well away from children.
All packaging materials used are environmentally compatible and reusable.
The cardboard parts are produced from recycled paper, and the wood is
untreated.
The plastics are marked as follows:
>PE< for polyethylene, e.g. packaging foils.
>PS< for polystyrene, e.g. padding (essentially CFC-Free).
>POM< for polyoxymethylene, e.g. plastic clamps.
Give the packaging for reuse to your local recycling centre. Your municipal or
local authority will give you its address.
Disposing of your old machine
When your machine finally reaches the end of its life and you withdraw it
from service, you should render it unserviceable before having it disposed of.
Warning! Children at play could lock themselves in your
machine (and suffocate) or otherwise endanger their lives.
Therefore pull out the main plug and detach and discard the
electrical supply lead.
Disable the door lock so that the door no longer closes.
Marking of plastic parts for graded recycling: all plastic parts in your
machine are marked with internationally standardised abbreviations (e.g.
<PS> for polystyrene). When your machine is disposed of, this enables plastic
waste to be sorted into individual types for environmentally conscious
recycling.
Take your decommissioned machine to your local recycling centre or dealer,
who will take it back from you for a small handling charge.
6
Economical and ecological dishwashing
● Only connect the dishwasher to the hot water supply if your hot water is
not electrically heated.
● Ensure that the water softener is correctly adjusted.
● Do not pre-rinse under running water.
● Select the wash programme to suit the nature and degree of the soiling
on the dishes.
● Do not use more detergent, special salt or rinse aid than is recommended
in these operating instructions and by the manufacturer of the respective
product.
7
Description of the appliance
3
4
5
6
7
8
9
10
IN102
1
2
The inside of the appliance
1. Water hardness adjustment
2. Upper basket stop
3. Upper spray arm
4. Salt container
5. Detergent dispenser
6. Control panel
7. Rinse aid dispenser
8. Filters
9. Lower spray arm
10. Upper basket
8
12 3 4 5 6
Control panel
1. On/Off indicator light
2. On/Off push button
3. Door handle
4. Programme marker
5. Programme selector dial
6. Programme sequence indicator
As the programme progresses, the knob turns, to show the phase in the
wash programme the appliance has reached.
Each phase is indicated with a symbol
Prewash/Rinse and Hold
Wash
Cold rinse
Hot rinse
Drying
9
Before using your dishwasher for the first time
1. Ensure that the electrical and water connections comply with the
installation instructions.
2. Remove all packaging from inside the appliance.
3. Set the water softener.
4. Pour half a litre of water inside the salt container and then fill with salt.
5. Fill the rinse-aid dispenser.
Setting the water hardness range
The dishwasher is equipped with a water softener designed to remove
minerals and salts from the water supply, which would have a detrimental or
adverse effect on the operation of the appliance.
The higher the content of these salts, the harder your water is.
Water hardness is measured in equivalent scales, German and French.
The softener should be adjusted according to the hardness of the water in
your area.
To ensure optimum regeneration of the water softener:
- the water softenening must be set to the local water hardness;
- the dishwasher salt container must always be filled with special salt.
Your local Water Authority can advise you on the hardness of the water in
your area.
The dishwasher is factory set at level 2.
If this level is not suitable for your area the softener should be adjusted.
10
Level
1
2
3
4
5
Water hardness
°dH
(german degrees)
0 - 4
5 - 11
12 - 22
23 - 39
40 - 50
°TH
(french degrees)
0 - 8
9 - 20
21 - 40
41 - 70
71 - 90
Use
of salt
NO
YES
YES
YES
YES
Water
softener
adjustment
-
-
+
-
+
Adjustment
on the
machine
1
1
1
2
2
Level 1
AA01
1
2
AA03
If your water is "level 1" it is already soft and therefore there is no need to
use salt.
Level 2
If your water hardness is "level 2", only regenerating salt will be necessary. It
is not necessary to set the water hardness level on the machine.
Levels 3 and 5 (water softener adjustment)
If your water is level 3 or 5, proceed as follows:
1. slide out the lower basket and unscrew
the cap of the salt container;
2. turn the two-position selector
anticlockwise from position - to
position + with the aid of a blunt
knife or a screwdriver.
Levels 4 and 5 (adjustment on the machine)
If your water is level 4 or 5, open the door
and turn the selector on the upper lefthand corner of the machine from position
1 to 2.
With a water hardness of level 5 both adjustments must be made.
11
